Insignia NS-LCD15F User Manual
15" LCD TV | Téléviseur ACL de 15 po
NS-LCD15F
Insignia NS-LCD15F
15” LCD TV
Contents
Safety information . . . . . . . . . . . . . . . . . . . . . . . . .1
Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Setting up your TV . . . . . . . . . . . . . . . . . . . . . . . . .4
Using your TV . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Maintaining. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . .10
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Legal notices . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
1 Year Limited Warranty. . . . . . . . . . . . . . . . . . . .13
Français. . . . . . . . . . . . . . . . . . . . . . . . 15
Safety information
Warning
T o reduce the risk of electric shock, do not remove the cover or
back. There are no user-serviceable parts inside. Refer
servicing to qualified service personnel.
To reduce the risk of fire or electric shock, do not expose your
TV to rain or moisture.
Caution
To prevent electric shock, match the wide blade on the power
cord plug to the wide slot on an electric outlet. If the plug does
not fit, consult a licensed electrician to replace the obsolete
outlet. Do not modify the power cord plug, or you will defeat
this safety feature.
This symbol indicates that dangerous
voltage con stituting a risk of electric sho ck
is present within your TV. This label is
located on the back of your TV.
This symbol indicates that there are
important operating and maintenance
instructions in the literatur e accompan ying
your TV.
Warning
Your TV contains tin-lead solder and a fluorescent lamp
containing a small amount of mercury. Disposal of these
materials may be regulated for environmental reasons. For
disposal or recycling information, contact your local authorities
or the Electronic Industries Alliance at www.eia.org.
Read instructions
Read all of the safety and operating instructions
before you use your TV.
Retain instructions
Retain safety and operating instructio ns for
future reference.
Follow warnings and instructions
Follow all warnings on your TV and in the
operating instructions. Follow all operating and
use instructions.
Wate r and moisture
Do not use your TV near water. For example, do
not use it near a bath tub, wash bowl, kitchen
sink, laundry tub, in a wet basement, or near a
swimming pool.
Cleaning
Unplug your TV before cleaning. Do not use
liquid or aerosol cleaners. Use only a damp cloth
to clean the exterior of your TV.
Ventilation
Slots and openings in the cabinet and the back
or bottom are provided for ventilation, reliable
operation, and protection from overheating.
These openings must not be blocked or covered.
Do not block the openings by placing your TV on
a bed, sofa, rug, or other similar surface. Do not
place your TV near or over a radiator or heat
register. Do not place your TV in a built-in
installation, such as a bookcase or rack, unless
you provide correct ventilation or follow the
manufacturer’s instructions.
Heat
Make sure that your TV is located away from
heat sources such as radiators, heat registers,
stoves, or other products (including amplifiers)
that produce heat.
Grounding or polarization
Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A
grounding type plug has two blades and a
grounding prong. The wide blade or grounding
prong are provided for your safety. If the plug
does not fit, contact an electrician to replace the
obsolete outlet.
Power cord protection
Route power cords so they are not likely to be
walked on or pinched by items placed on or
against them. Pay particular attention to cords at
plugs, convenience receptacles, and the point
where they exit from your TV.
Attachments
Only use attachments recommended by
Insignia.
Stand
Do not place your TV on an unstable cart, stand,
tripod, bracket, or table. Your TV may fall,
causing serious personal injury and serious
damage to your TV. Use only with a cart, stand,
tripod, bracket, or table recommended by the
manufacturer, or sold with your TV. If you mount
your TV to the wall, follow the manufacturer’s
instructions and use a mounting accessory
recommended by the manufacturer. Your TV and
cart combination should be moved with care.
Quick stops, excessive force, and uneven
surfaces may cause your TV and cart
combination to overturn.
Lightning
For added protection for your TV’s receiver
during a lightning storm, or when it is left
unattended and unused for long periods of time,
unplug it from the power outlet and disconnect
the antenna or cable system. This helps prevent
damage to your TV from lightning and power line
surges.
www.insignia-products.com
1
Insignia NS-LCD15F 15” LCD TV
Servicing
Do not attempt to service your TV yourself
because opening or removing covers may
expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service
personnel.
Overloading
Do not overload power outlets and extension
cords because this can result in a risk of fire or
electric shock.
Object and liquid entry
Never push objects of any kind into your TV
through openings because objec ts may touch
dangerous voltage points or short out parts that
could result in a fire or electric shock. Never spill
liquid of any kind on your TV.
