IEI Integration RPC-6010G User Manual

RPC-6010G Rackmount LCD Workstation
Page i
RPC-6010G Rackmount LCD Workstation
Revision
MODEL RPC6010G Rackmount Workstation
Revision Number Description Date of Issue
1.0 Initial release December 2006
RPC-6010G Rackmount LCD Workstation
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
Copyright
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
IBM PC is a registered trademark of International Business Machines Corporation. INTEL
is a registered trademark of INTEL Corporation. Other product names mentioned herein
are used for identification purposes only and may be trademarks and/or registered
trademarks of their respective owners.
Page iii
RPC-6010G Rackmount LCD Workstation
Packing List
NOTE:
If any of the components listed in the checklist below are missing, please do not
proceed with the installation. Contact the IEI reseller or vendor you purchased the
RPC-6010G rackmount workstation from or contact an IEI sales representative directly.
To contact an IEI sales representative, please send an email to sales@iei.com.tw
The items listed below should all be included in the RPC-6010G Rackmount Workstation
package.
1 x RPC-6010G Rackmount LCD Workstation
1 x Backplane to SBC connector cable
2 x Door keys
2 x Handles
2 x Handle brackets
1 x Mini-DIN 6 PS/2 connector cable
1 x Power cable (EU)
1 x Screw kit
7 x Short card clamps
2 x 4-pin USB cable
1 x VGA cable
.
Page iv
For Touch Panel (T-R) Models only:
1 x RS-232 cable
1 x TouchKit Driver CD
1 x Touch Pen
Images of the above items are shown in Section 4.2.3.
RPC-6010G Rackmount LCD Workstation
Table of Contents
1 INTRODUCTION..................................................................................................... 1
1.1 RPC-6010G O
1.2 RPC-6010G FEATURES.............................................................................................. 2
1.3 MODEL VARIATIONS................................................................................................... 2
1.4 CERTIFICATIONS ......................................................................................................... 3
2 MECHANICAL OVERVIEW................................................................................. 5
2.1 EXTERNAL OVERVIEW ............................................................................................... 6
2.1.1 Front Panel ........................................................................................................ 6
2.1.2 Rear Panel ......................................................................................................... 7
2.1.2.1 14-Slot Rear Panel ...................................................................................... 7
2.1.2.2 ATX Motherboard Rear Panel..................................................................... 8
2.1.3 Right Side Panel................................................................................................. 9
2.1.4 Left Side Panel ................................................................................................. 10
2.2 PHYSICAL DIMENSIONS............................................................................................ 10
2.2.1 General Physical Dimensions.......................................................................... 10
2.2.2 RPC-6010G Physical Dimensions ....................................................................11
3 DETAILED SPECIFICATIONS ........................................................................... 13
VERVIEW............................................................................................. 2
3.1 RPC-6010G S
3.2 LCD SPECIFICATIONS .............................................................................................. 15
3.3 ACE-832AP PSU S
3.4 RECOMMENDED IEI BACKPLANES, MOTHERBOARDS AND PSUS ............................. 16
4 INSTALLATION .................................................................................................... 17
4.1 INSTALLATION CONSIDERATIONS ............................................................................. 18
4.1.1 Installation Precautions................................................................................... 18
4.1.2 Installation Prerequisites ................................................................................. 18
4.2 UNPACKING.............................................................................................................. 19
4.2.1 Packaging ........................................................................................................ 19
4.2.2 Unpacking Procedure ...................................................................................... 19
PECIFICATIONS .................................................................................. 14
PECIFICATIONS.......................................................................... 16
Page v
4.2.3 Packing List ..................................................................................................... 20
4.3 PRE-INSTALLATION PREPARATION ............................................................................ 22
4.3.1 System Planning............................................................................................... 22
4.3.2 Tools ................................................................................................................. 22
4.4 INSTALLATION PROCEDURES .................................................................................... 23
4.4.1 Preinstalled Components ................................................................................. 23
4.4.2 User Installed Components.............................................................................. 23
4.4.3 Installation Steps.............................................................................................. 23
4.5 INSTALLING COMPONENTS INTO THE RPC-6010G ................................................... 24
4.5.1 Remove the Top Cover ..................................................................................... 25
4.5.2 Remove the CPU Card Clamp ......................................................................... 26
4.5.3 Remove the Dual CPU Card Clamp & Drive Bay Stabilizer Bracket ............. 26
4.5.4 Remove the Drive Bracket ............................................................................... 28
4.5.5 Remove the Drive Slot Blank Plate.................................................................. 28
RPC-6010G Rackmount LCD Workstation
4.5.6 Install Drives.................................................................................................... 29
4.5.6.1 5.25” Disk Drive ....................................................................................... 29
4.5.6.2 3.5” Disk Drive in a 5.25” Slot ................................................................. 30
4.5.6.3 3.5” Disk Drive ......................................................................................... 31
4.5.7 Reinstall the Drive Bracket.............................................................................. 32
4.5.8 Install the Backplane........................................................................................ 33
4.5.9 Install the CPU Card ....................................................................................... 35
4.5.10 Install the PCI/ISA Expansion Card .............................................................. 37
4.5.11 Installing Short Cards .................................................................................... 38
4.5.12 Connect the Cables ........................................................................................ 39
4.5.13 Close the Top Cover ....................................................................................... 40
4.6 MOUNTING THE RPC-6010G RACKMOUNT WORKSTATION ..................................... 40
5 MAINTENANCE.................................................................................................... 47
5.1 MAINTENANCE OVERVIEW....................................................................................... 48
5.2 CPU CARD REPLACEMENT ...................................................................................... 48
5.3 PCI/ISA EXPANSION CARD REPLACEMENT ............................................................. 49
5.4 BACKPLANE REPLACEMENT..................................................................................... 50
5.5 PSU REPLACEMENT................................................................................................. 51
5.6 COOLING FAN REPLACEMENT .................................................................................. 54
5.7 DISK DRIVE REPLACEMENT ..................................................................................... 57
Page vi
RPC-6010G Rackmount LCD Workstation
5.7.1 3.5” Disk Drive Replacement .......................................................................... 57
5.7.2 5.25” Disk Drive Replacement ........................................................................ 58
6 ON SCREEN DISPLAY (OSD) CONTROLS...................................................... 59
6.1 USER MODE OSD STRUCTURE ................................................................................ 60
6.1.1 OSD Buttons..................................................................................................... 60
