Infiniti Q70 2014 User Manual

Page 1
For your safety, read carefully and keep in this vehicle.
2014 Infiniti Q70 Hybrid
Owner’s Manual
Page 2
Foreword
Your INFINITI represents a new way of thinking about vehicle design. It integrates advanced engineering and superior crafts­manship with a simple, refined aesthetic sensitivity associated with traditional Ja­panese culture.
The result is a different notion of luxury and beauty. The car itself is important, but so is the sense of harmony that the vehicle evokes in its driver, and the sense of satisfaction you feel with the INFINITI from the way it looks and drives to the high level of retailer service.
To ensure that you enjoy your INFINITI to the fullest, we encourage you to read this Owners Manual immediately. It explains all of the features, controls and perfor­mance characteristics of your INFINITI; it also provides important instructions and safety information.
A separate Warranty Information Booklet is included in your Owners literature portfolio. The INFINITI Service and Main­tenance Guide explains details about maintaining and servicing your vehicle. Always carry it with you when you take your vehicle to an INFINITI retailer. The Warranty Information Booklet contents provide complete information about all
warranties covering this vehicle, the re­quirements to keep the warranties in effect as well as the INFINITI Roadside Assis­tance program.
Additionally, a separate Customer Care and Lemon Law Information Booklet will explain how to resolve any concerns you may have with your vehicle, as well as clarify your rights under your state’s lemon law.
In addition to factory installed options, your vehicle may also be equipped with additional accessories installed by INFINITI or by your INFINITI retailer prior to delivery. It is important that you familiarize yourself with all disclosures, warnings, cautions and instructions concerning proper use of such accessories prior to operating the vehicle and/or accessory. See an INFINITI retailer for details concerning the particu­lar accessories with which your vehicle is equipped.
READ FIRST THEN DRIVE SAFELY
Before driving your vehicle, read your Owners Manual carefully. This will ensure familiarity with controls and maintenance requirements, assisting you in the safe operation of your vehicle.
WARNING
IMPORTANT SAFETY INFORMATION REMIN­DERS FOR SAFETY!
Follow these important driving rules to help ensure a safe and comfortable trip for you and your passengers!
. NEVER drive under the influence of
alcohol or drugs.
. ALWAYS observe posted speed limits
and never drive too fast for conditions.
. ALWAYS give your full attention to
driving and avoid using vehicle features or taking other actions that could dis­tract you.
. ALWAYS use your seat belts and appro-
priate child restraint systems. Pre-teen children should be seated in the rear seat.
Page 3
. ALWAYS provide information about the
proper use of vehicle safety features to all occupants of the vehicle.
. ALWAYS review this Owners Manual for
important safety information.
IMPORTANT INFORMATION ABOUT THIS MANUAL
You will see various symbols in this manual. They are used in the following ways:
MODIFICATION OF YOUR VEHICLE
This vehicle should not be modified. Modification could affect its performance, safety or durability, and may even violate governmental regulations. In addition, damage or performance problems result­ing from modification will not be covered under the INFINITI warranties.
WHEN READING THE MANUAL
This manual includes information for all options available on this model. Therefore, you may find some information that does not apply to your vehicle.
All information, specifications and illustra­tions in this manual are those in effect at the time of printing. INFINITI reserves the right to change specifications or design at any time without notice.
WARNING
This is used to indicate the presence of a hazard that could cause death or serious personal injury. To avoid or reduce the risk, the procedures must be followed precisely.
CAUTION
This is used to indicate the presence of a hazard that could cause minor or moderate personal injury or damage to your vehicle. To avoid or reduce the risk, the procedures must be followed carefully.
SIC0697
If you see the symbol above, it means Do not do this” or Do not let this happen”.
If you see a symbol similar to those above in an illustration, it means the arrow points to the front of the vehicle.
Arrows in an illustration that are similar to those above indicate movement or action.
Arrows in an illustration that are similar to
Page 4
those above call attention to an item in the illustration.
CALIFORNIA PROPOSITION 65 WARNING
WARNING
Engine Exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
CALIFORNIA PERCHLORATE ADVI­SORY
Some vehicle parts, such as lithium batteries, may contain perchlorate materi­al. The following advisory is provided: Perchlorate Material - special handling may apply, See www.dtsc.ca.gov/ hazardouswaste/perchlorate.
Bluetooth®is a trademark owned by Bluetooth SIG, Inc. and licensed to Visteon Cor­poration and Clarion Co., Ltd.
SiriusXM Satellite Radio requires subscription, sold separately. Not available in Alaska, Hawaii or Guam. For more information, visit www.siriusxm.com.
© 2013 NISSAN MOTOR CO., LTD. All rights reserved. No part of this Owners
Manual may be reproduced or stored in a retrieval system, or transmitted in any form, or by any means, electronic, mechan­ical, photocopying, recording or otherwise, without the prior written permission of Nissan Motor Co., Ltd.
Page 5
INFINITI CUSTOMER CARE PROGRAM
INFINITI CARES ... Both INFINITI and your INFINITI retailer are dedicated to serving all your automotive needs. Your satisfaction with your vehicle and your
INFINITI retailer are our primary concerns.Your INFINITI retailer is always available to assist you with all your automobile sales and service needs.
However, if there is something that your INFINITI retailer cannot assist you with or you would like to provide INFINITI directly with comments or questions, please con­tact our (INFINITIs) Consumer Affairs De­partment using our toll-free number:
For U.S. customers
1-800-662-6200
For Canadian customers
1-800-361-4792
The Consumer Affairs Department will ask for the following information:
. Your name, address, and telephone
number
. Vehicle identification number (on dash
panel)
. Date of purchase . Current odometer reading . Your INFINITI retailers name . Your comments or questions
OR You can write to INFINITI with the informa-
tion on the left at:
For U.S. customers
INFINITI Division Nissan North America, Inc. Consumer Affairs Department P.O. Box 685003 Franklin, TN 37068-5003 or via e-mail at: nnaconsumeraffairs@nissan-usa.com
For Canadian customers
INFINITI Division Nissan Canada Inc. 5290 Orbitor Drive Mississauga, Ontario L4W 4Z5 or via e-mail at: information.centre@nissancanada. com
If you prefer, visit us at: www.infinitiUSA.com (for U.S. customer) or www.infiniti.ca (for Canadian customers) We appreciate your interest in INFINITI and
thank you for buying a quality INFINITI vehicle.
Page 6

Table of Contents

Hybrid System Overview
Illustrated table of contents
Hybrid System
0
Safety Seats, seat belts and supplemental restraint system
Instruments and controls
Pre-driving checks and adjustments
Monitor, climate, audio, phone and voice recognition systems
Starting and driving
In case of emergency
Appearance and care
Maintenance and do-it-yourself
Technical and consumer information
Index
1
2
3
4
5
6
7
8
9
10
Page 7
Page 8
Hybrid System Overview
Infiniti Direct Response
®
Hybrid
Lithium-ion (Li-ion) battery............... Hybrid System-2
High voltage cautions...................... Hybrid System-2
Road accident cautions.................... Hybrid System-3
Emergency shut-off system.............. Hybrid System-4
Operation of the hybrid system ....... Hybrid System-4
System............................... Hybrid System-2
Starting and slow speed driving ... Hybrid System-4
Medium or high speed driving..... Hybrid System-4
Rapid acceleration....................... Hybrid System-5
Deceleration and braking............. Hybrid System-5
Stopping ..................................... Hybrid System-5
Energy monitors .............................. Hybrid System-5
Assist charge gauge................... Hybrid System-5
Energy Flow (models with
navigation system)..................... Hybrid System-5
Fuel economy history (models with
navigation system)..................... Hybrid System-7
Regenerative brake ......................... Hybrid System-8
Efficient use of your vehicle ............ Hybrid System-8
Approaching Vehicle Sound for
Pedestrians (VSP) system................ Hybrid System-9
Hybrid vehicle precautions............ Hybrid System-10
High voltage components ........ Hybrid System-10
Hybrid
vehicle characteristics.............. Hybrid System-11
Page 9
INFINITI DIRECT RESPONSE HYBRID
®
SYSTEM
The INFINITI Direct Response Hybrid System combines the power of a gasoline engine and an electric motor to help minimize fuel consumption and emissions.
Depending on driving conditions, the vehicle runs on a combination of the gasoline engine and the electric motor, whichever is best for those conditions.
Because the gasoline engine charges the Lithium-ion (Li-ion) battery as needed, the battery does not have to be charged from an outside source like an all-electric vehicle.
LITHIUM-ION (Li-ion) BATTERY HIGH VOLTAGE CAUTIONS
®
WARNING
Your vehicle contains a sealed Lithium ion (Li-ion) high voltage battery. If the Li-ion battery is disposed of improperly, there is a risk of severe burns and electrical shock that may result in serious injury or death and there is also a risk of environmental damage.
CAUTION
. Do not misuse the Li-ion battery. . Do not use the Li-ion battery for any
other purpose.
The Li-ion battery is used to drive the electric motors in the INFINITI Direct Response Hybrid
The Li-ion battery has a limited service life. Contact your INFINITI retailer for informa­tion about recycling or disposal of the battery.
®
System.
. The INFINITI Direct Response Hybrid
System uses high voltage up to approxi­mately 408 volts. The system can be hot during and after starting. Be careful of both the high voltage and the high temperature. Obey the warning labels attached to the vehicle.
. Never disassemble, remove or replace
high-voltage parts and harnesses as well as their connectors. Doing so can cause severe burns or electric shock that may result in serious injury or death. High-voltage harnesses are colored or­ange. The vehicle high voltage system has no user serviceable parts. Take your vehicle to an INFINITI retailer for any necessary maintenance.
. Never try to remove the service plug
located in the trunk. The service plug is used only when the vehicle is serviced by trained technicians wearing personal protection equipment and is part of the high voltage system. Touching the ser­vice plug can cause severe burns or electric shock that may result in serious injury or death.
WARNING
®
Hybrid System-2 Hybrid System Overview
Page 10
ROAD ACCIDENT CAUTIONS
WARNING
In case of a collision:
. If your vehicle is drivable, pull your
vehicle off the road, put the transmis­sion in the P (Park) position, apply the parking brake and turn the INFINITI Direct Response Hybrid
. Check to see if there are exposed high
voltage parts and cables. Never touch the parts and cables. For their locations, see High voltage components(P.Hy­brid System-10). To avoid personal in­jury, never touch high-voltage wiring, connectors, and other high-voltage parts, such as electric motor inverter and Lithium ion (Li-ion) battery. An electric shock may occur if exposed electric wires are visible when viewed from inside or outside of your vehicle. Therefore, never touch exposed electric wires.
. If the vehicle receives a strong impact to
the floor while driving, stop the vehicle in a safe location and check the floor.
. Inspect the ground under the vehicle. If
liquid has leaked onto the ground, the
®
System off.
fuel system may have been damaged. Leave the vehicle as soon as possible.
. Leaks or damage to the Li-ion battery
may result in a fire. If you discover them, contact emergency services immedi­ately. Since the fluid leak may be lithium organic electrolyte from the Li-ion bat­tery, never touch the fluid leak inside or outside the vehicle. If the fluid contacts your skin or eyes, wash it off immedi­ately with a large amount of water and receive immediate medical attention to help avoid serious injury.
. If a fire occurs in the hybrid vehicle,
leave the vehicle as soon as possible. Only use a type ABC, BC or C fire extinguisher that is meant for use on electrical fires. Using water or the incorrect fire extinguisher can result in serious injury or death from electrical shock.
. If you are not able to safely assess the
vehicle due to vehicle damage, do not touch the vehicle. Leave the vehicle and contact emergency services. Advise 1st responders that this is a hybrid vehicle.
. In the event of an accident that requires
body repair and painting, the vehicle
should be delivered to an INFINITI retailer to have the Li-ion battery pack and high voltage parts such as the inverter, including the wiring harness, removed prior to painting. Li-ion battery packs exposed to heat in the paint booth will experience capacity loss. Damaged Li-ion battery packs may also pose safety risks to untrained mechanics and repair personnel.
Hybrid System Overview Hybrid System-3
Page 11
EMERGENCY SHUT-OFF SYSTEM OPERATION OF THE HYBRID SYSTEM
The emergency shut-off system is activated and the high-voltage system automatically turns off in the following conditions:
. Front and side collisions in which the
air bags are deployed.
. Certain rear collisions. . Certain INFINITI Direct Response Hy-
®
brid
System malfunctions
For the above collisions and the certain hybrid system malfunctions, the READY to drive indicator light will turn off. See Warning/indicator lights and audible re­minders(P.2-10).
The emergency shut-off activates for the above collisions to minimize risk of an event that could cause injury or an accident. If the emergency shut-off system activates, the hybrid system may not switched to READY to drive position, contact an INFINITI retailer. Even if the ignition switch is switched to READY to drive position, the system may shut-off suddenly. Therefore, drive cautiously to the nearest INFINITI retailer or contact an INFINITI retailer as soon as possible.
Hybrid System-4 Hybrid System Overview
To start the INFINITI Direct Response
®
Hybrid
1. Depress the brake pedal and place the
2. The READY to drive indicator light
When the READY to drive indicator light
driven, even if the gasoline engine is not running.
NOTE: The gasoline engine starts and stops
automatically. It may stop during low speed driving, deceleration or when the vehicle is stopped.
The gasoline engine may automatically run in the following conditions: . The level of remaining charge in the
System:
ignition switch in the ON position when the transmission is in the P (Park) or N (Neutral) position (P is recommended). (For more details, see Push-button ignition switch(P.5-9).)
flashes, then turns illuminated. (The hybrid system switched to the READY to drive mode when the indicator light illuminates.)
illuminates, the vehicle can be
Lithium ion (Li-ion) battery is low. The engine runs to charge the Li-ion battery and to provide power to the
drive the vehicle.
. The temperature of the engine coolant
is low.
. Based on driving conditions. . The shift lever is shifted to the P (Park)
position, the drivers seat belt is released and the drivers side door is then opened.
The hybrid system operates as follows based on driving conditions and the Li-ion battery charge.
STARTING AND SLOW SPEED DRIV­ING
The vehicle is driven by the electric motor depending on the available Li-ion battery charge.
MEDIUM OR HIGH SPEED DRIVING
The system automatically controls the gasoline engine and electric motor in order to obtain the optimum fuel mileage and performance, depending on the driving situation and available Li-ion battery charge.
When the remaining battery level is low, the Li-ion battery is charged by the electric motor that is driven to generate electric power while the vehicle is driving.
Page 12
RAPID ACCELERATION
The vehicle is accelerated using both the gasoline engine and the electric motor depending on the available Li-ion battery charge.
DECELERATION AND BRAKING
The Li-ion battery is charged by the electric motor that changes the energy of the rotating wheels into electric power. See Regenerative brake(P.Hybrid System-8).
STOPPING
The gasoline engine may stop running to save fuel depending on the available Li-ion battery charge.
ENERGY MONITORS
The INFINITI Direct Response Hybrid System monitors the status of power being sent to the electric motor and the Lithium ion (Li-ion) battery state of charge. The status is shown on the assist charge gauge in the meter and the energy flow/remain­ing Li-ion battery charge in the dot matrix display. System status can also be shown on the navigation system display (if so equipped) when the screen is in the energy flow mode or energy/fuel history mode.
®
JVO0001X
ASSIST CHARGE GAUGE
This meter displays the actual electric motor power consumption and the char­ging power to the Li-ion battery.
For additional information, See Assist charge gauge(P.2-8).
ENERGY FLOW (models with navi­gation system)
When you use this system, make sure the hybrid system is in the READY to drive mode. See Operation of the hybrid system(P.Hybrid System-4).
Hybrid System Overview Hybrid System-5
Page 13
If you use the system with the hybrid system off (ignition switch placed in the ACC position) for a long time, it will discharge the 12-volt battery power, and the hybrid system will not start.
Energy Flow for various operating modes can be displayed on the navigation system monitor.
