MULTIPLE COMPACT DISC
PLAYER
CDC-9300
Page 2
ELECTRICAL PARTS LIST (CDC-9300)
Ref No. Part No. Description Value Qty Remark
MAIN B'D (4002518400)
C121 3609153120-T CAP MA 0.015UF 100V J 0.015/100(M) 1
C107-108 C120
C165 C169 C194 C198
C128 C131
C141
C137 C139
C204 3509103530-T CAP CE F 0.01UF 50V Z 0.01/50 1
C113 3539223521-A
C116 C134 C136 C166 3609333120-T CAP MA 0.033UF 100V J 0.033/100(M) 5
C197
C199-200
C103-104 3539473531-A CAP CE F 4700PF 50V J AXIAL 4700P 15
C152 C155 C157
C167 C171 C173-174
C177 C179-180 C182
C184 C187
C126 3609473120-T CAP MA 0.047UF 100V 0.047/100 1
C119 3609472120-T CAP MA 0.0047UF 100V J 0.0047/100 1
C123 C127
C168 C195 3509101231-A
C162-163 C188 C193 3509271231-A
C148-149 3509330130-T CAP CE SL 33PF 50V J 33P 2
C158 C160 C189 C192
C159 C161 3539473531-A
C190-191 3509471231-A
C129-130 C140 3509561231-A
D111-115 D117-119 2058304100 DIODE IN4148M 1N4148 8
D101-105 2058100996 DIODE RECTIFIER LT1N4006(4007) 1N4006 5
C115 C138 C202 3409247871-T CAP AF RSG 0.47UF 50V 5 P 0.47/50 3
C112 3409210971-T CAP AF RSG 1UF 50V 5 P 1/50 1
C142 C196 3409210071-T
C114 C145 3409210141-T
C125 3409222071-T CAP AF RSG 22UF 50V 5 P 22/50 1
C109-110 3409222171-T
C101-102
C124 3409233971-T CAP AF RSG 3.3UF 50V 5 P 3.3/50 1
C118 3409247971-T CAP AF RSG 4.7UF 50V 5 P 4.7/50 1
C105-106 C122 3409247071-T
C1 C111 C117 3409247041-T CAP AF RSG 47UF 25V 5 P 47/25 25
C132-133 C135 C143
C146-147 C150 C153-154 C156
C164 C170 C172
C175-176 C178 C181
C183 C185-186 C201
C203
IC110-111 2118012526 IC LM833N NATIONAL LM 833L 2
IC103 IC108 2118012352 IC NJM 4560D JRC NJM4560D 2
R208 R231 3009122973 RES CF 1.2K 1/5W J N 1.2K 2
R101-102 3009101973
R174 R194 R197-199
R202 R216-217 R226
R234-235 R243
R106 R108-109 R115 3009104973 RES CF 100K 1/5W J N 100K 17
R121-122 R132-134
R137-138 R154 R162
R170 R179 R184 R193
R201
R105 3009100973 RES CF 10 1/5W J N 10 1
R144 R2 R149 R158-161 3009103973 RES CF 10K 1/5W J N 10K 14
R172-173 R185
R188-189 R191 R196
R255
R104 R112 R163 R165 3009124973 RES CF 120K 1/5W J N 120K 4
R228 R264 3009123973 RES CF 12K 1/5W J N 12K 2
R192
R200
3609102120-T
3509102530-T CAP MA 0.001UF 100V MINI
3609222120-T CAP MA 0.0022UF 100V J
3539472331-A CAP CE X 4700PF 16V M AXIAL
3609103120-T CAP MA 0.01UF 100V
3609392120-T CAP MA 0.0039UF 100V J
3609104122-T CAP MA 0.1UF 100V J SMALL
3529330311-A CAP CE SL 33PF 50V J AXIAL
3408222241 CAP RSA 2200UF 25V SNAP 16 P
3009121973 RES CF 120 1/5W J N
3009151973 RES CF 150 1/5W J N
CAP CE B 0.001UF 50V J AXIAL 0.001(M) 3
CAP CE F 22000PF 50V Z AXIAL
CAP CE B 100PF 50V K AXIAL
CAP CE B 270PF 50V K AXIAL
CAP CE F 47000PF 50V Z AXIAL
CAP CE B 470PF 50V K AXIAL
CAP CE B 560PF 50V K AXIAL
CAP AF RSG 10UF 50V 5 P
CAP AF RSG 100UF 25V 6 P
CAP AF RSG 220UF 50V SG 10 P