6.1.2 OSD Menu Structure ........................................................................................ 61
6.2 USING THE OSD....................................................................................................... 62
6.2.1 Main Display Features..................................................................................... 62
6.2.2 Color ................................................................................................................ 64
6.2.3 Language.......................................................................................................... 65
6.2.4 OSD Configurations......................................................................................... 66
6.2.5 Signal ............................................................................................................... 67
6.2.6 Backlight .......................................................................................................... 68
7 SOFTWARE DRIVER ........................................................................................... 69
7.1 T
OUCH SCREEN DRIVER........................................................................................... 70
7.2 DRIVER INSTALLATION............................................................................................. 71
7.3 TOUCH SCREEN DRIVER CONFIGURATION................................................................ 79
A CERTIFICATIONS ................................................................................................ 81
A.1 ROHS COMPLIANT.................................................................................................. 82
B RECOMMENDED IEI BACKPLANES, MOTHERBOARDS AND PSUS ..... 83
RECOMMENDED IEI BACKPLANES AND MOTHERBOARDS ....................................... 84
B.1
B.2 RECOMMENDED IEI POWER SUPPLY UNITS............................................................. 85
INDEX.............................................................................................................................. 87
Page vii
RPC-6010G Rackmount LCD Workstation
List of Figures
Figure 2-1: RPC-6010G Front Panel ............................................................................6
Figure 2-2: RPC-6010G Front Panel Door Open.........................................................7
Figure 2-3: RPC-6010G 14 Slot Rear Panel.................................................................8
Figure 2-4: RPC-6010G ATX Motherboard Rear Panel ..............................................9
Figure 2-5: RPC-6010G Right Side Panel....................................................................9
Figure 2-6: RPC-6010G Left Side Panel ....................................................................10
Figure 2-7: RPC-6010G Physical Dimensions ..........................................................11
Figure 4-1: Top Cover Left Side Retention Screws .................................................25
Figure 4-2: Remove Top Cover from Chassis ..........................................................25
Figure 4-3: CPU Card Clamp Right Side Retention Screws ..................................26
Figure 4-4: Dual CPU Card Clamp Retention Screws…………………………………27
Figure 4-5: Dual CPU Card Clamp Fan Bracket Retention Screws ........................27
Figure 4-6: Drive Bracket Retention Screws ............................................................28
Figure 4-7: Drive Slot Blank Plate Retention Screws ..............................................29
Figure 4-8: 5.25” Disk Drive Retention Screws ........................................................30
Figure 4-9: 3.5” to 5.25” Drive Bay Rack Retention Screws ...................................31
Figure 4-10: 3.5” Disk Drive Retention Screws ........................................................32
Figure 4-11: Install Copper Pillars and Plastic Spacers..........................................33
Figure 4-12: Backplane Retention Screws ...............................................................34
Figure 4-13: Slot Cover Retention Screw..................................................................36
Figure 4-14: Install the CPU Card ..............................................................................37
Figure 4-15: Installing a Short Card ..........................................................................39
Figure 4-16: Rack Handle Bracket Assembly and Installation ...............................41
Figure 4-17: Remove Rack Slide................................................................................42
Page viii
Figure 4-18: Workstation Slide Installation ..............................................................43
Figure 4-19: Rack Slide Bracket Assembly ..............................................................44
Figure 4-20: Rack Slide Bracket Installation ............................................................45
RPC-6010G Rackmount LCD Workstation
Figure 4-21: Install Workstation into Rack ...............................................................46
Figure 5-1: PSU External Retention Screws.............................................................52
Figure 5-2: PSU Internal Retention Screws ..............................................................52
Figure 5-3: PSU Mounting Bracket Retention Screws.............................................53
Figure 5-4: Cooling Fan Bracket External Screws...................................................55
Figure 5-5: Cooling Fan Bracket Bottom Panel Screws..........................................55
Figure 5-6: Fan Retention Screws .............................................................................56
Figure 6-1: OSD Control Buttons...............................................................................60
Figure 6-2: Main Display Features.............................................................................62
Figure 6-3: Color Options...........................................................................................64
Figure 6-4: Language Menu .......................................................................................65
Figure 6-5: OSD Configurations Menu......................................................................66
Figure 6-6: Signal Menu..............................................................................................67
Figure 6-7: Backlight Menu ........................................................................................68
Figure 7-1: Driver CD Pop Up Screen........................................................................71
Figure 7-2: Install Shield Wizard Preparation...........................................................72
Figure 7-3: Welcome Screen ......................................................................................72
Figure 7-4: Install PS/2 Interface Driver ....................................................................73
Figure 7-5: Install PS/2 Interface Driver ....................................................................74
Figure 7-6: Touch Monitor/USB Touch Controller Confirmation ...........................74
Figure 7-7: Controller Installation Directory.............................................................75
Figure 7-8: Controller Installation Directory.............................................................76
Figure 7-9: Program Icon Directory...........................................................................77
Figure 7-10: Installing .................................................................................................78
Figure 7-11: Installation Complete ............................................................................79
Page ix
RPC-6010G Rackmount LCD Workstation
List of Tables
Table 1-1: RPC-6010G Model Variations.....................................................................3
Table 2-1: General Physical Dimensions..................................................................10
Table 3-1: RPC-6010G Specifications .......................................................................14
Table 3-2: LCD Specifications....................................................................................15
Table 3-3: ACE-832AP PSU Specifications...............................................................16
Table 4-1: Packing List ...............................................................................................21
Table 6-1: OSD Menus ................................................................................................62
Page x
RPC-6010G Rackmount LCD Workstation
Chapter
1

1 Introduction

Page 1
1.1 RPC-6010G Overview
The RPC-6010G is a PC/AT compatible computer designed for industrial applications. It
has a rugged steel chassis specially designed to work under harsh environmental
conditions while also being high reliability. The RPC-6010G supports 14-slot passive
backplanes, ATX motherboards and a full line of dependable AC/DC power supplies. The
RPC-6010G can withstand shock, vibration, dust and a wide range of temperatures in
industrial environments. A lockable door protects drive bays and switches from
unauthorized misuse and dust. The RPC-6010G also has two removable cooling-fans
installed in the front panel for optimum cooling of the system.
