64-bit Intel® Xeon® Processor
with 800 MHz System Bus (1 MB
and 2 MB L2 Cache Versions)
Specification Update
June 2006
Notice: The 64-bit Intel
versions) may contain design defects or errors known as errata which may cause the product to
deviate from published specifications. Current characterized errata are documented in this
specification update.
®
Xeon® processor with 800 MHz system bus (1 MB and 2 MB L2 cache
Document Number: 302402-022
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. EXCEPT AS PROVIDED IN INTEL'S TERMS
AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS
OR IMPLIED WARRANTY RELATING TO SALE AND/OR USE OF INTEL PRODUCTS, INCLUDING LIABILITY OR WARRANTIES RELATING TO
FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT, OR OTHER
INTELLECTUAL PROPERTY RIGHT.
Intel products are not intended for use in medical, life saving, life sustaining, critical control or safety systems, or in nuclear facility applications.
Intel may make changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked “reserved” or “un defined.” Intel reserves these for
future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future changes to them.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.
Intel, the Intel
its subsidiaries in the United States and other countries.
Copyright © 2004-2006, Intel Corporation. All rights reserved.
*Other names and brands may be claimed as the property of others.
logo, Pentium, Pentium III Xeon, Celeron, Intel NetBurst and In te l Xeon are trad emarks or re giste red trad emarks of Intel Cor pora tion or
2 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Contents
Revision History .................................................................................................................5
Preface...............................................................................................................................6
Identification Information....................................................................................................7
Summary Table of Changes.............................................................................................12
Errata................................................................................................................................19
Specification Changes......................................................................................................44
Specification Clarifications ...............................................................................................45
Documentation Changes..................................................................................................46
64-bit Intel® Xeon® Processor with 800 MHz System Bus 3
(1 MB and 2 MB L2 Cache Versions) Specification Update
4 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Revision History
Version Description Date
-001 • Initial release of the document. July 2004
-002 • Removed erratum P18 and renumbered existing errata. July 2004
-003 • Added errata S32-S35. Renamed errata numbering from P to S. August 2004
-004 • Removed erratum S29 and renumbered existing errata.
• Added errata S35-S65.
• Added E0 step processor information to Table 1, “Identification
Information”.
• Added new notes to T able2, “64-bit Intel® Xeon® Processor with 800
MHz System Bus (1 MB and 2 MB L2 Cache Versions) Identification
Information” and deleted unnecessary notes.
• Added Table 3, “DP Platform Population Matrix for the 64-bit Intel®
Xeon® Processor with 800 MHz System Bus (1 MB and 2 MB L2
Cache Versions) FC-PGA4 Package”.
-005 • Added errata S66-S73. October 2004
-006 • Updated S-Spec table, code key, and mixed steppings statement to
include Low Voltage Intel® Xeon® processor
• Added errata S74-S75.
-007 • Updated erratum S26. Added errata S76and S77. December 2004
-008 • Added errata S78-S79; added additional text to “Mixed Steppings In
DP Systems” chapter.
-009 • Added 2 MB L2 cache version of the 64-bit Intel® Xeon® processor
with 800 MHz system bus; added errata S80-S81; added S-spec
numbers SL7ZC, SL7ZD, SL7ZE, and SL7ZF to Table 2.
-010 • Updated errata S28 and S53; updated summary table entries for S19
and S43.
-011 • Updated Table 2; added erratum S82; updated plans colu mn for
erratum S27; added Specification Clarification 1.
-012 • Updated steppings affected for erratum S27. May 2005
-013 • Updated Table 2. June 2005
-014 • Added erratum S83. Updated relevant document lists. July 2005
-015 • Updated summary table entry for S19. Added erratum S84. August 2005
-016 • Added errata S85 and S86. Added S-spec numbers to Table 2. Added
R-0 stepping to summary table of changes. Updated summary table
entries. Removed duplicate erratum S33.
-017 • Added erratum S87. Updated letters in Codes used in Summary
Table. Corrected S-spec notes for 3.40 GHz entries.
-018 • Added errata S88 and S89. Updated steppings affected for S22.
Updated Mixed Steppings in DP Systems section.
-019 • Added erratum S90. December 2005
-020 • Added erratum S91. Updated erratum S17. January 2006
-021 • Added erratum S1S and S92. May 2006
-022 • Added erratum S93. June 2006
Revision History
September 2004
November 2004
January 2005
February 2005
March 2005
April 2005
September 2005
October 2005
November 2005
64-bit Intel® Xeon® Processor with 800 MHz System Bus 5
(1 MB and 2 MB L2 Cache Versions) Specification Update
Preface
Preface
This document is an update to the specifications contained in the following documents:
1. 64-bit Intel
Link: http://developer/design/xeon/datashts/306249.htm
2. Intel
Link: http://developer/design/xeon/datashts/302355.htm
This document is intended for hardware system manufacturers and software developers of
applications, operating systems, or tools.
Nomenclature
S-Spec Number is a five-digit code used to identify products. Products are differentiated by their
unique characteristics, e.g., core speed, L2 cache size, package type, etc. as described in the
processor identification information table. Care should be taken to read all notes associated with
each S-Spec number.
Errata are design defects or errors. Errata may cause the processor’s behavior to deviate from
published specifications. Hardware and software designed to be used with any given processor
must assume that all errata documented for that processor are present on all devices unless
otherwise noted.
Specification Changes are modifications to the current published specifications. These changes
will be incorporated in the next release of the specifications.
Specification Clarifications describe a specification in greater detail or further highlight a
specification’s impact to a complex design situation. These clarifications will be incorporated in
the next release of the specifications.
Documentation Changes include typos, errors, or omissions from the current published
specifications. These changes will be incorporated in the next release of the specifications.
®
Xeon® Processor with 2 MB L2 Cache Datasheet (Document Number 306249)
®
Xeon® Processor with 800 MHz System Bus Datasheet (Document Number 302355)
6 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Identification Information
Identification Information
64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Package Markings
(604-pin FC-mPGA4 Package)
Figure 1. Top-Side Processor Marking Example
Intel Confidential
2D Matrix Includes
ATPO and Serial Number
(front end mark)
Pin 1 Indicator
Figure 2. Bottom-Side Marking Example
Pin 1 Indicator
Pin Field
Cavity
with
Components
Text Line1
Text Line2
Text Line3
The 64-bit Intel® Xeon® Processor with 800 MHz System Bus (1 MB and 2 MB L2 cache
versions) can be identified by the following values:
SL7DV
80546KE0461M
FPO – Serial Number
S-Spec
64-bit Intel® Xeon® Processor with 800 MHz System Bus 7
(1 MB and 2 MB L2 Cache Versions) Specification Update
Identification Information
Table 1. Identification Information
1
Family
1111b 0011b 0000b
1111b 0100b 0000b
NOTES:
1. The Family corresponds to bits [11:8] of the EDX regist er after RESE T, bits [11: 8] of the
EAX register after the CPUID instruction is executed with a 1 in the EAX register, and the
generation field of the Device ID registers accessible through Boundary Sca n
2. The Model corresponds to bits [7:4] of the EDX register after RESET, bits [7:4] of the
EAX register after the CPUID instruction is executed with a 1 in the EAX register, and the
model field of the Device ID registers accessible through Boundary Scan.
3. Brand ID returns 0000b, which means that Brand ID is unsupported in this processor.
Model
2
Brand ID
3
Cache and TLB descriptor parameters are provided in the EAX, EBX, ECX and EDX registers
after the CPUID instruction is executed with a 2 in the EAX register. Please refer to the Intel
Processor Identification and the CPUID Instruction Application Note (AP-485) for further
information on the CPUID instruction.
Table 2. 64-bit Intel® Xeon® Processor with 800 MHz System Bus (1 MB and 2 MB L2 Cache
Versions) Identification Information (Sheet 1 of 2)
S-Spec
SL7DV D-0 0F34h 2.80 800 1 MB 01 604-pin micro-PGA with 42.5 x
SL7HF 1
SL7DW D-0 0F34h 3 800 1 MB 01 604-pin micro-PGA with 42.5 x
SL7HG 1
SL7DX D-0 0F34h 3.20 800 1 MB 01 604-pin micro-PGA with 42.5 x
SL7HH 1
SL7DY D-0 0F34h 3.40 800 1 MB 01 604-pin micro-PGA with 42.5 x
SL7HJ 1, 2, 3
SL7DZ D-0 0F34h 3.60 800 1 MB 01 604-pin micro-PGA with 42.5 x
SL7HK 1, 2, 3
SL7PD E-0 0F41h 2.80 800 1 MB 01 604-pin micro-PGA with 42.5 x
SL7TB 1, 4, 6
SL7PE E-0 0F41h 3 800 1 MB 01 604-pin micro-PGA with 42.5 x
SL7TC 1, 4, 6
SL7PF E-0 0F41h 3.20 800 1 MB 01 604-pin micro-PGA with 42.5 x
SL7TD 1, 4, 6
SL7PG E-0 0F41h 3.40 800 1 MB 01 604-pin micro-PGA with 42.5 x
SL7TE 1, 3, 4, 6
SL7PH E-0 0F41h 3.60 800 1 MB 01 604-pin micro-PGA with 42.5 x
SL7VF 1, 2, 3, 4,
SL84B E-0 0F41h 2.80 800 1 MB 01 604-pin micro-PGA with 42.5 x
SL8KN G-1 0F49h 2.80 800 1 MB 01 604-pin micro-PGA with 42.5 x
Core
Stepping
CPUID
Core
Freq
(GHz)
Data Bus
Freq
(MHz)
L2
Cache
Size
Processor
Package
Revision
Package and Revision Notes
42.5 mm FC-PGA4 package
42.5 mm FC-PGA4 package
42.5 mm FC-PGA4 package
2, 3
42.5 mm FC-PGA4 package
2, 3
42.5 mm FC-PGA4 package
4, 6
42.5 mm FC-PGA4 package
4, 6
42.5 mm FC-PGA4 package
4, 6
42.5 mm FC-PGA4 package
3, 4, 6
42.5 mm FC-PGA4 package
2, 3, 4, 6
42.5 mm FC-PGA4 package
6
4, 5, 6
42.5 mm FC-PGA4 package
4, 6
42.5 mm FC-PGA4 package
8 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Identification Information
Table 2. 64-bit Intel® Xeon® Processor with 800 MHz System Bus (1 MB and 2 MB L2 Cache
Versions) Identification Information (Sheet 2 of 2)
S-Spec
SL8KP G-1 0F49h 3 800 1 MB 01 604-pin micro-PGA with 42.5 x
SL8KQ G-1 0F49h 3.20 800 1 MB 01 604-pin micro-PGA with 42.5 x
SL8KR G-1 0F49h 3.40 800 1 MB 01 604-pin micro-PGA with 42.5 x
SL8KS G-1 0F49h 3.60 800 1 MB 01 604-pin micro-PGA with 42.5 x
SL8RW G-1 0F49h 2.80 800 1 MB 01 604-pin micro-PGA with 42.5 x
SL7ZC N-0 0F43h 3.60 800 2 MB 01 604-pin micro-PGA with 42.5 x
SL7ZD N-0 0F43h 3.40 800 2 MB 01 604-pin micro-PGA with 42.5 x
SL7ZE N-0 0F43h 3.20 800 2 MB 01 604-pin micro-PGA with 42.5 x
SL7ZF N-0 0F43h 3 800 2 MB 01 604-pin micro-PGA with 42.5 x
SL8P7 R-0 0F4Ah 2.80 800 2 MB 01 604-pin micro-PGA with 42.5 x
SL8P6 R-0 0F4Ah 3 800 2 MB 01 604-pin micro-PGA with 42.5 x
SL8P5 R-0 0F4Ah 3.20 800 2 MB 01 604-pin micro-PGA with 42.5 x
SL8P4 R-0 0F4Ah 3.40 800 2 MB 01 604-pin micro-PGA with 42.5 x
SL8P3 R-0 0F4Ah 3.60 800 2 MB 01 604-pin micro-PGA with 42.5 x
SL8P2 R-0 0F4Ah 3.80 800 2 MB 01 604-pin micro-PGA with 42.5 x
SL8SV R-0 0F4Ah 3 800 2 MB 01 604-pin micro-PGA with 42.5 x
SL8T3 R-0 0F4Ah 3.20 800 2 MB 01 604-pin micro-PGA with 42.5 x
Core
Stepping
CPUID
Core
Freq
(GHz)
Data Bus
Freq
(MHz)
L2
Cache
Size
Processor
Package
Revision
Package and Revision Notes
42.5 mm FC-PGA4 package
42.5 mm FC-PGA4 package
42.5 mm FC-PGA4 package
42.5 mm FC-PGA4 package
42.5 mm FC-PGA4 package
42.5 mm FC-PGA4 package
42.5 mm FC-PGA4 package
42.5 mm FC-PGA4 package
42.5 mm FC-PGA4 package
42.5 mm FC-PGA4 package
42.5 mm FC-PGA4 package
42.5 mm FC-PGA4 package
42.5 mm FC-PGA4 package
42.5 mm FC-PGA4 package
42.5 mm FC-PGA4 package
42.5 mm FC-PGA4 package
42.5 mm FC-PGA4 package
4, 6
4, 6
3, 4, 6
2, 3, 4, 6
4, 5, 6
2, 3, 4, 6
2, 3, 4, 6
2, 4, 6
2, 4, 6
2, 3, 4, 6
2, 4, 6
2, 4, 6
2, 3, 4, 6
2, 3, 4, 6
2, 3, 4, 6
2, 3, 4, 5,
6
2, 4, 6, 7
NOTES:
1. These are Intel boxed processors.
2. These parts have Thermal Monitor 2 (TM2) feature enabled. For D-0 stepping, TM2 is enabled on 3.40 GHz and above, but it is
NOT supported.
