Insignia NS-LCD19W-09 User Manual
User Guide | Guía del Usuario
19” LCD TV
TV LCD de 19"
NS-LCD19W-09
Insignia NS-LCD19W-09 19” LCD TV
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Front. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Remote. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Installing remote control batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Using the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Setting up your TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Connecting an antenna, cable TV, or satellite TV. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Connecting a VCR or standard video device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Connecting a component video device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Connecting HDMI input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Connecting an external component . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Connecting a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Using your TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Turning the TV on and off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Choosing the video source. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Changing channels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Adjusting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Displaying current program information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Selecting a preset picture mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Selecting a preset audio mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Setting sleep mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Selecting an aspect ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Using the channel list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Using the favorites list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Using the on-screen menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Adjusting picture settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Adjusting audio settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Memorizing channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Setting the function menu options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Setting lock options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Maintaining. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Cleaning the cabinet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Legal notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
One-year limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Introduction
Congratulations on your purchase of a high-quality Insignia product. Your NS-LCD19W-09 represents the
state of the art in television design, and is designed for reliable and trouble-free performance.
www.insignia-products.com
3
f
It makes a difference how and where you use
The issue
The home theater entertainment experience is a growing trend, and larger TVs are
popular purchases. However, TVs are not always supported on the proper stands or
installed according to the manufacturer’s recommendations. We and the consumer
electronics industry are committed to making home entertainment enjoyable and safe.
TVs that are inappropriately placed on dressers, bookcases, shelves, desks,
speakers, chests, or carts may fall over and cause injury.
Insignia NS-LCD19W-09 19” LCD TV
CHILD SAFETY
your flat panel display
As you enjoy your new product, keep
these safety tips in mind
Tune into safety
• One size of TV stand does not fit all. Use only a TV
stand rated for the weight of your TV.
• Carefully read and understand all enclosed
instructions for proper use of this product.
• Don’t let children to climb on or play with
entertainment system furniture and TVs.
• Don’t place TVs on furniture that can easily be used
as steps, such as a chest of drawers.
• Remember that children can become excited while
watching a program, especially on a “larger-than-life”
TV. Make sure that you place or install the TV where it
cannot be pushed, pulled over, or knocked down.
• Make sure that you route all cords and cables so that
they cannot be pulled or grabbed by curious children.
Wall mounting
If you decide to wall mount your TV, always:
• One size of wall mount does not fit all. Use only a wall mount rated for the weight
of your TV and that has been recommended by this TV manufacturer, listed in this
manual, or otherwise listed by an independent laboratory (such as UL, CSA, or
ETL) as suitable for your TV.
• Follow all instructions supplied by the TV and wall mount manufacturers.
• If you have any doubts about your ability to safely wall mount your TV, get help
from a professional installer.
• Make sure that the wall where you are mounting the TV is
appropriate. Some wall mounts are not designed to be
mounted to walls backed with steel studs or cinder blocks.
If you are unsure, ask a professional installer.
• TVs can be heavy. At least two people are required for safe wall mount installation.
4
www.insignia-products.com
Insignia NS-LCD19W-09 19” LCD TV
Safety information
CAUTION:
ELECTRIC
COVER
PARTS INSIDE. REFER SERVICING
QUALIFIED SERVICE PERSONNEL.
Warning
To reduce the risk of electric shock, do not remove the cover or
back. There are no user-serviceable parts inside. Refer
servicing to qualified service personnel.
To reduce the risk of fire or electric shock, do not expose your
TV to rain or moisture.
Caution
To prevent electric shock, match the wide blade on the power
cord plug to the wide slot on an electric outlet. If the plug does
not fit, consult a licensed electrician to replace the obsolete
outlet. Do not modify the power cord plug, or you will defeat
this safety feature.
Warnings
• Use of controls or adjustments or performance of
procedures other than those specified herein may result in
hazardous radiation exposure.
• The apparatus shall be connected to a power outlet with a
protective ground connection.
• To prevent injury, this apparatus must be securely attached
to the floor/wall in accordance with the installation
instructions.
• Always place the TV on the floor or a sturdy, level, stable
surface that will support the weight of the unit.
• Installing the TV requires special skill that should only be
performed by qualified service personnel.
