Intel® Entry Server Board SE7210TP1-E,
Intel Server Platform SR1325TP1-E, Intel®
Server Chassis SC5200 and SC5250-E
Configuration Guide and Spares/Parts List
A reference guide to assist customers in ordering the necessary components to configure
the Server Board SE7210TP1-E, Server Platform SR1325TP1-E, Server Chassis SC5200 and
SC 5250-E Products
Rev 1.0
Change History:
10/23/2003 Rev 0.5 First revision
11/13/2003 Rev 0.7 Additional
11/27/2003 Rev 0.8 Formatting edits and updates; added available silver accessory information
2/6/2004 Rev 1.0 Minor format updates and removed all silver references in document
SERVER BOARD SE7210TP1-E-E & SERVER CHASSIS SC5100 CONFIGURATION GUIDE
information on spares/accessories and SR1325TP1 product
2
Disclaimer
Information in this document is provided in connection with Intel® products. No license, express or implied, by estoppel
or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's Terms and
Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied
warranty, relating to sale and/or use of Intel products including liability or warranties relating to fitness for a particular
purpose, merchantability, or infringement of any patent, copyright or other intellectual property right. Intel products are
not intended for use in medical, life saving, or life sustaining applications. Intel may make changes to specifications and
product descriptions at any time, without notice.
*Other brands and names may be claimed as the property of others. Intel, Pentium, Itanium, and Xeon are trademarks
or registered trademarks of Intel Corporation.
All products, dates, and figures are preliminary and are subject to change without any notice.
Copyright © Intel Corporation 2002/2003.
Contents
Contents............................................................................................................ 2
SE7210TP1-E Product Family Overview ........................................................3
SE7210TP1-E Board Configuration Overview ................................................3
Intel Server Platform SR1325TP1 Configuration Overview............................ 4
SE7210TP1-E Chassis Offerings ....................................................................5
SE7210TP1-E Baseboard Ordering Information............................................. 5
Intel Server Platform SR1325TP1 Ordering Information ................................6
Intel® RAID Controller Options for Server Board SE7210TP1-E................... 6
Server Chassis SC5200 BRP (BRP) Ordering Information............................7
Server Chassis SC5250-E Ordering Information ............................................7
Spares and Accessories: ................................................................................. 8
SE7210TP1-E Board Spares and Accessories (N/A)....................... 8
Integrated Platform SR1325TP1 Spares and Accessories............... 8
SC5200 Production Chassis Spares and Accessories ..................... 9
SC5250-E Production Chassis Spares and Accessories ...............10
SE7210TP1-E-E CONFIGURATION GUIDE
3
Production Configurations
SE7210TP1-E Product Family Overview
The Intel SE7210TP1-E product family consists of four production board skus and an integrated 1U sku known
as the Intel Server Platform SR1325TP1-E. This configuration guide describes the following production board
and chassis skus which are being offered as part of the SE7210TP1-E product family;
a) SE7210TP1 – Boxed board (base sku)
b) SE7210TP1SCSI – Boxed board with an additional integrated Adaptec single channel U320 controller
c) BTPBB – OEM 10-pack (base sku)
d) BTPSCSIBB – OEM board with an additional integrated Adaptec single channel U320 controller
e) SR1325TP1 – Integrated 1U server platform (See SR1325TP1-E Configuration Overview Section
below for more information)
SE7210TP1-E Product Family Board Configuration Overview
This section contains information needed to order and configure a production Server Board SE7210TP1-E with
a Server Chassis SC5200, SC5250-E or a third party pedestal chassis.
