W476 / W576 Notebook User's Manual

Original Issue: 2008/08

This manual guides you in setting up and using your new Notebook PC. Information in the manual has been carefully checked for

accuracy and is subject to change without notice.

No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic,

mechanical, photocopy, recording, or otherwise, without prior written consent.

Trademarks

Product names used herein are for identication purposes only and may be the trademarks of their respective companies.

Microsoft®, MS-DOS, Windows®, and Windows® Sound System are trademarks of Microsoft Corporation.

Intel®, Centrino™, Centrino Duo™, Pentium® M, Banias, Calexico are registered trademarks of Intel Corporation.

Sound Blaster, Sound Blaster Pro are trademarks of Creative Technology.

All other brands or product names mentioned in this manual are trademarks or registered trademarks of their respective companies.

III

Safety Instructions

Use the following safety guidelines to help protect yourself and
your notebook.

When Using Your W476 / W576 Notebook Computer

CAUTION: Do not operate your portable computer for an

extended period of time with the base resting directly on your
body. With extended operation, heat can build up in the base.
Allowing sustained contact with the skin can cause

English

discomfort or a burn.

• Do not attempt to service the notebook yourself. Always follow in­stallation instructions closely.

• Do not carry a battery in your pocket, purse, or other container
where metal objects (such as car keys) could short-circuit the bat-

tery terminals. The resulting excessive current ow can generate

extremely high temperature and may cause burns to your skin.

• Be sure that nothing rests on your AC adapter’s power cable and
that the cable is not located where it can be tripped over or stepped
on.

• While you are using the computer or charging the battery, place
the AC adapter in a ventilated area, like on a desktop or on the

oor. Do not cover the AC adapter with papers or other items that

may prevent ventilation. Also, do not use the AC adapter while it is
inside a carrying case.

• Do not insert objects into the air vent of your notebook computer.
Doing so can cause short-circuiting and may result in re or electri­cal shock.

• Use only the AC adapter and batteries that are supplied by your
notebook manufacturer. Using other types of battery or AC adapter

may heighten the risk of re or explosion.

• Incorrectly placed batteries may result in an explosion.

• Replace only with the same or compatible battery recommended
by the manufacturer.

• Please discard used batteries according to the manufacturer’s in­structions.

• Before you connect your notebook to a power source, ensure that
the voltage rating of the AC adapter matches that of the available
power source.

- 115 V/60 Hz in most of North and South America and some Far

Eastern countries such as South Korea.

- 100 V/50 Hz in eastern Japan and 100 V/60Hz in western Japan.

- 230 V/50 Hz in most of Europe, the Middle East, and the Far East.

• If you use an extension cord with your AC adapter, ensure that the

total ampere rating of all devices plugged into the extension cord

does not exceed its total capacity.

• When removing battery from your notebook, rst turn off the sys­tem, disconnect the AC adapter from the electrical outlet, then re­move the battery.

• To avoid risk of an electrical shock, do not connect or disconnect
any cables, or perform maintenance or reconguration of this prod­uct during a thunderstorm.

• Do not throw batteries into re, doing so may cause explosion.
Check with local authorities rst for battery disposal instructions.

• When setting up your notebook for work, place it on a level sur­face.

III

W476 / W576 NOTEBOOK SERIES USER’S MANUAL

• When traveling, do not check your notebook as baggage. You can
put your notebook through an X-ray security machine, but never
put your notebook through a metal detector. If you have your note­book checked by hand, be sure to have a charged battery ready in
case you are asked to turn on your notebook.

• When traveling with the hard drive removed from your notebook,
wrap the drive in an insulated material, such as cloth or paper. If
you have the drive checked by hand, you may be asked to install
the drive into your notebook. Your can have the hard drive checked
through an X-ray machine, but never put the drive through a metal
detector.

• When traveling, do not place your notebook in the overhead stor­age compartment where it could shift around. Do not drop your
notebook or subject it to other mechanical shocks.

• Protect your notebook, battery, and hard drive from environmental
hazards such as dirt, dust, food, liquids, extreme temperature, and
direct exposure to sunlight.

• When you move your notebook in environments where there is a
substantial difference of temperature or humidity level, condensa­tion may form on or within your notebook. To avoid damaging your

notebook, please allow sufcient time for the moisture to evaporate

before continue using.

NOTICE: When taking your notebook from a colder to a warmer environ-

ment or vice versa, allow your notebook enough time to adapt to the

new environment before turning on power.

•When unplugging the power cord, please make sure that you pull
on its connector or on its strain relief loop, and not on the power
cord itself. As you pull out the connector, please ensure that it is

pulled out evenly in order not to bend its connecting pins. Also, be­fore you connect the power cord, make sure that both connectors
are correctly oriented and aligned.

• Before you clean your notebook, turn it off rst, unplug it from its

power source, and remove the battery.

• Handle interior components with care. When removing a compo­nent, please hold it by the edge and not on the connecting pins
(such as the memory module).

When using your telephone equipments, safety instructions

should always be followed in order to prevent re, electrical

shock or injuries, these instructions include:

• Do not use this product near water, for example, near a bath

tub, washing basins, kitchen/laundry sinks, wet basements or

swimming pools.

• Avoid using cordless phones during an electrical storm as light

ening may cause electrical shocks.

• Do not use the telephone to report a gas leak within the leak

age area.

WARNING: Void of Warranty

* If the battery is not properly handled, there may be a risk of

explosion; make sure you are using the same or compatible

battery.

Please discard used batteries according to the instructions given

*

by the manufacturer.

Please be aware that use of cracked, severely scratched or poor

*

quality discs may damage the optical drive and corrupt data in

the disc. Such discs may break while drive operates in high-

speed, in this case, your product warranty may be voided.

