iiyama T2735MSC-B1 User Manual

PROLITE T2735MSC-B1

TOUCH TECHNOLOGY - CAPACITIVE

This technology uses a sensor-grid of micro-fine wires
integrated into the glass that covers the screen. Touch is
detected because electrical characteristics of the sensor grid
change when human finger is placed on the glass. Thanks to
the glass overlay this technology is highly durable, and the
touch function remains unaffected even if the glass is
scratched. It offers perfect picture performance and will work
with human finger (gloved or not) and magnetic ball.

AMVA+

AMVA+ Panel technology offers 24 bit ‘True Colour’
performance and amazing viewing angles.

27" 10 point multi-touch monitor with Edge to Edge glass and webcam
With 1920x1080 Full HD resolution and Projective Capacitive 10 point touch technology, the ProLite T2735MSC delivers seamless
and accurate touch response. Featuring AMVA+ LED-backlit LCD screen technology, it offers exceptional colour performance and
wide viewing angles, making it an excellent choice for a vast array of demanding interactive applications. Users can benefit from
its hinged stand allowing the monitor to lay down completely flat for use as a giant tablet. The T2735MSC comes equipped with
several video inputs and a USB 3.0 HUB as well as stereo speakers delivering good quality sound. An ideal screen for Interactive
Digital Signage, InStore Retail, Gaming and Interactive Presentations purposes.

1. DISPLAY CHARACTERISTICS

DIAGONAL 27"; 68.6cm

TOUCHTECHNOLOGY

projective capacitive, multitouch (10 compatible touch points - HID, only with supported OS), activated
by finger

PANEL AMVA+ LED-backlit

GLASS HARDNESS 7H minimum

DISPLAY AREA H X W 336.15 x 597.6 mm; 13.2" x 23.5"

RESPONSE TIME 5 ms

CONTRAST 5 000 000 : 1 ACR

CONTRAST 3 000 : 1 with touch panel

BRIGHTNESS 260 cd/m² with touch panel

VIEWING ZONE horizontal/vertical: 178°/ 178°; right/left: 89°/ 89°; up/down: 89°/ 89°

DISPLAY COLOUR 16.7 million

PIXEL PITCH H X V 0.311 x 0.311 mm

NATIVE RESOLUTION Full HD 1080p, 1920 x 1080 ( 2.1 megapixel)

HORIZONTAL SYNC 24 - 80 KHz

VERTICAL SYNC 55 - 75 Hz

SYNCHRONIZATION Separate Sync

ASPECT RATIO 16 : 9

LIGHT TRANSMITTANCE 87%

2. INTERFACES & CONNECTORS

ANALOG INPUT CONNECTOR VGA

DIGITAL INPUT CONNECTOR DVI-D, HDMI (MHL)

HEADPHONE CONNECTOR Yes

INPUTS USB (for touch connectivity), USB 3.0

USB HUB UP 1 x USB 3.0 / DOWN 2 x USB 3.0

3. SPECIAL FEATURES

PLUG & PLAY VESA DDC2B™

CONTROLS

On-Screen-Display in 9 languages (EN, FR, DE, NL, PL, RU, JP, Chinese - traditional and simplified)
and 5 front controls (Power, Select/ Input select, Scroll up/ Audio Adjust, Scroll down/ i-Style Colour,
Menu)

SPEAKERS 2 x 2 W (Stereo)

ANTI-THEFT-DEVICE Kensington-lock™ prepared

SAFETY CE, TÜV-Bauart, VCCI-B, PSE, CU

TILT ANGLE 15-70° up; ° down

VESA MOUNTING 100 x 100 mm
