Insignia NS-LCD37-09 User Manual
User Guide | Guide de l’utilisateur | Guía del Usuario
37" LCD TV| Téléviseur ACL de 37 po | Televisor LCD de 37"
NS-LCD37-09
Insignia NS-LCD37-09
37" LCD TV
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Front. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Remote control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Setting up your TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Installing remote control batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connecting your TV to a power outlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connecting an outside antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connecting cable TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connecting to an external signal source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connecting a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Using your TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Turning your TV on and off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Selecting the TV signal source. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Setting up the channel list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Changing channels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Selecting a digital sub-channel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Adjusting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Displaying status information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Checking the DTV signal strength . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Adding a channel label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Freezing the picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Setting the clock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Setting the sleep timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Viewing closed captions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Setting parental controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Using the on-screen menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
On-screen menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Maintaining. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Cleaning your TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
One-year limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Français. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Introduction
Congratulations on your purchase of a high-quality Insignia product. Your NS-LCD-37-09 represents the
state of the art in LCD TV design and is designed for reliable and trouble-free performance.
www.insignia-products.com
1
f
It makes a difference how and where you use
f
As you enjoy your new product, keep
The issue
The home theater entertainment experience is a growing trend, and larger TVs are
popular purchases. However, TVs are not always supported on the proper stands or
installed according to the manufacturer’s recommendations. We and the consumer
electronics industry are committed to making home entertainment enjoyable and safe.
TVs that are inappropriately placed on dressers, bookcases, shelves, desks,
speakers, chests, or carts may fall over and cause injury.
Tune into safety
Insignia NS-LCD37-09 37" LCD TV
CHILD SAFETY
your flat panel display
these safety tips in mind
• One size of TV stand does not fit all. Use only a TV
stand rated for the weight of your TV.
• Carefully read and understand all enclosed
instructions for proper use of this product.
• Don’t let children to climb on or play with
entertainment system furniture and TVs.
• Don’t place TVs on furniture that can easily be used
as steps, such as a chest of drawers.
• Remember that children can become excited while
watching a program, especially on a “larger-than-life”
TV. Make sure that you place or install the TV where
it cannot be pushed, pulled over, or knocked down.
• Make sure that you route all cords and cables so that
they cannot be pulled or grabbed by curious children.
Wall mounting
If you decide to wall mount your TV, always:
• One size of wall mount does not fit all. Use only a wall mount rated for the weight
of your TV and that has been recommended by this TV manufacturer, listed in this
manual, or otherwise listed by an independent laboratory (such as UL, CSA, or
ETL) as suitable for your TV.
• Follow all instructions supplied by the TV and wall mount manufacturers.
• If you have any doubts about your ability to safely wall mount your TV, get help
from a professional installer.
• Make sure that the wall where you are mounting the TV is
appropriate. Some wall mounts are not designed to be
mounted to walls backed with steel studs or cinder blocks.
If you are unsure, ask a professional installer.
• TVs can be heavy. At least two people are required for safe wall mount
installation.
2
www.insignia-products.com
Insignia NS-LCD37-09 37" LCD TV
Safety information
This symbol indicates that dangerous voltage
constituting a risk of electric shock is present
within your TV. This label is located on the back
of your TV.
This symbol indicates that there are important
operating and maintenance instructions in the
literature accompanying your TV.
Warning
Your TV contains tin-lead solder and a fluorescent
lamp containing a small amount of mercury.
Disposal of these materials may be regulated for
environmental reasons. For disposal or recycling
information, contact your local authorities or the
Electronic Industries Alliance at www.eia.org.
Important safety instructions
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use your TV near water.
6 Clean the cabinet with a dry cloth only.
7 Do not block any ventilation openings. Install
in accordance with the manufacturer’s
instructions.
8 Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9 Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong is provided for your safety.
If the provided plug does not fit into your
outlet, consult an electrician for replacement
of the obsolete outlet.
10 Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from your TV.
11 Only use attachments or accessories
specified by the manufacturer.
12 Use only with a cart, stand,
tripod, bracket, or table
specified by the manufacturer.
13 Unplug your TV during lightning
storms or when unused for long
periods of time.
14 Refer all servicing to qualified service
personnel.
15 Servicing is required when your TV has been
damaged in any way, such as the
power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into
your TV, your TV has been exposed to rain or
moisture, does not operate normally, or has
been dropped.