• Customers should not attempt to do the work themselves.
Insignia bears no responsibility for improper mounting or
mounting that results in accident or injury.
• The lamps in this product contain mercury. Please dispose
according to state, local, or federal law.
Caution
The AC power plug is used as the disconnect device, so the
AC power plug shall always remain readily accessible.
Read instructions
Read all of the safety and operating instructions
before you use your TV.
Retain instructions
Retain safety and operating instructions for
future reference.
Follow warnings and instructions
Follow all warnings on your TV and in the
operating instructions. Follow all operating and
use instructions.
TO REDUCE THE RISK OF
SHOCK, DO NOT REMOVE
(OR BACK). NO USER-SERVICEABLE
TO
This symbol indicates that dangerous
voltage constituting a risk of electric shock
is present within your TV. This label is
located on the back of your TV.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
your TV.
Water and moisture
Do not use your TV near water. For example, do
not use it near a bath tub, wash bowl, kitchen
sink, laundry tub, in a wet basement, or near a
swimming pool.
Cleaning
Unplug your TV before cleaning. Do not use
liquid or aerosol cleaners. Use only a dry cloth to
clean the exterior of your TV.
Ventilation
Slots and openings in the cabinet and the back
or bottom are provided for ventilation, reliable
operation, and protection from overheating.
These openings must not be blocked or covered.
Do not block the openings by placing your TV on
a bed, sofa, rug, or other similar surface. Do not
place your TV near or over a radiator or heat
register. Do not place your TV in a built-in
installation, such as a bookcase or rack, unless
you provide correct ventilation or follow the
manufacturer’s instructions.
Heat
Make sure that your TV is located away from
heat sources such as radiators, heat registers,
stoves, or other products (including amplifiers)
that produce heat.
Grounding or polarization
Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A
grounding type plug has two blades and a
grounding prong. The wide blade or grounding
prong is provided for your safety. If the plug does
not fit, contact an electrician to replace the
obsolete outlet.
Power cord protection
Route power cords so that they are not likely to
be walked on or pinched by items placed on or
against them. Pay particular attention to cords at
plugs, convenience receptacles, and the point
where they exit from your TV.
Attachments
Use only attachments recommended by
Insignia.
Stand
Do not place your TV on an unstable
cart, stand, tripod, bracket, or table.
Your TV may fall, causing serious
personal injury and serious damage
to your TV. Use only with a cart,
stand, tripod, bracket, or table recommended by
the manufacturer, or sold with your TV. If you
mount your TV to the wall, follow the
manufacturer’s instructions and use a mounting
accessory recommended by the manufacturer.
Your TV and cart combination should be moved
with care. Quick stops, excessive force, and
uneven surfaces may cause your TV and cart
combination to overturn.
www.insignia-products.com
5
Insignia NS-LCD19W-09 19” LCD TV
Lightning
For added protection for your TV’s receiver
during a lightning storm, or when it is left
unattended and unused for long periods of time,
unplug it from the power outlet and disconnect
the antenna or cable system. This helps prevent
damage to your TV from lightning and power line
surges.
Servicing
Do not attempt to service your TV yourself
because opening or removing covers may
expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service
personnel.
Replacement parts
When replacement parts are required, make
sure that the service technician uses
replacement parts specified by the manufacturer
that have the same characteristics as the
original part. Unauthorized substitutions may
result in fire, electric shock, personal injury, or
other hazards.
Overloading
Do not overload power outlets and extension
cords because this can result in a risk of fire or
electric shock.
Object and liquid entry
Never push objects of any kind into your TV
through openings because objects may touch
dangerous voltage points or short out parts that
could result in a fire or electric shock. Never spill
liquid of any kind on your TV.
Damage requiring service
Unplug this TV from the power outlet and refer
servicing to qualified service personnel under
the following conditions:
• When the power supply cord or plug is
damaged or frayed.
• If liquid has been spilled or objects have
fallen into your TV.
• If your TV has been exposed to rain or water.
• If your TV does not operate normally by
following the operating instructions. Adjust
only those controls that are covered by the
operating instructions because incorrect
adjustment of other controls may result in
damage and will often require extensive work
by a qualified technician to restore your TV to
its normal operation.