-

-

-

English

III

IVIII

Regulatory Notices

Federal Communications Commission Notice

This equipment has been tested and found to comply with the limits
for a Class B digital service, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.

Any changes or modications made to this equipment may void the

user’s authority to operate this equipment. This equipment gener­ates, uses, and can radiate radio frequency energy. If not installed

English

and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guaran­tee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by
one or more of the following measures:

● Reorient or relocate the receiving antenna.

● Increase the separation between the equipment and receiv-

er.

● Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

● Consult the dealer or an experienced radio/TV technician

for help.

● All external cables connecting to this basic unit must be

shielded.

For cables connecting to PCMCIA cards, see the option

manual or installation instructions.

Federal Communications Commission (FCC)
PART 68 Warning

This equipment complies with Part 68 of the FCC Rules. On the
bottom of the computer is a label that contains, among other in­formation, the FCC Registration Number and Ringer Equivalence
Number (REN) for this equipment. You must, upon request, provide
this information to your telephone company.
FCC Part 68 Registration Number: 6CTTAI - 25876 - FB - E

REN: 0.8B

The REN is useful to determine the quantity of devices you may
connect to your telephone and still have those devices ring when
your number is called. In most, but not all areas, the sum of the
REN’s of all devices should not exceed five (5.0). To be certain of
the number of devices you may connect to your line, as determined
by the REN, you should call your local telephone company to de­termine the maximum REN for your calling area.

If your MODEM causes harm to the telephone network, the local
Telephone Company may discontinue your service temporarily. If
possible, they will notify you in advance. However, if advanced no­tice isn’t practical, you will be notified as soon as possible. You will
be informed of your right to file a complaint with the FCC.

Your telephone company may make changes in its facilities, equip­ment, operations, or procedures that could affect the proper func­tioning for your equipment. I they do, you will be notified in advance
to give you an opportunity to maintain an uninterrupted telephone
service.

IVIII

CE Notice (European Union)

W476 / W576 NOTEBOOK SERIES USER’S MANUAL

This symbol indicates this W476 / W576 notebook computer
complies with the EMC Directive and the European Union’s Low
Voltage Directive. This symbol also indicates that W451U meets the
following technical standards:

• EN 55022 — “Limitations and Methods of Measurement for the
Radio Interferences of Information Technology Equipment.”

• EN 55024 — “Information technology equipment - Immunity char­acteristics - Limits and methods of measurement.”

• EN 61000-3-2 — “Electromagnetic compatibility (EMC) - Chapter
3: Limits - Section 2: Limits on the harmonic current emissions
(Equipment input current up to and including 16 A per phase).”

• EN 61000-3-3 — “Electromagnetic compatibility (EMC) - Chapter

3: Limits - Section 3: Limits on the voltage uctuations and icker

in low-voltage power supply systems for equipment with rate cur­rent up to and including 16 A.”

• EN 60950 — “Safety of Information Technology Equipment.”

NOTE: EN 55022 emissions requirements provide for two

classicaatios

• Class A governs commercial use

• Class B is governs residential use

BSMI Notice (Taiwan Only)
Most notebook computers are classified by the Bureau of Stan­dards, Meteorology and Inspection (BSMI) as Class B information
technology equipment (ITE).

The symbol above must be attached to the product indicating
compliance with the BSMI standard.

CCC Notice (China Only)

• For W476 only

On Class A systems, the following warning will appear near the
regulation label:

Warning: This is a Class A product. In a domestic environment, this
product may cause radio interference, in which case users may be
required to take adequate measures.

Caution: Suggest to operate under 35˚C

English

IVIII

English

VIV

Preface

Congratulations on your purchase of a Notebook computer! Your
new notebook features the most innovative features in portable
computing technology. It combines state-of-the-art ergonomics with
sophisticated architecture, providing you with a personal computer
that is compact, powerful, and easy to use. Designed for a wide
range of general, business, and personal productivity applications,

this notebook is an ideal choice for use in the ofce, at home, and

on the road.

This Manual contains all the information you need to set up and
use your notebook computer, It describes all of its features in a
thorough yet easy-to-read manner.

VIV

W476 / W576 NOTEBOOK SERIES USER’S MANUAL

Content

Safety instructions ......................................................................... I

Regulatory Notices ........................................................................ III

Preface .......................................................................................... V

Chapter 1 Operating Basics

1.1 Using the Battery Pack .........................................................02

1.2 Connecting the AC Adapter ..................................................03

1.3 Turning Your Notebook On and Off ......................................03

1.4 Installing W476 / W576 Device Drivers ................................04

1.5 Using the Power button ........................................................04

1.6 Keyboad Functions ...............................................................05

1.7 Using the Touchpad ..............................................................08

1.8 Storage .................................................................................09

1.9 Inroducing the Camera .........................................................10

1.10 Graphics Display ...................................................................10

1.11 Protecting Your W476 / W576 Notebook Computer .............12

Chapter 2 Connecting Peripherals

2.1 Using the USB Port ...............................................................15

2.2 Connecting to an External Monitor via the D-sub Port .........15

2.3 Using the Port Replicator Connector ...................................16

2.4 Using the LAN Port ...............................................................17

2.5 Using the Modem Port ..........................................................17

2.6 Using the e-SATA Port ........................................................18

2.7 PCI Express card/Newcard ...................................................18

2.8 Connecting to the HDMI Port ...............................................19

2.9 MS/ MS PRO/MS DUO/MMC/SD Cards ...............................19

2.10 Using your Bluetooth (optional) and Wireless devices. ........20

Chapter 3 Troubleshooting

3.1 Frequently Asked Questions .................................................22

Appendix A W476 Specications..................................................24

Appendix B W576 Specications..................................................26

Appendix C Service Centers ........................................................28

English

VIV

W476 / W576 NOTEBOOK SERIES USER’S MANUAL

Chapter 1 Operating Basics

This chapter will show you how to operate your W476 / W576
notebook computer, including connecting the AC adaptor, turning
the computer on/off, using touch-pad, keyboard, hot keys, battery,
and so on. If you are new to computers and to the operating
sys te m, thi s chapter will guide you through some of the new
exciting features.