16 Do not overload wall outlets. Overloaded wall
outlets, loose or damaged wall outlets,
extension cords, frayed power cords, or
damaged or cracked wire insulation are
dangerous. Any of these conditions could
result in electric shock or fire. Periodically
examine the cord of your TV, and if its
appearance indicates damage or
deterioration, unplug it, discontinue use of
your TV, and have the cord replaced with an
exact replacement part by an authorized
service person. Protect the power cord from
physical or mechanical abuse, such as being
twisted, kinked, pinched, closed in a door, or
walked upon. Pay particular attention to
plugs, wall outlets, and the point where the
cord exits your TV.
17 Ensure that you connect the earth ground
wire to prevent possible electric shock. If
grounding methods are not possible, have a
qualified electrician install a separate circuit
breaker. Do not try to ground the unit by
connecting it to telephone wires, lightening
rods, or gas pipes.
18 The main plug is the disconnecting device.
The plug must remain readily operable.
Outdoor antenna grounding
If an outside antenna or cable system is
connected to your TV, make sure that the
antenna or cable system is grounded to provide
some protection against voltage surges and
built-up static charges. Article 810 of the
National Electrical Code, ANSI/NFPA No. 70,
provides information with respect to correct
grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors,
location of the antenna-discharge unit,
connection to grounding electrodes, and
requirements for the grounding electrode.
7
6
5
4
3
1
1 Electric service equipment
2 Power service grounding electrode system
3 Ground clamps
4 Grounding conductors
5 Antenna discharge unit
6 Grounding clamp
7 Antenna lead-in wire
2
www.insignia-products.com
3
Insignia NS-LCD37-09 37" LCD TV
Note to CATV system installer
This reminder is provided to call the CATV
system installer’s attention to Article 820-40 of
the NEC that provides guidelines for correct
grounding and in particular, specifies that the
cable ground must be connected to the
grounding system of the building as close to the
point of cable entry as practical.
Mobile telephone warning
To avoid interference with your TV picture and
sound, operating problems, or even damage,
keep your cordless and cellular telephones away
from the TV.
Non-active pixels
The LCD panel contains almost 3 million thin film
transistors, which provide exceptionally sharp
video quality. Occasionally, a few nonactive
pixels may appear on the screen as a fixed blue,
green, or red point. These non-active pixels do
not adversely affect the performance of your TV,
and are not considered defects.
Features
Front
Remote control
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
INPUT
DISPLAY
VIDEO COMP
123
456
789
VOL
VOL
MENU
P-LOCK MTS/SAP CCD
ZOOM
PICTURE AUDIO
0
MUTE
FAVORIT E
ENTER
SLEEP
ZRC-101
POWER
HDMI
RECALL
CH
CH
EXIT
FREEZE
18
TV
19
20
21
22
23
24
25
26
27
28
1
2
3
4
5
6
7
# Button Description
1 VOL+ Press to increase the volume. In Menu
2 VOL– Press to decrease the volume. In Menu
3
4
CH
CH
5 MENU Press to show the on-screen menu.
6 INPUT Press to open the input source menu,
7 POWER Press to turn on your TV or put it into
mode, functions as the right arrow to
go to the next menu or increase a
setting.
mode, functions as the left arrow to go
to a previous menu or decrease a
setting.
Press to go to the next higher channel.
In Menu mode, functions as the up
arrow.
Press to go to the next lower channel.
In Menu mode, functions as the down
arrow.
then press the arrows to cycle through
the available input sources.
Standby mode.
# Button Description
1
POWER
2 INPUT Press to cycle through the
3 VIDEO Press to toggle between S-Video
4 COMP Press to select the component
5 Number buttons Press to enter channel numbers. In
6 – Use with the 0-9 number buttons
7 VOL + Press to increase the volume.
8 MUTE Press to mute the sound. Press
9 VOL – Press to decrease the volume.
10 FAVORITE Press to toggle the
11 MENU Press to open the on-screen menu.
12 Press to move down, up, left, or
13 ENTER Press to confirm changes or to
14 P.LOCK Press to activate or deactivate
15 ZOOM Press to select the display aspect
Press to turn on your TV or put it
into Standby mode.
available input sources.
and composite source modes.
source mode.
the on-screen menu, press to enter
your parental control password.
and ENTER to select digital
channels.
again to restore the sound.
Favorite/Normal mode. See
“Setting up the channel list” on
page 8 for more information.
right in the on-screen menu.
turn options on and off in the
on-screen menu.
parental controls. See “Setting
parental controls” on page 9 for
information on setting up parental
controls.
ratio.