• If your TV has been dropped or damaged in
any way.
• When your TV exhibits a distinct change in
performance.
Safety check
After completing any service or repair to this TV,
ask the service technician to perform routine
safety checks to determine that your TV is in
correct operating condition.
Power source
Operate your TV only from the type of power
source indicated on the marking label. If you are
not sure of the type of power supplied to your
home, consult your TV dealer or local power
company.
Screen protection
Your TV’s screen is made of glass. Do not drop
your TV or hit the glass screen. If the screen
breaks, be careful of broken glass.
Non-active pixels
The LCD panel contains almost 3 million thin film
transistors, which provide exceptionally sharp
video quality. Occasionally, a few nonactive
pixels may appear on the screen as a fixed blue,
green, or red point. These non-active pixels do
not adversely affect the performance of your TV,
and are not considered defects.
Outdoor antenna grounding
If an outside antenna or cable system is
connected to your TV, make sure that the
antenna or cable system is grounded to provide
some protection against voltage surges and
built-up static charges. Article 810 of the
National Electrical Code, ANSI/NFPA No. 70,
provides information with respect to correct
grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors,
location of the antenna-discharge unit,
connection to grounding electrodes, and
requirements for the grounding electrode.
1
1 Electric service equipment
2 Power service grounding electrode system
3 Ground clamps
4 Grounding conductors
5 Antenna discharge unit
6 Grounding clamp
7 Antenna lead-in wire
Note to CATV system installer
This reminder is provided to call the CATV
system installer’s attention to Article 820-40 of
the NEC that provides guidelines for correct
grounding and in particular, specifies that the
cable ground must be connected to the
grounding system of the building as close to the
point of cable entry as practical.
7
6
5
4
3
2
6
www.insignia-products.com
Insignia NS-LCD19W-09 19” LCD TV
End of life directives
Your new TV contains materials which can be
recycled and reused. At the end of your TV’s life,
specialized companies can dismantle the
discarded TV to concentrate the reusable
materials and to minimize the amount of
materials to be disposed of. Dispose of your old
TV according to local regulations.
Features
Accessories
Make sure that the following accessories are
provided in the packaging:
• Remote control and batteries (2 × AAA)
•User Guide
• Quick Setup Guide
Front
I
NPU
T
# Item Description
1 POWER button Press to turn your TV on or off.
2 Remote sensor Receives signals from the remote control.
3 Power/Standby
indicator
4 INPUT button Press to select the AV signal input. You can
5 MENU button Press to open the on-screen menu.
6VOL +/-
buttons
7 CH+/- buttons Press to change the channel.
Do not block.
Lights when your TV is plugged into a
power outlet. When your TV is on, the
indicator is blue. When your TV is in
standby mode, the indicator is red.
select TV, Video, S-Video, Component,
PC, or HDMI.
Press to adjust the volume.
Back
# Connection Description
1 ANT IN (coaxial
antenna input)
2 Headphone jack Plug your headphones into this jack.
3 AUDIO IN L and
AUDIO IN R (for
composite video)
4 VIDEO IN (composite
video)
5 S-VIDEO input Connect the S-Video output from an
6Y, Pb, Pr
(component) video in
7 AUDIO IN L and
AUDIO IN R (for
component video)
8 VGA IN (PC
connection)
9 PC AUDIO IN Connect the audio cable from your
10 HDMI input Connect the HDMI cable from an
Connect the outside antenna or cable
TV cable to this jack.
Connect the audio output from an
external device into these jacks.
Connect the composite video output
from an external device into this jack.
external device into this jack.
Connect the component video output
from an external device into these
jacks.
Connect the audio output from an
external device into these jacks.
Connect the VGA cable from your PC
to this connector.
PC to this jack.
external device to this connector.
www.insignia-products.com
7
Insignia NS-LCD19W-09 19” LCD TV
Remote Installing remote control batteries
To install the remote control batteries:
1 Open the battery cover on the back of the
remote control.
2 x AAA
2 Insert two AAA batteries into the battery
compartment. Make sure that you match the
+ and – symbols on the batteries with the +
and – symbols in the battery compartment.
3 Close the cover.
Notes
• Do not mix batteries of different types.
