Page 1
MODEL/S
BAR
IBF112S
IBF112W
REFRIGERATOR
112L
V 1.0
USER MANUAL
Page 2
WELCOME
CONTENTS
Residentia Group Pty Ltd
ACN. 600 546 656
165 Barkly Avenue
Burnley, Victoria
Australia 3121
—
Applico Ltd
635 Great South Road
Penrose, Auckland 1061
New Zealand
Congratulations on purchasing your new appliance!
The InAlto brand is proudly distributed within Australia by esidentia
Group Pty Ltd and within New Zealand by Applico Ltd.
Please refer to the warranty card at the rear of this manual for
information regarding your product’s parts and labour warranty, or visit
online at:
– www.residentia.group
– www.applico.co.nz
– www.inalto.co.nz
Both esidentia Group & Applico are customer obsessed and our
Support Teams are there to ensure you get the most out of your
appliance. Should you want to learn more about recommended
temperatures, the various features of your refrigerator, and importantly
taking care of your appliance when cleaning, our Support Teams are
here to help.
Telephone Contacts:
– AU: 1300 11 4357
– NZ: 0800 763 448
It is important that you read through the following use and care manual
thoroughly to familiarise yourself with the installation and operation
requirements of your appliance to ensure optimum performance.
Again, thank you for choosing an InAlto appliance and we look forward
to being of service to you.
2 Welcome
5 General Safety
8 Product Overview
9 Getting Started
9 Installation
11 Using Your Bar fridge
12 Tips for Using the Appliance
12 Tips for Energy Saving
13 Maintenance and Cleaning
15 FAQs and Troubleshooting
18 Warranty
19 Specifications
19 Purchase Details
32
Page 3
This page
GENERAL SAFETY
is intentionally
left blank
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
Read this manual thoroughly before first use, even if you are familiar with this type of product.
The safety precautions enclosed herein reduce the risk of fire, electric shock and injury when correctly
adhered to. Make sure you understand all instructions and warnings.
Keep the manual in a safe place for future reference, along with the completed warranty card and
purchase receipt. If you sell or transfer ownership of this product, pass on these instructions to the
new owner.
Always follow basic safety precautions and accident prevention measures when using an electrical
appliance, including the following:
IMPORTANT: Pay particular attention to messages that contain the words DANGER, WARNING or
CAUTION. These words are used to alert you to a potential hazard that can seriously injure you and
others. The instructions will tell you how to reduce the chance of injury and let you know what can
happen if the instructions are not followed.
This symbol alerts you to take care as this appliance contains a flammable
refrigerant (isobutane) and insulation blowing gas (cyclopentane). Do not
expose it to high heat, sparks and open flames.
The refrigerant isobutane (R600a) is contained within the refrigerant circuit
of the appliance, a gas with a high level of environmental compatibility,
which is nevertheless flammable. During transportation and installation of
CAUTION
RISK OF FIRE
WARNING: Do not damage the refrigerant circuit! Never use an appliance with a damaged
refrigerant circuit! If the refrigerant circuit becomes damaged, avoid proximity to open fires and all
types of heat and ignition sources. Thoroughly ventilate the room in which the appliance is located.
the appliance, ensure that none of the components of the refrigerant circuit
become damaged.
DANGER: It is hazardous for anyone other than an authorised service person to service this appliance.
In Queensland, the authorised service person MUST hold a Gas Work Authorisation for hydrocarbon
refrigerants to carry out servicing or repairs which involve the removal of covers.
The room for installing the appliance must be at least 1m³ per 8g of refrigerant. The amount and type of
refrigerant in the appliance can be found in the Technical Specifications on page 17 and on the rating
plate, found on the appliance.
Usage Conditions and Restrictions
• Domestic use only: This appliance is intended for indoor household use only. It is not intended for
commercial, industrial or outdoor use. It is not intended for use in a recreational vehicle.
• Purpose: Do not use this appliance for anything other than its intended purpose. Other uses are not
recommended and may cause fire, electric shock or personal injury.
• Attachments: The use of attachments is not recommended by the appliance manufacturer and
distributor as they may be hazardous.
• Improper use: Damage due to improper use, or repairs made by unqualified personnel will void your
warranty. We assume no liability for any eventual damages caused by misuse of the product or
noncompliance with these instructions.
54
Page 4
General Safety Instructions Cont.
