Page 1

user manual

Page 2

You have made an excellent choice with your

iConnect

™

media keyboard & wireless laser mouse

for Mac

This product comes with a limited one-year warranty. Before using, please read and follow these instructions. If you still need help, see the back page for other support options.

For more about our products, visit www.life-works.com.

Model IH-K236LS

system requirements

Mac OS X v10.5.x or later•

USB port•

CD-ROM drive•

contents

features 3 get started 3 your new keyboard 4 your new mouse 5 install software 6 dock your iPod or iPhone 9 using your keyboard 10 using your mouse 12 product operating tips 13 troubleshooting 14

Page 3

features

keyboard

charge-n-sync iPod•

or iPhone

with iTunes

illuminated touch-sensitive media keys•

2 rotating USB 2.0 ports•

rubberized wrist rest•

mouse

plug-n-play, no syncing needed•

2.4 GHz up to 30 fteet•

mouse low battery indicator•

horizontal & vertical scrolling•

stowable nano USB receiver•

get started

If you have not done so already, follow the steps in the get started guide to connect your new hardware.

Page 4

your new keyboard

iPod or iPhone dock cover

play/ pause

numeric keypad

Mac application launch keys

illuminated touch-sensitive

media keys

USB 2.0 ports

USB connector

power connector

rubberized wrist rest

Page 5

battery indicator light

laser sensor

power on/off switch

top view bottom view

scroll wheel (horizontal and vertical)

your new mouse

Please see your get started guide for instructions on how to connect your new hardware to your computer.

USB ports on keyboard rotate for easier use

Page 6

install software

If you have not already installed the keyboard driver software (as described in get started), you will need to do so to take advantage of all features available with your new keyboard.

insert installation CD

double-click iHome Keyboard icon 2.

The installation software will open.

when Welcome screen displays, click

3. Continue

Page 7

click 4. Install to install driver in default location type your password if asked to do so5.

when prompted, click 6. Continue Installation

Page 8

Click 7. Continue again

Click 8. Restart to restart your computer

Page 9

dock your iPod or iPhone

Keyboard must be connected to AC WARNINGf

adapter at all times when in use.

Your keyboard is designed to sync and charge your iPod or iPhone when docked.

gently slide the dock cover forward

insert your iPod or iPhone

For a snug t, use one of the three inserts before docking your iPod or iPhone.

See the table on next page for which insert to use. (Look for the number on the back of the insert.)

Page 10

device use insert

iPod nano (1

, 2nd, 3rd and 4th

generation)

iPod classic (80GB, 120GB)

iPod 5G (30 GB)

iPod touch, 1

and 2nd generation

(8GB, 16GB, 32GB)

iPhone 3G

iPod classic (160GB)

iPod 5G (60GB, 80GB)

using your keyboard

adjust the volume from the keyboard

Slide nger across volume control to adjust volume— left to lower, right to increase.

To go from minimum to maximum volume or notef back again, swipe four times.

Page 11

Mac application launch keys

function key function

decrease brightness

increase brightness

Exposé

F4 Dashboard

sleep

function key function

iTunes

Mail

iChat

F10 Safari

F11 iCal

F12 Front Row

Page 12

media keys

media key function

shufe

repeat

previous (hold for rewind)

next (hold for fast forward)

mute

eject iPod or iPhone

using your mouse

horizontal and vertical scroll

Roll the wheel up and down to scroll vertically.

Tilt the wheel left or right to scroll horizontally.

Page 13

product operating tips

WARNING:• Always connect the supplied AC

adapter when using the keyboard.

Use one of the included inserts to make your iPod/• iPhone t securely in the dock. (See “dock your iPod or iPhone” on page 9.)

Your mouse will operate from as far away as • 30 ft. (10 m) from your computer.

To save battery power, turn off the mouse when • not in use.

Store the nano USB receiver under the battery • cover for travel or when not in use.

Page 14

troubleshooting

situation try this

iPod/iPhone

does not

charge or

sync

Ensure AC adapter is connected.• Ensure USB cable is connected.• Ensure device is seated correctly.• Ensure iTunes is open.•

keyboard

or USB 2.0

ports do not

work

Ensure USB cable is connected.• Connect your keyboard to a port •

on the computer, not to a USB hub. Ensure AC adapter is connected.•

Mac

application

keys do not

launch

Reinstall the driver (see • “install software” on page 6).

Ensure your program is in the • application folder.

situation try this

mouse does

not work

Ensure the nano USB receiver is • connected.

