Inalto II64T User Manual

MODEL CODE/S

II64T

PRODUCT

INDUCTION
COOKTOP

DOCUMENT

USER
MANUAL

USER MANUAL PAGE 02 PAGE 03

PAGE CONTENT

04 SAFETY
INSTRUCTIONS

06 YOUR INALTO

COOKTOP

07 INSTALLATION
INSTRUCTIONS

10 OPERATING

YOUR COOKTOP

14 CLEANING &
MAINTENANCE

15 TROUBLESHOOTING
17 TECHNICAL DATA
18 WARRANTY

INFORMATION
19 PURCHASE

DETAILS

Dear Customer, Congratulations on purchasing your new induction

cooktop. The Inalto brand is proudly distributed within
Australia by Residentia Group Pty Ltd.

Please refer to the warranty card at the rear of this
manual for information regarding your product’s
parts and labour warranty, or visit us online at
www.residentiagroup.com.au.

At Residentia Group, we are customer obsessed and
our Support Team are there to ensure you get the most
out of your appliance. Should you want to learn more
about recommended cooking temperatures, the various
cooking functions available and importantly taking care
of your appliance when cleaning, our Support Team are
here to help.

You can use our online Support Centre at anytime by
visiting http://support.residentiagroup.com.au, or you
can contact us via phone by dialling 1300 11 HELP (4357).

It is important that you read through the following use
and care manual thoroughly to familiarise yourself with
the installation and operation requirements of your
appliance to ensure optimum performance.

Again, thank you for choosing an Inalto appliance and
we look forward to being of service to you.

Kind Regards,

The Residentia Team

T 1300 11 4357
E [e-mail]
W residentiagroup.com.au
ACN

600 546 656

Residentia Group

PO Box 581
Stanhope Gardens
NSW Australia 2768

USER MANUAL PAGE 04 PAGE 05

This cooktop must only be installed by a suitably
qualified and licenced person and in accordance with
the instructions provided. Incorrect installation may
cause harm to persons, damage property and void
the product’s warranty.

IMPORTANT!

The electricity supply to the cooktop must be cut off before
any adjustments or maintenance work is undertaken.

WARNING

When using this product, basic precautions should always
be taken including the following:

► This cooktop is designed for domestic household use

and for the cooking and frying of domestic foodstuffs.

IMPORTANT!
The adjacent furniture and all materials used in the
installation must be able to withstand a minimum
temperature of 85°C above the ambient temperature
of the room it is located in, whilst in use.

► Certain types of vinyl or laminate kitchen cabinetry

are particularly prone to heat damage or discolouration
at temperatures above the guidelines given.

► Any damage caused by the cooktop being installed in

contravention of this temperature limit, will be the
liability of the owner.

► Your new cooktop is guaranteed against electrical or

mechanical defects, subject to certain exclusions that
are noted in the Warranty Terms and Conditions (at the
rear of this user manual). The foregoing does not affect
your statutory rights.

► The use of this cooktop for any other purpose or in any

other environment, without the express agreement
of Residentia Group, will invalidate any warranty or
liability claim.

► You should not use this appliance to store items on or

as a work surface.

► No modifications to the appliance are permitted by

Residentia Group.

► You should not store or place flammable or highly

flammable liquids/materials on top of or near the
appliance. Items made from aluminium, plastic
or plastic film should also be kept away from the
appliance, as they may fuse to the surface.

► Repairs may only be carried out by authorised service

agents.

► Your Inalto cooktop is not to be used by children or

persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction.

► Any film or stickers that are present on the cooktop

when it is delivered should be removed before use.

► Care should be used when utilising the cooktop,

otherwise there is a risk of burns being caused.

► You should not allow the electrical connection cables to

come into contact with the cooktop surface when it is
hot or any hot cookware.

► If fat and oil overheats, then it can ignite extremely

quickly. For this reason, when cooking with fat and oil
the appliance should not be left unattended.

► Make sure that all of the cooking zones are switched off

after use.

► Cleaning of the cooktop should be carried out on a

regular basis, once the cooktop has cooled down.

► Great care should be taken whilst using this appliance

and when following the cleaning procedure.