Hybrid System-6 Hybrid System Overview
JVH0034M
Push the INFO button on the control panel and highlight the Energy Flowkey on the display using the INFINITI controller then push the ENTER button.
JVO0008M
This is an example of the Energy Flow display. The Energy Flow display changes, depending on the following operating conditions. The graphic indicates the amount of power in the Li-ion battery.
The following are displayed on the Energy Flow screen.
. When the vehicle is powered only by
the electric motor or gasoline engine.
. When the vehicle is powered by both
the electric motor and the gasoline engine.
. When the vehicle is charging the Li-ion
battery with the regenerative brake and gasoline engine.
Page 14
. When the vehicle is powered by the
gasoline engine and is charging the Li­ion battery.
. When there is no Energy Flow in the
vehicle
The Energy Flow and remaining Li-ion battery charge can be also shown on the dot matrix display. See Trip computer (P.2-28).
FUEL ECONOMY HISTORY (models with navigation system)
The Fuel Economy History screen appears in the display with the navigation system when the screen is in the Fuel Economy History mode.
JVH0034M
1. Push the INFO button on the control panel and highlight the Energy Flow key on the display using the INFINITI controller. Then push the ENTER button.
2. Highlight the Historykey, and push the ENTER button.
JVO0009M
The Fuel Economy History can be displayed on the navigation system monitor. This displays the vehicles average fuel con­sumption and regenerative electric power at 2 minute intervals.
The displayed values on the screen in­dicate general driving conditions. Accuracy varies with driving habits and road condi­tions.
1. Regenerated energy in the past 12 minutes: The regenerated energy in the past 12 minutes is indicated with symbols. One symbol indicates 30 watt-hour. The energy of 30 watt-hour illuminates a 30 watt bulb for an hour.
Hybrid System Overview Hybrid System-7
Page 15
REGENERATIVE BRAKE EFFICIENT USE OF YOUR VEHICLE
2. Fuel consumption in the past 12 minutes: Fuel consumption in the past 12 minutes is displayed.
3. Current fuel consumption (Latest col­umn): The current fuel consumption is calculated and displayed based on distance and fuel consumption.
NOTE: Information shown in the yellow column
means current (within 2 minutes) and information shown in the blue columns means past (more than 2 minutes).
When the vehicle decelerates while the vehicle is driven with the shift lever in the D (drive) position or in the manual shift mode, the Lithium ion (Li-ion) battery can be charged by the electric motor. The electric motor converts the energy of the rotating wheels into electric power under the following circumstances:
. When the accelerator pedal is released. . When the brake pedal is depressed . When there is no malfunction in the
brake system or the INFINITI Direct Response Hybrid
The regenerative brake may not work properly if the vehicle has tires and road wheels other than the ones specified in this manual.
®
System
Drive your vehicle with smooth accelera­tion and deceleration.
. While driving, energy is recovered
through the regenerative brake as the vehicle decelerates. However, for most efficient use, do not accelerate or decelerate your vehicle more than necessary.
. Avoid abrupt acceleration and decelera-
tion.
. The power of the Lithium ion (Li-ion)
battery can be checked on the Energy Flow in the center display (models with navigation system) or Li-ion battery status meter in the dot matrix display. See Energy Flow (models with naviga­tion system)(P.Hybrid System-5) or Trip computer(P.2-28). Gradual or non-abrupt acceleration and decelera­tion will make more effective use of the electric motor power, using less gaso­line engine power.
. When parking, be sure to place the shift
lever in the P (Park) position. While driving, place the shift lever in the D (Drive) position.
Hybrid System-8 Hybrid System Overview
Page 16
APPROACHING VEHICLE SOUND FOR PEDESTRIANS (VSP) SYSTEM
The Approaching Vehicle Sound for Pedes­trians (VSP) system is a function that uses sound to help alert pedestrians of the presence of the vehicle when it is being driven at a low speed in the electric drive mode under the following conditions:
. The sound starts when the vehicle
starts accelerating.
. The sound stops when the vehicle
speed is more than 19 MPH (30 km/h) while accelerating.
. The sound starts when the vehicle
speed is less than 16 MPH (25 km/h) while decelerating.
. The sound stops when the vehicle
stops.
. The sound does not stop with the
vehicle in the R (Reverse) position even if the vehicle stops.
The VSP system is automatically turned on when the vehicle is in the READY to drive mode.
If there is a malfunction in the VSP system, the VSP OFF indicator light in the meter illuminates. See Approaching Vehicle Sound for Pedestrians (VSP) OFF indicator light(P.2-18).
WARNING
. If the sound from the VSP system is not
heard while driving, stop the vehicle in a safe and quiet location. Open a window, and then place the vehicle in the R (Reverse) position with the brake pedal firmly depressed. Check that the operat­ing sound can be heard from the front side of the vehicle.
. If the sound cannot be heard, immedi-
ately contact an INFINITI retailer for inspection.
Hybrid System Overview Hybrid System-9
Page 17
HYBRID VEHICLE PRECAUTIONS
HIGH VOLTAGE COMPONENTS
WARNING
. The INFINITI Direct Response Hybrid
System uses high voltage up to approxi­mately 408 volts. The system can be hot while and after starting. Be careful of both the high voltage and the high temperature. Obey the warning labels attached to the vehicle.
. Never touch, disassemble, remove or
replace the high voltage parts, har­nesses and their connectors. High vol­tage harnesses are orange. Touching, disassembling, removing or replacing those parts and harnesses can cause severe burns or electric shock that may result in serious injury or death.
®
1. Electric motor inverter
2. High voltage harnesses (orange)
3. Lithium ion (Li-ion) battery
4. DC/DC converter
5. Service plug
JVO0011X
6. Electric compressor
7. Electric motor
8. 12-volt battery The hybrid system uses high voltage up to
approximately 408 volts. High voltage components are indicated in the illustra-
Hybrid System-10 Hybrid System Overview
Page 18
tion. High voltage harnesses are orange. The system can be hot while and after starting. Be careful of both the high voltage and the high temperature.
HYBRID VEHICLE CHARACTERISTICS
WARNING
. When you leave your vehicle, be sure to
place the ignition switch in the OFF position.
. Be sure to put the transmission in the P
(Park) position because the vehicle can move when the READY to drive indicator light is on even if the gasoline engine is not running. When the READY to drive indicator light is on, do not leave your vehicle in a shift position other than the P (Park) position. The vehicle will creep and start abruptly if the accelerator pedal is depressed by mistake. This may cause serious injury or death.
CAUTION
If the vehicle is parked for a long period of time, the battery discharges gradually. To
avoid this occurrence, drive the vehicle for approximately 30 minutes at least once every two to three months. Otherwise, the Lithium ion (Li-ion) battery may be da­maged. If the Li-ion battery is completely discharged and the hybrid system cannot be activated, contact an INFINITI retailer.
High voltage parts and harnesses on the hybrid vehicles emit approximately the same amount of electromagnetic waves as the conventional gasoline-powered ve­hicles or home electronic appliances de­spite of their electromagnetic shieldings. Unwanted noise may occur in the reception of a mobile two-way radio.
Charging the Li-ion battery while driving is important. The vehicle cannot run if the Li­ion battery is discharged. In the N (Neutral) position, the Li-ion battery does not recharge. Leaving the transmission in the N (Neutral) position for an extended period of time may discharge the Li-ion battery. The Li-ion battery recharges when the shift lever is in any position other than N (Neutral).
JVO0019X
An air vent shelf to cool the Li-ion battery. If the vent is covered, the battery will overheat resulting in reduced output performance of the hybrid system. See Lithium-ion (Li-ion) battery air vent(P.7-5).
A
is located on the rear parcel
*
Hybrid System Overview Hybrid System-11
Page 19
JVO0021X
JVO0006X
JVO0020X
CAUTION
Do not place objects over or into the air vent. The Li-ion battery may overheat and be damaged.
Hybrid System-12 Hybrid System Overview
CAUTION
Do not load large amounts of water in open containers (aquariums or buckets) into the vehicle. If the water spills onto the Li-ion battery, it may cause a short circuit and damage the battery.
CAUTION
Do not allow any liquid to get on or in the air vent. It may cause a short circuit and damage the Li-ion battery.
Noise and vibration
After the hybrid system is activated, the following noises and vibrations that are unique to the hybrid system may occur. This does not indicate a malfunction.
. Electric motor noise from the engine
compartment
Page 20
. Noise from the rear of the vehicle when
the hybrid system activates or deacti­vates
. Noise and vibration when the gasoline
engine starts running or stops
. Operating noise or electric motor noise
when releasing the accelerator pedal or depressing the brake pedal
. Engine noise due to rapid acceleration . Fan noise from the air inlet located on
the rear parcel shelf
. Noise from the climate control system . Noise from the vehicle in order to alert
pedestrians to the presence of an approaching vehicle. See Approaching Vehicle Sound for Pedestrians (VSP) system(P.Hybrid System-9).
Hybrid System Overview Hybrid System-13
Page 21
MEMO
Hybrid System-14 Hybrid System Overview
Page 22
0 Illustrated table of contents
Seats, seat belts and Supplemental Restraint
System (SRS)....................................................... 0-2
Exterior front ....................................................... 0-3
Exterior rear......................................................... 0-4
Passenger compartment ...................................... 0-5
Cockpit................................................................ 0-6
Instrument panel................................................. 0-8
Meters and gauges ............................................. 0-9
Engine compartment ......................................... 0-10
VQ35HR engine ........................................... 0-10
Warning and indicator lights ............................. 0-11
Page 23
SEATS, SEAT BELTS AND SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
1. Supplemental front-impact air bags (Page 1-37)
2. Front seat-mounted side-impact sup­plemental air bags (P.1-37)
3. Seat belts (P.1-10)
4. Head restraints/headrests (P.1-5)
8. Front seats (P.1-3)
9. Seat belts with pretensioners (P.1-49)
10. Rear seats Child restraints (P.1-19)
11. LATCH (Lower Anchors and Tethers for CHildren) system (P.1-21)
SSI0715
5. Roof-mounted curtain side-impact supplemental air bags (P.1-37)
6. Child restraint anchor points (for top tether strap child restraint) (P.1-33)
7. Occupant classification sensor (pat­tern sensor) (P.1-42)
0-2 Illustrated table of contents
Page 24
EXTERIOR FRONT
1. Hood (P.3-16)
2. Headlight and turn signal
Operation (P.2-38)Bulb replacement (P.8-29)
3. Windshield wiper and washer
Operation (P.2-35)
Wheel and tires (P.8-32, P.9-8)Flat tire (P.6-3)Tire pressure monitoring system
(TPMS) (P.2-15, P.5-4)
9. Outside mirrors (P.3-25)
10. Doors
Keys (P.3-2)Door locks (P.3-4)Intelligent Key system (P.3-6)Remote keyless entry system
(P.3-13) Welcome light (P.2-60)
JVC0142X
Maintenance (P.8-21)
4. Moonroof (P.2-57)
5. Power windows (P.2-55)
6. Recovery hook (P.6-15)
7. Fog light (P.2-43)
8. Tires
Illustrated table of contents 0-3
Page 25
EXTERIOR REAR
1. Trunk
Intelligent Key system (P.3-6)Remote keyless entry system
(P.3-13)
Trunk lid (P.3-17)12-volt battery (P.8-18)
6. Sonar system (if so equipped) (P. 5-
93)
7. Rear view camera (P.4-26)
8. Fuel-filler door
Operation (P.3-20)Fuel information (P.9-4)
9. Child safety rear door locks (P.3-6)
JVC0258X
2. High-mounted stop light (bulb repla­cement) (P.8-29)
3. Rear combination light (bulb replace­ment) (P.8-29)
4. Satellite antenna (P.4-48)
5. Rear window defroster (P.2-37)
0-4 Illustrated table of contents
Page 26
PASSENGER COMPARTMENT
1. Rear sunshade (if so equipped) (P.2-59)
2. Coat hooks (P.2-54)
3. Rear personal light (P.2-61)
4. Sun visors (P.3-23)
5. Power windows (P.2-55)
6. Moonroof switch (P.2-57)
7. Map light (P.2-61) Active noise control system
(P.5-105) SOS call switch* (Refer to the
separate Navigation System Owners
SSI0688
Manual.)
8. Sunglasses holder (P.2-52)
9. Inside rearview mirror
Operation (P.3-24)HomeLink
®
(P.2-63)
10. Rear armrest (P.1-4)
11. Rear cup holders (P.2-51)
12. Console box
Power outlet (P.2-49)USB input operation (P.4-69)
®
iPod
player operation (P.4-79)
13. Front cup holders (P.2-51)
Illustrated table of contents 0-5
Page 27
COCKPIT
1. Instrument brightness control switch (P.2-42)
2. AFS switch (if so equipped) (P.2-40)
3. Headlight, fog light and turn signal switch (P.2-38)
4. Trip computer switch (P.2-28)
JVC0259X
5. TRIP/RESET switch for twin trip od­ometer (P.2-7)
6. Windshield wiper and washer switch (P.2-35)
7. Shift lever (P.5-14)
8. Vehicle Dynamic Control (VDC) OFF switch (P.5-100)
9. Rear sunshade switch (if so equipped) (P.2-59)
10. Steering heater switch (if so equipped) (P.2-43)
11. Trunk lid release switch (P.3-17)
12. Sonar system off switch (if so equipped) (P.5-95)
13. Warning systems switch (if so equipped) (P.5-21, P.5-31, P.5-82)
14. Intelligent Brake Assist (IBA) OFF switch (if so equipped) (P.5-86)
15. Electric tilting/telescopic steering wheel lever (P.3-22)
16. Steering-wheel-mounted controls (left side)
Menu control switch (models with navigation system)/Audio tuning switch (models without navigation system) (P.4-82)
Hands-Free Phone System switch (P.4-97, P.4-86)
17. Steering wheel
Horn (P.2-44)Driver supplemental air bag
(P.1-37)
0-6 Illustrated table of contents
Page 28
Heated steering wheel (if so equipped) (P.2-43)
18. Steering-wheel-mounted controls (right side)
Cruise control switches (P.5-46)Intelligent Cruise Control (ICC)
switches (if so equipped) (P.5-48) Dynamic driver assistance switch
(if so equipped) (P.5-21, P.5-31, P.5-69)
Illustrated table of contents 0-7
Page 29
INSTRUMENT PANEL
1. Side ventilator (P.4-33)
2. Meters and gauges (P.2-6)
3. Hazard warning flasher switch (P.6-2)
4. Rear window and outside mirror defroster switch (P.2-37)
5. Center display (P.4-4)/Navigation sys-
0-8 Illustrated table of contents
JVO0132X
tem* (if so equipped)
6. Clock (P.2-49)
7. Center multi-function control panel Navigation system* (if so
equipped)
Vehicle information and setting buttons (P.4-10)
Bluetooth
®
Hands-Free Phone Sys-
tem (P.4-84, P.4-95) Audio system (P.4-48)
8. Automatic climate control system (P.4-34)/Forest Air
®
system (P.4-34)
9. Center ventilator (P.4-33)
10. Audio system (P.4-48)
11. Front passenger supplemental air bag (P.1-37)
12. Hood release handle (P.3-16)
13. Fuse box cover (P.8-24)
14. Parking brake Parking (P.5-18)
15. Push-button ignition switch (P.5-9)
16. Front passenger air bag status light (P.1-44)
17. Climate controlled seat switch (if so equipped) (P.2-46)/Seat heater switch (if so equipped) (P.2-44)
18. Drive mode select switch (P.5-18)
19. Cigarette lighter and ashtray (P.2-50)
20. Glove box lid release handle (P.2-52)
21. Trunk release power cancel switch (P.3-18)
*: Refer to the separate Navigation
System Owners Manual.