1.2 RPC-6010G Features
Some of the features of the RPC-6010G include:
RPC-6010G Rackmount LCD Workstation
8.4” TFT LCD with fully functional OSD and membrane keypads
Flexible driver combination
Lockable front door
USB x2 on the front panel
PICMG 1.3 backplane and Redundant power supply support
Advanced air-flow design
1.3 Model Variations
The RPC-6010G comes in a variety of models. The models have special features as
identified by their model name. The RPC-6010G model variations are listed in Table 1-1.
Model
ACE-832AP-RS (ATX) Power Supply
RPC-6010GW/ACE-832AP No Full-size CPU card 14
Touch
SBC Form Factor
Screen
Expansion
Slots
RPC-6010GW/ACE-832AP/T-R Yes Full-size CPU card 14
RPC-6010GWATX/ACE-832AP No ATX / microATX 7
RPC-6010GWATX/ACE-832AP/T-R Yes ATX / microATX 7
Page 2
RPC-6010G Rackmount LCD Workstation
Model
ACE-R4140AP Redundant Power Supply
RPC-6010GWR/ACE-R4140AP No Full-size CPU card 14
RPC-6010GWR/ACE-R4140AP/T-R Yes Full-size CPU card 14
RPC-6010GWATXR/ACE-R4140AP No ATX / microATX 7
RPC-6010GWATXR/ACE-R4140AP/T-R Yes ATX / microATX 7
Table 1-1: RPC-6010G Model Variations
Touch
SBC Form Factor
Screen
Expansion
Slots
1.4 Certifications
All RPC-6010G rackmount workstations comply with the following international standards:
RoHS
For a more detailed description of this standard, please refer to Appendix A.
Page 3
RPC-6010G Rackmount LCD Workstation
THIS PAGE IS INTENTIONALLY LEFT BLANK
Page 4
RPC-6010G Rackmount LCD Workstation
Chapter
2

2 Mechanical Overview

Page 5
2.1 External Overview
The following sections describe the physical layout of the RPC-6010G rackmount
workstation.
2.1.1 Front Panel
The RPC-6010G rackmount workstation has the following front panel items:
Plastic frame
8.4” Flat panel TFT LCD screen
Lockable drive bay access door with 62 key membrane keypad and OSD
controls conceals:
o Three 5.25” drive bays o One 3.5” drive bay
RPC-6010G Rackmount LCD Workstation
o Power switch o 2 USB connectors o Power and HDD LEDs o Reset button
Figure 2-1: RPC-6010G Front Panel
Page 6
RPC-6010G Rackmount LCD Workstation
Figure 2-2: RPC-6010G Front Panel Door Open (Drives Not Included)
2.1.2 Rear Panel
The RPC-6010G rackmount workstation is available with either a 14-slot rear panel
bracket or an ATX motherboard rear panel bracket. The following sections list the 14-slot
rear panel bracket and ATX motherboard rear panel bracket items.
2.1.2.1 14-Slot Rear Panel
The 14-slot rear panel has the following rear panel items:
Internal PSU
14 expansion slots
VGA connector
PS/2 mouse connector
Optional Touch Screen connector
Page 7
RPC-6010G Rackmount LCD Workstation
Figure 2-3: RPC-6010G 14 Slot Rear Panel
2.1.2.2 ATX Motherboard Rear Panel
The RPC-6010G rackmount workstation is available with two types of rear panel brackets.
The ATX motherboard rear panel has the following rear panel items:
Internal PSU
7 expansion slots
VGA connector
PS/2 mouse connector
Optional Touch Screen connector
ATX Motherboard connector area
Page 8
RPC-6010G Rackmount LCD Workstation
Figure 2-4: RPC-6010G ATX Motherboard Rear Panel
2.1.3 Right Side Panel
The RPC-6010G rackmount workstation has the following right side panel items:
Cooling vents
Figure 2-5: RPC-6010G Right Side Panel
Page 9
2.1.4 Left Side Panel
The RPC-6010G rackmount workstation has the following left side panel items:
Cooling vents
RPC-6010G Rackmount LCD Workstation
Figure 2-6: RPC-6010G Left Side Panel
2.2 Physical Dimensions
The following sections describe the physical dimensions of the RPC-6010G.
2.2.1 General Physical Dimensions
General physical dimensions for the RPC-6010G are shown in Table 2-1.
Width
(mm)
431 177 528
Table 2-1: General Physical Dimensions
Height
(mm)
Depth
(mm)
Page 10
RPC-6010G Rackmount LCD Workstation
2.2.2 RPC-6010G Physical Dimensions
The physical dimensions of the RPC-6010G are shown in Figure 2-1.
