Thank you for purchasing the Impact Standard or Deluxe Umbrella-Mount Bracket. These versatile brackets allow you to mount an umbrella and/or a portable ash* on almost any light stand, tripod, or boom. The bracket can tilt 180,° allowing you to aim your light in any direction. Tricky or tight positions are not a problem as you can mount your ash anywhere from vertical to horizontal orientations. Both models include two removable, reversible brass stud adapters which will allow you to mount the bracket not only to stands with the standard 5/8˝ stud, but also to stands or tripods with a 3/8˝ or 1/4˝ screw tting.
The Standard model features a oating lever for easy adjustments. It locks securely with a non-slip geared tooth mechanism. The Deluxe model is a sturdy metal bracket and features an adjustable shoe that accepts almost every standard shoe-mount ash.
We trust that our umbrella-mount brackets will serve your creative inspirations reliably for years to come. Please read these instructions carefully on how to set up and use your Impact Umbrella-Mount Bracket.
Caution
These brackets are not intended for use with umbrellas larger than 45.˝ For safety, and to protect your equipment, use weighted sand bags to stabilize your light stand.
*Impact Standard Umbrella Mount is not compatible with
®
Nikon
SD-900 ashes.
All ima ges in this manua l are for illustrat ive purposes onl y. Your umb rella-mount b racket may differ s lightly
from the on e pictured. Light s tands, oodl ights, umbre llas, and port able ash unit s are not included
with th is bracket unless i t was purchased as pa rt of a kit.
Page 3
Standard Umbrella-Mount Bracket
Cold-shoe mount
Rever sible stud adapter wit h 1/4-20 and 3/8˝ male threads
Locking knob
Umbrella locking knob
Umbrella socket
Locking knob
Vertical tap (port for mounting)
Horizontal tap (port for mounting)
Locking swivel lever
Horizontal tap (port for mounting)
Rever sible stud adapter wit h 1/4-20 and 3/8˝ female threads
Page 4
Deluxe Umbrella-Mount Bracket
Adjustable cold-shoe mount
Rever sible stud adapter wit h 1/4-20 and 3/8˝ male threads
Locking knob
Locking knob
Horizontal tap (port for mounting)
Vertical tap (port for mounting)
Horizontal tap (port for mounting)
Umbrella socket
Umbrella locking knob
Locking knob
Rever sible stud adapter wit h 1/4-20 and 3/8˝ female threads
Page 5
Setting Up Your Umbrella-Mount Bracket
1
The S tandard and Deluxe Umbrella-Mount brackets are very similar, but we’ll show how to set up both models in this guide. Begin by loosening t he locking knob. Remove the brass mounting st ud adapter. Even i f you don’t need t his stud adapter for your current setup, don’t lose it. You may need it in t he future.
2
If your light s tand has a standard 5/8˝ stud on top, mount your bracket on the stud and tighten the locking knob.
Page 6
3
Some light stands have a threaded screw on top. If the s tud is 5 /8˝ in diameter below the threads, you may wish t o mount your bracket directly to this stud. If the screw is 3 /8˝ or 1/4,˝ use the removable brass mounting stud adapter. Screw the brass adapter onto the threads of your light s tand and mount the umbrella bracket as shown in s tep 2.
4
Your Impac t Umbrella-Mount bracket can also be mounted in a horizontal position. The horizontal taps (mounting holes) are also useful for mounting the bracket onto boom arms.
Page 7
5
The cold-shoe mount on the S tandard Umbrella-Moun t Bracket will t any model of ash wit h a standard shoe (except Nikon features an adjustable cold shoe that will t any portable ash. Loosen the tension screw to expand the cold shoe. Mount your ash and retighten the tension screw.
®
SB-90 0 ashes). The Deluxe Umbrella-Moun t Bracket
6
Your Umbrella-Mount Bracket can also be used to mount a small light ing xture. Because of it s abili ty to tilt and swi vel, the bracke t will give you more opt ions for aiming your light than by using the light stand alone. Plus, you can mount an umbrella with lights that don’t feature an umbrella mount.
Page 8
oror
7
To mount a small ligh t xture, unscrew and remove the cold shoe. Mount t he light using the exposed 1/4˝ screw. Or turn this tting around for the 3/8˝ screw. If you need a 5 /8˝ stud tting, connect the two brass t ting adapter s. This gives you a st andard 5/8˝ stud t ting t hat most lights use.
8
The umbrella socket slopes upwards slightly to gi ve your ash bet ter beam spread into your umbrella. Inser t the umbrella shaf t into the high end of the umbrella socket and tigh ten the thumbscrew. Don’t over-tighten, to avoid pinching the umbrella shaft . Umbrellas larger than 4 5˝ are not recommended for use wit h these brackets.
Page 9
9
Make your adjustments to point the ash in to your umbrella. Release the locking knob underneath the cold shoe to rotate the ash. Retighten the knob.
10
Release the locking lever (standard model) or t he large locking knob (deluxe model) to tilt the ash. Retighten. If your ash can til t, adjust that also, if necessary.
Page 10
11
It’s a good practice to stabilize your setup with a sand bag or weigh t bag. This will prot ect you and your equipmen t from injury and damage.
12
You are ready to start shoot ing.
Page 11
Accessories
Impact Super Clamp
This is a great complement to the Impact Umbrella-Mount Bracket . Used together, the combinat ion allows you to mount a portable ash to tubes 1/ 2˝ to 2-1/8 ˝ in diameter or practically any rigid sur face. The Super Clamp is a versatile tool for which you’ll discover dozens of uses.
Impact Sand Bags & Shot Bags (Full)
Impact Sand Bags and Shot Bags come in a varie ty of shapes and weights, and are either black or orange. They are used for anchoring the bases of light stands and set walls. The saddle-style bags have t wo wings so they can be draped over light stand legs. Each side of the bag has a hand strap for easy handling and hanging on hooks. The outer shell is water resistant, heavy- dut y cordura nylon.
Impact Sand Bags (Empty)
Impact Sand Bags also come in an empt y version with a double-zippered closure. They can be lled with sand, small rocks, or any thing heavy, and emptied at t he end of the shoot. They come in a variety of sizes and capaci ties.
To see these accessories and all of our lighting equipment ,
please visit our Web site.
www.impactstudiolighting.com