Page 30
METERS AND GAUGES
1. Tachometer (P.2-8)
2. Warning/Indicator lights (P.2-10)
3. Speedometer (P.2-7)
4. Assist charge gauge (P.2-8)
5. Dot matrix liquid crystal display/ Odometer/twin trip odometer
JVI0200X
(P.2-21)
6. Fuel gauge (P.2-8)
Illustrated table of contents 0-9
Page 31
ENGINE COMPARTMENT
VQ35HR ENGINE
1. Engine oil filler cap (P.8-12)
2. Brake fluid reservoir (P.8-16)
3. Fuse/fusible link holder (P.8-24)
4. Window washer fluid reservoir (P.8-17)
5. Power steering fluid reservoir (P.8-15)
6. Inverter coolant reservoir (P.8-11)
7. Air cleaner (P.8-20)
8. Radiator filler cap (P.8-9)
9. Engine oil dipstick (P.8-12)
10. Engine coolant reservoir (P.8-9)
JVM0034X
0-10 Illustrated table of contents
Page 32
WARNING AND INDICATOR LIGHTS
Warning
light
Name Page
12-volt batteryCharge warning light
Anti-lock Braking System (ABS) warning light
Blind Spot Warning (BSW)/ Blind Spot Intervention (BSI) system warning light (orange)*
Brake system warning light (yellow)
Brake warning light (red) 2-12
Direct Response Hybrid®Sys­tem warning light
Distance Control Assist (DCA) system warning light (orange)*
Engine oil pressure warning light
High temperature warning light 2-14
Hybrid EPS (Electrical Power Steering) warning light
Intelligent Cruise Control (ICC) system warning light (orange)*
Lane Departure Warning (LDW) light (orange)*
Low tire pressure warning light 2-15
2-11
2-11
2-11
2-12
2-13
2-13
2-13
2-14
2-14
2-14
Warning
light
Indicator
light
Name Page
Master warning light 2-16
Preview Function warning light (orange)*
Seat belt warning light and chime
Supplemental air bag warning light
Vehicle Dynamic Control (VDC) warning light
Name Page
Adaptive Front lighting System (AFS) off indicator light*
Approaching Vehicle Sound for Pedestrians (VSP) OFF indicator light
Automatic Transmission (AT) position indicator light
Blind Spot Intervention (BSI) indicator light (green)*
ECO drive indicator light 2-18
EV indicator light 2-18
Exterior light indicator 2-18
Front fog light indicator light 2-18
2-16
2-16
2-17
2-17
2-17
2-18
2-18
2-18
Indicator
light
Front passenger air bag status light
High beam indicator light 2-18
Intelligent Brake Assist (IBA) off indicator light*
Lane Departure Warning (LDW) light (green)*
Malfunction Indicator Light (MIL)
READY to drive indicator light 2-20
Security indicator light 2-20
Turn signal/hazard indicator lights
Vehicle Dynamic Control (VDC) off indicator light
*: if so equipped
Name Page
2-18
2-18
2-19
2-19
2-20
2-20
Illustrated table of contents 0-11
Page 33
MEMO
0-12 Illustrated table of contents
Page 34
1 Safety Seats, seat belts and supplemental
restraint system
Seats................................................................... 1-2
Front seats ...................................................... 1-3
Armrest ........................................................... 1-4
Head restraints/headrests ................................... 1-5
Adjustable head
restraint/headrest components........................ 1-6
Non-adjustable head
restraint/headrest components........................ 1-6
Remove ........................................................... 1-6
Install.............................................................. 1-7
Adjust ............................................................. 1-7
Front-seat Active Head Restraints .................... 1-9
Seat belts.......................................................... 1-10
Precautions on seat belt usage ..................... 1-10
Pregnant women ........................................... 1-12
Injured persons ............................................. 1-12
Pre-crash seat belts with comfort function
(front seats) (if so equipped) ......................... 1-12
Three-point type seat belt ............................. 1-13
Seat belt extenders ....................................... 1-16
Seat belt maintenance................................... 1-16
Child safety ....................................................... 1-17
Infants........................................................... 1-18
Small children ............................................... 1-18
Larger children .............................................. 1-18
Child restraints ................................................. 1-19
Precautions on child restraints..................... 1-19
Lower Anchors and Tethers for CHildren
System (LATCH)............................................ 1-21
Rear-facing child restraint installation
using LATCH................................................. 1-23
Rear-facing child restraint installation using
the seat belts .............................................. 1-25
Forward-facing child restraint installation
using LATCH................................................. 1-28
Forward-facing child restraint installation
using the seat belts..................................... 1-30
Installing top tether strap ............................ 1-33
Booster seats .............................................. 1-34
Supplemental restraint system.......................... 1-37
Precautions on supplemental
restraint system........................................... 1-37
INFINITI Advanced Air Bag System
(front seats) ................................................. 1-42
Front seat-mounted side-impact supplemental air bag and roof-mounted curtain side-impact
supplemental air bag systems ..................... 1-47
Seat belts with pretensioners (front seats).... 1-49
Supplemental air bag warning labels ........... 1-50
Supplemental air bag warning light ............. 1-50
Repair and replacement procedure............... 1-51
Page 35
SEATS
being injured is increased.
CAUTION
When adjusting the seat positions, be sure not to contact any moving parts to avoid possible injuries and/or damages.
SSS0133
WARNING
. Do not ride in a moving vehicle when the
seatback is reclined. This can be danger­ous. The shoulder belt will not be against your body. In an accident, you could be thrown into it and receive neck or other serious injuries. You could also slide under the lap belt and receive serious internal injuries.
. For the most effective protection when
the vehicle is in motion, the seat should be upright. Always sit well back in the
seat with both feet on the floor and adjust the seat belt properly. See Pre­cautions on seat belt usage(P.1-10).
. Do not leave children unattended inside
the vehicle. They could unknowingly activate switches or controls. Unat­tended children could become involved in serious accidents.
. The seatback should not be reclined
further than necessary for comfort. Seat belts are most effective when the pas­senger sits well back and straight up in the seat. If the seatback is reclined, the risk of sliding under the lap belt and
1-2 Safety Seats, seat belts and supplemental restraint system
Page 36
FRONT SEATS
Front power seat adjustment
Operating tips:
. The power seat motor has an auto-reset
overload protection circuit. If the motor stops during operation, wait 30 sec­onds, then reactivate the switch.
. Do not operate the power seat switch
for a long period of time when the INFINITI Direct Response Hybrid tem is not running. This will discharge the 12-volt battery.
See Automatic drive positioner(P.3-27) for the seat position memory function.
®
Sys-
Forward and backward:
1
Moving the switch will slide the seat forward or backward to the desired position.
Reclining:
Move the recline switch the desired angle is obtained. To bring the seatback forward again, move the switch
2
forward.
*
The reclining feature allows adjustment of the seatback for occupants of different sizes for added comfort and to help obtain proper seat belt fit. (See Precautions on seat belt usage(P.1-10).) Also, the seat-
forward or backward
*
2
backward until
*
SSS1051
back can be reclined to allow occupants to rest when the vehicle is parked.
Safety Seats, seat belts and supplemental restraint system 1-3
Page 37
SSS1052
SSS1053
SSS1061
Seat lifter:
Push the front or rear end of the switch up or down to adjust the angle of the front portion or height of the seat.
Lumbar support (if so equipped):
The lumbar support feature provides lower back support to the occupants.
Push the front or back end of the switch to adjust the seatback lumbar area.
1-4 Safety Seats, seat belts and supplemental restraint system
ARMREST
Rear armrest
Pull the armrest forward until it is hor­izontal.
Page 38
HEAD RESTRAINTS/HEADRESTS
WARNING
Head restraint/headrest supplement the other vehicle safety systems. They may provide additional protection against injury in certain rear end collisions. Adjustable head restraints/headrests must be adjusted properly, as specified in this section. Check the adjustment after someone else uses the seat. Do not attach anything to the head restraint/headrest stalks or remove the head restraint/headrest. Do not use the seat if the head restraint/headrest has been removed. If the head restraint/headrest was removed, reinstall and properly adjust the head restraint/headrest before an occupant uses the seating position. Failure to follow these instructions can reduce the effective­ness of the head restraint/headrest. This may increase the risk of serious injury or death in a collision.
JVR0089X
The illustration shows the seating posi­tions equipped with head restraint/head­rest.
Indicates the seating position is
equipped with a head restraint.
Indicates the seating position is
equipped with a headrest. + indicates the seating position is not
equipped with a head restraint or head­rest.
. Your vehicle is equipped with a head
restraint/headrest that may be inte­grated, adjustable or non-adjustable.
. Adjustable head restraints/headrests
have multiple notches along the stalk to lock them in a desired adjustment position.
. The non-adjustable head restraints/
headrests have a single locking notch to secure them to the seat frame.
. Proper Adjustment:
For the adjustable type, align the
head restraint/headrest so the cen­ter of your ear is approximately level with the center of the head re­straint/headrest.
If your ear position is still higher
than the recommended alignment, place the head restraint/headrest at the highest position.
. If the head restraint/headrest has been
removed, ensure that it is reinstalled and locked in place before riding in that designated seating position.
Safety Seats, seat belts and supplemental restraint system 1-5
Page 39
SSS0992
JVR0203X
SSS1037
ADJUSTABLE HEAD RESTRAINT/ HEADREST COMPONENTS
1. Removable head restraint/headrest
2. Multiple notches
3. Lock knob
4. Stalks
NON-ADJUSTABLE HEAD RE­STRAINT/HEADREST COMPONENTS
1. Removable head restraint/headrest
2. Single notch
3. Lock knob
4. Stalks
1-6 Safety Seats, seat belts and supplemental restraint system
REMOVE
Use the following procedure to remove the head restraint/headrest.
1. Pull the head restraint/headrest up to the highest position.
2. Push and hold the lock knob.
3. Remove the head restraint/headrest from the seat.
4. Store the head restraint/headrest prop­erly in a secure place so it is not loose in the vehicle.
5. Reinstall and properly adjust the head restraint/headrest before an occupant
Page 40
uses the seating position.
SSS0996
INSTALL
1. Align the head restraint/headrest stalks with the holes in the seat. Make sure that the head restraint/headrest is facing the correct direction. The stalk with the adjustment notch installed in the hole with the lock knob
2
.
*
2. Push and hold the lock knob and push the head restraint/headrest down.
3. Properly adjust the head restraint/ headrest before an occupant uses the seating position.
1
must be
*
Safety Seats, seat belts and supplemental restraint system 1-7
SSS0997
ADJUST
For adjustable head restraint/headrest
Adjust the head restraint/headrest so the center is level with the center of your ears. If your ear position is still higher than the recommended alignment, place the head restraint/headrest at the highest position.
Page 41
JVR0259X
For non-adjustable head restraint/head­rest
Make sure the head restraint/headrest is positioned so the lock knob is engaged in the notch before riding in that designated seating position.
Raise
To raise the head restraint/headrest, pull it up.
Make sure the head restraint/headrest is positioned so the lock knob is engaged in the notch before riding in that designated seating position.
1-8 Safety Seats, seat belts and supplemental restraint system
SSS1035
SSS1036
Lower
To lower, push and hold the lock knob and push the head restraint/headrest down.
Make sure the head restraint/headrest is positioned so the lock knob is engaged in the notch before riding in that designated seating position.
Page 42
SSS0508
FRONT-SEAT ACTIVE HEAD RE­STRAINTS
The Active Head Restraint moves forward utilizing the force that the seatback re­ceives from the occupant in a rear-end collision. The movement of the head restraint helps support the occupant’s head by reducing its backward movement and helping absorb some of the forces that may lead to whiplash-type injuries.
Active Head Restraints are effective for collisions at low to medium speeds in which it is said that whiplash-type injury occurs most.
Active Head Restraints operate only in certain rear-end collisions. After the colli­sion, the head restraints return to their original positions.
Adjust the Active Head Restraints properly as described earlier in this section.
Safety Seats, seat belts and supplemental restraint system 1-9
Page 43
SEAT BELTS
PRECAUTIONS ON SEAT BELT USAGE
If you are wearing your seat belt properly adjusted, and you are sitting upright and well back in your seat with both feet on the floor, your chances of being injured or killed in an accident and/or the severity of injury may be greatly reduced. INFINITI strongly encourages you and all of your passengers to buckle up every time you drive, even if your seating position in­cludes a supplemental air bag.
Most U.S. states and Canadian provinces or territories specify that seat belts be worn at all times when a vehicle is being driven.
SSS0136A
SSS0134A
1-10 Safety Seats, seat belts and supplemental restraint system
Page 44
WARNING
. Every person who drives or rides in this
vehicle should use a seat belt at all times. Children should be properly re­strained in the rear seat and, if appro­priate, in a child restraint.
. The seat belt should be properly ad-
justed to a snug fit. Failure to do so may reduce the effectiveness of the entire restraint system and increase the chance or severity of injury in an accident. Serious injury or death can occur if the seat belt is not worn properly.
. Always route the shoulder belt over your
shoulder and across your chest. Never run the belt behind your back, under your arm or across your neck. The belt should be away from your face and neck, but not falling off your shoulder.
. Position the lap belt as low and snug as
possible AROUND THE HIPS, NOT THE WAIST. A lap belt worn too high could increase the risk of internal injuries in an accident.
. Be sure the seat belt tongue is securely
fastened to the proper buckle.
. Do not wear the seat belt inside out or
twisted. Doing so may reduce its effec­tiveness.
. Do not allow more than one person to
use the same seat belt.
. Never carry more people in the vehicle
than there are seat belts.
. If the seat belt warning light glows
continuously while the ignition switch is in the ON position with all doors closed and all seat belts fastened, it may indicate a malfunction in the system. Have the system checked by an INFINITI retailer.
. No changes should be made to the seat
belt system. For example, do not modify the seat belt, add material or install devices that may change the seat belt routing or tension. Doing so may affect the operation of the seat belt system. Modifying or tampering with the seat belt system may result in serious perso­nal injury.
. Once a seat belt pretensioner has
activated, it cannot be reused and must be replaced together with the retractor. See an INFINITI retailer.
. Removal and installation of the preten-
sioner seat belt system components should be done by an INFINITI retailer.
. All seat belt assemblies, including re-
tractors and attaching hardware, should be inspected after any collision by an INFINITI retailer. INFINITI recommends that all seat belt assemblies in use during a collision be replaced unless the collision was minor and the belts show no damage and continue to oper­ate properly. Seat belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.
. All child restraints and attaching hard-
ware should be inspected after any collision. Always follow the restraint manufacturers inspection instructions and replacement recommendations. The child restraints should be replaced if they are damaged.
Safety Seats, seat belts and supplemental restraint system 1-11
Page 45
SSS0016
SSS0014
PREGNANT WOMEN
INFINITI recommends that pregnant women use seat belts. The seat belt should be worn snug, and always position the lap belt as low as possible around the hips, not the waist, and place the shoulder belt over your shoulder and across your chest. Never run the lap/shoulder belt over your abdominal area. Contact your doctor for specific recommendations.
INJURED PERSONS
INFINITI recommends that injured persons use seat belts. Check with your doctor for specific recommendations.
PRE-CRASH SEAT BELTS WITH COM­FORT FUNCTION (front seats) (if so equipped)
The pre-crash seat belt tightens the seat belt with a motor to help restrain front seat occupants. This helps reduce the risk of injury in a collision.
The motor retracts the seat belt under the following emergency conditions:
. During emergency braking. . During sudden steering maneuvers. . Activation of the Intelligent Brake Assist
(IBA) system. (See Intelligent Brake Assist (IBA) system(P.5-86).)
The pre-crash seat belt will not be active when:
. The seat belt is not fastened. . The vehicle speed is under 10 MPH (15
km/h) during emergency braking.
. The vehicle speed is under 19 MPH (30
km/h) during sudden steering maneu­vers.
The pre-crash seat belt will not be active when the brake pedal is not depressed except when sudden steering maneuvers occur and the Intelligent Brake Assist (IBA) system activates.
The motor also retracts the seat belt when the seat belt is fastened or unfastened. When the seat belt is fastened, the motor tightens the seat belt for a snug fit. When the seat belt is unfastened, the motor retracts the seat belt. If the seat belt is not fully retracted, the motor retracts the seat belt when the door is opened.
