NS-L19X-10A_09-0241_MAN_V2_English.book Page 0 Tuesday, April 7, 2009 9:29 AM

User Guide

19" LCD TV with Decorative Faceplates

NS-L19X-10A

NS-L19X-10A_09-0241_MAN_V2_English.book Page i Tuesday, April 7, 2009 9:29 AM

Contents

CHILD SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Installing the stand or wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . .4

Installing the stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Installing a wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Adjusting the viewing angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Replacing the decorative faceplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Replacing the decorative faceplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

TV components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Side buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Using the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Installing the remote control battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Aiming the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Storing the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Programming a universal remote control to work with your TV . . . . 8

Making connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Connecting the power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Connecting an antenna, cable TV, or satellite TV box . . . . . . . . . . . . . . 9

Connecting a VCR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Connecting a camcorder or game . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Connecting an HDMI device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Connecting a component video device . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Connecting a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Connecting an audio amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Connecting a digital sound system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Connecting headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Connecting an FM radio antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Turning on your TV for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Understanding the basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Turning your TV on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Selecting the video input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

On-screen menu overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Navigating the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Selecting a channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Adjusting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Adjusting basic settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Displaying additional information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page ii Tuesday, April 7, 2009 9:29 AM

Contents

Adjusting the picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Adjusting the TV picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Adjusting Advanced Video settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Adjusting the computer image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Adjusting component settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Adjusting the sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Adjusting the sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Selecting the audio mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Playing TV audio only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Changing channel settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Automatically scanning for channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Adding or skipping channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Setting up a favorite channel list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Adding or changing a channel label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Checking the DTV signal strength . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Setting parental controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Setting or changing the password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Turning the button lock on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Blocking unrated TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Setting parental control levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Downloading rating information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Using closed captioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Turning closed captioning on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Setting the analog closed captioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Setting digital closed captioning styles . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Adjusting time settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Setting the date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Setting the sleep timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Adjusting menu settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Selecting the menu language and transparency . . . . . . . . . . . . . . . . . 28

Labeling an input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Setting the input sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Restoring default settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Listening to FM radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Switching to FM mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Selecting an FM program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Presetting FM stations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Fine tuning an FM station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Video and audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

FM radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Maintaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Legal notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Two-year limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page iii Tuesday, April 7, 2009 9:29 AM

Contents

iii

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 1 Tuesday, April 7, 2009 9:29 AM

CHILD SAFETY

It makes a difference how and where you use

your flat panel display

As you enjoy your new product, keep these

safety tips in mind

The issue

The home theater entertainment experience is a growing trend, and larger TVs are popular purchases. However, TVs are not always supported on the proper stands or installed according to the manufacturer’s recommendations. We and the consumer electronics industry are committed to making home entertainment enjoyable and safe.

TVs that are inappropriately placed on dressers, bookcases, shelves, desks, speakers, chests, or carts may fall over and cause injury.

Tune into safety

• One size of TV stand does not fit all. Use only a TV stand

rated for the weight of your TV.

• Carefully read and understand all enclosed instructions

for proper use of this product.

• Don’t let children climb on or play with entertainment

system furniture and TVs.

• Don’t place TVs on furniture that can easily be used as

steps, such as a chest of drawers.

• Remember that children can become excited while

watching a program, especially on a “larger-than-life” TV. Make sure that you place or install the TV where it cannot be pushed, pulled over, or knocked down.

• Make sure that you route all cords and cables so that they

cannot be pulled or grabbed by curious children.

Wall mounting

If you decide to wall mount your TV, always remember:

• One size of wall mount does not fit all. Use only a wall mount rated for the weight of

your TV and that has been recommended by this TV manufacturer, listed in this manual, or otherwise listed by an independent laboratory as suitable for your TV.

• Follow all instructions supplied by the TV and wall mount manufacturers.

• If you have any doubts about your ability to safely wall mount your TV, get help from a

professional installer.

• Make sure that the wall where you are mounting the TV is

appropriate. Some wall mounts are not designed to be mounted to walls backed with steel studs or cinder blocks. If you are unsure, ask a professional installer.

• TVs can be heavy. At least two people are required for safe wall mount installation.

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 2 Tuesday, April 7, 2009 9:29 AM

Important safety instructions

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your TV. This label is located on the back of your TV.

This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your TV.

1 Read these instructions. 2 Keep these instructions. 3 Heed all warnings. 4 Follow all instructions. 5 Do not use this apparatus near water. 6 Clean only with dry cloth. 7 Do not block any ventilation openings. Install in

accordance with the manufacturer's instructions.

8 Do not install near any heat sources such as

radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9 Do not defeat the safety purpose of the

polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10 Protect the power cord from being walked on or

pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11 Only use attachments/accessories specified by

the manufacturer.

12 Use only with a cart, stand, tripod,

bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13 Unplug this apparatus during lightning storms

or when unused for long periods of time.

14 Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

S3125A

15 The mains plug is the disconnecting device. The

plug must remain readily operable.

16 The apparatus with grounding-type plug is a

class I apparatus. Class I apparatus need to be connected to earth ground wire to prevent possible electric shock. Make sure that you connect the class I apparatus to a mains socket outlet with a protective earthing connection.

17 Remote control batteries should not be exposed

to excessive heat such as sunshine, fire, or the like.

18 The apparatus shall not be exposed to dripping

or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

Warnings

Electric shock hazard

To reduce the risk of fire or electric shock, do not remove any cover or expose the device to rain or moisture. No user-serviceable parts are inside. Refer servicing to qualified service technicians.

Lightning

For added protection for your device receiver during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the power outlet and disconnect any antenna or cable system. This helps prevent property damage and personal injury from lightning and power line surges.

Power lines

An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

Handling the LCD panel

• Your TV’s screen is made of glass. Do not drop your TV or hit, jolt, or press hard against the LCD panel. If the screen breaks, be careful of broken glass.

• If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel. This may cause skin inflammation.

• If the liquid gets in your mouth, immediately gargle, rinse, and consult with your doctor. Also, if the liquid gets in your eyes or touches your skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean water.

Replacement parts

When replacement parts are required, make sure that the service technician uses replacement parts specified by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, personal injury, or other hazards.

Safety check

After completing any service or repair to this device, ask the service technician to perform routine safety checks to determine that your TV is in correct operating condition.

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 3 Tuesday, April 7, 2009 9:29 AM

Power source

Operate your TV only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied to your home, consult an electrician or your local power company.

Cautions

Damage requiring service

Unplug this TV from the power outlet and refer servicing to qualified service personnel under the following conditions:

• When the power supply cord or plug is damaged or frayed.

• If liquid has been spilled or objects have fallen into your TV.

• If your TV has been exposed to rain or water.

• If your TV does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions because incorrect adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore your TV to its normal operation.

• If your TV has been dropped or damaged in any way.

• When your TV exhibits a distinct change in performance.

Outdoor antenna grounding

If an outside antenna or cable system is connected to your TV, make sure that the antenna or cable system is grounded to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to correct grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of the antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

Note to CATV system installer

Article 820 of the National Electrical Code, ANSI/NFPA No. 40 provides guidance for correct grounding. Specifically, it states that the cable ground must be connected to the grounding system of the building as close to the point of cable entry as practical.

Condensation

Moisture will form on the TV if the TV is brought from cool surroundings into a warm room or if the temperature of the room rises suddenly. When this happens, the TV's performance may be impaired. To prevent this, let the TV stand in its new surroundings for about an hour before switching it on, or make sure that the room temperature rises gradually.

Condensation may also form during the summer if the TV is exposed to the breeze from an air conditioner. In such cases, change the location of the TV.

Mobile telephone warning

To avoid interference with your TV picture and sound, operating problems, or even damage, keep your cordless and cellular telephones away from the TV.

End of life directives

Your TV contains tin-lead solder and a fluorescent lamp containing a small amount of mercury. Disposal of these materials may be regulated for environmental reasons. Your TV also contains material that can be recycled and reused. For disposal or recycling information, contact your local authorities or the Electronic Industries Alliance at www.eia.org to find a recycler in your area.

Non-active pixels

The LCD panel contains almost 3 million thin film transistors, which provide exceptionally sharp video quality. Occasionally, a few non-active pixels may appear on the screen as a fixed blue, green, or red point. These non-active pixels do not adversely affect the performance of your TV, and are not considered defects.

Antenna lead-in wire

Grounding clamp

Antenna discharge unit

Grounding conductors

Ground clamps

Power service grounding electrode system

Electric service equipment

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 4 Tuesday, April 7, 2009 9:29 AM

Introduction

Congratulations on your purchase of a high-quality Insignia product. Your NS-L19X-10A represents the state of the art in LCD TV design and is designed for reliable and trouble-free performance.

Installing the stand or wall-mount bracket

Installing the stand

To install the stand:

1 Carefully place your TV screen face-down on a

cushioned, clean surface to protect the screen from damages and scratches.

2 Secure the stand to the screen with the two

included screws.

2 Secure the wall-mount bracket to the back of

your TV using the four M4 screws provided with bracket.

Adjusting the viewing angle

To adjust the viewing angle:

• Adjust the angle forward 5° to back 10°.

-5

Caution

When adjusting the angle, be careful not to tip the TV.

Stand

3 To remove the stand from the TV, perform these

steps in reverse order.

Installing a wall-mount bracket

If you want to attach your TV to a wall-mount bracket (not provided), you must first remove the stand column.

To remove the stand column:

1 Lay your TV face down on a table or bench.

Make sure that you put down a soft cushion or cloth so that your TV does not get scratched.

2 Remove the two screws holding the stand

column to your TV, then remove the stand column.

Note

The appearance of the product in these instructions may differ from your actual product, and is for comparative purposes only.

To attach your TV to a wall-mount bracket:

Warning

These servicing instructions are for use by qualified service personnel only. To reduce the risk of hazards, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so.

Replacing the decorative faceplate

Screws

Replacing the decorative faceplate

To replace the faceplate:

1 Carefully pull the decorative faceplate off your

TV.

1 Remove the stand column.

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 5 Tuesday, April 7, 2009 9:29 AM

2 Align the plastic studs on the new faceplate

with the holes on the front of your TV, then press firmly to install the new decorative faceplate.

TV components

Accessories

Make sure that the following accessories are provided in the packaging:

• Remote control

•Lithium battery

• Decorative faceplates (2) One pre-installed

•User Guide

• Quick Setup Guide

• External radio antenna

•Component cable

Front

Side buttons

# Button Description

CH /CH

VOL .VOL

INPUT

(power)

Press to go to the next or previous channel in the channel list.

Press to decrease or increase the volume.

Press to open the on-screen menu.

Press to open the Input Source menu and select the video input source.

Press to turn your TV on or off (standby mode). When your TV is turned off, power still flows into it. To disconnect all power, unplug the power cord.

# Item Description

Remote control sensor

Power indic ator

Receives signals from the remote control. Do not block.

Lights blue when your TV is on. Lights red when your TV is off (standby mode). When your TV is off, power still flows into it. To disconnect all power, unplug the power cord.

