2018 QUICK REFERENCE GUIDE
Page 2
To view detailed instructional videos, go to
www.infinitiownersinfo.mobi/2018/q70
or snap this barcode with an
appropriate barcode reader.
Helpful Resources
BELOW IS A LIST OF HELPFUL RESOURCES THAT CAN BE USED TO LEARN MORE ABOUT THE VEHICLE’S SYSTEMS AND FEATURE OPERATIONS.
• VEHICLE OWNER’S MANUAL
• INFINITI CLIENT SUPPORT
Support is always available if your Infiniti retailer cannot assist you or you would
like to provide INFINITI directly with comments or questions.
• INFINITI ROADSIDE ASSISTANCE 1-800-662-6200 (option 1)
As part of the Infiniti Total Ownership Experience®, Roadside Assistance
is available to you, 24 hours a day 365 days a year, for emergency
roadside assistance.
• INFINITI ELITE® EXTENDED PROTECTION PROGRAM
1-800-662-6200
Infiniti Elite® Assurance Products provide you with quality long-term protection and
enhanced peace of mind.
• INFINITI FINANCIAL SERVICES CLIENT SUPPORT
1-800-627-4437
For client support with your Infiniti Financial Services loan or lease.
• INFINITI FINANCIAL SERVICES www.infinitifinance.com
Use the IFS Online Account Manager to check your account status, schedule
recurring payments and access important forms.
1-800-662-6200
• OWNER PORTAL 1-855-444-7244
www.owners.InfinitiUSA.com/iowners
Your Infiniti Owner Portal account contains your personal preferences, vehicle
information and links to key vehicle features and services.
• INFINITI INTOUCH™ 1-855-444-7244 usa.infinitiintouch.com
The suite of services that is your direct link to personal security, convenience
and confidence.
• SiriusXM® RADIO 1-877-447-0011
For support with your SiriusXM® subscription.
• INFINITI USA.COM www.InfinitiUSA.com/bluetooth
Reference this site for a list of compatible cellular phones and instructions on how
to pair your cellular phone to your vehicle.
• INFINITI ELECTRONIC QUICK REFERENCE GUIDE
(use the Quick Response (QR) code or URL on this page or on the back cover)
Page 3
Table of Contents
Cockpit Overview ....................................................................................1
Instrument Panel .................................................................................... 3
Meters and Gauges ............................................................................... 5
Connecting your Cellular Phone or Device via Bluetooth
Bluetooth
Cruise Control ......................................................................................... 8
Navigation System (if so equipped) ................................................... 9
Infiniti Intelligent Key System ...........................................................10
Fuel-filler Door ......................................................................................10
Seat Adjustments .................................................................................10
Additional information about your vehicle is also available in your Owner’s Manual, InTouch™ Owner’s Manual and at www.InfinitiUSA.com.
®
Streaming Audio ............................................................... 7
®
.......... 7
Locking and Unlocking your Vehicle via the Door Handle .........11
USB Connection Port .......................................................................... 11
Brightness Control Switches ............................................................. 11
Exterior Light Operation ....................................................................12
Windows.................................................................................................12
Clock Set/Adjustment ........................................................................13
Trip Computer ....................................................................................... 13
Wiper and Washer Switch .................................................................14
Voice Recognition.................................................................................14
Infiniti InTouch
™
Services (if so equipped) .......................................15
PLEASE SEE YOUR OWNER’S MANUAL FOR IMPORTANT SAFETY INFORMATION AND SYSTEM OPERATION LIMITATIONS.
• A cellular telephone should not
be used for any purpose while
driving so full attention may be
given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not
replace proper seat belt usage.
• Children 12 and under
should always ride in the
rear seat properly secured
in child restraints or seat
belts according to their age
and weight.
• Do not drink and drive.
For more information, refer to the “Safety — Seats,
seat belts and supplemental restraint system (section
1)”, the “Display screen, heater and air conditioner,
and audio system (section 4)” and the “Starting and
driving (section 5)” of your Owner’s Manual.
