Ik Multimedia iRig BlueTurn USER MANUAL
Bluetooth page turner
USER MANUAL
Contents
Table of Contents
Contents |
2 |
||
English |
3 |
||
|
Safety Information |
3 |
|
|
iRig BlueTurn |
3 |
|
|
Register your iRig BlueTurn |
3 |
|
|
Installation and setup |
4 |
|
|
|
Mode 1 |
6 |
|
|
Mode 2 |
7 |
|
|
Mode 3 |
8 |
|
Virtual keyboard in iOS |
9 |
|
|
Startup notes |
9 |
|
|
Foot-switches backlite |
10 |
|
|
Status LED |
10 |
|
|
Troubleshooting |
10 |
|
|
Specifications |
11 |
|
|
Warranty |
11 |
|
|
Support and more info |
11 |
|
Regulatory |
12 |
||
|
|
|
|
2
English
Safety Information
•To reduce risk of internal damage or malfunction, never expose the unit to rain, moisture or excessive humidity. Never let any liquid spill on the unit.
•Always remove the batteries if you plan to not use the unit for a long time.
•Never expose the unit to a temperature higher than 60°C (140°F) .
•Never step over the unit or step on it with your full weight, this might cause permanent damages to the iRig BlueTurn structure and foot switches.
•There are no user serviceable parts inside iRig BlueTurn, never open the unit.
•All servicing should be referred to qualified personnel only.
•iRig BlueTurn communicates via Bluetooth. Never insert iRig BlueTurn into metallic cases or structures that could shield the Bluetooth signal.
•CAUTION: risk of explosion if battery is replaced by an incorrect type. iRig BlueTurn can ONLY be used with consumer grade, non-rechargeable CARBON-ZINC or ALKALINE batteries.
iRig BlueTurn
Thank you for purchasing iRig BlueTurn.
Your package contains:
•iRig BlueTurn
•2 x AAA batteries
•Quick Start Guide
•Registration Card
iRig BlueTurn is a Bluetooth controller pedalboard that sports two foot-switches for scrolling through lyrics or guitar tabs from compatible Apps. The iRig BlueTurn is the perfect controller for Mac, PC, iOS or Android devices equipped for Bluetooth Low Energy.
iRig BlueTurn lets you take control with effortless scrolling through lyrics, guitar tabs and sheet music. It’s also great for teleprompting, slide presentations, instrument effects, media control and more.
Register your iRig BlueTurn
By registering, you can access technical support, activate your warranty and receive free JamPoints™ which will be added to your account. JamPoints™ allow you to obtain discounts on future IK purchases! Registering also keeps you informed of all the latest software updates and IK products.
Register at: www.ikmultimedia.com/registration
3
English
Installation and setup
1.Install the two AAA batteries into iRig BlueTurn’s battery compartment. It is very important to follow the polarity indicators for the batteries that are indicated on the internal part of the battery compartment. iRig BlueTurn works with Bluetooth LE technology. This allows for extra-low current consumption and very long battery life.
2.Power ON the iRig BlueTurn : Push and hold one of the two foot switches plus the ON switch on iRig BlueTurn (for the complete startup procedure, please refer to the “iRig BlueTurn modes” section in this manual).
|
HOLD |
|
ON |
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4