4
www.insignia-products.com
Insignia NS-LCD37-09 37" LCD TV
# Button Description
16 PICTURE Press to select the Brightness and
17 SLEEP Press to set the sleep timer. For
18 DISPLAY Press to display status
19 TV Press to select the ATSC (digital),
20 HDMI Press to select the HDMI mode.
21
22
23
24 EXIT Press to close the on-screen
25 MTS/SAP Press to select one of the preset
26 CCD Press to turn closed captions on
27 FREEZE Press to freeze the video image.
28 AUDIO Press to select the Bass or Tr ebl e
RECALL
CH
CH
Contrast setting. You can adjust
the brightness and contrast
without opening the on-screen
menu.
more information, see “Setting the
sleep timer” on page 9.
information.
or NTSC (analog) TV source.
Press to watch the previous
channel.
Press to tune to the next higher
channel in the channel list.
Press to tune to the next lower
channel in the channel list.
menu.
audio modes.
In analog TV mode, you can select
MONO, STEREO, or SAP
(secondary audio program).
In digital TV (DTV) mode, you can
select the audio language, if more
than one language is available.
and off. For more information, see
“Viewing closed captions” on page
9.
Press again to unfreeze the image.
Do not freeze the video image for
long periods of time. You may
damage the TV screen.
setting. You can adjust the bass or
treble without opening the
on-screen menu.
Using the remote control
To use the remote control:
• Point the remote control towards the remote
sensor on the front of your TV.
Setting up your TV
Installing remote control batteries
To install the remote control batteries:
1 Remove the battery cover.
2 Insert two AAA batteries into the battery
compartment. Make sure that you match the
+ and – symbols on the batteries with the +
and – symbols in the battery compartment.
3 Replace the cover.
Notes
• Do not mix batteries of different types.
• Do not mix old and new batteries.
• Remove batteries when the charge is depleted.
• Battery chemicals can cause a rash. If the
batteries leak, clean the battery compartment
with a cloth. If chemicals touch your skin, wash
immediately.
• If the remote control is not going to be used for
an extended period of time, remove the
batteries.
Connecting your TV to a power outlet
Notes
• Do not expose the remote control to shock or
liquids.
• Do not use the remote control in an area with
high humidity.
• Do not place the remote control in direct
sunlight.
• Do not place objects, such as furniture,
between the remote control and the remote
sensor.
• The remote control may not work if direct
sunlight or bright light shines on the remote
sensor. Either move your TV or change the
angle at which you use the remote control.
www.insignia-products.com
To connect your TV to a power outlet:
• Plug the power cord into a power outlet.
Notes
• Make sure that you use the correct type of
power. See the label on your TV.
• If you do not intend to use your TV for an
extended period of time, unplug the power cord
from the power outlet.
5
Insignia NS-LCD37-09 37" LCD TV
Connecting an outside antenna
Antenna cables come in two types: 75 ohm and
300 ohm.
75 ohm cable
300 ohm cable
• If your antenna cable has a 75 ohm
connector, connect the cable to the coaxial
jack on the back of your TV.
• If your antenna cable has a 300 ohm
connector, connect the cable to a
300-75 ohm adapter (not included), connect
the adapter to a 75 ohm cable, then connect
the other end of the 75 ohm connector to the
coaxial jack on the back of your TV.
Connecting cable TV
Your TV has a 75 ohm jack for connecting cable
TV.
Some cable TV providers scramble the signals
for “premium” (pay) channels. To view these
channels, you need a converter/descrambler
box.
If you do not have a converter/descrambler box,
you can connect your cable TV directly to your
TV. If you have a converter/descrambler box,
you can connect your cable TV using an RF
switch (not supplied). For more information
about connecting a converter/descrambler box,
contact your cable TV provider.
To connect cable TV without a
converter/descrambler box:
1 Connect one end of a 75 ohm cable to the
coaxial jack on the back of your TV.
2 Connect the other end of the cable to the
cable TV wall outlet.
Connecting to an external signal source
You can connect a DVD, VCD, VCR, or STB
using a variety of methods, including composite
cables, component cables, an S-Video cable, or
an HDMI cable. The S-Video cable does not
carry sound. If you use an S-Video cable, you
need to use audio cables to connect the audio
output.
Warning
Make sure that you turn off and unplug your TV
before connecting devices.
Note
For better video, use the S-Video jack if your
device has an S-Video connection. For best video,
use the HDMI jack if your device has an HDMI
connection.
To connect an external signal source:
1 For composite video—Plug the audio/video
cable into the AUDIO L/R and VIDEO IN (7)
jacks on the back of your TV, then connect
the other ends to the corresponding jacks on
the external signal source.