1. The SE7210TP1-E product family is offered in four production board configurations;
a) SE7210TP1 – Boxed board (base configuration: Parallel ATA and Serial ATA device support)
b) SE7210TP1SCSI – Boxed board base configuration with an additional integrated Adaptec single
channel U320 controller
c) BTPBB – OEM 10-pack (10-pack of boards; base configuration)
d) BTPSCSIBB – OEM 10-pack (10-pack of boards; base configuration with an additional integrated
Adaptec single channel U320 controller
2. The production Boxed Server Board SE7210TP1 contains the following:
a. One Intel
b. Quick Start User Guide
c. 2 CD-ROMs with Intel Server Management 5.8 software**, software drivers, configuration tools,
and technical product information
d. Two Serial ATA cables
e. One floppy-drive cable
f. One ATA/66/100 hard-drive cable
g. ATX 2.01–compliant I/O shield
h. Configuration label, stickers and back-panel label
3. The production Boxed Server Board SE7210TP1SCSI contains the following in addition to the boxed
SE7210TP1 listed above in section 2:
• One U320 SCSI cable
Entry Server Board SE7210TP1 (base configuration)
4. The Intel Entry Server Board SE7210TP1-E has been validated with the following Intel chassis:
• Intel Server Chassis SC5200 (Base Redundant Power)
• Intel Server Chassis SC5250-E
5. The Intel Entry Server Board SE7210TP1-E is also validated with a number of third party pedestal and highdensity chassis. Please see the SE7210TP1-E section of support.intel.com (post launch) and the product
snapshot updates (pre-launch) for the latest reference chassis list and information.
SE7210TP1-E-E CONFIGURATION GUIDE
4
Intel Server Platform SR1325TP1-E Configuration Overview
This section contains ordering and configuration information for the Intel Server Platform SR1325TP1-E. This is
an Intel designed and integrated 1U high density platform consisting of an SE7210TP1-E family server board
and an Intel 1U enclosure which is designed only to be supported and offered to customers as the Intel Server
Platform SR1325TP1 product sku.
Note: Intel is not offering a stand alone SR1325-E chassis sku for the SE7210TP1-E product family.
Customers configuring with third party high density chassis solutions should order one of the four SE7210TP1-E
board configurations described in the previous section (See section 1 of the SE7210TP1-E Board Configuration
Overview)
1. The SR1325TP1-E integrated server platform contains five fans and a 250W Power Supply. The Intel
Server Platform SR1325TP1-E includes:
• 1U SR7210TP1-E server board
• 1U SR1325-E chassis with 250W Power Supply
• Chassis cooling fans and ducting
• 1U Intel designed heatsink and heatsink mounting plate
• CD cable
• Floppy cable
• CD and floppy filler panel
• Intel cosmetic bezel
• North American power cord (varies by sku – see ordering tables below)
• Front panel board and cable (34-pin baseboard header to front panel)
• One PCI riser card assembly (one PCI-X capable slot)
• Intrusion switch
• Floppy/CD bracket assembly
• HDD Carrier Trays (2)
• I/O gasket
• Fixed drive bay supporting two cabled IDE, SATA or SCSI HDD’s (SCSI cable not included)
Note: A KDK Accessory Kit ships with the Server Platform SR1325TP1-E and includes the following
additional items. (This kit is included with the Server Platform SR1325TP1-E)
¾ 2 SATA Cables
¾ 1 IDE Cable
¾ Flex circuit CD interface board to floppy drive cable
¾ CD Interface board and mounting screws
¾ Floppy mounting screws
¾ Boxed board configuration label
¾ Rack handles (2) and screws
¾ Cable ties
¾ Quick start guide
¾ Appropriate additional screws
¾ 2 CD-ROMs
o Intel Server Management 5.8 software,
o Resource CD with software drivers, utilities software, configuration tools, and technical
information
• Rack rails are not
• Support for 3
included but are available as a separate accessory item (see ordering tables below)
rd
HDD (SATA or IDE) via an accessory kit upgrade (see ordering tables below)
SE7210TP1-E-E CONFIGURATION GUIDE
5
Note: The Intel Server Platform SR1325TP1-E does not ship with a CPU, HDD, memory, floppy drive or
CD drive populated. CD and floppy drives can be ordered from the SR1325TP1-E accessory list. See the
accessory list in this configuration guide for a list of available SR1325TP1-E spares and accessories along
with the necessary ordering information. Please reference the latest THOL for the latest list of validated and
compatible drives.
