Iluv i177 User Manual 2

Model : i177

Instruction Manual

English

Stereo Audio System with Dual Alarm for Your iPod®

INTRODUCTION

Congratulations on your purchase of the iLuv i177 for your iPod. Uniquely designed to work with your
iPod, this iLuv stereo audio system with the built-in universal dock provides advanced audio and radio
performance that brings out the best in your music. Remember to keep this manual for future reference.

· Enjoy rich sound from your iPod * with jAuraTM acoustic speaker technology

· Powerful built-in speakers allow you to hear your music with depth and clarity

· Digital clock display with dual alarm function

· Wake to your iPod, AM/FM radio, or buzzer

· Fall asleep to your iPod or AM/FM radio

· Plays and charges your iPod *

· Integrated universal dock for your iPod

· Supports iPod shue**

· Auxiliary line input for any audio devices
with 3.5mm jack

· AM/FM radio with PLL digital tuning technology

· External loop antenna provides better AM reception

· Liquid crystal display with white backlight and 4 level
dimmer control

What’s Included?

· Main unit

· Remote control (battery included)

· Dock adapters

· iPod shue adapter

· AC adapter

· Audio patch cable (3.5mm to 3.5mm)

· AM loop antenna

* Compatible with any iPod with dock connector (excluding 1st, 2nd, and 3rd generation iPod)
** iPod shue 2nd generation only / iPod shue cannot be played and charged at the same time.

iLuv | 1i177 | V14M14_IM_EN_09242008

TABLE OF CONTENTS

GETTING STARTED

INTRODUCTION

GETTING STARTED

Installing the AC adapter
Installing the backup battery for clock and alarm settings
Remote control rst time use and replacing of the battery
Installing the AM loop antenna
Installing the dock adapter
Location of controls on the main unit
Location of controls on the remote control
Location of indications on the LCD screen
Setting the clock time
Setting the alarm time

OPERATIONAL INSTRUCTIONS

Outputting the audio signal to an external amplier or recording device
Listening to your favorite songs on your iPod
Charging your iPod
Listening to other audio devices
Listening to your favorite radio stations
Using the alarm function
Adjusting the brightness of the LCD screen
Setting the sleep time

MAINTENANCE & TROUBLESHOOTING GUIDE

USER SAFETY GUIDE

SPECIFICATIONS

2 | iLuv

3

10
10
11
11
12
12
13

14

16

23

1

3
4
4

4

5

6

7
8
8

9

Installing the AC Adapter

Locate the AC adapter jack on the back of the unit. Insert the AC adapter cable into the jack, and
plug into the wall outlet.

Installing the Backup Battery for Clock and Alarm Settings

In order to oer consistent clock settings and alarm functions, the i177 uses a backup battery
system. This means that in the event of a power failure, all the settings of i177 will remain saved. For
example, after the installation of the Backup Battery, the AC cord is disconnected or a power failure
occurs, the display will not remain lit, but the time, date and alarm settings will be temporarily
maintained. The alarm, however, will not sound when the i177 is powered only by the Backup
Battery. To install Backup Battery, follow the instructions below:

1. Make sure the connection between the AC adapter and the unit is secure. This is important
because during battery replacement it is possible for all settings to be lost if clock and alarm
have already been set.

2. Locate the battery compartment on the bottom of the unit and open.

3. Insert 2 “AA” batteries, following the correct polarity (+/-) drawings inside the battery
compartment. For longer battery life, alkaline batteries are suggested. Please note that new
and used batteries should not be mixed. Likewise, alkaline, standard (carbon-zinc) or
rechargeable (nickel-cadmium) batteries should not be used together.

4. Secure the battery compartment by closing the cover.

Important Notes on Batteries

To prevent battery leakage, which may result in bodily injury, property damage or
damage to the unit, follow these instructions.

· Install all batteries correctly according to the polarity (+/–) as marked on the unit.

· Do not mix old and new batteries, carbon and alkaline, etc.

· Remove batteries from the unit when the device will not be used for an extended
period of time.