• Do not mix old and new batteries.
• Remove batteries when the charge is depleted.
• Battery chemicals can cause a rash. If the
batteries leak, clean the battery compartment
# Button Description
1
2 INPUT Press to cycle through the input source
3 ZOOM Press to change the zoom mode.
4 MUTE Press to mute the sound. Press again to
5 Number
6 – Press to view digital sub-channels. First
7 MENU Press to open the on-screen menu.
8CH +/- and
9 ENTER Press to confirm your selections.
10 CCD Press to select the closed caption mode
11 PICTURE Press to change the picture mode.
12 MTS/SAP Press to select Stereo, Mono, or SAP
13 DISPLAY Press to display information about the
14 SLEEP Press to cycle through the times available
15 RECALL Press to return to the previous channel in
16 EXIT Press to exit the on-screen menus.
17 AUDIO Press to change the sound mode.
18 CH.LIST Press to open the channel list.
19 FAVORITE Press to display your favorite channels list.
(power)
buttons
VOL +/-
Press to turn your TV on or off.
options.
restore the sound.
Press to enter channel numbers directly.
enter the main channel number, then press
this button, then enter the sub-channel
number.
Press to change the channel or press to
increase or decrease the volume.
while in TV mode.
mode.
input source.
for Sleep mode.
TV mode.
with a cloth. If chemicals touch your skin, wash
immediately.
• If the remote control is not going to be used for
an extended period of time, remove the
batteries.
8
www.insignia-products.com
Insignia NS-LCD19W-09 19” LCD TV
Using the remote control
To use the remote control:
• Point the remote control directly at your TV,
within a 60° angle horizontally (30° to either
side), and within 30° vertically of the remote
control sensor on the front of your TV and
within 26.25 feet (8 m) of your TV.
Caution
Do not expose the remote control to liquids, direct
sunlight, or shock. Do not mix batteries of different
types.
Notes
• Objects between the remote control and the
remote control sensor may block the remote
control signal.
• The range of the remote control may be
diminished if direct sunlight or other strong light
is shining on the remote control sensor. In this
case, change the angle of the lighting, move
your TV, or operate the remote control closer to
the remote control sensor.
Setting up your TV
Connecting an antenna, cable TV, or satellite TV
Grounding
Make sure that you connect the grounding/earth
wire to prevent possible electric shock. If
grounding methods are not possible, have a
qualified electrician install a separate circuit
breaker. Do not ground the TV by connecting it
to telephone wires, lightening rods, or gas pipes.
Connecting an antenna
Antenna cables come in two types: 75 ohm and
300 ohm.
75 ohm cable
300 ohm cable
• If your antenna cable has a 75 ohm
connector, connect the cable to the coaxial
jack on the back of your TV.
• If your antenna cable has a 300 ohm
connector, connect the cable to a
300-75 ohm adapter (not included), connect
the adapter to a 75 ohm cable, then connect
the other end of the 75 ohm connector to the
coaxial jack on the back of your TV.
Connecting cable TV
Your TV has a 75 ohm jack for connecting cable
TV.
Some cable TV providers scramble the signals
for “premium” (pay) channels. To view these
channels, you need a converter/descrambler
box.
If you do not have a converter/descrambler box,
you can connect your cable TV directly to your
TV. If you have a converter/descrambler box, you
can connect your cable TV using an RF switch
(not supplied). For more information about
connecting a converter/descrambler box, contact
your cable TV provider.
To connect an antenna or cable TV:
1 Connect the antenna cable from an antenna,
or cable TV to the ANT IN jack on the back of
your TV.
2 Turn on your TV.
3 Press INPUT repeatedly to select TV.
www.insignia-products.com
9
Insignia NS-LCD19W-09 19” LCD TV
Connecting a set-top box or satellite TV
#2
#1
To connect a set-top box or satellite TV
(alternative #1):
1 Connect the antenna cable from the set-top
box or satellite box to the ANT IN jack on the
back of your TV.
2 Turn on your TV and the cable or satellite
box.
3 Switch the channel selection to channel 3 or
4 on the cable or satellite box, then tune your
TV to the same channel.
4 Press INPUT repeatedly to select TV.
5 Change channels with the cable or satellite
box, or with the cable or satellite remote
control.