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 6 Tuesday, April 7, 2009 9:29 AM

Back

# Jack Description

Service port for upgrading firmware. Do not use.

Connect the 75 ohm coaxial cable from an FM antenna to this jack.

Connect headphones to this jack. For more information, see “Connecting headphones” on page

12.

Connect the video and audio output from an AV device to this jack. For more information, see “Connecting a camcorder or game” on page 10.

Connect the video and audio output from a component video device to these jacks. For more information, see “Connecting a component video device” on page 10.

12 13

SERVICE PORT

(headphone)

AV2 IN VIDEO/S-VIDEO2

and L/R AUDIO

COMPONENT2 IN Y, Cb/Pb, Cr/Pr and L/R

AUDIO

Remote control

# Jack Description

Connect a digital optical cable to this jack to output a

DIGITAL OUTPUT

HDMI1/HDMI2

VGA AUDIO/VGA PIC

AV1 VIDEO and L /R

AUDIO

COMPONENT1 IN Y, Cb/Pb, Cr/Pr and L/R

AUDIO

AUDIO OUT L/R

RS-232

S-VIDEO1

HDMI 3

digital audio signal to a digital audio amplifier. For more information, see “Connecting a digital sound system” on page 12.

Connect an HDMI device, such as a cable box or DVD player, to this jack. An HDMI cable carries both video and audio, so you do not need to make an audio connection. For more information, see “Connecting an HDMI device” on page 10.

Connect the audio and video outputs from your computer to these jacks. For more information, see “Connecting a computer” on page 11.

Connect the video and audio output from an AV device to this jack. For more information, see “Connecting a VCR” on page 9.

Connect the video and audio output from a component vide o device to these jacks. For more information, see “Connecting a component video device” on page 10.

Connect these jacks to an external audio amplifier to hear your TV sound through a stereo amplifier. For more information, see “Connecting an audio amplifier” on page 11.

Connect an antenna, ca ble TV, or cable/sate llite box output cable to this jack. For more information, see “Connecting an antenna, cable TV, or satellite TV box” on page 9.

For service only. Do not use.

Connect the S-Video output from a video device such as a DVD player, camcorder, or game console to this jack. For more information, see “Connecting a VCR’ on page 9.

# Button Description

ZOOM

COMP

HDMI

Numbers

VOL +/VOL –

(power)

Press to turn your TV on or off (standby mode). When your TV is turned off, power still flows into it. To disconnect all power, unplug the power cord.

Press to select the aspect ratio of the picture. You can select Norma l, Zoom, Wide, Cinema, or Auto Zoom. For more information, see “Adjusting the TV picture” on page 16.

Press to select a component input source. Press once for Component 1. Press twice for Component 2.

Press to select an HDMI input source. Press once for

HDMI 1. Press twice for HDMI 2. Press three times for HDMI 3.

Press to directly enter channel or FM radio frequency numbers, or to enter the Parental Control password.

Press to increase or decrease the volume.

22 23

www.insigniaproducts.com



NS-L19X-10A_09-0241_MAN_V2_English.book Page 7 Tuesday, April 7, 2009 9:29 AM

# Button Description

Press to confirm selections i n an on-screen menu, or to open a submenu.

Press to navigate within the on-screen menus. For more information, see “Navigating the menus” on page 14.

Press to open the on-screen menus. For more information, see “Navigating the menus” on page 14.

Press to set the sleep timer. For more information, see “Setting the sleep timer” on page 27.

Press to select the audio mode. For analog channels, you can selec t STEREO, SAP (secondary audio program), or MO NO.

For digital channels, you can select the audio track (if more than one track is available). For more information, see “Selecting the audio mode” on page 18.

Press to switch to FM radio mode. For more information, see “Switching to FM mode” on page 29.

Press to display the information banner.

Press to select TV mode.

Press to select an video input source. Press once for

AV1. Press twice for AV2. Press three times for S-VIDEO1. Press four times for S-VIDEO2.

Press to turn off the sound. Press again to restore the sound.

Press to display program guide information (if available) for DTV broadcasts.

Press to enter a program number for a digital sub-channel. For more information, see “Digital sub-channels” on page 15.

Press to return to the last channel viewed.

Press to display your favorite channel list. For more information, see “Setting up a favorite channel list” on page 20.

Press to display the input source menu. For more information, see “Selecting the video input source” on page 13.

Press to turn on closed captioning. For more information, see “Turning closed captioning on or off” on page 25.

Press to exit the on-screen menu.

Press to select the picture mode. For more information, see “Adjusting the TV picture” on page 16.

Press to select the audio mode. For more information, see “Selecting the audio mode” on page 18.

ENTER

SLEEP

MTS/SAP

INFO

VIDEO

MUTE

GUIDE

(dot)

RECALL

FAVOR ITE

INPUT

CCD

EXIT


AUDIO

Using the remote control

Installing the remote control battery

To install the remote control battery:

1 Remove the battery holder from the bottom of

the remote control.

2 Insert a lithium battery into the battery holder.

Make sure that (+) symbol on the battery facing up.

3 Reinsert the battery holder into the bottom of

the remote control.

Cautions

• Batteries should not be exposed to excessive heat, such as sunshine, heat registers, or fire.

• Battery chemicals can cause a rash. If the battery leaks, clean the battery holder with a cloth. If chemicals touch your skin, wash immediately.

• Make sure that batteries are disposed of correctly. Do not burn or incinerate.

Notes

• Remove the battery when the charge is depleted.

• If the remote control is not going to be used for an extended period of time, remove the battery.

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 8 Tuesday, April 7, 2009 9:29 AM

Aiming the remote control

To aim the remote control:

• Point the remote control toward the remote control sensor on the front of your TV.

16.4 ft (5 m)

Programming a universal remote control to work with your TV

You can operate your Insignia TV with a new or existing universal remote control.

To program a universal remote control:

1 Find the code for your universal remote control

by identifying its model (or your set-top box’s remote control manufacturer and model) on the charts below, then making note of the numbered code below it. You will use the numbered code to program your remote control to work with your Insignia TV.

Insignia TV codes for universal remote controls

(for all Insignia TVs manufactured after Jan. 1, 2007)

Universal remote control manufacturers and models

Philips PHDVD5,

PH5DSS,

PMDVR8, PDVR8

115 135 0464 8043

Comcast

M1057

0463 720 0463 0091 10463

RCA

RCU807

One for All URC-6690

Sony

RM-VL600

Set-top box manufacturers and models

Dish Network

VIP508, VIP622

Motorola

DRC800

TIVO

Series 3, HD

DirectTV

RC23

Notes

• Do not expose the remote control to shock.

• Do not expose the remote control to liquids and do not use the remote control in an area with high humidity.

• Do not place the remote control in areas of high heat or direct sunlight. The heat may warp the battery case.

• The remote control may not work correctly if sunlight or bright light is shining on the remote control sensor. To correct this problem, move your TV or use the remote control closed to the remote control sensor.

Storing the remote control

Your TV has a storage slot for storing the remote control when it is not being used.

To store the remote control:

• Slide the remote control into the storage slot of the side of your TV.

Codes for other remote controls are available online at: www.insigniaproducts.com/ universalcontrolcodes.aspx

Tips

• The brand name is often visible on the front of the universal remote control, and the model number is often visible on the back.

• If your universal remote control isn’t listed on the chart, refer to your universal remote control’s instructions and try codes for the brands Orion, Emerson, Memorex, Sansui, Sylvania, or Zenith. You may need to try several codes before finding a match.

2 Follow your universal remote control’s

instructions to enter the TV code you found in Step 1.

Tips

• If your universal remote control has a code search feature, run a code search to identify a code that matches your T V. See your universal remote control’s instructions for details.

• If your universal remote control has a “Learn” feature, you can manually program it using the Insignia TV remote to “teach” the commands one at a time. See your universal remote control’s instructions for details.

3 If all else fails, you must use a different universal

remote control that can operate both your set-top box and your TV. Five such remotes are listed on the chart, but many other compatible models are available in the market.

For more help, call technical support for your universal remote control or set-top box manufacturer, or call the Insignia Customer Care Center at 1-877-467-4289.

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 9 Tuesday, April 7, 2009 9:29 AM

Making connections

Cautions

• Check the terminals for position and type before making any connections.

• Loose connections can result in image or color problems. Make sure that all connections are tight and secure.

• The external audio/video equipment shown in these illustrations may be different from your equipment. If you have questions, refer to the user manual that came with your equipment.

• Always turn the power off when connecting external equipment.

Connecting the power

To connect the power:

• Plug the AC cord into an AC power outlet.

Notes

• Your TV should only be operated from the power source indicated on the label.

• Always unplug the AC power cord from the AC power outlet when you will not be using your TV for an extended period of time.

Connecting an antenna, cable TV, or satellite TV box

Connecting a VCR

To connect a VCR:

1 Make sure that your TV’s power cord is

unplugged and the VCR is turned off. Connect an AV cable to the AV VIDEO OUT jack

on the VCR. For a better picture, you can connect an S-Video cable to the S-VIDEO OUT jack instead of the AV VIDEO OUT jack.

Back of TV

AV1 I N VID EO a nd AUDIO-L and AUDIO-R jacks

AV ca ble

VCR

Note: Cables are often color-cod ed to connectors. Connec t yellow to yellow, red to red, and white to white.

VCR

To connect an antenna, cable TV, or satellite TV box:

1 Connect one end of a 75 ohm cable (not

included) to the RF OUT jack on the antenna or on the cable or satellite TV box.

RF jack

Back of TV

Antenna, cable TV, or satellite RF jack

RF coaxial cable (75 ohm)

2 Connect the other end of the cable to the RF

jack on the back of your TV.

Notes

• Use a 75 ohm cable to eliminate interference and noise from radio waves.

• Do not bundle the 75 ohm cable with the power cord or other cables.

• If the antenna is not installed correctly, contact qualified service personnel to correct the problem.

Back of TV

S-Video cable

Audio cable

S-VIDEO1 IN jack

2 Connect the other end of the cable to the AV1

IN VIDEO jack on the back of your TV. For a

better picture, you can connect an S-Video cable to the S-VIDEO 1 jack instead of using an AV cable with the AV1 IN VIDEO jack.

3 Connect an audio cable to the AV AUDIO OUT

jacks on the VCR.

4 Connect the other end of the cable to the AV1

IN AUDIO-L and AUDIO-R jacks on the back of

your TV.

To play from the VCR:

1 Turn on your TV, then press INPUT. The INPUT

SOURCE menu opens.

2 Press or to select AV1 or S-VIDEO 1, then

press ENTER.

Note

You ca n als o p res s VIDEO once for AV 1 or three time s for S-VIDEO 1.

3 Turn on the VCR, insert a videotape, then press

www.insigniaproducts.com

PLAY on the VCR.

NS-L19X-10A_09-0241_MAN_V2_English.book Page 10 Tuesday, April 7, 2009 9:29 AM

Connecting a camcorder or game

Tip

Some game consoles have an HDMI connector, which can be used for a better picture.

