Iluv INT170 User Manual

Model: iNT170
Instruction Manual
English
Internet Radio with Dual Alarm Clock
INTRODUCTION
Congratulations on your purchase of the iLuv iNT170. Bringing thousands of worldwide Internet radio stations right into your home, the iNT170 also provides advanced audio and radio performance that brings out the best in your music. Remember to keep this manual for future reference.
Internet Radio with Dual Alarm Clock
· Access worldwide internet radio stations powered by vTuner technology
· Powerful built-in speakers allow you to hear your music with depth and clarity
· Large display for easy read
· Dual alarm clock
· 40 preset stations for Internet radio & FM radio (20 Internet radio / 20 FM radio)
· Auxiliary line input for any audio devices with 3.5mm jack
· 3.5mm stereo headphone jack
· LCD dimmer level control (3 steps)
Digital Dual Alarm Clock
· Digital clock display with dual alarm clock
· Auto time update through internet or FM radio
· Wake to Internet radio, FM radio, or buzzer
· Sleep to Internet radio or FM radio
FM Radio
· FM stereo
· PLL digital tuning technology
What’s Included?
· Main unit
· AC adapter
· Remote control (battery included)
· Quick start guide
· Warranty card
iLuv | 1
TABLE OF CONTENTS
GETTING STARTED
INTRODUCTION
GETTING STARTED
Location of Controls on the Main Unit Location of Controls on the Remote Control Understanding the Controls Screen Displays
OPERATIONAL INSTRUCTIONS
General Setup Setting the Language Setting the Time and Date Alarm and Sleep Functions Connecting to a Network Internet Radio Mode Registering an Account Conguring “My Preferences” Conguring “My Account” Checking “My Favourites” Checking “My Added Stations” FM Radio Mode AUX In Mode System Resetting
MAINTENANCE & TROUBLESHOOTING GUIDE
IMPORTANT SAFETY INSTRUCTIONS
SPECIFICATIONS
3
10 11 13 16 18 19 20 21 21 22 22
23
24
31
1
4 5 7
9
9 9
Location of Controls on the Main Unit
1. SPEAKERS
2. NEGATIVE LCD screen
3. SNOOZE / DIMMER bar
4. VOLUME control
5. POWER button
6. MODE button
7. MUTE button
8. AL 1 button
1
2
3
4 5 6 7 8 9 10 11 12 13 14
9. AL 2 button
10. SLEEP button
11. PRESET button
12. MENU button
13. BACK / INFO control
14. SELECT / TUNING control
15. HEADPHONE jack
16. AUX IN jack
16
15
iLuv | 3iNT170 | V10M10_IM_EN_101320082 | iLuv
GETTING STARTED
SNOOZE DIMMER
INTERNET
RADIO
FM
AL. OFF
AL 2AL 1 SLEEP
PRESETINFO.
SELECT
BACK
MENU
AUX
MUTE
VOLVOL
GETTING STARTED
Location of Controls on the Main Unit - continued
Location of Controls on the Remote Control
1
2
3
4
5
6
7
8
9
10
1. SNOOZE/DIMMER button
2. POWER/AL OFF button
3. INTERNET RADIO button
11
4. UP, DOWN buttons
12
5. BACK button
13
6. SELECT button
14
7. VOLUME –/+ buttons
8. INFO Button
7
9. AL 2 button
4
10. AL 1 button
15
11. MUTE button
12. FM button
16
13. AUX button
14. MENU button
15. PRESET button
16. SLEEP button
RJ-45 (network cable) jack
POWER jack
Understanding the Controls
Main Unit
· POWER Press to enter the standby mode. The radio will display the date and time when in standby mode. Press a second time to return to the previous selection. When alarm is sounding, press to stop alarm.
· MODE Mode selection: Internet Radio, FM, AUX
· MUTE Mute and release speakers
· ALARM 1 Alarm 1 setting
· ALARM 2 Alarm 2 setting
· SLEEP Press to enter Sleep menu.
· VOL+ Press to increase the volume
· VOL– Press to decrease the volume
· PRESET Hold for a few seconds to store a station into the preset. Short press to select the preset for playback
· MENU Press to enter the context menu for selected mode. Press a second time to return to the previous selection
· BACK Press to return to the previously selected menu entry. Repeatedly pressing the BACK button returns you to the Context menu for the particular mode.
· INFO Press to see information about the service currently playing.
· SCROLL UP Press to scroll up a menu. In FM mode, the SCROLL UP button is also used to manually tune the radio to the next FM frequency.
· SCROLL DOWN Press to scroll down a menu. In FM mode, the SCROLL DOWN button is also used to manually tune the radio to the previous FM frequency.
· SELECT Press to select the current menu entry. In FM mode, press to auto scan and nd the stations.
