Interlogix TX-E401 Specsheet

Intrusion

Garage Door
Tilt Sensor

TX-E Series

OVERVIEW

The TX-E Garage Door Tilt Sensor from Interlogix provides
intrusion detection for garage structures. This sensor can be
mounted on top of any garage door and allows for quick and
easy installation without the need to align a magnet.

The TX-E Series Garage Door Tilt Sensor will transmit an open
and close signal to the panel each time the garage door is
opened or closed. When the alarm panel is armed, if the
garage door opens to a forty-five degree angle, the sensor
goes into an alarm condition that turns on the siren and
initiates a call to the central monitoring station. The TX-E Series
Garage Door Tilt Sensor also features a slow loop response
which eliminates false alarms triggered by garage door
movement due to wind.

Specifications

Compatibility Interlogix Learn-Mode panels and receivers

Frequency 319MHz (Crystal based)

Battery CR123A

Battery Life 5 years, typical

Operating Temperature -22°F (-30°C) to 120°F (49°C)

Operating Humidity 5-95% non condensing

Weight 2.0 oz.

Dimensions (WxHxD) 3.5 x 1.0 x 0.87 in. (8.89 x 2.54 x 2.20 cm)

Color White

Approvals FCC/IC

STA N DAR D FE ATU RES

• Field proven wireless technology

• Case tamper

• Extended operating temperature range

• Slow loop response that eliminates false alarm due to wind

• Replaceable battery with up to 5 years of battery life
(based on usage)

• 2 year warranty

Ordering Information

TX-E401 Garage Door Tilt Sensor

interlogix.com

Specifications subject to change without notice.

© 2016 United Technologies Corporation.

All rights reserved.

All trademarks are the property of their respective owners.

Interlogix is part of UTC Climate, Controls & Security

a unit of United Technologies Corporation.

2016/05 (LI-1705)
