Iluv i166 Instruction Manual
Stereo Audio System for Your iPod®
Instruction Manual
Model: i166
Please read this manual carefully before operating and save it for future reference.
Have a question? Please visit http://www.i-Luv.com
iLuvTM Stereo Audio System for Your iPod V11M11_IM_EN_10172007
www.i-Luv.com - 1 -
USER SAFETY GUIDE
INSTRUCTIONS ON ENVIRONMENT PROTECTION
Do not dispose of this product in the usual household garbage at the end of its life cycle; bring it to a collection point for the recycling of
electrical and electronic appliances. This symbol on the product means the instructions for use or the packing will inform about the methods
for disposal. The materials are recyclable as mentioned in its marking. By recycling, material recycling, or other forms of re-utilization of old
appliances, you make an important contribution to protect the environment. Please inquire at your local community administration for the
authorized disposal location.
IMPORTANT SAFETY WARNINGS
1. FCC regulations state that any change or modification to the equipment, not expressly approved by maker or its authorized parties, could void the
user’s authority to operate this equipment.
2. To prevent fire or electric shock, do not expose the unit to rain or moisture.
3. Never attempt to open the cabinet. Always refer servicing to a qualified technician.
IMPORTANT SAFETY INSTRUCTIONS
1. READ INSTRUCTIONS - All the safety and operating instructions should be read before the appliance is operated.
2. RETAIN INSTRUCTIONS - The safety and operating instructions should be retained in a secure place for future reference.
3. HEED WARNINGS - All warnings on the appliance and in the operating instructions should be observed.
4. FOLLOW INSTRUCTIONS - All operating and use instructions should be followed.
5. WATER AND MOISTURE - The appliance should not be used near water. For example: near a bathtub, kitchen sink, laundry tub, and/or swimming
pool.
6. HEAT - The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (including amplifiers)
that produce heat.
iLuvTM Stereo Audio System for Your iPod V11M11_IM_EN_10172007
www.i-Luv.com - 2 -
USER SAFETY GUIDE
IMPORTANT SAFETY INSTRUCTIONS – CONTINUED
7. POWER SOURCES - The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on
the appliance.
8. CLEANING - The appliance should be cleaned with a dry cloth.
9. OBJECT and LIQUID ENTRY - Care should be taken so that objects do not fall and liquids are not spilled into the device’s openings.
10. CARTS AND STANDS - The appliance should be used only with a cart or stand that is recommended by the manufacturer. An
appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the
appliance and cart combination to overturn
11. DAMAGE REQUIRING SERVICE - The appliance should be serviced by qualified service professional when:
a. The power-supply cord or plug has been damaged.
b. Objects have fallen into, or liquid has been spilled into the appliance’s apertures.
c. The appliance has been exposed to rain.
d. The appliance has been dropped and suffered damage.
e. The appliance does not appear to operate normally, or exhibits a change in performance.
12. SERVICING - The user should not attempt to service the appliance beyond that described in the user's operating instructions. All other servicing should
be referred to qualified service professional.
13. BATTERY USAGE – To prevent battery leakage, which may result in bodily injury, property damage or damage to the unit, follow these instructions:
a. Install all batteries correctly according to the polarity (+ -) as marked on the unit.
b. Do not mix old and new batteries, carbon and alkaline, etc.
c. Remove batteries from the unit when the device will not be used for an extended period of time.
14. LEAD AND MERCURY - This product may contain lead and/or mercury. Disposal of these materials may be regulated by your local authorities due to
environmental considerations. For more detailed disposal or recycling information, please contact your local authorities or the EIA (Electronic Industries
Alliance) – http://www.eiae.org
iLuvTM Stereo Audio System for Your iPod V11M11_IM_EN_10172007
www.i-Luv.com - 3 -
USER SAFETY GUIDE
FOR USERS IN THE USA
As specified in Part 15 of the FCC Rules, this equipment complies within the limits of a Class B digital device. These restrictions provide sufficient protection
against radio and TV interference in residential areas. However, even during normal operation, this device may cause TV or radio interference. In attempting
to eliminate some or all interference, you should try one or more of the following corrective measures:
1. Increase the distance between the device and the radio and/or TV
2. Try a different outlet on various electrical circuits for the device, the radio and/or TV.
3. Reposition the receiving antenna
Do not attempt to fix technical problems yourself if they continue to still exist. Refer servicing only to a qualified technical professional. Interfering or
modifying with your product’s internal components may cause a malfunction and an invalidation of the system’s warranty. This tampering can also void the
FCC authorization to operate it.