General Safety Instructions Cont.
• WARNING: Do not use mechanical devices or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
• Usage restriction: This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instructions concerning use of the appliance by a person responsible for their
safety.
• Children: Supervise young children to ensure they do not play with the appliance. Never allow
children to operate, play with or crawl inside the appliance.
• WARNING: Do not use electrical appliances inside the appliance, unless they are of the type
recommended by the manufacturer.
• Explosive or flammable substances: Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance. Do not store or use petrol or any other flammable vapours
and liquids in the vicinity of this or any other appliance. Do not use such substances for cleaning the
appliance. The fumes can create a fire hazard or an explosion.
• Damage: Do not use the appliance if the power cord, plug or the appliance itself is damaged. If
the cord is damaged, contact the after sales support line and have the cord replaced by qualified
personnel in order to avoid a hazard.
• WARNING: Do not damage the refrigerant circuit.
• Do not modify: Do not attempt to alter or modify this appliance in any way.
• Repair: Do not attempt to repair or replace any part of this appliance unless it is specifically
recommended in this manual. All other servicing should be referred to a qualified technician.
Contact the after sales support line for advice.
• WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear of
the appliance
Electrical Safety
• Voltage: Before connecting and turning on the appliance, ensure the electrical voltage and circuit
frequency correspond to that indicated on the appliance rating label.
• Earthing: This appliance should be properly earthed for your safety. The power cord of this appliance
is equipped with a three-prong plug for use in standard wall outlets to minimise the possibility of
electrical shock. Do not modify the cord and/or plug provided with the appliance. Improper use of
the earthed plug can result in the risk of electric shock.
• Connection: This appliance requires a standard 220-240 V AC 50Hz electrical outlet. Do not overload
the electrical circuit.
• Power cord: Do not kink or damage the power cord; do not leave it exposed or dangling. Secure it at
the back of the appliance so no one steps on or places anything on the cord or against it. Keep the
cord out of reach of children. When moving the appliance, make sure not to damage the power cord.
• WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
• Auxiliary Items: Do not use an inverter, adaptor or extension cord with this appliance. If the cord is
too short, have a qualified electrician install an outlet near the appliance. Use of an extension cord
and an inverter can negatively aect the performance of the unit.
• Protect from moisture: To protect against the risk of electric shock, do not immerse the unit, cord or
plug in water or spray it with any other liquid. Do not connect or disconnect the electric plug when
your hands are wet. Turn the power switch o before removing the plug from the socket.
• WARNING: Disconnect! To reduce the risk of fire, electric shock or personal injury, always unplug
the appliance from the socket when not in use, when moving and before cleaning or servicing. Never
unplug the unit by pulling the power cord. Always grip the plug firmly and pull straight out from the
power point.
• Electrical work: Any electrical work required for the installation of this appliance should be carried
out by a qualified electrician.
Installation
Heavy: This appliance is heavy, take care when moving it. To avoid back or other injury, consider a two
person lift or mechanical aid when installing it. Failure to do so can result in back or other injury.
Damage: When unpacking, check the appliance carefully for damage. If it is damaged, do not install
the appliance. Contact our after sales support centre on 1300 43 57 for advice on examination or return
of the damaged appliance.
Protect from moisture: Install the appliance in an indoor area protected from wind, rain, water spray
or drips.
Protect from heat: Do not install the appliance next to an oven, grill or other source of high heat, or
where it will be exposed to direct sunlight for prolonged periods of time.
WARNING: Ventilation: To ensure proper ventilation, keep any ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstructions. Ensure adequate air circulation around the
appliance to prevent overheating.
Level: Install the appliance level in order to ensure proper operation.
Cleaning and Maintenance
Disconnect: Unplug the appliance before cleaning or servicing. Failure to do so can result in electric
shock, injury or death. Do not connect or disconnect the plug when your hands are wet.
Flames: Do not let open flames or ignition sources enter the appliance.
Flammable/explosive substances: Never clean this appliance with flammable fluids. Do not store or
use volatile, flammable or explosive propellants or liquids in or close to this or any other appliance. The
fumes can create a fire hazard or explosion.
Solvents: Do not use solvent based cleaning agents or abrasives on the interior as these may damage
or discolour the surfaces of the appliances.
WARNING! Do not use mechanical devices or other means to accelerate the defrosting process.