To connect a camcorder or game:

1 Make sure that your TV’s power cord is

unplugged and the camcorder or game is turned off.

2 Connect an AV cable to the AV OUT VIDE O,

AUDIO-L, and AUDIO-R jacks on the camcorder

or game.

Camcorder or game

Note: Cables are often color-c oded to connec tors. Connect yellow to yellow, red to red, and white to white.

AV ca ble

Side of TV

2 Connect an HDMI cable to the HDMI OUT jack

on the HDMI device.

Device with HDMI output

Back of TV

HDMI 1 jack

HDMI cable

3 Connect the other end of the cable to the

HDMI 1 or HDMI 2 jack on the back of your TV

(you can also use the HDMI3 jack on the side of your TV.

To play from the HDMI device:

1 Turn on your TV, then press INPUT. The INPUT

SOURCE menu opens.

2 Press or to select HDMI1, HDMI2, or

HDMI3, then press ENTER.

3 Connect the other end of the cable to the AV2

IN VIDEO, AUDI O-L, and AUDIO-R jacks on the

side of your TV.

To play from a camcorder or game:

1 Turn on your TV, then press INPUT. The INPUT

SOURCE menu opens.

2 Press or to select AV2, then press ENTER.

Tip

You can also press VIDEO twice for AV 2.

3 Turn on the camcorder or game, and set it to the

correct output mode. See the camcorder’s or game’s user guides for more information.

Connecting an HDMI device

To connect an HDMI device:

1 Make sure that your TV’s power cord is

unplugged and the HDMI device is turned off.

Tip

You can also press HDMI repeatedly for HDMI.

3 Turn on the HDMI device, and set it to the

correct output mode. See the HDMI device’s user guide for more information.

Note

If the external device has DVI output only, use a DVI-to-HDMI adapter to connect to the HDMI jack, then connect an audio cable to the VGA AUDIO jack.

Connecting a component video device

To connect a component video device:

1 Make sure that your TV’s power cord is

unplugged and the component video device is turned off.

2 Connect a component video cable to the

COMPONENT OUT jacks on the component

video device.

Component video device

Audio cable

Back of TV

Component video cables

Note: Cables are often color-cod ed to connectors.

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 11 Tuesday, April 7, 2009 9:29 AM

3 Connect the other end of the component video

cable to the COMPONENT1 IN jacks on the back of your TV (you can also use the

COMPONENT2 IN jacks on the side of your TV).

4 Connect an audio cable to the AUDIO OUT jacks

(L/R) on the component device.

5 Connect the other end of the audio cable to the

COMPONENT AUDIO-R and AUDIO-L jacks on

the back of your TV.

To play from a component device:

1 Turn on your TV, then press INPUT. The INPUT

SOURCE menu opens.

2 Press or to select Component 1 or

Component 2, then press ENTER.

Tip

You can also press COMP repeatedly for Component 1 or Component 2.

3 Turn on the component video device and set it

to the correct output mode. See the component video device’s user guide for more information.

Connecting a computer

Tip

Some computers have an HDMI connector, which can be used for a better picture.

To play video from a computer:

1 Turn on your TV, then press INPUT. The INPUT

SOURCE menu opens.

2 Press or to select VGA, then press ENTER. 3 Turn on the computer, then adjust the display

properties, if necessary.

Connecting an audio amplifier

To connect an audio amplifier:

1 Make sure that your TV’s power cord is

unplugged and the amplifier is turned off.

2 Connect an audio cable to the AUDIO OUT jacks

(L/R) on your TV.

Amplifier



Back of TV

Audio cable

To connect a computer:

1 Make sure that your TV’s power cord is

unplugged and the computer is turned off.

2 Connect a VGA cable to the VGA jack on the

computer, then connect the other end of the cable to the VGA PIC jack on the back of your TV.

Note

The VGA cable should be a 15-pin D-Sub (analog RGB) cable.

Computer

Back of TV

Audio cable (stereo mini plugs)

VGA cable (analog RGB)

Note: Cables are often color-coded to connectors. Connect red to red and white to white.

3 Connect the other end of the cable to the audio

input jacks (L/R) on your amplifier.

To play the TV sound through an audio amplifier:

1 Turn on your TV and select a program to watch. 2 Turn on your amplifier, select the TV sound

source, then adjust the volume to a comfortable level.

3 Connect an audio cable to the AUDIO OUT jack

on the computer, then connect the other end of the cable to the VGA AUDIO jack on the back of your TV.

Note

The audio cable should have a stereo mini plug.

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 12 Tuesday, April 7, 2009 9:29 AM

Connecting a digital sound system

To connect a digital sound system:

1 Make sure that your TV’s power cord is

unplugged and the digital sound system is turned off.

2 Connect a digital optical audio cable to the

S/PDIF IN jack on the digital sound system.

Digital sound system

Back of TV

Digital output jack

3 Connect the other end of the cable to the

DIGITAL OUTPUT jack on the back of your TV.

Note

The DIGITAL OUTPUT jack works with digital TV channels only.

Connecting headphones



Optical audio cable

Connecting an FM radio antenna

To connect an FM radio antenna

• Connect the FM antenna (provided) to the FM antenna jack on the side of your TV.

Side of TV

FM antenna

Notes

For best reception, fully extend the FM antenna. Keep the FM antenna as horizontal as possible. If FM reception is poor in your area, us an outdoor FM

antenna (not provided) and connect it to your TV with 75 ohm coaxial cable (not provided).

To listen to FM radio:

1 Turn on your TV, then press INPUT. The INPUT

SOURCE menu opens.

2 Press or to select FM, then press ENTER.

Tip

You can also press FM on the remote control.

To connect headphones:

• Connect the headphones to the headphone jack on the side of your TV.

Side of TV

Note

Loud noise can damage your hearing. When using headphones, use the lowest volume setting that still lets you hear the sound.

Turning on your TV for the first time

Before you use your TV the first time, make sure to remove the protection film from the back cabinet, otherwise the ventilation openings will be blocked, which may cause overheating and other serious problems.

To config u r e your T V:

1 Make sure that you have inserted the battery in

the remote control, connected the antenna to the TV, and connect the AC power.

2 Press (Power), then wait several seconds. The

initial setup screen opens (only the first time you turn on your TV).

Choose your menu language

English

Français

Español

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 13 Tuesday, April 7, 2009 9:29 AM

3 Press or to select the menu language you

want, then press ENTER. The Choose your TV source screen opens.

4 Press or to select Antenna, Cable, or

Cable/Satellite Box, depending on the type of

connection you have:

• If you are using an antenna for a standard or HD TV signal, select Antenna.

• If your cable is connected directly to the TV (using no tuner box), select Cable.

• If your cable is connected to your TV through a tuner box, select Cable/Satellite Box.

5 Press ENTER when you have selected.

If you selected Antenna or Cable, the TV searches automatically for available channels in your area and stores the channel information in the channel list. This may take several minutes. While searching, the TV displays a progress report.

- OR -

If you selected Cable/Satellite Box, the auto channel search is not necessary.

Note

You can press EXIT to stop the auto channel search, but you will need to run the auto channel search again to create a channel list.

6 Select the corresponding video input source

through the Input Source menu.

Understanding the basics

Turning your TV on or off

Selecting the video input source

To select the video input source:

1 Turn on your TV, then press the INPUT key on

the remote, or the INPUT button on the TV. The

INPUT SOURCE menu opens.

Input Source

V 1

AV 2

S-Video 1

S-Video 2 Component 1 Component 2

VGA HDMI 1 HDMI 2 HDMI 3

2 Press or to highlight the video source, then

press ENTER. You can also select the input source using the

following remote control buttons:

• COMP—Press once to select Component 1. Press twice to select Component 2.

• HDMI–Press once to select HDMI 1. Press twice to select HDMI 2. Press three times to select HDMI 3.

• VIDEO—Press once to select AV1. Press twice to select AV2 . Press three times to select

S-Video 1. Press four times to select S-Video 2.

• TV—Press to select TV.

• FM—Press to select FM radio.

On-screen menu overview

Picture menu (TV mode)

To turn your TV on or off (standby mode):

1 Plug the power cord into an AC power outlet. 2 Press (power). Your TV turns on. 3 Press again to turn off your TV. When you

turn off your TV, it goes into standby mode.

Warning

When your TV is in standby mode, it is still receiving power. To completely disconnect power, unplug the power cord.

Note

If your TV does not receive an input signal for several minutes, it automatically goes into standby mode.

www.insigniaproducts.com

PICTURE AUDIO CHANNELS SETTINGS


Mode

Brightness

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect picture quality

RADIO

Standard

-16

EXIT

NS-L19X-10A_09-0241_MAN_V2_English.book Page 14 Tuesday, April 7, 2009 9:29 AM

Audio menu (TV mode, equalizer on)

PICTURE AUDIO CHANNELS SETTINGS

Audio

Equalizer

Equalizer Mode

Equalizer Setting

Balance

Digital Audio/SPDIF

MTS/SAP

MOVE SELECT PREVIOUS EXIT

Adjust settings to affect sound quality

ENTER

Custom

Audio menu (TV mode, equalizer off)

PICTURE AUDIO CHANNELS SETTINGS

Audio

Equalizer

Mode

Treble

Bass

Balance

Digital Audio/SPDIF

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect sound quality

Custom

Channels menu (TV mode)

RA W

Mono

EXIT

RA W

EXIT

Off

RADIO

Radio menu (FM mode)

PICTURE AUDIO CHANNELS SETTINGS

Radio

Available Stations

Frequency

Fine Tune

Auto Search

Audio Only

MOVE SELECT PREVIOUS EXIT

ENTER

Play FM Radio on your TV

Notes

• Depending on the signal source selected, you may see different options on your screen. The above menus are shown in TV mode (except the Radio menu).

• Menu items that are not selectable are grayed out. Menus in this manual are described in T V mode, unless otherwise indicated.

• The illustrations and screens shown in the manual are for explanation purposes and may vary from the actual screens on your TV.

Navigating the menus

105.15

Press to display the main menu.

RADIO

MHz

EXIT

PICTURE AUDIO CHANNELS SETTINGS

Channels

Auto Channel Search

Add/Skip Channels

Favorites

Channel Labels

Channel Strength

Audio Only

MOVE SELECT PREVIOUS EXIT

Adjust channel options

ENTER

Settings menu (TV mode)

PICTURE AUDIO CHANNELS SETTINGS

Settings

Parental Controls Closed Caption Time

Menu Settings

Input Labels

Input Sensor

MOVE SELECT PREVIOUS EXIT

Set various TV options

ENTER

RADIO

Press right or left arrow key to move the curs or on the screen or adjust a selected item. Press the right arrow key to open s ub-menus.

Off

EXIT

Press to select menu items.

RADIO

Press to confirm your selection or enter a sub-menu.

Press to return to the previous screen.

Off

EXIT

Press to close the menu.

Selecting a channel

To select a channel:

• Press CH+ or CH– to go to the next or previous channel on the memorized channel list.

• Press the number buttons to enter the analog or digital (main) channel number you want, then wait for the channel to change, or press ENTER to change the channel immediately.