CAP AF RSG 47UF 50V 6 P
RES CF 100 1/5W J N
0.001/50 4
0.0022/100(M) 2
4700P 1
0.01/100(M) 2
22000P 1
0.0039/100(M) 2
0.1/100(M) 2
100P 2
270P 4
33P 4
47000P 2
470P 2
560P 3
10/50 2
100/25 2
220/50 2
2200/25 2
47/50 3
100 13
120 1
150 1
Page 3
R167 3009153973 RES CF 15K 1/5W J N 15K 1
R142 R157 R175 3009102973 RES CF 1K 1/5W J N 1K 8
R180-182 R190 R195
R143 R205 R233 3009105973 RES CF 1M 1/5W J N 1M 3
R156 3009203973 RES CF 20K 1/5W J N 20K 1
R128 R171 R186-187 3009223973 RES CF 22K 1/5W J N 22K 4
R176 R227 3009243973 RES CF 24K 1/5W JN CDC-9300 24K 2
R183 3009274973 RES CF 270K 1/5W J N 270K 1
R214-215 R240-241 3009273973 RES CF 27K 1/5W J N 27K 4
R256-257 3009339973 RES CF 3.3 1/5W JN CDC-9300 3.3 2
R220 3009335973 RES CF 3.3M 1/5W J N 3.3M 1
R110-111 R164 3009362973 RES CF 3.6K 1/5W J N 3.6K 3
R117-118 R120 3009333973 RES CF 33K 1/5W J N 33K 11
R129-131 R145-148
R207 R232 3009391973 RES CF 390 1/5W J N 390 2
R107 R116 3009393973 RES CF 39K 1/5W J N 39K 2
R103 R135 R177-178 3009472973 RES CF 4.7K 1/5W J N 4.7K 4
R139 3009474973 RES CF 470K 1/5W J N 470K 1
R141 R153 R155 R206 3009473973 RES CF 47K 1/5W J N 47K 4
R113-114 R123-124 3009512973 RES CF 5.1K 1/5W J N 5.1K 6
R203 R229
R116 3009332973 RES CF 3.3K 1/5W J N 3.3K 1
R218-219 R221 3009561973 RES CF 560 1/5W J N 560 3
R209 R242 3009682973 RES CF 6.8K 1/5W J N 6.8K 2
R222-225 3009681973 RES CF 680 1/5W J N 680 4
R150-152 3009684973 RES CF 680K 1/5W J N 680K 3
R140 R204 R210-213 3009822973 RES CF 8.2K 1/5W J N 8.2K 11
R230 R236-239
R168-169 3009823973 RES CF 82K 1/5W J N 82K 2
Q126 Q128-Q130 2008610601-T TR NPN 2SD 1302S 2SD 1302S 4
Q106-108 Q123-125
Q102 Q104 Q112 2008609104
Q118 Q120
Q115-116 2028348100-T TR NPN MPSW01A MOTOROLA MSPW 01A 2
Q123-125 2008606104 DEL TR NPN KTC1815Y (KTC3198) KTC 1815Y 3
Q109 Q122 Q127 2008606105-T TR NPN KTA1266-Y-AT TO-92 KTA1266Y 3
Q101 Q103 Q105 Q113 2008209100 MPSA56-AT MPSA 56 6
Q119 Q121
Q114 Q117 2028048100-T TR PNP MPSW51A MOTOROLA MPSW 51A 2
Q110-111 2008600100-T
VR101 VR103-104
VR102
VR105
D107 2058502300 DIODE ZENER UZ-30BM(1N5256B) UZ 30BM 1
D116 2058502043 DIODE ZENER UZ-4.3BM(1N5229B) UZ 4.3BM 1
D108-109 2058502082 DIODE ZENER UZ-8.2BM(1N5237B) UZ 8.2BM 2
D106 2058502091 DIODE ZENER UZ-9.1B(1N5239B) UZ 9.1BM 1
CNT110 4428594902 LA5268/LABO640/2.5MM-02P 5268-02A 1
CNT114
CNT103 4428699140 PLUG 4P PLUG 4P 1
CNT107-A 4428594904 LA5268/LABO640/2.5MM-04P 5268-04A 1
CNT104-105 CNT108 4428594905 LA5268/LABO640/2.5MM-05P 5268-05A 3
CNT106 4428594906 LA5268/LABO640/2.5MM-06P 5268-06A 1
CNT101-102
CNT113 4428699190
IC109 2118060300
IC113 2128000200
IC105 2128130300
IC112 2128820200
IC107 2118001300
IC104 2138322125
IC101 2128611600 IC 7905 COMMON 7905 1
IC102 2128611206 IC 7805 G.S 7805 1
X-TAL101 3908101060
FIP101 2328130523