Damage requiring service
Unplug your TV from the power outlet and refer
servicing to qualified service personnel under
the following conditions:
• When the power supply cord or plug is
damaged or frayed.
• If liquid has been spilled or objects have
fallen into your TV.
• If your TV has been exposed to rain or water.
• If your TV does not operate normally by
following the operating instructions. Adjust
only those controls that are covered by the
operating instructions because incorrect
adjustment of other controls may result in
damage and will often require extensive work
by a qualified technician to restore your TV to
its normal operation.
• If your TV has been dropped or damaged in
any way.
• When your TV exhibits a distinct change in
performance.
Replacement parts
When replacement parts are required, make
sure that the service technician uses
replacement parts specified by the manufacturer
that have the same characteristics as the
original part. Unauthorized substitutions may
result in fire, electric shock, personal injury, or
other hazards.
Safety check
After completing any service or repair to your TV ,
ask the service technician to perform routine
safety checks to determine that your TV is in
correct operating condition.
Power source
Operate your TV only from the type of power
source indicated on the marking label. If you are
not sure of the type of power supplied to your
home, consult your TV dealer or local power
company.
Screen protection
Your TV’s screen is made of glass. Do not drop
your TV or hit the glass screen. If the screen
breaks, be careful of broken glass.
Pixel defect
Your TV’s screen is designed to display finely
detailed pictures. Occasionally, a few non-active
pixels may appear on the screen as fixed points
of blue, green, or red. This is not a defect and
does not affect your TV’s performance.
Outdoor antenna grounding
If an outside antenna or cable system is
connected to your TV, make sure that the
antenna or cable system is grounded to provide
some protection against voltage surges and
built-up static charges. Article 810 of the
National Electrical Code, ANSI/NFPA No. 70,
provides information with respect to correct
grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors,
location of the antenna-discharge unit,
connection to grounding electrodes, and
requirements for the grounding electrode.
7
6
5
4
3
1
1 Electric se rv ic e e q u i p me nt
2 Power service groun d i ng ele c tr o de
system
3 Ground clamps
4 Grounding conductors
5 Antenna discharge unit
6 Grounding clamp
7 Antenna lead-in wire
2
Note to CATV system installer
This reminder is provided to call the CATV
system installer’s attention to Article 820-40 of
the NEC that provides guidelines for correct
grounding and in parti c ula r, specifies that the
cable ground must be connected to the
grounding system of the building as close to the
point of cable entry as practical.
Mobile telephone warning
To avoid interference with y our TV picture and
sound, operating problems, or even damage,
keep your mobile telephone away from the TV.
End of life directives
Your new TV contains materials which can be
recycled and reused. At the end of your TV’s lif e ,
specialized companies can dismantle the
discarded TV to concentrate the reusable
materials and to minimize the amount of
materials to be disposed of. Make sure that you
dispose of your old TV according to local
regulations.
2
www.insignia-products.com
Insignia NS-LCD15F 15” LCD TV
Features
Front
1
2
3
6
# Button Description
1
VOL
2
VOL
3
CH
4
CH
5 MENU Press to show the on-screen menu.
6 INPUT Press to cycle through the available input
7 POWER Press to turn on your TV or put it into
Press to increase the volume. In Menu
mode, functions as the right arrow to go
to the next menu or increase a setting.
Press to decrease the volume. In Menu
mode, functions as the left arrow to go to
a previous menu or decrease a set ting.
Press to go to the next higher channel. In
Menu mode, functions as the up arro w.
Press to go to the next lower channel. In
Menu mode, functio n s as th e d ow n arro w.
sources. In Menu mode, functi ons as the
ENTER key.
Standby mode.
Remote control
1
2
3
4
15
16
17
5
4
5
6
7
8
7
9
10
11
12
13
CCD
AUDIO
ZOOM
MENU
MTS/SAP
AB
C
D
18
19
20
21
22
23
24
14
# Button Description
1 POWER Press to turn on your TV or put it into
2 INPUT Press to select the vi deo input signal
3 VIDEO Press to toggle between S-Video and
4 COMP Press to select Component source
5 Number buttons Press to enter channel numbers.
6 CCD Press to turn closed captions on and off.
7 VOL + Press to adjust the volume up.
8 MUTE Press to mute the sound. Press again to
9 VOL – Press to adjust the volume down.
10 ZOOM Press to select the display aspect ratio.
11
MENU
12 P.LOCK Press to activate or deactivate Parental
13 MTS/SAP Press to select one of the preset audio
14 A, B, C, D Not supported by this model.
Standby mode.
source.