Always wear your seat belt correctly and sit upright and well back.
If the motor cannot retract the seat belt when the seat belt is fastened or unfas­tened, it may indicate the pre-crash seat
1-12 Safety Seats, seat belts and supplemental restraint system
Page 46
belt system has a malfunction. Have your INFINITI retailer check and repair the system.
When the seat belt is retracted repeatedly in a short period of time, the motor may not be able to retract the seat belt. After 8 minutes, the motor normally reactivates and retracts the seat belt. If the seat belt still cannot be retracted by the motor, the pre-crash seat belt system has a malfunc­tion. Have your INFINITI retailer check and repair the system.
THREE-POINT TYPE SEAT BELT
WARNING
. Every person who drives or rides in this
vehicle should use a seat belt at all times.
. Do not ride in a moving vehicle when the
seatback is reclined. This can be danger­ous. The shoulder belt will not be against your body. In an accident, you could be thrown into it and receive neck or other serious injuries. You could also slide under the lap belt and receive serious internal injuries.
. For the most effective protection when
the vehicle is in motion, the seat should be upright. Always sit well back in the seat with both feet on the floor and adjust the seat belt properly.
. Do not allow children to play with the
seat belts. Most seating positions are equipped with Automatic Locking Re­tractor (ALR) mode seat belts. If the seat belt becomes wrapped around a childs neck with the ALR mode activated, the child can be seriously injured or killed if the seat belt retracts and becomes tight. This can occur even if the vehicle is parked. Unbuckle the seat belt to release the child. If the seat belt can not be unbuckled or is already unbuckled, release the child by cutting the seat belt with a suitable tool (such as a knife or scissors) to release the seat belt.
SSS0292
Fastening the seat belts
1. Adjust the seat. (See Seats(P.1-2).)
2. Slowly pull the seat belt out of the retractor and insert the tongue into the buckle until you hear and feel the latch engage.
.
The retractor is designed to lock during a sudden stop or on impact. A slow pulling motion permits the belt to move, and allows you some freedom of movement in the seat.
.
If the seat belt cannot be pulled from its fully retracted position, firmly pull the belt and release it.
Safety Seats, seat belts and supplemental restraint system 1-13
Page 47
Then smoothly pull the belt out of the retractor.
SSS0290
3. Position the lap belt portion low and snug on the hips as shown.
4. Pull the shoulder belt portion toward the retractor to take up extra slack. Be sure the shoulder belt is routed over your shoulder and across your chest.
The three-point type seat belts have two modes of operation:
. Emergency Locking Retractor (ELR) . Automatic Locking Retractor (ALR)
The Emergency Locking Retractor (ELR) mode allows the seat belt to extend and retract to allow the driver and passengers some freedom of movement in the seat.
The ELR locks the seat belt when the vehicle slows down rapidly or during impacts.
The Automatic Locking Retractor (ALR) mode (child restraint mode) locks the seat belt for child restraint installation.
When the ALR mode is activated the seat belt cannot be extended again until the seat belt tongue is detached from the buckle and fully retracted. The seat belt returns to the ELR mode after the seat belt fully retracts. For additional information, see Child restraints(P.1-19).
The ALR mode should be used only for child restraint installation. During normal seat belt use by an occupant, the ALR mode should not be activated. If it is activated, it may cause uncomfortable seat belt tension.
WARNING
When fastening the seat belts, be certain that seatbacks are completely secured in the latched position. If they are not com­pletely secured, passengers may be injured in an accident or sudden stop.
1-14 Safety Seats, seat belts and supplemental restraint system
Page 48
. Grasp the shoulder belt and pull
forward quickly. The retractor should lock and restrict further belt movement.
If the retractor does not lock during this check or if you have any question about seat belt operation, see an INFINITI retailer.
SSS0326
Unfastening the seat belts
To unfasten the seat belt, push the button on the buckle. The seat belt automatically retracts.
Checking seat belt operation
Seat belt retractors are designed to lock seat belt movement by two separate methods:
. When the belt is pulled quickly from the
retractor. . When the vehicle slows down rapidly. To increase your confidence in the seat
belts, check the operation as follows:
SSS1084
Center of rear seat
Selecting correct set of seat belts:
The center seat belt buckle is identified by the CENTER mark tongue can be fastened only into the center seat belt buckle.
Safety Seats, seat belts and supplemental restraint system 1-15
A
. The center seat belt
*
Page 49
WARNING
WARNING
. After adjustment, release the adjustment
button and try to move the shoulder belt anchor up and down to make sure it is securely fixed in position.
. The shoulder belt anchor height should
be adjusted to the position best for you. Failure to do so may reduce the effec­tiveness of the entire restraint system and increase the chance or severity of
SSS0294A
Shoulder belt height adjustment (front seats)
The shoulder belt anchor height should be adjusted to the position best for you. (See Precautions on seat belt usage(P.1-10).)
To adjust, push the button move the shoulder belt anchor to the desired position, so that the belt passes over the center of the shoulder. The belt should be away from your face and neck, but not falling off of your shoulder. Release the adjustment button to lock the shoulder belt anchor into position.
A
, and then
*
injury in an accident.
SEAT BELT EXTENDERS
If, because of body size or driving position, it is not possible to properly fit the lap­shoulder belt and fasten it, an extender that is compatible with the installed seat belts is available that can be purchased. The extender adds approximately 8 in (200 mm) of length and may be used for either the driver or front passenger seating position. See an INFINITI retailer for assis­tance with purchasing an extender if an extender is required.
1-16 Safety Seats, seat belts and supplemental restraint system
. Only INFINITI seat belt extenders, made
by the same company which made the original equipment seat belts, should be used with the INFINITI seat belts.
. Adults and children who can use the
standard seat belt should not use an extender. Such unnecessary use could result in serious personal injury in the event of an accident.
. Never use seat belt extenders to install
child restraints. If the child restraint is not secured properly, the child could be seriously injured in a collision or a sudden stop.
SEAT BELT MAINTENANCE
. To clean the seat belt webbing, apply a
mild soap solution or any solution recommended for cleaning upholstery or carpets. Then, wipe with a cloth and allow the seat belts to dry in the shade. Do not allow the seat belts to retract until they are completely dry.
. If dirt builds up in the shoulder belt
guide of the seat belt anchors, the seat
Page 50
CHILD SAFETY
belts may retract slowly. Wipe the
shoulder belt guide with a clean, dry
cloth.
. Periodically check to see that the seat
belt and the metal components such as
buckles, tongues, retractors, flexible
wires and anchors work properly. If
loose parts, deterioration, cuts or other
damage on the webbing is found, the
entire seat belt assembly should be
replaced.
WARNING
Do not allow children to play with the seat belts. Most seating positions are equipped with Automatic Locking Retractor (ALR) mode seat belts. If the seat belt becomes wrapped around a childs neck with the ALR mode activated, the child can be seriously injured or killed if the seat belt retracts and becomes tight. This can occur even if the vehicle is parked. Unbuckle the seat belt to release the child. If the seat belt can not be unbuckled or is already unbuckled, release the child by cutting the seat belt with a suitable tool (such as a knife or scissors) to release the seat belt.
Children need adults to help protect them. They need to be properly restrained.
In addition to the general information in this manual, child safety information is available from many other sources, includ­ing doctors, teachers, government traffic safety offices, and community organiza­tions. Every child is different, so be sure to learn the best way to transport your child.
There are three basic types of child restraint systems:
Safety Seats, seat belts and supplemental restraint system 1-17
. Rear-facing child restraint . Forward-facing child restraint . Booster seat
The proper restraint depends on the childs size. Generally, infants up to about 1 year and less than 20 lbs (9 kg) should be placed in rear-facing child restraints. For­ward-facing child restraints are available for children who outgrow rear-facing child restraints and are at least 1 year old. Booster seats are used to help position a vehicle lap/shoulder belt on a child who can no longer use a forward-facing child restraint.
WARNING
Infants and children need special protection. The vehicles seat belts may not fit them properly. The shoulder belt may come too close to the face or neck. The lap belt may not fit over their small hip bones. In an accident, an improperly fitting seat belt could cause serious or fatal injury. Always use appropriate child restraints.
All U.S. states and Canadian provinces or territories require the use of approved child restraints for infants and small
Page 51
children. See Child restraints(P.1-19). A child restraint may be secured in the
vehicle by using either the LATCH (Lower Anchor and Tethers for CHildren) system or with the vehicle seat belt. See Child restraints(P.1-19) for more information.
INFINITI recommends that all pre-teens and children be restrained in the rear seat. Studies show that children are safer when properly restrained in the rear seat than in the front seat.
This is especially important because your vehicle has a supplemental restraint sys­tem (Air bag system) for the front passen­ger. See Supplemental restraint system (P.1-37).
INFANTS
Infants up to at least 1 year old should be placed in a rear-facing child restraint. INFINITI recommends that infants be placed in child restraints that comply with Federal Motor Vehicle Safety Standards or Cana­dian Motor Vehicle Safety Standards. You should choose a child restraint that fits your vehicle and always follow the manu­facturers instructions for installation and use.
SMALL CHILDREN
Children that are over 1 year old and weigh at least 20 lbs (9 kg) should remain in a rear-facing child restraint as long as possible up to the height or weight limit of the child restraint. Children who outgrow the height or weight limit of the rear-facing child restraint and are at least 1 year old should be secured in a forward-facing child restraint with a harness. Refer to the manufacturers instructions for minimum and maximum weight and height recom­mendations. INFINITI recommends that small children be placed in child restraints that comply with Federal Motor Vehicle Safety Standards or Canadian Motor Vehi­cle Safety Standards. You should choose a child restraint that fits your vehicle and always follow the manufacturers instruc­tions for installation and use.
LARGER CHILDREN
Children should remain in a forward-facing child restraint with a harness until they reach the maximum height or weight limit allowed by the child restraint manufac­turer.
Once a child outgrows the height or weight limit of the harness-equipped forward-
facing child restraint, INFINITI recommends that the child be placed in a commercially available booster seat to obtain proper seat belt fit. For a seat belt to fit properly, the booster seat should raise the child so that the shoulder belt is properly posi­tioned across the chest and the top, middle portion of the shoulder. The shoulder belt should not cross the neck or face and should not fall off the shoulder. The lap belt should lie snugly across the lower hips or upper thighs, not the abdo­men.
A booster seat can only be used in seating positions that have a three-point type seat belt. The booster seat should fit the vehicle seat and have a label certifying that it complies with Federal Motor Vehicle Safety Standards or Canadian Motor Vehicle Safety Standards. Once the child has grown so the shoulder belt is no longer on or near the face and neck, and the lap belt can be positioned properly across the lower hips or upper thighs, use the seat belt without the booster seat.
1-18 Safety Seats, seat belts and supplemental restraint system
Page 52
CHILD RESTRAINTS
WARNING
Never let a child stand or kneel on any seat and do not allow a child in the cargo area. The child could be seriously injured or killed in a sudden stop or collision.
SSS0099
SSS0100
PRECAUTIONS ON CHILD RE­STRAINTS
WARNING
. Failure to follow the warnings and
instructions for proper use and installa­tion of child restraints could result in serious injury or death of a child or other passengers in a sudden stop or collision:
The child restraint must be used and installed properly. Always follow all of the child restraint manufacturers instructions for installation and use.
Infants and children should never be held on anyones lap. Even the strongest adult cannot resist the forces of a collision.
Do not put a seat belt around both a child and another passenger.
INFINITI recommends that all child restraints be installed in the rear seat. Studies show that children are safer when properly restrained in the rear seat than in the front seat. If you must install a forward-facing child restraint in the front seat, see For-
Safety Seats, seat belts and supplemental restraint system 1-19
Page 53
ward-facing child restraint installa­tion using the seat belts(P.1-30).
Even with the INFINITI Advanced Air Bag System, never install a rear­facing child restraint in the front seat. An inflating air bag could seriously injure or kill a child. A rear-facing child restraint must only be used in the rear seat.
Be sure to purchase a child restraint that will fit the child and vehicle. Some child restraints may not fit properly in your vehicle.
Child restraint anchor points are designed to withstand loads from child restraints that are properly fitted.
Never use the anchor points for adult seat belts or harnesses.
A child restraint with a top tether strap should not be used in the front passenger seat.
Keep seatbacks as upright as pos­sible after fitting the child restraint.
Infants and children should always be placed in an appropriate child restraint while in the vehicle.
. When the child restraint is not in use,
keep it secured with the LATCH system or a seat belt. In a sudden stop or collision, loose objects can injure occu­pants or damage the vehicle.
A child restraint in a closed vehicle can become very hot. Check the seating surface and buckles before placing a child in the child restraint.
This vehicle is equipped with a universal child restraint anchor system, referred to as the LATCH (Lower Anchors and Tethers for CHildren) system. Some child restraints include rigid or webbing-mounted attach­ments that can be connected to these anchors.
For details, see Lower Anchors and Tethers for CHildren System (LATCH)(P.1-
21). If you do not have a LATCH compatible
child restraint, the vehicle seat belts can be used.
Several manufacturers offer child restraints
1-20 Safety Seats, seat belts and supplemental restraint system
CAUTION
for infants and small children of various sizes. When selecting any child restraint, keep the following points in mind:
. Choose only a restraint with a label
certifying that it complies with Federal Motor Vehicle Safety Standard 213 or Canadian Motor Vehicle Safety Stan­dard 213.
. Check the child restraint in your vehicle
to be sure it is compatible with the vehicles seat and seat belt system.
. If the child restraint is compatible with
your vehicle, place your child in the child restraint and check the various adjustments to be sure the child restraint is compatible with your child. Choose a child restraint that is de­signed for your childs height and weight. Always follow all recommended procedures.
All U.S. states and Canadian provinces or territories require that infants and small children be restrained in an approved child restraint at all times while the vehicle is being operated. Canadian law requires the top tether strap on forward-facing child restraints be secured to the designated anchor point on the vehicle.
Page 54
SSS0567
LATCH label location
Lower Anchors and Tethers for CHildren System (LATCH)
Your vehicle is equipped with special anchor points that are used with the LATCH (Lower Anchors and Tethers for CHildren) system compatible child restraints. This system may also be referred to as the ISOFIX or ISOFIX compatible system. With this system, you do not have to use a vehicle seat belt to secure the child restraint.
LATCH lower anchor
WARNING
Failure to follow the warnings and instruc­tions for proper use and installation of child restraints could result in serious injury or death of a child or other passengers in a sudden stop or collision:
. Attach LATCH system compatible child
restraints only at the locations shown in the illustration.
. Do not secure a child restraint in the
center rear seating position using the LATCH lower anchors. The child restraint will not be secured properly.
. Inspect the lower anchors by inserting
your fingers into the lower anchor area. Feel to make sure there are no obstruc­tions over the anchors such as seat belt webbing or seat cushion material. The child restraint will not be secured properly if the lower anchors are ob­structed.
Child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used to attach
Safety Seats, seat belts and supplemental restraint system 1-21
adult seat belts, or other items or equip­ment to the vehicle. Doing so could damage the child restraint anchorages. The child restraint will not be properly installed using the damaged anchorage, and a child could be seriously injured or killed in a collision.
Page 55
SSS0637
LATCH lower anchor location
LATCH lower anchor location
The LATCH anchors are located at the rear of the seat cushion near the seatback. A label is attached to the seatback to help you locate the LATCH anchors.
LATCH webbing-mounted attachment
Installing child restraint LATCH lower anchor attachments
LATCH compatible child restraints include two rigid or webbing-mounted attachments that can be connected to two anchors located at certain seating positions in your vehicle. With this system, you do not have to use a vehicle seat belt to secure the child restraint. Check your child restraint for a label stating that it is compatible with LATCH. This information may also be in the instructions provided by the child restraint manufacturer.
1-22 Safety Seats, seat belts and supplemental restraint system
SSS0643
SSS0644
LATCH rigid-mounted attachment
The child restraint top tether strap must be used when installing child restraints with the LATCH lower anchor attachments or seat belts. (See Installing top tether strap(P.1-33).)
