PRIMUS THEATER PACK II
Owner’s Guide
PRIMUS THEATER PACKIIOWNER’S GUIDE
Table of Contents
3 Introduction
3 Unpacking the System
3 Planning Your System
4 Placement
4 Wall-Mounting the Satellites
5 Center and Satellite Speaker Connections
6 Operation
6 Maintenance and Service
7 Specifications
2
PRIMUS THEATER PACK II
INTRODUCTION
PLANNING YOUR SYSTEM
Infinity Primus®Series
The Primus Series of loudspeakers continues Infinity’s
longstanding commitment to accurate sound reproduction.Our
proprietary Metal Matrix Diaphragm
™
(MMD®) drivers, precision
dividing networks and rigid, well-braced enclosures combine to
deliver uncompromised performance in any stereo or multichannel
home theater system. In addition, Primus Series speakers are
magnetically shielded for safe placement adjacent to a television.
Unpacking the System
Carefully unpack the system. If you suspect damage from transit,
report it immediately to your dealer and/or delivery service. Keep
the shipping carton and packing materials for future use.Open
the package and verify the following contents:
(1) Center
Before deciding where to best place your speakers, survey your room
and study Figures 1 and 2.
Optional Infinity
Subwoofer
Right
Front
Channel
Right
Surround
Channel
Left
Surround
Channel
Front
Channel
Left
Center
Channel
Couch
Figure 1. In this overhead view of a typical installation, satellite speakers
are used to reproduce sound for the front and surround channels.The
center channel reproduces sound and dialogue.The powered subwoofer
provides bass for effects and music.
Optional Infinity
Subwoofer
Left
Front
Channel
Right
Front
Channel
Center
Channel
Right
Surround
Channel
(4) Satellite Speakers
(20) Rubber Feet
••••••••••
••••••••••
Couch
Left
Surround
Channel
Figure 2.This figure shows an alternative layout,which may be more
suitable for some rooms.
PRIMUS THEATER PACK II
3