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 15 Tuesday, April 7, 2009 9:29 AM

• To select a digital sub-channel, press the number buttons to select the main digital channel, then press the dot (.) button to select the sub-channel. Wait for the channel to change, or press ENTER to change the channel immediately.

Note

Button presses must be within three seconds of each other.

• Press RECALL to go to the last channel viewed.

• Press FAVO RI TE to display a list of your saved favorite channels, press or to select the channel you want from the list, then press ENTER to go to that channel.

Note

If the list has more than one page, press or to scroll through the pages.

Digital sub-channels

A digital TV signal transmits more data than an analog signal. This increase in data provides a better picture and sound with less static and interference. The increased data capacity also lets broadcasters fit several channels into the same bandwidth as an analog signal. Broadcasters may use these sub-channels to transmit a variety of information, such as weather forecasts, foreign languages, and commercials. A digital sub-channel is indicated by the main channel number, followed by a dot, then the sub-channel number. For example, 5.1 indicates sub-channel 1 of main channel 5.

Adjusting the volume

To adjust the volume:

• Press VOL+ or VOL– to increase or decrease the volume.

• Press MUTE to temporarily turn off all sound. Press MUTE again to restore the sound.

Adjusting basic settings

To adjust basic settings:

1 Press MENU. The on-screen menu opens with

the Picture menu displayed.

PICTURE AUDIO CHANNELS SETTINGS


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

ENTER

MOVE SELECT PREVIOUS EXIT

Adjust settings to affect picture quality

2 Press or to highlight Settings, then press

or ENTER. The Settings menu opens.

PICTURE AUDIO CHANNELS SETTINGS

Settings

Parental Controls

Closed Caption

Time

Menu Settings

Input Labels

Input Sensor Off

MOVE SELECT PREVIOUS EXIT

ENTER

Set TV parental controls

RADIO

EXIT

3 Press or to highlight an option, press

ENTER to access the option, then press or

to adjust the option or press or to select the setting. You can select:

• Parental Controls—Lets you control which programs/movies your children can watch, based on industry ratings. See “Setting parental controls” on page 22.

• Closed Caption—Lets you turn closed captioning on or off. Also lets you set closed caption options. See “Using closed captioning” on page 25.

• Time—Lets you set the clock and the sleep timer. See “Setting the date and time” on page 27 and “Setting the sleep timer” on page 27.

• Menu Settings—Lets you set menu language and menu transparency.

• Input Labels—Lets you label a device connected to your TV’s input jacks. See “Labeling an input source” on page 28.

• Input Sensor—Lets you set the input sensor to automatically detect devices connected to the ports on the back and side of your TV. See “Setting the input sensor” on page 29.

• Computer Settings—(PC mode only) Lets you adjust picture settings to optimize a computer display. See “Adjusting the computer image” on page 17.

• Component Settings—(Component mode only) Lets you set options for a device connected to your TV with component cables. See “Adjusting component settings” on page

RADIO

17.

• Reset to Default—Lets you reset most TV settings for the current source to factory default values.

-16

EXIT

Displaying additional information

4 Press MENU to return to the previous menu, or

press EXIT to close the menu.

To display additional information:

1 Press INFO to show an information banner. The

information banner shows current program information such as channel number, video input source, and resolution.

• Digital mode information—Displays channel number, station name, channel label, broadcast program name, TV rating, signal type, audio information, resolution, CC mode, current time, and current program start and end times.

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 16 Tuesday, April 7, 2009 9:29 AM

• Analog mode information—Displays channel number, channel label (if preset), signal type, audio information, and resolution.

2 Press GUIDE to show the digital program guide,

which may show a list of available programs, program times, and program summaries, depending on the information provided by the broadcaster.

Adjusting the picture

Adjusting the TV picture

To adjust the picture:

1 Press MENU. The on-screen menu opens with

the Picture menu displayed, then press ENTER or to access.

PICTURE AUDIO CHANNELS SETTINGS


Mode

Brightness

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect picture quality

Scroll down to additional settings

Standard

-16

EXIT

RADIO

• Advanced Video—Lets you adjust the Aspect Ratio, OverScan, Color Temperature, Backlight, Noise Reduction and Advanced Contrast. See “Adjusting Advanced Video settings” on page

16.

• Reset Picture Settings—Reset all picture settings to factory default.

3 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Adjusting Advanced Video settings

To adjust the Advanced Video settings:

1 Press MENU. The on-screen menu opens with

the Picture menu displayed, then press ENTER or to access.

2 Press or to highlight Advanced Video, then

press ENTER. The Advanced Video submenu opens.

PICTURE AUDIO CHANNELS SETTINGS


• Advanced Video

Aspect Ratio

OverScan

Color Temperature Backlight

Noise Reduction Advanced Contrast

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust how the picture fills the screen

RADIO

Normal

Off

Cool

Low

EXIT

PICTURE AUDIO CHANNELS SETTINGS


Contrast

Color

Tint

Sharpness

Advanced Video Reset Picture Settings

ENTER

MOVE SELECT PREVIOUS EXIT

Adjust the white level of the picture.

EXIT

2 Press or to highlight an option, press

ENTER to access the option, then press or

to adjust the option or press or to select the setting. You can select:

• Mode—Selects the picture mode. You can select Vivid (a bright and vivid picture),

Standard (a standard picture), Energy Savings (the backlight brightness is decreased), Theater (a finely detailed picture), Sports (a dynamic picture), or Custom

(customized picture). You can also press PICTURE on the remote control to select the picture mode.

• Brightness—Adjusts the brightness.

• Contrast—Adjusts the contrast.

• Color—Adjusts the color saturation.

• Tint—Adjusts the image tint.

• Sharpness—Adjusts the sharpness.

-16

RADIO

3 Press or to highlight an option, press

ENTER to access the option, then press or

to adjust the option or press or to select the setting. You can select:

• Aspect Ratio - Selects the aspect ratio of the picture. You can select Normal (selects the correct aspect ratio to match the source image), Wide (shows a full-screen picture), Zoom (enlarges the picture but may crop the top and bottom), Cinema (stretches the picture at the edges, but maintains a good aspect ratio at the center of the screen), or Auto Zoom (selects the correct aspect ratio automatically) if Auto Zoom in the Channels menu is set to ON. When Auto Zoom in the

Channels menu is set to OFF, only Normal, Wide, Zoom, or Cinema can be selected.

• Overscan—Turn t his On to adjust the picture’s reproduction rate when receiving HDMI/DVI signals in VIDEO format.

• Color Te mp e ra tu r e—Selects the color temperature. You can select Cool (to enhance the blues), Normal, or Warm (to enhance the reds).

• Backlight—Sets the overall brilliance of the screen.

• Noise Reduction—Selects the noise reduction mode to reduce picture noise (snow). You can select Low, Middle

, High, or

Off.

• Advanced Contrast—Select Adaptive Contrast to automatically adjust the picture detail and brightness, or Dynamic Contrast Ratio to enhance the contrast ratio between light and dark areas of the picture.

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 17 Tuesday, April 7, 2009 9:29 AM

4 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Adjusting the computer image

To adjust the computer image:

1 Make sure that your TV is in VGA mode. For

more information, see “Selecting the video input source” on page 13.

2 Press MENU. The on-screen menu opens.

PICTURE AUDIO CHANNELS SETTINGS


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

Adjust settings to affect picture quality

ENTER

3 Press or to highlight Settings, then press

or ENTER. The Settings menu opens.

• Phase—Adjusts the focus of stable images

• Reset Computer Settings—Resets computer settings to factory default.

6 Press MENU to return to the previous menu, or

press EXIT to close the menu.

Adjusting component settings

To adjust component settings:

1 Make sure that your TV is in Component mode.

For more information, see “Selecting the video input source” on page 13.

RADIO

-16

EXIT

2 Press MENU. The on-screen menu opens.

PICTURE AUDIO CHANNELS SETTINGS


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect picture quality

EXIT

RADIO

-16

PICTURE AUDIO CHANNELS SETTINGS

RADIO

Settings

Menu Settings

Input Labels

Input Sensor

Computer Settings

Component Settings

Reset to Default

MOVE SELECT PREVIOUS EXIT

ENTER

Set options for when a computer is connected to the TV

Off

EXIT

4 Press or to highlight Computer Settings,

then press ENTER. The Settings - Computer Settings menu opens.

PICTURE AUDIO CHANNELS SETTINGS

Settings •

Auto Adjust

H. Position

V. Position

Clock

Phase

Reset Computer Settings

Adjust to the PC signal timing automatically when On

Computer Settings

MOVE SELECT PREVIOUS EXIT

ENTER

RADIO

EXIT

5 Press or to highlight an option, press

ENTER to access the option, then press or

to adjust the option or press or to select the setting. You can adjust:

• Auto Adjust—Automatically adjusts the image settings such as position and phase

• H.Position—Moves the image right or left

• V. Pos it io n —Moves the image up or down

• Clock—Adjusts the sample frequency

3 Press or to highlight Settings, then press

or ENTER. The Settings menu opens.

4 Press or to highlight Component Settings,

then press ENTER. The Settings - Component Settings menu opens.

PICTURE AUDIO CHANNELS SETTINGS

Settings •

Phase

Reset Component Settings

Minimizes horizontal distortion

Component Settings

MOVE SELECT PREVIOUS EXIT

ENTER

RADIO

EXIT

5 Press or to highlight an option, press

ENTER to access the option, then press or

to adjust the option or press or to select the setting. You can adjust:

• Phase—Adjusts the phase to minimize horizontal distortion.

• Reset Component Settings—Resets component settings to factory default.

6 Press MENU to return to the previous menu, or

press EXIT to close the menu.

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 18 Tuesday, April 7, 2009 9:29 AM

Adjusting the sound

To adjust the sound:

1 Press MENU. The on-screen menu opens.

PICTURE AUDIO CHANNELS SETTINGS


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect picture quality

2 Press or to highlight Audio, then press or

ENTER. The Audio menu opens.

Audio Menu (Equalizer On)

Audio

Equalizer

Equalizer Mode

Equalizer Setting

Balance

Digital Audio/SPDIF

MTS/SAP

MOVE SELECT PREVIOUS EXIT

Adjust settings to affect sound quality

ENTER

Audio Menu (Equalizer Off )

Audio

Equalizer

Mode

Treble

Bass

Balance

Digital Audio/SPDIF

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect sound quality

3 Press or to highlight an option, press

ENTER to access the option, then press or

to adjust the option or press or to select the setting. You can adjust:

• Equalizer—Select Off for normal frequency response or On for optimized frequency response.

• Equalizer Mode—(Available when Equalizer is On) Selects the sound mode. You can select

Custom (for a customized sound mode), Standard (for normal programs), Theater (for

enhanced treble and base), Music (for musical programs), or News (for news programs). You can also press AUDIO one or more times to select the equalizer mode.

PICTURE AUDIO CHANNELS SETTINGS

-16

EXIT

Custom

RA W

Mono

EXIT

Custom

RA W

EXIT

Off

RADIO

• Equalizer Setting—(Available when the Equalizer is On) Select to make custom audio settings.

