Infinity NV32, NV31CK, NV30CK, NV31K, NV30K User Manual

Owner’s Guide

Manual del usuario

Guide d’utilisation

NV28 | NV29 | NV30K | NV30CK

NV31K | NV31CK | NV32

Thank you for

English

Contents

purchasing the
Infinity Upright
Vacuum.

Important Safety Instructions 2

Getting Started 4

Using the Vacuum 6

Transporting the Vacuum 7

Cleaning with the Vacuum Accessories 8

Emptying the Dust Cup Assembly 10

Proper Care of Your Infinity Upright Vacuum 11

Troubleshooting 12

Checking for Blockages 13

Maintenance 14

Warranty and Registration 16

TOLL FREE: 1-888-668-9600

www.infinityvac.com 1

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS For Household Use Only

When using an electrical appliance, basic
safety precautions should always be
observed, including the following:

READ ALL INSTRUCTIONS BEFORE
USING YOUR INFINITY UPRIGHT
VACUUM.

WARNING:

To reduce the risk of electric shock,
the two-pronged power cord plug
is polarized [one prong is larger
than the other]; it will fit into the
outlet only one way. DO NOT
force into outlet or try to modify
to fit.

WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK OR INJURY.

DO NOT USE OUTDOORS OR ON WET SURFACES:

General Electrical Safety:

Unplug from electrical outlet when not in use and before servicing.

DO NOT use vacuum with a damaged cord or plug.
DO NOT pull or carry vacuum by the cord.
DO NOT unplug by pulling on cord; to unplug, grasp the plug, not the cord.
DO NOT handle plug or vacuum cleaner with wet hands.
DO NOT run the vacuum over the power cord.
DO NOT use the cord as a handle.
DO NOT close a door on the cord.
DO NOT pull cord around sharp corners.
DO NOT leave appliance when plugged in.

Keep cord away from heated surfaces.
Turn off all controls before plugging or unplugging vacuum cleaner.

Hose Attachments:
DO NOT use if air flow is restricted; if the air paths, the hose, or the extension

tube become blocked, turn the vacuum cleaner off. Remove all obstructions
before you turn on the unit again.

Keep the end of the hose, wands and other openings away from face and body.
Keep rotating brush and suction openings away from hair, face, fingers,

uncovered feet or loose clothing.
Only use manufacturer’s recommended attachments.

General Use:

Use only as described in this manual.
DO NOT put any objects into openings.
Keep your work area well lit.
Keep the vacuum moving over the carpet surface at all times to avoid damaging

the carpet fibers.

DO NOT place vacuum on unstable surfaces such as chairs or tables.
DO NOT allow young children to operate the vacuum or use as a toy.
DO NOT use vacuum cleaner if it has been dropped, damaged, left outdoors, or

submerged in water. Return to EURO-PRO Operating LLC for examination, repair,
or adjustment.

2 TOLL FREE: 1-888-668-9600

Cyclonic Chamber/Dust Cup/Filters:

Before turning on the vacuum:

• Make sure that dust cup, cyclonic chamber and all filters are in place after
routine maintenance.

• Make sure that all components and filters are thoroughly dry after routine
cleaning.

• Only use filters and accessories provided by EURO-PRO Operating LLC
[Failure to do so will void the warranty.]

General Cleaning:
DO NOT run the vacuum over large-sized objects.
DO NOT pick up hard or sharp objects such as glass, nails, screws or coins that

could damage the vacuum cleaner.
DO NOT pick up smoking or burning objects such as hot coals, cigarette butts, or

matches.
DO NOT pick up flammable or combustible materials such as lighter fluid,

gasoline, kerosene or use in areas where they may be present.
DO NOT pick up toxic solutions such as chlorine bleach, ammonia, or drain

cleaner.
DO NOT use in an enclosed space where vapors are present from paint, paint

thinner, moth-proofing substances, flammable dust or other explosive or toxic
materials.

DO NOT vacuum up any liquids.
DO NOT immerse vacuum cleaner in water or other liquids.
DO NOT use outdoors or on wet surfaces; use only on dry surfaces.

Use extra care when cleaning on stairs.

English

3www.infinityvac.com

Getting Started

1

a

b

c

d

e

f

g

*h *i

Along with your upright unit, you will
find the following components:

a Detachable Handle (Ergonomic Grip)
b Telescopic Wand
c Cleaning Attachments
d Upper Hose Holder
e Extra Filters
f Super Stretch Hose
g Spare Motor Belt

*

Note: depending on the model you

select, your Infinity comes with a Pet Hair

h

Power Brush (
Brush (

) and Low Reach Bare Floor

i

) that are kept in a separate

accessory bag.

2

3

Your Infinity Upright is a snap to
assemble:

1 Lock into upright position.
2 Attach the Upper Hose Holder: use a

Phillips Head screwdriver to remove
the screw attached to the vacuum
body.

3 Place the Upper Hose Holder into the

slot; screw the holder onto the
vacuum body.

5

4

4 Slide the Telescopic Wand into the

upright unit to click in place.

5 Slide the Detachable Handle onto

the Telescopic Wand.

4 TOLL FREE: 1-888-668-9600

English

6

6 Attach each end of the Super Stretch

Hose to the vacuum and press into
Upper Hose Holder for easy storage.

IMPORTANT:
To prevent vacuum
from tipping, secure
hose in lower holder.

77

7 Store Crevice Tool and Upholstery/

Dusting Brush on the unit.

8

8 When storing your vacuum, wind

cord around the two cord holders
and secure with cord clip:

• Quick Cord release at the top of
the unit – place in the upright
position.

• Second holder [fixed] near the
base.

To release the cord, turn the Quick
Cord release to the left or right.

5www.infinityvac.com
