Model: ICE102-WHITE

Questions:1-800-968-9853

English

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed, including the following:

1.Read all instructions carefully.

2.DANGER! To protect against risk of electric shock, do not immerse cord, plug or any parts of the unit in water or other liquids.

3.Close supervision is necessary when using this appliance near children. This appliance is not suitable for use by children.

4.Never leave an appliance unattended while in use.

5.Do not place an appliance on or near a hot gas or electric burner, or in a heated oven. Do not place on top of any other appliance.

6.Do not let the power cord of an appliance hang over the edge of a table or countertop or touch any hot surface.

7.Do not operate any electrical appliance with a damaged cord or plug or after the appliance malfunctions or has been dropped or damaged in any manner. If damage is suspected, contact the

nearest authorized service centre for examination, repair or electrical or mechanical adjustment.

8.Unplug from power outlet when not in use, before putting on or taking off attachments, and before cleaning.

9.The use of accessory attachments that are not recommended by the appliance manufacturer may cause fire, electric shock or injury.

10.Avoid contact with moving parts when the unit is in operation.

11.Never touch the cooling elements when the unit is in operation.

12.Do not use outdoors.

13.Do not use appliance for other than its intended use.

SAVE THESE INSTRUCTIONS HOUSEHOLD USE ONLY

1

English

UNPACKING YOUR ICE MAKER

1.Inspect and remove all packing materials. This includes the foam and any adhesive tape both inside and outside of the unit.

2.Inspect and remove any remains of packing, tape, or printed materials before powering on your IGLOO appliance.

WARNING

Please read this manual carefully before using.

Retain it for your future reference.

PRODUCT REGISTRATION

Keep for your records to obtain Warranty Service

Thank you for purchasing this quality IGLOO product.This easy-to-use manual will guide you in getting the best use out of your appliance.

Remember to record the model and serial number. They are on a label in back of the appliance.

__________________________

Model number

__________________________

Ice maker serial number

__________________________

Date of purchase

Staple your receipt to your manual.

You will need it to obtain warranty service.

2

English

SAFETY INSTRUCTIONS

Electrical Requirements

Wiring and Grounding Instructions

This appliance must be plugged into at least a 15 AMP 110-115 VOLT 60 Hz GROUNDED OUTLET. This appliance must be grounded. It is equipped with a 3- wire cord having a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.

WARNING! Improper use of grounded wire can result in the risk of electric shock. Consult a electrician if necessary. Do not attempt to defeat this safety feature by modifying the plug.

Avoid the use of an extension cord because it may overheat and cause a risk of fire. However, if it is necessary to use an extension cord:

A.Use only 3-wire extension cords with a 3-blade grounding plug.

B.The marked rating of an extension cord must be be equal to or greater than the rating of this appliance.

C.It should be positioned such that it does not drape over the counter or tabletop where it can be pulled on by children intentionally.

Attempting any maintenance or cleaning:

To minimize the possibility of electric shock, unplug this appliance from the power supply or disconnect at the household distribution panel by removing the fuse or switching off the circuit breaker before attempting any maintenance or cleaning.

NOTE: Disconnect power plug from the power outlet before maintenance or cleaning

3

English

TABLE OF CONTENTS



Important Safeguards ............................................................

1-2

Safety Instructions ......................................................................

3

Parts and Accessories.............................................................

5-6

Operating Instructions................................................................

7

Pre-Operating Instructions .................................................................

7

Operating Instructions.......................................................................

8

Operating Process............................................................................

9

Cleaning and Maintenance......................................................

10

Troubleshooting Guide.............................................................

11

Warranty ...................................................................................

12

Specifications

Model # ICE102-WHITE

Electrical Shock Protection

Class 1

Power

115V/60Hz 2.7 A

Ice Making Current

1.9 Amp

Ice Harvest Current

2.7Amp

Refrigerant

R134a/2.3 Oz.

Design Pressure







High Side

290 Psig

Low Side

88 Psig

Dimensions

11.7" x 14.5" x 14.9"

Weight

26.4 lbs (12 kg).

Enclosure

ABS plastic

4

English

PARTS, FUNCTIONS AND FEATURES

1

3

2

4 6

5

7

8

1.Cover with transparent window

2.Ice maker and pusher

3.Water reservoir (Not shown)

4.Control panel

5.Water drain cap: for draining water from ice water

6.Compressor cooling fan (Do not block air flow)

7.Ice shovel

8.Ice basket

5

English

Control Panel: Easy to use, button function with LED indicators

A.Power ON LED indicator light

B.Power ON/OFF button

C.Ice cube SELECT SIZE button

D.Selected ice size LED light indicator displaying: SMALL, MEDIUM, and LARGE ice cubes to make

E."ADD WATER" (Alerts that there is no water in the water reservoir), must add water

F."ICE FULL" LED indicator

D

C

E

F

B A

Water Drain: Do not lose any parts. (Failure to put rubber plug back will cause water to leak.)

A. Drain cap

B. Rubber plug C. Drain spout

a b c

Drain water to store or when appliance will not be used for long periods

6

English

OPERATING INSTRUCTIONS

This portable ice maker uses a fully automatic control system, with an advanced microcomputer for easy and convenient ice making. Making ice is simple and fast. Just add water, plug into an outlet, and press the ON button. You can select one of the three ice cube sizes with the touch of a button. When first turning on the unit or during icemaking cycles, the compressor will stay idle for 3 minutes, while energizing.

There are warning indicators that alert you to fill water when the reservoir is empty and to remove ice when the storage basket is full. The ice maker also has built-in safeguards that can limit accidental damage, automatically shutting down the system when necessary.

Pre-Operating Instructions

Please read carefully.

1.The tilted angle of the ice maker cabinet should not exceed 45˚ during transportation or use. Do not turn the appliance upside down.

Doing so could cause the compressor or refrigerating system to operate incorrectly. When the ice maker is moved or transported, please allow time for the fluids in the compressor to settle. Before using the ice maker for the first time, please wait 2 hours after the unit has been leveled and positioned in its proper place before plugging it in and turning it on.

2.Please ensure the ice maker is level and on a stable table or platform to avoid malfunction.

3.The machine must be placed on a dry and level surface with sufficient ventilation, far from heat sources such as ovens, heaters and corrosive gases. Leave an 8" (20 cm) clearance on all sides of the ice maker for proper ventilation.

4.Do not fill the water reservoir with hot water. This may damage the ice maker. It is best to fill the water reservoir with water of room temperature or lower.

7
