FS-V2
FLEX SELECT Series –
AMERICAN LOUDSPEAKER INNOVATION
innovoxaudio.com
PROUDLY MADE IN THE U.S.A.
296 North Pascal Street
(shown without grilles)
DESCRIPTION
NOMINAL DATA
DESCRIPTIVE DATA
• Custom built to match the exact height of
• Ultra slim profile – only two inches deep
• High resolution drivers for precise vocal
• Can be used with an optional Innovox
The Flex Select Model FS-V2 is an ultra slim vertical speaker pair designed to mate with flat panel video displays. It
has been designed for applications where the budget allows the use of separate amplifiers external to video displays.
Carefully selected drivers are employed with sophisticated filter networks to take full advantage of the reserve power
available with separate amplifiers to optimize performance and SPL in a slim profile. Nominal cov erag e angle is 120° H
x 100° V. Configuration per channel includes two 3.5” long-excursion LF drivers and one .75” textile dome HF driver.
Frequency Response 120 – 20,000 Hz ± 3 dB
Sensitivity 90 dB @ 2.83 volts / 1M
Impedance 8 Ω
Power Handling 90 watts long-term (AES-2)
(per channel)
Maximum Output 103 dB long-term,
109 dB peak
Nominal Coverage Angles 120° H x 100° V
Dimensions height: (custom 19.0 – 60.0 “)
width: 4.1 “
depth: 2.1 ”
Net Weight 10-17 lbs per pair
(depending on height)
Shipping Weight 13-20 lbs per pair
(depending on height)
Saint Paul MN 55104
Key Features
your flat panel display
articulation
sub-bass in 2.1 applications
System Configuration Low profile custom-sized side-mount
speaker for flat-panel displays
Components & Loading (2) 3.5 ” woofers;
Recommended High-Pass Filter On-board 1st order @ 120 Hz;
no outboard HP needed
Cabinet Type Very low profile, sealed, integral grille
Enclosure Material Extruded ABS plastic with steel baffle
plate
Finish Black is standard;
(custom colors available)
Connectors Phoenix
Grille Integral fabric wrap
(per channel) (1) 0.75“ soft-dome tweeter
