Insignia NS-BC1ZSS9 User Manual

USER GUIDE

165-Can Beverage Cooler

NS-BC1ZSS9

Before using your new product, please read these instructions to prevent any damage.

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Control and display panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Setting up your beverage cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Before using your cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Finding a suitable location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Leveling your cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Installing the handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Reversing the door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Connecting to power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Using your beverage cooler. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 Turning on your cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 Setting the temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 Memory function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 Lighting your cooler. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 Arranging your beverages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Maintaining your beverage cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Cleaning the interior of your cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Defrosting your cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Storing your cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Moving your beverage cooler. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 Tips on saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 Error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 Problems and solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 ONE-YEAR LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

2	www.insigniaproducts.com

165-Can Beverage Cooler

Introduction

Congratulations on your purchase of a high-quality Insignia product. Your NS-BC1ZSS9 represents the state of the art in beverage cooler design and is designed for reliable and trouble-free performance.

IMPORTANT SAFETY

INSTRUCTIONS

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your cooler.

This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your cooler.

WARNING

1Read these instructions.

2Keep these instructions.

3Heed all warnings.

4Follow all instructions.

5Do not use this appliance near water.

6Clean only with a damp cloth.

7Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatuses (including amplifiers) that produce heat.

9Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the appliance.

11Do not use extension cords or ungrounded (two-prong) adapters.

www.insigniaproducts.com

3

12Unplug this appliance during lightning storms or when it will not be used for long periods of time.

13Make sure that the available AC power matches the voltage requirements of this appliance.

14Do not handle the plug with wet hands. This could result in an electric shock.

15Unplug the power cord by holding the plug, never by pulling the cord.

16Do not turn the appliance on or off by plugging or unplugging the power cord.

17Turn off the appliance before unplugging it.

18Refer all servicing to qualified service personnel. Servicing is required when the appliance has been damaged in any way, such as when the power-supply cord or plug is damaged, when liquid has been spilled or objects have fallen into the appliance, or when the appliance has been exposed to rain or moisture, does not operate normally, or has been dropped.

19To reduce the risk of fire or electric shock, do not expose this appliance to rain, moisture, dripping, or splashing, and do not place objects filled with liquids on top of it.

WARNING

Electric Shock Hazard

Failure to follow these instructions can result in electric shock, fire, or death.

1WARNING–Keep ventilation openings in the appliance enclosure or in the built-in structure clear of obstruction.

2WARNING–Do not touch the interior of the chiller compartment with wet hands. This could result in frost bite.

3WARNING–Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.

4WARNING–Do not damage the refrigerant circuit when handling, moving, or using the cooler.

5WARNING–Do not use electrical appliances inside the storage compartment of the appliance, unless they are of the type recommended by the manufacturer.

6WARNING–DANGER—Never allow children to play with, operate, or crawl inside the cooler.

Risk of child entrapment. Before you throw away your old cooler:

1)Take off the door

2)Leave the shelves in place so that children may not easily climb inside

7Unplug the cooler before carrying out user maintenance on it.

4	www.insigniaproducts.com

165-Can Beverage Cooler

8This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.

9If a component part is damaged, it must be replaced by the manufacturer, its service agent, or similar qualified persons in order to avoid a hazard.

10Dispose of the cooler according to local regulations as the cooler contains flammable gas and refrigerant.

11Follow local regulations regarding disposal of the cooler due to flammable refrigerant and gas. All refrigeration products contain refrigerants, which under the guidelines of federal law must be removed before disposal. It is the consumer's responsibility to comply with federal and local regulations when disposing of this product.

12This cooler is intended to be used in household and similar environments.

13Do not store or use gasoline or any flammable liquids inside or in the vicinity of this cooler.

14Do not use extension cords or ungrounded (two prong) adapters with this cooler. If the power cord is too short, have a qualified electrician install an outlet near the cooler.

15If the supply cord is damaged, it must be replaced by the manufacturer, its service agent, or a similarly qualified person in order to avoid a hazard.

www.insigniaproducts.com

5

Features

•165-can capacity

•Temperature range from 34° to 50°F (1° to 10°C)

•Auto-defrosting fan to eliminate ice and condensation build-up

•Touch controls and LED display

•Interior light

•Reversible door

•Removable shelves

Package contents

•Beverage cooler

•Handle

•Door reversal accessories (hex wrench, left hinge, & spare plastic plugs)

•User Guide

Components

Temperature control panel

Glass door

Wire shelves

Air vent

6	www.insigniaproducts.com

		165-Can Beverage Cooler
Control and display panel
Light	Display	Raise Temperature
5
Standby		Lower temperature Change temperature unit (°F/°C)

BUTTON FUNCTION

Hold for five seconds to set your cooler to “Standby” mode (the cooler stops cooling and light turns off).

Press to set whether the interior light stays on or off while the door is closed.

Press to increase the temperature by one degree.

Press to decrease the temperature by one degree.

Press to change the display between Fahrenheit and Celcius.

Notes:

•Touch the control panel lightly when pressing the keys.

•To avoid scratching the control panel, do not touch it with sharp objects.

Setting up your beverage cooler

Before using your cooler

•Remove the exterior and interior packaging.

•Let the cooler stand upright for approximately half an hour before connecting it to power. This reduces the possibility of a malfunction in the cooling system from improper handling during transportation.

•Clean the interior surface with a damp, warm cloth.

Finding a suitable location

•This cooler is designed to be built into your cabinets. Place it on a floor, countertop, or cabinet that is strong enough to support the cooler when it is fully loaded.

www.insigniaproducts.com

7

•If the cooler is not properly ventilated, the compressor will use more power. Make sure that you leave space on all sides:

•Top: .2 in. (.5 cm)

•Sides: .2 in. (.5 cm)

•Back: .8 in. (2.0 cm)

At least 34.5 in. (87.6 cm)

At least 24.2 in. (61.5 cm)

At least 23.8 in. (60.5 cm)

23.4 in.

(59.5 cm)

34.3 in.

(87.0 cm)

23.4 in. (59.5 cm)

•Leave enough space for the door to open at least 90 degrees.

•Place the cooler away from direct sunlight and sources of heat (stove, heater, radiator, etc.). If the cooler has to be put next to a heat source, use a suitable insulation board. Ambient temperatures below 50°F (10°C) or above 85°F (29.4°C) will hinder the performance of this cooler. This cooler is not designed for use in a garage or any other outside location.

•Avoid placing the cooler in moist areas.

•This unit is not designed to be installed in an RV or used with an inverter.

•Do not stack your cooler.

•For your cooler to operate normally, avoid placing it in areas with high magnetic fields or high humidity.

•Do not block the air vent on the front of your cooler.

Leveling your cooler

•It is very important for the cooler to be level in order to function properly. If the cooler is not leveled during installation, the door may not close or seal properly, causing cooling, frost, or moisture problems.

•To level your cooler, you may either turn the feet clockwise to raise the cooler or turn it counter-clockwise to lower it. The front feet should be adjusted slightly higher than the back feet.