3. These parts are enabled for Enhanced Intel SpeedStep
4. These parts are enabled for Enhanced Halt State (C1E).
5. These parts are LV (low-power) processors.
6. These parts have Execute Disable bit functionality.
7. These parts are MV (mid-power) processors.
64-bit Intel® Xeon® Processor with 800 MHz System Bus 9
(1 MB and 2 MB L2 Cache Versions) Specification Update
®
Technology (EIST).
Identification Information
Mixed Steppings in DP Systems
Intel Corporation fully supports mixed steppings of the 64-bit Intel Xeon processor with 800 MHz
system bus as well as mixed steppings of the 64-bit Intel Xeon processor with 2 MB L2 cache. The
following list and processor matrix describes the requirements to support mixed steppings:
• Mixed steppings are only supported with processors that have identical family numbers as
indicated by the CPUID instruction.
• While Intel has done nothing to specifically prevent processors operating at differing
frequencies from functioning within a multiprocessor system, there may be uncharacterized
errata that exist in such configurations. Intel does not support such configurations. In mixed
stepping systems, all processors must operate at identical frequencies (i.e., the highest
frequency rating commonly supported by all processors).
• While there are no known issues associated with the mixing of processors with differing cache
sizes in a multiprocessor system, and Intel has done nothing to specifically prevent such
system configurations from operating, Intel does not support such configurations since there
may be uncharacterized errata that exist. In mixed stepping systems, all processors must be of
the same cache size.
• While Intel believes that certain customers may wish to perform validation of system
configurations with mixed frequencies, cache sizes or voltages and that those efforts are an
acceptable option to our customers, customers would be fully responsible for the validation of
such configurations.
• Intel requires that the proper microcode update be loaded on each processor operating in a
multiprocessor system. Any processor that does not have the proper microcode update loaded
is considered by Intel to be operating out of specification.
• The workarounds identified in this and following specification updates must be properly
applied to each processor in the system. Certain errata are specific to the multiprocessor
environment. Errata for all processor steppings will affect system performance if not properly
worked around. Also see Also see Table 2 and Table 3 for additional details on which
processors are affected by specific errata.
• In mixed stepping systems, the processor with the lowest feature-set, as determined by the
CPUID Feature Bytes, must be the Bootstrap Processor (BSP). In the event of a tie in
feature-set, the tie should be resolved by selecting the BSP as the processor with the lowest
stepping as determined by the CPUID instruction.
• While there are no known issues associated with the mixing of processors of different
power-optimization segments (i.e. LV or MV) in a multiprocessor system, and Intel has done
nothing to specifically prevent such system configurations from operating, Intel does not
support such configurations since there may be uncharacterized errata that exist. In mixed
stepping systems, all processors must be of the same power-optimization segment.
10 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Identification Information
Table 3. DP Platfor m Population Matrix for the 64-bit Intel® Xeon® Processor with 800 MHz
System Bus (1 MB and 2 MB L2 Cache Versions) FC-PGA4 Package
Processor Signature / Core
Stepping
0F34h / D-0 NI NI NI X X
0F41h / E-0 NI NI NI X X
0F49h / G-1 NI NI NI X X
0F43h / N-0 X X X NI NI
0F4Ah / R-0 X X X NI NI
NOTES:
1. X = Mixing processors of different steppings is not supported. This stepping/frequency is not supported in DP .
2. NI = Currently no known issues associated with mixing these steppings.
3. TBD = No issues are expected, however further investigation is required to fully validate this DP solution.
0F34h / D-0 0F41h / E-0 0F49h / G-1 0F43h / N-0 0F4Ah / R-0
64-bit Intel® Xeon® Processor with 800 MHz System Bus 11
(1 MB and 2 MB L2 Cache Versions) Specification Update
Summary Table of Changes
Summary Table of Changes
The following table indicates the Errata, Documentation Changes, Specification Clarifications, or
Specification Changes that apply to Intel processors. Intel intends to fix some of the errata in a
future stepping of the component, and to account for the other outstanding issues through
documentation or specification changes as noted. This table uses the following notation:
Codes Used In Summary Table
X: Erratum, Specification Change or Clarification that applies to the
given processor stepping.
(No mark) or (Blank Box): This erratum is fixed in listed stepping or specification change does
not apply to listed stepping.
Doc: Document change or update that will be implemented.
Plan Fix: This erratum may be fixed in a future of the product.
Fixed: This erratum has been previously fixed.
No Fix: There are no plans to fix this erratum.
Change bar to left of table row indicates this item is either new or
modified from the previous version of this document.
Each Specification Update item will be prefixed with a capital letter to distinguish the product. The
key below details the letters that are used in Intel’s microprocessor Specification Updates:
A=Intel
B = Mobile Intel
C=Intel
D = Dual-Core Intel
E=Intel
F=Intel
G=Intel
H = Mobile Intel
J = 64-bit Intel
K = Mobile Intel
L=Intel
M = Mobile Intel
N=Intel
O=Intel
P=Intel
Q = Mobile Intel
®
Pentium® II processor
®
®
Celeron® processor
®
Pentium® III processor
®
Pentium® processor Extreme Edition and Intel® Pentium® D processor
®
Pentium® III Xeon® processor
®
Celeron® D processor
®
®
Xeon® processor MP
®
Xeon® processor
Pentium® II processor
®
Xeon® processor 2.80 GHz
®
Celeron® processor at 466/433/400/366/333/300 and 266 MHz
®
Xeon® processor MP with 1 MB L2 cache
®
Pentium® III processor
®
Celeron® processor
Pentium® 4 processor
®
Pentium® 4 processor supporting Hyper-Threading Technology on 90 nm
process technology
R=Intel
S = 64-bit Intel
®
Pentium® 4 processor on 90 nm process
®
Xeon® processor with 800 MHz system bus (1 MB and 2 MB L2 cache
versions)
T = Mobile Intel
U = 64-bit Intel
V = Mobile Intel
®
Pentium® 4 processor-M
®
Xeon® processor MP with up to 8 MB L3 cache
®
Celeron® processor on .13 micron process in micro-FCPGA package
12 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Summary Table of Changes
W= Intel® Celeron® M processor
X=Intel
Y=Intel
Z = Mobile Intel
AC = Intel
The Specification Updates for the Pentium
®
Pentium® M processor on 90 nm process with 2 MB L2 cache
®
Pentium® M processor
®
®
Celeron® processor in 478-pin package
Pentium® 4 processor with 533 MHz system bus
®
processor, Pentium® Pro processor, and other Intel
products do not use this convention.
Errata (Sheet 1 of 5)
No.
S1 XXXXXNo FixTransaction is not retired after BINIT#
S2 XXXXXNo FixInvalid opcode 0FFFh requires a ModRM byte
S3 XXXXXNo FixProcessor may hang due to speculative page walks to
S4 XXXXXNo FixMemory type of the load lock different from its corresponding
S5 XXXXXNo FixMachine Check Architecture error reporting and recovery may
S6 XXXXXNo FixDebug mechanisms may not function as expected
S7 XXXXXNo FixCascading of performance counters does not work correctly
S8 XXXXXNo FixEMON event counting of x87 loads may not work as expected
S9 XXXXXNo FixSystem bus interrupt messages without data and which
S10 XXXXXNo FixThe processor signals page fault exception (#PF) instead of
S11 XXXXXNo FixFSW may not be completely restored after page fault on
S12 XXXXXNo FixProcessor issues inconsistent transaction size attributes for
S13 XXXXXNo FixWhen the processor is in the system management mode
S14 XXXXXNo FixShutdown and IERR# may result due to a machine check
S15 XXXXXNo FixProcessor may hang under certain frequencies and 12.5%
S16 XXXXXNo FixSystem may hang if a fatal cache error causes bus write line
S17 XXXXXNo FixA write to APIC task priority register (TPR) that lowers priority
S18 XXXXXNo FixParity error in the L1 cache may cause the processor to hang
S19 XX FixedSequence of locked operations can cause two threads to
D-0/
0F34h
E-0/
0F41h
G-1/
0F49h
N-0/
0F43h
R-0/
0F4Ah
Plans Errata
non-existent system memory
store unlock
not work as expected
when forced overflow is enabled
receive a hard-failure response may hang the processor
alignment check exception (#AC) on an unlocked
CMPXCHG8B instruction
FRSTOR or FLDENV instructions
locked operation
(SMM), Debug registers may be fully writeable
exception on a Hyper-Threading Technology enabled
processor
STPCLK# duty cycle
(BWL) transaction to occur to the same cache line address as
an outstanding bus read line (BRL) or bus read-invalidate line
(BRIL)
may seem to have not occurred
receive stale data and cause application hang
64-bit Intel® Xeon® Processor with 800 MHz System Bus 13
(1 MB and 2 MB L2 Cache Versions) Specification Update
Summary Table of Changes
Errata (Sheet 2 of 5)
No.
S20 XFixedA 16-bit address wrap resulting from a near branch (jump or
S21 XXXXXNo FixBus locks and SMC detection may cause the processor to
S22 Fixed Incorrect physical address size returned by CPUID instruction
S23 XXXXXNo FixIncorrect debug exception (#DB) may occur when a data
S24 XXXXXNo FixxAPIC may not report some illegal vector errors
S25 XXXXXPlan FixEnabling no-eviction mode (NEM) may prevent the operation
S26 XXXXXPlan FixTPR (Task Priority Register) updates during voltage
S27 XXXXNo FixInteractions between the instruction translation lookaside
S28 XXX FixedSTPCLK# signal assertion under certain conditions may
S29 XXXXXNo FixIncorrect duty cycle is chosen when on-demand clock
S30 XXXXXNo FixMemory aliasing of pages as uncacheable memory type and
S31 XXXXXNo FixUsing STPCLK# and executing code from very slow memory
S32 XXXXXNo FixProcessor provides a 4-byte store unlock after an 8-byte load
S33 Duplicate Erratum: see S5
S34 XXXXXPlan FixExecution of IRET and INTn instructions may cause
S35 XXXXXNo FixData breakpoints on the high half of a floating-point line split
S36 XXXXXNo FixMachine Check Exceptions may not update Last-Exception
S37 XXXXXNo FixMOV CR3 performs incorrect reserved bit checking when in
S38 XXXXXNo FixStores to page tables may not be visible to pagewalks for
S39 XFixedA split store memory access may miss a data breakpoint
S40 XFixedEFLAGS.RF may be incorrectly set after an IRET instruction
S41 XFixedWriting the Echo TPR disable bit in IA32_MISC_ENABLE
S42 XFixedIncorrect access controls to
D-0/
0F34h
E-0/
0F41h
G-1/
0F49h
N-0/
0F43h
R-0/
0F4Ah
Plans Errata
call) may cause an incorrect address to be reported to the
#GP exception handler
temporarily hang
breakpoint is set on an FP instruction
of the second logical processor in a Hyper-Threading
Technology enabled boot strap processor (BSP)
transitions of power management events may cause a system
hang
buffer (ITLB) and the instruction streaming buffer may cause
unpredictable software behavior
cause a system hang
modulation is enabled in a processor supporting
Hyper-Threading Technology
write back (WB) may hang the system
could lead to a system hang
lock
unexpected system behavior
may not be captured
Record MSRs (LERs)
PAE paging
subsequent loads without serializing or invalidating the page
table entry
may cause a #GP fault
MSR_LASTBRANCH_0_FROM_LIP MSR registers
14 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata (Sheet 3 of 5)
Summary Table of Changes
No.