English

1PB

32

1.1 Using the Battery Pack

W476 / W576 notebook computer is designed to operate with one
of the following power sources:

• AC power
(using the AC adapter connected to an electrical outlet)

• Lithium-Ion (Li-Ion) battery pack

You should use the AC adapter whenever possible; use the battery
pack only when AC power is unavailable. The rechargeable Li­Ion battery pack allows you to operate your notebook computer

English

without an external power source. When you use the AC adapter
to connect your notebook to a power outlet, the internal battery will
begin to recharge. While the battery is charging, the Battery Charge
icon on the indicator panel will be on. Once the battery is fully
charged, the Battery Charge icon will turn off. Quick charging time
is 2.5 hours for the Lithium-Ion (Li-Ion) battery when the computer
is turned off, while the normal battery charging time is 3.5 hours.

• Operating a fax modem, video, or audio equipment can increase

the use of your computer’s power.

• Decreasing monitor brightness can also save power.

• When the battery is not fully charged, allow your battery to be

charged completely before using it (i.e., before disconnecting AC
power). Calibrating the battery before use is also highly recom­mended.

• Li-Ion Battery is vulnerable, do not charge it with other power adap-

ter, otherwise fire or explosion may occur.

►Replacing the Battery◄

The battery will gradually weaken over time. We recommend that

you replace your battery when you notice a signicant decrease of

battery capacity.
To change the battery pack, follow the steps below:

1. Turn off the computer.

2. Close the lid and ip the computer over.

3. Slide the side battery latch (1) to the left. Continue to hold it
until the battery is removed.

4. Make sure the replacement battery is properly oriented before
inserting it into the battery compartment.

Note: The battery can not be charged to 100% when remaining
battery is no less than 95%. It is based on the supplier’s advice,
and to extend charging frequency and battery life.

►Maintenance of the AC Adapter◄

• Do not connect the adapter to any other device.

•

Do not step on the power cord or place heavy objects on top of it. Ca­refully route the power cord and keep cables away from all traffic.

• When unplugging the power cord, do not pull on the cord itself but

on the plug instead.

• If you are using an extension cord, make sure that the devices

plugged onto the cord do not exceed its total capacity. Furthermo­re, the devices plugged into the electrical outlet shall not exceed
the fuse’s total ampere rating.

• Please verify power voltage before connecting the electrical cord

to the power outlet. If you are uncertain of its power specification,
please consult with your local vendors or power company for more
details.

32

W476 / W576 NOTEBOOK SERIES USER’S MANUAL

1

2

3

1.2 Connecting the AC Adapter

The AC adapter converts AC power to DC power and reduces the
voltage supplied to the computer. It can automatically adjust to any
voltage from 100 to 240 volts and outputs power at 19V, 4.74A for
W476V / W576V (19V, 3.42A for W476M / W576M), allowing you to
use your notebook computer in almost any region.

CAUTIO N: Use only the AC a da pter and the power cor d we
recommend. Using the wrong adapter may damage your computer.
We assume no responsibilities for damages arising from misuse of
AC adapters.

To properly connect the adapter, follow the steps as below:

1. Connect the power cord to the AC adapter.

2. Connect the AC adapter to the DC power port of your computer.

3. Connect the AC adapter power cord to an AC outlet.

1.3 Turning Your Notebook On and Off

►Turning on the power◄
Open the notebook lid, press and hold the power button for one or
two seconds. The power indicator will glow blue once the computer
is powered on.

►Turning off the power◄
If you are not going to use your notebook computer for a while,
it is best to turn off its power. Before turning off power, close all

programs rst and shut down the operating system.

After turning off your notebook computer, make it a habit to leave
the LCD panel open for a while after it has been used for an
extended period of time. This allows the interior of your notebook
computer to cool off. Closing the panel will force the heat up
against the LCD screen, and doing so after a while may damage
the screen. More importantly, never close the LCD panel for a long
period of time when the computer is on or when the power saving
function is disabled.

►Suspend mode◄
You can adjust default power management settings in the Power
Option /Advanc ed dial og box. T he Powe r Opt ions dial og bo x
provides several operating functions after your computer has been
idle for a while.

English

32

54

1.4 Installing W476 / W576 Device Drivers

1.5 Using the Power button

If your W476 / W576 Notebook Computer already has an operating
system installed, it is best to install all necessary device drivers in
order for he hardware to properly function.
Before installing drivers, check with your vendors to see if they
have already installed all the drivers with the operating system, if
not, please follow the steps below:

1. You can nd the Utility Driver CD like the one shown below:

English

2. Put the CD into the CD R-W or DVD-RW (optional) Drive. An
Auto Run installation screen will appear.

The power button located on the top side allow you to power on.

54

1.6 Keyboad Functions

W476 / W576 notebook computer is equipped with a standard
typewriter-layout keyboard and has extra features.

Basic Keypad

Keypad Function Desription

<Enter> key. Execute a command. Within many text
editing programs, the <Enter> key inserts a hard carriage
return, just like what an ordinary typewriter does.
<Esc> key. Press this key to cancel or escape from a
command or function.
<Ins> key. Known as the Insert key. Press this key to
change from insert to type over mode.
<Fn>+<PrtSc> key. Known as the Print Screen key.
Press this key to map the whole screen to share memory

+

for your specic usage.