• Treble—(Available when the Equalizer is Off) Adjusts the high sounds.

• Bass—(Available when the Equalizer is Off) Adjusts the low sounds.

• Balance—Adjusts the balance between the left and right audio channels.

• Digital Audio/SPDIF—Sends digital audio to an external audio system. Options are RAW (to pass through the original digital audio sound), or PCM (to send 2-channel stereo audio).

• MTS/SAP—(Analog programs only) Lets you select an alternate to the program’s main audio. See “Selecting the audio mode” on page 18.

• Audio Language—(DTV channels only) Selects an alternate audio language, if available.

• Auto Volume—Equalizes the overall volume levels for all channels.

• Reset Audio Settings—Resets all audio settings to factory default.

Press MENU to return to the previous menu, or press EXIT to close the menu.

Selecting the audio mode

You can select the audio mode for analog channels.

To select the audio mode for analog channels:

• See “Adjusting the sound” on page 18 to make settings through the on-screen menu.

- OR -

• Press MTS/SAP on the remote one or more times. You can select:

• MONO—Select this option if there is noise or static on weak stereo broadcasts.

• STEREO—Select this option for programs broadcast in stereo.

• SAP—Select this option to listen to a secondary audio program, if available.

Note

Mono is automatically selected if the program is broadcast in mono.

To select an audio track for a digital channel:

• Press MTS/SAP. If an audio track is available, it plays.

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 19 Tuesday, April 7, 2009 9:29 AM

Playing TV audio only

You can turn off the picture on your TV and listen to only the program audio.

To play only the TV audio:

1 Press MENU. The on-screen menu opens.

PICTURE AUDIO CHANNELS SETTINGS


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

Adjust settings to affect picture quality

ENTER

2 Press or to highlight Channels, then press

or ENTER. The Channels menu opens.

PICTURE AUDIO CHANNELS SETTINGS

Channels

Add/Skip Channels

Favorites

Channel Labels

Channel Strength

Audio Only

Auto Zoom

MOVE SELECT PREVIOUS EXIT

Play the audio with the picture turned off.

ENTER

Off

Changing channel settings

Automatically scanning for channels

To auto scan for channels:

1 Press MENU. The on-screen menu opens.

RADIO


Mode Standard

-16

EXIT

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

Adjust settings to affect picture quality

2 Press or to highlight CHANNELS, then

press or ENTER. The Channels menu opens.

RADIO

Channels

Auto Channel Search

Add/Skip Channels

Favorites

Off

EXIT

Channel Labels

Channel Strength

Audio Only On

MOVE SELECT PREVIOUS EXIT

Manually add and skip channels in your program list

Automatically search for channels.

PICTURE AUDIO CHANNELS SETTINGS

ENTER

PICTURE AUDIO CHANNELS SETTINGS

ENTER

RADIO

-16

EXIT

RADIO

EXIT

3 Press or to highlight Audio Only, then

press ENTER.

4 Press or to select On. 5 Press EXIT to close the menu.

Notes

• Audio Only works only when the input source is TV and your TV is receiving a broadcast signal.

• To exit Audio Only mode, press any button. When you exit Audio Only mode, the Audio Only option is automatically reset to Off.

3 Press or to highlight Auto Channel Search,

then press ENTER. The Channels - Auto Channel Search menu opens.

PICTURE AUDIO CHANNELS SETTINGS

Channels

• Auto Channel Search

Choose your TV source

Antenna

Cable

Cable/Satellite Box

MOVE SELECT PREVIOUS EXIT

ENTER

Select Antenna if using an antenna for standard or HD TV

Analog Channels

Digital Channels

RADIO

EXIT

4 Press or to select Antenna, Cable, or

Cable/Satellite Box, depending on the type of

connection you have:

• If you are using an antenna for a standard or HD TV signal, select Antenna.

• If your cable is connected directly to the TV (using no tuner box), select Cable.

• If your cable is connected to your TV through a tuner box, select Cable/Satellite Box.

5 Press ENTER when you have selected.

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 20 Tuesday, April 7, 2009 9:29 AM

- OR If you selected Cable/Satellite Box, the auto

channel search is not necessary.

Note

You can press EXIT to stop the auto channel search, but you will need to run the auto channel search again to create a channel list.

Adding or skipping channels

You can manually add or skip channels in the channels list so that your TV skips the channels when you press CH+/CH–. You can still tune to the hidden channels by using the number buttons.

To add or skip a channel:

1 Press MENU. The on-screen menu opens.

PICTURE AUDIO CHANNELS SETTINGS


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect picture quality

3 Press or to highlight Add/Skip Channels,

then press ENTER. The Channels - Add/Skip Channels menu opens.

PICTURE AUDIO CHANNELS SETTINGS

Channels • Add/Skip Channels

Ch 1.2 Sencore

Ch 2.1 WGBH-SD

Ch 2.10 WGBH-DX

Ch 6.0

Ch 12.0

MOVE SELECT PREVIOUS EXIT

Manually add and skip channels in your program list

ENTER

Ch 2.0

Ch 2.2 PBS-HD

Ch 4.0

Ch 7.0

Ch 14.0

RADIO

EXIT

4 Press , , , or to highlight the channel you

want to add or skip (the default is to show the channel), then press ENTER to add or remove the check mark from the channel.

Note

If the list has more than one page, press or to

RADIO

scroll through the pages.

5 Press EXIT to close the menu.

-16

EXIT

Setting up a favorite channel list

You can create a favorite channel list so you can quickly browse through your favorite channels by pressing FAVO RI TE, then selecting a channel from the favorite channel list.

To set up the favorite channel list:

1 Press MENU. The on-screen menu opens.

2 Press or to highlight CHANNELS, then

press or ENTER. The Channels menu opens.

PICTURE AUDIO CHANNELS SETTINGS

Channels

Auto Channel Search

Add/Skip Channels

Favorites

Channel Labels

Channel Strength

Audio Only On

MOVE SELECT

Manually add and skip channels in your program list

ENTER

EXIT

RADIO

PICTURE AUDIO CHANNELS SETTINGS


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect picture quality

-16

EXIT

2 Press or to highlight CHANNELS, then

press or ENTER. The Channels menu opens.

PICTURE AUDIO CHANNELS SETTINGS

Channels

Auto Channel Search

Add/Skip Channels

Favorites

Channel Labels

Channel Strength

Audio Only On

MOVE SELECT PREVIOUS EXIT

ENTER

Add channels to create a favorite list

EXIT

RADIO

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 21 Tuesday, April 7, 2009 9:29 AM

3 Press or to highlight Favorites, then press

ENTER. The Channels - Favorites menu opens.

PICTURE AUDIO CHANNELS SETTINGS

Channels • Favorites

Ch 1.2 Sencore

Ch 2.1 WGBH-SD

Ch 2.10 WGBH-DX

Ch 6.0

Ch 12.0

MOVE SELECT PREVIOUS EXIT

ENTER

Add channels to create a favorite list

Ch 2.0

Ch 2.2 PBS-HD

Ch 4.0

Ch 7.0

Ch 14.0

4 Press , , or to highlight the channel you

want to add to your Favorites list, then press ENTER. To remove the channel from your Favorites list, remove the checkmark.

Note

If the list has more than one page, press or to scroll through the pages.

5 Press EXIT to close the menu. 6 To select a channel in the favorite channel list,

press FAV OR IT E, press or to highlight the channel, then press ENTER.

Adding or changing a channel label

If a channel is not already labeled, you can label the channel to make it easier to identify. You can also relabel a channel that is already labeled.

To label a channel:

1 Press MENU. The on-screen menu opens.

3 Press or to highlight Channel Labels, then

press ENTER. The Channels - Channel Labels screen opens with the channel number field highlighted.

RADIO

PICTURE AUDIO CHANNELS SETTINGS

Channels

EXIT

Create labels for channels, up to 10 characters

• Channels labels

1.2

MOVE SELECT PREVIOUS EXIT

ENTER

S e n c o r e

RADIO

EXIT

4 Press or to select the channel number you

want to label, then press to move to the channel label field.

5 Press or to select a character, then press

or to move to the next position. Repeat this step to add more characters (as many as 10).

6 When the label is complete, press ENTER, then

confirm when the confirmation box opens.

7 Press EXIT to close the menu.

Checking the DTV signal strength

You can check the DTV signal strength to determine if you need to adjust your antenna or digital cable input. The higher the signal strength, the less likely you are to experience picture degradation.

To check the DTV signal strength:

1 Press MENU. The on-screen menu opens.

PICTURE AUDIO CHANNELS SETTINGS


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

Adjust settings to affect picture quality

ENTER

-16

EXIT

2 Press or to highlight CHANNELS, then

press or ENTER. The Channels menu opens.

Channels

Add/Skip Channels

Favorites

Channel Labels

Channel Strength

Audio Only Off

Auto Zoom Off

MOVE SELECT PREVIOUS EXIT

Create labels for channels, up to 10 characters

PICTURE AUDIO CHANNELS SETTINGS

ENTER

EXIT

RADIO

PICTURE AUDIO CHANNELS SETTINGS


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect picture quality

-16

EXIT

2 Press or to highlight CHANNELS, then

press or ENTER. The Channels menu opens.

PICTURE AUDIO CHANNELS SETTINGS

Channels

Add/Skip Channels

Favorites

Channel Labels

Channel Strength

Audio Only

Auto Zoom

MOVE SELECT PREVIOUS EXIT

ENTER

Display signal strength of selected digital channels.

Off Off

EXIT

RADIO

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 22 Tuesday, April 7, 2009 9:29 AM

3 Press or to highlight Channel Strength,

then press ENTER. The Channel Strength screen opens showing the signal strength meter.

Channel Strength

WGBH-DX

MOVE SELECT PREVIOUS EXIT

Channel Strength

ENTER

Now 67 %

100

EXIT

4 Press EXIT to close the menu.

Setting parental controls

Parental controls let you prevent your children from watching inappropriate material on TV. When set, parental controls read the rating of the program (with some exceptions, such as news and sports) and deny access to programs that exceed the ratings level you select. To watch programs that exceed the selected rating, you must enter a password.

Setting or changing the password

To set the parental password:

1 Press MENU. The on-screen menu opens.

4 Press the number buttons to enter the four-digit

password. The default password is 0000. You should change the password to a number you can remember. The Parental Controls sub-menu opens.

PICTURE AUDIO CHANNELS SETTINGS

Settings

Button Lock

Block Unrated TV

Change Password

Enter a new 4-digit password then re-enter it to confirm

• Parental Controls

USA Parental Locks

Canadian Parental Locks

MOVE SELECT PREVIOUS EXIT

ENTER

RADIO

EXIT

5 Press or to highlight Change Password,

then press ENTER. The password entry screen opens.

6 Press the number buttons to enter a new

password, and then enter the new password again. The Parental Controls submenu reopens.

Note

If you forget your password, enter 9999.