SE7210TP1-E Chassis Offerings
This section contains information needed to order and configure a production Server Board SE7210TP1-E with
a Server Chassis SC5200, SC5250-E or third party pedestal chassis.
1) The Intel Server Chassis SC5250-E is available in either black or beige and includes two system fans and
a fixed 450W power supply. A hot swap SCSI backplane accessory is available as an upgrade option. The
chassis contains the following:
• Fixed power supply
• Two system fans
• Cables (1 each)
o Front panel cable
o USB cable
o Chassis intrusion cable
• Adapter plates for hot swap SCSI backplane
• North American power cord (varies by SKU –see table below)
• Optional SATA backplane accessory
• Printed Quick Start Guide and electronic copy of product guide (manual) on a CD-ROM.
2) The Intel Server Chassis SC5200 is available in two SKUs. One with a fixed power supply and another
with a redundant power supply. Full validation on the SE7210TP1-E has been completed on the redundant
power supply (BRP) version. There are also accessories available to reconfigure as a rack and add a hot
swap SCSI backplane. The KDK contains the following:
• Fixed power supply (450W) or redundant power supply (450W 1+1)
• Four system fans and EPAC (not hot-plug)
• Cables (1 each):
o Front Panel Cable (34-pin baseboard header to front panel)
o USB Cable (USB header to front panel board)
o Chassis Intrusion Cable (baseboard header to chassis switch)
• North American power cord (varies by SKU –see table below)
• Printed Quick Start Guide and electronic copy of product guide (manual) on a CD-ROM.
3. The Server Board SE7210TP1-E is also validated with a number of third party pedestal and high density
chassis. Please see the SE7210TP1-E section of support.intel.com for details.
SE7210TP1-E Production Board Ordering Information
Product Code MM # UPC Quantity
Included
SE7210TP1 855944 7 35858 16392 7 1 Intel entry server SE7210TP1 Boxed
Description
Board (base configuration; with 2
SE7210TP1-E-E CONFIGURATION GUIDE
6
integrated SATA ports and 2 PATA
headers)
SE7210TP1SCSI 855938 7 35858 16393 4 1 Intel entry server SE7210TP1SCSI
Boxed Board (base configuration
and an integrated single channel
U320 SCSI controller)
BTPBB 855936 7 35858 16557 0 1 OEM 2-port sku (10 pack). 10-pack
Base board only (base configuration;
with 2 integrated SATA ports and 2
PATA headers)
BTPSCSIBB 855937 7 35858 16556 3 1 OEM 2-port sku (10 pack). 10-pack
Base board only. (base
configuration and an integrated
single channel U320 SCSI controller)
Intel Server Platform SR1325TP1-E Ordering Information – Production Units
Product Code MM # UPC Quantity
Included
SR1325TP1 856605 7 35858 16394 1 1 Integrated 1U SR1325TP1-E
production server platform with
board and chassis. Includes 1U
heatsink.
-- Power cord NOT included
SR1325TP1NA 857848
7 35858 16395 8 1 Integrated 1U SR1325TP1-E
production server platform with
board and chassis. Includes 1U
heatsink
-- Power cord included
Intel® RAID Controller Options for Server Board SE7210TP1-E
Product Code MM # UPC Quantity
Included
Description
Description
SRCU42L 847810 7 35858 15787 2 1 Intel® SRCU42L RAID Controller:
2 Channel (1 internal, 1 external) U320
RAID controller with 80303 @100
MHz I/O Processor with 64MB cache.
SE7210TP1-E-E CONFIGURATION GUIDE
7
Low profile PCI card with audible
alarm
SRCZCR 851134 7 35858 15891 6 1 Intel SRCZCR RAID Controller –
Modular ROMB solution. Turns two
onboard SCSI channels into RAID.
