The RAID Expander RES3FV288 is a RAID expander with these features:
RAID Expander Card RES3FV288
Figure 2. Intel®
Form Factor Low-profile MD2 SFF card size
Bus compatibility PCIe
PCIe bus width x4
Data transfer rate 12 Gb/s per port
Phys (Unified Serial Ports) 36
Connectors, external 1 mini-SAS HD x2 (SFF-8644) 8 ports
Connectors, internal 1 mini-SAS HD x1
Maximum number of disk drives up to 24 direct-attached
Enclosure Support SES-3
Thermal Sensor Processor temperature
Encryption No
RAID Expander Card
1 mini-SAS HD x2
1 mini-SAS HD x4
(SFF-8643) 28 ports
This section explains how to install your RAID Expander and connect it to internal and external disk drives.
4.1 Before You Begin
• Read Appendix A: Safety Information.
• Familiarize yourself with your product's physical features (see Section 3.1 Standard RAID Expander Features on
Page 3).
•Ensure that you have the right number of drives and cables for your application (see Section 4.3
Drives and Cableson Page 9).
Selecting Disk
4.2 Replacing the Full-Height Bracket with a Low-
Profile
Bracket
If you are installing your RAID Expander into a low-profile computer cabinet, replace the original full-height bracket
with the low-profile bracket included in your distribution kit.
expander, and the low-profile
To replace the full-height bracket with the low-profile bracket:
1. Remove the full-height bracket from the expander card. The full-height bracket is
expander, with the mounting screws inserted from
remove the mounting
bracket is mounted on the back, as shown in the figures below.
Low-profile bracket
Figure 3. Replacing the Bracket
screws, as shown in Figure 5, then set the screws aside for use in the next step.
The full-height bracket is mounted on the front of the
installed on the front side of the
the back (see Figure 4). Using a Phillips head screw driver,
2. Attach the low-profile bracket to the expander card. The low-profile bracket is
side of the expander, with the mounting screws inserted from
Insert the screws through the holes on the front of the expander, then fasten the
bracket with a Phillips screw driver.
the front, as shown the Figure 6.
Figure 5
installed on the back
screws to the
Caution: The mount points on the low-profile bracket have a smooth or flat side and a raised side that
looks like a spacer (see Figure 6). Be sure to install the bracket with the flat side against the expander card
and the raised side
facing away from the expander card.
Flat side of bracket
Front of board
Figure 6.
Caution: The torque on the mounting screws should be a maximum of 3.0-4.0 lbf-in to avoid
deformation. Be sure that the expander is not bent after attaching the low-profile bracket to the
expander card.
After physically installed into a server system, the RES3FV288 RAID Expander is transparent to users in RAID
configurations. Refer to the technical specification or user
to know how to configure a
RAID system.
guide of the RAID controller connected to this expander card
Mean Operating Time Between Failures number (MTBF):
electrical
TBD hours at 40°C
Bus Type
Description
Requirements
RAID Expander
12V: TBD mV peak-to-peak (max)
Product
Typical Current
All power is supplied to the RES3FV288 French Valley
RAID Expander Card through the standard PCI Express
connector
connector. The +12 V rail is used to generate the other
required voltage
and +1.8 V.
The max operation power is TBD W.
Appendix B: Technical Specifications
Environmental Specifications
Note: Your RAID Expander requires adequate airflow to operate reliably. The recommended airflow is 200 LFM
(linear feet per minute), minimum to avoid operating above the maximum ambient temperature. Forced airflow is
required.
The thermal and atmospheric characteristics are:
The storage and transit environment conditions are:
components
Note: Ambient temperature is measured 1” from the expander processor.
DC Power Requirements
PCIe Ripple and noise
Current Requirements
RAID Expander RES3FV288
’s 12 V rails, or a remote RA 4-pin 12V power
rails of 3.3V, 1.8V, 1.005V, and 0.925V