Connect the nano USB receiver to • a different USB port.

Check that the battery is inserted • correctly.

Move the mouse closer to the nano • USB receiver.

Ensure the laser sensor on the • bottom of the mouse is clean.

Install a fresh battery.•

mouse low

battery

indicator (red

light) ashing

Install a fresh battery.•

Page 15

FCC Statement

This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction guide, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.• Increase the separation between the equipment and the receiver.• Connect the equipment into an outlet on a circuit different from that to which •

the receiver is connected. Consult a service representative for help.•

Properly shielded and grounded cables and connectors must be used in order to comply with FCC emission limits. LifeWorks is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modications to this equipment. Unauthorized changes or modications could void the user’s authority to operate the equipment.

Responsible party: LifeWorks Technology Group LLC 1412 Broadway, New York, NY 10018

Tested To Comply With FCC Standards FOR HOME OR OFFICE USE

Warning Improper setup, use and care of this product can increase the risk

of serious injury, death or device damage. Read and keep this guide and all other printed guides for future reference. For updated guides or replacements, go to www.life-works.com

Do Not Attempt Repairs Do not attempt to take apart, open, repair, service

or modify the device(s). Doing so may risk electric shock or other hazard. Evidence of any attempt to open or modify the device, including any peeling, puncture or removal of labels, will void the Limited Lifetime Warranty.

Choking Hazard This product contains small parts that may pose a choking

hazard to children and pets.

Keyboard and Mouse Devices: Health Warning

Use of a keyboard or mouse may be linked to serious injuries or disorders. As in many activities, when using a computer you may experience occasional discomfort in various parts of your body. However, do not ignore symptoms such as persistent or recurring discomfort, pain, throbbing, aching, tingling, numbness, burning sensation or stiffness. Promptly see a qualied doctor, even if symptoms occur when you are not working at your computer.

There is general consensus among researchers that there may be many factors linked to the occurrence of these symptoms, including overall health, stress, physical condition and how a person positions and uses his or her body during work and other activities (including the use of a keyboard or mouse). The amount of time a person spends performing an activity may also be a factor. If you have questions about how your own lifestyle, activities or physical condition may be related to these symptoms, see a qualied health professional.

Battery-Powered Devices

Use of rechargeable or disposable batteries in an improper manner may result in battery uid leakage, overheating or explosion. Battery uid is corrosive, may be toxic, can cause skin and eye burns, and is harmful if swallowed.

Radio Frequency Technical Specications: 2.4 GHz Devices

Non-specic short range device. RF output power meets all SRD requirements.

Page 16

technical support

for technical support please visit www.life-works.com or call (877) LIFE-540 (877-543-3540)

one-year warranty

for warranty information, please visit

www.life-works.com/warranty

Wireless Devices

Remove the batteries from any wireless device, or turn it off, before boarding an aircraft or packing the device in luggage that will be checked. Wireless devices can transmit radio frequency (RF) energy whenever batteries are installed and the device is turned on.

AC-Powered Devices

Failure to take the following precautions can result in serious injury or death from electric shock or re, or in damage to the device.

Use only the power supply unit and AC power cord that came with your device • or from an authorized repair center. Conrm that your electrical outlet provides the type of power indicated on the power supply unit in terms of voltage (V) and frequency (Hz). If you are not sure of the type of power supplied to your home, consult a qualied electrician.

Avoid non-standard power sources, such as generators or inverters, even if the • voltage and frequency appear acceptable. Only use AC power provided by a standard wall outlet.

Do not overload your wall outlet, extension cord, power strip or other electrical • receptacle. Conrm that they are rated to handle the total current drawn by the device and any other devices on the same circuit.

Protect the power cords from being walked on. Protect cords from being • pinched or sharply bent, particularly where they connect to the power outlet, the power supply unit and the device. Do not jerk, knot, sharply bend or otherwise abuse the power cords. Do not expose the power cords to heat sources.

Keep children and pets away from the power cords. Do not allow them to bite • or chew on the cords.

When disconnecting the power cords, pull on the plug; do not pull on the cord.•

If a power cord or power supply becomes damaged in any way, stop using it immediately. Unplug your device during lightning storms or when unused for long periods of time.

iHome is a trademark of SDI Technologies Inc. used under license.

iPod and iTunes are trademarks of Apple Inc., registered in the U.S. and other countries. iPhone is a trademark of Apple Inc., registered in the U.S.

All other brands and logos are trademarks of their respective companies.

Printed in China

document version number 0903-0

for model number IH-K236LS