Composite source modes.
mode.
In the on-screen menu, press to enter
your parental control’s password.
For more information, see “Viewing
closed captio ns” on page 7.
restore the sound.
Press these keys to move down, up, left,
or right in the on-screen menus. When
the on-screen menu is closed, press left
or right to adjust the volume, and press
up or down to change channels.
Press MENU to open the on-screen
menu.
Controls. See “Setting parental controls”
on page 7 for information on setting up
Parental Controls.
modes. You can select MONO, STEREO,
or SAP.
www.insignia-products.com
3
Insignia NS-LCD15F 15” LCD TV
# Button Description
15 DISPLAY Press to display status information.
16 TV Press to select TV mode.
17 PC Press to select PC mode.
18
19
20 AUDIO Press to select the sound mode.
21
22 EXIT Press to close the on-screen menu.
23 PICTURE Press to change to Video Page.
24 SLEEP Press to set the sleep timer. For more
RECALL
CH
CH
Press to watch the previous channel.
Press to change TV channe ls up.
Press to change TV channe ls down.
information, see “Setting the sleep
timer” on page 6.
Using the remote control
To use the remote control:
• Point the remote control towards the remote
sensor on the front of your TV.
Notes
• Do not expose the remote control to shock or
liquids.
• Do not use the remote control in an area with
high humidity.
• Do not place the remote control in direct
sunlight.
• Do not place objects, such as furniture,
between the remote control and the remote
sensor.
• The remote control may not work if direct
sunlight or bright light shines on the remote
sensor. Either move your TV or change the
angle at which you use the remote control.
Notes
• Do not mix batteries of different types.
• Do not mix old and new batteries.
• Remove batteries when the charge is depleted.
• Battery chemicals can cause a rash. If the
batteries leak, clean the battery compartment
with a cloth. If chemicals touch your skin, wash
immediately.
• If the remote control is not going to be used for
an extended period of time, remove the
batteries.
Universal remote control programming
This TV is compatible with several popular
universal remote co ntrols.
Brand Program code
Philips 115
RCA 135
Connecting your TV to a power outlet
To connect your TV to a power outlet:
• Plug the power cord into a power outlet.
Notes
• Make sure that you use the correct type of
power. See the label on your TV.
• If you do not intend to use your TV for an
extended period of time, unplug the power cord
from the power outlet.
Connecting an outside antenna
Antenna cables come in two types: 75 ohm and
300 ohm.
75 ohm cable
Setting up your TV
Installing remote control batteries
To install the remote control batteries:
1 Remove the battery cover.
2 Insert two AAA batteries into the battery
compartment. Make sure that you match the
+ and – symbols on the batteries with the +
and – symbols in the battery compartment.
3 Replace the cover.
300 ohm cable
• If your antenna cable has a 75 ohm
connector, connect the cable to the coaxial
jack on the back of your TV.
• If your antenna cable has a 300 ohm
connector, connect the cable to a
300-75 ohm adapter (not included), connect
the adapter to a 75 ohm cable, then connect
the other end of the 75 ohm connector to the
coaxial jack on the back of your TV .
Connecting cable TV
Your TV has a 75 ohm jack for connecting cable
TV.
Some cable TV providers scramble the signals
for “premium” (pay) channels. To view these
channels, you need a converter/descrambler
box.
If you do not have a converter/descrambler box,
you can connect your cable TV directly to your
TV. If y ou ha v e a con v erter/descr amb ler bo x, y ou
can connect your cable TV using an RF switch
(not supplied). For more information about
connecting a converter/descramble box, contact
your cable TV provider.
4
www.insignia-products.com
Insignia NS-LCD15F 15” LCD TV
To connect cable TV without a converter/descrambler box:
1 Connect one end of a 75 ohm cable to the
coaxial jack on the back of your TV.
2 Connect the other end of the cable to the
cable TV wall outlet.
To connect cable TV with a converter/descrambler box:
• Use the following illustration to connect a
converter/descrambler box. (The RF switch
and the signal splitter are not provided.)
Set the RF switch to the A position to watch
unscrambled channels using your TV remote
control. Set the RF switch to the B position to
watch scrambled channels using the
converter/descrambler controls.
RF switch
A
Two-set signal splitter
TV
R
Y
RW
B
Out
TV
Cable converter/descrambler box
In
Connecting to an external signal source
You can connect a DVD, VCD, or VCR using a
variety of methods, including composite cables,
component cables, or an S-Video cable. The
S-Video cable does not carry sound. If you use
an S-Video cable, you need to use audio cables
to connect the audio output.
