InFocus Work Big LP70+ Technical Specifications

Work Big LP

70

+

Work Big LP70

+

People wonder why they never see you without
your mobile InFocus Work Big LP70+. Those
people have obviously never attended one
of your riveting presentations. Once they’ve
witnessed how easily this lightweight projector’s
1500 powerful lumens ood any room, anywhere
with vibrant color and unparalleled clarity while
integrating data, video and audio, they’ll
suddenly get the big picture. Then they’ll want
all that convenience, exibility and brilliance for
themselves. Yet another reason they’ll never see
you without your LP70+.

Play with your projector.

Change rooms. Change ofces. Change cities. No
matter where you are and what you’re present­ing, the incredibly portable, full-featured LP70+ is
right there with you, waiting to make yet another
stunning impression.

It’s never been easier to make an impact
on the y:

Hook up in seconds for seamless
connectivity.

Access common functions with the
integrated keypad.

Enjoy crisp images, full color and an
amazing 1100:1 contrast ratio with the
latest digital processing technology
from Texas Instruments.

®

Don’t let it out of your sight.

One-touch

Keypad

Audio Input

Leveling Foot

Security Lock

Ambient Room Light Sensor

Dual Infrared Sensors

Composite

Video

Seamless DVI

Connectivity

Projection distances

Min. Diagonal Image Size Max. Diagonal Image Size
Distance Throw Ratio*: 1:82 Throw Ratio*: 1.51

Feet Meters Feet Meters Feet Meters

5.0 1.5 2.7 0.8 3.4 1.0

10.0 3.0 5.3 1.6 6.8 2.1

15.0 4.6 8.0 2.4 10.1 3.1

20.0 6.1 10.6 3.2 13.5 4.1

30.0 9.1 16.0 4.9 20.3 6.2

32.8 10.0 17.5 5.3 22.2 6.8

*Diagonal throw ratio = (distance/diagonal image size);
Horizontal throw ratio =(distance/horizontal image size)

S-Video

INFOCUS TECHNICAL SPECIFICATIONS

†

Native Resolution XGA 1024 x 768
Display Technology DLP

®

by Texas Instruments®: 0.7" XGA DMD DDR
Input Sources Computer (M1-DA), video (S-Video and RCA), audio (3.5mm mini jack)
Compatibility/Formats VGA through SXGA, 1152, Macintosh

®

Video Compatibility NTSC, PAL, SECAM, EDTV (480p, 576p), HDTV (720p, 1080i)
Brightness 1500 max ANSI lumens
Contrast Ratio 1100:1 full on/full off
Lamp 120W UHP/4000 Hours*
Digital Keystone Correction +/- 15° vertical; data/video
Image Offset 110% (+/- 5%)
Projection Lens Zoom Lens with manual focus and manual zoom adjust
Zoom Ratio 1.27:1
Throw Ratio 1.85 – 2.35:1
Aspect Ratio 4:3 (standard); 16:9 video, data
Audible Noise 32dB
Number of Colors 16.7 million
Image size (diagonal) 2.7'/0.8m (min) – 22.2'/6.8m (max)
Projection Methods Front, rear
Audio 1.0 watt speaker
Control Projector keypad; IR remote control; Wired control through USB
Dimensions 2.5" (H) x 6.1" (L) x 7.8" (W)
(maximum dimensions) 63.4 mm (H) x 148.8 mm (L) x 199.0 mm (W)
Weight (standard) 2.4 lbs (1.1 kg)
Power Supply 100V – 240V at 50 – 60 Hz
Power Consumption 155W
H-Synch Range 15 – 100 kHz
V-Synch Range 43.5 – 130 Hz
Pixel Clock 12 – 135 MHz
Operating Temperature 5° – 35° C at sea level (0' to 10,000'); 45° – 95° F
Menu Languages English, Norwegian, Spanish, Italian, Portuguese, German, French, Chinese (simple),
Chinese (traditional), Japanese
Approvals FCC A (US/Canada), S-JQA (Japan), PSE (Japan), CCC (China), IRAM (Argentina), GOST (Russia),
UL & cUL (US/Canada), TUV GS (Germany), NOM (Mexico), MIC (Korea), C-Tick (Australia)
Lamp Warranty 90 days
Product Warranty 2 year standard parts and labor, 90 days on accessories

† InFocus reserves the right to alter product offerings and specications at any time without notice.
* Actual lamp life may vary based on the ambient environment. Conditions that may affect lamp life include temperature,

altitude, and rapidly switching the projector on and off.

InFocus Corporate Headquarters:

27700B SW Parkway Avenue
Wilsonville, Oregon 97070-9215, USA
Phone: [phone]
1-800-294-6400
Fax: [phone]

In Europe:

Strawinskylaan 585
1077 XX Amsterdam
The Netherlands
Phone: [phone]
Fax: [phone]
Freephone: 008000 4636287 (008000 INFOCUS)

In Asia:

#07-01, Tanglin Shopping Centre
19 Tanglin Road
Singapore 247909
Phone: [phone]
Fax: [phone]

InFocus, In Focus, INFOCUS (stylized), Play Big, Work Big, LP, and SP are either registered trademarks or trademarks of InFocus Corporation in the United States and other
countries. DLP, the DLP logo, and the DLP medallion are trademarks of Texas Instruments. All other trademarks are used for identication purposes only and are the
property of their respective owners in this and other countries. ©2006 InFocus Corporation. All rights reserved. Part Number: 805-0000-00. WB_LP70+_DS_E_012606.

Enduring Quality

If you’re happy, InFocus is happy. That’s why
every InFocus projector comes with a standard
two-year limited factory warranty (including parts

and labor) and a 90-day lamp-replacement warranty.

Ships standard with

Wireless Navigator IR Remote Control

(including batteries)

Power cord (national and regional variants)

M1-A analog computer cable with USB

Composite video cable

Audio cable

Projector System CD

Multi-language User Guide, Quick Start

Guide, ProjectorManager control software,
ProjectorManager Installation Guide,
ProjectorManager User Guide

Quick Start Card

Lens cap

User Guide

Safety instructions/warnings

Optional Accessories

Projection Screens
Performance Cables
Enhanced Remote Controls
Universal Travel Cases

For more information about the LP70+,
any InFocus business projector, optional
accessories, or service programs please
visit: www.infocus.com