· SNOOZE/DIMMER Press to start the Snooze mode if the alarm sounds otherwise press to adjust the LCD dimmer.
iLuv | 5iNT170 | V10M10_IM_EN_101320084 | iLuv
GETTING STARTED
FM
Scan setting
Audio setting System settings Main menu
System settings
Network
Time/Date Languages Factory Reset Software update
GETTING STARTED
Understanding the Controls - continued
Remote Control
· POWER Press to enter the standby mode. The radio will display the date and time when in standby mode. Press a second time to return to the previous selection. When alarm is sounding, press to stop alarm.
· MUTE Mute and release speakers
· INTERNET RADIO Press to entry Internet Radio mode.
· FM Press to entry FM radio mode.
· AUX Press to entry Aux in mode.
· ALARM 1 Alarm 1 setting
· ALARM 2 Alarm 2 setting
· SLEEP Press to enter Sleep menu.
· VOL+ Press to increase the volume
· VOL– Press to decrease the volume
· PRESET Press to select the preset for playback
· MENU Press to enter the context menu for selected mode. Press a second time to return to the previous selection
· BACK Press to return to the previously selected menu entry. Repeatedly pressing the BACK button returns you to the Context menu for the particular mode.
· INFO Press to see information about the service currently playing.
· SCROLL UP Press to scroll up a menu. In FM mode, the SCROLL UP button is also used to manually tune the radio to the next FM frequency.
· SCROLL DOWN Press to scroll down a menu. In FM mode, the SCROLL DOWN button is also used to manually tune the radio to the previous FM frequency.
· SELECT Press to select the current menu entry. In FM mode, press to auto scan and nd the stations.
· SNOOZE/DIMMER Press to start the Snooze mode if the alarm sounds, otherwise press to adjust the LCD dimmer.
Screen Displays
The LCD screen displays various menus, dialogues and displays. When the text is too long to t on the screen, it is rst shown truncated and after a few seconds, it scrolls slowly so that all text can be read.
Menus: The iNT170 has three basic menus (FM, Internet and AUX In). Use the SELECT button to proceed through and select options. A scroll bar on the right of the screen shows if there are further options above or below those visible.
· Each mode has a Mode menu, with options specic to that mode.
- For example, the FM mode menu has just two options: Scan setting and Audio setting.
- In addition, each mode menu has two nal options: System settings > and Main menu >. The ‘>’ indicates options leading to further menus.
· The System settings menu allows access to system settings and information such as network, time, language and software update.
- Menus with more options than will t on one screen have a scroll bar to the right.
· The Main menu allows access to all modes plus sleep and timer functions.
* Some menus, for example the System settings menu, have several submenus.
iLuv | 7iNT170 | V10M10_IM_EN_101320086 | iLuv
GETTING STARTED
Daylight savings
Daylight savings
OK
OFF
*
04/07/2009
07:00AM 08:30AM
04:32PM
Internet
Radio
01• 01 • 2009
00:00
Set Time/Date
OPERATIONAL INSTRUCTIONS
Screen Displays - continued
Dialogue screens: Dialogue screens are shown to allow the user to change settings. They vary in
complexity from simple Yes/No options up to the scrollable network password input screen.
· As with menus, the selected item is shown with a white background.
· Dialogue screens mark the current setting with an asterisk (*).
· The Standby screen shows the time, date and any active alarm times.
· As you cycle through the play modes using the MODE button, the LCD screen will show a splash screen for each mode. After one second, the unit enters the selected mode plays the last station that was playing in that mode. If this is not possible, the iNT170 will attempt to connect to the selected source by scanning for stations, networks, or prompting for user input as appropriate.
General Setup
1. Place iNT170 on a suitable shelf or table and plug it in to a power outlet.
2. Once plugged in, the unit will automatically turn on. You should see a welcome message ‘iLuv Starting’ and a moving progress bar.
3. The rst time the unit is switched on, it shows the main menu. Press the SELECT button until FM is highlighted on the menu.
4. Press the SELECT button again to conrm.
5. The FM Now playing screen displays, showing the lowest frequency (87.5 MHz). Press the SELECT button. The frequency display will increase incrementally as the radio scans up. Once a station is found, it will play, with the station name shown in the Now playing display.
Setting the Language
The default language is English. To change this, press the MENU button > System settings > Languages > then select your language.
· A list of supported languages will appear on the LCD screen. Scroll up or down to choose from the list.
Setting the Time and Date
The time and date can be updated manually or automatically. Setting manually is simpler, but the time and date will be lost when power is o. Setting automatically is a little more complicated at rst, but the time and date will be automatically synchronized with external clocks, so it should only need to be done once. As a result, automatic update is generally more accurate. To enter the Time settings menu, press the MENU button > System settings > Time/date >
Manual Updating: Select “Set Time/Date”, the date and time are displayed as MM-DD-YYYY and hh:mm AM/PM with the rst value, MM active (ashing).
· Adjust each value (month, day, year, hour, minute) with the , and SELECT buttons. As each value is adjusted, the next value becomes active and ashes.
· When you select the nal value (minutes or AM/PM, depending on whether the clock is set to 12 or 24 hour mode), the display reverts to the now playing screen and shows the newly updated time.
iLuv | 9iNT170 | V10M10_IM_EN_101320088 | iLuv