<Del> key. Known as the Delete key. Press this key to
delete the character to the right of the cursor, or delete
marked texts or items.
<Pause> key. Press this key to temporarily halt execution
of a comm and . Pre ssing an y oth er keys to resu me
execution of a command.

W476 / W576 NOTEBOOK SERIES USER’S MANUAL

<Shift> key. Press this key in combination with letters
to produce uppercase letters in typing. Use this key
in combination with those two-character keys (found
on the second row of the keyboard) to produce the
upper marked keys. Al so us ed in most prog rams
in combination with other keys to execute a certain
command.

<Tab> key. Press this key to move the cursor to the
next tab on the right. This key works much the same
way as on an ordinary typewriter.

<Ctrl> key. Known as the Control key. Used in most
programs in combination with other keys to execute a
command.

<Alt> key. Known as the Alternate key. Used in most
programs in combination with other keys to execute a
command.

English

54

76

<Num Lk> key. Activates the embedded 15-key numeric
keypad.
<Fn>+<Scr Lk> key. Used in most programs to scroll the
screen without having to move the cursor. The keys are

+

in color-coded blue.
<Cap Lock> k ey. Used in most programs t o always
activate uppercase letters.

Up arrow key. Moves the cursor up one line at a time.

Special Function Keys

►Embedded Numeric Keypad◄

English

Down arrow key. Moves the cursor down one line at a
time.

Left arrow key. Moves the cursor to the left one space at
a time.

Right arrow key. Moves the cursor to the right one space
at a time.

<Home> key. Moves the cursor to the beginning of a
screen or line.

<PgUp> key. Moves the cursor up one screen at a time.

<PgDn> key. Moves the cursor down one screen at a
time.

<End> key. Moves the cursor to the end of a screen or a
line.

The embedded numeric keypad functions like the one on a desktop
keyboard. It is indicated by small characters located on the upper
left-hand corner of the keycaps.

Desired Access Num Lock On Num Lock Off

Number keys on
embedded keypad

Note: If an external k eyboard or keypa d is connect ed to your
notebook computer, the Numlock automatically shifts from an
internal keyboard to the external keyboard or keypad.

Type numbers in a
normal manner

76

W476 / W576 NOTEBOOK SERIES USER’S MANUAL

►Windows Keys◄

Key Description

+[F1] Opens help and support

+E Explores my computer

+F Finds document

+M Minimizes all

+ Shift + M

+ R Displays run dialog box

+ Tab Activates next taskbar button

Undoes minimize all

►Basic keypad◄
you can input letters, numbers, punctuation marks, and special
symbols with it.

►Fn Keys◄
By pressing the Fn key with other keys, it can simulate all keyboard
functions of a regular desktop keyboard.

[Fn]+[F1]
[Fn]+[F2]
[Fn]+[F3]
[Fn]+[F4]
[Fn]+[F5]
[Fn]+[F6]
[Fn]+[F7]
[Fn]+[F8]
[Fn]+[F9]
[Fn]+[F10]
[Fn]+[F11]
[Fn]+[F12]
[Fn]+[Esc]

Suspend switch

Activate or deactivate wireless functions

Switch between LCD or CRT monitor

Increase screen brightness

Decrease screen brightness

Audio mute

Decrease audio volume

Increase audio volume

Play or pause media player

Stop media player

Media player skip backward

Media player skip forward

Enable or disable Bluetooth function

English

76

98

1.7 Using the Touchpad

The Touchpad is a pressure-sensitive pointing device that provides
all of the features of a two-button mouse; its primary function is to
move the cursor around the screen.

Touchpad

English

Sin ce t he Touchpad is a pressure-sensiti ve d ev ice, therefore
proper care should be attended to in order to prevent damage.
Please also note the following precautions:

• Make sure the touchpad does not come into contact with dirt,
liquid or grease.

• Do not touch the touchpad if your fingers are dirty.

• Do not place heavy objects on the touchpad or on the touchpad
buttons.

►Clicking◄
You can move the pointer over to the item with your nger on the

pad, and click once on the left button below to select it, or simply
tap once on the touchpad.

Touchpad

buttons

►Double Clicking◄
Move the pointer over to the item with your nger on the pad, and

click twice on the left button to select menu items, or simply tap
twice on the touchpad.

►To drag and drop◄
Move the pointer over to the item with your nger on the pad, click

once on the left button beneath the Touchpad and select the item
you want, once the item is selected, you can then drag the item by

gliding your nger on the Touchpad (clicking twice on the Touchpad

buttons equals to the speed of a double-click on a regular mouse).

►The Scroll buttons◄

If you are scrolling through the document, you may do so by gliding

your nger on the Touchpad while holding the scroll button.

You may adjust your Touchpad settings by going into Start/Control
Panel /Mouse/Buttons. You can change the Touchpad’s operating
orientations through these settings, for example changing from
right-handed to left-handed operations. You may also adjust cursor
speed as well as response time of mouse clicks.

98

W476 / W576 NOTEBOOK SERIES USER’S MANUAL

1

2

1.8 Storage

►Hard Disk◄

W476 / W576 notebook computer is equipped with a built-in large
capacity 2.5 inch IDE hard disk drive where you store or install
your computer operating system as well as software programs. The
internal hard disk is normally assigned as Drive C after formatting.

 If you wish to replac e your hard disk, contact y our local

vendor for info rmati on ab out y ou r n ot ebook comp uter’s
hardware setup.

 You can increase the system’s storage capacity by replacing

the standard hard disk drive with a drive of a greater capacity.