Or
For S-Video—Plug in the audio cables as
described above, then plug one end of an
S-Video cable into the S-Video jack (3) on
the back of your TV, then plug the other end
into the S-Video jack on the external signal
source.
Or
For component video—Plug the Y, Pb, and
Pr video cables and the Audio L and Audio R
cables into the COMPONENT VIDEO IN (6)
and AUDIO L/R (5) jacks on the back of your
TV, then plug the other ends of the cables
into the corresponding jacks on the external
signal source.
Or
To connect cable TV with a
converter/descrambler box:
• Use the following illustration to connect a
converter/descrambler box. (The RF switch
and the signal splitter are not provided.)
Set the RF switch to the A position to tune to
unscrambled channels using your TV remote
control. Set the RF switch to the B position to
watch scrambled channels using the
converter/descrambler controls.
RF switch
A
B
Out
TV
Cable converter/descrambler box
Two-set signal splitter
In
6
www.insignia-products.com
Insignia NS-LCD37-09 37" LCD TV
For HDMI—Plug one end of an HDMI cable
into the HDMI1 INPUT (1) or HDMI2 INPUT
(4) jack on the back of your TV, then plug the
other end into an HDMI device.
To connect a computer using VGA:
1 Plug a VGA cable from your computer into
the VGA jack on the back of your TV.
1 2
AUDIO
PC IN
VGA
AV 1 IN
ANTENNA / CABLE
DIGITAL / ANALOG
SPDIF
AUDIO
OUT
COMPONENT 1
COMPONENT 2
Pr Pb
Pr Pb
2 Turn on your TV.
3 Press INPUT repeatedly to select the
external signal source you want to watch.
4 Turn on external signal source.
5 Insert a disc or videotape into the external
signal source, then press PLAY.
Connecting a computer
You can connect a computer using the HDMI or
VGA jack on the back of your TV.
Warning
Make sure that you turn off and unplug your TV
before installing devices.
Note
When the computer goes into standby mode, your
TV turns off. If your TV does not turn on when you
“wake” your computer, press the POWER button
on your TV or remote control.
VGA jackAudio jack
2 Plug an audio cable from your computer’s
audio out jack into the AUDIO jack on the
back of your TV.
3 Plug in and turn on your TV.
4 Press INPUT repeatedly to select the VGA
input source.
To connect a computer using HDMI:
• Plug an HDMI cable into the HDMI INPUT
jack on the back of your TV and into the
HDMI Out jack on the back of the computer.
www.insignia-products.com
3
HDMI jack
7
Insignia NS-LCD37-09 37" LCD TV
Using your TV
Turning your TV on and off
To turn your TV on and off:
1 Make sure that the power cord is connected
to your TV and a power outlet.
2 Press to turn on your TV. The power
indicator LED turns blue.
3 Press again to return your TV to standby.
The power indicator LED turns red.
Selecting the TV signal source
To select the TV signal source:
• With the TV on, press INPUT on either the
TV or the remote to choose from:
• TV
• Composite Rear
• Composite Side
• S-Video Rear
• S-Video Side
• Component1
• Component2
•VGA
• HDMI1
• HDMI2
• HDMI3
Press VIDEO to choose between composite
and S-Video.
Note
HDMI, the HDMI logo, and High-Definition
Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.
Setting up the channel list
After you select your TV source, if you selected
antenna or cable you need to set up the channel
list. When you set up your channel list, your TV
searches for all available channels in your area
and stores a list of these channels. When you
press CH or CH , your TV skips the
channels that do not have a signal.
Automatically setting up channels
To automatically set up the channel list:
1 Press MENU. The on-screen display menu
opens with Setup highlighted.
2 Press to enter the sub-menu, then press
or to highlight Auto Ch Search.
3 Press ENTER or to start the search.
Note
You can press Exit to stop the search.
Manually adding or deleting channels from the
channel list
After you create a channel list using the Auto Ch
Search option, you can manually add or delete
channels from the channel list.
To add or delete channels:
1 Press MENU. The on-screen display menu
opens with Setup highlighted.
2 Press to enter the sub-menu, then press
or to highlight Manual Channel Set. The
Channel Setup Table
3 Press or to select a channel, then
press ENTER to toggle between viewable
and not viewable.
4 Press MENU or EXIT to close the menu.
opens.
Changing channels
To change channels:
• Press CH or CH on the remote control
to go to the next lower or higher channel.
Or
Press the number buttons to directly select a
channel (for example, if you want channel 83,
press 8, then press 3).