► You should not use a steam jet or any other high

pressure cleaning equipment to clean the appliance.

DECLARATION OF CONFORMITY

The manufacturer declares that the cooktop is built using
certified materials and requires the appliance to be installed
in accordance with the standards currently in force. This
appliance must be used by a trained person for domestic
purposes only.

TO AVOID DAMAGING YOUR COOKTOP

► The ceramic glass can be damaged by objects falling

onto it.

► The ceramic glass edge can be damaged by knocks from

cookware.

► Cast iron and cast aluminium cookware with damaged

bases may scratch the ceramic surface if they are
dragged across it.

► Pans should be lifted on and off the cooktop surface

and not dragged.

► Cooking zones should not be switched on without

cookware placed on it. Also the cookware should not be
empty.

UNPACKING

During transportation, protective packaging was used to
protect the appliance against any damage. After unpacking,
please dispose of all elements of packaging in a way that will
not cause damage to the environment. All materials used for
packaging the appliance are environmentally friendly; they
are 100% recyclable and are marked with the appropriate
symbol.

► During unpacking, the packaging materials (polythene

bags, polystyrene pieces, etc.) should be kept out of
reach of children.

DISPOSAL OF THE APPLIANCE

Old appliances should not simply be disposed of with
normal household waste, but should be delivered to a
collection and recycling centre for electric and electronic
equipment. A symbol shown on the product, the instruction
manual or the packaging shows that it is suitable for
recycling.

Materials used inside the appliance are recyclable and are
labelled with information concerning this. By recycling
materials or other parts from used devices you are
making a significant contribution to the protection of our
environment.

Information on appropriate disposal centres for used
devices can be provided by your local authority.

SAFETY INSTRUCTIONS

USER MANUAL PAGE 06 PAGE 07

SPECIFICATIONS

MODEL PRODUCT DIMENSIONS W×D×H CUTOUT DIMENSIONS W×D

II64T 590mm, 520mm, 56mm 560mm x 490mm

MODEL BURNERS OTHER

II64T

2 x 1.85/2.10 kW induction zones

(Ø 200mm)

2 x 1.40 kW induction zones

(Ø 160mm)

Touch control operation
Automatic pot/pan detection
4 individual residual heat indicators
Frameless

INDUCTION COOKTOP SURFACE LAYOUT

A 1.85 / 2.10 kW zones (Ø 200mm)
B 1.40 kW zone (Ø 160mm)

It’s important to carefully read the following installation instructions before beginning the installation of your cooktop.

IMPORTANT! The connection of this cooktop must be carried out by a suitably qualified and licensed person, in

accordance with the current version of the following:

► AS/NZS 3000: 2007 Wiring Regulations
► 2010 Electricity Safety Regulations
► The installation instructions within this user manual

POSITIONING

Warning. The adjacent furniture must be able to withstand a minimum temperature rise of 85°C above the ambient
temperature of the room it is located in, during periods of use.

This cooktop is to be built into a kitchen unit (depending on size) or 600mm cooktop that is at least 30mm thick. The
following minimum clearance distances must be observed:

► 700mm between the cooktop surface and the underside of any horizontal surface above it.
► 50mm clearance around the front and sides of the appliance, and 55mm clearance at the back of the appliance,

measured from the cut out, providing the material next to the cooktop is made of a non-combustible material.

► If the cooktop is positioned so that the right or left hand side of the appliance will be near to the edge of a kitchen unit.

There must be a gap of at least 150mm between the side of the cooktop and the vertical surface of the kitchen unit.

IMPORTANT! Underneath the appliance there MUST be a partition made of insulating material (e.g. wood). There

must be a gap of at least 20 mm between the underneath of the appliance and this partition.

 You must make sure that there is a 5mm gap below the underneath of the worktop at the front edge of the hob.

IMPORTANT! If you are installing this cooktop above an oven the oven MUST have a cooling fan.

INSTALLING THE COOKTOP

► Cut a hole in the bench top that corresponds with the relevant drawing on page 6.

YOUR INALTO COOKTOP INSTALLATION INSTRUCTIONS

TOUCH CONTROLS

A B

B A

590

520

56

Min. 65