Figure 2-7: RPC-6010G Physical Dimensions (millimeters)
Page 11
RPC-6010G Rackmount LCD Workstation
THIS PAGE IS INTENTIONALLY LEFT BLANK
Page 12
RPC-6010G Rackmount LCD Workstation
Chapter
3

3 Detailed Specifications

Page 13
3.1 RPC-6010G Specifications
Table 3-1 shows the RPC-6010G specifications.
LCD Type 8.4" TFT
Input Interface VGA
Max. Resolution 800 x 600
Backlight MTBF 20,000 Hrs
Contrast 500:1
LCD Color 262K
Brightness (cd/m2) 220
Chassis Heavy-duty steel
View Angle (H / V) 130 / 110
OSD function Yes
RPC-6010G Rackmount LCD Workstation
Mounting 19” Rack Mount
Rack Height 4U
Cooling Fan 1 – 12cm
Expansion Slots
Dimensions (WxHxD) (mm) 431 x 177 x 528
Weight (Gross/Net) 15kg / 18kg
Color White
Vibration
Shock 10G acceleration peak to peak (11ms)
Humidity 5 ~ 95%, relative
Operation Temperature 0 ~ 50°C
14 for RPC-6010G
7 for RPC-6010GATX
5 ~ 17 Hz, 0.1” double amplitude displacement
17 ~ 640 Hz, 1.5G acceleration peak to peak
Table 3-1: RPC-6010G Specifications
Page 14
RPC-6010G Rackmount LCD Workstation
3.2 LCD Specifications
Table 3-2 lists the RPC-6010G LCD specifications.
Size 8.4”
MFR/Model AUO/G084SN03
Resolution SVGA (800 x 600)
Active Area (mm) 170.4 x 127.8
Pixel Pitch (mm) 0.213
Number of Colors 262K
View Angle (H/V) 130 / 110
Brightness (cd/m2) 220
Contrast Ratio 500:1
Response Time (ms) (at 25C) 35
Power Consumption (W) 3.3
Interface 1ch LVDS
Supply Voltage (V) 3.3
Backlight 1 CCFL
Lamp Life (hrs) 20,000
Table 3-2: LCD Specifications
Page 15
RPC-6010G Rackmount LCD Workstation
3.3 ACE-832AP PSU Specifications
Table 3-3 lists the ACE-832AP power supply specifications.
INPUT Voltage 90 ~ 264VAC Full Range
Frequency 50 ~ 60Hz
Input Current 6A(RMS)@115VAC
3A(RMS)@230VAC
Inrush Current 60A Max for 115VAC
90A Max for 230VAC
OUTPUT Voltage Min. load Max. load Ripple & Noise
+3.3V 0.3A 28A 50mV
+5V 0.1A 30A 50mV
+12V 0A 15A 120mV
-5V 0A 0.3A 100mV
-12V 0A 0.8A 120mV
+5Vsb 0A 2A 100mV
Total Current of +3.3V & +5V & +12V ≦280W
GENERAL Power 300W
PFC Active
Hold-up Time 17ms minimum
Efficiency 65%
MTBF 50,000hrs
Temperature 0 ~ 50°C (Operating)
-20 ~ 80°C (Storage)
Dimensions 140 x 150 x 86mm
Table 3-3: ACE-832AP PSU Specifications
3.4 Recommended IEI Backplanes, Motherboards and PSUs
Page 16
Refer to Appendix B for recommended IEI backplanes, motherboards and power supply
units for the RPC-6010G rackmount workstation.
RPC-6010G Rackmount LCD Workstation
Chapter
4

4 Installation

Page 17
4.1 Installation Considerations
4.1.1 Installation Precautions
When installing the RPC-6010G, please follow the precautions listed below:
Read the user manual: The user manual provides a complete description of
the RPC-6010G rackmount workstation, installation instructions and
configuration options.
Turn Off Power: When installing the RPC-6010G rackmount workstation,
make sure the power is off. Failing to turn off the power may cause severe
injury to the user and/or damage the system.
Certified Engineers: Only certified engineers and technicians should install
and modify the RPC-6010G rackmount workstation. Non-certified engineers
or technicians should not attempt to install the RPC-6010G rackmount
RPC-6010G Rackmount LCD Workstation
workstation.
Mounting: The RPC-6010G rackmount workstations are heavy devices.
When rack mounting the RPC-6010G rackmount workstation, please ensure
that at least two people are assisting with the procedure.
Anti-static Discharge: Electronic components like CPU cards and
backplanes must be installed into the RPC-6010G rackmount workstation.
Follow proper grounding procedures before installing these components.
4.1.2 Installation Prerequisites
Prepare the following before installing the RPC-6010G rackmount workstation:
Completely installed CPU card: The RPC-6010G rackmount workstation
CPU card is separately purchased. Before installing the RPC-6010G
rackmount workstation, a CPU card should be properly installed. The
following components may also have to be installed (refer to the user manual
that came with the CPU card):
Page 18
o CPU o Heatsink and cooling fan o Memory modules (DIMMs) o Compact flash disks
RPC-6010G Rackmount LCD Workstation
Backplane/Motherboard: The backplane or motherboard installed in the
RPC-6010G rackmount workstation is separately purchased.
Disk Drives: Disk drives installed into the RPC-6010G rackmount workstation
are separately purchased. Disk drive support is CPU card dependent. Before
purchasing a CPU card or disk drives, please check the CPU card disk drive
support.
4.2 Unpacking
4.2.1 Packaging
When shipped, the RPC-6010G rackmount workstation is wrapped in a plastic bag. Two
polystyrene ends are placed on either side of the RPC-6010G rackmount workstation. The
workstation is then placed into a first (internal) cardboard box. This box is then sealed and
placed into a second (external) cardboard box. The second box is also sealed. A small
box containing accessory items is placed within the internal (first) box.