Or
Press RECALL to go to the last viewed
channel.
Selecting a digital sub-channel
Most digital TV channels have more than one
channel. The main channel carries the signal for
the main TV program. The sub-channels carry
signals for additional or alternate programming,
such as a radio or news broadcast.
For example, if the main channel number is 8,
the sub-channel number might be 8-1, 8-2, or
8-3.
To select a sub-channel:
1 Press the number buttons for the main
channel (for example 8).
2 Press –, then press the sub-channel button
(for example 1).
Adjusting the volume
To adjust the volume:
• Press VOL – or VOL + to decrease or
increase the volume.
• Press MUTE to turn off the sound. Press
MUTE again to turn the sound back on.
Displaying status information
ENTER
8
www.insignia-products.com
To display status information:
• Press DISPLAY. Your TV displays status
information, such as the channel number or
signal source.
Insignia NS-LCD37-09 37" LCD TV
Checking the DTV signal strength
To check the DTV signal strength:
1 Press MENU. The on-screen display menu
opens with Setup highlighted.
2 Press to enter the sub-menu, then press
or to highlight DTV Signal. The DTV
signal meter opens.
3 Press MENU or EXIT to close the menu.
Adding a channel label
To add a label to a channel:
1 Press MENU. The on-screen display menu
opens with Setup highlighted.
2 Press to enter the sub-menu, then press
or to highlight Channel Labels. The
Channel Label
menu opens.
3 Press or to move the cursor to the
channel field, then press or to select a
channel.
4 Press or to move the cursor to the label
field, then press or to select the
character.
5 Press ENTER to return to the previous menu.
Freezing the picture
You can freeze (still) the screen image.
Caution
To protect your TV, do not freeze the screen
image for long periods of time.
To freeze or unfreeze the picture:
• Press FREEZE.
3 Press to enter the sub-menu, then press
or to highlight Time Set. The
menu opens.
4 Press or move to the different fields,
then press or to change the settings.
5 Press MENU or EXIT to close the menu.
Setting the sleep timer
The sleep timer lets you select the amount of
time before your TV turns off automatically.
To set the sleep timer:
1 Press MENU. The on-screen display menu
opens with Setup highlighted.
2 Press or repeatedly to highlight
Feature. The
3 Press to enter the sub-menu, then press
or to highlight Sleep Timer.
4 Press or to select the amount of time
(Off, 5 min, 10 min, 15 min, 30 min, 45 min,
60 min, 90 min, 120 min, 180 min, or
240 min). To turn off the timer, select Off.
Note
You can also press SLEEP to set the sleep timer.
Viewing closed captions
Feature
Time Set
menu opens.
Setting the clock
To set the clock:
1 Press MENU. The on-screen display menu
opens with Setup highlighted.
2 Press or repeatedly to highlight
Feature. The
Feature
menu opens.
ENTER
Note
To select or customize digital closed captions, use
Digital Captions
the
sub-menus in the
To view closed captions:
• Press CCD repeatedly to select a closed
caption option. You can select:
• On
• Off
• On When Mute
Setting parental controls
Your TV has a V-chip that lets you control the
type of programs your children can watch.
Parental controls include two ratings: MPAA
(based on age) and TV Parental Guidelines
(based on content and age). A TV program may
have an MPAA or TV Parental Guidelines rating,
so you should set controls for both ratings.
Before you can select ratings, you need to set up
a parental controls password.
or
Digital Closed Caption
Feature
menu.
www.insignia-products.com
9
Insignia NS-LCD37-09 37" LCD TV
To set up a password:
1 Press MENU. The on-screen display menu
opens with Setup highlighted.
2 Press or repeatedly to highlight
Feature. The
Feature
menu opens.
3 Press to enter the sub-menu, then press
or to highlight Password Set.
4 Press the number buttons to enter the old
password. If you have not set a password,
enter 0000. Press ENTER to continue.
5 Press the number buttons to enter a new
password. Press ENTER to continue.
6 Press the number buttons to enter the new
password again, to confirm. Press ENTER to
continue.
5 Press or to select USA Parental
Locks or Canadian Parental Locks, then
press ENTER. The lock menu that you have
selected opens.
USA Parental Locks
ENTER
6 Press or , or or to move to a rating,
then press ENTER to select the rating.
When you block a rating, that rating and all
higher ratings are blocked.
7 Press MENU or EXIT to close the menu.
American MPAA ratings
Caution
Write down your password and save it for future
use.
Note
If you forget your password, enter 3448 for the old
password, then enter a new password. This
password always remains valid for resetting your
password.