S43 XX FixedRecursive page walks may cause a system hang
S44 XFixedWRMSR to bit[0] of IA32_MISC_ENABLE register changes
S45 XXXX FixedVERR/VERW instructions may cause #GP fault when
S46 XFixedINS or REP INS flows save an incorrect memory address for
S47 XFixedFXSAVE instruction may result in incorrect data on
S48 XX FixedThe base of a null segment may be non-zero on a processor
S49 XX FixedUpper 32 bits of FS/GS with null base may not get cleared in
S50 XXXXXNo FixProcessor may fault when the upper 8 bytes of segment
S51 XFixedCompatibility mode STOS instructions may alter RSI register
S52 XFixedLDT descriptor which crosses 16 bit boundary access does
S53 XFixedUpper reserved bits are incorrectly checked while loading
S54 XXXXXNo FixLoading a stack segment with a selector that references a
S55 XFixedCPUID instruction incorrectly reports CMPXCH16B as
S56 XXXXXNo FixFXRSTOR may not restore non-canonical effective addresses
S57 XXXXXNo FixA push of ESP that faults may zero the upper 32-bits of RSP
S58 XFixedEnhanced halt state (C1E) voltage transition may affect a
S59 XXXXNo FixEnhanced halt state (C1E) may not be entered in a
S60 XFixedWhen the Execute Disable Bit function is enabled a page fault
S61 XFixedExecute Disable Bit set with AD assist may cause livelock
S62 XX FixedThe Execute Disable Bit fault may be reported before other
D-0/
0F34h
E-0/
0F41h
G-1/
0F49h
N-0/
0F43h
R-0/
0F4Ah
Plans Errata
only one logical processor on a Hyper-Threading Technology
enabled processor
descriptor is in non-canonical space
SMI on processors supporting Intel® Extended Memory 64
Technology (Intel® EM64T)
processors supporting Intel® Extended Memory 64
Technology (Intel® EM64T)
supporting Intel® Extended Memory 64 Technology (Intel®
EM64T)
Virtual-8086 Mode on processors with Intel® Extended
Memory 64 Technology (Intel® EM64T) Enabled
selector is loaded from a far jump through a call gate via the
Local Descriptor Table
results on a processor supporting Intel® Extended Memory 64
Technology (Intel® EM64T)
not cause a #GP fault on a processor supporting Intel®
Extended Memory 64 Technology (Intel® EM64T)
PDPTR's on a processor supporting Intel® Extended Memory
64 Technology (Intel® EM64T)
non-canonical address can lead to a #SS fault on a processor
supporting Intel® Extended Memory 64 Technology (Intel®
EM64T)
supported
on processors with Intel® Extended Memory 64 Technology
(Intel® EM64T) enabled
system’s power management in a Hyper-Threading
Technology enabled processor
Hyper-Threading Technology enabled processor
in a mispredicted branch may result in a page fault exception
types of page fault when both occur
64-bit Intel® Xeon® Processor with 800 MHz System Bus 15
(1 MB and 2 MB L2 Cache Versions) Specification Update
Summary Table of Changes
Errata (Sheet 4 of 5)
No.
S63 XFixedWrites to IA32_MISC_ENABLE may not update flags for both
S64 XFixedExecute Disable Bit set with CR4.PAE may cause livelock
S65 XFixedSYSENTER or SYSEXIT instructions may experience
S66 XXXXXNo FixChecking of Page Table Base Address may not match
S67 XXXXXNo FixIA32_MCi_STATUS MSR may improperly indicate that
S68 XXXXXNo FixWith Trap Flag (TF) asserted, FP instruction that triggers
S69 XXXXXNo FixPDE/PTE loads and continuous locked updates to the same
S70 XFixedMCA-corrected memory hierarchy error counter may not
S71 XXXXXNo FixBranch Trace Store (BTS) and Precise Event-Based
S72 XXX FixedL-bit of CS and LMA bit of IA32_EFER register may have
S73 XXXX FixedThe base of an LDT (Local Descriptor Table) register may be
S74 XFixedUnaligned Page-Directory-Pointer (PDPTR) Base with 32-bit
S75 XXXXXNo FixMemory ordering failure may occur with snoop filtering
S76 XXXXXNo FixControl Register 2 (CR2) can be updated during a REP
S77 XXXXXNo FixREP STOS/MOVS instructions with RCX >= 2^32 may cause
S78 XXXX FixedREP MOVS or REP STOS instruction with RCX >= 2^32 may
S79 XXXXXPlan FixAn REP LODSB or an REP LODSD or an REP LODSQ
S80 XXXX FixedData access which spans both canonical and non-canonical
D-0/
0F34h
E-0/
0F41h
G-1/
0F49h
N-0/
0F43h
R-0/
0F4Ah
Plans Errata
logical processors
incorrect canonical address checking on processors
supporting Intel® Extended Memory 64 Technology (Intel®
EM64T)
Address Bit Width supported by the platform
additional MCA information may have been captured
unmasked FP Exception may take single step trap before
retirement of instruction
cache line may cause system livelock
increment correctly
Sampling (PEBS) may update memory outside the
BTS/PEBS buffer
erroneous value for one instruction following mode transition
in Hyper-Threading Technology-Enabled processor
supporting Intel® Extended Memory 64 Technology (Intel®
EM64T)
non-zero on a processor supporting Intel® Extended Memory
64 Technology (Intel® EM64T)
mode PAE (Page Address Extension) paging may cause
processor to hang
third-party agents after issuing and completing a BWIL (Bus
Write Invalidate Line) or BLW (Bus Locked Write) transaction
MOVS/STOS instruction with fast strings enabled
system hang
fail to execute to completion or may write to incorrect memory
locations on processors supporting Intel® Extended Memory
64 Technology (Intel® EM64T)
instruction with RCX >= 2^32 may cause a system hang on
processors supporting Intel® Extended Memory 64
Technology (Intel® EM64T)
address space may hang system
16 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata (Sheet 5 of 5)
Summary Table of Changes
No.
S81 XXXXXPlan FixRunning in System Management Mode (SMM) and L1 data
S82 XXXXXNo FixA 64-bit value of Linear Instruction Pointer (LIP) may be
S83 XXXXXPlan FixIt is possible that two specific invalid opcodes may cause
S84 XXXXXNo FixAt core-to-bus ratios of 16:1 and above Defer Reply
S85 XXXXXNo FixProcessor may issue Frost Side Bus transactions up to 6
S86 XXXXXNo FixFront Side Bus machine checks may be reported as a result
S87 XXXXXNo FixWriting the local vector table (LVT) when an interrupt is
S88 XXXXXNo FixThe processor may issue multiple code fetches to the same
S89 XPlan FixCPUID feature flag reports LAHF/SAHF as unavailable,
S90 XXXXXNo FixIRET under certain conditions may cause an unexpected
S91 XFixedUpper 32 bits of ‘From’ address reported through LBR or LER
S1S XXXXXNoFixEXTEST/CLAMP may cause incorrect values to be driven on
S92 XXXXXNo FixThe IA32_MC0_STATUS/IA32_MC1_STATUS/
S93 XXXXXNo FixDebug Status Register (DR6) Breakpoint Condition Detected
D-0/
0F34h
E-0/
0F41h
G-1/
0F49h
N-0/
0F43h
R-0/
0F4Ah
Plans Errata
cache adaptive mode may cause unexpected system
behavior when SMRAM is mapped to cacheable memory
reported incorrectly in the Branch Trace Store (BTS) memory
record or in the Precise Event Based Sampling (PEBS)
memory record
unexpected memory accesses
transactions with non-zero REQb values may cause a Front
Side Bus stall
clocks after RESET# is asserted
of on-going transactions during warm reset
pending may cause an unexpected interrupt
cache line for systems with slow memory
however the execution of LAHF/SAHF may not result in an
Invalid Opcode exception
Alignment Check Exception
MSRs, BTMs or BTSs may be incorrect
processor pins
IA32_MC4_STATUS Overflow Bit is not set when multiple
un-correctable machine check errors occur at the same time.
Flags May be Set Incorrectly.
64-bit Intel® Xeon® Processor with 800 MHz System Bus 17
(1 MB and 2 MB L2 Cache Versions) Specification Update
Summary Table of Changes
Specification Changes
No. SPECIFICATION CHANGES
None for this revision of the Specification Update.
Specification Clarifications
No. SPECIFICATION CLARIFICATIONS
None for this revision of the Specification Update.
Documentation Changes
No. DOCUMENTATION CHANGES
None for this revision of the Specification Update.
18 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
Errata
S1 Transaction is not retired after BINIT#
Problem: If the first transaction of a locked sequence receives a HITM# and DEFER# during the snoop phase
it should be retried and the locked sequence restarted. However, if BINIT# is also asserted during
this transaction, the transaction will not be retried.
Implication: When this erratum occurs, locked transactions will not be retried.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S2 Invalid opcode 0FFFh requires a ModRM byte
Problem: Some invalid opcodes require a ModRM byte and other following bytes, while others do not. The
invalid opcode 0FFFh did not require a ModRM in previous generation microprocessors such as
Pentium II or Pentium III processors, but it is required in the Intel Xeon processor.
Implication: The use of an invalid opcode 0FFFh without the ModRM byte may result in a page or limit fault on
the Intel Xeon processor. When this erratum occurs, locked transactions will not be retried.
Workaround: To avoid this erratum use ModRM byte with invalid 0FFFh opcode.
Status: For the steppings affected, see the Summary Table of Changes.
S3 Processor may hang due to speculative page walks to non-existent system
memory
Problem: A load operation issued speculatively by the processor that misses the data translation lookaside
buffer (DTLB) results in a page walk. A branch instruction older than the load retires so that this
load operation is now in the mispredicted branch path. Due to an internal boundary condition, in
some instances the load is not canceled before the page walk is issued.
The page miss handler (PMH) starts a speculative page-walk for the Load and issues a cacheable
load of the page directory entry (PDE). This PDE load returns data that points to a page table entry
in uncacheable (UC) memory. The PMH issues the PTE Load to UC space, which is issued on the
front side bus. No response comes back for this load PTE operation since the address is pointing to
system memory, which does not exist.
This load to non-existent system memory causes the processor to hang because other bus requests
are queued up behind this UC PTE load, which never gets a response. If the load was accessing
valid system memory, the speculative page-walk would successfully complete and the processor
would continue to make forward progress.
Implication: Processor may hang due to speculative page walks to non-existent system memory.
Workaround: Page directories and page tables in UC memory space must point to system memory that exists.
Status: For the steppings affected, see the Summary Table of Changes.
S4 Memory type of the load lock different from its corresponding store unlock
Problem: The Intel Xeon Processor employs a use-once protocol to ensure that a processor in a
multiprocessor system may access data that is loaded into its cache on a read-for-ownership (RFO)
operation at least once before it is snooped out by another processor. This protocol is necessary to
avoid a dual processor livelock scenario where no processor in the system can gain ownership of a
line and modify it before that data is snooped out by another processor. In the case of this erratum,
the use-once protocol incorrectly activates for split load lock instructions. A load lock operation
64-bit Intel® Xeon® Processor with 800 MHz System Bus 19
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
accesses data that splits across a page boundary with both pages of WB memory type. The
use-once protocol activates and the memory type for the split halves get forced to UC. Since
use-once does not apply to stores, the store unlock instructions go out as WB memory type. The
full sequence on the Bus is: locked partial read (UC), partial read (UC), partial write (WB), locked
partial write (WB). The Use-once protocol should not be applied to Load locks.
