IMESA: A LIFE BY YOUR SIDE

Imesa is a leading company in the production of laundry equipment. We achieved this goal thanks to more than 40 years of total

commitment to the continuing challenges to satisfy the growing technological expectation of human beings and meetings changes
in lifestyle.

Innovation, quality, safety, versatility, service and reliability: IMESA success is based on this six concepts. Innovation in

technology and proposal. Quality guranteed by an UNI EN ISO 9001 certied production system. Safety of products certied by
qualied operational organisation in various part of the world. Versatility and exibility which allows many possibilities of

customisation. Reliability thanks to the solid product structure.

Customer satisfaction is IMESA main achievement. Thanks to an international and professional net of distributor and to a well
trained service net, IMESA can assure a global service in Italy, in Europe and in all the world.

During the offer step, IMESA distributor offers a complete support in the correct equipment choice and complete the job with a

nancial analysis of the investment as well as with the project.

IMESA can deliver in a very short time thanks to equipment stock in many countries: Italy, Spain, French, Portugal, Algeria,
Hungary, …
The wide service net can assure a quick technical assistance in case of necessity and the spare parts can be easily purchased

in IMESA ofcial website.

IMESA S.p.A Via degli Olmi, 22 - 31040 Cessalto (TV) ITALIA + 39 0421 468011 [phone] [email protected] - www.imesa.it

DISTRIBUTED BY

Q130101A_ENG The manufacturer declines all responsibility for any inexactitudes contained in this catalogue. The manufacturer reserves the right to bring without warning any modications he might believe necessary, without changing the essential characteristic of the product.

G

U

A

R

A

N

T

E

E

★

G

U

A

R

A

N

T

E

E

★

G

U

A

R

A

N

T

E

E

★

100%

SATISFACTION

G

U

A

R

A

N

T

E

E

★

G

U

A

R

A

N

T

E

E

★

G

U

A

R

A

N

T

E

E

★

100%

SATISFACTION

ERGONOMICS, SAFETY AND SAVINGS

IMESA ES

ES SERIES:

A RAY OF SUNSHINE
IN YOUR LAUNDRY

IMESA tumble dryers are the ideal answer to the laundry needs
of hotels, restaurants, hospital laundries, retirement homes,
industrial laundries, Coin op laundries, …

Designing the ES tumble dryers, the IMESA R & D department
paid a lot of attention to energy saving, ecology, easy
maintenance and, of course, to operator safety. The reduced
dimensions make this tumble dryer easy to be transported and
installed in already existing laundries.

Thanks to the new generation microprocessor all the laundry
costs can be kept continually under control, this means that
laundry management has never be so easy!

EASE OF LOADING AND
UNLOADING:

Door width and its position makes it
easy to load and unload the linen.
The door can be opened at 180°, so
that user operation is not disturbed.
To make the line process easier,
the dryer is available also with left
opening (under request).

SAFETY:

A safety device stops the tumble dryer
if the door is opened while the dryer
is working.

LOW NOISE:

To make the laundry a nice and not
noisy room, the IMESA tumble dryers
have been studied to maintain a noise
level below 70dB (A).

Electric heating:

thanks to the microprocessor, which
allows the power level control, the
electric heated dryer can work at
full power or partial power reducing
power consumption.

Steam heating:

Thanks to the damper system, heat
is immediately available. With this
system problems due to water
hammering are avoided: IMESA dryer
is studied to last!

Gas heating:

IMESA tumble dryers can works with
all types of gas and are equipped

with electronic ignition plug and ame

control.

ES 10 – 14 – 18 – 23 – 34

IMESA ES tumble dryers are all available with:

- Stainlees steel drum;

- Eposidic painted panel;

- Microprocessor controlled: 30 modiable programs;

- Residual humidity control;

- Big lint screen; easy to be cleaned when the
request is displayed;

- Cooling function, to avoid shocks to the linen;

- High efciency suction system;

- Energy control function.

Options:

- Reversing drum option
(standard on models ES 23 and ES 34);

- Drum speed control (DSC);

- Suction fan speed control (FSC);

- Power level control.

ES LINE:

ECOLOGIC,

ECONOMIC,

ERGONOMIC!

