PARTS LIST

GAS SKILLETS

MODELS: GMTSE-30

GMTSE-40

CROWN FOOD SERVICE EQUIPMENT LTD.

70 OAKDALE ROAD, DOWNSVIEW, (TORONTO), ONTARIO, M3N 1V9

TELEPHONE: [phone], FAX: [phone]

PART NUMBER 10013R3 1 2009-03-23

PRINTED IN CANADA

PARTS LIST, GAS SKILLETS, MODELS GMTSE-30, GMTSE-40

FIGURE 1

PART NUMBER 10013R3 2 2009-03-23

PARTS LIST, GAS SKILLETS, MODELS GMTSE-30, GMTSE-40

FIGURE 1

QUANTITY

ITEM PART NO. DESCRIPTION 30 40

1 7021-2 Cover Assembly 1

7022-2 Cover Assembly 1
2 9-3303 Pour Lip Strainer 1 1
3 9-3021 High Limit Thermostat 1 1
4 4344-1 Thermocouple 1 1
5 2426-1 High Limit Box 1 1
6 3703-1 Base Bracket Assembly 2 2
7 3704-1 Bushing 2 2
8 3209-1 Left Hand Door Assembly 1

3596-1 Left Hand Door Assembly 1
9 9-3443-1 Actuator Rod, 1/8 x 18" 1 1
10 9-3444 Actuator Rod Guide 1 1
11 9-3445 Lock Collar 2 2
12 9-3446 Spring 1 1
13 3838-1 Micro Switch Bracket 1 1
14 4-M603-1 Micro Switch 1 1
15 3039-1 Decal 1

3039-3 Decal 1
16 4-PL04-2 Ignition Pilot Light, Green, 28V 1 1
17 4753-1 Temperature Pilot Light, Red, 28V 1 1
18 4-TB05 Bezel 1 1

** 19 4689-1 Dial (C) 1 1

4352-1 Dial (F) 1 1

PART NUMBER 10013R3 3 2009-03-23

PARTS LIST, GAS SKILLETS, MODELS GMTSE-30, GMTSE-40

QUANTITY

ITEM PART NO. DESCRIPTION 30 40

20 9111-1 Up/Down Switch 1 1

** 21 5555-1 Temperature Control c/w Potentiometer, 120V 1 1

5555-2 Temperature Control c/w Potentiometer, 240V 1 1

* 9109-2 Rotary Shaft Seal 1 1

22 4-22TB Terminal Block Section 2 2
23 4-22ES End Section 1 1
24 4-35EU Ground Lug 1 1
25 9123-1 Transformer, 115/230-24V, 50/60 Hz, 50VA 1 1
26 9068-1 Fuse Holder 1 1
27 9092-1 Fuse, 1 Amp., 250V 1 1
28 3684-1 Box Cover 1 1

* 29 9-3327 Capacitor, 30 MFD, 120V 1 1

9-3324 Capacitor, 10 MFD, 220V 1 1
30 9017-5 Gear Clamp 1 1
31 9210-2 Ignition Module 1 1
32 5-MC02 Magnetic Catch 2 2

** 33 5526-1 Ball Drive Actuator Kit, 115V

(Includes 37, 38, 41)

5525-1 Ball Drive Actuator Kit, 220V

(Includes 37, 38, 41)
34 3733-1 Lower Pin 1 1
35 5329-2 Cotter Pin, 1/8 x 3/4" 2 2
36 9078-2 Washer, 7/17 x 1" 2 2

** 37 9-3329 Motor, 120V 1 1

9-3326 Motor, 220V 1 1

1 1

1 1

38 4267-1 Motor Cover 1 1

PART NUMBER 10013R3 4 2009-03-23

PARTS LIST, GAS SKILLETS, MODELS GMTSE-30, GMTSE-40

QUANTITY

ITEM PART NO. DESCRIPTION 30 40

39 1-R350 Retaining Ring 2 2
40 9-3036 Yoke Pin c/w Retaining Rings 1 1
41 5400-1 Lift Jack Extension Shield 2 2
42 3201-1 Side Panel 2 2
43 2573-1 Right Hand Door Assembly 1