Never use a sharp or metal instrument to remove frost or clean the appliance. Use a plastic scraper, if
necessary.
Service: Do not attempt to repair, modify or replace any part of the appliance unless specifically
recommended in this manual. Refer all other servicing to a qualified technician, or contact the after
sales support line for advice on examination or repair of the appliance.
Responsible disposal
Note: At the end of its working life, do not throw this appliance out with your household rubbish.
Electrical and electronic products contain substances that can have a detrimental eect on the
environment and human health if disposed of inappropriately. Observe any local regulations regarding
the disposal of electrical consumer goods and dispose of it appropriately for recycling and recovery of
the refrigerant and blowing agent. Contact your municipal authorities for advice on recycling facilities
in your area.
WARNING! This refrigeration appliance contains flammable refrigerants and insulation blowing
gases, which must be removed before disposal. Contact your municipal authorities for any codes or
regulations concerning the disposal of such materials.
Never use this appliance with a damaged refrigerant circuit! If the coolant circuit becomes damaged,
avoid proximity to open fires and all types of heat sources. The room in which the appliance is located
should be ventilated for a few minutes.
76
Page 5
PRODUCT OVERVIEW GETTING STARTED
Bar Fridge Layout
1
2
3
4
5
KEY
1. Freezer door
2. Thermostat
3. Removable shelf
4. Vegetable basket
5. Adjustable foot
6. Door storage
Unpacking
• Packaging materials: This appliance has been packaged to protect it against transportation
damage. Remove all packaging materials from around and inside the appliance and keep the
original packaging carton and materials in a safe place. It will help prevent any damage if the
product needs to be transported in the future, and you can use it to store the appliance when it is
not in use. In the event the carton is to be disposed of, please recycle all packaging materials where
possible.
• Suocation: Plastic wrapping can be a suocation hazard for babies and young children, so ensure
all packaging materials are out of their reach and disposed of safely.
6
• Power cord: Unwind the power cord to its full length and inspect it for damage. Do not use the
appliance if it or its cord have been damaged or are not working properly. In case of damage,
contact our after sales support line for advice on examination, repair or return of the damaged
product.
• Read the manual: Read this manual to familiarise yourself with the appliance. Pay particular
attention to the safety instructions on the previous pages.
• Clean: To remove any dust from transit and storage, clean the interior and exterior surfaces of the
appliance with lukewarm water and a soft cloth. Dry thoroughly. Important: do not use harsh or
abrasive detergents or powders as these will damage the finish.
INSTALLATION
• Two person installation: Use two or more people to move and install the appliance. Failure to do so
can result in back or other injury.
• Freestanding design: This appliance is designed to be freestanding only, and should not be recessed
or built-in.
• Floor surface: This appliance must be properly positioned on a dry, sturdy, level surface that is strong
enough to support it when it is fully loaded.
• Ambient temperature: The ambient temperatures must correspond to the climate class ( T )
indicated on the rating plate of the appliance: 16° C – 38° C
• Clearances: Ensure that air can circulate freely around the back of the cabinet, which is necessary to
cool the compressor and condenser. Allow at least 10cm clear space at the back, 10cm at the sides of
the unit and 20cm between the top and any surface above (i.e. a bench top). If you are installing your
refrigerator next to a fixed wall, leave sucient space on the hinge side to allow for the door to swing
open.
Do NOT install/use the appliance in the following locations/situations:
• In moist areas or areas of high humidity.
• In a recreational vehicle, or for use with an inverter.
• In direct sunlight, near heat sources, next to an open flame, cooking or heating appliance, or near
any other source of high heat.
• Direct sunlight may aect the acrylic coating and heat sources may increase the unit’s power
consumption. For best energy eciency install the appliance in the coolest area of the room.
• In an area with extreme cold ambient temperatures.
• In an area with excessive moisture and high humidity. Make sure it is protected from elements such
as wind, rain, water spray or drips.
• In an area where petrol or other explosive and/or flammable liquids or fumes are used or stored. The
fumes can create a fire hazard or explosion.
98
Page 6
Installation Cont.
Electrical connection
• WARNING! It must be possible to disconnect the appliance from the mains power supply; the plug
must therefore be easily accessible after installation.
• Before plugging in your new bar fridge, let it stand upright for at least 2 hours. This will allow the
refrigerant gases to settle into the compressor and reduce the possibility of a malfunction in the
cooling system.