Set the RF switch to the B position to watch
scrambled channels controlled by the cable
or satellite box or remote control.
RF switch
A
B
Out
TV
Cable converter/descrambler box
Two-set signal splitter
In
Connecting a VCR or standard video device
To connect a set-top box or satellite TV
(alternative #2):
1 Plug an RCA video cable into the cable or
satellite box and into the VIDEO IN (yellow)
jack on the back of your TV.
2 Plug the RCA audio cables into the cable or
satellite box and into the AUDIO IN R (red)
and AUDIO IN L (white) jacks on the back of
your TV.
3 Turn on your TV and the cable or satellite
box.
4 Press INPUT repeatedly to select Video.
5 Change channels with the cable or satellite
box, or with the cable or satellite remote
control.
To connect a set-top box or satellite TV
(alternative #3):
1 Use the following illustration to connect a
converter/descrambler box. (The RF switch
and the signal splitter are not provided.)
2 Set the RF switch to the A position to watch
unscrambled channels controlled by your TV
remote control.
- OR -
To connect a standard video device to the
VIDEO IN jacks:
1 Plug an RCA video cable into a VCR or other
standard video source and into the VIDEO IN
(yellow) jack on the back of your TV.
2 Plug the RCA audio cables into the video
device's audio output jack and into the
AUDIO IN R (red) and AUDIO IN L (white)
jacks on the back of your TV.
3 Turn on your TV.
4 Press INPUT repeatedly to select Video.
To connect a standard S-Video device to the
S-VIDEO jack:
1 Plug an S-Video cable into the S-Video out
jack on an S-Video device and into the
S-VIDEO jack on the back of your TV.
2 Plug RCA audio cables into the S-Video
device audio output jacks and into the AUDIO
IN L and AUDIO IN R jacks on the back of
your TV.
3 Turn on your TV.
4 Press INPUT repeatedly to select S-Video.
10
www.insignia-products.com
Insignia NS-LCD19W-09 19” LCD TV
Connecting a component video device
To connect a DVD or other video source to
the component in jacks:
1 Plug component video cables into the DVD
player or other video device and into the
Y/Pb/Pr jacks on the back of your TV.
2 Plug the RCA audio cables into the audio out
jacks on the DVD player or other video device
and into the lower AUDIO R (red) and
AUDIO L (white) jacks on the back of your
TV.
3 Turn on your TV and the DVD player, then
insert a DVD.
4 Press INPUT repeatedly to select
Component.
Connecting an external component
Camcorder
Game console
To connect an external component:
1 Plug an RCA video cable into a VCR or other
standard video source and into the VIDEO IN
(yellow) jack on the back of your TV.
2 Plug the RCA audio cables into the video
device's audio output jack and into the
AUDIO IN R (red) and AUDIO IN L (white)
jacks on the back of your TV.
3 Turn on your TV and the external component.
4 Press INPUT repeatedly to select Video.
Connecting a computer
Connecting HDMI input
HDMI
To connect a standard video device to the
VIDEO IN jacks:
1 Plug an HDMI cable into a DVD or other
video source and into the HDMI jack on the
back of your TV.
2 Turn on your TV.
3 Press INPUT repeatedly to select HDMI.
To connect a computer using VGA:
1 Turn off your TV and your PC.
2 Plug a VGA cable into the VGA port on the
computer and into the VGA IN port on the
back of your TV.
3 Plug an audio cable into the audio jack on the
computer and into the PC AUDIO IN jack on
the back of your TV.
4 Turn on your TV, then turn on your PC.
5 Press INPUT repeatedly to select PC.
6 Check the image on your TV. There may be
problems associated with the resolution,
vertical pattern, contrast, or brightness in PC
mode. If problems occur, change your PC to
another resolution, change the refresh rate to
another rate, or adjust the brightness and
contrast on the menu until the picture is clear.
If the refresh rate of the PC graphic card can
not be changed, change the PC graphic card
or consult the manufacturer of the card.
www.insignia-products.com
11
Insignia NS-LCD19W-09 19” LCD TV
Mode Resolution
VGA 640×480 31.5 60
SVGA 800×600 37.9 60
XGA 1024×768 48.4 60
Caution
With DPMS set to ON, the TV will automatically
turn off after two minutes if there is no signal in PC
mode.