 Always turn off your notebook computer before removing the

hard drive. Failure to do so will damage the computer and the
hard disk. Avoid jarring or moving your computer while the
hard disk is still being accessed.

►Optical Disc Drive (ODD)◄

W476 / W576 notebook computer is equipped with one of the DVD
Super Multi

The optical drive is normally used for installing operating system
and software programs. To insert and remove a disc from the drive:

1. Press the button on the front of the drive to eject the disc tray
and gently pull out the tray.

2. Place the disc on the tray with label side up.

3. Place the disc on the spindle and press it down gently until the
disc clicks into place.

4. Slide the tray back until it clicks shut.

Warning: When the computer is reading from the optical drive, the

indicator light for ODD will ash on. Do not attempt to remove the

disc while the indicator light is still active.

Warning: Do not insert any foreign objects into the disc tray. Do not
force the tray to open or close. When the drive is not in use, keep
the tray closed in order to prevent dust or dirt from entering the drive.

If you experience difculty when removing a disc, stick a paper clip (or

use a pin or a thin metal rod) into the emergency eject hole, the CD
disc tray should eject immediately. This procedure can also be used
to remove a CD from the drive when the notebook is powered off.

Please refer to gure below.

English

98

1110

1.9 Inroducing the camera

1.10 Graphics Display

Your W476 / W576 notebook computer comes with a built-in cam­era.With this camera, you can conduct videoconferences with your
friends or colleagues whenever and wherever as if they are right in
front of you. It also works as a digital camera (with a resolution up to

2.0 Megapixel) that you can use to take snapshots instantly.

►W476 / W576 camera

English

Your computer has a high-performance graphics display system, which
can easily handle the demands of today’s multimedia computing.

►Screen Controls◄
Brightness
Function keys can increase or decrease the brightness of the monitor.

• <Fn> + <F4> decreases the LCD panel brightness.

• <Fn> + <F5> increases the LCD panel brightness.

Resolution

1. Click My Computer/Control Panel/Appearance and Themes/ Display.
Click on the Settings tab. The dialog box will display your monitor’s
current resolution.

2. Under “Screen resolution,” use the slide bar to adjust monitor ’
s resolution. Normally, you should use the resolution your LCD
monitor was designed for.

Note: Using a lower resolution than the screen was designed for will
reduce the displaying area. Using the computer in DOS mode produces
the same effect, because it uses a 640 by 480 resolution by default.

►Dual Displays◄

Under Windows operating system, you may use an external monitor
and your notebook’s LCD screen simultaneously. You may also choose
to only use the external monitor with the LCD disabled or vice versa.

1110

1. Open Control Panel.

2. Double-click on Display. The Display Properties window will
open.

3. Click on the Settings tab.

4. Click on the Advanced button.

■ W476V / W576V

Click on GeForce 9300 (W476V) or 9600 (W576V) tab.

Choose nView Display Settings to adjust.

■ W476M / W576M

Choose Intel Graphics Media Accelerator Driver for mobile.

Click Graphics Properties to adjust.

W476 / W576 NOTEBOOK SERIES USER’S MANUAL

Single Display (for both W476V / W576V and W476M / W576M)

In Single Display mode, you can choose which device to apply as
the Primary display. The video display hot keys are available. You
can select different video outputs by pressing Fn+F3 repeatedly.

Clone (for W476V / W576V)
Extended Desktop (for W476M / W576M)

In Clone/Extended Desktop mode, the vi deo display hot keys
are available. You can select different video outputs by pressing
Fn+F3 repeatedly. If the external monitor is connected, the display
on LCD and external monitor is the same.

Dualview (for W476V / W576V)
Dual Display Clone (for W476M / W576M)

In Dualview/Dual Display Clone mode, choose the monitor for
extended display. Dualview/Dual Display Clone mode is controlled
by the driver. You can adjust the type of video output in the Menu.
Fn+F3 has no switch function under this mode.

English

1110

1312

Tip: In order to ensure problem-free video display, when you
use an external monitor, change the output mode in the Display
properties dialog box first. After changing the output mode, you
can then use the video display hot keys.

Note: Light or dark pixels may appear on the LCD screen as a
result of LCD’s manufacturing limitations, however, this will not
effect your LCD screen’s normal functions.

English

1.11 Protecting Your W476 / W576 Notebook

Computer

W476 / W576 Notebook Computer provides both hardware and
software security locks to protect your computer.

Using a security lock:
A security lock notch can be found on the right side of the com­puter. This notch allows you to connect a Kensington-compatible
security lock to it.

►W476 security lock

►W576 security lock

1312

W476 / W576 NOTEBOOK SERIES USER’S MANUAL

Help

Using a system protecing:
You can only enter the BIOS setup utility only when the computer
is turned on, in another word, between the time it’s turned on and
before the Windows splash screen appears. If your computer is
already turned on, reboot your computer and press the F2 key to
enter the setup utility.

►Security menu◄

• Supervisor Password
A Supervisor Password is required before you set User Password.

After selecting Change Supervisor Password, enter a new pass­word then re-enter it to confirm. The password you enter should
contain up to 6 alphanumeric characters. If you make a mistake
while entering your password, you can always press Esc to start
over.

• User Password
You can enter into the setup utility to change or remove user pass-

words; however, you can not change or remove the Supervisor
Password, nor can you access the diskette.

• HDD Password
To input, change, or disable hard drive password. When shown as

[Locked], the hard drive password currently can not be changed
or disabled. To change or disable the function, turn off the system
and enter Setup right after turning it back on.
* Please remember the password when you decide to use HDD

Password. Your notebook service center may not be able to re­store the HDD once the password is missing.

