PRO Series
Food Waste Disposers
Dimensions
9 "
6 11/16"
13 1/2"
* Add 1/2” when stainless steel sinks are used.
4"
5 3/4"
Job Specifications
PRO 1100XL™
Evolution Series
For those who enjoy the very
best kitchen appliances.
Submittal Sheet
The ultimate in disposer performance.
Nothing grinds more with less noise.
• SoundSeal
®
technology delivers
ultra-quiet performance. Hold a
conversation with normal voices
in the same room.
• MultiGrind
®
technology delivers
3 stages of grind vs. 1 stage
in standard disposer.
• Exclusive Jam-Sensor
feature. Increases motor torque
500% to automatically break through
the toughest jams.
• Includes sound-reducing
Quiet Collar® Sink Baffle containing
antimicrobial material.
• Made in USA exclusively for
professional plumbing contractors.
Sample Specification
Food Waste Disposer(s) shall be
InSinkErator Model PRO 1100XL with
MultiGrind
technologies, 1.1 HP motor, Auto-Reverse
Grind System
*
Grind Chamber and components.
Warranty:
We Come To You
Limited Warranty.
*
The complete InSinkErator warranty is included in the Care & Use
Booklet packed with each unit.
®
and SoundSeal
®
feature, Stainless Steel
Food waste disposers can provide an environmentally responsible alternative to
transporting food waste to landfills. And they can help reduce greenhouse gas
emissions. At capable wastewater treatment plants, food waste can be recycled
into renewable energy and fertilizer. (Check the plant in your area.)
www.insinkerator.com/green
®
®
Circuit
®
®
12- Year In-Home
Specifications
Type of Feed Continuous
On/Off Control Wall Switch
Motor Single Phase
HP 1.1
Reversing Auto-Reverse Grind
System
Volts 120
HZ 60
RPM 1725
Amp. (Avg. Load) 12.3
Time Rating Intermittent
Lubrication Permanently
Lubricated Upper &
Lower Bearings
Shipping
Weight (Approx.) 25.8 lbs.
Unit Finish Stainless Steel
Black
Overall Height 13- 1/2”
SoundSeal Plus Anti-Vibration Mount
Technology
Tailpipe Mount
Antimicrobial Quiet
Collar
Multi-Layer
SoundLimiter
MultiGrind Plus GrindShear Ring
Technology
feature
Undercutter Disk
Jam-Sensor
Grind Chamber
Capacity 40 oz.
Motor Manual Reset
Protection Overload
Average Approx. 1 Gallon Per
Water Usage Person Per Day
Average
Electrical Usage 3-4 KWh Per Year
Drain 1-1/2” Anti-Vibration
Connection (Hose Clamp)
Dishwasher
Drain Connection Yes
Anti-Vibration
Tri-Action Lug System
®
feature
®
Sink Baffle
®
Circuit
™
™
Insulation
®
®
™
®
™
The mark of responsible forestry
BV-COC-080715
© 1996 Forest Stewardship Council A.C.
1-800-558-5700
www.insinkerator.com
P576-13D-64-10 Printed in U.S.A. © 2013 InSinkErator, InSinkErator® is a business unit of Emerson Electric Co. All Rights Reserved.
The Emerson logo is a trademark and service mark of
Emerson Electric Co. The mounting collar configuration
InSinkErator may make improvements and/or changes
in the specifications at any time, in its sole discretion,
is a trademark of Emerson Electric Co.
without notice or obligation and further reserves the
right to change or discontinue models.
