iHome IP28 User Manual

Model iP28

The Portable Speaker System

For Your iPhone & iPod

hour



res

nute

sleep

ooze

immer

EXB

clo

Questions? Visit www.ihomeaudio.com

Table of Contents

Quick Start.................................................................................................................................................................... 2

Controls and Indicators / iP28 Display Setting Up the iP

Connect iP28 to Power Source, Installing/Replacing Backup Battery, Installing /Replacing Batteries for Portable Use

Setting the Clock, Using the Alarm ........................................................................................................................... 5

Listening and Charging iPod/iPhone, Using Sleep Mode & Dimme ..................................................................... 6

Using the Line-in Jack, Using the Travel Lock ......................................................................................................... 7

A Consumer Guide to Product Safety Troubleshooting Warranty Information

28...................................................................................................................................................... 4

.................................................................................................................................................... 9-10

.............................................................................................................................................. 11

..................................................................................................................... 3

....................................................................................................................... 8

Maintenance

• Place the unit on a level surface away from sources of direct sunlight or excessive heat.

• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other protective material should be placed between it and the furniture.

• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents, such as Benzene, thinner or similar materials can damage the surface of the unit.

FCC Information

This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment complies with the limits for a Class B digital device as specified in Part 15 of FCC Rules. These limits provide reasonable protection against radio and TV interference in a residential area.

However, your equipment might cause TV or radio interference even when it is operating properly. To eliminate interference you can try one or more of the following corrective measures:

• Reorient or relocate the receiving antenna.

• Increase the distance between the equipment and the radio or TV.

• Use outlets on different electrical circuits for the equipment and the radio or TV.

• Consult your dealer or an experienced radio/television technician if the problem still exists.

Modifying or tampering with your system’s internal components can cause a malfunction and might invalidate the system’s warranty and void your FCC authorization to operate it.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

iP28 Quick start

line in

DC 7.5V

lock

/o

RESET

TEST



| r

set

min

s lee

l a

r m

s n

z e

i mm

1: AC power

Attach AC adaptor cable to jack on back of the iP28 and plug the other end into a wall socket to play and charge iPhone/iPod.

Use this insert

For this iPhone/iPod

4: iPhone/iPod

2: batteries

3: inserts

Select the dock insert for your

For portable operation, open battery compartment on the bottom of the unit. Insert 4 “AA” (LR6) batteries as indicated.

iPhone 3G

insert 15

iPhone 3G/3GS

NOTE: If you do not have an insert for your iPhone/iPod, please visit www.ihomeaudio.com or call iHome toll free at 800-288-2892 to purchase one.

iPhone or iPod model from the table below and place insert in dock. Never dock an

iPhone/iPod without the proper insert in place.

touch 2G

insert 16

iPod touch 2G

nano 5G insert 18

nano 5G

Insert an iPhone or iPod into the dock (iPhone/IPod must not be in a “skin” or case). iPhone/iPod will charge while docked. Press the Button on the iP28 to play your iPhone/iPod.

THIS UNIT HAS A BATTERY SAVING FEATURE WHICH LOWERS THE SOUND OUTPUT. FOR MAXIMUM SOUND OUTPUT, CONNECT TO AC ADAPTOR.

Sleep

Button

Controls and Indicators

Universal Dock

EXB Button

Clock Set Button

Minute Set Button

Hour Set Button

Alarm Reset/

Power Off Button

Main Battery Low Indicator

minute sleep alarmclockEXBhour

iPod Play/Pause Power ON Button

DST Indicator

Alarm Armed

DST Switch

Back of Unit

line in

Line in Jack

iP28 Display

PM Indicator

snooze | dimmer

Snooze/Dimmer Button

/o

lock

DC Jack

Travel Lock/Off Button

Time/Alarm Display

DC 7.5V

Alarm On-Off /Set Button

Volume Up Button

Volume Down Button

EXB Indicator

iPod Indicator

Clock Backup Battery Low Indicator

Travel Lock Indicator

Sleep Indicator