Page 4
Cockpit Overview
7
5
4
8
9
10
1
6 6
3
2
1
Page 5
Cockpit Overview
1
Dynamic Driver Assistance (DDA) switch (if so equipped)
2
Intelligent Cruise Control (ICC) switches (if so equipped)
3
Wiper and washer switch
4
Trip computer controls and reset button (behind the steering wheel)
5
Vehicle information display
6
Paddle shifters
7
Vehicle information display brightness controls (behind the steering wheel)
8
Combined turn signal / headlight control switch
9
Menu control switches and audio control switches
10
Bluetooth® control switches and audio control switches
2
Page 6
Instrument Panel
7
11
9
10
1
6
8
2
3
4
5
3
Page 7
Instrument Panel
1
Multi-function control touch-screen / RearView Monitor display / Around View® Monitor
(AVM) display (if so equipped)
2
Climate control panel
• Heater and air conditioning (automatic)
• Front/Rear window defroster
3
Navigation control panel
4
Audio control panel
5
Shift lever
6
Push-button ignition system (behind the steering wheel)
7
Adaptive Front Lighting system switch (behind the steering wheel)
8
Tilt/Telescopic steering wheel switch (behind the steering wheel)
9
Parking brake
10
Hood latch release
11
Lower switch bank
• Vehicle Dynamic Control (VDC)
OFF switch
• Trunk release
• Rear sunshade switch (if so equipped)
• Warning Systems switch (if so equipped)
• Heated steering wheel switch (if so equipped)
4
Page 8
Meters and Gauges
1
5
2
3
4
5
6
Page 9
Meters and Gauges
1
Engine coolant temperature gauge
2
Tachometer
3
Shift lever indicator
4
Vehicle information display
5
Speedometer
6
Fuel gauge
6
Page 10
Connecting your Cellular Phone
or Device via Bluetooth
Using Bluetooth® technology, you can
connect (pair) your cellular phone with the
in-vehicle system for hands-free use of
your cellular phone.
1. Press the SETTING button on the
2. Touch the “Phone/Mail” key.
3. Touch “Connect Device”.
4. Touch “Add New (X/5 Free)”.
5. When a PIN appears on the screen,
For any Bluetooth® connectivity issues, reboot your cellular phone or device.
* Some jurisdictions prohibit the use of cellular telephones while driving.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
®
*
control panel.
operate the Bluetooth
enter/confirm the PIN.
®
device to
Bluetooth® Streaming Audio
*
1
If you have a compatible Bluetooth® device with streaming
audio (A2DP and AVRCP profiles), you can set up a wireless
connection between your Bluetooth® device and the in-vehicle
audio system, enabling you to listen to the audio from your
device through the vehicle’s audio system.
After connecting your Bluetooth
1
button
Streaming Audio.
For any Bluetooth
phone or device.
* Some jurisdictions prohibit the use of cellular telephones while driving.
Please see your Owner’s Manual for important safety information, system
limitations, and additional operating and feature information.
on the control panel to switch to Bluetooth®
®
connectivity issues, reboot your cellular
®
device, press the MEDIA
7
Page 11
Cruise Control
SETTING A CRUISING SPEED
• Press the CRUISE ON/OFF switch 1 to turn on the system.
• With the vehicle at the desired speed, push down the switch 2 to COAST/SET to
enable cruise control.
• The cruising speed can be adjusted to a higher or lower speed by toggling the
control switch 2 up or down.
CANCELING THE PRESET SPEED
• Push the CANCEL switch
INTELLIGENT CRUISE CONTROL (ICC) (if so equipped)
The ICC system is designed to maintain a selected distance from the vehicle in front of
you and reduce the speed to match a slower vehicle ahead.
• To increase the distance to the vehicle ahead to be maintained by the ICC system,
push the distance switch
is shown by the number of lines on the set distance indicator 5.
• When a vehicle is detected ahead, a car icon will illuminate on the vehicle ahead
detection indicator
slower vehicle.
To use Conventional (fixed speed) Cruise Control mode (if so equipped):
• While cruise control is off, push and hold the CRUISE ON/OFF switch 1 for more
than 1.5 seconds. The CRUISE indicator light will illuminate.
• Accelerate to the desired speed.
• Push the switch 2 down toward COAST/SET and release it. The SET indicator
light will illuminate.
Please see your Owner’s Manual for important safety information, system limitations, and additional operating and
feature information.
3
or tap the brake pedal.
4
until the display shows the desired set distance, which
6
and your vehicle will reduce the speed to match the
CONVENTIONAL CRUISE CONTROL (if so equipped)
3
2
1
INTELLIGENT CRUISE CONTROL (ICC) (if so equipped)
3
4
2
1
6
5
8
Page 12
Navigation System (if so equipped)
5
4
3
1
2
Use the Infiniti controller 1 and ENTER button 2 to navigate through the center display screen.
• Press the BACK button 3 to return to the previous screen.
• Press the MAP button 4 to display the map.
SETTING A ROUTE
To set a route, first ensure that the correct region is selected on the touch-screen.
5
1. Press the NAVI button
2. Touch the “Destination Menu” key
3. Select the preferred destination setting method.
4. Enter the address number, street name, and city as prompted by the screen.
CANCELING A ROUTE
1. Press the NAVI button 5 on the Infiniti controller.
2. Touch the “Cancel Route” key 7.
Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.
on the Infiniti controller.
6
on the display.