When installing a child restraint, carefully read and follow the instructions in this manual and those supplied with the child restraint.
Page 56
SSS0791
Top tether anchor point locations
Anchor points are located on the rear parcel shelf.
If you have any questions when installing a top tether strap child restraint on the rear seat, consult an INFINITI retailer for details.
WARNING
Child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used to attach
adult seat belts, or other items or equip­ment to the vehicle. Doing so could damage the child restraint anchorages. The child restraint will not be properly installed using the damaged anchorage, and a child could be seriously injured or killed in a collision.
REAR-FACING CHILD RESTRAINT IN­STALLATION USING LATCH
Refer to all Warnings and Cautions in the Child safetyand Child restraintssec­tions before installing a child restraint.
Follow these steps to install a rear-facing child restraint using the LATCH system:
1. Position the child restraint on the seat. Always follow the child restraint man­ufacturers instructions.
SSS0648
Rear-facing web-mounted step 2
2. Secure the child restraint anchor at­tachments to the LATCH lower anchors. Check to make sure the LATCH attach­ment is properly attached to the lower anchors.
Safety Seats, seat belts and supplemental restraint system 1-23
Page 57
SSS0649
Rear-facing rigid-mounted step 2
Rear-facing step 3
3. For child restraints that are equipped with webbing-mounted attachments, remove any additional slack from the anchor attachments. Press downward and rearward firmly in the center of the child restraint with your hand to com­press the vehicle seat cushion and seatback while tightening the webbing of the anchor attachments.
1-24 Safety Seats, seat belts and supplemental restraint system
SSS0639
SSS0650
Rear-facing step 4
4. After attaching the child restraint, test it before you place the child in it. Push it from side to side while holding the child restraint near the LATCH attach­ment path. The child restraint should not move more than 1 inch (25 mm), from side to side. Try to tug it forward and check to see if the LATCH attach­ment holds the restraint in place. If the restraint is not secure, tighten the LATCH attachment as necessary, or put the restraint in another seat and test it again. You may need to try a different child restraint or try installing by using the vehicle seat belt (if
Page 58
applicable). Not all child restraints fit in all types of vehicles.
5. Check to make sure the child restraint is properly secured prior to each use. If the child restraint is loose, repeat steps 1 through 4.
bag and status light(P.1-44).
SSS0100
REAR-FACING CHILD RESTRAINT IN­STALLATION USING THE SEAT BELTS
WARNING
The three-point seat belt with Automatic Locking Retractor (ALR) must be used when installing a child restraint. Failure to use the ALR mode will result in the child restraint not being properly secured. The restraint could tip over or be loose and cause injury to a child in a sudden stop or collision. Also, it can change the operation of the front passenger air bag. See Front passenger air
Safety Seats, seat belts and supplemental restraint system 1-25
Page 59
SSS0100
Refer to all Warnings and Cautions in the
Rear-facing step 1
Child safety(P.1-17) and Child re­straints(P.1-19) before installing a child restraint.
Follow these steps to install a rear-facing child restraint using the vehicle seat belts
2. Route the seat belt tongue through the
Rear-facing step 2
child restraint and insert it into the buckle until you hear and feel the latch engage. Be sure to follow the child restraint manufacturers instructions for belt routing.
in the rear seats:
1. Child restraints for infants must be
used in the rear-facing direction and therefore must not be used in the front seat. Position the child restraint on the
seat. Always follow the restraint man­ufacturers instructions.
1-26 Safety Seats, seat belts and supplemental restraint system
SSS0654
SSS0655
Rear-facing step 3
3. Pull the shoulder belt until the belt is fully extended. At this time, the seat belt retractor is in the Automatic Lock­ing Retractor (ALR) mode (child restraint mode). It reverts to the Emergency Locking Retractor (ELR) mode when the seat belt is fully retracted.
Page 60
SSS0656
Rear-facing step 4
4. Allow the seat belt to retract. Pull up on the shoulder belt to remove any slack in the belt.
SSS0657
Rear-facing step 5
5. Remove any additional slack from the seat belt; press downward and rear­ward firmly in the center of the child restraint to compress the vehicle seat cushion and seatback while pulling up on the seat belt.
Safety Seats, seat belts and supplemental restraint system 1-27
SSS0658
Rear-facing step 6
6. After attaching the child restraint, test it before you place the child in it. Push it from side to side while holding the child restraint near the seat belt path. The child restraint should not move more than 1 inch (25 mm), from side to side. Try to tug it forward and check to see if the belt holds the restraint in place. If the restraint is not secure, tighten the seat belt as necessary, or put the restraint in another seat and test it again. You may need to try a different child restraint. Not all child restraints fit in all types of vehicles.
Page 61
7. Check to make sure that the child restraint is properly secured prior to each use. If the seat belt is not locked, repeat steps 1 through 6.
After the child restraint is removed and the seat belt fully retracted, the ALR mode (child restraint mode) is canceled.
FORWARD-FACING CHILD RESTRAINT INSTALLATION USING LATCH
Refer to all Warnings and Cautions in the Child safetyand Child restraintssec­tions before installing a child restraint.
Follow these steps to install a forward­facing child restraint using the LATCH system:
1. Position the child restraint on the seat. Always follow the child restraint man­ufacturers instructions.
SSS0645
Forward-facing web-mounted step 2
2. Secure the child restraint anchor at­tachments to the LATCH lower anchors. Check to make sure the LATCH attach­ment is properly attached to the lower anchors.
If the child restraint is equipped with a top tether strap, route the top tether strap and secure the tether strap to the tether anchor point. See Installing top tether strap(P.1-33). Do not install child restraints that require the use of a top tether strap in seating positions that do not have a top tether anchor.
SSS0646
Forward-facing rigid-mounted step 2
3. The back of the child restraint should be secured against the vehicle seat­back.
If necessary, adjust or remove the head restraint to obtain the correct child restraint fit. If the head restraint is removed, store it in a secure place. Be
sure to reinstall the head restraint when the child restraint is removed.
See Head restraints/headrests(P.1-5) for head restraint adjustment informa­tion.
If the seating position does not have an head restraint and it is interfering with
1-28 Safety Seats, seat belts and supplemental restraint system
Page 62
the proper child restraint fit, try another seating position or a different child restraint.
SSS0647
Forward-facing step 4
4. For child restraints that are equipped with webbing-mounted attachments, remove any additional slack from the anchor attachments. Press downward and rearward firmly in the center of the child restraint with your knee to com­press the vehicle seat cushion and seatback while tightening the webbing of the anchor attachments.
5. Tighten the tether strap according to the manufacturers instructions to re­move any slack.
Safety Seats, seat belts and supplemental restraint system 1-29
SSS0638
Forward-facing step 6
6. After attaching the child restraint, test it before you place the child in it. Push it from side to side while holding the child restraint near the LATCH attach­ment path. The child restraint should not move more than 1 inch (25 mm), from side to side. Try to tug it forward and check to see if the LATCH attach­ment holds the restraint in place. If the restraint is not secure, tighten the LATCH attachment as necessary, or put the restraint in another seat and test it again. You may need to try a different child restraint. Not all child restraints fit in all types of vehicles.
Page 63
7. Check to make sure the child restraint is properly secured prior to each use. If the child restraint is loose, repeat steps 1 through 6.
FORWARD-FACING CHILD RESTRAINT INSTALLATION USING THE SEAT BELTS
WARNING
The three-point seat belt with Automatic Locking Retractor (ALR) must be used when installing a child restraint. Failure to use the ALR mode will result in the child restraint not being properly secured. The restraint could tip over or be loose and cause injury to a child in a sudden stop or collision. Also, it can change the operation of the front passenger air bag. See Front passenger air bag and status light(P.1-44).
1-30 Safety Seats, seat belts and supplemental restraint system
Forward-facing (front passenger seat)
Refer to all Warnings and Cautions in the Child safetyand Child restraintssec­tions before installing a child restraint.
Follow these steps to install a forward­facing child restraint using the vehicle seat belt in the rear seats or in the front passenger seat:
1. If you must install a child restraint in
the front seat, it should be placed in a forward-facing direction only. Move the seat to the rearmost position. Child restraints for infants must be used in the rear-facing direction and, therefore, must not be used in the front seat.
step 1
SSS0640
2. Position the child restraint on the seat. Always follow the child restraint man­ufacturers instructions.
The back of the child restraint should be secured against the vehicle seat­back.
If necessary, adjust or remove the head restraint or headrest to obtain the correct child restraint fit. If the head restraint or headrest is removed, store it in a secure place. Be sure to reinstall
the head restraint or headrest when the child restraint is removed. See
Head restraints/headrests(P.1-5) for head restraint or headrest adjustment, removal and installation information.
If the seating position does not have an adjustable head restraint or headrest and it is interfering with the proper child restraint fit, try another seating position or a different child restraint.
Page 64
SSS0360B
Forward-facing step 3
3. Route the seat belt tongue through the child restraint and insert it into the buckle until you hear and feel the latch engage. Be sure to follow the child restraint manufacturers instructions for belt routing.
If the child restraint is equipped with a top tether strap, route the top tether strap and secure the tether strap to the tether anchor point (rear seat installa­tion only). See Installing top tether strap(P.1-33). Do not install child restraints that require the use of a top tether strap in seating positions that do not have a top tether anchor.
SSS0651
Forward-facing step 4
4. Pull the shoulder belt until the belt is fully extended. At this time, the seat belt retractor is in the Automatic Lock­ing Retractor (ALR) mode (child restraint mode). It reverts to Emergency Locking Retractor (ELR) mode when the seat belt is fully retracted.
Safety Seats, seat belts and supplemental restraint system 1-31
SSS0652
Forward-facing step 5
5. Allow the seat belt to retract. Pull up on the shoulder belt to remove any slack in the belt.
Page 65
9. Check to make sure the child restraint is properly secured prior to each use. If the seat belt is not locked, repeat steps 2 through 8.
SSS0653
6. Remove any additional slack from the
Forward-facing step 6
seat belt; press downward and rear­ward firmly in the center of the child restraint with your knee to compress the vehicle seat cushion and seatback while pulling up on the seat belt.
7. Tighten the tether strap according to the manufacturers instructions to re­move any slack.
8. After attaching the child restraint, test
Forward-facing step 8
it before you place the child in it. Push it from side to side while holding the child restraint near the seat belt path. The child restraint should not move more than 1 inch (25 mm), from side to side. Try to tug it forward and check to see if the belt holds the restraint in place. If the restraint is not secure, tighten the seat belt as necessary, or put the restraint in another seat and test it again. You may need to try a different child restraint. Not all child restraints fit in all types of vehicles.
1-32 Safety Seats, seat belts and supplemental restraint system
SSS0641
Page 66
SSS1085
Forward-facing step 10
10.If the child restraint is installed in the front passenger seat, place the ignition switch in the ON position. The front passenger air bag status light should illuminate. If this light is not illuminated, see Front passenger air bag and status light(P.1-44). Move
the child restraint to another seating position. Have the system checked by
an INFINITI retailer.
After the child restraint is removed and the seat belt is fully retracted, the ALR mode (child restraint mode) is canceled.
SSS0791
INSTALLING TOP TETHER STRAP
WARNING
Child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used to attach adult seat belts, or other items or equip­ment to the vehicle. Doing so could damage the child restraint anchorages. The child restraint will not be properly installed using the damaged anchorage, and a child could be seriously injured or killed in a collision.
First, secure the child restraint with the LATCH lower anchors (rear outboard seat positions only) or the seat belt, as applic­able.
1. Flip up the anchor cover from the anchor point which is located directly behind the child seat.
2. If necessary, raise or remove the head restraint or headrest to position the top tether strap over the top of the seat­back. If the head restraint or headrest is removed, store it in a secure place. Be sure to reinstall the head restraint or headrest when the child restraint is removed.
See Head restraints/headrests(P.1-5) for head restraint or headrest adjust­ment, removal and installation informa­tion.
Position the top tether strap over the top of the seatback.
3. Secure the tether strap to the tether anchor point on the rear parcel shelf.
4. Refer to the appropriate child restraint installation procedure steps in this section before tightening the tether strap.
Safety Seats, seat belts and supplemental restraint system 1-33
Page 67
If you have any questions when installing a top tether strap, consult your INFINITI retailer for details.
BOOSTER SEATS
Precautions on booster seats
WARNING
If a booster seat and seat belt are not used properly, the risk of a child being injured in a sudden stop or collision greatly increases:
. Make sure the shoulder portion of the
belt is away from the childs face and neck and the lap portion of the belt does not cross the stomach.
. Make sure the shoulder belt is not
behind the child or under the childs arm.
. A booster seat must only be installed in
a seating position that has a lap/ shoulder belt.
LRS0455
Booster seats of various sizes are offered by several manufacturers. When selecting any booster seat, keep the following points in mind:
. Choose only a booster seat with a label
certifying that it complies with Federal Motor Vehicle Safety Standard 213 or Canadian Motor Vehicle Safety Stan­dard 213.
. Check the booster seat in your vehicle
to be sure it is compatible with the vehicles seat and seat belt system.
LRS0453
. Make sure the child’s head will be
properly supported by the booster seat or vehicle seat. The seatback must be at or above the center of the childs ears. For example, if a low back booster seat
1
is chosen, the vehicle seatback
*
must be at or above the center of the childs ears. If the seatback is lower than the center of the childs ears, a high back booster seat used.
. If the booster seat is compatible with
your vehicle, place your child in the booster seat and check the various adjustments to be sure the booster
*
2
should be
1-34 Safety Seats, seat belts and supplemental restraint system
Page 68
seat is compatible with your child. Always follow all recommended proce­dures.
LRS0464
All U.S. states and Canadian provinces or territories require that infants and small children be restrained in an approved child restraint at all times while the vehicle is being operated.
The instructions in this section apply to booster seat installation in the rear seats or the front passenger seat.
Booster seat installation
CAUTION
Do not use the lap/shoulder belt Automatic Locking Retractor (ALR) mode when using a booster seat with the seat belts.
Refer to all Warnings and Cautions in the
Child safety”, “Child restraintsandBooster seatssections earlier in this
section before installing a child restraint. Follow these steps to install a booster seat
in the rear seat or in the front passenger seat:
Safety Seats, seat belts and supplemental restraint system 1-35
Page 69
SSS0640
1. If you must install a booster seat in the
front seat, move the seat to the rear­most position.
2. Position the booster seat on the seat. Only place it in a forward-facing direc­tion. Always follow the booster seat manufacturers instructions.
LRS0454
Front passenger position
3. The booster seat should be positioned on the vehicle seat so that it is stable.
If necessary, adjust or remove the head restraint or headrest to obtain the correct booster seat fit. If the head restraint or headrest is removed, store it in a secure place. Be sure to reinstall
the head restraint or headrest when the booster seat is removed. See Head
restraints/headrests(P.1-5) for head restraint or headrest adjustment, re­moval and installation information.
If the seating position does not have an adjustable head restraint or headrest
and it is interfering with the proper booster seat fit, try another seating position or a different booster seat.
4. Position the lap portion of the seat belt low and snug on the childs hips. Be sure to follow the booster seat manu­facturers instructions for adjusting the seat belt routing.
5. Pull the shoulder belt portion of the seat belt toward the retractor to take up extra slack. Be sure the shoulder belt is positioned across the top, middle por­tion of the childs shoulder. Be sure to follow the booster seat manufacturers instructions for adjusting the seat belt routing.
6. Follow the warnings, cautions and instructions for properly fastening a seat belt shown in Seat belts(P.1-
10).