Please dispose the used batteries properly according to your local
government regulations.

iLuv | 3i177 | V14M14_IM_EN_09242008

GETTING STARTED

GETTING STARTED

Remote Control - First Time Use and Replacing of the Battery

The remote control battery has been previously installed and ready for operation for immediate
use. For the rst time use, pull out the insulation tag from the button battery tray before operating
the remote control. When the remote control stops functioning, you must replace the battery with
a new one. To do so, locate the battery compartment on the side of the remote and follow the
steps below:

1. Squeeze the notch labeled “Tab A” while pulling the
“battery door latch B” out towards you. This will allow
the battery holder to release and pop out. Please refer
to the picture on the right side.

2. Insert a “CR2025” 3V lithium battery. Make certain to
follow the correct polarity, following the directions of
the corresponding symbols (+/–).

3. Secure battery and push the battery holder back into
the remote control until fully inserted.

Battery
door latch

Installing the AM Loop Antenna

For AM radio operation, locate the AM antenna jack on the back of the unit. Plug the AM loop
antenna into the connector. To achieve the best reception possible, a distance of 30 cm between
the AM antenna, the unit and the iPod is recommended.

Installing the Dock Adapter

To guarantee that your iPod will t properly into the built-in universal dock, several detachable
dock adapters for old iPod players are included with this product. Please check the bottom of dock
adapters to determine compatibility with your iPod.

1. Inserting the dock adapter
a. Choose a dock adapter that corresponds with the iPod you would like to dock. Using the
correct dock adapter ensures a proper t.
b. Gently push the dock adapter down into the universal dock.
c. Carefully place your iPod into the universal dock. Please note that iPod must not be in a case
or “Skin”.

2. Removing the dock adapter

• Remove your iPod, grasp the dock adapter and lift upwards carefully.

4 | iLuv

Location of Controls on the Main Unit

1. VOLUME

2. PLAY / PAUSE

3. BAND/RADIO

4. Connector for iPod shue 2nd Generation

5. iPod / shue

6. Built-in Universal Dock

7. ALARM 1

8. ALARM 2

A

B

18

9. SEARCH

10. LCD Display

11. WAKE TO

12. SLEEP

13. AUX

14. TIME SET

15. POWER OFF

16. SNOOZE/DIMMER

4 6 971 32 85

141211 151310 16

2317 1719 20 2221

17. Speaker Ports

18. AC Adapter Jack

19. LINE-OUT Jack

20. AM Loop Antenna Socket

21. Battery Compartment

22. LINE-IN Jack

23. FM Antenna Wire

iLuv | 5i177 | V14M14_IM_EN_09242008

GETTING STARTED

BAND/
RADIO

AUX

SNOOZE/
DIMMER

iPod

GETTING STARTED

Location of Controls on the Remote Control

24. POWER ON/OFF

24

25

26

27

28

Note: The included remote control commands all of the basic functions on the i177. Aim the remote control toward

the bottom right corner of the main unit for the best results. Please note that the provided remote control
cannot control iPod shue, the rst generation iPod, or the second generation of iPod.

29

30

31

32

To install a new battery, please refer to the section “Remote Control - First Time Use and
Replacing of the Battery”.

6 | iLuv

Turns i177 on/o or switches o alarm when alarm is sounding.

25. BAND / RADIO
Chooses radio function.

26. SNOOZE / DIMMER
Activates snooze mode when the alarm sounds. It also
adjusts the strength of the LCD backlight.

27. / DOWN
Skips to the previous track when iPod is playing, or scans
currently playing track toward the beginning by pressing and
holding. In the radio mode, it tunes the radio stations by
pressing and holding.

28. VOLUME –
Decreases the volume level.

29. AUX
Enables the AUX function.

30. PLAY / PAUSE
Selects iPod and plays a track. In the play mode, it is used to
pause the playback.

31. / UP
Skips to the next track when iPod is playing, or scans
currently playing track toward the end by pressing and
holding. In the radio mode, it tunes the radio stations by
pressing and holding.

32. VOLUME +
Increases the volume level.

Location of Indications on the LCD Screen

Wake To Indicator

iPod, Radio, Buzzer

iPod Indicator

Sleep Indicator

Time/Alarm Display

Alarm 1 Armed

PM Indicator

AM/FM Indicator

Shue Indicator
Alarm 2 Armed
Wake To Indicator

iPod, Radio, Buzzer

ST/KHz/MHz Indicator

Radio Frequency/Date
Volume Level/AUX Display

iLuv | 7i177 | V14M14_IM_EN_09242008