ES SS 10 – 14 – 18 – 23

Studied to last: a reliable structure and high quality components! We are proud of
our product reliability in which we trust so much to grant the best warranty condition:

24 MONTHS TOTAL WARRANTY!

GOST CERTIFICATION:

IMESA tumble dryers are meeting
Russian Federation product standards.

All IMESA gas heated dryers are certied

respecting European Community rules.

Ideal for Coin Op laundry, IMESA ES SS tumble dryers are
available with:

- Stainlees steel drum;

- Eposidic painted panel;

- Microprocessor controlled: 30 modiable programs;

- Rervesing drum;

ES SS LINE:

- Residual humidity control;

Full customer satisfaction

ES tumble dryers ensure excellent results. Available in
several heating versions (electric, gas and steam), IMESA drying
is optimal and utility costs are reduced due to the special heated
air directing system.

With the reversing drum option, the best ironing uniformity and
quality is guaranteed also for big size linen: reverse tumbling
prevents the linen from a “ball up” which would cause, at the
end of the cycle, an uneven mix where some linen is dry and
some is still wet.

With the two optional functions DSC and FSC, the laundry
professionals can modify the drum speed and the fan speed
independently to obtain the best drying results!

The “no wrinkle system” at the end of the cycle will make the

nishing operation easier. When the dryer cycle ends, the

drum will continue to rotate in one direction, and in the opposite
one, with regular pauses thus avoiding wrinkles.

M 7 microprocessor:
everything under
control.

Developed to make the dryer use and
maintenance easier as well as cost
control, the IM7 microprocessor is

extremely exible and intuitive.

COMUNICATION NO PROBLEM

IMESA knocks down comunication
barriers; IM7 microprocessor can
speak more languages. The keypad
is using only symbols so it is easily
understood.

SAVE IN MAINTENANCE

An easy maintenance means a reduction
of costs. All the displayed alarms are
saved in the microprocessor memory
and can be easily retrieved in case
of service. Thanks to the HELP Area,
instruction to most common problem
resolution can be read directly on
tumble dryer display. A quicker and
correct diagnosis will help to solve
the machine stops in the shortest
possible time!

Standard on all ES tumble dryers the microprocessor allows you to
control easily:

Drying time;

-

Drying temperature;

-

Drum speed (option DSC);

-

Suction fan speed (option FSC);

-

Heating power level (only on electric heated model);

-

No wrinkle cycle.

-

REDUCING MANAGEMENT COSTS

Thanks to the Power Control function
the electric heating tumble dryer can
work on different power level: basing
on the available power the user will
choose the appropriate level. The
consumed energy can be controlled
at display (this function is available in
all heating version).
Electric loading can be controlled
directly from keypad.

DRYING PROGRAM

Each fabric needs parameters in the
drying phase. Drying program may
differ by temperature, time, drum
speed, suction speed, no wrinkle
parameter, etc. The IM7
microprocessor allows for up to 30
different programs which can be

modied by the user following its

needs. Each program is named
and can be recalled each time it is
needed. In this way the drying result
will be always of high quality,
damages on linen will be avoided and
cycle setting time will be saved.

IMESA:

ADDING VALUE

- Big lint screen; easy to be cleaned when the
request is displayed;

- Cooling function, to avoid shocks to the linen;

- High efciency suction system;

- Energy control function.

Options:

- Mechanical coin box;

- Electronic coin box;

- Cashless payment system (electronic key). This system
may be combined with a mechanical or electronic coin box;

- Connection to central cash;

- Display personalisation with advertising messages.

ES M 55 – 75

Ideal for medium / high productivity laundry, IMESA ES M tumble dryers are all available
with:

- Stainless steel drum;

- Eposidic painted panel;

- Microprocessor controlled: 30 programs;

- Residual humidity control;

- Big lint screen easy to be cleaned when the request
is displayed;

- Cooling function, to avoid shocks to the linen;

- High efciency suction system;

- Inverter;

- Motorreductiongear;

- Reversing drum;

- Energy control function.

Tilting Version:

- Pneumatic forward tilting to make easier the unloading
on a trolley or on a transporting belt (version T1);

- Pneumatic backward tilting to receive the loading by

QUALITY AT

EVERYONE

DISPOSAL!

ES M LINE:

HIGH

CAPACITY
FOR HIGH

QUALITY

RESULTS!

a conveyor (version T2);

TO YUOR JOB!

- Remote control.
