Iiyama TF4338MSC-B1AG Product Data Sheet

43" 12pt open frame touch monitor with edge-to-edge glass

The ProLite TF4338MSC-B1AG is the ideal solution for education, interactive Digital Signage, Instore Retail, Kiosks and
table top Gaming. With 1920x1080 Full HD resolution and Projective Capacitive 12 point touch technology, the ProLite
TF4338MSC-B1AG delivers seamless and accurate touch response. Featuring an IPS LED panel, it offers exceptional colour
performance, high contrast and wide viewing angles. The screen comes with a rugged bezel and the panel withstands the
60950-1 ball drop test, making it suitable for demanding environments like table top integration.

PROLITE TF4338MSC-B1AG (PRELIMINARY SPECIFICATIONS)

Touch technology - Capacitive

This technology uses a sensor-grid of micro-fine wires
integrated into the glass that covers the screen. Touch
is detected because electrical characteristics of the
sensor grid change when human finger is placed on the
glass. Thanks to the glass overlay this technology is
highly durable, and the touch function remains
unaffected even if the glass is scratched. It offers
perfect picture performance and will work with human
finger (also latex gloved) and stylus-pen.

Open frame LFD

Open frame monitors are an ideal solution for kiosk
integrators and Instore Retail.

13.02.2018 10:20:02

Panel IPS LED, AG coated glass

Native resolution 1920 x 1080 (Full HD megapixel)

Aspect ratio 16:9

Brightness 450 cd/m² typical

Static contrast 1100:1 typical

Advanced contrast 0M:1

Response time 12ms

Colour support 16.7mln (6bit + A-FRC)

Bezel colour and finish black, glossy

Touch technology projective capacitive

Touch points 12 (multitouch (12 compatible touch points - HID, only with supported OS),

activated by finger)

Touch method finger

Touch interface USB, RS232

Supported operating systems All iiyama monitors are Plug & Play and compatible with Windows and Linux. For

details regarding the supported OS for the touch models, please refer to the driver
instruction file available in the downloads section.

Analog signal input VGA (x1)

Digital signal input DVI (x1), HDMI (x1), DisplayPort (x1)

Audio input Mini jack (x1)

Audio output Mini jack (x1), Speakers (2 x 8W)

HDCP yes

USB HUB x0

Extra Open Frame

Max. non-stop operating time 24/7

Glass thickness 4mm

60950 Ball drop test yes

Housing (bezel) metal

OSD languages EN, DE, FR, ES, IT, PT, CN, RU, JP, CZ, NL, PL

Control buttons Power, Scroll up/ Volume+, Scroll down/ Volume-, Auto/Exit, Input Select/OK, Menu

Plug&Play DDC2B, Mac OSX

Orientation landscape, portrait, face-up

DISPLAY CHARACTERISTICS01

TOUCH02

INTERFACES / CONNECTORS / CONTROLS03

FEATURES04

GENERAL05

MECHANICAL06

ACCESSORIES INCLUDED07
