½" NPTM
}
Level
TROLL®
Accessories
Information Sheet
A
ARTESIAN WELL CABLE
OPTION
¾" NPTM
Method 1 Method 2
Fittings
Service
grip
Service
grip
Fittings
B
(SEALED WELL APPLICATIONS)
APPLICATION
®
Permits installation of a Level TROLL
seal is made around the cable. Allows easy removal from a ¾" NPT application.
Includes a black dome compression fitting that makes a water- and air-tight seal
around the cable.
Components are factory-installed on the Level TROLL RuggedCable™ or
miniTROLL Quick-Connect cable
COMPONENTS
Black two-piece dome connector with ½" male threads (NPTM)
A
White PVC adapter that accepts connector A (interior threads are ½" female, NPTF)
B
and mates with ¾" NPT threads
INSTALLATION
1. Loosen halves of connector A and slide to desired position on cable.
or miniTROLL® into a sealed well where the
2. Tighten the compression fitting firmly around the cable and screw into PVC
adapter B for installation into ¾” NPT fitting.
Additional adapter(s) may be added for installation into 1” or other size NPT fitting.
TIP: Cable may be ordered with the sealing fittings below the
service grip (Method 1) or above the service grip (Method 2),
depending on well configuration.
1 800 446 7488
(toll-free, US and Canada) or 970 498 1500 www.in-situ.com
Due to continuing product development this information is subject to change without notice. In-Situ and the In-Situ logo, Win-Situ, TROLL, miniTROLL, BaroTROLL,
RuggedReader, RuggedCable, and RDO are trademarks or registered trademarks of In-Situ Inc. Copyright © 2000 – 2007 by In-Situ Inc. All rights reserved.
0027772 rev. 002 07/07