Implication: When this erratum occurs, the memory type of the load lock will be different than the memory type
of the store unlock operation. This behavior (Load Locks and Store Unlocks having different
memory types) does not however introduce any functional failures such as system hangs or
memory corruption.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S5 Machine Check Architecture error reporting and recovery may not work as
expected
Problem: When the processor detects errors it should attempt to report and/or recover from the error. In the
situations described below, the processor does not report and/or recover from the error(s) as
intended.
• When a transaction is deferred during the snoop phase and subsequently receives a Hard
Failure response, the transaction should be removed from the bus queue so that the processor
may proceed. Instead, the transaction is not properly removed from the bus queue, the bus
queue is blocked, and the processor will han g .
• When a hardware prefetch results in an uncorrectable tag error in the L2 cache,
MC0_STATUS.UNCOR and MC0_STATUS.PCC are set but no machine check exception
(MCE) is signaled. No data loss or corruption occurs because the data being prefetched has not
been used. If the data location with the uncorrectable tag error is subsequently accessed, an
MCE will occur. However , upon this MCE, or any other subsequent MCE, the information for
that error will not be logged because MC0_STATUS.UNCOR has already been set and the
MCA status registers will not contain information about the error which caused the MCE
assertion but instead will contain information about the prefetch error event.
• When the reporting of errors is disabled for machine check architecture (MCA) Bank 2 by
setting all MC2_CTL register bits to 0, uncorrectable errors should be logged in the
IA32_MC2_STATUS register but no machine-check exception should be generated.
Uncorrectable loads on bank 2, which would normally be logged in the IA32_MC2_STATUS
register, are not logged.
• When one half of a 64 byte instruction fetch from the L2 cache has an uncorrectable error and
the other 32 byte half of the same fetch from the L2 cache has a correctable error, the proces sor
will attempt to correct the correctable error but cannot proceed due to the uncorrectable error.
When this occurs the processor will hang.
• When an L1 cache parity error occurs, the cache controller logic should write the physical
address of the data memory location that produced that error into the IA32_MC1_ADDR
REGISTER (MC1_ADDR). In some instances of a parity error on a load operation that hits
the L1 cache, however, the cache controller logic may write the physical address from a
subsequent load or store operation into the IA32_MC1_ADDR register.
• When an error exists in the tag field of a cache line such that a request for ownership (RFO)
issued by the processor hits multiple tag fields in the L2 cache (the correct tag and the tag with
the error) and the accessed data also has a correctable error, the processor will correctly log the
multiple tag match error but will hang when attempting to execute the MCE handler.
• If a memory access receives a machine check error on both 64 byte halves of a 128-byte L2
cache sector, the IA32_MC0_STATUS register records this event as multiple errors, i.e., the
valid error bit and the overflow error bit are both set indicating that a machine check error
20 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
occurred while the results of a previous error were in the error-reporting bank. The
IA32_MC1_ST ATUS register should also record this event as multiple errors but instead
records this event as only one correctable error.
• The overflow bit should be set to indicate when more than one error has occurred. The
overflow bit being set indicates that more than one error has occurred. Because of this erratum,
if any further errors occur, the MCA overflow bit will not be updated; thereby incorrectly
indicating only one error has been received.
• If an I/O instruction (IN, INS, REP INS, OUT, OUTS, or REP OUTS) is being executed, and if
the data for this instruction becomes corrupted, the processor will signal a MCE. If the
instruction is directed at a device that is powered down, the processor may also receive an
assertion of SMI#. Since MCEs have higher priority, the processor will call the MCE handler,
and the SMI# assertion will remain pending. However, while attempting to execute the first
instruction of the MCE handler, the SMI# will be recognized and the processor will attempt to
execute the SMM handler. If the SMM handler is successfully completed, it will attempt to
restart the I/O instruction, but will not have the correct machine state due to the call to the
MCE handler. This can lead to failure of the restart and shutdown of the processor.
• If PWRGOOD is deasserted during a RESET# assertion causing internal glitch e s, the MCA
registers may latch invalid information.
• If RESET# is asserted, then deasserted, and reasserted, before the processor has cleared the
MCA registers, then the information in the MCA registers may not be reliable, regardless of
the state or state transitions of PWRGOOD.
• If MCERR# is asserted by one pro cessor and observed by another processor, the observing
processor does not log the assertion of MCERR#. The MCE handler called upon assertion of
MCERR# will not have any way to determine the cause of the MCE.
• The Overflow Error bit (bit 62) in the IA32_MC0_STATUS register indicates, when set, that a
machine check error occurred while the results of a previous error were still in the error
reporting bank (i.e. The Valid bit was set when the new error occurred). If an uncorrectable
error is logged in the error-reporting bank and another error occurs, the overflow bit will not be
set.
• A different mechanism than the rest of the register writes the MCA Error Code field of the
IA32_MC0_STATUS register. For uncorrectable errors, the other fields in the
IA32_MC0_STATUS register are only updated by the first error. Any further errors that are
detected will update the MCA Error Code field without updating the rest of the register,
thereby leaving the IA32_MC0_STATUS register with stale information.
• When a speculative load operation hits the L2 cache and receives a correctable error, the
IA32_MC1_Status Register may be updated with incorrect information. The
IA32_MC1_Status Register should not be updated for speculative loads.
• The processor should only lo g the address fo r L1 parity errors in the IA32_MC1_Status
register if a valid address is available. If a valid address is not available, the Address Valid bit
in the IA32_MC1_Status register should not be set. In instances where an L1 parity error
occurs and the address is not available because the linear to physical address translation is not
complete or an internal resource conflict has occurred, the Address Valid bit is incorrectly set.
• The processor may hang when an instruction code fetch receives a hard failure response from
the front side bus. This occurs because the bus control logic does not return data to the core,
leaving the processor empty. IA32_MC0_STATUS MSR does indicate that a hard fail
response occurred.
• The processor may hang when the following events occur and the machine check exception is
enabled, CR4.MCE=1. A processor that has it’s STPCLK# pin asserted will internally enter
the Stop Grant State and finally issue a Stop Grant Acknowledge special cycle to the bus. If an
uncorrectable error is generated during the Stop Grant process it is possible for the Stop Grant
64-bit Intel® Xeon® Processor with 800 MHz System Bus 21
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
special cycle to be issued to the bus before the processor vectors to the machine check handler.
Once the chipset receives its last Stop Grant special cycle it is allowed to ignore any bus
activity from the processors. As a result, processor accesses to the machine check handler may
not be acknowledged, resulting in a processor hang.
Implication: The processor is unable to correctly report and/or recover from certain errors
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S6 Debug mechanisms may not function as expected
Problem: If the first transaction of a locked sequence receives a HITM# and DEFER# during the snoop phase
it should be retried and the locked sequence restarted. However, if BINIT# is also asserted during
this transaction, the transaction will not be Certain debug mechanisms may not function as
expected on the processor. The cases are as follows:
• When the following condit ions occur: 1) An FLD instruction signals a stack overflow or
underflow, 2) the FLD instruction splits a page-boundary or a 64 byte cache line boundary, 3)
the instruction matches a Debug Register on the high page or cache line respectively, and 4)
the FLD has a stack fault and a memory fault on a split access, the processor will only signal
the stack fault and the debug exception will not be taken.
• When a data breakpoint is set on the ninth and/or tenth byte(s) of a floating-point store using
the Extended Real data type, and an unmasked floating-point exception occurs on the store, the
break point will not be captured.
• When any instruction has multiple debug register matches, and any one of those debug
registers is enabled in DR7, all of the matches should be reported in DR6 when the processor
goes to the debug handler. This is not true during a REP instruction. As an example, during
execution of a REP MOVSW instruction the first iteration a load matches DR0 and DR2 and
sets DR6 as FFFF0FF5h. On a subsequent iteration of the instruction, a load matches only
DR0. The DR6 register is expected to still contain FFFF0FF5h, but the processor will update
DR6 to FFFF0FF1h.
A Data breakpoint that is set on a load to uncacheable memory may be ignored due to an internal
segment register access conflict. In this case the system will continue to execute instructions,
bypassing the intended breakpoint. Avoiding having instructions that access segment descriptor
registers e.g. LGDT , LIDT close to the UC load, and avoiding serialized instructions before the UC
load will reduce the occurrence of this erratum.
Implication: Certain debug mechanisms do not function as expected on the processor.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S7 Cascading of performance counters does not work correctly when forced
overflow is enabled
Problem: The performance counters are organized into pairs. When the CASCADE bit of the Counter
Configuration Control Register (CCCR) is set, a counter that overflows will continue to count in
the other counter of the pair. The FORCE_OVF bit forces the counters to overflow on every
non-zero increment. When the FORCE_OVF bit is set, the counter overflow bit will be set but the
counter no longer cascades.
Implication: The performance counters do not cascade when the FORCE_OVF bit is set.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
22 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
S8 EMON event counting of x87 loads may not work as expected
Problem: If a performance counter is set to count x87 loads and floating-point exceptions are unm asked, the
FPU Operand (Data) Pointer (FDP) may become corrupted.
Implication: When this erratum occurs, FPU Operand (Data) Pointer (FDP) may become corrup ted.
Workaround: This erratum will not occur with floating point exceptions masked. If floating-point exceptions are
unmasked, then performance counting of x87 loads should be disabled.
Status: For the steppings affected, see the Summary Table of Changes.
S9 System bus interrupt messages without data and which receive a
hard-failure response may hang the processor
Problem: When a system bus agent (processor or chipset) issues an interrupt transaction without data onto
the system bus, and the transaction receives a hard-failure response, a potential processor hang can
occur. The processor, which generates an inter-processor interrupt (IPI) that receives hard-failure
response, will still log the MCA error event cause as hard-failure, even if the APIC causes a hang.
Other processors, which are true targets of the IPI, will also hang on hard failure-without-data, but
will not record an MCA hard-failure event as a cause. If a hard-failure response occurs on a system
bus interrupt message with data, the APIC will complete the operation so as not to hang the
processor.
Implication: The processor may hang.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S10 The processor signals page fault exception (#PF) instead of alignment
check exception (#AC) on an unlocked CMPXCHG8B instruction
Problem: If a page fault exception (#PF) and alignment check exception (#AC) both occur for an unlocked
CMPXCHG8B instruction, then #PF will be flagged.
Implication: Software that depends on the #AC before the #PF will be affected since #PF is signaled in this case.
Workaround: Remove the software’s dependency on #AC having precedence over #PF. Alternately, correct the
page fault in the page fault handler and then restart the faulting instruction.
Status: For the steppings affected, see the Summary Table of Changes.
S11 FSW may not be completely restored after page fault on FRSTOR or
FLDENV instructions
Problem: If the FPU operating environment or FPU state (operating environment and register stack) being
loaded by an FLDENV or FRSTOR instruction wraps around a 64-Kbyte or 4-Gbyte boundary and a
page fault (#PF) or segment limit fault (#GP or #SS) occurs on the instruction near the wrap
boundary, the upper byte of the FPU status word (FSW) might not be restored. If the fault handler
does not restart program execution at the faulting instruction, stale data may exist in the FSW.
Implication: When this erratum occurs, stale data will exist in the FSW.
Workaround: Ensure that the FPU operating environment and FPU state do not cross 64-Kbyte or 4-Gbyte
boundaries. Alternately, ensure that the page fault handler restarts program execution at the faulting
instruction after correcting the paging problem.
Status: For the steppings affected, see the Summary Table of Changes.
64-bit Intel® Xeon® Processor with 800 MHz System Bus 23
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
S12 Processor issues inconsistent transaction size attributes for locked
operation
Problem: When the processor is in the Page Address Extension (PAE) mode and detects the need to set the
Access and/or Dirty bits in the page directory or page table entries, the processor sends an 8-byte
load lock onto the system bus. A subsequent 8 byte store unlock is expected, but instead a 4 byte
store unlock occurs. Correct data is provided since only the lower bytes change, however external
logic monitoring the data transfer may be expecting an 8-byte store unlock.
