Iluv i7500 User Manual

iLuvTM Mini Audio System V10M10_IM_EN_01302006

iLuv

TM

Instruction Manual

i7500

Please read this manual carefully before operating and save it for future reference.

iLuvTM Mini Audio System V10M10_IM_EN_01302006

CONTENTS

1. CAUTIONS AND WARNINGS ………………………………………………………………………. 2

2. IMPORTANT SAFETY INSTRUCTIONS …………………………………………………………... 3

3. HANDLING COMPACT DISCS ……………………………………………………………………… 5

4. CONTROL PANEL

a. MAIN UNIT ………………………………………………………………………………….. 6

b. SUBWOOFER ………………………………………………………………...................... 7

5. REMOTE CONTROL …………………………………………………………………………………. 8

6. INSTALLATION & CONNECTIONS ………………………………………………………………… 8

7. OPERATIONS

a. GENERAL OPERATIONS ………………………………………………………………… 9

b. CLOCK & RADIO …………………………………………………………………………... 9

c. MP3 CD / AUDIO CD ………………………………………………………………………. 10

d. USB / SD / MS / MMC ……………………………………………………………………… 11

e. iPod ………………………………………………………………………………………….. 12

8. SPECIFICATIONS ……………………………………………………………………………………. 12

- 1 - www.i-Luv.com

iLuvTM Mini Audio System V10M10_IM_EN_01302006

CAUTIONS AND WARNINGS

WARNING: To prevent fire or shock hazard, do not expose this appliance to rain or moisture.

These markings are located on the bottom, side or back of the unit.

CAUTION: To prevent the risk of electric shock, do not remove cover (or back). Non- user-serviceable parts
inside. Refer servicing to a service professional.

The lightning flash with an arrowhead symbol, within an equilateral triangle, is intended to alert the user to
the presence of un-insulated "dangerous voltage" within the product's enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to a person.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating, maintenance and servicing instructions in the literature accompanying the appliance.

Dripping warning: "This product shall not be exposed to any dripping or splashing, and no objects filled
with liquids, such as vases, shall be placed on or near the product."

Ventilation warning: "The normal ventilation of the product shall not be impeded for intended use."

Note: Minimum distances must be kept around the apparatus for sufficient ventilation, especially while use
of the apparatus is in tropical and/or moderate climates.

Dispose of old batteries safely. Do not throw them into a fire.

LASER SAFETY

This unit utilizes laser technology. Only a qualified professional should
remove the cover or attempt to service this device, due to possible eye
injury.

CAUTION

• Use of controls or adjustments or performance of procedure other than
specified herein may result in hazardous radiation exposure.

• Hazardous laser radiation when open and interlock defeated.

DANGER

Invisible laser radiation when open and interlock failure. Avoid direct
exposure to beam.

- 2 - www.i-Luv.com

iLuvTM Mini Audio System V10M10_IM_EN_01302006

IMPORTANT SAFETY INSTRUCTIONS

1. READ INSTRUCTIONS - All the safety and operating instructions should be read before the appliance
is operated.

2. RETAIN INSTRUCTIONS - The safety and operating instructions should be retained in a secure place
for future reference.

3. HEED WARNINGS - All warnings on the appliance and in the operating instructions should be adhered
to.

4. FOLLOW INSTRUCTIONS - All operating and use instructions should be followed.

5. WATER AND MOISTURE - The appliance should not be used near water. For example: near a bathtub,
kitchen sink, laundry tub, and swimming pool or even in a wet basement.

6. VENTILATION - The appliance should be situated so that its location and position does not interfere
with its proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug or
similar surface that may block the ventilation openings; or, be placed in a built-in installation, such as a
bookcase or cabinet that may impede the flow of air through the ventilation openings.

7. HEAT - The appliance should be situated away from heat sources such as radiators, heat registers,
stoves, or other appliances (including amplifiers) that produce heat.

8. POWER SOURCES - The appliance should be connected to a power supply only of the type described
in the operating instructions or as marked on the appliance.

9. GROUNDING AND POLARIZATION - Precautions should be taken to ensure that the grounding or
polarization of the appliance is correct.

10. POWER CORD PROTECTION - Power supply cords should be routed so that they are not likely to be
walked on or obstructed by items placed upon or against them. Pay particular attention to cords at
plugs, convenience receptacles, and the point at which they exit from the appliance.

11. CLEANING - The appliance should be cleaned only as recommended by the manufacturer.

12. POWER LINES - An outdoor antenna should be located away from power lines.

13. NONUSE PERIODS - The power cord of the appliance should be unplugged from the outlet when the
appliance is to be left unused for an extended period of time.

14. OBJECT and LIQUID ENTRY - Care should be taken so that objects do not fall and liquids are not
spilled into the device’s openings.

15. CARTS AND STANDS - The appliance should be used only with a cart or stand that is recommended
by the manufacturer. An appliance and cart combination should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

16. WALL OR CEILING MOUNTING - If the appliance is mounted to a wall or ceiling, it should be
mounted only as recommended by the manufacturer.

17. DAMAGE REQUIRING SERVICE - The appliance should be serviced by qualified service
professional when:

a. The power-supply cord or plug has been damaged.
b. Objects have fallen into, or liquid has been spilled into the appliance’s apertures.
c. The appliance has been exposed to rain.

- 3 - www.i-Luv.com

iLuvTM Mini Audio System V10M10_IM_EN_01302006

A

IMPORTANT SAFETY INSTRUCTIONS

d. The appliance has been dropped and suffered damage.
e. The appliance does not appear to operate normally or exhibits a marked change in

performance.

18. SERVICING - The user should not attempt to service the appliance beyond that described in the
user's operating instructions. All other servicing should be referred to qualified service professional.

19. OUTDOOR ANTENNA GROUNDING - If an outside antenna is connected to the receiver, be sure
that the antenna system is grounded so as to provide some protection against voltage surges and
built up static charges. Section 810 of the National Electrical Code, ANS/NFPA No. 70-1984 provides
information with respect to proper grounding of the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge
unit, connection to grounding electrodes, and requirements for the grounding electrode.

Example of antenna grounding
as per national electrical code

Antenna lead in wire

Ground clamp

ntenna discharge unit

(NEC section 810-20)

Electric service

equipment

Grounding conductors
(NEC section 810-21)

Ground clamps

Power service grounding electrode system (NEC art 250, part H)

20. PROTECTIVE ATTACHMENT PLUG - The appliance is equipped with an attachment plug that has
an overload protection. This is a safety feature. If replacement of the plug is required, be sure the
service technician has used a replacement plug specified by the manufacturer that has the same
overload protection as the original plug. (UK Version Only)

- 4 - www.i-Luv.com