English

1312

1514

Chapter 2 Connecting Peripherals

English

This chapt er will show you step-by-step how to conne ct your
peripherals to the W476 / W576 notebook computer.

1514

W476 / W576 NOTEBOOK SERIES USER’S MANUAL

2.1 Using the USB Port

The USB port allows multiple peripherals to run simultaneously on

a single computer. These peripherals may include: oppy drives,

mouse, digital cameras, scanners, printers, optical disk drive,
keyboards, and games devices...etc. The USB Port can also act as
a hub or as an external workstation.

►W476 USB Port

►W576 USB Port

2.2

Connecting to an External Monitor via the D-sub Port

The notebook comes with a D-sub port for you to connect to an
external monitor. To connect an external monitor, please follow the
steps below:

1. Turn off your W47 6 / W576 note bo ok and make s ure the
monitor power switch is turned off.

2. Connect the connector cable of the monitor to the D-sub port
on the left side of your notebook. Secure the cable connection
with the screws provided.

3. Connect the monitor power cable and plug it into a properly
grounded wall outlet.

4. Turn on the monitor.

5. Turn on your W476 / W576 notebook. Both the LCD panel and
the monitor screen will show the display. Your notebook is set
at default to run at simultaneous display mode.

6. If you only want to show the display on the external monitor
(CRT/LCD) and shut off the LCD display, you can use the <Fn>
+ <F3> hot-key to switch display type between LCD and CRT.
Keep pressing the hot-key until you get the display to external
CRT/LCD only.

►W476 D-sub Port

►W576 D-sub Port

English

1514

1716

2.3

Using the Port Replicator Connector(

Port Replicator Connector allows you to connect an external port
replicator devices (optional). This external device is an easy one-

step connectivity solution whether at home or the ofce.

English

W576 Only

)

1. DC Power Port
Lets you connect the AC power adapter in supplying continuous
power to your Port Replicator.

2 Serial Port

The serial port, or COM port, allows you to connect serial
devices, such as printers or scanners.

3. External Monitor Port
The external monitor port allows you to connect an external
monitor.

4. Parallel Port
The parallel port, or LPT port, allows you to connect parallel
devices, such as a printer to your notebook.

5. USB V2.0 Port
The two USB ports allow you to connect USB devices such
as external game pads, pointing devices, key boards and/or
speakers.

6. RJ45 10/100/1000Mbps Ethernet LAN Port
Internal LAN port connects your notebook to other computers/
networks through a local area network (LAN)

7. Stereo Line-out Port
The optional stereo line-out port allows you to connect a set of
speakers or a headphone to your notebook.

8. Power Switch

To power up or off the port replicator.

1716

W476 / W576 NOTEBOOK SERIES USER’S MANUAL

2.4 Using the LAN Port

1. Connect one end of the cable into the network wall outlet or the
HUB.

2. Connect the other end of the cable into the computer’s LAN
port.

►

►

W476

W576

LAN Port

LAN Port

2.5 Using the Modem Port

The built-in fax/data modem allows you to connect a phone line to
a phone jack.

►

►

W476

W576

Modem Port

Modem Port

English

1716

1918

2.6 Using the e-SATA Port

2.7 PCI Express card/Newcard

With the built-in e-SATA po rt , you can connect your e-SATA­compatible peripherals for data backup. The Windows operating
sy s tem will auto m atica l ly re c ogni z e the dev i c e an d ins t all
appropriate driver(s) for it. Yet it is still recommended to install
the drivers that came with your peripherals. For more information,
please refer to your hardware manuals.

►

W476

e-SATA Port

English

►

W576

e-SATA Port

The PCI Expr es s car d (or Newcar d) slot can be used a s an
interface between your computer and a variety of communication
device s, such as n etwor k a dapters , f ax/mode ms or e xtern al
storage devices.

►Inserting a Card◄

1. Insert the card with label side up, make sure that the metal
connector is inserted into the card slot.

2. Insert the card into the slot. You will feel some resistance as the
card reaches to the end.

3. Your PCI Express cards require dri ve rs , or programs that
allow the operating system to use the device. Your Windows
operating system should already contain the driver for your
device, if not, you will be prompted to install the driver.

►W476 Newcard slot

►W576 Newcard slot

►Removing a Card◄
Press the eject button on the card slot to release the eject

button, then press the eject button again to release the card.

1918

W476 / W576 NOTEBOOK SERIES USER’S MANUAL

2.8 Connecting to the HDMI Port

Your W476 / W576 notebook computer comes with an HDMI port
which allows you to connect your computer to an external television
set. This is possible by using an HDMI cable:

►W476 HDMI port

►W576 HDMI port

2.9 MS/ MS PRO/MS DUO/MMC/SD Cards

Multimedia card slot is located on the right side of your W476 /
W576 notebook computer, it accepts MS/ MS PRO/MS DUO/
MMC/SD cards.

►W476 Multimedia card slot

►

W576 Multimedia card slot

English

1918

2120

2.10 Using your Bluetooth (optional) and Wireless
devices.

Your W476 / W576 computer supports both Bluetooth and Wi-Fi
compatible devices. You can press Fn+Esc to enable or disable
Bluetooth function only and press Fn+F2 to turn on/off wireless
function only.

****For how to connect your Bluetooth and wireless device to your
comput e r, pl e ase refer to th e ma n u a l fr o m yo u r hardw a r e
manufacturers.****

English

2120

W476 / W576 NOTEBOOK SERIES USER’S MANUAL

Chapter 3 Troubleshooting

In this chapter, we will list some frequently encountered technical
problems and tell you how to resolve them.

English

2120

2322

3.1 Frequently Asked Questions

My computer switches to hibernation mode much too quickly



and I have to constantly hit a key or move the mouse to bring
back the screen. What can I do?