Warning
Make sure that you turn off and unplug your TV
before connecting devices.
Note
For better video, use the S-Video jack if your VCR
has an S-Video connection.
To connect an external signal source:
1 Make one of the following connections:
• For composite video—Plug the
audio/video cable into the AUDIO L,
AUDIO R, and VIDEO in jacks on the
back of your TV.
• For S-Video—Plug in the audio cables as
described above, then plug one end of an
S-Video cable into the S-VIDEO jack on
the back of your TV and the other end into
the S-Video jack on the external signal
source.
• For component video—Plug the Y, Pb,
and Pr video cables and the Audio L and
Audio R cables into the component input
jacks.
2 Turn on your TV.
3 Press the INPUT button repeatedly to select
the external signal source you want to watch.
4 Turn on external signal source.
5 Insert a disc or videotape into the external
signal source, then press the PLAY button.
AV IN COMPONENT IN
R
L
Video Composite
input rear
DC IN
PC IN
AUDIO
VGA Audio
input
VGA
VGA
input
Connecting a computer
Warning
Make sure that you turn off and unplug your TV
before installing devices.
To connect a computer:
1 Plug a VGA cable from your computer into
the VGA jack on the back of your TV.
2 Plug an audio cable from your computer’s
audio out jack into the PC IN AUDIO jack on
the back of your TV.
3 Plug in and turn on your TV.
4 Press the INPUT button repeatedly, or press
the PC key on the remote control, to select
the PC source.
Using your TV
Turning your TV on and off
To turn your TV on and off:
1 Make sure that the AC power adapter cord is
connected to your TV and to a power outlet.
2 Press the POWER button to turn on your TV.
The power indicator LED turns green.
3 Press the POWER button again to retur n
your TV to standby . The power indicator LED
turns orange.
Video Component
input
www.insignia-products.com
5
Insignia NS-LCD15F 15” LCD TV
Selecting the TV signal source
To select the TV signal source:
• With the TV on, press the INPUT button on
either the TV or the remote to choose from:
• TV (antenna)
• AV (composite)
•S-Video
• Component
• VGA - computer
Setting up the channel list
If you selected antenna or cable as your TV
source, you need to set up the channel list.
When you set up your channel list, your TV
searches for all available channels in your area
and stores a list of these channels. When you
press the CH – or CH + buttons, your TV skips
the channels that do not have a signal.
Automatically setting up channels
To automatically set up the channel list:
1 Press the MENU button. The on-screen
menu opens to the Audio page .
2 Press or to select the TV menu. The TV
menu opens.
Or, press the number buttons to directly
select a channel (for example, if you want
channel 83, press 8, then press 3). If you
want channel 125, press 1, then 2, then 5.
Or , press t he RECALL button to go to the last
viewed channel.
Adjusting the volume
To adjust the volume:
• Press the VOL – or VOL + button on the
remote to decrease or increase the volume.
Or, press or on the TV to decrease or
increase the volume.
• Press the MUTE b utton to turn off the sound.
Press the MUTE button again to turn the
sound back on.
Displaying status information
To display status information:
• Press the DISPLAY button. Your TV displays
status information at the top left of the
screen, such as the channel number or signal
source.
Setting the clock
To set the clock:
1 Press the MENU button. The on-screen
menu opens to the Audio page.
2 Press or repeatedly to select the OSD
menu . The OSD menu opens.
3 Press or to highlight Auto Search, then
press or to start the search.
Manually adding or deleting channels from the channel list
After you create a channel list using the Auto
Search option, you can manually add or delete
channels from the channel list.
To add or delete channels:
1 Change to the channel you want to add or
delete.
2 Press the MENU button. The on-screen
menu opens to the Audio page.
3 Press or to select the TV menu ,
then press or to highlight Skip.
4 Press or to set Skip to On or Off. If you
want to add the channel to the channel list,
set Skip to Off. If you want to delete the
channel from the channel list, set Skip to On.
5 Press MENU or EXIT to close the menu.
Changing channels
To change channels:
• Press the CH – or CH + button on the remote
control to go to the next lower or higher
channel.
3 Press or to highlight Set Time.
4 Press or to move to the different fields,
then press or to change the settings.
5 Press MENU or EXIT button to close the
menu.
Setting the sleep timer
The sleep timer lets you select the amount of
time before your TV turns off automatically.
