iLive IJ328-IB User Manual
IJ328-IB
Karaoke Stereo with Dock for iPod
T A B L E O F C O N T E N T S
Warnings and Precautions .......................................................2
Important Safety Instructions ..................................................3
In the Box & Features .............................................................4
Powering the Unit & Changing the Remote Battery ..............5
Docking an iPod ......................................................................6
Playing an iPod & Playing an iPod Karaoke Song .................7
Playing a CD & Playing a Standard CD for Karaoke .............8
Playing a CD+G Disc .............................................................9
Programming a CD or CD+G Disc .........................................9
Video Output: Connecting a Television ................................10
Audio Output: Connecting a Stereo System .........................11
Audio Input: Connecting an MP3 Player ..............................11
Locations of Controls & Definitions ............................... 12-19
Service & Parts Information .................................................20
IJ328-IB.indd 1 7/10/2008 2:21:40 PM
2
2
Warnings and Precautions
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
WARNING: Use of this unit near uorescent lighting may cause interference regarding use of the remote.
If the unit is displaying erratic behavior move away from any uorescent lighting, as it may be the cause.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh, etc) batteries.
WARNING: The remote control’s button cell battery contains mercury. Do not put in the trash, instead
recycle or dispose of as hazardous waste
WARNING: Danger of explosion if the remote control’s batteries are incorrectly installed. Replace only
with the same or equivalent battery.
WARNING: Changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This symbol, located on back or
bottom of the unit, is intended to alert
the user to the presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may be of
sufcient magnitude to constitute a
risk of electric shock to persons.
This symbol, located on back or
bottom of the unit, is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.
This product utilizes a Class 1 laser
to read Compact Discs. This laser
Compact Disc Player is equipped with
safety switches to avoid exposure
when the CD door is open and
the safety interlocks are defeated.
Invisible laser radiation is present
when the CD Player’s lid is open and
the system’s interlock has failed or
been defeated. It is very important
that you avoid direct exposure to the
laser beam at all times. Please do not
attempt to defeat or bypass the safety
switches.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
To reduce the risk of electric shock, do not remove cover (or back).
There are no user-serviceable parts inside. Please refer any servicing
to qualied service personnel.
IJ328-IB.indd 2 7/10/2008 2:21:40 PM
33
Important Safety Instructions
1. Read Instructions - All the safety and operating instruction should be read
before the product is operated.
2. Retain Instructions - The safety and operating instruction should be
retained for future reference.
3. Heed Warnings - All warning on the product and in the operating
instructions should be adhered to.
4. Follow instructions - All operating and use instructions should be
followed.
5. Cleaning - Unplug this product from the wall outlet before cleaning. Do
not use liquid cleaners or aerosol cleaners. Clean only with a dry cloth.
6. Attachments - Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
7. Water and Moisture - Do not use this product near water - for example,
near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement,
or near a swimming pool, and the like. The apparatus shall not be exposed
to dripping or splashing and that no objects lled with liquids, such as
vases, shall be placed on apparatus.
8. Accessories - Do not place this product on an unstable cart, stand tripod,
bracket, or table. The product may fall, causing serious injury to a child
or adult, and serious damage to the product. Use only with a cart, stand,
tripod, bracket, or table recommended by the manufacturer, or sold with
the product. Any mounting of the product should follow the manufacturer’s
instructions, and should use a mounting accessory recommended by the
manufacturer.
9. A product and cart combination should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause the appliance and cart
combination to overturn.
See gure:
10. Ventilation - Slots and openings in the cabinet are provided for ventilation
and to ensure reliable operation of the product and to protect it from
overheating, and these openings must not be blocked or covered. The
openings should never be blocked by placing the product on a bed, sofa,
rug, or other similar surface. This product should not be placed in a built-in
installation such as a bookcase or rack unless proper ventilation is provided
or the manufacturer’s instruction have been adhered to.
11. Power Sources - This product should be operated only from the type of
power source indicated on the marking label. If you are not sure of the type
of power supply to your home, consult your product dealer or local power
company. For products intended to operate from battery power, or other
sources, refer to the operating instruction.
12. Grounding or Polarization - This product may be equipped with a
polarized alternating-current line plug (a plug having one blade wider than
the other). This plug will t into the power outlet only one way. This is a
safety feature. If you are unable to insert the plug fully into the outlet, try
reversing the plug. If the plug should still fail to t, contact your electrician
to replace your obsolete outlet. Do not defeat the safety purpose of the
polarizes plug.
Alternate Warnings - This product is equipped with a three-wire
grounding-type plug, a plug having a third (grounding) pin. This plug
will only t into a grounding-type power outlet. This is a safety feature.
If you are unable to insert the plug into the outlet, contact your electrician
to replace your obsolete outlet. Do not defeat the safety purpose of the
grounding-type plug.
13. Power-Cord Protection - Power supply cords should be routed so that
they are not likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs, convenience
receptacles, and point where they exit from the product.
14. Protective Attachment Plug - The product is equipped with an attachment
plug having overload protection. This is a safety feature. See Instruction
Manual for replacement or resetting of protective device. If replacement of
the plug is required, be sure the service technician has used a replacement
plug specied by the manufacturer that has the same overload protection as
the original plug.
