Inalto IO99 User Manual

MODEL CODE/S

IO99

PRODUCT

MULTI—
FUNCTION
OVEN

DOCUMENT

USER
MANUAL

USER MANUAL

PAGE 02

Dear Customer, Congratulations on purchasing your new oven. The

Inalto brand is proudly distributed within Australia by
Residentia Group Pty Ltd.

Please refer to the warranty card at the rear of this
manual for information regarding your product’s
parts and labour warranty, or visit us online at
www.residentiagroup.com.au.

At Residentia Group, we are customer obsessed and
our Support Team are there to ensure you get the most
out of your appliance. Should you want to learn more
about recommended cooking temperatures, the various
cooking functions available, how to set and program
your LED clock, and importantly taking care of your
appliance when cleaning, our Support Team are here to
help. You can use our online Support Centre at anytime
by visiting http://support.residentiagroup.com.au, or you
can contact us via phone by dialling 1300 11 HELP (4357).

It is important that you read through the following use
and care manual thoroughly to familiarise yourself with
the installation and operation requirements of your
appliance to ensure optimum performance.

Again, thank you for choosing an Inalto appliance and
we look forward to being of service to you.

Kind Regards,

The Residentia Team

T 1300 11 4357
E [e-mail]
W residentiagroup.com.au
ACN

600 546 656

Residentia Group

PO Box 581
Stanhope Gardens
NSW Australia 2768

PAGE 03

PAGE CONTENT

04 SAFETY
INSTRUCTIONS

06 YOUR INALTO

OVEN

08 INSTALLATION
INSTRUCTIONS

11 OPERATING

YOUR OVEN

15 CLEANING &
MAINTENANCE

17 TROUBLESHOOTING

& TECHNICAL DATA

18 WARRANTY
INFORMATION
19 PURCHASE
DETAILS

USER MANUAL

PAGE 04

This oven must only be installed by a suitably qualified
and licenced person and in accordance with the
instructions provided. Incorrect installation may
cause harm to persons, damage property and void
the product’s warranty.

IMPORTANT!

The power supply to the oven must be cut off before any
adjustments or maintenance work is undertaken.

WARNING

When using this product, basic precautions should always
be taken including the following:

► This oven is designed for domestic household use and

for the cooking of domestic foodstuffs.

IMPORTANT!
Your built-in oven is an electrical appliance and as with
any electrical appliance (particularly with electric heating
elements), basic precautions must be followed in order to
reduce the risk of fire, burns, electrical shocks and/or other
serious injuries or even death.

► The appliance becomes hot during operation. Take care

not to touch the hot parts inside the oven.

► This appliance is not intended for use by persons

(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.

► Children should be supervised to ensure that they do

not play with the appliance.

► While in operation direct contact with the oven may

cause burns!

► Ensure that small items of household equipment,

including connection leads, do not touch the hot oven
as the insulation material of this equipment is usually
not resistant to high temperatures.

► Do not leave the oven unattended when cooking. Oils

and fats may catch fire due to overheating.
► Do not put pans on the opened door of the oven.
► Do not use harsh cleaning agents or sharp metal objects

to clean the door as they can scratch the surface, which

could then result in the glass cracking.
► Do not use the oven in the event of a technical fault.

Any faults must be fixed by an appropriately qualified

and authorised Residentia Group service agent. Refer to

the warranty section at the rear of this user manual.
► In the event of any incident caused by a technical fault,

disconnect the power and report the fault to the service

centre to be repaired.
► The rules and provisions contained in this instruction

manual should be strictly observed.
► Do not allow anybody who is not familiar with the

contents of this instruction manual to operate the oven.
► The oven should not be cleaned using steam-cleaning

equipment, as damage can occur to the inner electrical

components.
► The panels adjacent to the oven must be made of heat-

resistant material, or heat deflectors installed.
► Cabinets with a veneer exterior must be assembled with

glues, which can withstand temperature of up to 100

degrees Celsius.
► Keep combustible materials such as: curtains, drapes,

furniture, pillows, clothing, linens, bedding, paper, etc.

at least 900mm from the front sides and rear of the

oven.
► Do not use this oven in areas where fuel, paint or other

flammable liquids or their associated vapours may be

present.

SAFETY INSTRUCTIONS

PAGE 05

► To reduce the risk of fire, do not place or install this

oven in areas where the ventilation or circulation ducts
may become blocked.

► The oven’s power cord must be connected to a properly

grounded and protected, 220-240V electrical outlet.
Always use ground fault protection where required by
the electrical code.

► This oven is hard-wired and an extension cord should

not be used.

► When transporting or storing the unit, keep it in a dry

location, free from dust, excessive vibration or other
factors, which may damage the unit.

► Do not operate any oven with a damaged cord or plug,

after the heater malfunctions or has been dropped
or damaged in any manner. Return the oven to an
authorised Residentia Group service centre to be
checked.

► If the supply cord is damaged, it must be replaced by

a special cord or assembly available from Residentia
Group or its authorised service agent.

► Use this oven only as described in this manual. Any

other use not recommended by the manufacturer may
cause fire, electric shock, or injury to persons.

► Never add cold water to food on a hot universal tray

or baking tray or directly onto food in a hot oven. The
steam created could cause serious burns or scalding
and the sudden change in temperature can damage the
enamel.

► Do not lift the oven by the handle.

DECLARATION OF CONFORMITY

This appliance complies with the following Australian/
European Directives:

— 2006/95/CE General regulations / Low tension
— 1935/2004/CE 90/128/EEC This appliance is suitable to

come in contact with food
— 2004/108/CE Electromagnetic compatibility
— Low voltage – 73/23
— Safety standards – EN 60335-1, EN30-1-1, AS/NZS 3350-

1,3350-2-6

The manufacturer declares that the oven is built using
certified materials and requires the appliance to be installed
in accordance with the standards currently in force. This
oven should only be used by a trained person and for
domestic purposes only.

UNPACKING

During transportation, protective packaging was used to
protect the appliance against any damage. After unpacking,
please dispose of all elements of packaging in a way that will
not cause damage to the environment. All materials used for
packaging the appliance are environmentally friendly; they
are 100% recyclable and are marked with the appropriate
symbol.

► During unpacking, the packaging materials (polythene

bags, polystyrene pieces, etc.) should be kept out of
reach of children.

DISPOSAL OF THE APPLIANCE

Old appliances should not simply be disposed of with
normal household waste, but should be delivered to a
collection and recycling centre for electric and electronic
equipment. A symbol shown on the product, the instruction
manual or the packaging shows that it is suitable for
recycling.

Materials used inside the appliance are recyclable and are
labelled with information concerning this. By recycling
materials or other parts from used devices you are
making a significant contribution to the protection of our
environment.

Information on appropriate disposal centres for used
devices can be provided by your local authority.

USER MANUAL

PAGE 06

CONTROLS

KEY
—

1. Oven indicator light— this light indicates that the oven is heating. When the oven reaches the desired temperature,

the indicator light will switch off.

2. Temperature knob— this knob allows you to set your ovens cooking temperature.

3. Digital Timer— programmable touch control digital timer.

4. Cooking mode knob— this knob allows you to set your ovens cooking function.

YOUR INALTO OVEN

1

2

3

4