4.2.2 Unpacking Procedure
To unpack the RPC-6010G rackmount workstation, follow the steps below:
NOTE:
The front side LCD screen has a protective plastic cover stuck to the screen.
Remove the plastic cover only after the RPC-6010G rackmount workstation has
been properly installed. This ensures the screen is protected during the
installation process.
Step 1:
Use box cutters, a knife or a sharp pair of scissors to open the top of the external
(second) box.
Step 2:
Open the external (second) box.
Page 19
RPC-6010G Rackmount LCD Workstation
Step 3:
Step 4:
Step 5:
Step 6:
Step 7:
Use box cutters, a knife or a sharp pair of scissors to open the top of the internal
(first) box.
Lift the workstation out of the boxes.
Remove both polystyrene ends from each side.
Pull the plastic cover off the workstation.
Make sure all the components listed in the packing list are present.
4.2.3 Packing List
NOTE:
If some of the components listed in the checklist below are missing, please do
not proceed with the installation. Contact the IEI reseller or vendor you
purchased the AC-KIT-883HD audio module from or contact an IEI sales
Step 0:
representative directly. To contact an IEI sales representative, please send an
email to sales@iei.com.tw
When the RPC-6010G rackmount workstation is received, make sure all the components
listed below are present.
Quantity Description Image
1
2
2
Backplane to SBC connector cable
Door key
Handle
.
Page 20
RPC-6010G Rackmount LCD Workstation
Quantity Description Image
2
1
1
1
7
1
Handle bracket
Mini-DIN 6 PS/2 connector cable
Power cable
Screw kit
Short card clamp
VGA cable
2
1
1
1
Table 4-1: Packing List
4-pin USB wire cable
For Touch Panel (T-R) Models only
RS-232 cable
TouchKit Driver CD
Touch pen
Page 21
RPC-6010G Rackmount LCD Workstation
4.3 Pre-installation Preparation
4.3.1 System Planning
User supplied CPU cards and backplanes or motherboards need to be installed in the
system before installing the RPC-6010G rackmount workstation.
The backplane determines the following system parameters:
CPU card type
Expandability
The CPU card determines the following system parameters:
CPU
Embedded graphics
4.3.2 Tools
System memory
HDD, FDD and optical drive connectivity and capacity
Speed
It is therefore proper to correctly specify the system before the system is installed. This
ensures that prudent selections can be made when the system is being developed.
Before installing the RPC-6010G rackmount workstation, make sure the following tools
are on hand:
Philips (crosshead) screwdriver: All the retention screws on the system are
Philips screws.
Soft working mat: When installing the RPC-6010G rackmount workstation,
the screen should be placed face down on a soft working mat.
Page 22
RPC-6010G Rackmount LCD Workstation
4.4 Installation Procedures
4.4.1 Preinstalled Components
The following components are preinstalled in the RPC-6010G rackmount workstation.
Power supply unit (PSU)
Cooling fan module
Drive bracket
LCD screen
4.4.2 User Installed Components
The following user supplied components need to be installed into the RPC-6010G
rackmount workstation:
Disk drives
Backplane and CPU card, or motherboard
PCI or ISA expansion cards (optional)
4.4.3 Installation Steps
Complete the following steps to properly install the workstation:
Step 1:
Step 2:
Step 3:
Step 4:
Step 5:
Step 6:
Open the top cover.
Remove the CPU card clamp.
Remove the dual CPU card clamp and drive bay stabilizer bracket.
Remove the disk drive bracket.
Install the disk drives.
Reinstall the disk drive bracket with the installed disk drives.
Step 7:
Step 8:
Step 9:
Install the backplane.
Install the CPU card.
Install the PCI or ISA expansion cards (optional).
Page 23
RPC-6010G Rackmount LCD Workstation
Step 10:
Step 11:
Step 12:
Step 13:
Step 14:
Connect all required cables.
Reinstall the dual CPU card clamp and drive bay stabilizer bracket.
Reinstall the CPU card clamp.
Close the top cover.
Mount the workstation.Step 0:
4.5 Installing Components into the RPC-6010G
NOTE:
This section gives a generic description of the component installation process
for the RPC-6010G rackmount workstation.
WARNING:
Failure to follow the installation procedures outlined in this section may cause
severe damage to the RPC-6010G rackmount workstation. Please follow the
installation instructions carefully.
Page 24
RPC-6010G Rackmount LCD Workstation
4.5.1 Remove the Top Cover
The top cover is secured to the RPC-6010G rackmount workstation with six screws (three
each on the left and right panels). To remove the top cover, please follow the steps below.
Step 1: Remove the six top cover retention screws (three each on the left and right
panels). (See Figure 4-1)
Figure 4-1: Top Cover Left Side Retention Screws (Right Side Similar)
Step 2: Remove the top cover from the chassis to reveal the internal components.
(See Figure 4-2) Step 0:
Figure 4-2: Remove Top Cover from Chassis
Page 25
4.5.2 Remove the CPU Card Clamp
The CPU card clamp is secured to the RPC-6010G rackmount workstation with four
retention screws. To remove the CPU card clamp, please follow the steps below.
Step 1: Remove four retention screws, two each on the left and right sides of the
workstation, that secure the CPU card clamp to the chassis (Figure 4-3).
RPC-6010G Rackmount LCD Workstation
Figure 4-3: CPU Card Clamp Right Side Retention Screws (Left Side Similar)
Step 2:
Remove the CPU card clamp from the chassis.Step 0:
4.5.3 Remove the Dual CPU Card Clamp & Drive Bay Stabilizer Bracket
The dual CPU card clamp and drive bay stabilizer bracket is secured to the RPC-6010G
rackmount workstation with 10 retention screws. To remove the dual CPU card clamp and
drive bay stabilizer bracket, please follow the steps below.