6
7
9
Page 13
Infiniti Intelligent Key System
ROLL DOWN FEATURE
The windows can be opened remotely using your
Infiniti Intelligent Key.
• Press and hold the unlock button
open the windows and moonroof (if so
equipped) remotely.
• If the unlock button
windows will stop. To resume the roll
down feature, press and hold the unlock
1
button
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating and
feature information.
again.
1
is released, the
1
to
Seat Adjustments
POWER SEAT ADJUSTMENTS
• To slide the seat forward or
backward, push the
switch 1 forward or backward.
• To recline the seatback, push the
1
or backward.
SEAT LIFTER
• To adjust the angle of the front portion or height of the seat,
push the front or rear end of the switch
POWER LUMBAR SUPPORT
• To adjust the seat lumbar support, push the front or back end of
the switch
switch
2
forward
3
.
1
1
3
2
up or down.
Fuel-filler Door
To open the fuel-filler door, unlock the
vehicle and gently push the rearward
side of the fuel-filler door.
Please see your Owner’s Manual for important
safety information, system limitations, and additional
operating and feature information.
AUTOMATIC ENTRY/
EXIT FUNCTION
• To turn on and off the automatic
entry/exit function, with the
vehicle in P (Park) and the
ignition switch in the OFF
position, press and hold the SET switch 4 for more than
10 seconds.
Please see your Owner’s Manual for important safety information, system limitations, and
additional operating and feature information.
4
10
Page 14
Locking and Unlocking your
Vehicle via the Door Handle
To use the door handles to lock and
unlock your vehicle, make sure the
1
Intelligent Key is with you (that is, in
your pocket or purse).
• Push the door handle request
1
switch
corresponding door.
• Push the door handle request
switch
unlock the rest of the doors.
• To lock the vehicle, push either door
handle request switch
to unlock the
1
again within 1 minute to
1
once.
USB Connection Port
• The USB ports
located in the center
console under the armrest.
Compatible audio and
video files stored on a
USB device can be played
through the vehicle’s audio
system and front display.
Please see your Owner’s Manual for important safety information, system
limitations, and additional operating and feature information.
1
are
Brightness Control Switches
1
To change the settings for the door locking and
unlocking system, press the SETTING button
select the “Others” key, and select the “Comfort”
key on the display.
• To unlock all doors by touching the
inside of the door handle, select
“Selective Door Unlock”.
• To disable unlocking by touching the inside of the door handle, select
“Touch Sensitive Door Sensor”.
Please see your Owner’s Manual for important safety information, system limitations, and
additional operating and feature information.
11
Use these switches to adjust
2
,
2
the brightness of the vehicle
information display.
• To increase the brightness,
1
push the upper switch
• To decrease the brightness,
push the lower switch
Please see your Owner’s Manual for
important safety information, system
limitations, and additional operating and
feature information.
.
2
.
1
2
Page 15
Exterior Light Operation Windows
1
2
3
4
1
OFF position
2
Automatic headlight mode ON position (headlights switch on/off
automatically depending on ambient light conditions/daytime running
light system)
3
Side lights, license plate lights and combination meter lighting ON position
4
Headlight ON position
5
Front fog light switch
6
Push the headlight switch forward for the high beams.
7
Pull the headlight switch rearward to flash the high beams.
For normal headlight operation, leave the exterior light switch in the AUTO
position
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
2
.
5
6
2
7
All power windows can be operated through the main
switch on the driver’s door.
1
Power windows open/close
2
Disable rear passenger window operation by
rear passengers
Please see your Owner’s Manual for important safety information, system
limitations, and additional operating and feature information.
1
12
Page 16
Clock Set/Adjustment
1
Trip Computer
1
3
To adjust the time and the appearance of the clock on the display:
Press the SETTING button
Locate and touch the “Clock” key to adjust “On-Screen Clock”, “Daylight Savings Time”,
“Clock Format (24h)”, and “Time Zone” on the display.
The time can be adjusted through “Offset Adjustment”
and/or hours forward or backward. The current clock time can be set up to a
difference of 12 hours and 59 minutes.
ANALOG CLOCK
To set the clock forward, press the button
To set the clock backward, press the button 4.
Please see your Owner’s Manual for important safety information, system limitations, and additional operating and
feature information.
13
1
on the control panel.
3
4
2
2
by adjusting the minutes
.
3
When the button
pressed, the following modes
will appear on the vehicle
information display
• MPG
• MPG/MPH
• TIME/MILES
• RANGE
To reset the elapsed time/miles, press and hold the
3
button
time/miles will reset at the same time.