To set the sleep timer:
1 Press the MENU button. The on-screen
menu opens to the Audio page.
6
www.insignia-products.com
Insignia NS-LCD15F 15” LCD TV
2 Press or to select the OSD menu .
The OSD menu opens.
3 Press or to highlight Sleep Timer.
4 Press or to select the amount of time
(Off, 5 min, 10 min, 15 min, 30 min, 45 min,
60 min, 90 min, 120 min, 180 min, 240
min).
5 To turn off the timer, select Off.
Note
You can also press the SLEEP button to set the
sleep timer.
Viewing closed captions
To view closed captions:
• Press the CCD button repeatedly to select a
closed caption option. You can select CC1,
CC2, CC3, CC4, TT1, TT2, TT3, TT4, or Off.
To turn on closed captions with the menu:
1 Press the MENU button. The on-screen
menu opens to the Audio menu.
2 Press or to select the OSD menu .
The OSD menu opens.
To set up a password:
1 Press the MENU button. The on-screen
menu opens to the Audio page.
2 Press or to select the V-Chip menu .
The V-Chip menu opens.
3 Press or repeatedly to highlight Set
Password. The Password screen opens.
4 Press the number buttons to enter the old
password. If you have not set a password,
enter 0000.
5 Press the number buttons to enter a new
password.
3 Press or to highlight CC, then press
or to turn closed captioning On or Off.
4 Press or to highlight CC Preset, then
press or to turn closed captioning preset
option to CC1, CC2, CC3, CC4, TT1, TT2,
TT3, TT4, or Off.
5 Press MENU or EXIT to close the menu.
Setting parental controls
Your TV has a V-chip that lets you control the
type of programs your children can watch.
Parental controls include four rating systems:
MPAA Rating, PG Rating, Can. English, and
Can. French. Each rating system has preset
levels for each of the five Age settings: Child,
Youth, Youth Adult, Adult, and Custom.
Before you can select ratings, you need to set up
a parental controls password.
6 Press the number buttons to enter the new
password again, to confirm.
Caution
Write down your password and save it for future
use.
Note
If you forget your password, enter 3448 for the old
password, then enter a new password. This
password always remains valid for resetting your
password.
Setting the Parental Control level
To set the Parental Control level:
1 Press the MENU button. The on-screen
menu opens to the Audio menu.
www.insignia-products.com
7
Insignia NS-LCD15F 15” LCD TV
2 Press or to select the V-Chip menu .
The V-Chip menu opens.
3 Press or repeatedly to highlight Age,
then press or to set the Age option to
Child, Youth, Youth Adult, Adult, or
Custom.
Each Age setting changes the rating settings
accordingly.
4 Press MENU or EXIT to close the menu. To custom set the Parental Control level:
1 Press the MENU button. The on-screen
menu opens to the Audio menu.
2 Press or to select the V-Chip menu .
The V-Chip menu opens.
7 To set the Can.English rating, press or
to move to Can.English, then press or , to
set the rating to E, C, C8+, G, PG,
14+, or
18+.
8 To set the Can.French rating, press or
to move to Can.French, then press or , to
set the rating to E, G, 8+, 13+, 16+, or 18+.
9 Press MENU or EXIT button to close the
menu.
American MPAA ratings
Rating Description
OFF Not rated.
G General audiences.
PG Parental guidance suggested. Some
PG-13 Parental guidance strongly suggested.
R Restricted. Not suitable for children
NC-17 Not suitable for children under 17
XAdults only.
material may not be suitable for
children.
Some material may not be sui table for
children under 13 years of age.
under 17 years of age unless
accompanied by a parent or guardian.
years of age.
TV Parental Guidelines (PG) ratings
3 Press or repeatedly to highlight Age,
then press or to set the Age option to
Custom.
4 To set the MPAA rating, press or
repeatedly to highlight MPAA Rating, then
press or to set the rating to G, PG,
PG-13, R, NC-17, X, or Off.
5 To set the TV rating, press or
repeatedly to highlight PG Rating. The
Rating window opens.
6 Press or to mov e to a rating, then press
or , to block (B), or unblock (U) that rating.
When you block a rating, that rating and all
higher ratings are blocked. When you unblock
a rating, that rating and all lower ratings are
unblocked.
Rating Description
NONE Not rated.
TV-Y All children.
TV-Y7 Children over seven years of age.
TV-G General audiences.
TV-PG Parental guidance suggested.
TV-14 Parents strongly cautioned.
TV-MA Mature audiences only.
