iHome IP38 User Manual

Model iP38

Portable Stereo Alarm Clock

Speaker Case for your iPod

iPhone

Questions? Visit www.ihomeaudio.com

Table of Contents

iP38 Quick Start

Controls and Indicators

Getting Started with your iP38

Using the iP38

A Consumer Guide to Product Safety

Trouble Shooting

Warranty Information

4-5

Maintenance

• Place the unit on a level surface away from sources of direct sunlight or excessive heat.

• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other protective material should be placed between it and the furniture.

• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents, such as Benzene, thinner or similar materials can damage the surface of the unit.

FCC Information

This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment complies with the limits for a Class B digital device as specified in Part 15 of FCC Rules. These limits provide reasonable protection against radio and TV interference in a residential area.

However, your equipment might cause TV or radio interference even when it is operating properly. To eliminate interference you can try one or more of the following corrective measures:

• Reorient or relocate the receiving antenna.

• Increase the distance between the equipment and the radio or TV.

• Use outlets on different electrical circuits for the equipment and the radio or TV.

• Consult your dealer or an experienced radio/television technician if the problem still exists.

Modifying or tampering with your system’s internal components can cause a malfunction and might invalidate the system’s warranty and void your FCC authorization to operate it.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Battery Information

For Models Requiring More Than One Battery

• Do not mix with used or other battery types/brands

• Replace all cells at the same time

• Do not open batteries

• Do not dispose of in fire

• Do not heat above 75ºC (167ºF)

• Do not expose contents to water

• Do not charge or recharge

• Do not install backwards

iP38 Quick Start

1:batteries

Open battery compartment located inside unit. Insert 5 “AA” batteries (not included) as indicated on diagram. Unit can now play iPod/iPhone. Batteries will not charge iPod/iPhone.

Use this insert

For this

iPhone/iPod

www.ihomeaudio.com or call iHome toll free at 800-288-2792 to purchase one

NOTE: If you do not have an insert for your iPod, please visit

iPhone 3G

insert 15

iPhone 3G/3GS

3:inserts

2:AC adaptor

RESET

TEST

Connect AC adaptor to the DC jack (left side of iP38) and plug the other end into a working wall socket to charge and play iPod/iPhone. Does not charge batteries.

iPod touch 2G

insert 16

iPod touch 2G

iPod nano 5G

insert 18

iPod nano 5G

4:iPod/iPhone

Select the dock insert for your iPod/iPhone model from the table above and place insert in dock.

Never dock an iPod/iPhone without an insert in place.

Gently place iPod/iPhone on the connector plug in dock. Press Power Button to ON. Unit and iPod/iPhone will turn on. Adjust volume by pressing the

+ or – Button.