Setting the Parental Control level
To set the Parental Control level:
1 Press MENU. The on-screen display menu
opens with Setup highlighted.
2 Press or repeatedly to highlight
Feature. The
Feature
menu opens.
3 Press to enter the sub-menu, then press
or to highlight Parental Control. The
Password screen opens.
4 Press the number buttons to enter the
password. Press ENTER to continue. The
Parental Control Menu
opens.
Rating Description
NONE Not rated.
G General audiences.
PG Parental guidance suggested. Some
material may not be suitable for
children.
PG-13 Parental guidance strongly suggested.
Some material may not be suitable for
children under 13 years of age.
R Restricted. Not suitable for children
under 17 years of age unless
accompanied by a parent or guardian.
NC-17 Not suitable for children under 17
years of age.
XAdults only.
Canadian MPAA Ratings
Rating Description
CChildren.
C8+ Children 8 years and above.
G General audience.
PG Parental guidance suggested.
14+ 14 years old and above.
18+ Adult programming.
XAdults only.
10
ENTER
www.insignia-products.com
Insignia NS-LCD37-09 37" LCD TV
TV Parental Guidelines ratings
Rating Description
NONE Not rated.
TV-Y All children.
TV-Y7 Children over seven years.
TV-G General audiences.
TV-PG Parental guidance suggested.
TV-14 Parents strongly cautioned.
TV-MA Mature audiences only.
Some of the age-based TV Parental Guidelines
ratings also have content-based ratings.
Rating Description
FV Fantasy violence.
L Adult language.
S Sexual situations.
V Violence.
D Sexually suggestive dialog.
Using the on-screen menu
Your TV has an on-screen menu that lets you
adjust TV settings, such as video and audio
settings.
To use the on-screen menu:
1 Press MENU. The on-screen display menu
opens.
2 Press or repeatedly to select a menu
item.
3 Press or to enter a sub-menu.
ENTER
4 Press ENTER or to confirm an adjustment
or toggle a setting.
5 Press MENU or EXIT to close the on-screen
display menu.
www.insignia-products.com
11
Insignia NS-LCD37-09 37" LCD TV
On-screen menus
Menu Options
Setup Tuning Band–Selects the TV antenna
Video
(Options may vary in
different modes.)
source (Air or Cable).
DTV Signal–Displays the digital TV
signal strength. For more information,
see “Checking the DTV signal strength”
on page 9.
Auto Ch Search–Automatically sets up
a list of the channels available in your
area. For more information, see
“Automatically setting up channels” on
page 8.
Add On Ch Search–Lets you add new
channels without going through the
entire list of available channels.
Manual Ch Set–Lets you add or delete
channels from the channel list. For
more information, see “Manually
adding or deleting channels from the
channel list” on page 8.
Channel Labels–Lets you add a label
to a channel. For more information, see
“Adding a channel label” on page 9.
Menu Language–Selects the language
for the on-screen menu. You can select
English, French, or Spanish.
Aspect Ratio–Selects the screen
aspect ratio: Normal, Wide, Zoom, or
Cinema. You can also press ZOOM to
select the aspect ratio.
Favorite Channel mode–Lets you edit
your favorite channel list. Press
FAVORITE on the remote to toggle this
mode on or off.
Contrast–Increases the picture level to
adjust the white areas of the picture.
Decreases the picture level to adjust
the black areas of the picture. (0 ~ 100)
Brightness–Increases the brightness
to add more light to dark areas of the
picture. Decreases the brightness to
add more dark to light areas of the
picture. (0 ~ 100)
Sharpness–Increases the sharpness
for a cleaner and clearer image.
Decreases the sharpness for a
smoother picture. (-50 ~ 50)
Color–Adjusts the overall color of the
picture. (0 ~ 100)
Tint–Increases the color level to add
more green to skin tones. Decreases
the color level to add more purple to
skin tones. (R50 ~ G50)
Backlight–Adjusts the backlight level
(0 ~ 10).
Settings–Restores the video settings
to factory default.
Menu Options
Audio
(Options may vary in
different modes.)
Audio Language–Selects an alternate
language if the program has more than
one language available. Only available
in ATSC TV mode.
Bass–Adjusts the low sounds (bass).
Treble–Adjusts the high sounds
(treble).
Balance–Adjusts the right and left
speaker volumes.
Surround sound–Turns surround
sound On or Off (default).
Digital Audio Output–Selects the audio
mode for the digital audio optical jack.