1-36 Safety Seats, seat belts and supplemental restraint system
Page 70
SUPPLEMENTAL RESTRAINT SYSTEM
SSS1085
7. If the booster seat is installed in the front passenger seat, push the ignition switch to the ON position. The front passenger air bag status light or may not illuminate depending on the size of the child and the type of booster seat used. See Front passenger air bag and status light(P.1-44).
may
PRECAUTIONS ON SUPPLEMENTAL RESTRAINT SYSTEM
This Supplemental Restraint System (SRS) section contains important information concerning the following systems:
. Driver and passenger supplemental
front-impact air bag (INFINITI Advanced Air Bag System)
. Front seat-mounted side-impact supple-
mental air bag
. Roof-mounted curtain side-impact sup-
plemental air bag
. Seat belt with pretensioner
Supplemental front-impact air bag system:
The INFINITI Advanced Air Bag System can help cushion the impact force to the head and chest of the driver and front passenger in certain frontal collisions.
Front seat-mounted side-impact supple­mental air bag system: This system can
help cushion the impact force to the chest and pelvis area of the driver and front passenger in certain side impact collisions. The side air bag is designed to inflate on the side where the vehicle is impacted.
Roof-mounted curtain side-impact supple­mental air bag system: This system can
help cushion the impact force to the head
Safety Seats, seat belts and supplemental restraint system 1-37
of occupants in front and rear outboard seating positions in certain side impact collisions. The curtain air bags are de­signed to inflate on the side where the vehicle is impacted.
These supplemental restraint systems are designed to supplement the crash protec­tion provided by the driver and passenger seat belts and are not a substitute for them. Seat belts should always be cor­rectly worn and the occupant seated a suitable distance away from the steering wheel, instrument panel and door fin­ishers. (See Seat belts(P.1-10) for instructions and precautions on seat belt usage.)
The supplemental air bags operate only when the ingition switch is in the ON position.
After pushing the ingition switch to the ON position, the supplemental air bag warn­ing light illuminates. The supplemental air bag warning light will turn off after about 7 seconds if the systems are operational.
Page 71
1-38 Safety Seats, seat belts and supplemental restraint system
SSS0131B
SSS0132B
WARNING
. The supplemental front air bags ordina-
rily will not inflate in the event of a side impact, rear impact, rollover, or lower severity frontal collision. Always wear your seat belts to help reduce the risk or severity of injury in various kinds of accidents.
. The front passenger air bag will not
inflate if the passenger air bag status light is lit or if the front passenger seat is unoccupied. See Front passenger air bag and status light(P.1-44).
. The seat belts and the supplemental
front air bags are most effective when you are sitting well back and upright in the seat with both feet on the floor. The front air bags inflate with great force. Even with the INFINITI advanced air bag system, if you are unrestrained, leaning forward, sitting sideways or out of position in any way, you are at greater risk of injury or death in a crash. You may also receive serious or fatal injuries from the supplemental front air bag if you are up against it when it inflates. Always sit back against the seatback
Page 72
and as far-away as practical from the steering wheel or instrument panel. Always use the seat belts.
. The driver and front passenger seat belt
buckles are equipped with sensors that detect if the seat belts are fastened. The Advanced Air Bag System monitors the severity of a collision and seat belt usage then inflates the air bags as needed. Failure to properly wear seat belts can increase the risk or severity of injury in an accident.
. The front passenger seat is equipped
with an occupant classification sensor (pattern sensor) that turns the front passenger air bag OFF under some conditions. This sensor is only used in this seat. Failure to be properly seated and wearing the seat belt can increase the risk or severity of injury in an accident. See Front passenger air bag and status light(P.1-44).
. Keep hands on the outside of the
steering wheel. Placing them inside the steering wheel rim could increase the risk of injury if the front air bag inflates.
SSS0007
SSS0006
SSS0008
SSS0009
Safety Seats, seat belts and supplemental restraint system 1-39
Page 73
SSS0099
WARNING
. Never let children ride unrestrained or
extend their hands or face out of the window. Do not attempt to hold them in your lap or arms. Some examples of dangerous riding positions are shown in the illustrations.
. Children may be severely injured or
killed when the front air bags, side air bags or curtain air bags inflate if they are not properly restrained. Pre-teens and children should be properly re­strained in the rear seat, if possible.
. Even with the INFINITI Advanced Air Bag
System, never install a rear-facing child restraint in the front seat. An inflating front air bag could seriously injure or kill your child. See Child restraints(P.1-
19) for details.
SSS0059A
SSS0100
1-40 Safety Seats, seat belts and supplemental restraint system
SSS0188A
Page 74
SSS0140
SSS0162
SSS0159
WARNING
Front seat-mounted side-impact supplemen­tal air bags and roof-mounted curtain side­impact supplemental air bags:
. The front seat-mounted side-impact air
bags and roof-mounted curtain air bags ordinarily will not inflate in the event of a frontal impact, rear impact, rollover or lower severity side collision. Always wear your seat belts to help reduce the risk or severity of injury in various kinds of accidents.
. The seat belts, side air bags and curtain
air bags are most effective when you are sitting well back and upright in the seat. The side air bag and curtain air bag inflate with great force. Do not allow anyone to place their hand, leg or face near the side air bag on the side of the seatback of the front seat or near the side roof rails. Do not allow anyone sitting in the front seats or rear outboard seats to extend their hand out of the window or lean against the door. Some examples of dangerous riding positions are shown in the previous illustrations.
. When sitting in the rear seat, do not
hold onto the seatback of the front seat. If the supplemental side air bag inflates, you may be seriously injured. Be espe­cially careful with children, who should always be properly restrained. Some examples of dangerous riding positions are shown in the illustrations.
. Do not use seat covers on the front
seatbacks. They may interfere with supplemental side air bag inflation.
Safety Seats, seat belts and supplemental restraint system 1-41
Page 75
1. Crash zone sensor
2. Supplemental front air bag modules (INFINITI Advanced Air Bags)
3. Front seat-mounted side-impact sup­plemental air bags
4. Occupant classification sensor (pat­tern sensor)
5. Occupant classification system con­trol unit
6. Roof-mounted curtain side-impact supplemental air bags
7. Roof-mounted curtain side-impact supplemental air bag inflators
1-42 Safety Seats, seat belts and supplemental restraint system
SSS1086
8. Lap outer pretensioners (if so equipped)
9. Air bag Control Unit (ACU)
10. Satellite sensors
11. Seat belts with pretensioners
INFINITI ADVANCED AIR BAG SYS­TEM (front seats)
This vehicle is equipped with the INFINITI Advanced Air Bag System for the driver and front passenger seats. This system is designed to meet certification require­ments under U.S. regulations. It is also permitted in Canada. All of the informa-
tion, cautions and warnings in this manual still apply and must be followed.
The driver supplemental front-impact air bag is located in the center of the steering wheel. The front passenger supplemental front-impact air bag is mounted in the instrument panel above the glove box. The front air bags are designed to inflate in higher severity frontal collisions, although they may inflate if the forces in another type of collision are similar to those of a higher severity frontal impact. They may not inflate in certain frontal collisions. Vehicle damage (or lack of it) is not always an indication of proper front air bag
Page 76
operation. The INFINITI Advanced Air Bag System has
dual stage air bag inflators. The system monitors information from the crash zone sensor, the Air bag Control Unit (ACU), seat belt buckle switches and the occupant classification sensor (pattern sensor). In­flator operation is based on the severity of a collision and seat belt usage for the driver. For the front passenger, the occu­pant classification sensor is also moni­tored. Based on information from the sensors, only one front air bag may inflate in a crash, depending on the crash severity and whether the front occupants are belted or unbelted. Additionally, the front pas­senger air bag may be automatically turned OFF under some conditions, depending on the information provided by the occupant classification sensor. If the front passenger air bag is OFF, the passenger air bag status light will be illuminated (if the seat is unoccupied, the light will not be illumi­nated, but the air bag will be off). (See Front passenger air bag and status light (P.1-44) for further details.) One front air bag inflating does not indicate improper performance of the system.
If you have any questions about your air
bag system, contact an INFINITI retailer. If you are considering modification of your vehicle due to a disability, you may also contact an INFINITI retailer. Contact infor­mation is contained in the front of this Owners Manual.
When a front air bag inflates, a fairly loud noise may be heard, followed by release of smoke. This smoke is not harmful and does not indicate a fire. Care should be taken not to inhale it, as it may cause irritation and choking. Those with a history of a breathing condition should get fresh air promptly.
Front air bags, along with the use of seat belts, help to cushion the impact force on the head and chest of the front occupants. They can help save lives and reduce serious injuries. However, an inflating front air bag may cause facial abrasions or other injuries. Front air bags do not provide restraint to the lower body.
Even with INFINITI advanced air bags, seat belts should be correctly worn and the driver and passenger seated upright as far as practical away from the steering wheel or instrument panel. The front air bags inflate quickly in order to help protect the front occupants. Because of this, the force
of the front air bag inflating can increase the risk of injury if the occupant is too close to, or is against, the air bag module during inflation.
The front air bags deflate quickly after a collision.
The supplemental front air bags operate only when the ignition switch is in the ON position.
After pushing the ignition switch to the ON position, the supplemental air bag warn­ing light illuminates. The supplemental air bag warning light will turn off after about 7 seconds if the system is operational.
Safety Seats, seat belts and supplemental restraint system 1-43
Page 77
of injury in an accident.
Status light:
The front passenger air bag status light
is located on the instrument panel. After the ignition switch is placed in the ON position, the front passenger air bag status light illuminates for about 7 seconds and then turns off or illuminates depending on the front passenger seat occupied status. The light operates as follows:
SSS1085
Front passenger air bag status light
Front passenger air bag and status light
WARNING
The front passenger air bag is designed to automatically turn OFF under some condi­tions. Read this section carefully to learn how it operates. Proper use of the seat, seat belt and child restraints is necessary for most effective protection. Failure to follow all instructions in this manual concerning the use of seats, seat belts and child restraints can increase the risk or severity
. Unoccupied passenger seat: The
light is OFF and the front passenger air bag is OFF and will not inflate in a crash.
. Passenger seat occupied by a small
adult, child or child restraint as out­lined in this section: The illuminates to indicate that the front passenger air bag is OFF and will not inflate in a crash.
. Occupied passenger seat and the pas-
senger meets the conditions outlined in this section: The indicate that the front passenger air bag is operational.
1-44 Safety Seats, seat belts and supplemental restraint system
light
light is OFF to
Front passenger air bag:
The front passenger air bag is designed to automatically turn OFF when the vehicle is operated under some conditions as de­scribed below as permitted by U.S. regula­tions. If the front passenger air bag is OFF, it will not inflate in a crash. The driver air bag and other air bags in your vehicle are not part of this system.
The purpose of the regulation is to help reduce the risk of injury or death from an inflating air bag to certain front passenger seat occupants, such as children, by requiring the air bag to be automatically turned OFF.
The occupant classification sensor (pattern sensor) is in the front passenger seat cushion and is designed to detect an occupant and objects on the seat. For example, if a child is in the front passenger seat, the Advanced Air Bag System is designed to turn the passenger air bag OFF in accordance with the regulations. Also, if a child restraint of the type specified in the regulations is on the seat, the occupant classification sensor can detect it and cause the air bag to turn OFF.
Front passenger seat adult occupants who are properly seated and using the seat belt
Page 78
as outlined in this manual should not cause the passenger air bag to be auto­matically turned OFF. For small adults it may be turned OFF, however, if the occupant does not sit in the seat properly (for example, by not sitting upright, by sitting on an edge of the seat, or by otherwise being out of position), this could cause the sensor to turn the air bag OFF. Always be sure to be seated and wearing the seat belt properly for the most effective protection by the seat belt and supple­mental air bag.
INFINITI recommends that pre-teens and children be properly restrained in a rear seat. INFINITI also recommends that appro­priate child restraints and booster seats be properly installed in a rear seat. If this is not possible, the occupant classification sensor is designed to operate as described above to turn the front passenger air bag OFF for specified child restraints. Failing to properly secure child restraints and to use the ALR mode (child restraint mode) may allow the restraint to tip or move in an accident or sudden stop. This can also result in the passenger air bag inflating in a crash instead of being OFF. (See Child restraints(P.1-19) for proper use and
installation.) If the front passenger seat is not occupied,
the passenger air bag is designed not to inflate in a crash. However, heavy objects placed on the seat could result in air bag inflation, because of the object being detected by the occupant classification sensor. Other conditions could also result in air bag inflation, such as if a child is standing on the seat, or if two children are on the seat, contrary to the instructions in this manual. Always be sure that you and all vehicle occupants are seated and restrained properly.
Using the passenger air bag status light, you can monitor when the front passenger air bag is automatically turned OFF with the seat occupied. The light will not illuminate when the front passenger seat is unoccu­pied.
If an adult occupant is in the seat but the passenger air bag status light is illumi­nated (indicating that the air bag is OFF), it could be that the person is a small adult, or is not sitting on the seat properly.
If a child restraint must be used in the front seat, the passenger air bag status light may or may not be illuminated, depending on the size of the child and the type of
Safety Seats, seat belts and supplemental restraint system 1-45
child restraint being used. If the passenger air bag status light is not illuminated (indicating that the air bag might inflate in a crash), it could be that the child restraint or seat belt is not being used properly. Make sure that the child restraint is installed properly, the seat belt is used properly and the occupant is positioned properly. If the passenger air bag status light is still not illuminated, reposition the occupant or child restraint in a rear seat.
If the passenger air bag status light will not illuminate even though you believe that the child restraint, the seat belts and the occupant are properly positioned, the system may be sensing an unoccupied seat (in which case the air bag is OFF). Your INFINITI retailer can check that the system is OFF by using a special tool. However, until you have confirmed with your retailer that your air bag is working properly, reposition the occupant or child restraint in a rear seat.
The INFINITI Advanced Air Bag System and passenger air bag status light will take a few seconds to register a change in the passenger seat status. However, if the seat becomes unoccupied, the air bag status light will remain off.
Page 79
If a malfunction occurs in the front passenger air bag system, the supplemen­tal air bag warning light meter and gauges area will blink. Have the system checked by an INFINITI retailer.
, located in the
Other supplemental front-impact air bag precautions
WARNING
. Do not place any objects on the steering
wheel pad or on the instrument panel. Also, do not place any objects between any occupant and the steering wheel or instrument panel. Such objects may become dangerous projectiles and cause injury if the front air bags inflate.
. Do not place objects with sharp edges
on the seat. Also, do not place heavy objects on the seat that will leave permanent impressions in the seat. Such objects can damage the seat or occupant classification sensor (pattern sensor). This can affect the operation of the air bag system and result in serious perso­nal injury.
. Do not use water or acidic cleaners (hot
steam cleaners) on the seat. This can
damage the seat or occupant classifica­tion sensor. This can also affect the operation of the air bag system and result in serious personal injury.
. Immediately after inflation, several front
air bag system components will be hot. Do not touch them; you may severely burn yourself.
. No unauthorized changes should be
made to any components or wiring of the air bag system. This is to prevent accidental inflation of the supplemental air bag or damage to the supplemental air bag system.
. Do not make unauthorized changes to
your vehicles electrical system, suspen­sion system or front end structure. This could affect proper operation of the front air bag system.
. Tampering with the air bag system may
result in serious personal injury. Tamper­ing includes changes to the steering wheel and the instrument panel assem­bly by placing material over the steering wheel pad and above the instrument panel or by installing additional trim material around the air bag system.
1-46 Safety Seats, seat belts and supplemental restraint system
. Modifying or tampering with the front
passenger seat may result in serious personal injury. For example, do not change the front seats by placing material on the seat cushion or by installing additional trim material, such as seat covers, on the seat that is not specifically designed to assure proper air bag operation. Additionally, do not stow any objects under the front pas­senger seat or the seat cushion and seatback. Such objects may interfere with the proper operation of the occu­pant classification sensor.
. No unauthorized changes should be
made to any components or wiring of the seat belt system. This may affect the front air bag system. Tampering with the seat belt system may result in serious personal injury.
. Work on and around the front air bag
system should be done by an INFINITI retailer. Installation of electrical equip­ment should also be done by an INFINITI retailer. The Supplemental Restraint System (SRS) wiring harnesses* should not be modified or disconnected. Un­authorized electrical test equipment and probing devices should not be used on
Page 80
the air bag system.