Step 1:
Remove the six retention screws that secure the dual CPU card clamp and drive
bay stabilizer bracket to the sides of the workstation chassis (Figure 4-4).
Page 26
RPC-6010G Rackmount LCD Workstation
Figure 4-4: Dual CPU Card Clamp and Drive Bay Stabilizer Bracket
Right Side Retention Screws (Left Side Similar)
Step 2: Remove the four retention screws that secure the dual CPU card clamp and
drive bay stabilizer bracket to the fan bracket ( Figure 4-5).
Figure 4-5: Dual CPU Card Clamp and Drive Bay Stabilizer Bracket to
Fan Bracket Retention Screws
Page 27
RPC-6010G Rackmount LCD Workstation
Step 3:
Remove the CPU card clamp and drive bay bracket from the chassis.Step 0:
4.5.4 Remove the Drive Bracket
The drive bracket is secured to the RPC-6010G rackmount workstation with four retention
screws. To remove the drive bracket, please follow the steps below.
Step 1:
Remove four retention screws that secure the drive bracket to the chassis
(Figure 4-4).
Figure 4-6: Drive Bracket Retention Screws
Step 2:
Remove the drive bracket from the chassis.Step 0:
4.5.5 Remove the Drive Slot Blank Plate
The drive bracket has three 5.25” and one 3.5” drive slot blank plates. To remove the drive
slot blank plates, please follow the steps below.
Step 1:
Remove the retention screws from each side of the drive bracket that secure the
drive slot blank plates to the drive bracket (Figure 4-5).
Page 28
RPC-6010G Rackmount LCD Workstation
Figure 4-7: Drive Slot Blank Plate Retention Screws (Other Side Similar)
Step 2:
Remove the drive slot blank plate from the drive bracket.Step 0:
4.5.6 Install Drives
4.5.6.1 5.25” Disk Drive
The drive bracket supports three 5.25” disk drives. To install a 5.25” disk drive, follow the
instructions below.
Step 1:
Step 2:
Step 3:
Step 4:
Remove the dual CPU card clamp and drive bay stabilizer bracket from the
RPC-6010G rackmount workstation (see Section 4.5.3).
Remove the drive bracket from the RPC-6010G rackmount workstation (see
Section 4.5.4).
Remove the appropriate drive slot blank plate (see Section 4.5.5).
Slide the 5.25” disk drive into the drive bracket. Make sure the IDE/SATA
connector and the power connector of the drive are facing the rear of the
bracket.
Page 29
Step 5: Insert the appropriate number of retention screws into each side of the 5.25”
disk drive through the drive bracket (Figure 4-8).Step 0:
RPC-6010G Rackmount LCD Workstation
Figure 4-8: 5.25” Disk Drive Retention Screws (Other Side Similar)
4.5.6.2 3.5” Disk Drive in a 5.25” Slot
With the use of IEI’s 3.5” to 5.25” drive bay rack, a standard 3.5” disk drive can be installed
into a 5.25” drive bay slot. To install a 3.5” hard disk drive into a 5.25” slot of the drive
bracket, follow the instructions below.
Step 1:
Step 2:
Slide a 3.5” disk drive into a 3.5” to 5.25” drive bay rack. Make sure the
IDE/SATA connector and the power connectors of the drive are facing the rear of
the rack.
Insert the appropriate number of retention screws into each side of the 3.5” disk
drive through the 3.5” to 5.25” drive bay rack (Figure 4-9).
Page 30
RPC-6010G Rackmount LCD Workstation
Figure 4-9: 3.5” to 5.25” Drive Bay Rack Retention Screws (Other Side Similar)
Step 3:
Step 4:
Step 5:
Step 6:
Remove the dual CPU card clamp and drive bay stabilizer bracket from the
RPC-6010G rackmount workstation (see Section 4.5.3).
Remove the drive bracket from the RPC-6010G rackmount workstation
(see Section 4.5.4).
Remove the appropriate drive slot blank plate (see Section 4.5.5).
Install the 3.5” to 5.25” drive bay rack into the drive bracket
(see Section 4.5.6.1)
Step 0:
4.5.6.3 3.5” Disk Drive
To install a 3.5” disk drive, follow the instructions below.
Step 1:
Remove the dual CPU card clamp and drive bay stabilizer bracket from the
RPC-6010G rackmount workstation (see Section 4.5.3).
Step 2:
Step 3:
Remove the drive bracket from the RPC-6010G rackmount workstation
(see Section 4.5.4).
If installing a floppy disk drive, remove the 3.5” drive slot blank plate
(see Section 4.5.5).
Page 31
RPC-6010G Rackmount LCD Workstation
Step 4:
Step 5:
Slide a 3.5” disk drive into one of the 3.5” drive brackets. Make sure the
connectors of the drive are facing the rear of the drive bracket.
Insert the appropriate number of retention screws into each side of the 3.5” disk
drive through the 3.5” drive bracket (Figure 4-10).Step 0:
Figure 4-10: 3.5” Disk Drive Retention Screws
4.5.7 Reinstall the Drive Bracket
After the drives have been installed, reinstall the drive bracket into the chassis.
NOTE:
It might be easier to connect the disk drive IDE/SATA connectors to the ribbon
cables and the disk drive power connectors to the PSU before the drive bracket
is reinstalled into the chassis.
Step 1:
Step 2:
Remount the drive bracket in the original position it was removed from.
Make sure all drive bracket retention screw holes are properly aligned with the
corresponding retention screw holes in the workstation.