15. Outdoor Antenna Grounding - If an outside antenna is connected to the
receiver, be sure the antenna system is grounded so as to provide some
protection against voltage surges and built-up static charges. Article 810 of
the National Electrical Code, ANSI/NFPA 70, provides information with
regard to proper grounding of the mast and supporting structure, grounding
of the mast and supporting structure, grounding of the lead-in wire to an
antenna-discharge unit, size of grounding conductors, location of antennadischarge unit, connection to grounding electrodes, and requirements for
the grounding electrode.
See gure:
16. Lightning - For added protection for this product during a lightning storm,
or when it is left unattended and unused for long periods of time, unplug it
from the wall outlet and disconnect the antenna or cable system. This will
prevent damage to the product due to lightning and power-line surges.
17. Power Lines - An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light or power circuits,
or where it can fall into such power lines or circuits. When installing
an outside antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them might be fatal.
18. Overloading - Do not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of re or electric shock.
19. Object and Liquid Entry - Never push objects of any kind into this
product through openings as they may touch dangerous voltage points or
short-out parts that could result in a re or electric shock. Never spill liquid
of any kind on the product.
20. Servicing - Do not attempt to service this product yourself as opening or
removing covers may expose you to dangerous voltage or other hazards.
Refer all servicing to qualied service personnel.
21. Damage Requiring Service - Unplug this product from the wall outlet
and refer servicing to qualied service personnel under the following
conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualied technician to
restore the product to its normal operation.
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance - this
indicates a need for service.
22. Replacement Parts - When replacement parts are required, be sure the
service technician has used replacement parts specied by the manufacturer
or have the same characteristics as the original part. Unauthorized
substitutions may result in re, electric shock, or other hazards.
23. Safety Check - Upon completion of any service or repairs to this product,
ask the service technician to perform safety checks to determine that the
product is in proper operating condition.
24. Wall or Ceiling Mounting - The product should be mounted to a wall or
ceiling only as recommended by the manufacturer.
25. Heat - The product should be situated away from heat sources such as
radiators, heat registers, stoves, or other products (including ampliers)
that produce heat. Battery shall not be exposed to excessive heat such as
sunshine, re, or the like.
26. Main plug is used as disconnect device and it should remain readily
operable during intended use. In order to disconnect the apparatus from
the mains completely, the mains plug should be disconnected from the
mains socket outlet completely.
27. Excessive sound pressure from earphones and headphones can cause
hearing loss.
IJ328-IB.indd 3 7/10/2008 2:21:41 PM
4
In the Box Features
CD+G Karaoke Player with iPod® Karaoke Function
• Top-Load Player plays CD+G, CD Discs
• 5.5" B&W Monitor displays CD+G graphics & lyrics
Docking Station for iPod
• Certied iPod Connector installed for iPod docking
• Recharge Circuit for iPod/mini/nano/photo/video
• Includes docking brackets to t iPod Players
• Controls Connected iPod Players
• iPod Authentication IC installed
Play Features
• Programmable Tracks
• Repeat 1 or ALL Play
• Song Skip/Search on CD Discs
• Master Volume Control
• Mic Volume Control
• Echo Controls
• AVC Control
• 2-Digit Red LED Display
Jacks
• 2 Microphone Jacks, 6.3mm
• Aux-In Jack, RCA type
• Video Out Jack, RCA type, works with iPod Nano also
• Audio Output Jacks, L&R RCA type
• Speakers built in
Remote Control
• Controls docked iPod & Player
• Controls Disc Player
AC-Powered, AC Adaptor included
• Includes
• 1-Microphone
• Brackets for iPod
• A/V Cable, 3-RCA to 3-RCA
• Remote Control, battery included
• AC/DC Adaptor
IJ328-IB.indd 4 7/10/2008 2:21:41 PM
5
Changing the Remote Battery
The Remote Control has a button cell battery pre loaded into it.
Step 1: Push the Release Button and pull out the Battery Compartment to access
the battery.
Step 2: Replace the old battery with an equivalent new battery (CR2025).
Step 3: The positive side of the battery, as indicated by a plus symbol, must be
facing up with inserted into the remote.
Powering the Unit
The unit is powered by plugging the AC adaptor into a standard 120V ~ 60Hz outlet.
Video Out R Out L Out
R In L In
V- Hold Brightness Contrast
Video In
LITHIUM BA
T
TER
Y
CR 2025
3V
CR2025
PUSH
OPEN
LITHI
UM BATT
ER
Y
CR 2025
3V
CR2025
PUSH
OPEN
AC 120V / 60Hz
IJ328-IB.indd 5 7/10/2008 2:21:42 PM
6
Docking an iPod
Step 1: Locate the numbered bracket that ts the iPod that will be docked.
• Each included bracket has a number on it, indicating which iPod
model that bracket is compatible with. See the separate bracket chart
page toidentify which bracket is needed.
Step 2: Snap the bracket into place over the iPod connector in the docking
station.
• All brackets will only t one way onto the dock.
• When inserting an iPod nano (rst or second generation), slide the
dock connection on the unit so that it matches the opening on the iPod
nano (rst or second generation).
Step 3: Connect the iPod to the iPod connector inside the docking station.
• Once an iPod is connected to the docking station, the unit will amplify
and charge the docked iPod.
IJ328-IB.indd 6 7/10/2008 2:21:42 PM
Loading...