PICTURE AUDIO CHANNELS SETTINGS

RADIO


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect picture quality

-16

EXIT

2 Press or to highlight SETTINGS, then press

or ENTER. The Settings menu opens with

Parental Controls selected.

Settings

PICTURE AUDIO CHANNELS SETTINGS

Parental Controls

Closed Caption

Time

Menu Settings

Input Labels

Input Sensor Off

MOVE SELECT PREVIOUS EXIT

ENTER

Set TV parental controls

RADIO

EXIT

3 Press ENTER. The Enter Password screen opens.

7 Press EXIT to close the menu.

Turning the button lock on or off

When the button lock is turned On, the buttons on the TV control panel are locked and only the remote control is able to operate the TV.

To turn parental controls button lock on or off:

1 Press MENU. The on-screen menu opens.

PICTURE AUDIO CHANNELS SETTINGS


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect picture quality

2 Press or to highlight SETTINGS, then press

or ENTER. The Settings menu opens with

Parental Controls selected.

Settings

Parental Controls

Closed Caption

Time

Menu Settings

Input Labels

Input Sensor Off

MOVE SELECT PREVIOUS EXIT

ENTER

Set TV parental controls

PICTURE AUDIO CHANNELS SETTINGS

RADIO

-16

EXIT

RADIO

EXIT

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 23 Tuesday, April 7, 2009 9:29 AM

3 Press ENTER. The Enter Password screen opens. 4 Press the number buttons (0-9) to enter the

four-digit password. The Settings - Parental Controls submenu opens.

Settings

Button Lock

Block Unrated TV

Change Password

Lock or unlock the buttons on the TV

• Parental Controls

USA Parental Locks

Canadian Parental Locks

MOVE SELECT PREVIOUS EXIT

ENTER

5 Press or to highlight Button Lock, then

press ENTER.

6 Press or to select On (to turn on the Button

Lock) or Off (to turn off the Button Lock).

7 Press EXIT to close the menu.

Note

Removing the AC power and reconnecting it resets the button lock to Off.

Blocking unrated TV

To block unrated TV:

1 Press MENU. The on-screen menu opens.

PICTURE AUDIO CHANNELS SETTINGS

EXIT

RADIO

4 Press the number buttons (0-9) to enter the

four-digit password. The Settings - Parental Controls submenu opens.

Settings

Button Lock

Block Unrated TV

Change Password

Block TV programs that do not have a rating.

• Parental Controls

USA Parental Locks

Canadian Parental Locks

MOVE SELECT PREVIOUS EXIT

PICTURE AUDIO CHANNELS SETTINGS

ENTER

5 Press or to highlight Block Unrated TV,

then press ENTER.

6 Press or to select On (to block unrated TV

programs) or Off.

7 Press EXIT to close the menu.

Setting parental control levels

You can set parental controls for the U.S. and Canada. The following procedure shows how to set controls for U.S. TV ratings. You use similar steps for controlling U.S. movie and Canadian TV ratings.

To set parental controls:

1 Press MENU. The on-screen menu opens.

RADIO

EXIT

PICTURE AUDIO CHANNELS SETTINGS

RADIO


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

ENTER

MOVE SELECT PREVIOUS EXIT

Adjust settings to affect picture quality

-16

EXIT

2 Press or to highlight SETTINGS, then press

or ENTER. The Settings menu opens with

Parental Controls selected.

Settings

PICTURE AUDIO CHANNELS SETTINGS

Parental Controls

Closed Caption

Time

Menu Settings

Input Labels

Input Sensor Off

MOVE SELECT PREVIOUS EXIT

Set TV parental controls

ENTER

RADIO

EXIT

PICTURE AUDIO CHANNELS SETTINGS

RADIO


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect picture quality

-16

EXIT

2 Press or to highlight SETTINGS, then press

or ENTER. The Settings menu opens with

Parental Controls selected.

Settings

PICTURE AUDIO CHANNELS SETTINGS

Parental Controls

Closed Caption

Time

Menu Settings

Input Labels

Input Sensor Off

MOVE SELECT PREVIOUS EXIT

ENTER

Set TV parental controls

RADIO

EXIT

3 Press ENTER. The Enter Password screen opens.

www.insigniaproducts.com

3 Press ENTER. The Enter Password screen opens.

NS-L19X-10A_09-0241_MAN_V2_English.book Page 24 Tuesday, April 7, 2009 9:29 AM

4 Press the number buttons to enter the four-digit

password. The Settings - Parental Controls submenu opens.

PICTURE AUDIO CHANNELS SETTINGS

Settings

Button Lock

Block Unrated TV

Change Password

Restrict movie and TV programs by US Ratings

• Parental Controls

USA Parental Locks

Canadian Parental Locks

MOVE SELECT PREVIOUS EXIT

ENTER

RADIO

EXIT

5 Press or to highlight USA Parental Locks

(or Canadian Parental Locks), then press ENTER. (USA Parental Locks shown in this example.)

PICTURE AUDIO CHANNELS SETTINGS

Settings • Parental Controls • USA Parental Locks

MP AA Rating

None G

PG PG-13 R

NC-17 X

ENTER

MOVE SELECT PREVIOUS EXIT

Restrict movie and TV programs by US Ratings

TV Ratings

All FV L S V D None TV -Y TV -Y7 TV -G TV -PG

TV -14 TV -MA

RADIO

EXIT

U. S. TV ratings (content-based)

All All ratings.

FV Fantasy violence.

L Strong language.

SSexual situations.

VViolence.

D Suggestive dialog.

U.S. movie (MPAA) ratings

None Not rated.

G General audiences.

PG Parental guidance suggested.

PG-13 Suitable for children 13 and older.

R Parental guidance suggested for children under 17.

NC-17 Not suitable for children under 17.

XAdults only.

Canadian En glish ratings

EExempt programming.

C Suitable for all children.

C8+ Suitable for children 8 and older.

G General audiences.

PG Parental guidance suggested.

14+ Suitable for children 14 and older.

18+ Adults only.

6 Press or to set the MPAA Rating (or English

Rating for Canadian), then press or to select the rating.

7 - OR - 8 Press or to set the TV Ratings (or French

Rating for Canadian), then press , , , or to select the rating.

9 Press ENTER to confirm. A lock symbol appears

when a rating is blocked.

10 Repeat to block additional ratings.

Note

When you block a rating, that rating and all higher ratings are blocked.

11 Press EXIT to close the menu.

U.S. TV ratings (age-based)

None Not rated.

TV-Y All children.

TV-Y7 Suitable for children 7 and older.

TV-G General audiences.

TV-PG Parental guidance suggested.

TV-14 Parental guidance strongly suggested.

TV-MA Mature audiences only.

Canadian French ratings

EExempt programming.

G General audiences.

8 ans+ Suitable for children 8 and older.

13 ans+ Suitable for children 13 and older.

16 ans+ Suitable for children 16 and older.

18 ans+ Adults only.

Downloading rating information

You can download rating information to use when setting parental controls.

To download rating information:

1 Press MENU. The on-screen menu opens.

PICTURE AUDIO CHANNELS SETTINGS


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect picture quality

RADIO

-16

EXIT

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 25 Tuesday, April 7, 2009 9:29 AM

2 Press or to highlight SETTINGS, then press

or ENTER. The Settings menu opens with

Parental Controls selected.

Settings

Parental Controls

Closed Caption

Time

Menu Settings

Input Labels

Input Sensor Off

MOVE SELECT PREVIOUS EXIT

Set TV parental controls

PICTURE AUDIO CHANNELS SETTINGS

ENTER

3 Press ENTER. The Enter Password screen opens. 4 Press the number buttons to enter the four-digit

password. The Settings - Parental Controls submenu opens.

Settings

Block Unrated TV

Change Password

RRT5 Settings

Display an advanced parental controls ratings table for digital channels

• Parental Controls

USA Parental Locks

Canadian Parental Locks

MOVE SELECT PREVIOUS EXIT

PICTURE AUDIO CHANNELS SETTINGS

ENTER

5 Press or to highlight RRT5 Settings, then

press ENTER. If the program is broadcast with RRT5 rating

information, the information is downloaded automatically and can be used for parental controls.

6 To clear RRT5 settings, go to the RRT5 Settings

submenu, select Reset, then press ENTER to clear.

Using closed captioning

Turning closed captioning on or off

2 Press or to highlight SETTINGS, then press

or ENTER. The SETTINGS menu opens.

RADIO

EXIT

Settings

Parental Controls

Closed Caption

Time

Menu Settings

Input Labels

Input Sensor Off

MOVE SELECT PREVIOUS EXIT

Set TV parental controls

PICTURE AUDIO CHANNELS SETTINGS

ENTER

RADIO

EXIT

3 Press or to highlight Closed Caption, then

press ENTER. The Settings - Closed Caption menu opens.

PICTURE AUDIO CHANNELS SETTINGS

RADIO

Settings •

Mode

Closed Caption

Analog Caption

Digital Caption

Digital CC Settings

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust Closed Captioning settings

EXIT

RADIO

CC Off

CC1

CC4

EXIT

4 Press or to highlight Mode, then press

ENTER. A menu opens.

5 Press or to select CC Off (turns off closed

captioning), CC On (turns on closed captioning), or CC on Mute (turns on closed captioning when the sound is muted).

6 Press EXIT to close the menu.

Note

You can also press CCD to turn closed captioning on or off.

Setting the analog closed captioning

To select the closed captioning mode:

1 Press MENU. The on-screen menu opens.

To turn closed captioning on or off:

1 Press MENU. The on-screen menu opens.

PICTURE AUDIO CHANNELS SETTINGS


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

Adjust settings to affect picture quality

ENTER

www.insigniaproducts.com

PICTURE AUDIO CHANNELS SETTINGS

RADIO


Mode Standard

RADIO

-16

EXIT

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect picture quality

-16

EXIT

2 Press or to highlight SETTINGS, then press

or ENTER. The Settings menu opens.

NS-L19X-10A_09-0241_MAN_V2_English.book Page 26 Tuesday, April 7, 2009 9:29 AM

3 Press or to highlight Closed Caption, then

press ENTER. The Settings - Closed Caption menu opens.

Settings •

Mode

Analog Caption

Digital Caption

Digital CC Settings

Adjust Closed Captioning settings

Closed Caption

MOVE SELECT PREVIOUS EXIT

PICTURE AUDIO CHANNELS SETTINGS

ENTER

CC Off

4 Press or to highlight Analog Caption, then

press ENTER. A menu opens.

5 Press or to select an analog caption setting.

You can selec t :

• CC1 through CC4—Closed captioning appears in a small banner across the bottom of the screen. CC1 is usually the “printed” version of the audio. CC2 through CC4 display content provided by the broadcaster.

• Tex t 1 through Te x t4 —Closed captioning that covers half or all of the screen. Tex t1 through Te xt 4 display content provided by the broadcaster.

6 Press EXIT to close the menu.

Setting digital closed captioning styles

You can customize the way DTV closed captioning is displayed.

To customize DTV closed captioning:

1 Press MENU. The on-screen menu opens.

PICTURE AUDIO CHANNELS SETTINGS


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect picture quality

2 Press or to highlight SETTINGS, then press

or ENTER. The Settings menu opens.