32MB memory integrated, PCI 64/66,
Intel® 80303 I/O Processor
Server Chassis SC5200 BRP (Base Redundant Power) Ordering Information
Product Code MM # UPC Quantity
Included
KHD3RP450 853634 735858 15931 9 1 Redundant chassis SKU, 450W
KHD3RP450NA 852134
735858 15931 9 1 Redundant chassis SKU, 450W
Server Chassis SC5250-E Ordering Information
Description
1+0 chassis with one power
supply modules. Hot swap drive
backplane is NOT included in
this SKU, but can be purchased
as an accessory
-- Power cord NOT included
1+0 chassis with one power
supply modules. Hot swap drive
backplane is NOT included in
this SKU, but can be purchased
as an accessory
-- Power cord included
Product Code MM # UPC Quantity
Included
KPTBASE450 853718 735858159456 1 SC5250-E production chassis
(Beige color) – Power cord NOT
included
KPTBASE450NA 854463 735858159456 1 SC5250-E production chassis
(Beige color) – Power cord
Included
SE7210TP1-E-E CONFIGURATION GUIDE
Description
8
KPTBASE450BLK 853719 735858159647 1 SC5250-E production chassis
(Black color) – Power cord NOT
included
KPTBASE450BLKNA 854465 735858159647 1 SC5250-E production chassis
(Black color) – Power cord
included
Spares and Accessories:
SE7210TP1-E Board Spares and Accessories (N/A)
Integrated Platform SR1325TP1-E Spares and Accessories
Product Code MM # UPC Qty.
Included
FXXCBL250K 856361 7 35858 16418 4 1 250W Power Supply
AXXTPHS 856583 7 35858 16419 1 1 1U Heatsink, heatsink mounting
FTPAPMKIT 856368 7 35858 16420 7 1 SR1325TP1 chassis maintenance
AXXSCD* 856519 7 35858 16426 9 1 Slimline CD Accessory and
AXXSFLOPPY* 856444 7 35858 16427 6 1 Slimline Floppy Accessory and
AXX1U2URAIL* 837071 7 35858 14763 7 1 Rail kit for Intel Server Platform
FXXBRACKETS* 837069 7 32858 14762 0 1 1U brackets for Intel Server
Description
plate and installation guide
kit
mounting hardware
mounting hardware
SR1325TP1-E and other Intel
chassis. Contains (1) set of left 7
right rail kit (1/2 bearing), (1) rail
installation instruction sheet
Platform SR1325TP1-E and other
Intel server chassis. Contains (1)
Right/Front/Mid brackets, (1)
Left/Front/Mid bracket, (1)
Right/Rear bracket, (1) Left/Rear
bracket, appropriate
screws/washers, installation
SE7210TP1-E-E CONFIGURATION GUIDE
9
AKASCSICABLE* 853922 7 35828 16108 4 1 SCSI cable and terminator
ATPA3HDUPKIT 857943 7 35858 16573 0 1 Optional HDD kit for support of a
SC5200 Production Chassis Spares and Accessories
instruction kit
third SATA or IDE HDD with the
Intel Server Platform SR1325TP1.
(3rd HDD enabled in place of the
CD/floppy). Includes three SATA
cables, CDROM filler panel,
appropriate screws and an
installation guide
Product Code MM # UPC Qty.
Included
AXX2HSDRVUG 835948 7 35858 14630 2 1 HOT SWAP SCSI DRIVE
AHD2RACK
AHG2IO 844599 7 35858 15299 0 50 I/O SHIELD AND GASKET-
FHD3BRPS450W 851831 735858 15948 7 1 Spare 450W power module for
FHD3BRPDB 852234
835849 7 35858 14670 8 1 RACK KIT- TO CONVERT PED
735858 15965 4
1 Power distribution board spare for
Description
UPGRADE KIT - UPGRADE BASE
KDK SKU TO 5 HOT SWAP SCSI
DRIVES or HSRP to 10 drives
SKU INTO 5U RACK. INCLUDES
RAILS, RACK MOUNTING HDW,
RACK BEZEL IN BLACK.