Page 32
Step 3:
Reinsert all drive bracket retentions screws. Step 0:
RPC-6010G Rackmount LCD Workstation
4.5.8 Install the Backplane
To install a backplane, follow the instructions below.
Step 1: Install the correct amount of copper pillars and plastic spacers into the base of
the chassis (Figure 4-11).
NOTE:
The backplane shown in Figure 4-11 is an example for reference only. The
location and number of copper pillars and plastic spacers depends on the
backplane being used.
Figure 4-11: Install Copper Pillars and Plastic Spacers
Page 33
RPC-6010G Rackmount LCD Workstation
Step 2:
Step 3:
Step 4:
Mount the backplane into the chassis. Make sure the backplane is positioned so
that when the CPU card and PCI/ISA expansion cards are installed, both the
CPU card and the PCI/ISA card I/O connectors face the I/O brackets on the rear
panel.
Align the retention screw holes in the backplane with the copper pillars installed
in Step 1.
Insert retention screws to secure the backplane to the chassis (Figure 4-12)
Step 0:
Page 34
Figure 4-12: Backplane Retention Screws
RPC-6010G Rackmount LCD Workstation
4.5.9 Install the CPU Card
CAUTION
Before a CPU card is inserted into the backplane, make sure the CPU card has
been correctly prepared and that all the CPU card jumper settings are
configured correctly. For CPU card component installation procedures, please
refer to the user manual that came with the CPU card.
CAUTION
Depending on the location of the CPU card, the disk drive ribbon cable
connectors and other peripheral device cable connectors may have to be
connected to the CPU card before it can be installed.
To install a CPU card onto the backplane, follow the instructions below:
Step 1: Remove the slot bracket from the chassis rear panel by removing the slot cover
retention screw (Figure 4-13).
Page 35
RPC-6010G Rackmount LCD Workstation
Figure 4-13: Slot Cover Retention Screw
Step 2:
Step 3:
Step 4:
Remove the CPU card clamp. (See Section 4.5.2)
Remove the dual CPU card clamp and drive bay stabilizer bracket. (See
Section 4.5.3)
Slide the CPU card into the reserved PCI/ISA socket on the backplane. Make
sure the back edge of the CPU card slides into the plastic guide rails at the front
end of the chassis.
Page 36
RPC-6010G Rackmount LCD Workstation
Figure 4-14: Install the CPU Card
Step 5:
Step 6:
To secure the CPU card, reinsert the previously removed slot cover retention
screw.
If a PCI/ISA expansion card is not being installed, reinstall the dual CPU card
clamp and drive bay stabilizer bracket and the CPU card clamp. If a PCI/ISA
expansion card is being installed, proceed to the next section.
Step 0:
4.5.10 Install the PCI/ISA Expansion Card
To install a PCI expansion card or an ISA expansion card please follow the instructions
below.
Step 1:
Remove the slot cover retention screw to remove the slot bracket from the
chassis rear panel (Figure 4-13).
Page 37
RPC-6010G Rackmount LCD Workstation
Step 2:
Step 3:
Step 4:
Step 5:
Step 1:
Step 2:
If necessary, remove the CPU card clamp. (See Section 4.5.2)
If necessary, remove the dual CPU card clamp and drive bay stabilizer bracket.
(See Section 4.5.3)
Slide the PCI/ISA expansion card into the reserved PCI/ISA socket on the
backplane.
To secure the PCI/ISA expansion card, reinsert the previously removed slot
cover retention screw. Step 0:
If necessary, reinstall the CPU card clamp.
If necessary, reinstall the dual CPU card clamp and drive bay stabilizer bracket.
4.5.11 Installing Short Cards
When installed, some cards may still fall short below the CPU card clamp. To better
secure the CPU card or expansion cards, use the short card clamps that came with the
workstation.
Step 3:
Step 4:
Step 5:
Locate the screw hole on the CPU card clamp closest to the target card.
Adjust the short card clamp in a vertical direction until the shock absorber part of
the clamp secures the expansion card.
Fasten a screw to secure the card clamp. Step 0:
Page 38
RPC-6010G Rackmount LCD Workstation
Figure 4-15: Installing a Short Card
4.5.12 Connect the Cables
The following cables may have to be connected depending on the CPU card and the
backplane installed in the system:
PSU cables must be connected to the following components (if installed):
o CPU card o Backplane o FDD o HDD o Optical drive
Disk drive ribbon cables must be connected to the corresponding CPU card
disk drive connectors.
Other connections may have to be made; please refer to the documentation that came
with the CPU card.
Page 39
RPC-6010G Rackmount LCD Workstation
4.5.13 Close the Top Cover
Before closing the top cover, make sure the following items have been completed:
The backplane is properly installed
The CPU card is properly installed
The PCI/ISA expansion cards are properly installed
The disk drives are properly installed into the drive bracket
The drive bracket is properly reinstalled into the workstation
All cables are properly connected
If all of the above listed items have been properly installed, close the top cover and
reinsert the previously removed retention screws.
4.6 Mounting the RPC-6010G Rackmount Workstation
The RPC-6010G workstation can be mounted to the posts of a standard 19” rack cabinet.
Adequate rails, rack tray, or side brackets should also be available for supporting the
weight of the workstation. Make sure that all cabling is correctly attached and carefully
routed when installing the workstation.
NOTE:
At least two people are required to mount the workstation. The rack or cabinet
into which the workstation is installed should provide adequate and sufficient
ventilation, grounding, power source, and stability features.
Page 40
RPC-6010G Rackmount LCD Workstation
NOTE:
This section gives a generic description of the rack mounting process for the
RPC-6010G rackmount workstation. Alternate rack mounting systems may
require different mounting procedures. Be sure to follow the manufacturer’s
instructions when mounting the workstation.