• RAW: AC-3 in - AC-3 out/PCM
• PCM: AC-3 in - PCM out/PCM in
TV Speaker–Turns the internal TV
speaker On (default) or Off. Does not
affect the digital audio output, the
headphone output, and the composite
audio output.
Settings–Restores the audio settings
to factory default.
in - PCM out.
- PCM out.
12
www.insignia-products.com
Insignia NS-LCD37-09 37" LCD TV
Menu Options
Feature Time Set–Sets the clock. For more
information, see “Setting the clock” on
page 9.
Sleep Timer–Sets the sleep timer. For
more information, see “Setting the
sleep timer” on page 9.
Advanced Video Set–
• Noise Reduction–Select from
Low, Mid, High, and Off.
• Color Temperature–Select from
Normal, Warm, and Cool
(default).
• 3D Y/C–Choose from On
(default) or Off.
• Dynamic Contrast–Choose
from On or Off (default).
• Setting–Restores the settings
to factory default.
Password Set–Lets you set the
password for parental control options.
The default password is 0000. See
“Setting parental controls” on page 9.
Parental Control–Accesses V-chip
controls. For more information, see
“Setting parental controls” on page 9.
Digital Caption–Sets the digital
caption type. Choose from Service
1-6, Text 1-4, and CC 1-4.
Closed Caption Options–Customizes
closed captions for digital
broadcasting systems. You can adjust
Size, Font, Tex t Color, Text Opacity,
Background Color, Background
Opacity, Edge Effect, and Edge Color.
Component Set–Only available in
component mode. Lets you set
Horizontal Position (0~100), Vertical
Position (0~100), Clock (0 ~ 100),
and Phase (0 ~ 100). The Settings
option restores the settings to factory
default.
VGA Set–Only available in VGA mode.
Lets you set Horizontal Position
(0~100), Vertical Position (0~100),
Clock (0 ~ 100), and Phase (0~100).
You can also select Auto Adjust to
automatically adjust the settings. The
Settings option restores the settings to
factory default.
Audio Only–Choose from On or Off
(default).
Input Label–Lets you change the input
label.
Maintaining
• Do not use your TV in areas that are too hot
or too cold, because the cabinet may warp or
the screen may malfunction.
• Storage temperatures are 32° to 122°F
(0° to 50°C).
• Working temperatures are 41° to 104°F
(5° to 40°C).
• Do not place your TV in direct sunlight or
near a heat source.
Cleaning your TV
Clean the screen and cabinet with a soft,
lint-free cloth. If the screen or cabinet is
especially dirty, moisten a soft, lint-free cloth in a
weak detergent solution, squeeze the excess
moisture from the cloth, then wipe the screen or
cabinet with the cloth. Use a clean cloth to dry
the screen or cabinet.
Caution
Avoid the following, because it may cause
damage to your TV:
• Cleaning your TV with volatile substances,
such as insect sprays, solvents, and thinners.
• Leaving items made from rubber or PVC in
contact with your TV for long periods.
• Letting liquids drip into the cabinet
Troubleshooting
Warning
Do not try to repair your TV yourself. Refer all
service to a qualified service technician.
Symptom Possible solution
No power • Make sure that the power cord
No picture • Make sure that the video cables
Good picture but no
sound
Good sound but poor
color
Poor picture • Make sure that the room is not
Horizontal dotted line • Your TV may be too close to
is connected to your TV and a
power outlet.
• Unplug the power cord, wait 60
seconds, then plug the cord
back in and turn on your TV.
are connected securely to the
back of your TV.
• Adjust the contrast and
brightness.
• Make sure that the correct
video mode is selected.
• Make sure that the incoming
signal is compatible.
• Make sure that the antenna is
connected correctly.
• Check the closed caption
settings. Some TEXT modes
can block the screen.
• Increase the volume.
• Make sure that the sound is not
muted.
• Make sure that the correct
audio mode is selected.
• Adjust the contrast, color, and
brightness settings.
too bright. Light reflecting off
the screen can make the picture
difficult to see.
• If an S-VHS camera or a
camcorder is connected while
another connected device is
turned on, the picture may be
poor. Turn off one or more
devices.
another electrical device, such
as a hair dryer or neon light.
Turn off the device or move
your TV.
www.insignia-products.com
13
Insignia NS-LCD37-09 37" LCD TV
Symptom Possible solution
“Ghost” or double image • This may be caused by
Picture has a few bright
or dark dots
Remote control does not
work
Snowy picture or noise • Make sure that the A/V and
VGA picture is not stable
or synchronized
No output from one of
the speakers
Control buttons do not
work
After images appear • Do not display a still image,
obstructions to the antenna,
such as high-rise buildings or
hills. Using a highly directional
antenna may improve the
picture quality.