Implication: This erratum affects no known commercially available chipsets.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S13 When the processor is in the system management mode (SMM), Debug
registers may be fully writeable
Problem: When in system management mode (SMM), the processor executes code and stores data in the
SMRAM space. When the processor is in this mode and writes are made to DR6 and DR7, the
processor should block writes to the reserved bit locations. Due to this erratum, the processor may
not block these writes. This may result in invalid data in the reserved bit locations.
Implication: Reserved bit locations within DR6 and DR7 may become invalid.
Workaround: Software may perform a read/modify/write when writing to DR6 and DR7 to ensure that the values
in the reserved bits are maintained.
Status: For the steppings affected, see the Summary Table of Changes.
S14 Shutdown and IERR# may result due to a machine check exception on a
Hyper-Threading Technology enabled processor
Problem: When a MCE occurs due to an internal error, both logical processors on a Hyper-Threading (HT)
T echnology enabled processor normally vector to the MCE handler. However, if one of the logical
processors is in the “Wait for SIPI” state, that logical processor will not have a MCE handler and
will shut down and assert IERR#.
Implication: A processor with a logical processor in the “Wait for SIPI” state will shut down when an MCE
occurs on the other thread.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S15 Processor may hang under certain frequencies and 12.5% STPCLK# duty
cycle
Problem: If a system deasserts STPCLK# at a 12.5% duty cycle, and the processor is running below 2 GHz,
and the processor thermal control circuit (TCC) on-demand clock modulation is active, the
processor may hang. This erratum does not occur under the automatic mode of the TCC.
Implication: When this erratum occurs, the processor will hang.
Workaround: If use of the on-demand mode of the processor's TCC is desired in conjunction with STPCLK#
modulation, then assure that STPCLK# is not asserted at a 12.5% duty cycle.
Status: For the steppings affected, see the Summary Table of Changes.
24 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
S16 System may hang if a fatal cache error causes bus write line (BWL)
transaction to occur to the same cache line address as an outstanding bus
read line (BRL) or bus read-invalidate line (BRIL)
Problem: A processor internal cache fatal data ECC error may cause the processor to issue a bus write line
(BWL) transaction to the same cache line address as an outstanding bus read line (BRL) or bus
read-invalidate line (BRIL). As it is not typical behavior for a single processor to have a BWL and
a BRL/BRIL concurrently outstanding to the same address, this may represent an unexpected
scenario to system logic within the chipset.
Implication: The processor may not be able to fully execute the machine check handler in response to the fatal
cache error if system logic does not ensure forward progress on the system bus under this scenario.
Workaround: System logic should ensure completion of the outstanding transactions. Note that during recovery
from a fatal data ECC error, memory image coherency of the BWL with respect to BRL/BRIL
transactions is not important. Forward progress is the primary requirement.
Status: For the steppings affected, see the Summary Table of Changes.
S17 A write to APIC task priority register (TPR) that lowers priority may seem to
have not occurred
Problem: Uncacheable stores to the APIC space are handled in a non-synchro nous way with respect to the
speed at which instructions are retired. If an instruction that masks the interrupt flag (for example
CLI) is executed soon after an uncacheable write to the task priority register (TPR) that lowers the
APIC priority the interrupt masking operation may take effect before the actual priority has been
lowered. This may cause interrupts whose priority is lower than the initial TPR but higher than the
final TPR to not be serviced until the interrupt flag is finally cleared (for example STI). Interrupts
will remain pended and are not lost
Implication: This condition may allow interrupts to be accepted by the processor but may delay their service
Workaround: This can be avoided by issuing a TPR Read after a TPR Write that lowers the TPR value. This will
force the store to the APIC priority resolution logic before any subsequent instruction s are
executed. No commercial operating system is known to be impacted by this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S18 Parity error in the L1 cache may cause the processor to hang
Problem: If a locked operation accesses a line in the L1 cache that has a parity error, it is possible that the
processor may hang while trying to evict the line.
Implication: If this erratum occurs, it may result in a system hang. Intel has not observed this erratum with any
commercially available software.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S19 Sequence of locked operations can cause two threads to receive stale data
and cause application hang
Problem: While going through a sequence of locked operations, it is possible for the two threads to receive
stale data. This is a violation of expected memory ordering rules and causes the application to
hang.
Implication: When this erratum occurs in an Hyper-Thread Technology enabled system, an application may
hang.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
64-bit Intel® Xeon® Processor with 800 MHz System Bus 25
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
S20 A 16-bit address wrap resulting from a near branch (jump or ca ll) may cause
an incorrect address to be reported to the #GP exception handler
Problem: If a 16-bit application executes a branch instruction that causes an address wrap to a target address
outside of the code segment, the address of the branch instruction should be provided to the general
protection exception handler. It is possible that, as a result of this erratum, that the general
protection handler may be called with the address of the branch target.
Implication: A 16-bit software environment which is affected by this erratum, will see that the address reported
by the exception handler points to the target of the branch, rather than the address of the branch
instruction.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S21 Bus locks and SMC detection may cause the processor to temporarily hang
Problem: The processor may temporarily hang in an HT Technology enabled system, if one logical processor
executes a synchronization loop that includes one or more bus locks and is waiting for release by
the other logical processor. If the releasing logical processor is executing instructions that are
within the detection range of the self-modifying code (SMC) logic, then the processor may be
locked in the synchronization loop until the arrival of an interrupt or other event.
Implication: If this erratum occurs in an HT Technology enabled system, the application may temporarily stop
making forward progress. Intel has not observed this erratum with any commercially available
software.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S22 Incorrect physical address size returned by CPUID instruction
Problem: The CPUID instruction Function 80000008H (Extended Address Sizes Function) returns the
address sizes supported by the processor in the EAX register. This Function returns an incorrect
physical address size value of 40 bits. The correct physical address size is 36 bits.
Implication: Function 80000008H returns an incorrect physical address size value of 40 bits.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S23 Incorrect debug exception (#DB) may occur when a data breakpoint is set
on an FP instruction
Problem: The default microcode floating-point event handler routine executes a series of loads to obtain data
about the FP instruction that is causing the FP event. If a data breakpoint is set on the instruction
causing the FP event, the load in the microcode routine will trigger the data breakpoint resulting in
a debug exception.
Implication: An incorrect debug exception (#DB) may occur if data breakpoint is placed on an FP instruction.
Intel has not observed this erratum with any commercially available software or system.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S24 xAPIC may not report some illegal vector errors
Problem: The local xAPIC has an error status register, which records all errors it detects. Bit 6 of this
register, the receive Illegal Vector bit, is set when the local xAPIC detects an illegal vector in a
message that it receives. When an illegal vector error is received on the same internal clock that the
26 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
error status register is being written due to a previous error, bit 6 does not get set and illegal vector
errors are not flagged.
Implication: The xAPIC may not report some Illegal Vector errors when they occur at approximately the same
time as other xAPIC errors. The other xAPIC errors will continue to be reported.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S25 Enabling no-eviction mode (NEM) may prevent the operation of the second
logical processor in a Hyper-Threading Technology enabled boot strap
processor (BSP)
Problem: In an HT Technology enabled system, when NEM is enabled by setting Bit 0 of MSR 080h
(IA32_BIOS_CACHE_AS_RAM), the second logical processor associated with the BSP may fail
to wake up from “Wait-for-SIPI” state.
Implication: In an HT Technology enabled system, the second logical processor associated with the BSP may
not respond to SIPI. The OS will continue to operate but with one less logical processor than
expected.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S26 TPR (Task Priority Register) updates during voltage transitions of power
management events may cause a system hang
Problem: Systems with Echo TPR Disable (R/W) bit (bit [23] of t he IA32_MISC _ENABLE regi ster) set to
'0' (default), where xTPR messages are being transmitted on the system bus to the processor, may
experience a system hang during voltage transitions caused by power management events.
Implication: This may cause a system hang during voltage transitions of power management events.
Workaround: It is possible for the BIOS to contain a workaround for this erratum. The BIOS workaround
disables the Echo TPR updates on the affected steppings.
Status: For the steppings affected, see the Summary Table of Changes.
S27 Interactions between the instruction translation lookaside buffer (ITLB) and
the instruction streaming buffer may cause unpredictable software behavior
Problem: Complex interactions within the instructi on fetch/decode unit may make it possible for the
processor to execute instructions from an internal streaming buffer containing stale or incorrect
information.
Implication: When this erratum occurs, an incorrect instruction stream may be executed resulting in
unpredictable software behavior.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S28 STPCLK# signal assertion under certain conditions may cause a system
hang
Problem: The assertion of STPCLK# signal before a logical processor awakens from the “Wait-for-SIPI”
state for the first time, may cause a system hang. A processor supporting HT Technology may fail
to initialize appropriately, and may not issue a Stop Grant Acknowledge special bus cycle in
response to the second STPCLK# assertion.
Implication: When this erratum occurs in an HT Technology enabled system, it may cause a system hang.
64-bit Intel® Xeon® Processor with 800 MHz System Bus 27
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
Workaround: BIOS should initialize the second thread of the processor supporting HT Technology prior to
STPCLK# assertion.
Status: For the steppings affected, see the Summary Table of Changes.
S29 Incorrect duty cycle is chosen when on-demand clock modulation is
enabled in a processor supporting Hyper-Threading Technology
Problem: When a processor supporting HT T echnology enables on-demand clock modulation on both logical
processors, the processor is expected to select the lowest duty cycle of the two potentially different
values. When one logical processor enters the AUTOHALT state, the duty cycle implemented
should be unaffected by the halted logical processor. Due to this erratum, the duty cycle is
incorrectly chosen to be the higher duty cycle of both logical processors.
Implication: Due to this erratum, higher duty cycle may be chosen when the on-demand clock modulation is
enabled on both logical processors.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S30 Memory aliasing of pages as uncacheable memory type and write back
(WB) may hang the system
Problem: When a page is being accessed as either UC or write combining (WC) and write back (WB), under
certain bus and memory timing conditions, the system may loop in a continual sequence of UC
fetch, implicit write back, and RFO retries
Implication: This erratum has not been observed in any commercially available operating system or application.
The aliasing of memory regions, a condition necessary for this erratum to occur, is documented as
being unsupported in the IA-3 2 Intel
Section 10.12.4, Programming the PAT. However, if this erratum occurs the system may hang
®
Architecture Software Developer’s Manual, Volume 3,
Workaround: The pages should not be mapped as either UC or WC and WB at the same time.
Status: For the steppings affected, see the Summary Table of Changes.
S31 Using STPCLK# and executing code from very slow memory could lead to a
system hang
Problem: The system may hang when the following conditions are met:
1. Periodic STPCLK# mechanism is enabled via the chipset.
2. HT Technology is enabled.
3. One logical processor is waiting for an event (i.e. hardware interrupt).
4. The other logical processor executes code from very slow memory such that every code fetch
is deferred long enough for the STPCLK# to be reasserted.
Implication: If this erratum occurs, the processor will go into and out of the sleep state without making forward
progress, since the logical processor will not be able to service any pending event. This erratum has
not been observed in any commercial platform running commercial software.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S32 Processor provides a 4-byte store unlock after an 8-byte load lock
Problem: When the processor is in the Page Address Extension (PAE) mode and detects the need to set the
Access and/or Dirty bits in the page directory or page table entries, the processor sends an 8 byte
load lock onto the system bus. A subsequent 8 byte store unlock is expected, but instead a 4 byte
28 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
store unlock occurs. Correct data is provided since only the lower bytes change, however external
logic monitoring the data transfer may be expecting an 8 byte load lock.
Implication: No known commercially available chipsets are affected by this erratum.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S33 Duplicate erratum: see Erratum S5
S34 Execution of IRET and INTn instructions may cause unexpected system
behavior
Problem: There is a small window of time, requiring alignment of many internal micro architectural events,
during which the speculative execution of the IRET or INTn instructions in protected or IA-32e
mode may result in unexpected software or system behavior.
Implication: This erratum may result in unexpected instruction execution, events, interrupts or a system hang
when the IRET instruction is executed. The execution of the INTn instruction may cause debug
breakpoints to be missed.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S35 Data breakpoints on the high half of a floating-point line split may not be
captured
Problem: When a floating point load which splits a 64-byte cache line gets a floating point stack fault, and a
data breakpoint register maps to the high line of the floating point load, internal boundary
conditions exist that may prevent the data breakpoint from being captured.