Some of the age-based TV Parental Guidelines
ratings also have content-based ratings.
Rating Description
FV Fantasy violence.
L Adult language.
S Sexual situations.
V Violence.
D Sexually suggestive dialog.
Canadian English MPAA Ratings
Rating Description
ENot rated
CChildren
C8+ Child ren 8 years and above
G General audience
PG Parental guidance suggeste d.
14+ 14 years old and above
18+ Adu lt programming
8
www.insignia-products.com
Insignia NS-LCD15F 15” LCD TV
Canadian French MPAA Ratings
Rating Description
ENot rated
GChildren
8+ Children 8 years and above
13+ Children 13 years and above
16+ Children 16 years and above
18+ Adult programming
Using the on-screen menu
Your TV has an on-screen menu that lets you
adjust TV settings, such as video and audio
settings.
To use the on-screen menu:
1 Press the MENU button. The on-screen
menu opens to the Audio page.
2 Press the or buttons repeatedly to select
the Video page, the V-chip page, the OSD
page, or the TV page.
3 Press or to highlight a menu item, then
press or to set the value or enter the
sub-menu (if available).
If you enter a sub-menu, press or to
highlight a menu item, then press or to
set the value.
4 Press MENU or EXIT to cl ose the on-screen
menu.
On-screen menus
On-screen
menu
Audio
Options
Volume–Adjust the volume up or down.
Balance–Adjusts the right and left speaker
volumes.
Bass–Adjusts the l ow sounds (bass).
Treble–Adjusts the high sounds (treble).
Preset–Des igned for different types of sound
output. There are four preset mode options,
including Personal , Voic e, Music, and Theater.
In Personal mode, you can set Bass, Treble,
and Equalizer according to your taste.
Equalizer–You can select and adjust the levels
for 100 Hz, 300 Hz , 1 kHz, 3 kHz, and 8 kHz.
Reset to default–Restores the settings to
factory default.
On-screen
menu
Video
V-chip
OSD
Options
Brightness–Increases the brightness to ad d
more light to dark areas of the picture.
Decreases the brightness to add more dark to
light areas of the pic ture. (0 ~ 100)
Contrast–Incre ases the picture level to adjust
the white areas of the picture. Decrea ses the
picture level to adjust the black areas of the
picture. (0 ~ 100)
Position–Only available in VGA mode. Lets you
set the horizontal and vertical position of the
Video noise–Only available in VGA mode. Lets
you adjust the phase and clock from –50 to
+50.
Auto adjust–Only available in VGA mode.
Automatically adju sts the PC input to the
optimal screen size.
Information–Only available in VGA and
Component modes. Shows the current signal
input information.
Color–Adjusts the overall color of the picture.
(0~100)
Sharpness–Increases the sharpness for a
cleaner and clearer image. Decreases the
sharpness for a smoother picture. You can
select Normal, Sharp, Sharpest, Softest, and
Soft.
Tint–Adjusts picture color fr om 0~100.
Dyn.skin tone–When the Dynamic skin tone is
ON, skin tones are more vivid.
Color Temp–Selects the color temperature of
the picture. In VGA mode, there are five
options, incl uding Normal, Warm, Cool,
SRGB, and User color. Other modes, there are
3 options, including Normal, Warm, and Cool.
Preset–Selects a preset picture mode. Options
include Personal, Movie, Sport, Weak Sign al,
and Game.
Image Size–Selects the image size. Options
include Zoom and Normal.
Reset to default –Resets the picture settings to
factory default mode.
Child lock –Enables or disables the Child lock
function.
Age–Selects a Chil d lock rating. Options
include Child,
Custom, and Off.
MPAA Rating–Sets the MPAA rating when Age
is set to Custom,
PG Rating–Sets the TV Parental Guidelines
(PG) when Age is set to Custom. Can.English–
Lets you set the Canadian English rating when
Age is set to Custom. Can.French–Lets you set
the Canadian French rating when Age is set to
Custom.
Set Password–Sets the password f or parental
control options . The default password is 0000.
See “Setting parental controls” on page 7.
Set Time–Sets the clock. For more
information, see “Setting the clock” on page 6.
Language–Sets th e language of the on-screen
menus. You can select English, French, or
Spanish.
Sleep Tim er–Sets the sleep timer.
CC–Enablea or disables the Closed Caption
function
CC Preset–Selects a Closed Caption channel.
Reset to default–Resets the OSD settings to
factory default.
Youth, Youth Adult, Adult,
www.insignia-products.com
9
Loading...