This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference.
IMPORTANT NOTES
Since digital circuitry may cause interference to other radio or television tuners nearby, switch this unit off when not in use or move it away from the affected
radio/television tuner.
FOR USERS IN CANADA
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the Radio Interference Regulations of
Industry Canada. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television operation (which can be determined by turning the equipment off), the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for help.
iLuvTM Stereo Audio System for Your iPod V11M11_IM_EN_10172007
www.i-Luv.com - 4 -
TABLE OF CONTENTS
Getting Started
General features ……………………………………………………………………………………………………………………………………………...… 5
Power Source…………….……………………………………………………………..………………………………………………………..……………... 6
Protect your Furniture ………………..……………………….……………………………………………………………………………………………….. 6
Installing the remote control battery ….....………………………………………………………………………………………………………….………… 6
Installing the dock adapter …………………………………………………………………………………………………………………………………….. 7
Location of controls on the main unit ……………………………………………………………………………………………………………….…...…… 8
Location of controls on the remote control …………………………………………………………………………………………………………………... 10
Location of indications on the LCD screen …...……………………………………………………………………………………………………………... 11
Setting the clock …….....…………….…………...……………………………………………………………………………………………………………. 11
Operational Instructions
Setting the alarm ………………………………………………………………………………………………………………………………………..……… 12
Using the Snooze Function ……………………………………………………………………………………………………………………………………. 12
Using the Sleep Function ……………………………………………………………………………………………………………………………………… 12
Listening to your iPod ………………………………………………………………………………………………………………………………………….. 13
Controlling your iPod using the Remote Control ……………………………………………………………………………………………………………. 13
Listening to the Radio ………………………………………………………………………………………………………………………………………….. 13
Charging your iPod ……………………………………………………………………………………………………………………………………………. 14
AUX In …………………………………………………………………………………………………………………………………………………………… 14
Subwoofer Out ………….………………………………………………………………………………………………………………………………………. 15
Adjusting the brightness of the LCD screen ………...………………………………………………………………………………………………………. 15
Resetting the Unit …………………………………………………………………………………………………………………………..………………….. 15
Back Up Function ………………………………………………………………………………………………………………………………………………. 15
Maintenance …………………………………………………………………………………………………………………………………………………….. 15
Troubleshooting Guide ……………………………………………………………………………………………………………..……………………………… 16
iLuvTM Stereo Audio System for Your iPod V11M11_IM_EN_10172007
www.i-Luv.com - 5 -
GETTING STARTED
Congratulations on your purchase of the new iLuv
TM
i166 for your iPod. Targeted specifically to work with iPod, iLuv stereo audio system with the built-in
universal dock provides advanced audio and radio performance that brings out the best in your music. Do not forget to keep this manual for future reference.
Stereo Audio with iPod dock and AM/FM, Dual Alarm Clock
• Powerful built-in speakers allow you to hear and enjoy your music.
• Digital clock display with dual alarm function
• High and low dimmer control
• Sleep or wake to your iPod, AM/FM radio or Buzzer
• Charges your iPod
• Integrated universal dock for your iPod
• Auxiliary line input for 1
st
and 2nd generation iPod and other audio devices*
• Subwoofer output jack for bass boost sound effect (subwoofer speaker not included)
• AM/FM radio with PLL digital tuning technology
• Liquid crystal display with blue backlight
• Full function 18-key remote control included (also controls your iPod)
In the box
• Stereo audio system
• Remote control (battery included)
• Dock adapters
• Instruction manual
• Warranty card
*Any Audio Device with 3.5 mm output (iPod Shuffle 1
st
and 2nd Gen., MP3, CD, DVD players, Laptops, PDAs, etc.)