2008606104 DEL TR NPN KTC1815Y (KTC3198)
MPSA06-AT
TR NPN DTC 144ES
3248322320 RES SEMI RH0615C100223
3248347320 RES RH0615C100473
3248310220 RES SEMI RH0615C100102
4428699030 Header Right Angle 5268-03A
4428699180 PLUG 8P PLUG 8P
PLUG 9P PLUG 9P
IC CXA 1081S SONY CDC-9300
IC YM3433B-D YAMAHA CDC-9300
IC CXD 1167Q SONY CDC-9300
IC SAA 7350GP/M3 CDC-9300
IC CXA1082BS SONY CDC-9300
IC DWP-304C,CXP50116-506Q(CUP)
CRYSTAL 16.934MHZ 49/U 20PF CRYSTAL 16.934MHZ
FIP 11RM8 CDC-9300
KTC 1815Y 6
MPSA 06 5
DTC 144E 2
22KB 3
47KB 1
1KB 1
5268-03A 1
CXA 1081S 1
YM 3433B-D 1
CXD 1167 1
SAA 7350 1
CXA 1082BS 1
DWP 304C 1
FIP 11RM8 1
RCA P.C. B'D (4002518410)
CNT114 4428599030
Header Right Angle 5268-03A
5268-03A 1
SENOR P.C. B'D (4002518420)
CNT107-A 4355933610
CNT107 4428595804
CON ASS'Y 4P TO SENSOR A B'D CON ASS'Y 4P
GIL-S-4P-S2T2-EF CDC-9300 GIL-S-4P-S2T2-EF
2
1
1
1
1
Page 4
5
O
TRANS P.C. B'D (4003319401)
CNT206 4458933108
CON ASS'Y 6P TO MAIN B'D
CON ASS'Y 6P 1
CHUCK MOTOR P.C. B'D (4003319402)
CNT104 4355933510
CON ASS'Y 5P TO MAIN B'D CON ASS'Y 5P
ROULETTE MOTOR P.C. B'D (4003319403)
CNT107 4355933610
CNT201 4428595003 LW5267/LWB0640/2.5MM-03P 5267-3P 1
CON ASS'Y 4P TO SENSOR A B'D CON ASS'Y 4P
L MOTOR P.C. B'D (4003319404)
CNT108 4355933910
CON ASS'Y 5P TO MAIN B'D CON ASS'Y 5P
DISC SENSOR P.C. B'D (4003319406)
CNT201 4355933212
CON ASS'Y 3P TO S MOTOR B'D CON ASS'Y 3P
FUNCTION P.C. B'D (4003319407)
CNT202 4355934112
CON ASS'Y 7P TO FRONT B'D CON ASS'Y 7P
FROUNT P.C. B'D (4003319408)
CNT111 4355933407
CNT202 4428699170
CON ASS'Y 9P TO MAIN B'D CON ASS'Y 9P
GIL-S-7P-S2L2-EF ANGLE CDC9300 GIL-S-7P-S2L2-EF
TIMER S/W P.C. B'D (4003319409)
CNT110 4355934018
CON ASS'Y 2P TO MAIN B'D CON ASS'Y 2P
POWER S/W P.C. B'D (4003319410)
CNT105 4355934227
CON ASS'Y 5P TO MAIN B'D CON ASS'Y 5P
MOTOR P.C. B'D (4003319408)
CNT103 4355933810
CON ASS'Y 4P TO MAIN B'D CON ASS'Y 4P
PICK-UP UNIT
CNT101 4355933710
CNT102 4355934310
CON ASS'Y 8P TO MAIN B'D CON ASS'Y 8P
CON ASS'Y 8P(SILD)TO MAIN B'D CON ASS'Y 8P(SILD)
ASS'Y
TRANS 2828081810
2828082810
2828083810
2828084810
F/Holder 4458999110
4458999110
F101 5508411636 FUSE TS20MM 400MA/250V U/C/S/V FUSE TS20MM 400MA/250V 1
F102 5508410836 FUSE TS20MM 125MA/250V U/C/S/V FUSE TS20MM 125MA/250V 1
(F102) 5508211233
(F102) 5508412434
AC CORD 4308999110 CORD AC POWER SUPPLY DOME CORD AC POWER SUPPLY D
TRANS POWER 110V/220V CDC-9300 TRANS POWER
TRANS POWER 120V CDC-9300 TRANS POWER
TRANS POWER 230V CDC-9300 TRANS POWER
TRANS POWER 240V CDC-9300 TRANS POWER
FUSE CLIP 5*20 FUSE CLIP 5*20
FUSE CLIP 5*20 FUSE CLIP 5*20
FUSE NB 20MM 250MA/250V U/C FUSE NB 20MM 250MA/2
FUSE 218T20MM 1.25A/250V UCSKJ FUSE 218T20MM 1.25A/2
1
1
1
1
1
1
1
1
1
1
1
1
1
시판
1A
1B
1C
4
시판
2A군,B군,C군
시판
시판
1A
1B군,C군
1
`