Implication: When this erratum occurs, a data breakpoint will not be captured.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S36 Machine Check Exceptions may not update Last-Exception Record MSRs
(LERs)
Problem: The Last-Exception Record MSRs (LERs) may not get updated when Machine Check Exceptions
occur.
Implication: When this erratum occurs, the LER may not cont ain information relating to the machine check
exception. They will contain information relating to the exception prior to the machine check
exception.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S37 MOV CR3 performs incorrect reserved bit checking when in PAE paging
Problem: The MOV CR3 instruction should perform reserved bit checking on the upper unimplemented
address bits. This checking range should match the address width reported by CPUID instruction
0x8000008. This erratum appli e s whenever PAE is enabled.
Implication: Software that sets the upper address bits on a MOV CR3 instruction and expects a fault may fail.
This erratum has not been observed with commercially available software.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
64-bit Intel® Xeon® Processor with 800 MHz System Bus 29
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
S38 Stores to page tables may not be visible to pagewalks for subsequent loads
without serializing or invalidating the page table entry
Problem: Under rare timing circumstances, a page table load on behalf of a programmat ically younger
memory access may not get data from a programmatically older store to the page table entry if
there is not a fencing operation or page translation invalidate operation between the store and the
younger memory access. Refer to the IA-32 Intel
®
Architecture Software Developer’ s Manual for
the correct way to update page tables. Software that conforms to the Software Developer's Manual
will operate correctly.
Implication: If the guidelines in the Software Developer's Manual are not followed, stale data may be loaded
into the processor's Translation Lookaside Buffer (TLB) and used for memory operations. This
erratum has not been observed with any commercially available software.
Workaround: The guidelines in the IA-32 Intel
Status: For the steppings affected, see the Summary Table of Changes.
®
Architecture Software Developer’s Manual should be fol low ed.
S39 A split store memory access may miss a data breakpoint
Problem: It is possible for a data breakpoint specified by a linear address to be missed during a split store
memory access. The problem can happen with or without paging enabled.
Implication: This erratum may limit the debug capability of a debugger software.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S40 EFLAGS.RF may be incorrectly set after an IRET instruction
Problem: EFLAGS.RF is used to disable code breakpoints. After an IRET instruction, EFLAGS.RF may be
incorrectly set or not set depending on its value right before the IRET instruction.
Implication: A code breakpoint may be missed or an additional code breakpoint may be taken on next
instruction.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S41 Writing the Echo TPR disable bit in IA32_MISC_ENABLE may cause a #GP
fault
Problem: Writing a ‘1’ to the Echo TPR disable bit (bit 23) in IA32_MISC_ENABLE may incorrectly cause
a #GP fault.
Implication: A #GP fault may occur if the bit is set to a ‘1’.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S42 Incorrect access controls to MSR_LASTBRANCH_0_FROM_LIP MSR
registers
Problem: When an access is made to the MSR_LASTBRANCH_0_FROM_LIP MSR register, an expected
#GP fault may not happen.
Implication: A read of the MSR_LASTBRANCH_0_FROM_LIP MSR register may not cause a #GP fault.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
30 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
S43 Recursive page walks may cause a system hang
Problem: A page walk, accessing the same page table entry multiple times but at different levels of the page
table, which causes the page table entry to have its Access bit set may result in a system hang.
Implication: When this erratum occurs, the system may experience a hang.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S44 WRMSR to bit[0] of IA32_MISC_ENABLE register changes only one logical
processor on a Hyper-Threading Technology enabled processor
Problem: On an HT Technology enabled processor, a write to the fast-strings feature bit[0] of
IA32_MISC_ENABLE register changes the setting for the current logical processor only.
Implication: Due to this erratum, the non-current logical processor may not update fast-strings feature bit[0] of
IA32_MISC_ENABLE register.
Workaround: BIOS may set the fast-strings enable bit on both logical processors to workaround this erratum. It is
possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S45 VERR/VERW instructions may cause #GP fault when descriptor is in
non-canonical space
Problem: If a descriptor referenced by the selector specified for the VERR or VERW instructions is in
non-canonical space, it may incorrectly cause a #GP fault on a processor supporting Intel
Extended Memory 64 Technology (Intel
®
EM64T).
®
Implication: Operating systems or drivers that reference a selector in non-canonical space may experience an
unexpected #GP fault. Intel has not observed this erratum with any commercially available
software.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S46 INS or REP INS flows save an incorrect memory address for SMI on
processors supporting Intel® Extended Memory 64 Technology (Intel®
EM64T)
Problem: In IA-32e mode of the Intel EM64T processor, an INS or an REP INS instruction, followed by an
SMI, may save an incorrect memory address to the System Management Mode (SMM) save state
location.
Implication: Due to this erratum, the SMM macro-handler may use the incorrect memory address while
reproducing the I/O access of SMI.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S47 FXSAVE instruction may result in incorrect data on processors
supporting Intel® Extended Memory 64 Technology (Intel®EM64T)
Problem: In IA-32e mode of the Intel EM64T processor, the upper 32 bits of the FDP value written out to
memory by the FXSAVE instruction may be incorrect.
Implication: This erratum may cause incorrect data to be saved into th e memory.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
64-bit Intel® Xeon® Processor with 800 MHz System Bus 31
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
S48 The base of a null segment may be non-zero on a processor supporting
Problem: In IA-32e mode of the Intel EM64T processor, the base of a null segment may be non-zero.
Implication: Due to this erratum, Intel EM64T enabled systems may encounter unexpected behavior when
®
Extended Memory 64 Technology (Intel® EM64T)
Intel
accessing memory using the null selector.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S49 Upper 32 bits of FS/GS with null base may not get cleared in Virtual-8086
Mode on processors with Intel
®
Extended Memory 64 Technology (Intel®
EM64T) Enabled
Problem: For processors with Intel EM64T enabled, the upper 32 bits of the FS and GS data segment
registers corresponding to a null base may not get cleared when segments are loaded in
Virtual-8086 mode.
Implication: This erratum may cause incorrect data to be loaded or stored to memory if FS/GS is not initialized
before use in 64-bit mode. Intel has not observed this erratum with any commercially available
software.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S50 Processor may fault when the upper 8 bytes of segment selector is loaded
from a far jump through a call gate via the Local Descriptor Table
Problem: In IA-32e mode of the Intel EM64T processor, control transfers through a call gate via the Local
Descriptor Table (LDT) that uses a 16-byte descriptor, the upper 8-byte access may wrap and
access an incorrect descriptor in the LDT. This only occurs on an LDT with a LIMIT>0x10008
with a 16-byte descriptor that has a selector of 0xFFFC.
Implication: In the event this erratum occurs, the upper 8-byte access may wrap and access an incorrect
descriptor within the LDT, potentially resulting in a fault or system hang. Intel has not observed
this erratum with any commercially available software.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S51 Compatibility mode STOS instructions may alter RSI register results on a
processor supporting Intel
EM64T)
Problem: When a processor supporting Intel EM64T is in IA-32e mode and executes a STOS instruction in
compatibility mode, it may modify the RSI register contents.
Implication: When this erratum occurs, systems may encounter unexpected behavior.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S52 LDT descriptor which crosses 16 bit boundary access does not cause a
#GP fault on a processor supporting Intel
Technology (Intel® EM64T)
Problem: When a processor supporting Intel EM64T in IA-32e mode accesses an LDT entry (16-byte) that
crosses the 0xffff limit, a #GP fault is not signaled and instead the upper 8-bytes of the entry is
fetched from the wrapped around address (usually 0x0). This will cause the erroneous data to be
loaded into the upper 8-bytes of the descriptor.
32 64-bit Intel® Xeon® Processor with 800 MHz System Bus
®
Extended Memory 64 Technology (Intel®
®
Extended Memory 64
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
Implication: When this erratum occurs, systems may encounter unexpected behavior. Intel has not observed this
erratum with any commercially available software.
Workaround: Software should prevent LDT selector accesses from crossing the 0xfff f limit.
Status: For the steppings affected, see the Summary Table of Changes.
S53 Upper reserved bits are incorrectly checked while loading PDPTR's on a
processor supporting Intel
®
(Intel
Problem: In IA-32 and IA-32e mode of the Intel processor, upper reserved bits are incorrectly checked while
EM64T)
®
Extended Memory 64 Technology
loading PDPTR's, allowing software to set the reserved bits.
Implication: Operating system or driver so ftware is able to set the reserved bits which may result in an
unexpected system behavior.
Workaround: None identified.
Status: For the steppings affected, see the Summary Table of Changes.
S54 Loading a stack segment with a selector that references a non-canonical
address can lead to a #SS fault on a processor supporting Intel
®
Extended
Memory 64 Technology (Intel® EM64T)
Problem: When a processor supporting Intel EM64T is in IA-32e mode, loading a stack segment with a
selector which references a non-canonical address will result in a #SS fault instead of a #GP fault.
Implication: When this erratum occurs, Intel EM64T enabled sy stems may encounter unexpected behavior.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S55 CPUID instruction incorrectly reports CMPXCH16B as supported
Problem: A read of the CMPXCHG16B feature flag improperly indicates that the CMPXCHG16B instruction is
supported.
Implication: When a processor supporting Intel EM64T attempts to execute a CMPXCH16B instruction, the
system may hang rather than #UD fault.
Workaround: It is possible for the BIOS to contain a workaround for this erratum, such that the CMPXCH16B
feature flag indicates that the instruction is not supported, and the execution of the CMPXCHG16B
instruction results in a #UD fault.
Status: For the steppings affected, see the Summary Table of Changes.
S56 FXRSTOR may not restore non-canonical effective addresses on
processors with Intel
enabled
Problem: If an x87 data instruction has been executed with a non-canonical effective address, FXSAVE may
store that non-canonical FP Data Pointer (FDP) value into the save image. An FXRSTOR
instruction executed with 64-bit operand size may signal a General Protection Fault (#GP) if the
FDP or FP Instruction Pointer (FIP) is in non-canonical form.
Implication: When this erratum occurs, Intel EM64T enabled sy stems may encounter an unintended #GP fault.
Workaround: Software should avoid using non-canonical effective addressing in EM64T enabled processors.
BIOS can contain a workaround for this erratum removing the unintended #GP fault on
FXRSTOR.
Status: For the steppings affected, see the Summary Table of Changes.
64-bit Intel® Xeon® Processor with 800 MHz System Bus 33
(1 MB and 2 MB L2 Cache Versions) Specification Update
®
Extended Memory 64 Technology (Intel® EM64T)
Errata
S57 A push of ESP that faults may zero the upper 32-bits of RSP
Problem: In the event that a push ESP instruction, that faults, is executed in compatibility m ode, the
processor will incorrectly zero upper 32-bits of RSP.
Implication: A Push of ESP in compatibility mode will zero the upper 32-bits of RSP. Due to this erratum, this
instruction fault may change the contents of RSP. This erratum has not been observed in
commercially available software.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S58 Enhanced halt state (C1E) voltage transition may affect a system’s power
management in a Hyper-Threading Technology enabled processor
Problem: In an HT Technology enabled system, the second logical Processor may fail to wake up from
“Wait-for-SIPI” state during a C1E voltage transition.
Implication: This erratum may affect a system’s entry in to the power management mode offered by the C1E
event for HT Technology enabled plat forms.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S59 Enhanced halt state (C1E) may not be entered in a Hyper-Threading
Technology enabled processor
Problem: If the IA32_MISC_ENABLE MSR (0x1A0) C1E enable bit is not set prior to an INIT event on an
HT T echnology enabled system, the processor will not enter C1E until the next SIPI wakeup event
for the second logical processor.
Implication: Due to this erratum, the processor will not enter C1E state.
Workaround: If C1E is supported in the system, the IA32_MISC_ENABLE MSR should be enabled prior to
issuing the first SIPI to the second logical processor.
Status: For the steppings affected, see the Summary Table of Changes.
S60 When the Execute Disable Bit function is enabled a page fault in a
mispredicted branch may result in a page fault exception
Problem: If a page fault in a mispredicted branch occurs in the ITLB, it should no t be reported by the
processor. However , if the execute disable bit function is enabled (IA32_EFER.NXE = 1) and there
is a page fault in a mispredicted branch in the ITLB, a page fault exception may occur.