CC1

CC4

EXIT

-16

RADIO

3 Press or to highlight Closed Caption, then

press ENTER. The Settings - Closed Caption menu opens.

PICTURE AUDIO CHANNELS SETTINGS

Settings •

Mode

Analog Caption

Digital Caption

Digital CC Settings

Set Closed Caption for digital programs.

Closed Caption

MOVE SELECT PREVIOUS EXIT

ENTER

RADIO

CC Off

CC1

CC4

EXIT

4 Press or to highlight Digital Caption, then

press ENTER. A menu opens.

5 Press or to select a digital caption setting.

You can select CS1 through CS6, then press

ENTER.

6 Press or to highlight Digital CC Settings,

then press ENTER. The Digital CC Settings menu opens with Style highlighted.

Digital CC Setings

Style

Size Font Text Color Text Opacity Background Color Background Opacity Edge Effect Edge Color

Custom

Normal Default

Yellow

Solid

Black

Solid

None

Red

CLOSED CAPTION

MOVE SELECT

Set the lock of digital CC. Automatic uses broadcaster's style.

ENTER

PREVIOUS EXIT

EXIT

7 Press to set the Style to Custom. 8 Press or to highlight an option, then press

press or to set the option. You can select:

• Size—Selects the font size

• Font—Selects the font style

• Tex t Col o r—Selects the color for the words

• Tex t O paci t y—Selects the opacity level for the words

• Background Color—Selects the color for the background

• Background Opacity—Selects the opacity level for the background

• Edge Effect—Selects the edge style

• Edge Color—Selects the edge color

9 Press MENU to return to the previous menu, or

press EXIT to close the menu.

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 27 Tuesday, April 7, 2009 9:29 AM

Adjusting time settings

Setting the date and time

To set the date and time:

1 Press MENU. The on-screen menu opens.

PICTURE AUDIO CHANNELS SETTINGS


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect picture quality

2 Press or to highlight SETTINGS, then press

or ENTER. The SETTINGS menu opens.

3 Press or to highlight Time, then press

ENTER. The Settings - Time submenu opens.

4 Press or to highlight Date/Time, then press

ENTER. The Time - Date/Time submenu opens.

PICTURE AUDIO CHANNELS SETTINGS

Settings •

Mode

Time Zone Daylight Savings Year Month Day

If automatic, options are automatically set by TV source

Time • Date/Time

MOVE SELECT PREVIOUS EXIT

ENTER

5 Press or to highlight Mode, then press

ENTER. A menu opens.

6 Press or to select Manual (to set the

options manually) or Auto (the options are automatically set by the TV signal source).

7 Press ENTER to close the menu. 8 Press or to highlight Time Zone, then press

ENTER. The Time - Time Zone menu opens.

9 Press or to select your time zone. You can

select Eastern, Central, Mountain, Pacific,

Alaska, Hawaii, Atlantic, or Newfoundland. 10 Press ENTER to close the menu. 11 If your viewing area observes daylight savings

time, press or to highlight Daylight

Savings, then press ENTER. The Time - Daylight

Savings menu opens.

12 Press or to select On, then press ENTER to

close the menu.

13 If you selected

Manual for Mode, make the

setting as follows:

• Set the year, month, and day by pressing or to highlight Year, Month, or Day, then press or to adjust the setting.

Auto

Atlantic Off

2008 OCT 28

• Set the time by pressing or to highlight Hour, then press or to move the highlight to the hour, minute, or AM/PM field.

• Press or to adjust the setting.

14 Press EXIT to close the menu.

Setting the sleep timer

You can specify the amount of time you want your

RADIO

-16

EXIT

RADIO

EXIT

TV to wait before it automatically turns off.

To set the sleep timer:

1 Press MENU. The on-screen menu opens.

PICTURE AUDIO CHANNELS SETTINGS


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect picture quality

RADIO

-16

EXIT

2 Press or to highlight SETTINGS, then press

or ENTER. The SETTINGS menu opens.

3 Press or to highlight Time, then press

ENTER. The Settings - Time submenu opens.

Settings •

Date/Time

Sleep Timer Off

Set a time for the TV to turn off automatically

Time

MOVE SELECT PREVIOUS EXIT

PICTURE AUDIO CHANNELS SETTINGS

ENTER

RADIO

EXIT

4 Press or to highlight Sleep Timer, then

press ENTER. A menu opens.

5 Press or to select the amount of time before

your TV turns off automatically.

Note

To turn off the sleep timer, select Off.

6 Press EXIT to close the menu.

Note

You can a lso p ress SLEEP on the remote control to set the sleep timer.

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 28 Tuesday, April 7, 2009 9:29 AM

Adjusting menu settings

Selecting the menu language and transparency

To select the on-screen menu language and menu transparency:

1 Press MENU. The on-screen menu opens.

PICTURE AUDIO CHANNELS SETTINGS


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect picture quality

2 Press or to highlight SETTINGS, then press

or ENTER. The SETTINGS menu opens.

Settings

Parental Controls

Closed Caption

Time

Menu Settings

Input Labels

Input Sensor

MOVE SELECT PREVIOUS EXIT

Adjust TV Menu options

ENTER

3 Press or to highlight Menu Settings, then

press ENTER. The Settings - Menu Settings menu opens.

Settings •

Transparency

Language

Set menu language to English, Français or Español

Menu Settings

MOVE SELECT PREVIOUS EXIT

ENTER

4 Press or to highlight Language, then press

ENTER. A language menu opens.

5 Press or to select the menu language you

want. Options include English, French, and

Spanish. 6 Press ENTER to close the menu. 7 Press or to select Transparency, then press

ENTER. 8 Press or to adjust the menu transparency. 9 Press EXIT to close the menu.

PICTURE AUDIO CHANNELS SETTINGS

English

Français

Español

English

Labeling an input source

You can add a label to an input source to make it easier to identify.

To label an input source:

1 Press MENU. The on-screen menu opens.

PICTURE AUDIO CHANNELS SETTINGS


RADIO

-16

EXIT

Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect picture quality

2 Press or to highlight SETTINGS, then press

or ENTER. The SETTINGS menu opens.

PICTURE AUDIO CHANNELS SETTINGS

Settings

Parental Controls

RADIO

Closed Caption Time Menu Settings

Input Labels

Input Sensor Off

MOVE SELECT PREVIOUS EXIT

ENTER

Off

EXIT

Create labels for the devices connected to your TV

3 Press or to highlight Input Labels, then

press ENTER. The Settings - Input Labels screen opens.

PICTURE AUDIO CHANNELS SETTINGS

RADIO

Settings •

Input

Input Labels

Label

Custom

Reset Input Labels

MOVE SELECT PREVIOUS EXIT

ENTER

EXIT

Create labels for the devices connected to your TV

4 Press or to highlight Input, then press or

to select the input you want to label.

5 Press or to highlight Label, then press or

to select a preset label for the input.

- OR Press or to highlight Label, then press or

to select Custom.

RADIO

-16

EXIT

RADIO

EXIT

RADIO

VGA

EXIT

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 29 Tuesday, April 7, 2009 9:29 AM

6 Press or to highlight Custom, then press .

A custom label entry field opens.

Settings •

Input Labels

Input

Label

Custom

Reset Input Labels

MOVE SELECT PREVIOUS EXIT

Create labels for the devices connected to your TV

PICTURE AUDIO CHANNELS SETTINGS

ENTER

• Press or to select a character, then press or to move to the next position. Repeat this step to add more characters.

• Press ENTER to open a confirmation screen, then select Ye s to confirm.

• Press ENTER to exit the menu.

7 Press MENU to exit.

Note

To restore input labels to factory default, highlight Reset Input Labels, then press ENTER. Select Ye s on the confirmation screen and press ENTER again.

Setting the input sensor

To set the input sensor:

1 Press MENU. The on-screen menu opens.

PICTURE AUDIO CHANNELS SETTINGS


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect picture quality

AV1

Custom

EXIT

-16

RADIO

Restoring default settings

Caution

When you restore default settings, all the settings you have customized (except the password and parental rating) are reset.

To restore default settings:

1 Press MENU. The on-screen menu opens.

PICTURE AUDIO CHANNELS SETTINGS


Mode Standard

Brightness 70

Contrast

Color

Tint

Sharpness

MOVE SELECT PREVIOUS EXIT

ENTER

Adjust settings to affect picture quality

2 Press or to highlight SETTINGS, then press

or ENTER. The SETTINGS menu opens.

Settings

Menu Settings

Input Labels

Input Sensor

Computer Settings

Component Settings

Reset to Default

MOVE SELECT PREVIOUS EXIT

Reset to Default

3 Press or to highlight Reset to Default, then

press ENTER. A confirmation box opens.

4 Press or to select Ye s (to reset) or No (to not

reset).

5 Press ENTER, then press EXIT.

PICTURE AUDIO CHANNELS SETTINGS

ENTER

RADIO

-16

EXIT

RADIO

Off

EXIT

2 Press or to highlight SETTINGS, then press

or ENTER. The SETTINGS menu opens.

PICTURE AUDIO CHANNELS SETTINGS

Settings

Parental Controls

Closed Caption

Time

Menu Settings

Input Labels

Input Sensor On

MOVE SELECT PREVIOUS EXIT

ENTER

Detects devices connected to the ports on the back or side of the TV

RADIO

EXIT

3 Press or to highlight Input Sensor, then

press ENTER. A menu opens.

4 Press or to select On (to activate the input

sensor) or Off (to deactivate the input sensor).

5 Press ENTER, then press EXIT.

www.insigniaproducts.com

Listening to FM radio

This TV has a built-in FM tuner which is capable of receiving radio broadcasts. To listen to the radio, you must select FM mode first.

Note

Make sure to connect the FM antenna to the FM jack on the side of your TV, and extend the antenna as far as possible.

Switching to FM mode

To switch to FM mode:

• Press FM on the remote control.

- OR Press Input, then press or to select FM,

then press ENTER.

NS-L19X-10A_09-0241_MAN_V2_English.book Page 30 Tuesday, April 7, 2009 9:29 AM

Selecting an FM program

To select an FM program:

• Press the number buttons (0-9) to select a preset station directly.

- OR Press CH+ or CH- to select a preset station.

- OR Access the RADIO menu and choose a station

from the Available Stations list.

- OR Access the RADIO menu and input the

frequency on the Frequency menu.

Presetting FM stations

To preset FM stations automatically:

1 Press MENU. The on-screen menu opens with

the RADIO menu displayed.

Note

If there is no available radio program in the channel list, ''Channel list is empty. Please do auto search first,'' appears on the RADIO menu. Press or to select Ye s , then press ENTER to begin the auto search.

2 Press or ENTER to access.

3 Press or ENTER to access.

PICTURE AUDIO CHANNELS SETTINGS

Radio

Available Stations

Frequency

Fine Tune

Auto Search

Audio Only

MOVE SELECT PREVIOUS EXIT

Change a station from 87.0 to 107.9 Mhz.