• The appliance must be earthed. The plug of the power supply cord is equipped with a contact for
this purpose. Do not under any circumstances cut or remove the third (earth) prong from the power
cord.
If the plug does not fit your outlet, consult a licensed electrician for advice to have the outlet
changed.
• Plug the unit into a dedicated, properly earthed wall outlet. Ensure that your outlet voltage and
circuit frequency correspond to the voltage stated on the rating label.
• Secure the bar fridge’s supply cord behind the unit. Do not leave it exposed or dangling to prevent
injury and accidental disconnection from the power supply.
• Adjust the temperature control as described below.
• When first starting up, and after a period out of use, allow the unit to cool down for at least 2–3
hours (4 hours if starting up during warm weather in summer) before placing food in the bar fridge.
Reversing the door
This is a two person proceedure.
1. Remove the plastic cover from the top door hinge.
2. Unscrew the three screws from the bottom bracket and remove the hinge bracket from the opposite
side and place aside.
3. Slide the fridge door down approximately 15cm and remove from the top hinge, lifting the door away
from the fridge.
4. Remove the two screws from the top bracket and replace the bracket using the same screws on to
the opposite side. Note: You will need to remove the plastic cover caps from the opposite side first.
5. Slide the fridge door back into the top hinge, ensuring that it is the correct way up. Then screw the
bottom hinge bracket into place, securing the door in place.
6. Fit the plastic cover caps and ensure that the door is aligned both vertically and horizontally, before
tightening the bottom hinge. Re-adjust the levelling feet.
Noise From Your Bar Fridge
• You may notice that your bar fridge makes some unusual noises from time to time. Most of these are
perfectly normal, but you should be aware of them!
• These noises are caused by the circulation of the refrigerant liquid in the cooling system. This is not a
fault and will not aect the performance of your unit and is common with all modern fridges.
USING YOUR BAR FRIDGE
The temperature selector knob is located on the right hand side wall of the refrigerator interior. The
thermostat knob controls the temperature.
The Theromstat Controls
• Your fridge has one control for regulating the temperature. The temperature control is located on the
upper right hand side.
• The fridge has four settings:
0 OFF: the unit is o
1 MIN: this is the minimum temperature setting
2 MED: this is the middle temperature setting
3 HIGH: this is the highest temperature setting
• Depending on your room’s ambient temperature, you may need to adjust the temperature setting
to achieve your desired temperature.
• The OFF setting on the thermostat control will turn the refrigerator o.
Note: If the unit is unplugged, lost power, or turned o, you must wait 3 to 5 minutes before
Restarting the unit.
• If you choose to change the thermostat setting, adjust thermostat control by one numerical
at a time. Allow several hours for the temperature to stabalize between adjustments.
Using for the First Time
When you install your appliance, set the thermostat knob to “Med”. Give your refrigerator time
to cool down completely before adding food. It is the best to wait 24 hours before adding food.
IMPORTANT: Once the unit has started, continuous operation is recommended. Please try and avoid
turning the unit o and on as this may aect the service life.
Defrosting Your Bar Fridge
• For the most ecient operation and minimum energy consumption, defrost the freezer when the
frost on the freezer walls is excessive or 3 to 4 mm thick. To minimize disruption, choose a time when
the stock of frozen food is low.
IMPORTANT: Do not use boiling water because it may damage the plastic parts. In addition, never use
a sharp or metallic instrument to remove frost as it may damage the cooling coils and will void the
warranty. We recommend using the plastic scraper provided with your unit.
• Remove the frozen food from the freezer and place it in a cooler to protect the food.
• Set the thermostat to the OFF position or unplug the bar fridge.
• During defrosting, the ice melts into the cabinet.
• Clean the interior of the fridge and freezer and remove any water.
• Reset the thermostat to desired setting.
• Allow the cabinet to cool for one hour.
• Return food to the freezer.
Helpful Tip. Defrosting usually takes a few hours. Leaving the door open will help speed the process.
Also, pouring warm water (not boiling) on the ice/frost will help speed melting. If you must use a
scraper please use caution it is very easy to damage the freezer compartment and void your warranty.
1110
Page 7
TIPS FOR USING THE APPLIANCE
MAINTENANCE & CLEANING
• Do not store food uncovered in the bar fridge. Always use good quality, fridge-proof packaging to
maintain food quality. Remove air from packages of solid food and seal bags tightly before freezing.