Implication: When this erratum occurs, a page fault exception may occur.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S61 Execute Disable Bit set with AD assist may cause livelock
Problem: If Execute Disable Bit is set and the resulting page requires the processor to set the A and/or D bit
(Access and/or Dirty bit) in the PTE, then the processor may livelock.
Implication: When this erratum occurs, the processor may livelock resulting in a system hang or operating
system failure.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
34 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
S62 The Execute Disable Bit fault may be reported before other types of page
fault when both occur
Problem: If the Execute Disable Bit is enabled and both the Execute Disable Bit fault and page faults occur,
the Execute Disable Bit fault will be reported prior to other types of page fault being reported.
Implication: No impact to properly written code since both types of faults will be generated but in the opposite
order.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S63 Writes to IA32_MISC_ENABLE may not update flags for both logical
processors
Problem: On processors supporti ng HT Technology with Execute Disable Bit feature, writes to
IA32_MISC_ENABLE may only update IA32_EFER.NXE for the current logical processor.
Implication: Due to this erratum, the non-current logical processor may not update its IA32_EFER.NXE bit.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S64 Execute Disable Bit set with CR4.PAE may cause livelock
Problem: If the Execute Disable bit of IA32_MISC_Enable is set along wit h the PAE bit of CR4
(IA32_EFER.NXE & CR4.PAE), the processor may livelock.
Implication: When this erratum occurs, the processor may livelock resulting in a system hang or operating
system failure.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S65 SYSENTER or SYSEXIT instructions may experience incorrect canonical
address checking on processors supporting Intel® Extended Memory 64
Technology (Intel
Problem: Processors which support Intel EM64T always perform canonical address checks before accessing
memory . SYSE NTER or SYSEXIT instructions may check an incorrect address.
Implication: Due to this erratum, an unexpected #GP fault may occur, or a reference to a non-canonical address
without a #GP fault may occur.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
®
EM64T)
S66 Checking of Page Table Base Address may not match Address Bit Width
supported by the platform
Problem: If the page table base address included in the page map level-4 table, page-directory pointer table,
page-directory table, or page table exceeds the physical address range supported by the platform
(e.g. 36 bits) and it is less than the implemented address range (e.g. 40 bits), the processor does not
check to see if the address is invalid.
Implication: If software sets such an invalid physical address in the listed tables, the processor does not generate
a page fault (#PF) upon accessing that virtual address, and the access results in an incorrect read or
write. If BIOS provides only valid physical address ranges to the operating system, this erratum
will not occur.
Workaround: Ensure that BIOS provides only valid physical address ranges to the operating system.
64-bit Intel® Xeon® Processor with 800 MHz System Bus 35
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
Status: For the steppings affected, see the Summary Table of Changes.
S67 IA32_MCi_STATUS MSR may improperly indicate that additional MCA
information may have been captured
Problem: When a data parity error is detected and the bus queue is busy, the ADDRV and MISCV bits of the
IA32_MCi_STATUS register may be asserted even though the contents of the IA32_MCi_ADDR
and IA32_MCi_MISC MSRs were not properly captured.
Implication: If this erratum occurs, the MCA information captured in the IA32_MCi_ADDR and
IA32_MCi_MISC registers may not correspond to the reported machine-check error, even though
the ADDRV and MISCV are asserted.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S68 With Trap Flag (TF) asserted, FP instruction that triggers unmasked FP
Exception may take single step trap before retirement of instruction
Problem: If an FP instruction generates an unmasked exception wit h the EFLAGS.TF = 1, it is possible for
external events to occur, including a transition to a lower power state. When resuming from a lower
power state, it may be possible to take the single step trap before the execution of the original FP
instruction completes.
Implication: When this erratum occurs, a single step trap will be taken unexpectedly.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S69 PDE/PTE loads and continuous locked updates to the same cache line may
cause system livelock
Problem: In a multi-processor configuration, if one processor is continuously doing locked updates to a
cache line that is being accessed by another processor doing a page table walk, the page table walk
may not complete.
Implication: Due to this erratum, the system may livelock until some external event interrupts the locked
update. Intel has not observed this erratum with any commercially available software.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S70 MCA-corrected memory hierarchy error counter may not increment
correctly
Problem: An MCA-corrected memory hierarchy error counter can report a maximum of 255 errors. Due to
the incorrect increment of the counter, the number of errors reported may be incorrect.
Implication: Due to this erratum, the MCA counter may report an incorrect number of soft errors.
Workaround: None at this time.
Status: For the steppings affected, see the Summary Table of Changes.
S71 Branch Trace Store (BTS) and Precise Event-Based Sampling (PEBS) may
update memory outside the BTS/PEBS buffer
Problem: If the BTS/PEBS buffer is defined such that:
1. The difference between the BTS/PEBS buffer base and the BTS/P EBS absolute maximum is
not an integer multiple of the corresponding record sizes,
36 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
2. The BTS/PEBS absolute maximum is less than a record size from the end of the virtual
address space, and
3. The record that would cross the BTS/PEBS absolute maximum will also continue past the end
of the virtual address space,
a. BTS/PEBS record can be written that will wrap at the 4-Gbyte boundary (IA-32) or 2^64
boundary (Intel EM64T mode), and write memory outside of the BTS/PEBS buffer.
Implication: Software that uses BTS/PEBS near the 4-Gbyte boundary (IA-32) or 2^64 boundary (Intel EM64T
mode), and defines the buffer such that it does not hold an integer multiple of records, can update
memory outside the BTS/PEBS buffer.
Workaround: Define the BTS/PEBS buffer such that the BTS/PEBS ab sol ute maximum minus the BTS/PEBS
buffer base is an integer multiple of the corresponding record sizes as recommended in the IA-32
IA-32 Intel
Status: For the steppings affected, see the Summary Table of Changes.
®
Architecture Software Developer’s Manual, Volume 3.
S72 L-bit of CS and LMA bit of IA32_EFER register may have erroneous value for
one instruction following mode transition in Hyper-Threading
Technology-Enabled processor supporting Intel
®
Extended Memory 64
Technology (Intel® EM64T)
Problem: In an Intel EM64T-enabled processor, the L-bit of the Code Segment (CS) descriptor may not
update with the correct value in a processor with HT Technology. This may occur in a small
window when one logical processor is making a transition from a compatibility-mode to a 64-bit
mode (or vice versa) while the other logical processor is being stalled. A similar problem may
occur for the observation of the EFER.LMA bit by the decode logic.
Implication: The first instruction following a mode transition may be decoded as if it was still in the previous
mode. For example, this may result in an incorrect stack size used for a stack operation, i.e. a write
of only 4 bytes and an adjustment to ESP of only 4 in 64-bit mode. The problem can manifest itself
on any instruction which may behave differently in 64-bit mode than in compatibility mode.
Workaround: It is possible for BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S73 The base of an LDT (Local Descriptor Table) register may be non-zero on a
processor supporting Intel
®
Extended Memory 64 Technology (Intel®
EM64T)
Problem: In IA-32e mode of an Intel EM64T-enabled processor, the base of an LDT register may be
non-zero.
Implication: Due to this erratum, Intel EM64T-enabled systems may encounter unexpected behavior when
accessing an LDT register using the null selector. There may be no #GP fault in response to this
access.
Workaround: None identified.
Status: For the steppings affected, see the Summary of Changes.
S74 Unaligned Page-Directory-Pointer (PDPTR) Base with 32-bit mode PAE
(Page Address Extension) paging may cause processor to hang
Problem: When the MOV to CR0, CR3 or CR4 instructions are executed in legacy PAE paging mode and
software is using an unaligned PDPTR base the processor may hang or an incorrect page
translation may be used.
Implication: Software that is written according to Intel's alignment specification (32-byte aligned PDPTR Base)
will not encounter this erratum. Intel has not observed this erratum with commercially available
software. Systems may hang or experience unpredictable behavior when this erratum occurs.
64-bit Intel® Xeon® Processor with 800 MHz System Bus 37
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary of Changes.
S75 Memory ordering failure may occur with snoop filtering third-party agents
after issuing and completing a BWIL (Bus Write Invalidate Line) or BLW
(Bus Locked Write) transaction
Problem: Under limited circumstances, the processors may, after issuing and completing a BWIL or BLW
transaction, retain data from the addressed cache line in shared state even though the specification
requires complete invalidation. This data retention may also occur when a BWIL transaction’s
self-snooping yields HITM snoop results.
Implication: A system may suffer memory ordering failures if its central agent incorporates coherence
sequencing which depends on a full self-invalidation of the cache line associated with (1) BWIL
and BLW transactions, or (2) all HITM snoop results without regard to the transaction type and
snoop results’ source.
Workaround: 1. The central agent can issue a bus cycle that causes a cache line to be invalidated (Bus Read
Invalidate Line (BRIL) or BWIL transaction) in response to a processor-generated BWIL (or
BLW) transaction to insure complete validation of the associated cache line. If there are no
intervening processor-originated transactions to that cache line, the central agent’s invalidating
snoop will get a clean snoop result. Or,
2. Snoop filtering central agents can:
a. Not use processor-originated BWIL or BLW transactions to update their snoop filter
information, or
b. Update the associated cache line state information to shared state on the originating bus
(rather than invalid state) in reaction to a BWIL or BLW.
Status: For the steppings affected, see the Summary Table of Changes.
S76 Control Register 2 (CR2) can be updated during a REP MOVS/STOS
instruction with fast strings enabled
Problem: Under limited circumstances while executing a REP MOVS/STOS string instruction, with fast
strings enabled, it is possible for the value in CR2 to be changed as a result of an interim paging
event, normally invisible to the user. Any higher priority architectural event that arrives and is
handled while the interim paging event is occuring may see the modified value of CR2.
Implication: The value in CR2 is correct at the time that an architectural page fault is signaled. Intel has not
observed this erratum with any commercially available software.
Workaround: None identified.
Status: For the steppings affected, see the Summary Table of Changes at the beginning of this section.
S77 REP STOS/MOVS instructions with RCX >= 2^32 may cause system hang
Problem: In IA-32e mode using Intel EM64T-enabled processors, executing a repeating stri ng instruction
with the iteration count greater than or equal to 2^32 and a pending event may cause the REP
STOS/MOVS instruction to live lock and hang.
Implication: When this erratum occurs, the processor may live lock and result in a system hang. Intel has not
observed this erratum with any commercially available software.
Workaround: Do not use strings larger than 4 GB.
Status: For the steppings affected, see the Summary Table of Changes.
38 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
S78 REP MOVS or REP STOS instruction with RCX >= 2^32 may fail to execute
to completion or may write to incorrect memory locations on processors
supporting Intel
Problem: In IA-32e mode using Intel EM64T-enabled processors, an REP MOVS or an REP STOS
instruction executed with the register RCX >= 2^32, may fail to execute to completion or may
write data to incorrect memory locations.
Implication: This erratum may cause incomplete instruction execution or incorrect data in the memory. Intel has
not observed this erratum with any commercially available software.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
®
Extended Memory 64 Technology (Intel® EM64T)
S79 An REP LODSB or an REP LODSD or an REP LODSQ instruction with RCX
>= 2^32 may cause a system hang on processors supporting Intel
Extended Memory 64 Technology (Intel
Problem: In IA-32e mode using In tel EM64T-enabled processors, a REP LOSDB or an REP LODSD or an
®
EM64T)
®
REP LODSQ instruction executed with the register RCX >= 2^32 may fail to complete execution
causing a system hang. Additionally, there may be no #GP fault due to the non-canonical address in
the RSI register.
Implication: This erratum may cause a system hang on Intel EM64T-enabled platforms. Intel has not observed
this erratum with any commercially available software.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S80 Data access which spans both canonical and non-canonical address space
may hang system
Problem: If a data access causes a page split across the canonical to non-canonical address space, the
processor may livelock which in turn would cause a system hang.
Implication: When this erratum occurs, the processor may livelock, resulting in a system hang. Intel has not
observed this erratum with any commercially available software.
Workaround: None identified.
Status: For the steppings affected, see the Summary Table of Changes.
