Interlogix S30-1SLC-A-60, S35-2SLC-10, S30-1SLC-A-10, S25-2MLC-2, S20-2MLC-2 User Manual
...
IFS SFP Tranceivers
User Manual
P/N 1069181 • REV 02.00 • ISS 22AUG11
Copyright © 2011 UTC Fire & Security. All rights reserved.
r
Trademarks and
Manufacture
Interlogix, IFS SFP Tranceivers Brand and logo are trademarks of
patents
UTC Fire & Security.
Other trade names used in this document may be trademarks or registered
trademarks of the manufacturers or vendors of the respective products.
UTC Fire & Security Americas Corporation, Inc.
2955 Red Hill Avenue, Costa Mesa, CA 92626-5923, USA
Authorized EU manufacturing representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Version This document applies to IFS SFP Tranceivers version 00.20.
Certification
FCC compliance Class B: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
There is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
• Consult the dealer or an experienced radio/TV technician for help.
European Union
directives
Contact information
Customer support
2004/108/EC (EMC directive): Hereby, UTC Fire & Security declares that this
device is in compliance with the essential requirements and other relevant
provisions of Directive 2004/108/EC
2002/96/EC (WEEE directive): Products marked with this symbol cannot be
disposed of as unsorted municipal waste in the European Union. For proper
recycling, return this product to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at designated collection points. For
more information see: www.recyclethis.info.
www.utcfireandsecurity.com
www.interlogix.com/customer-support
N4131
which the receiver is connected.
or www.interlogix.com
Safety Notices
The fiber optic SFP transceiver modules are equipped with a Class 1 laser, which
emits invisible radiation. Read the following safety warnings carefully.
Class 1 Laser Product
Complies with FDA Regulation 21 CFR 1040.10 and 1040.11
Class 1 radiation is present when the device or system is powered
up. Do not look directly into a laser aperture, as prolonged exposure
may cause eye damage.
Only trained and qualified personnel should be allowed to install or
replace these SFP modules
Content
Overview 1
Checklist 2
Installing an IFS SFP Module 3
Connecting the fiber cable 3
Removing the SFP transceiver 4
SFP Specifications 5
Appendix A 8
Fiber Optical Cable Connection Parameters 8
IFS SFP Tranceivers User Manual i
Overview
Thank you for purchasing an IFS SFP transceiver. The IFS SFP transceiver can
be installed into any IFS network equipment with a 100Base-FX or 1000BaseSX/LX mini-GBIC interface. This user guide provides an overview of the various
IFS SFPs (also known as mini-GBIC) transceiver modules available from
Interlogix. This user guide also provides instructions for installing, connecting and
removing these transceivers. These SFP transceiver modules are hot-pluggable,
which means you can insert and remove these modules into any IFS network
equipment with a mini-GBIC port without interrupting the host system. The IFS
SFP line also features a selection of environmentally hardened SFPs designed
for operating in environments from -40~75 degrees Celsius.
IFS SFP Tranceivers User Manual 1
Checklist
The SFP package should contain the following items:
• The SFP Transceiver Module x1
• This User Manual x1
If any items are missing or damaged, please consult Interlogix or the
dealer/distributor from whom you purchased your SFP transceiver module.
2 IFS SFP Tranceivers User Manual
Installing an IFS SFP Module
This section describes how to insert an IFS SFP transceiver into a mini-GBIC
slot.
The IFS SFP transceivers are hot-pluggable and hot-swappable. You can insert
and remove an IFS SFP transceiver in any IFS network equipment with a miniGBIC port without having to power down the switch or media converter. As
shown in Figure 1.
Figure 1: Inserting an IFS SFP tranceiver
Install the IFS SFP into an IFS network switch or media converter before
connecting a cable coming from another switch, workstation or media converter.
1. Make sure both pieces of network equipment that you are connecting
together are using the same media type SFP. For example: 100Base-FX to
100Base-FX or 1000Base-SX to 1000Base-SX.
2. Check to make sure that the fiber-optic cable type matches the SFP
transceiver model.
• S20 Series and S25 Series optics operate with multimode OM1, OM2
or OM3 fiber. LC type fiber connectors are required.
• S30 Series and S35 Series optics operate with single mode fiber. LC
type fiber connectors are required.
Connecting the fiber cable
1. Insert the duplex LC connector from the network fiber cable into the SFP
transceiver.
IFS SFP Tranceivers User Manual 3
2. Connect the other end of the cable to a device – i.e. switches with an SFP
installed, fiber NIC on a workstation or a Media Converter.