Note
With DPMS set to OFF, if the TV turns off
automatically because there is no activity, you
must turn the TV back on manually. It will not
come on automatically when you start to use your
PC again.
Line frequency
(KHz)
Using your TV
Turning the TV on and off
To turn your TV on and off:
1 Press POWER on the front of your TV or
on the remote control. The
POWER/STANDBY indicator turns blue.
2 To turn off your TV, press POWER again. The
POWER/STANDBY indicator turns red.
Choosing the video source
To select the video source:
1 Press INPUT to open the
menu, then press CH+ or CH- to choose the
source you want. You can select:
•TV
•Video
•S-Video
• Component
•PC (VGA)
• HDMI
2 Press ENTER to confirm your selection.
Changing channels
To change channels:
• Press the CH+ or CH- to select a higher or
lower channel.
To enter a channel number directly:
1 Press the number buttons on the remote
control.
In digital TV mode, a main (major) channel
can have one or more sub. (minor) channels.
Press the number buttons to enter the main
channel, press the - button (to the left of the 0
button), then press the number button for the
sub-channel. For example, if you want to
watch channel 5.2, press 5, press the button, then press 2.
2 Press ENTER to confirm.
To go to the previous channel:
• Press RECALL.
Select Source
Frame frequency
(Hz)
Adjusting the volume
You can adjust the volume using the controls on
your TV's side panel or the remote control.
To adjust the volume:
1 Press VOL+ or VOL- to increase or decrease
the volume.
2 Press MUTE to mute the sound, then press
this button again to restore the sound.
Displaying current program information
To display current program information:
• Press DISPLAY.
Selecting a preset picture mode
To select a preset picture mode:
• Press PICTURE repeatedly to cycle through
the available picture modes. Choices include
Mild, Standard, Vivid, and Custom.
Selecting a preset audio mode
To select a preset picture mode:
• Press AUDIO repeatedly to cycle through the
available audio modes. Choices include Off,
Concert, Living Room, Hall, Bathroom,
Cave, Arena, and Church.
Setting sleep mode
To select the sleep mode duration:
• Press SLEEP repeatedly to cycle through the
available number of minutes. Choices include
Off, 5 Min, 10 Min, 15 Min, 30 Min, 45 Min,
60 Min, 90 Min, 120 Min, 180 Min, and 240
Min.
After you set the sleep timer, your TV will turn
off automatically after the selected amount of
time.
Selecting an aspect ratio
To select an aspect ratio:
• Press ZOOM repeatedly to cycle through the
available zoom modes. Choices include Full
Screen, Normal, Wide, Zoom, and Cinema.
Choices may be different for different signal
sources.
Using the channel list
To use the channel list:
1 Press CH.LIST to display the channel list.
2 Press VOL+ or VOL- to go to the next or
previous page.
3 Press CH+ or CH- to select the channel you
want, then press ENTER to confirm.
Using the favorites list
To use the favorites list:
1 Press FAVORITE to display your favorite
channels list.
2 Press CH+ or CH- to select the channel you
want, then press ENTER to confirm.
To add channels on your favorites list:
1 Go to the channel you want to add, then
press FAVO RITE .
12
www.insignia-products.com
Insignia NS-LCD19W-09 19” LCD TV
2 Press CH+ or CH- to select to a blank record,
then press ENTER to add the current
channel to your favorites list.
To remove channels from your favorites list:
1 Go to the channel you want to remove, then
press FAVO RIT E to open your favorites list.
2 Press CH+ or CH- to select to the record of
current channel, then press ENTER to
remove it from your favorites list.
Using the on-screen menus
Use your remote control to navigate in the
on-screen menus. The on-screen menus shown
in this guide may be different from those on your
TV. These are examples to illustrate your TV’s
operation.
To use the on-screen menus:
1 Press INPUT on the remote control to select
the video source.
2 Press MENU on the remote control. The
on-screen menu appears.
3 Press CH+ or CH- to highlight the Video,
Audio, Channel, Function, or Lock icon,
then press ENTER to enter the menu.
