ILLUSTRATED PARTS LIST
UCC-40 POST-MIX DISPENSER
UCC-40
1 of 4
Manual Part No. 569030055
10-15-2001
IMI Cornelius Co., 2001
ILLUSTRATED PARTS LIST
UCC-40 POST-MIX DISPENSER
IMI CORNELIUS INC.
One Cornelius Place
Anoka, MN. 55303 --6234
Telephone 1-800-238-3600
Facsimile 1-800-258-0255
www.cornelius.com
Manual Part No. 569030055
10-15-2001
IMI Cornelius Co., 2001
FIGURE 1. GENERAL ASSEMBLY
2 of 4
UCC-40
ILLUSTRATED PARTS LIST
UCC-40 POST-MIX DISPENSER
IMI CORNELIUS INC.
One Cornelius Place
Anoka, MN. 55303 --6234
Telephone 1-800-238-3600
Facsimile 1-800-258-0255
www.cornelius.com
Item
No.
10 230302 Handle Rfg Platform
11 230040 Brkt Mtr Agit
12 400411 Gasket
13 350078 Motor Agit 120V 60HZ
14 230943 Brkt Mtr Fan
15 550031 Bushing Snap
16 260969 Kit Comp 1/3HP 120V 60HZ
17 230877 Hood Asy Gray
18 260061 Holder Bulb Temperature Control
19 350012 Blade Agit
20 186610000 Pin Sprg
21 400262 Cap Plug
22 230130 Brkt Line
Part No. Name
1 260064 Cabinet Asy
2 260146 Evap Coil Asy
3 18607001 Control Ice Bank
4 230218 Platform Rfg
5 350128 Cord Pwr 120V 60HZ
350124 Cord Pwr 230V 50HZ
6 550087 Cond Coil
7 230510 Shroud Fan
8 350015 Blade Fan
9 350094 Motor Fan 120V 60HZ
350097 Motor Fan 230V 50/60HZ
350079 Motor Agit 230V 50/60HZ
260967 Kit Comp 1/3HP 230V 50HZ
260972 Comp 1/3HP 240V 60HZ
350148 Relay 1/3HP 120V 60HZ
350151 Relay 1/3HP 230V 50HZ
350152 Relay 1/3HP 240V 60HZ
350108 Overld 1/3HP 120V 60HZ
350106 Overld 1/3HP 230V 50HZ
350107 Overld 1/3HP 240V 60HZ
230064 Brkt Bulb Holder
Item
No.
23 320389000 Bushing Snap
24 230208 Brkt Product Coil
25 89053 Tube
26 300200000 Clamp
27 650047 Insulation Tubg
28 77081400 Fitg Adptr 3/8MPT x 3/8-Barb
29 400243 Fitg Pack 3/8-Tube x 3/8MPT
30 550275 Pump 50GPH
31 318129000 Insulation Pump
32 Item Not Used
33 400249 Nut, Pack, 3/8
34 Item Not Used
35 187483000 Clamp
36 398034400 Pin Hitch
37 350072 Motor Pump 1/3HP 120V 60HZ
38 31525012 O-Ring .301 I.D.
39 260136 Coil Asy Carb Water
40 230231 Cover Box Elec
41 230819 Wrapper, Electrical Box,
42 60439010 Control Liquid Level 120V 60HZ
43 400288 Screw MA 6-32 x 1/4 TAPR
44 230230 Cover Box Elec 120V 60HZ
45 550035 Bushing
46 350137 Receptacle Single 115V 60HZ
47 400238 Fitg Pack 1/4-Tube x 5/16-Barb
Part No. Name
(No Longer Available)
350075 Motor Pump 1/3HP 230V 50/60HZ
(No Longer Available)
115V 60Hz (No Longer Available)
230783 Box Elec
7 Min Timer
60439012 Control Liquid Level 230V 50HZ
7 Min Timer
60439011 Control Liquid Level 120V 60HZ
3 Min Timer
60439013 Control Liquid Level 230V 50HZ
3 Min Timer
(No Longer Available)
UCC-40
3 of 4
Manual Part No. 569030055
10-15-2001
IMI Cornelius Co., 2001
ILLUSTRATED PARTS LIST
UCC-40 POST-MIX DISPENSER
IMI CORNELIUS INC.
One Cornelius Place
Anoka, MN. 55303 --6234
Telephone 1-800-238-3600
Facsimile 1-800-258-0255
www.cornelius.com
Item
No.
48 260888 Tube Assy Recirc Carb Water
49 350182 Switch Rocker
50 230185 Box Elec 120V 60HZ
51 400424 Washer Terminal Cup
52 400282 Screw No. 10-32 x 5/8
53 20223010 Washer Ft .489 I.D.
54 189723000 Grommet Cmpr
55 350158 Sleeve Compressor
56 230303 Heat Sink
57 400284 Screw No. 6 x 5/8” PH B
58 400294 Screw DR No. 8-18 x 3/8” RDRP
59 400241 Fitg Compsn 1/4 x 3/8-Barb
60 77080101 Fitg Barb 1/4 x 7/16-20
61 31525002 O-Ring .176 I.D.
62 400244 Nut Pack 7/16-20
63 260345 Coil Wtr Asy Pre-Chill
64 20543 Clamp Pump
65 400046 Fitg Nipl 3/8MPT x 3/8F
66 311304000 Gasket 3/8 Male Flare
67 77030100 Nut Swiv 5/8-18
68 400153 Nipl Swiv 1/4-Barb
69 260431 Fitg Filter Asy
70 550276 Pump 125GPH
71 711200003 Kit Service Probe
72 77040100 Fitg L Swiv 1/4-Barb x 7/16-20
73 111353000 Clamp
74 174478000 Tube, Flexcor .265 I.D. (Sold by
Part No. Name
(No Longer Available)
the Foot)
Item
No.
75 178025100 Gasket 1/4 Male Flare
76 65259 Kit Valve Chk Sngl
77 77040200 Fitg Splicer .265 I.D. Tube
78 400412 Washer (No Longer Available)
79 77040900 Fitg L Swiv 5/8-18 x 3/8-Barb
80 311304000 Gasket 3/8 Male Flare
81 230070 Brkt Mntg Carb Tank
82 400422 Washer (No Longer Available)
83 400188 Nut 1/4 (No Longer Available)
84 550073 Carb, Tank Ass’ y
85 31525007 O-Ring .488 I.D.
86 66008 Kit Relief Valve 180PSI
87 550040 Insert Carb Inlet Wtr
88 260037 Valve Chk Dual Back Water
89 550198 Fitg Filter Body 3/8NPT
90 550197 Screen Filter
91 31525017 O-Ring .426 I.D.
92 400130 Fitg Inlet, 3/8MF x 11/16-64
93 31525012 O-Ring .301 I.D.
94 64678 Spring
95 64560 Ball .312 Dia.
96 64686 Sleeve
97 398033002 O-Ring .239 I.D.
98 77401400 Fitg Chk Val 1/4MF x 9/16-27FM
99 77400200 Body Chk Valve Dual
Part No. Name
(No Longer Available)
(No Longer Available)
(No Longer Available)
Compressor Kits include Compressor,
Relay, Overload, Grommets and Sleeves
Manual Part No. 569030055
10-15-2001
IMI Cornelius Co., 2001
4 of 4
UCC-40