3. Check the LNK/ACT LED of the SFP slot of the switch / converter. Ensure
that the SFP transceiver is operating correctly.
4. Check the link mode of the SFP port to see if there is any link failure. With
some fiber-NICs or Media Converters, setting the link mode to “1000 Force”
or “100 Force” may be needed for proper operation.
Removing the SFP transceiver
1. Make sure there is no network activity by consulting with a network
administrator before removing the SFP or use the switch or media converters
management interface (if available) to disable the port in advance.
2. Gently remove the fiber optic cable connector.
3. Flip the wire handle of the SFP module out to a horizontal position.
4. Pull out the SFP module gently out of the mini-GIBIC slot with the wire
handle.
Figure 2: Pull out the SFP transceiver
2
3
Caution: Never pull out the SFP transceiver module without using the pull
handle or the push bolts on the module. Directly pulling out the SFP module with
force could damage the SFP module and mini-GIBIC slot of the network device.
4 IFS SFP Tranceivers User Manual
SFP Specifications
The IFS SFP transceivers are available in the following models.
Twisted Pair SFP 1000 Base TX GigE
Part # Connector Wire Type Max Distance
S30-RJ RJ 45 Cat 5e 100M (328 ft)
Fast
Ethernet 100 Base FX
Optical
Power
(dBm)
Receiver
Sensitivitiy
(dBm)
Receiver
Sensitivitiy
(dBm)
Receiver
Sensitivitiy
(dBm)
Operating
Temperature
0 to + 50C
(32 to 122F)
-40 to +75C
(-40 to 167F)
Operating
Temperature
0 to + 50C
(32 to 122F)
-40 to +75C
(-40 to 167F)
Operating
Temperature
0 to + 50C
(32 to 122F)
0 to + 50C
(32 to 122F)
Optical
Optical
Wave
Length
1310nm 12 -20 ~ -14 -32
1310nm 12 -20 ~ -14 -32
Wave
Length
1310nm 19 -15 ~ -8 -34
1310nm 19 -15 ~ -8 -34
TX RX
Budget
(dBm)
Optical
Budget
(dBm)
Optical
Budget
(dBm)
Power
(dBm)
Optical
Power
(dBm)
Single
Mode
Single
Mode
Fiber
Type
Single
Mode
Single
Mode
Max
Distance
2km
(1.2mi)
2km
(1.2mi)
Max
Distance
20km
(12mi)
20km
(12mi)
Max
Wave Length
Distance
20km
1310/1550nm 18 -14 ~ -8 -32
(12mi)
20km
1550/1310nm 18 -14 ~ -8 -32
(12mi)
Part #
S20-2MLC2 LC 2 Multimode
S25-2MLC2 LC 2 Multimode
Fast Ethernet 100 Base LX
Part #
S20-2SLC20 LC 2
S25-2SLC20 LC 2
Fast Ethernet 100 Base BX
Part #
S20-1SLC/A-20 LC 1
S25-1SLC/B-20 LC 1
Fiber
Connector
Fiber
Connector
Fiber
Connector
# of
Fibers
# of
Fibers
# of
Fibers
Fiber Type
Fiber Type
IFS SFP Tranceivers User Manual 5
Gigabit Ethernet 1000 Base SX
Part #
Fiber
Connector
# of
Fibers
Fiber Type
S30-2MLC LC 2 Multimode
S35-2MLC LC 2 Multimode
OM1 &
OM2
Max Distance
(720/1800ft)
(720/1800ft)
OM1/OM2
220/550m
220/550m
Optical
Wave
Length
Budget
(dBm)
Power
(dBm)
Sensitivitiy
(dBm)
850nm 7.5 -9.5 ~ -1 -17
850nm 7.5 -14 ~ -8 -17
Operating
Temperature
0 to + 50C
(32 to 122F)
-40 to +75C
(-40 to 167F)
Receiver
Optical
OM1 Multimode fiber @ 200/500MHz-km
OM2 Multimode fiber @ 500.500MHZ-km Laser Rated for GbE LANs