4 Press CH+ or CH- highlight a setting, then
press ENTER to confirm.
5 Press VOL+ or VOL- to adjust the setting.
6 Press EXIT to close the menu and return to
normal viewing.
Adjusting picture settings
Adjusting TV picture settings
To adjust TV picture settings:
1 Press MENU on the remote control. The
on-screen menu appears.
2 Press CH+ or CH- to highlight the Video
icon, then press ENTER to enter the
menu.
Video
• Color—Set the color saturation of the
picture.
•Tint—Set the color tone of the picture.
• Sharpness—Set the amount of detail
enhancement of the picture.
• Color Temperature—Select Warm
(increased red tones), Custom (to make
your own settings), Cool (increased blue
tones), or Standard for a balance.
• Advanced Video—Select to change
advanced picture settings, which include:
• DNR–Digital Noise Reduction. Adjust
to reduce the appearance of digitizing
error caused by compression: Off,
Auto, Weak, Medium, or Strong.
• Black Level Extender–Adjust to
increase the level of detail in black
areas of the picture: On or Off.
• White Peak Limiter–Adjust to increase
the level of detail in white areas of the
picture: On or Off.
• CTI–Color Transient Intensity. Adjust
the picture to eliminate color errors:
Medium, Strong, Off, and Weak.
• Flesh Tone–Adjust the flesh colors: On
and Off.
• Adaptive Luma Control–Adjust the
luminance of the picture: On and Off.
4 Press VOL+ or VOL- to adjust the setting.
5 Repeat Steps 3 and 4 to adjust the other
settings.
6 Press EXIT to close the menu and return to
normal viewing.
Adjusting PC picture settings
When you are using a PC with your TV, a special
PC option becomes available. This lets you
optimize your TV’s picture settings for use with
the PC.
To adjust PC picture settings:
1 Press MENU on the remote control. The
on-screen menu appears.
2 Press CH+ or CH- to highlight the Video
icon, then press ENTER to enter the
menu.
Video
3 Press CH+ or CH- to highlight an option, then
press ENTER to confirm. Choices include:
• Mode—Select a preset picture mode
which best corresponds to your viewing
requirements. Choices include Mild,
Standard, Vivid, and Custom.
Note
The Brightness, Contrast, Sharpness, Color
Temperature, and Tint can only be adjusted if
Custom mode is selected.
• Brightness—Set the brightness level of
the picture.
• Contrast—Set the contrast balance of the
picture.
www.insignia-products.com
13
Insignia NS-LCD19W-09 19” LCD TV
3 Press CH+ or CH- to highlight PC, then press
ENTER to confirm. The
opens.
4 Press CH+ or CH- to highlight an option, then
press ENTER to confirm. Choices include:
• Auto Sync—Press VOL+ to automatically
adjust the settings for optimum PC
viewing.
• H Position—Adjusts the horizontal
position of the picture.
• V Position—Adjusts the vertical position
of the picture.
• Phase—Adjusts the phase setting of the
picture.
• Clock—Adjusts the clock setting of the
picture.
5 Press VOL+ or VOL- to adjust the setting.
6 Repeat Steps 4 and 5 to adjust the other
settings.
7 Press EXIT to close the menu and return to
normal viewing.
Adjusting audio settings
To adjust audio settings:
1 Press MENU on the remote control. The
on-screen menu appears.
2 Press CH+ or CH- to highlight the Audio
icon, then press ENTER to enter the
menu.
PC Video
sub-menu
Audio
• Equalizer—Selects a preset equalizer
setting. Settings include Off, Rock, Pop,
Live, Dance, Techno, Classic, and Soft.
• SPDIF Type—Adjusts the spdif output.
Settings include Off, Dolby Digital, and
PCM.
• AVL—Reduces the differences in volume
level between different broadcasters.
• Audio Only—Turns off the picture and
leaves the sound on. Press ENTER to
enter the sub-menu, then press VOL- to
select OK. Press ENTER to confirm. The
TV picture turns off, but the sound
remains on. Press POWER to restore the
picture on the screen.
4 Press VOL+ or VOL- to adjust the setting.
5 Repeat Steps 3 and 4 to adjust the other
settings.
6 Press EXIT to close the menu and return to
normal viewing.
