Insinkerator SupremeSS Specsheet
Food Waste Disposers
Disposers are designed
and manufactured
in the USA with over
80% domestic content
Evolution
™
Supreme SS
Evolution
®
Series
Grind More. Hear Less.
Dimensions
9 "
6 11/16"
*
13"
5 3/4"
4"
Superior performing
food waste disposer.
®
Submittal Sheet
Superior performing
food waste disposer.
• SoundSeal
®
technology delivers
ultra-quiet performance. Hold a
conversation with normal voices
in the same room.
• MultiGrind
®
technology delivers
3 stages of grind vs. 1 stage
in standard disposer.
• Includes Antimicrobial Quiet Collar
®
sound reducing sink baffle.
Sample Specification
Food Waste Disposer(s) shall be
InSinkErator Model Evolution
Supreme SS™
SoundSeal
stainless steel grind chamber and
components.
Warranty:
7- Year parts and in-home service.
The complete InSinkErator warranty is included in the Care & Use
*
Booklet packed with each unit.
with MultiGrind® and
®
technologies, 1 HP motor,
Specifications
Type of Feed Continuous
On/Off Control Wall Switch
Motor Single Phase
HP 1
Volts 120
HZ 60
RPM 1725
Amp. (Avg. Load) 10.2
Time Rating Intermittent
Lubrication Permanently
Shipping
Weight (Approx.) 22.9 lbs.
Unit Finish Black Enamel /
Overall Height 13”
SoundSeal Anti-Vibration Mount
Technology
MultiGrind GrindShear Ring
Technology
Grind Chamber
Capacity 40 oz.
Motor Manual Reset
Protection Overload
Average Approx. 1 Gallon Per
Water Usage Person Per Day
Average
Electrical Usage 3-4 KWh Per Year
Drain 1-1/2” Anti-Vibration
Connection (Hose Clamp)
Dishwasher
Drain Connection Yes
Lubricated Upper &
Lower Bearings
Ruby
Anti-Vibration
Tailpipe Mount
Antimicrobial
Quiet Collar
Multi-Layer
SoundLimiter
Tri-Action Lug
feature
Undercutter Disk
™
®
Sink Baffle
®
Insulation
®
System
®
®
®
Job Specifications
H841-15M-83-10 Printed in U.S.A. © 2015 InSinkErator, InSinkErator® is a business unit of Emerson Electric Co. All Rights Reserved.
* Add 1/2” when stainless steel sinks are used.
1-800-558-5700
www.insinkerator.com
The mark of responsible forestry
BV-COC-080715
© 1996 Forest Stewardship Council A.C.
™
The Emerson logo is a trademark and service mark of
Emerson Electric Co. The mounting collar configuration
is a trademark of Emerson Electric Co. Quick Lock® is a
registered trademark of Emerson Electric Co.
InSinkErator may make improvements and/or changes
in the specifications at any time, in its sole discretion,
without notice or obligation and further reserves the
right to change or discontinue models.
