IK Multimedia iRig 2 User guide

Guitar interface
USER MANUAL

Contents

Table of Contents
Contents 2
English 3
iRig 2 3 Register your iRig 2 3 iRig 2 Overview 4 Installation and setup 5 Using iRig 2 with mixers, speakers or amplifiers 9 Amplifier output jack 9
THRU-FX switch 10
Setting input level 11 Stand adapter 11 Specifications 12 Warranty 12 Support and more info 12
2

English

iRig 2

Thank you for purchasing iRig 2.
Your package contains:
• iRig 2
• Slot for velcro strip
• Velcro strip
• Quick start guide
• Registration card
1x
1x
1x
iRig 2 is the new and improved version of the groundbreaking and best selling iRig guitar interface. Featuring the powerful sound and streamlined convenience you loved about iRig, it packs essential new features like versatile gain control, a 1/4” amplifier output and Android compatibility into its sleek pocketable enclosure. Its new 1/4” output jack lets you use iRig 2 with an amplifier as a part of your live rig without the use of an adaptor. iRig 2 features a switch that lets you select between a processed signal and a clean “thru” input signal. This means you can also use your mobile device as a tuner, recorder or other tool while preserving the purity of a 100% analog signal path.

Register your iRig 2

By registering, you can access technical support, activate your warranty and receive free JamPoints™ which will be added to your account. JamPoints™ allow you to obtain discounts on future IK purchases! Registering also keeps you informed of all the latest software updates and IK products.
Register at: www.ikmultimedia.com/registration
3
English

iRig 2 Overview

6
5
4 3
1. Captive 1/8” TRRS cable
2
1
2. 1/4” TS amplifier output
3. THRU-FX switch
4. Input level control
5. 1/8” stereo headphone out
6. 1/4” TS instrument input
4
English

Installation and setup

1. Plug your iRig 2 into your device.
1/8"
2. Plug your headphones or earbuds into iRig 2.
1/8"
5