Please see your Owner’s Manual for important safety information,
system limitations, and additional operating and feature information.
for more than 1 second. Both elapsed
1
is
2
:
• OUTSIDE TEMP
• SETTING
• WARNING
2
Page 17
Wiper and Washer Switch
2
1
Voice Recognition
1
Move the lever
the following positions to operate the
windshield wipers:
One sweep operation
MIST
OFF Wipers are OFF
AUTO Rain-sensing automatic wipe
LO Continuous wipe, slow
Continuous wipe, fast
HI
To adjust the wiper sensitivity for the AUTO
setting, twist the control ring
Pull the lever
windshield washer.
To turn the rain-sensing automatic wiper
system off, push up the lever to the OFF
position, or pull down the lever to the LO or
HI position.
Please see your Owner’s Manual for important safety information, system limitations, and additional operating
and feature information.
1
up or down to one of
2
.
1
toward you operate the
PULLING UP THE WIPER ARM
The wiper arm should be in the UP
position when replacing the wiper.
• With the shift lever in the
P (PARK) position, place
the ignition switch in the
OFF position.
• Within 1 minute, push the
wiper switch to the MIST
position twice. The wiper
operation stops in midoperation and the wiper arm
can be pulled up.
• To return the wiper arm, place
the wiper arm in the DOWN
position and operate the wiper
switch once.
SYSTEM OPERATING TIPS
• The interior of the vehicle should be as quiet
as possible.
• Speak naturally. Speaking too fast, too slow, too
soft, or too loud makes voice recognition
more difficult.
• Confirm that the correct voice commands are
being used. Glance at the screen to see the currently
available commands.
USING THE VOICE RECOGNITION SYSTEM
• Press the
list of commands will appear on the screen.
• After the tone sounds, speak the command.
• To skip the voice prompt and give the command
immediately, press the button
wheel to interrupt the system. Speak the next
command after the tone sounds.
• To cancel the command, press and hold the button
1
on the steering wheel.
Please see your Owner’s Manual for important safety information, system
limitations, and additional operating and feature information.
button
1
on the steering wheel, and a
1
on the steering
14
Page 18
Infiniti InTouch™ Services (if so equipped)
Infiniti InTouch ™ Services combine personalized convenience settings and personal
security features to compliment the Total Ownership Experience®. For more details on
Infiniti InTouch Services or to enroll your vehicle, please visit
usa.infinitiintouch.com or call 1-855-444-7244.
1
To access Infiniti InTouch Services:
1
Press the INFO button on the Infiniti controller.
2
Select the “InTouch Services” key on the display.
In case of an emergency, press the invehicle telematics SOS button 3, located
3
Please see your Owner’s Manual for important safety information, system limitations, and additional operating and
feature information.
above and in front of the rearview mirror.
2
15
Available services include, but are not limited to:
• Automatic Collision Notification
• Alarm Notification
• Maintenance Alert
• Scheduled Maintenance Notification
• Report Stolen Vehicle
• Emergency Call
• Enhanced Roadside Assistance
• My Schedule
• Infiniti Personal Assistant
• Destination Send-to-Vehicle
• Connected Search
• Drive Zone
• Maximum Speed Alert
• Mobile Information Service
• Valet Alert
INFINITI INTOUCH SERVICES ENROLLMENT
1. Create an Infiniti Owner Portal account.
(https://owners.infinitiusa.com/iowners/)
2. From within your Infiniti Owner Portal account,
enroll in Infiniti InTouch Services.
3. Download the Infiniti InTouch Services companion
app from the App store and login using your Infiniti
Owner Portal ID and Password.
Page 19
Memo
Page 20
Printing June 2017
QR18EA 0Y51U0
Printed in USA
This Quick Reference Guide is intended to provide an overview of some of
the unique features of your new vehicle. Please see your Owner’s Manual
for important safety information and system operation limitations.
Features and equipment in your vehicle may vary depending on model,
trim level, options selected, order, date of production, region or availability.
Therefore, you may find information about features or equipment that
are not included or installed on your vehicle.
All information, specifications and illustrations in this Quick Reference
Guide are those in effect at the time of printing. INFINITI reserves the
right to change specifications, performance, design or component
suppliers without notice and without obligation. From time to time,
INFINITI may update or revise this Quick Reference Guide to provide
owners with the most accurate information currently available. Please
carefully read and retain, with this Quick Reference Guide, all revision
updates sent to you by INFINITI to ensure you have access to accurate
and up-to-date information regarding your vehicle. Current versions
of vehicle Quick Reference Guides, Owner’s Manuals and any updates
can also be found in the Owner section of the INFINITI website at
https://owners.infinitiusa.com/iowners/navigation/manualsAndGuides.
If you have questions concerning any information in your Owner’s Manual,
contact INFINITI Client Support (see contact information listed above).
To view detailed instructional videos, go to
www.infinitiownersinfo.mobi/2018/q70 or snap
this barcode with an appropriate barcode reader.
Loading...