Gigabit Ethernet 1000 Base SX
Part #
Fiber
Connector
# of
Fibers
Fiber Type
OM3
S30-2MLC-2 LC 2 Multimode
Max
Distance
OM3
2km
(1.2mi)
Wave
Length
Optical
Budget
(dBm)
Optical
Power (dBm)
1310nm 10 -9 ~ -1 -19
Receiver
Sensitivitiy
(dBm)
Operating
Temperature
0 to + 50C
(32 to 122F)
OM3 Multimode fiber @ 2000/500MHz-km Optimized got 850nm VCSELs
Gigabit Ethernet 1000 Base LX
Part #
Fiber
Connector
# of
Fibers
S30-2SLC-10 LC 2
S35-2SLC-10 LC 2
S30-2SLC-30 LC 2
S35-2SLC-30 LC 2
Fiber
Type
Single
Mode
Single
Mode
Single
Mode
Single
Mode
Wave
Length
Optical
Budget
(dBm)
Max
Distance
10km
1310nm 18 -9.5 ~ -3 -20
(6.2mi)
10km
1310nm 18 -9.5 ~ -3 -20
(6.2mi)
30km
1310nm 18 -2 ~ +3 -23
(18.6mi)
30km
1310nm 18 -2 ~ +3 -23
(18.6mi)
Optical
Power
(dBm)
Receiver
Sensitivitiy
(dBm)
Operating
Temperature
0 to + 50C
(32 to 122F)
-40 to +75C
(-40 to 167F)
0 to + 50C
(32 to 122F)
-40 to +75C
(-40 to 167F)
6 IFS SFP Tranceivers User Manual
Gigabit Ethernet 1000 Base ZX
Part #
Fiber
Connector
# of
Fibers
S30-2SLC-70 LC 2
S35-SLC-70 LC 2
Fiber
Type
Single
Mode
Single
Mode
Max
Distance
70km
(43mi)
70km
(43mi)
Optical
Wave
Budget
Length
(dBm)
1550nm 19* -15 ~ -8 -34
1550nm 19* -15 ~ -8 -34
Power
(dBm)
Sensitivitiy
(dBm)
Operating
Temperature
0 to + 50C
(32 to 122F)
-40 to +75C
(-40 to 167F)
Receiver
Optical
* Note: High Power Optic. There must be a minimum of 5dB of optical loss to the fiber for proper operation.
Gigabit Ethernet 1000 Base BX
Fiber
Part #
Connector
# of
Fibers
S30-1SLC/A-10 LC 1
S30-1SLC/B-10 LC 1
S30-1SLC/A-20 LC 1
S30-1SLC/B-20 LC 1
Fiber
Type
Single
Mode
Single
Mode
Single
Mode
Single
Mode
Max
Wave Length
Distance
(6.2mi)
(6.2mi)
(12mi)
(12mi)
TX RX
10km
1310/1490nm 11 -9 ~ -3 -20
10km
1490/1310nm 11 -9 ~ -3 -20
20km
1310/1490nm 15 -8 ~ -2 -23
20km
1490/1310nm 15 -8 ~ -2 -23
Optical
Budget
(dBm)
Power
(dBm)
Sensitivitiy
(dBm)
Operating
Temperature
0 to + 50C
(32 to 122F)
0 to + 50C
(32 to 122F)
0 to + 50C
(32 to 122F)
0 to + 50C
(32 to 122F)
Receiver
Optical
Gigabit Ethernet 1000 Base BX
Fiber
Part #
Connector
# of
Fibers
S30-1SLC/A-60 LC 1
S30-1SLC/B-60 LC 1
Fiber
Type
Single
Mode
Single
Mode
Max
Wave Length
Distance
60km
(37mi)
60km
(37mi)
TX RX
1310/1490nm 24 0 ~ +5 -24
1490/1310nm 24 0 ~ +5 -24
Optical
Budget
(dBm)
Power
(dBm)
Sensitivitiy
(dBm)
Operating
Temperature
0 to + 50C
(32 to 122F)
0 to + 50C
(32 to 122F)
Receiver
Optical
* Note: High Power Optic. There must be a minimum of 5dB of optical loss to the fiber for proper operation.
IFS SFP Tranceivers User Manual 7
Appendix A
Fiber Optical Cable Connection Parameters
The wiring details are as below:
• Fiber Optical patch Cables:
Standard Fiber Type Cable Specification
1000Base-SX (850nm) Multi-mode 50/125 ȝm or 62.5/125ȝm
1000Base-LX (1310nm) Single mode 9/125ȝm
1000Base-LX (1550nm) Single mode 9/125ȝm
100Base-FX (1310nm)
Multi-mode 50/125ȝm or 62.5/125ȝm
Single mode 9/125ȝm
8 IFS SFP Tranceivers User Manual
Loading...
