27" 10 point touch monitor with edge to edge glass and AMVA panel
PROLITE T2736MSC-B1
PRELIMINARY
Touch technology - Capacitive
This technology uses a sensor-grid of micro-fine wires
integrated into the glass that covers the screen. Touch
is detected because electrical characteristics of the
sensor grid change when human finger is placed on the
glass. Thanks to the glass overlay this technology is
highly durable, and the touch function remains
unaffected even if the glass is scratched. It offers
perfect picture performance and will work with human
finger (also latex gloved) and stylus-pen.
Scratch resistance
Scratch resistance is essential for touch solutions used
in public places and schools. This is achieved thanks to
a glass overlay covering the screen. It guarantees high
durability of the touch function and even more
importantly the touch function remains unaffected
even if the glass is scratched.
29.03.2018 07:35:03
Design Edge to edge glass
Diagonal 27"
Panel AMVA LED
Native resolution 1920 x 1080 @60Hz (2.1 megapixel Full HD)
Aspect ratio 16:9
Brightness 300 cd/m² typical
Brightness 270 cd/m² with touch
Static contrast 3000:1 typical
Viewing zone horizontal/vertical: horizontal°/vertical 178°, right/left: 0°/0°, up/down: 0°/0°
Bezel colour and finish black, matte
Touch technology projective capacitive
Touch points 10 (HID, only with supported OS)
Touch method stylus, finger, glove (latex)
Touch interface USB
Supported operating systems All iiyama monitors are Plug & Play and compatible with Windows and Linux. For
details regarding the supported OS for the touch models, please refer to the driver
instruction file available in the downloads section.
Analog signal input VGA xx1
Digital signal input HDMI xx1
DisplayPort xx1
Audio output Speakers 2 x 2W
HDCP yes
USB HUB xx2
60950 Ball drop test yes
Impact testing IPIPX1 (front)
OSD key lock yes
OSD languages EN, DE, FR, IT, RU, PL, NL
Plug&Play DDC2B
VESA mounting 100 x 100mm
Cables power (1.8m), VGA (1.8m), USB (1.8m), HDMI (1.8m)
Guides quick start guide, safety guide
DISPLAY CHARACTERISTICS01
TOUCH02
INTERFACES / CONNECTORS / CONTROLS03
FEATURES04
GENERAL05
MECHANICAL06
ACCESSORIES INCLUDED07
29.03.2018 07:35:03
Power supply unit internal
Power supply AC AC - 100V, 240/V, 50Hz
Power usage 0.5W stand by
Regulations CE, TÜV-Bauart, PSE, VCCI, TÜV-GS, CB, EAC, Energy Star , ErP, WEEE, REACH
All trademarks and registered trademarks acknowledged. E & O E. Specification subject to change without notice. All LCD's comply with ISO-9241307:2008 in connection with pixel defects.
© IIYAMA CORPORATION. ALL RIGHTS RESERVED
POWER MANAGEMENT08
SUSTAINABILITY09