• A few bright or dark dots on an
LCD screen is normal. It does
not affect the operation of this
TV.
•Press TV.
• Replace the batteries. Make
sure that the + and – symbols
on the batteries align with the +
and – symbols in the battery
compartment.
• Clean the remote sensor on the
front of your TV.
• Bright or fluorescent lighting
may interfere with the remote
control signal. Turn off the light
or move your TV.
antenna cables are connected
correctly and securely.
• Make sure that you have
selected the correct VGA mode
on your computer.
• Adjust the balance in the
menu.
• Unplug the power cord, wait a
few seconds, then plug the cord
back in and turn on your TV.
such as a logo, game, or
computer image, for an
extended period of time. This
can cause a permanent after
image to be burned into the
screen. This type of damage is
not covered by your warranty.
Appendix
Sound
To attach a wall mount bracket to your TV:
1 Remove the two T4 and two M4 screws
holding your TV to the stand.
Remove T4 screws Remove M4 screws
2 Remove the four screws from the bottom of
the stand.
3 Secure the wall mount bracket to the back of
your TV using four M6 screws, as indicated in
the illustration in Step 1.
Specifications
Design specifications are subject to change
without notice.
200 mm
Attach
bracket
here
Remove stand
Remove 4 stand screws
200 mm
Wall-mount hardware (sold separately) lets you
mount your TV on a wall.
For detailed information on mounting your TV on
a wall, see the instructions provided with the
wall-mount hardware.
Contact a technician for assistance when
installing the wall-mount bracket. Best Buy is not
responsible for any damage to your TV or injury
to yourself or others.
We suggest that you keep your TV at least
2.36 inches (60 mm) from the wall to prevent
cable interference.
Before you wall-mount your TV, you need to
remove the base.
14
Analog standard NTSC
Digital standard ATSC, 8-VSB, Clear-QAM
Screen 37-inch
Channel coverage • VHF: 2-13
•UHF: 14-69
• CATV: Mid band - A-8 ~ A-1, A ~ I
• Super band - J ~ W
• Hyper band - AA ~ ZZ, AAA, BBB
• Ultra band - 65 ~ 94, 100 ~ 135
Power source AC 100~240 V 50/60 Hz
Power consumption Active: <200 W
Standby mode: <1 W
Audio power 10 W + 10 W internal speaker
S-Video input Y: 1 V(p-p), 75 ohm, negative sync
C: 0.286 V(p-p) (burst signal), 75 ohm
Video/audio input Video: 1 V(p-p), 75 ohm, negative sync
Audio: 500 mV(rms)
www.insignia-products.com
Insignia NS-LCD37-09 37" LCD TV
Component input Y: 1 V(p-p), 75 ohm, including sync
Pr/Cr: ±0.35 V(p-p), 75 ohm
Pb/Cb: ±0.35 V(p-p), 75 ohm
Audio: 500 mV(rms)
Suggested resolutions: 1080i, 720p, 480p,
480i
HDMI input 3 HDMI input terminal
HDCP compliant
E-EDID compliant
Suggested scan rates:
• 1080i
•720p
•480p
•480i
VGA input D-Sub 15-pin terminal
E-EDID compliant
Suggested scan rates:
• 640×480 @ 60 Hz
• 800×600 @ 60 Hz
• 1024 × 768@ 60 Hz
• 1360 x 768 @ 60 Hz,
Audio input: Headphone mini-jack for
stereo
Dimensions
(with base)
35.75 × 25.04 × 10.24 inches
(90.8 × 63.6× 26.0 cm)
Weight 35.2 lbs. (16 kg)
Accessories • Power cord
• User guide
• Remote control
• Batteries (2 AAA)
•VGA cable
• PC audio cable
•Quick Start guide
FCC warning
Changes or modifications not expressly approved by the
party responsible for compliance with the FCC Rules could
void the user’s authority to operate this equipment.
Cables
Connections to this device must be made with shielded
cables with metallic RF/EMI connector hoods to maintain
compliance with FCC Rules and Regulations.
Manufactured under license from Dolby Laboratories. “Dolby” and
the double-D symbol are trademarks of Dolby Laboratories.
Legal notices
FCC Part 15
This device complies with Part 15 of the FCC Rules.
Operation of this product is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply within
the limits for a class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced technician for
help.
www.insignia-products.com
15
Insignia NS-LCD37-09 37" LCD TV
16
www.insignia-products.com