• Keep portions small to ensure they are frozen (and subsequently defrosted) rapidly.
• Make sure that fresh, unfrozen food packages do not touch food that is already frozen, thus avoiding
a temperature rise in the frozen food.
• When freezing food, do not push food together too much, leave some space for air to circulate
around each item. Do not place packages directly against the back wall.
• When buying frozen food, only buy quantities that you can store straight away; use an insulated
container for your shopping and when you get home, place the food in the chilling compartment
immediately.
• When storing pre-packed, commercially frozen food, follow the food manufacturer’s instructions
for storing the food in a home fridge or freezer. Do not exceed any storage times listed on the
packaging.
• Once you have opened a packet of frozen food, re-wrap it airtight to prevent surface evaporation
which causes drying or freezer burn.
• Do not place carbonated liquids such as bottles of fizzy drink in the chilling compartment as the
container could explode under pressure and damage the chiller.
• Do not refreeze food once it has been defrosted.
• Frozen food which has thawed accidentally should either be used immediately or thrown away.
Alternatively, if the food is uncooked and has not been completely defrosted, it may be cooked and
then refrozen.
• CAUTION! Do not remove items from the chilling compartment if your hands are damp or wet as
this could cause skin abrasions.
TIPS FOR ENERGY SAVING
• The appliance should be placed in the coolest area of the room, away from heat producing
appliances or heating ducts. Please avoid placement in direct sunlight.
• Let hot foods cool to room temperature before placing them in the appliance.
• Do not overload the appliance with unfrozen food as this may cause it to freeze slowly and risk food
spoilage.
• Be sure to wrap foods properly and wipe containers dry before placing them in the appliance. This
cuts down on frost building up inside in the unit.
• Please do not wrap items in aluminium foil, wax paper or paper towel. This materials interfere with
cold air circulation, making the appliance less ecient.
• Organise and label food to reduce door openings and extended searches. Remove as many items as
needed at one time, ensuring the unit is opened as few times as possible.
Defrosting
The bar fridge requires manual defrost. For ecient operation and minimum energy consumption,
defrost the chilling compartment when the frost on the chiller walls is building up. Do not let frost build
up to more than 3–4mm thickness. For eciency, choose a time when your stock of frozen food is low.
• Unplug the power cord
• Please remove the foods from the refrigerator and place them properly to prevent foods from melting
or going bad, then prepare a water container for holding defrosting water.
• Pour the water in drain tray into the water container, and it is recommended to use a dry towel to dry
the defrosting water on liner and evaporator, then wring dry the towel. Repeat the operation until
defrosting completed.
• You can use the natural temperature of the natural defrosting, you can also use the ice shovel to
eliminate the frost (to use plastic or wooden ice shovel to prevent damage to the liner)
• You can also use the appropriate amount of hot water to speed up defrosting, with the dry towel to
dry the water after defrosting.
• Put all foods back and power on the appliance again.
Cleaning
WARNING
Before cleaning the appliance, make sure it is switched o and disconnected from the power supply.
Failure to do so can result in electric shock or injury.
• Wash the inside surfaces and the interior accessories with a damp, warm cloth moistened in a water
and baking soda solution. The solution should be about 2 tablespoons of baking soda to 1 litre of
water. Rinse and wipe dry with a soft cloth.
• Clean the outside of the unit with a damp, well wrung out cloth, keeping the area of the controls dry.
Keep the lid gasket (seal) clean.
• Never use boiling water to accelerate defrosting as it may damage the plastic components.
• Regularly check the appliance for defrost water. If necessary, clean the drain. If the drain is blocked,
water will collect in the base of the appliance.
• After cleaning/defrosting, push the drain plug in.
• After everything is dry, place appliance back into service.
• Allow approximately 1–2 hours for the cabinet to cool down again (depending on the length of time
the appliance was disconnected from the power).
WARNING
Never clean the unit with an abrasive, acid, oil or solvent based cleaning agent. Never use flammable
fluids or sprays for cleaning as the fumes from these substances can create a fire hazard or Explosion.
1312
Page 8
Maintentance and Cleaning Cont.
Interior
This bar fridge has an interior LED light bulb built into the lid. It alights and extinguishes automatically
when the lid is opened and closed. If the light bulb needs replacing, contact our after sales support to
book a service call. The light bulb can only be replaced by properly qualified service personnel.