This is part of Windows Power Management. Access Power
Management by clicking on Start / Control Panel / Performance
and Maintenance / Power Options, and change the time next to
the “Turn off monitor” option to the time you want. You have the

English

choice of either adjusting time for the power supply or for the
battery.

I’ve heard that cleaning and rearranging les on the hard drive



will improve program’s launch speed. How do I do this?

Go o d disk maintena n c e s can improve program launch

speed. This normally includes deleting unnecessary les, and

defragmenting hard disk so that files can be more efficiently
grouped. Windows contains maintenance utilities for these

tasks; run Disk Cleanup to remove unnecessary les, and Disk
Defragmenter to defragment fragmented le blocks. For more

information about these utilities, please refer to your Windows
documentation.

The dial tone volume of the internal fax/modem is too low. How



can I increase its volume?

Go to Start/Control Panel/Sounds, Speech, and Audio Devices,
under Device volume, adjust your speaker volume by controlling

the volume bar.

What kind of external microphone can I use with my notebook



computer?

You will need to use a self-amplifying microphone.

There are echoes coming from my speakers. What can I do?



Double click on the Speaker icon on the task bar. Then, under
Microphone Balance, check the Mute box.

Because of a sof tw ar e problem, I was unable to shut the



computer down from Windows, I pressed the power button to
power off the computer, but it didn’t work. How can I force a
power off?

Make sure you press the power button for at least 4 seconds.
Normally, this will force the computer to shut off.

Why can’t I charge the battery of my notebook computer after it



is out of use for some time?

After your notebook computer has not been used for a long
time (for example: more than one month), the battery will enter
into low voltage protection mode. Under this circumstance,
restoring to normal voltage will require the battery to be slowly
charged for several hours. Once the battery has been fully
charged, your computer will resume to normal operation.

2322

W476 / W576 NOTEBOOK SERIES USER’S MANUAL



My computer says: “CMOS Battery Low”, what should I do?

If your computer is without power (i.e. unplug the computer
power source from the power outlet and remove the battery
pack from it) for over 45 days, you would lose the information
stored in CMOS.

Please fol lo w the s teps below to r ec onfigure your C MO S
settings:

1. Press F2 to enter into the BIOS setup utility.

2. Se l ect “Loa d Opt iona l Def a ults ? ”. W h en yo u see the
following prompt, choose <OK> and then press <Enter>.

3. Select “Save Changes and Exit”, select <OK> and press
<Enter> to restart your computer.



How to unplug or eject devices

In the notication area next to your task bar, double-click the

1.
Safe Removal icon. Safe removal displays a list of Plug and
Play devices that support safe removal and that are currently
attached to the system. If you do not see the Safe Removal
icon, your device does not support safe removal, and you
cannot unplug or eject your device using Safe Removal.

2. In Safely Remove Hardware, in the list of devices, select the
device that you want to unplug or eject, and then click Stop.

This tells the system that you will be unplugging or ejecting

the device.

3. In Stop a Hardware device, click OK.

A notication appears stating that it is now safe to unplug or

eject the device.

Caution
Unplugging or ejecting a device that supports safe removal
without first using the Safe Removal application to warn the
system can cause data to be lost or your system to become
unstable. For example, if a device is unplugged during a data
transfer, data loss is likely. If you use Safe Removal, however,
you can warn the system before you unplug or eject a device,
preventing possible loss of data.

Note
For removable storage devices that can safely be removed
while the system is on, the system disables write caching by
default. It does this so the devices can be removed without loss
of data. When write caching is disable, however, the system
will likely experience slower performance, so be sure to enable

write caching when you have nished removing the device.

English

2322

2524

Appendix A W476 Specications

English

This append ix li sts t echnica l and hard ware spec ifica tions of
your W476 notebook computer. Please note that the information
me n tione d her e may not comp l e tely match you r not e b ook

computer’s actual specications. Specication is subject to change
without notice, and the present manual may be modied at a later

time.

2524

W476 / W576 NOTEBOOK SERIES USER’S MANUAL

Microprocessor

• Intel® Centrino® 2 Processor Technology

• 45nm Intel® Core™2 Duo processor (Penryn) 2.26G~2.8G

• Intel® Celeron® processor (Montevina)

• PGA package478pin, Socket P

• 1066MHz FSB

Core Logic

®

PM45/ ICH9M (W476V)

• Intel

®

• Intel

GM45/ ICH9M (W476M)

Memory

• 512MB to maximum 8GB 667/800MHz DDR2 SDRAM with two
SODIMM memory sockets

• 1 MB flash ROM BIOS

Data Storage

• SATA hard disk, 5400 rpm, available in 160GB/250GB/320GB

• One modularized 5.25”/12.7mm slim DVD-COMBO/DVD-Dual/
Super Multi

• 5-in-1 MS/ MS PRO/MS DUO/MMC/SD Card Reader

Graphics

• NVIDIA

• Intel

®

Geforce 9300M GS 256MB (W476V)

®

Graphics Media Accelerator (GMA 4500MHD) (W476M)

Display and Video

• 14.1” TFT-LCD, WXGA (1280x800), Glare Type

• Simulataneous LCD and CRT display support

• Dual indenpendent display

Connectivity

• Intergrated 10/100 Mbps Fast Ethernet connection

• Built-in 56Kbps V.92 fax/data modern

• Three Universal Serial Bus (USB) 2.0 ports

• Dual band antenna Intel® Wireless LAN Shirley Peak (1x2) a/g/n
(Intel® WiFi Link 5100) (Option)

