English: Installation Sheet

Description

The Advisor™ family of life-safety protection and comfort management systems detects situations, and provides control and
information for homes and businesses.

This document provides instructions on installing and programming the Advisor Cellular Modem (P/N AV-3G) for use with the
AdvisorOne panel. Note: This instruction sheet does not provide instructions on how to install the antenna. Please refer to the
Advisor One 3G Antenna Installation Sheet (P/N 466-4436) for more information.

The Advisor Cellular Modem provides cellular communication for reporting, 2-way voice, remote maintenance, remote access, and
firmware upgrade management to the Advisor system.

P/N 466-4412 • REV C• 27APR15 1 / 5

Preparation and Installation

Installation

Action

Note

US

Plug the power supply into the outlet and secure with the supplied screw.

Canada

Plug the power supply into the outlet.

Do not use the securement tab and screw.

All Other Installations

Follow regional requirements.

Service Activation:

Before installing the module, it must be activated on an existing dealer account. If you do not have a dealer account, please contact
Interlogix support directly to initiate the account set-up procedure. The activation process automatically activates the module within
a few hours. If you already have a dealer account, you can activate and manage the module via our website address:

https://login.uplink.com/interlogix/login.aspx.

1. Enter your login name and password, then press Login.

2. Press Activate Unit on the left side of the page.

3. Enter the serial number of the module from the label on the front of the unit (10-digit number preceded by S/N) and select
Interlogix SMS Plan from the drop-down menu, then press Activate.

4. Fill out the required information and select reporting options, then press Update.

Preparing to Install the Advisor Cellular Modem:

WARNING: Use caution when installing or removing the Power Supply to an outlet with a metal cover.

1. Depending on the situation, it may be necessary to contact the central monitoring station before starting the installation.

2. If a power supply is present, remove the screw from the securement tab and unplug the power supply.

3. Remove the screw securing the panel chassis. Open the panel by pressing down on the tabs and carefully swing the panel
chassis open.

CAUTION: Use static electricity precautions when handling electronic components.

4. Release the battery strap (H in Figure 6). Disconnect the battery from the battery connector (I in Figure 6) by pressing down on
the wire end of the battery clip. Remove the existing battery.

5. To access the location of the Cellular module, remove the Communication Modules Cover (C in Figure 2) by pulling outward on
the tabs (D in Figures 2 and 6) and then lifting upward when the tabs release.

Installing the Advisor Cellular Modem:

1. Remove adhesive backing from the Ground Shield.

2. Install the Ground Shield (F in Figures 3 and 4) into the CELLULAR module location and on top of the ribbon cable (G in Figure

4), carefully aligning the guide holes in the shield with the with the two guide pins inside the panel.

3. Install SIM card in the Advisor Cellular Modem, if not already installed.

4. Install the Advisor Cellular Modem (A in Figures 1 and 5) on top of the ground shield and ribbon cable, carefully aligning the
header of the Cellular module (B in Figures 1 and 5) with the pins on the circuit board. Press into place.

Note: The Advisor Cellular Modem must be installed in the designated cellular module slot (marked CELLULAR MODEM in the
plastic). DO NOT force the module into place.

5. Before replacing the Communication Modules Cover, remove the breakout (E in Figure 2) for the Advisor Cellular Modem.

6. Reinstall the Communication Modules Cover by pressing the cover down until the tabs (D in Figures 2 and 6) snap into place.

Note: The Communication Modules Cover must be secured for proper operation.

7. Reinstall the battery into the holder.
Note: Do not connect the battery connector and do not secure the battery strap at this time.

8. Refer to the AdvisorOne 3G Antenna Installation Sheet (P/N 466-4436) for installing the antenna.

9. Supply power to the panel as noted in Table 1.

Table 1: Powering the Panel