Service, repair and spare parts
Do not attempt to alter or modify this appliance in any way, or to repair or replace any part unless
it is specifically recommended in this manual. All other servicing should be referred to a qualified
technician. Contact our after sales support for advice.
Our after sales support centre stocks a selection of spare parts for the InAlto 112L Bar Fridge.
To enquire about purchasing a part, our after sales support.
Power Failure
Most power failures are corrected within a few hours and should not aect the temperature of your
appliance if you minimise the number of times the door is opened. If the power is going to be o for a
longer period of time, take proper steps to protect the contents.
Levelling the Unit
If the refrigerator is not level the door may not close or seal properly. This could cause cooling, frost, or
moisture problems. It is very important of the refrigerator to be level in order to function properly.
• To level your refrigerator you may either turn the level leg clockwise to raise that side; or turn the
level leg anti-clockwise to lower that side.
Note: Having someone push against the top of the refrigerator takes some weight o the leveling leg
and makes it easier to adjust the leveling leg.
FAQS & TROUBLESHOOTING
Problem Possible Cause Possible Solution
The appliance
does not
operate.
The appliance
is not cold
enough.
The appliance
has an odd
odour.
The internal
light does not
illuminate.
The door
will not close
properly.
The door
is dicult
to open.
• The appliance is not plugged in.
• The appliance is turned o.
• The circuit breaker tripped or a
blown fuse.
• Check the temperature control
setting.
• The door is opened too often, or
is kept open for too long; the door
is not closed completely; hot food
has been placed inside.
• The appliance has recently been
disconnected for a period of time.
• Food may not be wrapped properly.
• Food may be rotten.
• The interior may not be clean.
• The appliance is not plugged in.
• The appliance is turned o.
• The circuit breaker tripped or a
blown fuse.
• The light is damaged.
• The appliance is not level.
• The gasket is dirty.
• Food is stacked too high.
• A dierence in pressure between
the air inside and outside of the
unit.
• Plug in the appliance.
• Turn on power point.
• Reset circuit breaker/replace fuse.
• Reduce the temperature.
• Do not open door for 2+ hours; Check
that the door is closed properly and for
any obstructions preventing the door
closing properly; Remove hot food and
let it cool first before replacing it.
• Plug in the appliance.
• Check that the food is wrapped
tightly.
• Check for rotten food and remove.
• Clean the interior of the appliance.
• Plug in the appliance.
• Turn on power point.
• Reset circuit breaker/replace fuse.
• Please contact after sales support.
• Level the appliance.
• Clean gasket with warm water and
a soft cloth.
• Re-position food so it does not
obstruct.
• This is a normal phenomenon and
cannot be avoided.
Moisture
forms on the
inside
appliance
walls.
Moisture
forms on the
outside of the
appliance.
There are
vibrations.
• Hot and humid weather increases
the internal rate of frost build-up.
• The lid is slightly open.
• The lid is kept open too long, or is
opened too frequently.
• The door is slightly open, causing
cold air from inside the appliance
to meet warm, moist air from the
outside.
• The appliance is not level.
• The floor is uneven or weak.
• The appliance is touching the wall.
1514
• This is normal.
• Close the door.
• Open the door less often
• Close the door or check for
obstructions.
• Level the appliance.
• Be sure your floor can adequately
support the appliance.
• Move the appliance away from the
wall and check it is level.
Page 9
WARRANTY
AUSTRALIAN WARRANTY TERMS & CONDITIONS
REFRIGERATION APPLIANCES
This document sets out the terms and conditions of the
product warranties for Residentia Group Appliances. It is
an important document. Please keep it with your proof of
purchase documents in a safe place for future reference
should you require service for your Appliance.