Audio

• Built-in High Definition Audio

• Built-in two stereo speakers Dual Array Microphone

• Separate audio port s for headphone-o ut a nd microphone-in
devices

Keyboard and pointing devices

• 86-key US/87-key EU/90-key JP with Windows function keys

• Ergonomically-centered touchpad p ointing device with scroll
function

I/O ports

• One e-SATA / USB2.0 combo Port

• One RJ-11 phone jack (V.92, 56Kbps modem)

• One RJ-45 network jack

• One DC-in jack (AC adapter)

• One D-SUB

• One speaker/headphone-out jack (3.5mm mini jack)

• One MIC-in jack (3.5mm mini jack)

• One PCI Express Card

• One HDMI Port for W476V

• Two USB 2.0 Ports

Dimensions and Weight (with battery and optical drive)

• 14.1” display model; about 2.38kg (W476V), 2.36kg (W476M)

•

338(W)x239(D)x29.8~38.4(H) mm

Power: 90W AC adapter, 19V 4.74A (W476V)
65W AC adapter, 19V 3.42A (W476M)

English

2524

2726

Appendix B W576 Specications

English

This append ix li sts t echnica l and hard ware spec ifica tions of
your W576 notebook computer. Please note that the information
me n tione d her e may not comp l e tely match you r not e b ook

computer’s actual specications. Specication is subject to change
without notice, and the present manual may be modied at a later

time.

2726

W476 / W576 NOTEBOOK SERIES USER’S MANUAL

Microprocessor

• Intel® Centrino® Processor Technology

• 45nm Intel® Core™2 Duo processor (Penryn) 2.26G~2.8G

• Intel® Celeron® processor (Montevina)

• PGA package478pin, Socket P

• 1066MHz FSB

Core Logic

®

PM45/ ICH9M (W576V)

• Intel

®

• Intel

GM45/ ICH9M (W576M)

Memory

• 512MB to maximum 8GB 667/800MHz DDR2 SDRAM with two
SODIMM memory sockets

• 1 MB flash ROM BIOS

or

• 2GB

4GB Intel® Turbo Memory (Option)

Data Storage

• SATA hard disk, 5400 rpm, available in 160GB/250GB/320GB

• One modularized 5.25”/12.7mm slim DVD-COMBO/DVD-Dual/
Super Multi

• 5-in-1 MS/ MS PRO/MS DUO/MMC/SD Card Reader

Graphics

• NVIDIA

• Intel

®

Geforce 9600M GS 512MB (W576V)

®

Graphics Media Accelerator (GMA 4500MHD) (W576M)

Display and Video

• 15.4” TFT-LCD, WXGA (1280x800), Glare Type

• Simulataneous LCD and CRT display support

• Dual indenpendent display

Connectivity

• Intergrated 10/100/1000 Mbps Fast Ethernet connection

• Built-in 56Kbps V.92 fax/data modern

• Three Universal Serial Bus (USB) 2.0 ports

• Dual band antenna Intel® Wireless LAN Shirley Peak (1x2) a/g/n
(Intel® WiFi Link 5100) (Option)

Audio

• Built-in High Definition Audio

• Built-in two stereo speakers Dual Array Microphone

• Separate audio port s for headphone-o ut a nd microphone-in
devices

Keyboard and pointing devices

• 86-key US/87-key EU/90-key JP with Windows function keys

• Ergonomically-centered touchpad p ointing device w ith scroll
function

I/O ports

• One e-SATA / USB2.0 combo Port

• One RJ-11 phone jack (V.92, 56Kbps modem)

• One RJ-45 network jack

• One DC-in jack (AC adapter)

• One D-SUB

• One speaker/headphone-out jack (3.5mm mini jack)

• One MIC-in jack (3.5mm mini jack)

• One PCI Express Card

• One HDMI Port

• Two USB 2.0 Ports

Dimensions and Weight (with battery and optical drive)

• 15.4” display model; about 2.66kg (W576V), 2.6kg (W576M)

•

357(W)x257(D)x29.8~38.8(H) mm

Power: 90W AC adapter, 19V 4.74A (W576V)
65W AC adapter, 19V 3.42A (W576M)

English

2726

2928

Appendix C Service Centers

English

This appendix will list our global service centers for your W476 /
W576 notebook computer.

2928

W476 / W576 NOTEBOOK SERIES USER’S MANUAL

Taiwan (Headquarters) GIGA-BYTE TECHNOLOGY CO., LTD.

Address: No.6, Bau Chiang Road, Hsin-Tien, Taipei 231, Taiwan
TEL: [phone]
FAX: [phone]

WEB Address (English): http://www.gigabyte.com.tw/
WEB Address (Chinese): http://www.gigabyte.tw/

U.S.A. G.B.T. INC.

TEL: [phone]
FAX: [phone]
WEB Address: http://www.gigabyte.us

China G.B.T. TECH. TRADING CO., LTD.

WEB Address: http://www.gigabyte.com.cn/

Guangzhou
TEL: [phone]
FAX: [phone]

Beijing
TEL: [phone]
FAX: [phone]

Chengdu
TEL: [phone]
FAX: [phone]

Wuhan
TEL: [phone]
FAX: [phone]

Xian
TEL: [phone]
FAX: [phone]

Shenyang
TEL: [phone]
FAX: [phone]

Shen Zhen
TEL: [phone]
FAX: [phone]

Ningbo
TEL: [phone]
FAX: [phone]

Russia

Moscow Representative Ofce of Giga-Byte Technology Co., Ltd.

TEL: [phone]
WEB Address: http://www.gigabyte.ru/

Germany

HAMBURG Representative Ofce of Giga-Byte Technology Co.,

Ltd.

TEL: [phone]
Address: BULLENKOPPEL 16 22047 HAMBURG

English

2928