. A cracked windshield should be replaced
immediately by a qualified repair facility. A cracked windshield could affect the function of the supplemental air bag system.
* The SRS wiring harness connectors
are yellow and orange for easy identification.
When selling your vehicle, we request that you inform the buyer about the front air bag system and guide the buyer to the appropriate sections in this Owners Man­ual.
SSS0521
FRONT SEAT-MOUNTED SIDE-IM­PACT SUPPLEMENTAL AIR BAG AND ROOF-MOUNTED CURTAIN SIDE-IM­PACT SUPPLEMENTAL AIR BAG SYS­TEMS
The side air bags are located in the outside of the seatback of the front seats. The curtain air bags are located in the side roof rails. All of the information, cautions and
warnings in this manual still apply and must be followed. The side air bags and
curtain air bags are designed to inflate in higher severity side collisions, although they may inflate if the forces in another
type of collision are similar to those of a higher severity side impact. They are designed to inflate on the side where the vehicle is impacted. They may not inflate in certain side collisions on the side where the vehicle is impacted.
Vehicle damage (or lack of it) is not always an indication of proper supplemental side air bag and curtain side-impact air bag operation.
When side air bags and curtain air bags inflate, a fairly loud noise may be heard, followed by release of smoke. This smoke is not harmful and does not indicate a fire. Care should be taken not to inhale it, as it may cause irritation and choking. Those with a history of a breathing condition should get fresh air promptly.
Side air bags, along with the use of seat belts, help to cushion the impact force on the chest and pelvis of the front occupants. Curtain air bags help to cushion the impact force to the head of occupants in the front and rear outboard seating positions. They can help save lives and reduce serious injuries. However, an inflating side air bags and curtain air bags may cause abrasions or other injuries. Side air bags and curtain air bags do not provide restraint to the
Safety Seats, seat belts and supplemental restraint system 1-47
Page 81
lower body. The seat belts should be correctly worn
and the driver and passenger seated upright as far as practical away from the side air bag. Rear seat passengers should be seated as far away as practical from the door finishers and side roof rails. The side air bags and curtain air bags inflate quickly in order to help protect the occupants. Because of this, the force of the side air bags and curtain air bags inflating can increase the risk of injury if the occupant is too close to, or is against, these air bag modules during inflation. The side air bags and curtain air bags will deflate quickly after the collision is over.
The side air bags and curtain air bags operate only when the ignition switch is in the ON position.
After pushing the ignition switch to the ON position, the supplemental air bag warn­ing light illuminates. The air bag warning light will turn off after about 7 seconds if the systems are operational.
. Do not place any objects near the
seatback of the front seats. Also, do not place any objects (an umbrella, bag, etc.) between the front door finisher and the front seat. Such objects may become dangerous projectiles and cause injury if side air bag inflates.
. Right after inflation, several side air
bags and curtain air bag system compo­nents will be hot. Do not touch them; you may severely burn yourself.
. No unauthorized changes should be
made to any components or wiring of side air bag and curtain air bags. This is to prevent damage to or accidental inflation of the side air bag and curtain air bag systems.
. Do not make unauthorized changes to
your vehicles electrical system, suspen­sion system or side panel. This could affect proper operation of the side air bag and curtain air bag systems.
. Tampering with the air bag system may
result in serious personal injury. For example, do not change the front seats by placing material near the seatback or
1-48 Safety Seats, seat belts and supplemental restraint system
WARNING
by installing additional trim material, such as seat covers, around the side air bags.
. Work around and on the side air bag and
curtain air bag systems should be done by an INFINITI retailer. Installation of electrical equipment should also be done by an INFINITI retailer. The Supple­mental Restraint System (SRS) wiring harnesses* should not be modified or disconnected. Unauthorized electrical test equipment and probing devices should not be used on the side-impact air bag system.
* The SRS wiring harness connectors
are yellow and orange for easy identification.
When selling your vehicle, we request that you inform the buyer about the side air bag and curtain air bag systems and guide the buyer to the appropriate sections in this Owners Manual.
Page 82
SEAT BELTS WITH PRETENSIONERS (front seats)
WARNING
. The pretensioners cannot be reused after
activation. They must be replaced to­gether with the retractor and buckle as a unit.
. If the vehicle becomes involved in a
collision but a pretensioner is not activated, be sure to have the preten­sioner system checked and, if necessary, replaced by an INFINITI retailer.
. No unauthorized changes should be
made to any components or wiring of the pretensioners. This is to prevent damage to or accidental activation of the pretensioner system. Tampering with the pretensioner system may result in ser­ious personal injury.
. Work around and on the pretensioners
should be done by an INFINITI retailer. Installation of electrical equipment should also be done by an INFINITI retailer. Unauthorized electrical test equipment and probing devices should not be used on the pretensioner system.
. If you need to dispose of the preten-
sioner or scrap the vehicle, contact an INFINITI retailer. Correct pretensioner disposal procedures are set forth in the appropriate INFINITI Service Manual. Incorrect disposal procedures could cause personal injury.
The pretensioner system may activate with the supplemental air bag system in certain types of collisions. Working with the seat belt retractor, it helps tighten the seat belt when the vehicle becomes involved in certain types of collisions, helping to restrain front seat occupants.
The pretensioner is encased with the seat belt retractor. These seat belts are used the same way as conventional seat belts.
When a pretensioner seat belt activates, smoke is released and a loud noise may be heard. The smoke is not harmful, and it does not indicate a fire. Care should be taken not to inhale it as it may cause irritation and choking. Those with a history of a breathing condition should get fresh air promptly.
After pretensioner activation, load limiters allow the seat belt to release webbing (if necessary) to reduce forces against the
Safety Seats, seat belts and supplemental restraint system 1-49
chest. The supplemental air bag warning light
is used to indicate malfunctions in the pretensioner system. See Supplemental air bag warning light(P.1-50). If the operation of the supplemental air bag warning light illuminates, have the system checked by an INFINITI retailer.
When selling your vehicle, we request that you inform the buyer about the seat belt pretensioners and guide the buyer to the appropriate sections in this Owners Man­ual.
Page 83
SSS1016
SPA1097
servicing: . The supplemental air bag warning light
remains on after approximately 7 sec­onds.
. The supplemental air bag warning light
flashes intermittently.
. The supplemental air bag warning light
does not come on at all.
Under these conditions, the air bags and/ or pretensioner systems may not operate properly. They must be checked and repaired. Take your vehicle to the nearest INFINITI retailer.
SUPPLEMENTAL AIR BAG WARNING LABELS
Warning labels about the supplemental front-impact air bag systems are placed in the vehicle as shown in the illustration.
SRS air bag
The warning labels surface of the sun visors.
1
are located on the
*
SUPPLEMENTAL AIR BAG WARNING LIGHT
The supplemental air bag warning light, displaying monitors the circuits for the air bag systems, pretensioners and all related wiring.
When the ignition switch is in the ON position, the supplemental air bag warning light illuminates for about 7 seconds and then turns off. This means the SRS air bag systems are operational.
If any of the following conditions occur, the air bags and/or pretensioner systems need
1-50 Safety Seats, seat belts and supplemental restraint system
in the instrument panel,
WARNING
If the supplemental air bag warning light is on, it could mean that the air bags and/or pretensioner systems will not operate in an accident. To help avoid injury to yourself or others, have your vehicle checked by an INFINITI retailer as soon as possible.
Page 84
REPAIR AND REPLACEMENT PROCE­DURE
The front air bags, side air bags, curtain air bags and pretensioners are designed to activate on a one-time-only basis. As a reminder, unless it is damaged, the sup­plemental air bag warning light will remain illuminated after inflation has occurred. Repair and replacement of these systems should be done only by an INFINITI retailer.
When maintenance work is required on the vehicle, the front air bags, side air bags, curtain air bags, pretensioners and related parts should be pointed out to the person conducting the maintenance. The ignition switch should always be in the LOCK position when working under the hood or inside the vehicle.
WARNING
. Once a front air bag, side air bag, or
curtain air bag has inflated, the air bag module will not function again and must be replaced. Additionally, the activated pretensioner must also be replaced. The air bag module and pretensioner should be replaced by an INFINITI retailer. The
air bag module and pretensioner system cannot be repaired.
. The front air bag, side air bag, curtain air
bag and the pretensioner system should be inspected by an INFINITI retailer if there is any damage to the front end or side portion of the vehicle.
. If you need to dispose of the supple-
mental air bag or pretensioner or scrap the vehicle, contact an INFINITI retailer. Correct supplemental air bag and seat belt pretensioner system disposal pro­cedures are set forth in the appropriate INFINITI Service Manual. Incorrect dis­posal procedures could cause personal injury.
Safety Seats, seat belts and supplemental restraint system 1-51
Page 85
MEMO
1-52 Safety Seats, seat belts and supplemental restraint system
Page 86
2 Instruments and controls
Cockpit................................................................ 2-3
Instrument panel ................................................. 2-5
Meters and gauges.............................................. 2-6
Speedometer and odometer ............................ 2-7
Tachometer...................................................... 2-8
Assist charge gauge........................................ 2-8
Fuel gauge ...................................................... 2-8
Warning/indicator lights and
audible reminders ............................................. 2-10
Checking bulbs.............................................. 2-11
Warning lights............................................... 2-11
Indicator lights .............................................. 2-17
Audible reminders ......................................... 2-20
Dot matrix liquid crystal display ........................ 2-21
Operational indicators ................................... 2-23
Maintenance indicators ................................. 2-26
Trip computer................................................ 2-28
Security systems ............................................... 2-32
Vehicle Security System ................................ 2-32
INFINITI Vehicle Immobilizer System .............. 2-34
Windshield wiper and washer switch ................. 2-35
Rain-sensing auto wiper system .................... 2-36
Rear window and outside mirror
defroster switch................................................. 2-37
Headlight and turn signal switch ....................... 2-38
Xenon headlights......................................... 2-38
Headlight switch .......................................... 2-38
Turn signal switch........................................ 2-43
Fog light switch ........................................... 2-43
Heated steering wheel (if so equipped) ............. 2-43
Horn ................................................................. 2-44
Heated seats (if so equipped) ........................... 2-44
Climate controlled seats (if so equipped) .......... 2-46
Warning systems switch (if so equipped) .......... 2-47
Intelligent Brake Assist (IBA) OFF switch
(if so equipped) ................................................ 2-47
Vehicle Dynamic Control (VDC) OFF switch ......... 2-48
Clock................................................................. 2-49
Adjusting the time ....................................... 2-49
Power outlet ..................................................... 2-49
Cigarette lighter and ashtrays ........................... 2-50
Front............................................................ 2-50
Rear............................................................. 2-50
Storage............................................................. 2-51
Cup holders ................................................. 2-51
Sunglasses holder ...................................... 2-52
Glove box .................................................... 2-52
Console box................................................. 2-53
Card holder.................................................. 2-53
Rear pocket ................................................. 2-54
Page 87
Coat hooks.................................................... 2-54
Trunk hooks .................................................. 2-54
Windows ........................................................... 2-55
Power windows ............................................. 2-55
Moonroof........................................................... 2-57
Power moonroof ............................................ 2-58
Rear sunshade (if so equipped) ......................... 2-59
Welcome light.................................................... 2-60
Battery saver system..................................... 2-60
Interior lights..................................................... 2-61
Map lights..................................................... 2-61
Personal lights .............................................. 2-61
Interior light control switch............................ 2-62
Vanity mirror lights ........................................... 2-63
Trunk light ........................................................ 2-63
HomeLink
®
Universal Transceiver ...................... 2-63
Programming HomeLink Programming HomeLink
customers and gate openers........................ 2-66
Operating the HomeLink
®
............................. 2-64
®
for Canadian
®
Universal Transceiver ................................... 2-66
Programming troubleshooting ...................... 2-66
Clearing the programmed information.......... 2-67
Reprogramming a single HomeLink
®
button....................................... 2-67
If your vehicle is stolen ............................... 2-67
Page 88
COCKPIT
1. Instrument brightness control switch (P.2-42)
2. AFS switch (if so equipped) (P.2-40)
3. Headlight, fog light and turn signal switch (P.2-38)
4. Trip computer switch (P.2-28)
JVC0259X
5. TRIP/RESET switch for twin trip od­ometer (P.2-7)
6. Windshield wiper and washer switch (P.2-35)
7. Shift lever (P.5-14)
8. Vehicle Dynamic Control (VDC) OFF switch (P.5-100)
9. Rear sunshade switch (if so equipped) (P.2-59)
10. Steering heater switch (if so equipped) (P.2-43)
11. Trunk lid release switch (P.3-17)
12. Sonar system off switch (if so equipped) (P.5-95)
13. Warning systems switch (if so equipped) (P.5-21, P.5-31, P.5-82)
14. Intelligent Brake Assist (IBA) OFF switch (if so equipped) (P.5-86)
15. Electric tilting/telescopic steering wheel lever (P.3-22)
16. Steering-wheel-mounted controls (left side)
Menu control switch (models with navigation system)/Audio tuning switch (models without navigation system) (P.4-82)
Hands-Free Phone System switch (P.4-97, P.4-86)
17. Steering wheel
Horn (P.2-44)Driver supplemental air bag
(P.1-37)
Instruments and controls 2-3
Page 89
Heated steering wheel (if so equipped) (P.2-43)
18. Steering-wheel-mounted controls (right side)
Cruise control switches (P.5-46)Intelligent Cruise Control (ICC)
switches (if so equipped) (P.5-48) Dynamic driver assistance switch
(if so equipped) (P.5-21, P.5-31, P.5-69)
2-4 Instruments and controls
Page 90
INSTRUMENT PANEL
1. Side ventilator (P.4-33)
2. Meters and gauges (P.2-6)
3. Hazard warning flasher switch (P.6-2)
4. Rear window and outside mirror defroster switch (P.2-37)
5. Center display (P.4-4)/Navigation sys-
JVO0132X
tem* (if so equipped)
6. Clock (P.2-49)
7. Center multi-function control panel Navigation system* (if so
equipped)
Vehicle information and setting buttons (P.4-10)
Bluetooth
®
Hands-Free Phone Sys-
tem (P.4-84, P.4-95) Audio system (P.4-48)
8. Automatic climate control system (P.4-34)/Forest Air
®
system* (P.4-34)
9. Center ventilator (P.4-33)
10. Audio system (P.4-48)
11. Front passenger supplemental air bag (P.1-37)
12. Hood release handle (P.3-16)
13. Fuse box cover (P.8-24)
14. Parking brake Parking (P.5-18)
15. Push-button ignition switch (P.5-9)
16. Front passenger air bag status light (P.1-44)
17. Climate controlled seat switch (if so equipped) (P.2-46)/Seat heater switch (if so equipped) (P.2-44)
18. Drive mode select switch (P.5-18)
19. Cigarette lighter and ashtray (P.2-50)
20. Glove box lid release handle (P.2-52)
21. Trunk release power cancel switch (P.3-18)
*: Refer to the separate Navigation
System Owners Manual.
Instruments and controls 2-5
Page 91
METERS AND GAUGES
1. Tachometer (P.2-8)
2. Warning/Indicator lights (P.2-10)
3. Speedometer (P.2-7)
4. Assist charge gauge (P.2-8)
*: The needle indicators in the speed­ometer, tachometer, assist charge gauge and fuel gauge may move slightly after the ignition switch is pushed to the LOCK position. This is not a malfunction.
CAUTION
. For cleaning, use a soft cloth, dampened
with water. Never use a rough cloth, alcohol, benzine, thinner or any kind of solvent or paper towel with a chemical cleaning agent. They will scratch or cause discoloration to the lens.
. Do not spray any liquid such as water on
the meter lens. Spraying liquid may cause the system to malfunction.
JVI0200X
5. Dot matrix liquid crystal display/ Odometer/twin trip odometer (P.2-21)
6. Fuel gauge (P.2-8)
2-6 Instruments and controls
Page 92
TRIP A ? TRIP B ? TRIP A
Resetting the trip odometer:
Pushing the TRIP RESET switch than 1 second resets the trip odometer to zero.