ENTER

105.15

MHz

RADIO

EXIT

4 Press or to highlight Available Stations,

then press to access.

5 Press or to select a preset number, then

press or .

6 Press or to highlight Frequency, then press

to access.

7 Press or to select a frequency, then press

or to move to the next position and press ENTER. The TV locates your station.

Note

If you want to clear specific radio station, you may set the frequency to 0.0MHz.

PICTURE AUDIO CHANNELS SETTINGS

RADIO

Radio

Available Stations

Frequency

Fine Tune

Auto Search

Audio Only

MOVE SELECT PREVIOUS EXIT

Search for radio stations and save them to "Available Stations"

ENTER

105.15

MHz

EXIT

3 Press or to select Auto Search, then press

ENTER.

The available broadcast stations in your area are preset in order from low to high frequency. Auto Search Finished appears when the auto search is complete, then the radio is tuned to the lowest frequency preset.

Note

Using Auto Search will delete previously preset broadcast stations.

To preset FM stations manually:

1 Manually tune the radio to a frequency of your

choice.

2 Press CH+ or CH- to select the preset number to

assign to the station.

- OR Press MENU. The on-screen menu opens with

the RADIO menu displayed.

Fine tuning an FM station

To fine tune an FM station:

1 Press MENU. The on-screen menu opens with

the RADIO menu displayed.

2 Press or ENTER to access.

PICTURE AUDIO CHANNELS SETTINGS

Radio

Available Stations

Frequency

Fine Tune

Auto Search

Audio Only

MOVE SELECT PREVIOUS EXIT

Make small adjusts to the frequency of weak signals.

3 Press or to select Fine Tune, then press

or to fine tune the station.

4 Press EXIT.

ENTER

105.15

RADIO

MHz

EXIT

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 31 Tuesday, April 7, 2009 9:29 AM

Troubleshooting

Warning

Do not try to repair your TV yourself. Contact authorized service personnel.

Video and audio

Problem Solution

No picture or sound (the screen is not lit)

Dark, poor, or no picture (the screen is lit), but sound is good

No color, picture is dark, or color is not correct

Only noise (snow) appears on the screen

Picture has dotted lines or stripes

Picture has double images • Use a highly directional outdoor antenna or

Picture has a few brig ht or dark dots

Good picture, no sound • Increase the volume.

Audio noise or static • Move radio frequency communication equipment,

• Make sure that the power cord is plugged into a power outlet.

• Press (power) on your TV or the remote control.

• Try another channel. The problem could be with the TV station.

• Select the correct picture mode. For more information, see “Adjusting the picture” on page 16.

• Adjust the brightness. For more information, see “Adjusting the picture” on page 16.

• Make sure that the antenna or cable TV is connected correctly. For more information, see “Connecting an antenna, cable TV, or satellite TV box” on page 9.

• Adjust the color saturation. For more information, see “Adjusting the picture” on page 16.

• Make sure that the antenna or cable TV is connected correctly. For more information, see “Connecting an antenna, cable TV, or satellite TV box” on page 9.

• Try another channel. The problem could be with the TV station.

• Adjust the antenna.

• Move your TV away from noise sources, such as cars, neon signs, or hair dryers.

change to cable or satellite TV.

• A few bright or dark dots on an LCD screen is normal. It does not affect the operation of this TV.

•Press MUTE to make sure that the sound is not muted.

• Make sure that the audio mode is set to STEREO or MONO. For more information, see “Selecting the audio mode” on page 18.

such as a cordless phone, away from your TV.

General

Problem Solution

Cannot tune to one or more channels

Password is lost • On the Parental Controls menu, enter 9999 for the

Cannot access some items

TV cabinet creaks • When you are using your TV, the temperature inside

Buttons do not work • Unplug the power cord for a few seconds, then plug

• The program you want to watch may be blocked through the parental controls. For more information, see “Setting parental control levels” on page 23 or “Turning the button lock on or off” on page 22.

• The channel may have been deleted from the channel list. You can tune to the channel b y pressing the number buttons or you can add the channel back to the channel list. For more information, see “Changing channel settings” on page 19.

password, then set a new password. For more information, see “Setting or changing the password” on page 22.

• If a setting or option is grayed out, it is not available in the current input mode.

the cabinet increases. This causes the cabinet to expand or contract, which produces the creaking noise. This is not a malfunction.

it back in and turn on your TV.

FM radio

Problem Solution

Cannot hear the FM station well

Reception is weak and sound quality is poor

The FM broadcast is affected by interference

Note

• The receiving frequency is not tuned in fully. Adjust the frequency manually to improve reception.

• Fully extend the FM antenna.

• Keep the FM antenna as horizontal as possible.

• The radio signal may be weak. Try moving your TV to another location (such as near a window) to improve reception.

• A device emitting radio signals, such as a mobile phone, is being used near your TV. Keep such devices away from your TV.

If the problem is not solved by using these troubleshooting instructions, turn off your TV, then turn it on again.

Maintaining

Remote control

Problem Solution

Remote control does not work

• Replace the battery. For more information, see

• Make sure that the battery are inserted correctly.

• Make sure that the power cord is plugged into an

“Installing the remote control battery” on page 7.

For more information, see “Installing the remote control battery” on page 7.

AC powe r outlet.

www.insigniaproducts.com

• To clean your TV, wipe with it a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth dipped in a soap and water solution or a weak detergent solution.

• Use eyeglass cleaner to remove stubborn dirt from the screen.

• Never use alcohol, paint thinner or benzine to clean your TV.

• Before using a chemically treated cloth, read the instructions that came with the cloth carefully.

NS-L19X-10A_09-0241_MAN_V2_English.book Page 32 Tuesday, April 7, 2009 9:29 AM

Specifications

Design and specifications are subject to change without notice. Dimensions and weight are approximate.

TV type

TV panel

TV system

Channels

Audio multiplex

Audio output

Power requirement

Power consumption

Dimensions

Weig ht

Input terminals

Output terminals

Control terminals

FM radio presets

FM frequency range

LCD

19-inch TFT LCD NTSC-M, ATSC VHF: 2 - 13 UHF: 14 - 69 CATV: 1 - 125 CADTV: 1-135 DTV: 2 - 69

BTSC system 5W × 2

AC 120 V, 60 Hz 35 W

18.1 × 12.5 × 9.84 inches (19") (460 × 318 × 250 mm)

10.14 lbs. (4.6 kg) Composite video/left and right audio (2) S-Video (2) Component video/left and right audio (2) HDMI (3) VGA/audio (1) FM antenna (1) Antenna (1)

Headphone jack (1) Audio output (1) Digital output (1) RS-232 (1) Service Port (1)

87.0~107.9 MHz

Canada ICES-003 statement

This Class B digital apparatus complies with Canadian ICES-003. Standard Television Receiving Apparatus — Appareil de

réception télévision ordinaire, Canada BETS-7 / NTMR-7

Legal notices

FCC Part 15

This device complies with Part 15 of the FCC Rules. Operation of this product is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply within the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced technician for help.

FCC warning

Changes or modifications not expressly approved by the party responsible for compliance with the FCC Rules could void the user’s authority to operate this equipment.

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 33 Tuesday, April 7, 2009 9:29 AM

Two-year limited warranty

Insignia Products (“Insignia”) warrants to you, the original purchaser of this new NS-L19X-10A (“Product”), that the Product shall be free of defects in the original manufacture of the material or workmanship for a period of two (2) years from the date of your purchase of the Product (“Warranty Period”). This Product must be purchased from an authorized dealer of Insignia brand products and packaged with this warranty statement. This warranty does not cover refurbished Product. If you notify Insignia during the Warranty Period of a defect covered by this warranty that requires service, terms of this warranty apply.

How long does the coverage last?

The Warranty Period lasts for 2 years (730 days) from the date you purchased the Product. The purchase date is printed on the receipt you received with the Product.

What does this warranty cover?

During the Warranty Period, if the original manufacture of the material or workmanship of the Product is determined to be defective by an authorized Insignia repair center or store personnel, Insignia will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts. Products and parts replaced under this warranty become the property of Insignia and are not returned to you. If service of Products or parts are required after the Warranty Period expires, you must pay all labor and parts charges. This warranty lasts as long as you own your Insignia Product during the Warranty Period. Warranty coverage terminates if you sell or otherwise transfer the Product.

How to obtain warranty service?

If you purchased the Product at a retail store location, take your original receipt and the Product to the store you purchased it from. Make sure that you place the Product in its original packaging or packaging that provides the same amount of protection as the original packaging. If you purchased the Product from an online web site, mail your original receipt and the Product to the address listed on the web site. Make sure that you put the Product in its original packaging or packaging that provides the same amount of protection as the original packaging.

To obtain in-home warranty service for a television with a screen 30 inches or larger, call 1-888-BESTBUY. Call agents will diagnose and correct the issue over the phone or will have an Insignia-approved repair person dispatched to your home.

Where is the warranty valid?

This warranty is valid only to the original purchaser of the product in the United States, Canada, and Mexico.

What does the warranty not cover?

This warranty does not cover:

• Customer instruction

•Installation

•Set up adjustments

•Cosmetic damage

• Damage due to acts of God, such as lightning strikes

•Accident

•Misuse

•Abuse

•Negligence

•Commercial use

• Modification of any part of the Product, including the antenna

• Plasma display panel damaged by static (non-moving) images applied for lengthy periods (burn-in).

This warranty also does not cover:

• Damage due to incorrect operation or maintenance

• Connection to an incorrect voltage supply

• Attempted repair by anyone other than a facility authorized by Insignia to service the Product

• Products sold as is or with all faults

• Consumables, such as fuses or batteries

• Products where the factory applied serial number has been altered or removed

REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR EXCLUSIVE REMEDY. INSIGNIA SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR THE BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS

PRODUCT, INCLUDING, BUT NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT, LOST BUSINESS OR LOST PROFITS. INSIGNIA PRODUCTS MAKES NO OTHER EXPRESS WARRANTIES WITH RESPECT TO THE PRODUCT, ALL EXPRESS AND IMPLIED WARRANTIES FOR THE PRODUCT, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF AND CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE AND NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER THE WARRANTY PERIOD. SOME STATES, PROVINCES AND JURISDICTIONS DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE.

Contact Insignia: For customer service please call 1-877-467-4289

www.insigniaproducts.com Distributed by Best Buy Purchasing, LLC

7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2009 Best Buy Enterprise Services, Inc. All rights reserved. INSIGNIA is a trademark of Best Buy Enterprise Services, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 34 Tuesday, April 7, 2009 9:29 AM

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page 35 Tuesday, April 7, 2009 9:29 AM

www.insigniaproducts.com

NS-L19X-10A_09-0241_MAN_V2_English.book Page -1 Tuesday, April 7, 2009 9:29 AM

www.insigniaproducts.com (877) 467-4289

Distributed by Best Buy Purchasing, LLC

7601 Penn Avenue South, Richfield, MN USA 55423-3645

All other products and brand names are trademarks of their respective owners.

ENGLISH 09-0241

Insignia NS-L19X-10A User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