SE7505VB2. COMMON PART
WITH SHG2
SC5200 Base Redundant KDK.
Power cord not included.
the SC5200 Base Redundant KDK
power supply
FHD2DLTBRK 836423 7 35858 14669 2 5 SETS DLT MOUNTING BRACKET,
INCLUDES SLIMLINE CD ROM
MOUNTING BRACKET, AND
CONNECTOR BOARD
FHD2FPBRD 835851 7 35858 14622 7 1 FRONT PANEL BOARD & CABLE
SE7210TP1-E-E CONFIGURATION GUIDE
0
FHD2HWKT 836557 7 35858 14707 1 1 HARDWARE KIT – SCREWS FOR
BOARD MOUNTING AND 2 PAIR
OF 5.25” DRIVE RAILS
FHDSDE
823386 7 35858 12706 6 5 Sets SPARE, RIGHT AND LEFT SIDE
PANELS- PAINTED
FHDTP 823385 7 35858 12707 3 10 SPARE,TOP PANEL- PAINTED
FHDBTTM
FHDFEET
FHDPKG
823372 7 35858 12708 0 10 SPARE, BOTTOM PANEL-
PAINTED
823396 7 35858 12709 7 10 SPARE, PEDISTAL FOOT
(BEIGE)
823390 7 35858 12713 4 1 SPARE, PACKAGING
AXXEXTSCSICBL
830656 7 35858 13953 3 1 ACCESSORY, EXTERNAL SCSI
CABLE
ASATAHSDB 853276 7 35858 15948 7 1 SATA Drive bay including SATA
hot swap drive bay assembly, 4
SATA drive carriers, 1 SATA
connection ID label, 4 SATA cables
and 1 user guide. Works with
SC5250-E and SC5200 Base, BRP
and HSRP chassis
PWRCABLEUS
816324 7 35858 16288 3 1 North American Power Cord
SC5250-E Production Chassis Spares and Accessories
Product
Code
AXX2HSDRVUG 835948 7 35858 14630 2 1 HOT SWAP SCSI DRIVE UPGRADE KIT -
FPTPMKIT 852425 7 35858 15972 2 1
MM # UPC Qty.
Included
Description
UPGRADE BASE KDK SKU TO 5 HOT
SWAP SCSI DRIVES
Preventative maintenance Kit
1 Front Panel Board
1 Front Panel cable
1 USB cable
1 Intrusion Switch/cable
1 92MM fan
1 120MM fan with fan guard attached
1 box of hardware which consist of:
2 left side peripheral rails
SE7210TP1-E-E CONFIGURATION GUIDE
1
2 right side peripheral rails
1 lockplate
15 standoffs for server board mounting
9 screws to mount RM
38 screws to mount server board, etc
(common screw)
11 countersunk screws to mount
CDROM, Floppy, etc
4 screws to mount fan to a Hud3 HS
Bay
4 tie wraps for cable management
1 cable clamp for cable management
1 cable tie to cable management with
Hud3 HS Bay
1 rubber bumper for server board
mounting
2 mounting brackets for Hud3 HS bay
PWRCABLEUS
ASATAHSDB 853276 7 35858 15948 7 1 SATA Drive bay including SATA hot swap
FPTCOSMKIT 852424 7 35858 15973 9 1 SE5250-E Cosmetic kit
816324 7 35858 16288 3 1 North American Power Cord
drive bay assembly, 4 SATA drive carriers, 1
SATA connection ID label, 4 SATA cables and
1 user guide. Works with SC5250-E and
SC5200 Base, BRP and HSRP chassis
1 black bezel 1 dusty beige bezel 4 chassis
feet 2 side cover latches
SE7210TP1-E-E CONFIGURATION GUIDE
11
Loading...