Receiving SAP (Secondary Audio Program) Broadcasts
This TV can receive MTS (Multi-channel
Television Sound) stereo programs and the SAP
that accompanies the stereo program (if
available).
Only monaural sound is available if the
broadcast is in mono, even though Stereo or
SAP is selected. Select Mono if you want to
listen to mono sound during a stereo/SAP
broadcast.
Stereo or SAP can be received on an analog
channel.
To listen to SAP:
1 Press MTS/SAP to cycle through the
available sound settings. Choices include
Mono, Stereo, and SAP.
Alternate languages (if available) can also be
selected on digital broadcasts by pressing
MTS/SAP.
2 Press EXIT return to TV viewing.
14
3 Press CH+ or CH- to highlight a setting, then
press ENTER to confirm. Choices include:
• Balance—Adjusts the audio output
between left and right speakers.
• Bass—Increases or decreases the level
of bass sounds.
• Treble—Increases or decreases the level
of the treble sounds.
• Sound Surround—Turns the simulated
surround sound On and Off.
• Mode—Selects the type of sound which
best corresponds to your listening
requirements by selecting Mode in the
Audio
menu.
www.insignia-products.com
Memorizing channels
To select channels with the CH+ or CH- buttons,
your TV first needs to memorize the channels.
When your TV memorizes channels, it scans for
channels with signals, then stores the channel
information into memory.
To memorize available channels:
1 Press MENU on the remote control. The
on-screen menu appears.
2 Press CH+ or CH- to highlight the Channel
icon, then press ENTER to enter the
menu.
Channel
Insignia NS-LCD19W-09 19” LCD TV
3 Press CH+ or CH- to highlight a selection,
then press ENTER to initiate the scan or go
to the sub-menu (if available). Choices
include:
• Tuner—Lets you choose the source of
your TV signal. Press VOL+ or VOL- to
select Antenna or Cable, then press
ENTER to confirm.
• Channel Scan—Scans the TV signal
source for available channels, then puts
them into memory. Press ENTER to
initiate the scan. When the scan is
completed, the first program appears on
the screen.
• Channel Skip—Lets you specify
channels that you do not want shown on
your channel list. The channels are still
available by directly inputting the channel
number. Press ENTER to go to the
sub-menu. See “Skipping channels” on
page 15.
• Channel Label—Lets you name each
channel. Press ENTER to go to the
sub-menu. See “Labeling channels” on
page 15.
4 Press VOL+ or VOL- to adjust the setting.
5 Repeat Steps 3 and 4 to adjust the other
settings.
6 Press EXIT to close the menu and return to
normal viewing.
Skipping channels
To skip selected channels:
1 Press MENU on the remote control. The
on-screen menu appears.
2 Press CH+ or CH- to highlight the Channel
icon, then press ENTER to enter the
menu.
3 Press CH+ or CH- to highlight Channel Skip,
then press ENTER to go to the sub-menu.
The
Channel Skip
sub-menu opens.
Channel
6 Press EXIT to close the menu and return to
Labeling channels
To label selected channels:
1 Press MENU on the remote control. The
2 Press CH+ or CH- to highlight the Channel
3 Press CH+ or CH- to highlight Channel
4 Press CH+ or CH- to highlight Channel
5 Press CH+ or CH- to highlight Channel
6 When you have selected the first character,
7 Repeat Steps 4 through 6 to label additional
8 Press EXIT to close the menu and return to
normal viewing.
on-screen menu appears.
icon, then press ENTER to enter the
menu.
Label, then press ENTER to go to the
sub-menu. The
opens.
Index, then press INPUT repeatedly to select
a channel to label.
Label, then press INPUT repeatedly to select
the letter, number, or symbol you want.
press VOL+ to go to the next character (up to
a maximum of 10), then repeat Steps 5 and
6. When you finish the label, press ENTER to
confirm.
If you need to change a character you have
already entered, press VOL- to go to that
character.
channels.
normal viewing.
Channel Label
Channel
sub-menu
4 Press CH+ or CH- to select a channel
number to skip, then press ENTER to
confirm. A checkmark appears in the box.
5 Repeat step 4 to skip additional channels.
www.insignia-products.com
15
Loading...