S81 Running in System Management Mode (SMM) and L1 data cache adaptive
mode may cause unexpected system behavior when SMRAM is mapped to
cacheable memory
Problem: In a HT Technology-enabled system, unexpected system behavior may occur if a change is made to
the value of the CR3 result from an Resume from System Management (RSM) instruction while in
L1 data cache adaptive mode (IA32_MISC_ENABLES MSR 0x1a0, bit 24). This behavior will
only be visible when SMRAM is mapped into WB/WT cacheable memory on SMM entry and exit.
Implication: This erratum can have multiple failure symptoms, including incorrect data in memory. Intel has not
observed this erratum with any commercially available software.
Workaround: Disable L1 data cache adaptive mode by setting the L1 data cache context mode control bit (bit 24)
of the IA32_MISC_ENABLES MSR (0x1a0) to 1.
Status: For the steppings affected, see the Summary Table of Changes.
64-bit Intel® Xeon® Processor with 800 MHz System Bus 39
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
S82 A 64-bit value of Linear Instruction Pointer (LIP) may be reported incorrectly
in the Branch Trace Store (BTS) memory record or in the Precise Event
Based Sampling (PEBS) memory record
Problem: On a processor supporting Intel EM64T ,
• If an instruction fetch wraps around the 4G boundary in Compatibility mode, the 64-bit value
of LIP in the BTS memory record will be incorrect (upper 32 bits will be set to FFFFFFFFh
when they should be 0).
• If a PEBS event occurs on an instruction whose last byte is at memory location FFFFFFFFh,
the 64-bit value of LIP in the PEBS record will be incorrect (upper 32 bits will be set to
FFFFFFFFh when they should be 0).
Implication: Intel has not observed this erratum on any commercially available software.
Workaround: None identified.
Status: For the steppings affected, see the Summary Table of Changes.
S83 It is possible that two specific invalid opcodes may cause unexpected
memory accesses
Problem: A processor is expected to respond with an undefined opcode (#UD) fault when executing either
opcode 0F 78 or a Grp 6 Opcode with bits 5:3 of the Mod/RM field set to 6, however the processor
may respond instead, with a load to an incorrect address.
Implication: This erratum may cause unpredictable system behavior or system hang.
Workaround: It is possible for BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S84 At core-to-bus ratios of 16:1 and above Defer Reply transactions with
non-zero REQb values may cause a Front Side Bus stall
Problem: Certain processors are likely to hang the Front Si de Bus (FSB) if the following conditions are met:
1. A Defer Reply transaction has a REQb[2:0] value of either 010b, 011b, 100b, 110b, or 111b,
and
2. The operating bus ratio is 16:1 or higher.
When these conditions are met, the processor may incorrectly and indefinitely assert a snoop stall
for the Defer Reply transaction. Such an event will block further progress on the FSB.
Implication: If this erratum occurs, the system may hang. Intel has not observed this erratum with any
commercially available system.
Workaround: None identified.
Status: For the steppings affected, see the Summary Table of Changes.
S85 Processor may issue Frost Side Bus transactions up to 6 clocks after
RESET# is asserted
Problem: The processor may issue transactions beyond the documented 3 Front Side Bus (FSB) clocks and
up to 6 FSB clocks after RESET# is asserted in the case of a warm reset. A warm reset is where the
chipset asserts RESET# when the system is running.
Implication: The processor may issue transactions up to 6 FSB clocks after RESET# is asserted.
Workaround: None identified.
Status: For the steppings affected, see the Summary Table of Changes.
40 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
S86 Front Side Bus machine checks may be reported as a result of on-going
transactions during warm reset
Problem: Processor Front Side Bus (FSB) protocol/signal integrity machine checks may be reported if the
transactions are initiated or in-progress during a warm reset. A warm reset is where the chipset
asserts RESET# when the system is running.
Implication: The processor may log FSB protocol/signal integrity machine checks if transactions are allowed to
occur during RESET# assertions.
Workaround: BIOS may clear FSB protocol/signal integrity machine checks for systems/chipsets which do not
block new transactions during RESET# assertions.
Status: For the steppings affected, see the Summary Table of Changes.
S87 Writing the local vector table (LVT) when an interrupt is pending may cause
an unexpected interrupt
Problem: If a local interrupt is pending when the LVT entry is written, an interrupt may be taken on the
new interrupt vector even if the mask bit is set.
Implication: An interrupt may immediately be generated with the new vector when a L VT entry is written, even
if the new LVT entry has the mask bit set. If there is no interrupt service routine (ISR) set up for
that vector the system will GP fault. If the ISR does not do an end of interrupt (EOI) the bit for the
vector will be left set in the in-service register and mask all interrupts at the same or lower priority.
Workaround: Any vector programmed into an LVT entry must have an ISR associated with it, even if that vector
was programmed as masked. This ISR routine must do an EOI to clear any unexpected interrupts
that may occur. The ISR associated with the spurious vector does not generate an EOI, therefore
the spurious vector should not be used when writing the LVT.
Status: For the steppings affected, see the Summary Table of Changes.
S88 The processor may issue multiple code fetches to the same cache line for
systems with slow memory
Problem: Systems with long latencies on ret urn ing code fetch data from memory, e.g. BIOS ROM, may
cause the processor to issue multiple fetches to the same cache line, once per each instruction
executed.
Implication: This erratum may slow down system boot time. Intel has not observed a failure, as a result of this
erratum, in a commercially available system.
Workaround: None identified.
Status: For the steppings affected, see the Summary Table of Changes.
S89 CPUID feature flag reports LAHF/SAHF as unavailable, however the
execution of LAHF/SAHF may not result in an Invalid Opcode exception
Problem: As described in the IA-32 Intel Architecture Software Developer’s Manual, support for
LAHF/SAHF instructions in 64-bit mode has been added to processors with EM64T enabled. The
CPUID feature flag may indicate that the LAHF/SAHF instructions are unavailable in 64-bit mode,
even though the instructions are supported and able to be executed without an Invalid Opcode
exception.
Implication: The CPUID feature flag incorrectly reports LAHF/SAHF instructions as unavailable in 64-bit
mode, though they can be executed normally.
Workaround: It is possible for BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
64-bit Intel® Xeon® Processor with 800 MHz System Bus 41
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
S90 IRET under certain conditions may cause an unexpected Alignment Check
Exception
Problem: In IA-32e mode, it is possible to get an Alignment Check Exception (#AC) on the IRET instruction
even though alignment checks were disabled at the start of the IRET. This can only occur if the
IRET instruction is returning from CPL3 code to CPL3 code. IRETs from CPL0/1/2 are not
affected. This erratum can occur if the EFLAGS value on the stack has the AC flag set, and the
interrupt handler's stack is misaligned. In IA-32e mode, RSP is aligned to a 16-byte boundary
before pushing the stack frame.
Implication: In IA-32e mode, under the conditions given above, an IRET can get a #AC even if alignmen t
checks are disabled at the start of the IRET. This erratum can only be observed with a software
generated stack frame.
Workaround: Software should not generate misaligned stack frames for use with IRET.
Status: For the steppings affected, see the Summary Table of Changes.
S91 Upper 32 bits of ‘From’ address reported through LBR or LER MSRs, BTMs
or BTSs may be incorrect
Problem: When a far transfer switches the processor from IA-32e mode to 32-bit mode, the upper 32 bits of
the ‘From’ (source) addresses reported through the LBR (Last Branch Record) or LER (Last
Exception Record) MSRs (Model-Specific Registers), BTMs (Branch Trace Messages) or BTSs
(Branch Trace Stores) may be incorrect.
Implication: The upper 32 bits of the ‘From’ address debug information reported through LBR or LER MSRs,
BTMs or BTSs may be incorrect.
Workaround: It is possible for BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Table of Changes.
S1S EXTEST/CLAMP may cause incorrect values to be driven on processor pins
Problem: When using TAP boundary scan instructions EXTEST/CLAMP while SLP# is asserted at certain
bus ratios, incorrect values may be driven on some processor pins. Address Strobe pins do not
respond at bus ratios 15:1 and 16:1, while Address pins and Request Command pins do not respond
at bus ratio 22:1 and 24:1.
Implication: Due to this erratum, incorrect values may be driven on some processor pins during boundary scan
testing.
Workaround: Avoid asserting SLP# when using TAP Boundary Scan instructions EXTEST/CLAMP.
Status: For the steppings affected, see the Summary Table of Changes.
S92 The IA32_MC0_STATUS/ IA32_MC1_STATUS Overflow Bit is not set when
multiple un-correctable machine check errors occur at the same time.
Problem: When two MC0/MC1 enabled un-correctable machine check errors are detected in the same
internal clock cycle, the highest priority error will be logged in IA32_MC0_STATUS /
IA32_MC1_STATUS register, but the overflow bit may not be set.
Implication: The highest priority error will be logged and signaled if enabled, but the overflow bit in the
IA32_MC0_STATUS/ IA32_MC1_STATUS register may not be set.
Workaround: None identified.
Status: No Fix.
42 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Errata
S93 Debug Status Register (DR6) Breakpoint Condition Detected Flags May be
Set Incorrectly
Problem: The Debug Status Register (DR6) may report det ection of a spurious breakpoint condition under
certain boundary conditions when either:
• A "MOV SS" or "POP SS" in st ruction is immediately followed by a hardware debugger
breakpoint instruction, or
• Any debug register access ("MOV DRx, r32" or "MOV r32, DRx") results in a general-detect
exception condition.
Implication: Due to this erratum the breakpoint condition detected flags may be set incorrectly.
Workaround: None identified.
Status: No Fix.
64-bit Intel® Xeon® Processor with 800 MHz System Bus 43
(1 MB and 2 MB L2 Cache Versions) Specification Update
Specification Changes
Specification Changes
There are no new Specification Changes for this revision of the 64-bit Intel® Xeon® Processor
with 800 MHz System Bus (1 MB and 2 MB L2 Cache Versions) Specification Update.
The Specification Changes listed in this section apply to the following documents:
1. 64-bit Intel
Link: http://developer/design/xeon/datashts/306249.htm
2. Intel
Link: http://developer/design/xeon/datashts/302355.htm
All Specification Changes will be incorporated into a future version of the appropriate Intel Xeon
processor documentation.
®
Xeon® Processor with 2 MB L2 Cache Datasheet (Document Number 306249)
®
Xeon® Processor with 800 MHz System Bus Datasheet (Document Number 302355)
44 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Specification Clarifications
There are no new Specification Clarifications for this revision of the 64-bit Intel® Xeon®
Processor with 800 MHz System Bus (1 MB and 2 MB L2 Cache Versions) Specification Update.
The Specification Clarifications listed in this section apply to the following documents:
1. 64-bit Intel
Link: http://developer/design/xeon/datashts/306249.htm
2. Intel
Link: http://developer/design/xeon/datashts/302355.htm
All Specification Clarifications will be incorporated into a future version of the appropri ate Intel
Xeon processor documentation.
®
Xeon® Processor with 2 MB L2 Cache Datasheet (Document Number 306249)
®
Xeon® Processor with 800 MHz System Bus Datasheet (Document Number 302355)
Specification Clarifications
64-bit Intel® Xeon® Processor with 800 MHz System Bus 45
(1 MB and 2 MB L2 Cache Versions) Specification Update
Documentation Changes
Documentation Changes
Note: Documentation changes for IA-32 Intel® Architecture Software Developer’s Manual, Volumes 1,
2A, 2B, and 3 will be posted in the separate document IA-32 Intel
Developer’s Manual Documentation Changes. Follow the link below to become familiar with this
file.
http://developer.intel.com/design/pentium4/specupdt/252046.htm
There are no new Documentation Changes for this revision of the 64-bit Intel® Xeon®
Processor with 800 MHz System Bus (1 MB and 2 MB L2 Cache Versions) Specification Update.
The Documentation Changes listed in this section apply to the following documents:
1. 64-bit Intel
Link: http://developer/design/xeon/datashts/306249.htm
2. Intel
Link: http://developer/design/xeon/datashts/302355.htm
All Documentation Changes will be incorporated into a future version of the appropriate Intel
Xeon processor documentation.
®
Xeon® Processor with 2 MB L2 Cache Datasheet (Document Number 306249)
®
Xeon® Processor with 800 MHz System Bus Datasheet (Document Number 302355)
®
Architecture Software
46 64-bit Intel® Xeon® Processor with 800 MHz System Bus
(1 MB and 2 MB L2 Cache Versions) Specification Update
Loading...