1. IN THIS WARRANTY
(a) ‘acceptable quality’ as referred to in clause 10 of this
warranty has the same meaning referred to in the ACL;
(b) ‘ACL’ means Trade Practices Amendment (Australian
Consumer Law) Act (No.2) 2010;
(c) ‘Appliance’ means any Residentia Group product
purchased by you accompanied by this document;
(d) ‘ASR’ means Residentia Group authorised service
representative;
(e) ‘Residentia Group’ means Residentia Group Pty Ltd
of 165 Barkly Ave, Burnley VIC 3121, ACN 600 546 656
in respect of Appliances purchased in Australia;
(f ) ‘major failure’ as referred to in clause 10 of this
warranty has the same meaning referred to in the ACL
and includes a situation when an Appliance cannot
be repaired or it is uneconomic for Residentia Group,
at its discretion, to repair an Appliance during the
Warranty Period;
(g) ‘Warranty Period’ means:
(i) where the Appliance is used for personal,
(h) ‘you’ means the purchaser of the Appliance not having
2. This warranty only applies to Appliances purchased
3. During the Warranty Period Residentia Group or its
4. Parts and Appliances not supplied by Residentia Group
domestic or household use (i.e. normal
single family use) as set out in the instruction
manual, the Appliance is warranted against
manufacturing defects for 24 months, following
the date of original purchase of the Appliance;
purchased the Appliance for re-sale, and ‘your’ has a
corresponding meaning.
and used in Australia and is in addition to (and does
not exclude, restrict, or modify in any way) any
non-excludable statutory warranties in Australia.
ASR will, at no extra charge if your Appliance is readily
accessible for service, without special equipment and
subject to these terms and conditions, repair or replace
any parts which it considers to be defective. Residentia
Group or its ASR may use remanufactured parts to
repair your Appliance. You agree that any replaced
Appliances or parts become the property of Residentia
Group. This warranty does not apply to light globes,
batteries, lters or similar perishable parts.
are not covered by this warranty.
5. You will bear the cost of transportation, travel and
delivery of the Appliance to and from Residentia Group
or its ASR. If you reside outside of the service area,
you will bear the cost of:
(a) travel of an authorised representative;
(b) transportation and delivery of the Appliance to and
from Residentia Group or its ASR, in all instances,
unless the Appliance is transported by Residentia
Group or its ASR, the Appliance is transported at
the owner’s cost and risk while in transit to and from
Residentia Group or its ASR.
6. Proof of purchase is required before you can make
a claim under this warranty.
7. You may not make a claim under this warranty unless
the defect claimed is due to faulty or defective parts
or workmanship. Residentia Group is not liable in the
following situations (which are not exhaustive):
(a) the Appliance is damaged by:
(i) accident
(ii) misuse or abuse, including failure to properly
(iii) normal wear and tear
(iv) power surges, electrical storm damage or
(v) incomplete or improper installation
(vi) incorrect, improper or inappropriate operation
(vii) insect or vermin infestation
(viii) failure to comply with any additional instructions
(b) the Appliance is modied without authority from
(c) the Appliance’s serial number or warranty seal has
(d) the Appliance was serviced or repaired by anyone
8. This warranty, the contract to which it relates and the
9. To the extent permitted by law, Residentia Group
maintain or service
incorrect power supply
supplied with the Appliance;
Residentia Group in writing;
been removed or defaced;
other than Residentia Group, an authorised repairer
or ASR.
relationship between you and Residentia Group are
governed by the law applicable where the Appliance
was purchased.
excludes all warranties and liabilities (other than as
contained in this document) including liability for any
loss or damage whether direct or indirect arising from
your purchase, use or non use of the Appliance.
10. For Appliances and services provided by Residentia
Group in Australia, the Appliances come with a
guarantee by Residentia Group that cannot be
excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled
to have the Appliance repaired or replaced if the
Appliance fails to be of acceptable quality and the
failure does not amount to a major failure. The benets
to you given by this warranty are in addition to your
other rights and remedies under a law in relation to the
Appliances or services to which the warranty relates.
11. At all times during the Warranty Period, Residentia
Group shall, at its discretion, determine whether repair,
replacement or refund will apply if an Appliance has a
valid warranty claim applicable to it.
12. To enquire about claiming under this warranty, please
follow these steps:
(a) carefully check the operating instructions, user manual
and the terms of this warranty;
(b) have the model and serial number of the Appliance
available;
(c) have the proof of purchase (e.g. an invoice) available;
(d) telephone the numbers shown below.
13. You accept that if you make a warranty claim,
Residentia Group and its ASR may exchange
information in relation to you to enable Residentia
Group to meet its obligations under this warranty.
IMPORTANT
Before calling for service, please ensure that the steps
in point 12 have been followed.
→ Service: Please call 1300 11 HELP (4357)
THIS WARRANTY IS VALID IN AUSTRALIA ONLY.