Average fuel economy and distance to empty information is also available. (See Dot matrix liquid crystal display(P.2-21) and How to use STATUS button(P.4-10).)
*
3
for more
SIC4318
Speedometer
SPEEDOMETER AND ODOMETER
Speedometer
The speedometer indicates vehicle speed in miles per hour (MPH) and kilometers per hour (km/h).
SIC4319
Odometer/twin trip odometer
Odometer/twin trip odometer
The odometer
2
are displayed on the dot matrix liquid
*
crystal display when the ignition switch is in the ON position.
The odometer records the total distance the vehicle has been driven.
The twin trip odometer records the dis­tance of individual trips.
Changing the display:
Pushing the TRIP RESET switch right of the combination meter panel changes the display as follows:
1
and twin trip odometer
*
*
3
on the
Instruments and controls 2-7
Page 93
JVI0196X
JVI0197X
JVI0846X
TACHOMETER
The tachometer indicates engine speed in revolutions per minute (RPM). Do not rev
the engine into the red zone
The scale length and the red zone vary with the engine model.
*
1
.
CAUTION
When engine speed approaches the red zone, shift to a higher gear or reduce engine speed. Operating the engine in the red zone may cause serious engine damage.
2-8 Instruments and controls
ASSIST CHARGE GAUGE
The gauge indicates the condition of the electric motor.
When the needle is between the center and the PWR electric motor is powering the drive wheels and the Lithium-ion (Li-ion) battery is discharging.
When the needle is between the center and CHG electric motor is generating power to recharge the Li-ion battery.
1
side, this indicates that the
*
2
side, this indicates that the
*
FUEL GAUGE
The gauge indicates the approximate fuel level in the tank.
The gauge may move slightly during braking, turning, acceleration, or going up or down hills.
The gauge needle returns to 0(Empty) after the ignition switch is pushed to the OFF position.
Refill the fuel tank before the gauge registers 0(Empty).
The low fuel warning dot matrix liquid crystal display when the fuel level is getting low. Refuel as soon as
appears on the
Page 94
it is convenient, preferably before the gauge reaches 0. There will be a small reserve of fuel in the tank when the fuel gauge needle reaches 0.
The located on the right side of the vehicle.
indicates that the fuel-filler door is
CAUTION
. When the fuel gauge reads 0, put a
minimum of 4 US gallons (15 liters) of gasoline in the fuel tank. If there is less than 4 US gallons (15 liters) in the tunk, the hybrid system may not start.
. If the vehicle runs out of fuel, the
malfunction indicator light (MIL) may come on. Refuel as soon as possible. After a few driving trips, the should turn off. If the light remains on after a few driving trips, have the vehicle inspected by an INFINITI retailer.
For additional information, see Malfunction Indicator Light (MIL) (P.2-19).
light
Instruments and controls 2-9
Page 95
WARNING/INDICATOR LIGHTS AND AUDIBLE REMINDERS
12-volt battery charge warning light Master warning light
Anti-lock Braking System (ABS) warning light
Blind Spot Warning (BSW)/Blind Spot Inter­vention (BSI) system warning light (orange)*
Brake system warning light (yellow) Vehicle Dynamic Control (VDC) warning light Security indicator light
Brake warning light (red)
Direct Response Hybrid®System warning light
Distance Control Assist (DCA) system warning light (orange)*
Engine oil pressure warning light ECO drive indicator light
High temperature warning light EV indicator light
Hybrid EPS (Electrical Power Steering) warn­ing light
Intelligent Cruise Control (ICC) system warn­ing light (orange)*
Lane Departure Warning (LDW) light (orange)* Front passenger air bag status light
Low tire pressure warning light High beam indicator light
Preview Function warning light (orange)* Lane Departure Warning (LDW) light (green)*
Seat belt warning light and chime Malfunction Indicator Light (MIL)
Supplemental air bag warning light READY to drive indicator light
Adaptive Front lighting System (AFS) off indicator light*
Approaching Vehicle Sound for Pedestrians (VSP) OFF indicator light
Automatic transmission (AT) position indica­tor light
Blind Spot Intervention (BSI) ON indicator light (green)*
Exterior light indicator
Front fog light indicator light
*: if so equipped
Intelligent Brake Assist (IBA) off indicator light*
Turn signal/hazard indicator lights
Vehicle Dynamic Control (VDC) off indicator light
2-10 Instruments and controls
Page 96
CHECKING BULBS
With all doors closed, apply the parking brake and push the ignition switch to the ON position without starting the INFINITI Direct Response Hybrid following lights will come on (if so equipped):
, or , , , , , , ,
The following lights come on briefly and then go off (if so equipped):
, , or , , , , , , ,
If any light does not come on, it may indicate a burned-out bulb or an open circuit in the electrical system. Have the system checked by an INFINITI retailer.
Some indicators and warnings are also displayed on the dot matrix liquid crystal display between the speedometer and tachometer. (See Dot matrix liquid crystal display(P.2-21).)
®
System. The
WARNING LIGHTS
12-volt battery charge warning
light
If the light comes on when the ignition switch is in the ON position, it may indicate the charging system is not functioning properly. See an INFINITI retailer immedi­ately.
CAUTION
The charging system may not be functioning properly if the 12-volt battery charge warn­ing light comes on while the hybrid system is running. The hybrid system will stop operating when the 12-volt battery becomes discharged. Immediately stop the vehicle in a safe place and contact your INFINITI retailer.
or Anti-lock Braking
System (ABS) warning light
When the ignition switch is in the ON position, the Anti-lock Braking System (ABS) warning light illuminates and then turns off. This indicates the ABS is opera­tional.
If the ABS warning light illuminates while the hybrid system is running, or while driving, it may indicate the ABS is not functioning properly. Have the system checked by an INFINITI retailer.
If an ABS malfunction occurs, the anti-lock function is turned off. The brake system then operates normally, but without anti­lock assistance. (See Brake system(P.5-
96).)
Blind Spot Warning (BSW)/ Blind Spot Intervention (BSI) sys­tem warning light (orange; if so equipped)
When the ignition switch is pushed to the ON position, the indicator light will first illuminate in orange and turn green before turning off. This indicates that the Blind Spot Warning (BSW) and Blind Spot Inter­vention (BSI) systems are operational.
If the light comes on in orange and remains on, it may indicate that the BSW and BSI systems are not functioning properly. Although the vehicle is still driveable, have the systems checked by an INFINITI retailer. See Blind Spot Warning (BSW) system/ Blind Spot Intervention (P.5-31).
TM
(BSI) system
Instruments and controls 2-11
Page 97
Brake system warning light
(yellow)
This light will illuminate after the hybrid system is started and then turns off after a few seconds.
WARNING
If both the brake system warning light (yellow) and the brake warning light (red) illuminate when the parking brake is re­leased and the hybrid system is on, do not drive the vehicle. More brake pedal effort than normal will be required and there will be a significant reduction in brake perfor­mance, which could result in an accident. Immediately stop the vehicle in a safe location and contact an INFINITI retailer.
If the brake system warning light (yellow) illuminates when the ignition switch is in the ON position, it may indicate a malfunc­tion in the brake system or one of the following other functions.
. Regenerative brake system . Hill start assist system . Rise-up and build-up function
See an INFINITI retailer for an inspection as soon as possible.
A chime sounds if a malfunction occurs in the brake system power supply.
or Brake warning light
(red)
This light functions for both the parking brake and the foot brake systems.
Parking brake indicator:
When the ignition switch is in the ON position, the light comes on when the parking brake is applied.
Low brake fluid warning:
When the ignition switch is in the ON position, the light warns of a low brake fluid level. If the light comes on with the parking brake not applied, stop the vehicle and perform the following:
1. Check the brake fluid level. If brake fluid is low, add fluid and have the system checked by your INFINITI retai­ler. (See Brake fluid(P.8-16).)
2. If the brake fluid level is correct, have the warning system checked by an INFINITI retailer.
Brake system malfunction warning:
If the brake warning light (red) and the following warning light illuminate at the same time when the parking brake is released and the brake fluid level is sufficient, there may be a malfunction in the brake system.
. Brake system warning light (yellow)
WARNING
If both the brake system warning light (yellow) and the brake warning light (red) illuminate when the parking brake is re­leased and the hybrid system is on, do not drive the vehicle. More brake pedal effort than normal will be required and there will be a significant reduction in brake perfor­mance, which could result in an accident. Immediately stop the vehicle in a safe location and contact an INFINITI retailer.
A chime sounds if a malfunction occurs in the brake system power supply.
. Anti-lock Braking System (ABS) warning
light Avoid driving at high speed and
sudden braking, and see an INFINITI
2-12 Instruments and controls
Page 98
retailer as soon as possible for an inspection.
WARNING
. Your brake system may not be working
properly if the brake warning light (red) is on. Driving could be dangerous. If you judge it to be safe, drive carefully to the nearest serv ice station for repairs. Otherwise, have your vehicle towed because driving it could be dangerous.
. Pressing the brake pedal with the hybrid
system stopped and/or low brake fluid level may increase your stopping dis­tance and braking will require greater pedal effort as well as pedal travel.
. If the brake fluid level is below the
minimum or MIN mark on the brake fluid reservoir, do not drive until the brake system has been checked at an INFINITI retailer.
Direct Response Hybrid®Sys-
tem warning light
When the ignition switch is in the "ON" position, the Direct Response Hybrid System warning light illuminates. After
starting the hybrid system, the hybrid system warning light turns off.
If the hybrid system warning light illumi­nates while driving, it may indicate that there is a malfunction in the electric motor and/or other hybrid system components.
Stop your vehicle immediately and contact your INFINITI retailer.
If the hybrid system warning light blinks while driving, it may indicate that the Li-ion battery charge is low and you cannot continue to drive.
Do not allow the vehicle to coast when the Li-ion battery is low or when the hybrid system warning light blinks while driving. The engine will not automatically start to charge the Li-ion battery while the vehicle is coasting.
Distance Control Assist (DCA) system warning light (orange; if so equipped)
This light comes on if there is a malfunc­tion in the Distance Control Assist (DCA) system.
If the warning light illuminates, park the vehicle in a safe place. Stop the hybrid
®
system, restart the hybrid system, resume
driving and turn on the DCA system again.
If it is not possible to turn on the system or the warning light stays on, it may indicate that the system is malfunctioning. Although the vehicle is still driveable under normal conditions, have the vehicle checked at an INFINITI retailer.
Engine oil pressure warning
light
This light warns of low engine oil pressure. If the light flickers or comes on during normal driving, pull off the road in a safe area, stop the engine immediately and call an INFINITI retailer or other authorized repair shop.
The engine oil pressure warning light is not designed to indicate a low oil level. Use the dipstick to check the oil level. (See
Engine oil(P.8-12).)
CAUTION
Running the engine with the engine oil pressure warning light on could cause serious damage to the engine almost immediately. Such damage is not covered by warranty. Turn off the engine as soon as
Instruments and controls 2-13
Page 99
it is safe to do so.
High temperature warning
light
When the ignition switch is in the ON position, the high temperature warning light illuminates and then turns off. This indicates that the high temperature sensor in the engine coolant system is opera­tional.
CAUTION
If the high temperature warning light illuminates when the ignition switch is in the ON position, it may indicate the engine temperature is extremely high.
Stop the vehicle safety as soon as possible.
If the vehicle is overheated, continuing vehicle operation may seriously damage the engine. (See If your vehicle overheats (P.6-12) for the immediate action required.)
Hybrid EPS (Electrical Power
Steering) warning light
When the ignition switch is in the ON
2-14 Instruments and controls
position, the Hybrid EPS (Electrical Power Steering) warning light illuminates. After starting the hybrid system, the Hybrid EPS warning light turns off. This indicates that the electrical power steering system is operational.
If the Hybrid EPS warning light illuminates while the hybrid system is running, it may indicates the Hybrid EPS system is not functioning properly and may need servi­cing. Have the Hybrid EPS system checked by an INFINITI retailer.
When the Hybrid EPS warning light illumi­nates with the hybrid system running, the power assist to the steering will cease operation but you will still have control of the vehicle. At this time, greater steering efforts are required to operate the steering wheel, especially in sharp turns and at low speeds. However, if the steering wheel operation is still performed, the Hybrid EPS may stop and the Hybrid EPS warning light will illuminate. Place the ignition switch in the OFF position. For a while after it refrains from the steering wheel control, the temperature of the Hybrid EPS system will go down and the power assist level will return to normal after starti ng the hybrid system. The Hybrid EPS warning light will
go off.
Intelligent Cruise Control (ICC) system warning light (orange; if so equipped)
This light comes on if there is a malfunc­tion in the Intelligent Cruise Control (ICC) system.
If the warning light comes on, park the vehicle in a safe place. Stop the hybrid system, restart the hybrid system, resume driving and set the ICC system again.
If it is not possible to set the system or the indicator stays on, it may indicate that the system is malfunctioning. Although the vehicle is still driveable under normal conditions, have the vehicle checked at an INFINITI retailer.
Lane Departure Warning (LDW) light (orange; if so equipped)
When the ignition switch is pushed to the ON position, the light will come on in orange, turn green, and then turn off. This indicates that the Lane Departure Warning (LDW) and Lane Departure Prevention (LDP) systems are operational.
While the LDW and/or LDP system is on, the light will blink in orange and a warning
Page 100
chime will sound if the vehicle is traveling close to either the left or the right of a traveling lane with detectable lane mar­kers.
If the light comes on in orange and remains on, it may indicate that the LDW and LDP systems are not functioning properly. Have the systems checked by an INFINITI retailer.
See Lane Departure Warning (LDW) sys­tem/Lane Departure Prevention (LDP) sys­tem(P.5-21).
Low tire pressure warning
light
Your vehicle is equipped with a Tire Pressure Monitoring System (TPMS) that monitors the tire pressure of all tires except the spare.
The low tire pressure warning light warns of low tire pressure or indicates that the TPMS is not functioning properly.
After the ignition switch is pushed ON, this light illuminates for about 1 second and turns off.
Low tire pressure warning:
If the vehicle is being driven with low tire pressure, the warning light will illuminate. A CHECK TIRE PRESSURE warning also
appears in the dot matrix liquid crystal display.
If you select tire pressure information in the display, the LOW PRESSURE warning message will be displayed. The tire pres­sure for each tire will also be displayed.
When the low tire pressure warning light illuminates, you should stop and adjust the tire pressure to the recommended COLD tire pressure shown on the Tire and Loading Information label. The low tire pressure warning light does not automati­cally turn off when the tire pressure is adjusted. After the tire is inflated to the recommended pressure, the vehicle must be driven at speeds above 16 MPH (25 km/h) to activate the TPMS and turn off the low tire pressure warning light. Use a tire pressure gauge to check the tire pressure.
The CHECK TIRE PRESSURE warning is active as long as the low tire pressure warning light remains illuminated.
For additional information, see Dot matrix liquid crystal display(P.2-21), Tire Pres­sure Monitoring System (TPMS) (P.5-4) and Tire Pressure Monitoring System (TPMS) (P.6-3).
TPMS malfunction:
If the TPMS is not functioning properly, the low tire pressure warning light will flash for approximately 1 minute when the ignition switch is pushed ON. The light will remain on after the 1 minute. Have the system checked by an INFINITI retailer. THE CHECK TIRE PRESSURE warning does not appear if the low tire pressure warning light illumi­nates to indicate a TPMS malfunction.
For additional information, see Tire Pres­sure Monitoring System (TPMS) (P.5-4).
WARNING
. If the light does not illuminate with the
ignition switch pushed ON, have the vehicle checked by an INFINITI retailer as soon as possible.
. If the light illuminates while driving,
avoid sudden steering maneuvers or abrupt braking, reduce vehicle speed, pull off the road to a safe location and stop the vehicle as soon as possible. Driving with under-inflated tires may permanently damage the tires and in­crease the likelihood of tire failure. Serious vehicle damage could occur
Instruments and controls 2-15
Loading...