2573-2 Right Hand Door Assembly 1
44 9010-300 Pipe, 3/4 x 30" 1 1
45 9014-1 Reducing Elbow, 3/4 x 1/2" 1 1
46 9009-030 Nipple, 1/2 x 3" 1 1
47 9-2007 Ball Valve, 1/2" 1 1
48 9009-000 Close Nipple, 1/2" 2 2
49 9015-3 Union, 1/2" 1 1
50 9012-3 Street Elbow, 1/2" 1 1

** 51 5450-1 Combination Gas Control, Natural 1 1

5450-2 Combination Gas Control, Propane 1 1
52 9009-073 Nipple, 1/2 x 7-3/8" 1

9009-064 Nipple, 1/2 x 6-1/2" 1
53 9011-3 Elbow, 1/2" 1 1
54 9009-050 Nipple, 1/2 x 5" 1 1
55 9009-264 Pipe, 1/2 x 26-1/2" 1 1
56 2432-1 Manifold Assembly 1
56 1189-1 Manifold Assembly 1
57 3-122A Orifice Nipple 4 6
58 9035-1 Pipe Plug, 1/8", NPT 1 1

PART NUMBER 10013R3 5 2009-03-23

PARTS LIST, GAS SKILLETS, MODELS GMTSE-30, GMTSE-40

QUANTITY

ITEM PART NO. DESCRIPTION 30 40

** 59 9-3351-44 Burner Orifice #44, Natural Gas 4

9-3351-47 Burner Orifice #47, Natural Gas 6

9-3351-55 Burner Orifice #55, Propane 4

9-3351-56 Burner Orifice #56, Propane 6
60 7227-1 Burner 4 6
61 M50S-1420-34 Screw, 1/4 - 20 x 3/4 8 8
62 8-2042 Lock Pin 2 2
63 8-2035L End Lock Plate 2 2
64 5428-1 Stationary Disc 2 2
65 5430-1 Core 2 2
66 8-2026 Spring 2 2
67 5429-1 Rotary Disc 2 2
68 8-2021 End Stop Plate 2 2
69 7262-1 Burner Box Assembly, Right Hand 1

7260-1 Burner Box Assembly, Right Hand 1
70 7261-1 Burner Box Assembly, Left Hand 1

7259-1 Burner Box Assembly, Left Hand 1
71 6891-1 Flue Assembly 1

6888-1 Flue Assembly 1
72 5169-2 Igniter Cable 1 1

** 73 9-3380 Ignitor/Sensor Pilot, Natural Gas 1 1

9-3380-1 Ignitor/Sensor Pilot, Propane 1 1
74 M50C-1420-12 Screw, 1/4 -20 x 1/2" 2 2
75 3991-1 Lighter Orifice Bracket 1 1
76 S01C-14 Lock Washer, 1/4" 2 2

PART NUMBER 10013R3 6 2009-03-23

PARTS LIST, GAS SKILLETS, MODELS GMTSE-30, GMTSE-40

QUANTITY

ITEM PART NO. DESCRIPTION 30 40

77 9029-1 Hex Nut, 1/4 - 20 2 2
78 3-696A Elbow, 3/8 C x 1/8 MPT 1 1
79 3-129B Bulk Head 1 1

** 80 9-3335-56 Lighter Orifice #56, Natural Gas 1 1

9-3335-65 Lighter Orifice #65, Propane 1

9-3335-72 Lighter Orifice #72, Propane 1
81 6350-1 Lighter Tube Assembly 1

6351-1 Lighter Tube Assembly 1
82 4127-3 Cord Set, 120V 1 1
83 4139-1 Vent Cover 1 1
84 4355-1 Swivel Spacer 1 1
85 5817-1 Arm 1 1
86 9248-1 Knob 1 1
87 4354-1 Swivel Base 1 1
88 F01S-14 Washer, 1/4 Stainless Steel 1 1
89 1-55S3 Hex Bolt, 1/4 - 20 x 3/8 Stainless Steel 1 1

* NOT SHOWN.
** SELECT AS REQUIRED.