The Australian Consumer Law requires the
inclusion of the following statement with
this warranty:
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
1716
Page 10
WARRANTY
SPECIFICATIONS
NEW ZEALAND WARRANTY TERMS & CONDITIONS
REFRIGERATION APPLIANCES
To help care for your investment, be sure to register your
appliance online. Registration will help you if you need to
arrange service in the future, and serves as a record of your
purchase – including critical information like model number
and serial number – that you can refer to at any time.
Simply visit the below website, or ask your retailer for help:
www.inalto.co.nz/register
WARRANTY:
These products are covered by a warranty for a period
of 24 months from the date of purchase, subject to the
following conditions*. The warranty covers rectication free
of charge of any fault arising from defective materials or
components, or faulty workmanship or assembly.
* The conditions above mentioned are:
1. That the purchaser carefully follows all instructions
packed with the product;
2. That the purchaser and/or installer carefully follows
the installation instructions provided and complies
with electrical wiring regulations, gas and/or plumbing
codes;
3. That the purchaser carefully follows instructions
provided in the owner’s handbook relating to the
proper use and care of the product and does not use
the product for any purpose other than the domestic
use for which it has been designed;
4. Commercial use of the product for professional or
industrial purposes will void this warranty.;
5. That the product was purchased and installed in New
Zealand;
6. That this warranty does not extend to:
a) optional glass lids for hobs apart from claims
b) ‘consumable’ parts such as light bulbs or lters;
c) damage to ceramic glass caused by liquid or
d) damage to surface coatings caused by
e) defects caused by normal wear and tear,
f) a product dismantled, repaired or serviced by
g) a product not in possession of the original
h) damage caused by power outages or surges
i) damage caused by pests (eg. rats, cockroaches
which relate to mechanical or physical damage
thereof at the date of purchase;
solid spill-overs, lack of maintenance, or impact;
cleaning or maintenance using products not
recommended by the owner’s handbook;
accident, negligence, alteration, misuse or
incorrect installations;
any serviceman other than an authorised service
agent;
purchaser;
etc.)
7. That if the product is a freestanding microwave
oven or small appliance it must be returned to the
dealer/ retailer for servicing. These products, unless
stated otherwise, have a 12 month warranty from
original date of purchase with 24 months on the
microwave magnetron; Waste disposers have a
12 month warranty.
8. The provision of service under this warranty is limited
by a 25km boundary from the retailer where the
product was purchased except for microwaves. Such
travelling outside of these limits will incur commercial
cost to be paid by you, regulated by the number of
kilometres travelled beyond the 25km limit (50km
return trip). Microwaves are to be delivered to the
nearest authorised service agent by the customer.
Please refer to your user manual for any further conditions
that may apply to your specic model.
Nothing herein contained shall be construed in any way
as excluding or limiting your rights under the Consumer
Guarantees Acts 1993.
For Service please visit www.applico.co.nz/service or
contact the dealer/retailer from whom you purchased the
product from or call the 0800 number listed below. If you
are unable to establish the date of purchase, or the fault is
not covered by this warranty, or if the product is found to
be in working order, you will be required to bear all service
call charges.
Registration of this warranty constitutes acceptance of the
terms and conditions of this warranty.
Should you require any assistance, please call Customer
Services on 0800 763 448.
Distributed by Applico Ltd.
www.applico.co.nz
May 2019
After registering your appliance online, we recommend you
ll out the below information for your reference and keep
this warranty card in a safe place.
THIS WARRANTY IS VALID IN NEW ZEALAND ONLY.
Product Dimensions: 470w × 500d × 860h mm
Weight: 24.5kg
Gross Capacity: 112L
Other Features: 14 Litre freezer, Adjustable temperature control, Interior light,
Recessed handle, Reversible door, Glass vegetable crisper,
Adjustable tempered glass shelving, 3 internal door storage racks
Energy Rating: 2 Stars MEPS
Standards
This product complies with AS/NZS 60335.1 and AS/NZS 60335.2.24 electrical safety, and with
EN 55014-1:2006+A1:2009 A2:2011 for electromagnetic compatibility.
PURCHASE DETAILS
PRODUCT:
RETAILER:
DATE OF PURCHASE:
INVOICE NO:
MODEL NO:
SERIAL NO*:
* Your serial number can be found on the rating plate which is on the rear of your unit.
1918
Page 11
20
Loading...