To rack mount the workstation, please follow the steps below.
Step 1: The left and right side panels of the workstation each have four screw holes for
rack handle bracket installation. Assemble the rack handle brackets and secure
them to the workstation. (See Figure 4-16)
Figure 4-16: Rack Handle Bracket Assembly and Installation
Page 41
Step 2: Remove the rack slides from the rack slide brackets. (See Figure 4-17)
RPC-6010G Rackmount LCD Workstation
Page 42
Figure 4-17: Remove Rack Slide
Step 3: The left and right side panels of the workstation each have five screw holes for
rack slides. Attach one slide section each to the left and right side panel of the
workstation. (See Figure 4-16)
RPC-6010G Rackmount LCD Workstation
Figure 4-18: Workstation Slide Installation (Other Side Similar)
Step 4: Assemble the slide brackets per the manufacturer’s instructions.
(See Figure 4-19)
Page 43
RPC-6010G Rackmount LCD Workstation
Figure 4-19: Rack Slide Bracket Assembly
Step 5: Attach the slide brackets to the rack per the manufacturer’s instructions.
(See Figure 4-20)
Page 44
RPC-6010G Rackmount LCD Workstation
Figure 4-20: Rack Slide Bracket Installation
Step 6: Insert the workstation with the attached slides into the rack slide brackets until
the handle brackets are flush against the rack. (See Figure 4-21)
Page 45
RPC-6010G Rackmount LCD Workstation
Figure 4-21: Install Workstation into Rack
Step 7: If necessary, secure the workstation handle brackets to the rack with the
fasteners that came with the workstation.
Step 0:
Page 46
RPC-6010G Rackmount LCD Workstation
Chapter
5

5 Maintenance

Page 47
5.1 Maintenance Overview
Maintaining the RPC-6010G rackmount workstation is essential for the smooth operating
of system applications. Maintaining the system might mean replacing failed components
during the lifetime of the workstation. The following RPC-6010G components can be
replaced.
CPU card
PCI/ISA expansion card
Backplane
Power supply unit (PSU)
Cooling fans
Disk drives
o 3.5” o 5.25”
RPC-6010G Rackmount LCD Workstation
WARNING:
Never attempt to remove the external panels or access any internal
components of the workstation while it is connected to a power source. Always
be sure to turn off and disconnect the workstation from all power sources
before attempting to access the internal components. Failure to do so may
seriously injury to the user or cause irreparable damage the internal
components of the workstation.
5.2 CPU Card Replacement
To replace a CPU card, please follow the instructions below.
Step 1:
Turn off and disconnect the workstation from all power sources.
Page 48
Step 2:
Remove the workstation from the rack in which it is installed.
RPC-6010G Rackmount LCD Workstation
Step 3:
Step 4:
Step 5:
Step 6:
Step 7:
Step 8:
Step 9:
Step 10:
Open the top cover of the RPC-6010G rackmount workstation.
(See Section 4.5.1)
Disconnect all internal and external peripheral device connections
from the CPU card.
Remove the CPU card clamp. (See Section 4.5.2)
Remove the dual CPU card clamp and drive bay stabilizer bracket. (See
Section 4.5.3)
Remove the retention screw that secures the CPU card to the slot on the rear
panel.
Slide the CPU card out of the workstation.
Install a new CPU card. (See Section 4.5.9)
Reinstall the CPU card clamp.
Step 11:
Step 12:
Step 13:
Reinstall the dual CPU card clamp and drive bay stabilizer bracket.
Reinstall the top cover of the workstation.
Reinstall the workstation into the rack. Refer to Section 4.6 for complete
mounting instructions.Step 0:
5.3 PCI/ISA Expansion Card Replacement
To replace a PCI/ISA expansion card, please follow the instructions below.
Step 1:
Step 2:
Step 3:
Step 4:
Turn off and disconnect the workstation from all power sources.
Remove the workstation from the rack in which it is installed.
Open the top cover of the RPC-6010G rackmount workstation.
(See Section 4.5.1)
Disconnect all internal and external peripheral device connections from the
PCI/ISA expansion card.
Page 49
RPC-6010G Rackmount LCD Workstation
Step 5:
Step 6:
Step 7:
Step 8:
Step 9:
Step 10:
Step 11:
Step 12:
Step 13:
Remove the CPU card clamp. (See Section 4.5.2)
Remove the dual CPU card clamp and drive bay stabilizer bracket. (See
Section 4.5.3)
Remove the retention screw that secures the PCI/ISA expansion card to the slot
on the rear panel.
Slide the PCI/ISA expansion card out of the workstation.
Install a new PCI/ISA expansion card. (See Section 4.5.10)
Reinstall the CPU card clamp.
Reinstall the dual CPU card clamp and drive bay stabilizer bracket.
Reinstall the top cover of the workstation.
Reinstall the workstation into the rack. Refer to Section 4.6 for complete
mounting instructions.Step 0:
5.4 Backplane Replacement
To replace a backplane, please follow the instructions below.
Step 1:
Step 2:
Step 3:
Step 4:
Step 5:
Step 6:
Turn off and disconnect the workstation from all power sources.
Remove the workstation from the rack in which it is installed.
Open the top cover of the RPC-6010G rackmount workstation.
(See Section 4.5.1)
Remove the CPU card clamp. (See Section 4.5.2)
Remove the dual CPU card clamp and drive bay stabilizer bracket. (See
Section 4.5.3)
Disconnect and remove all CPU cards (see Section 4.5.9) and PCI/ISA
expansion cards (see Section 4.5.10).
Page 50
RPC-6010G Rackmount LCD Workstation
Step 7:
Step 8:
Step 9:
Step 10:
Step 11:
Step 12:
Step 13:
Remove the retention screws that secure the backplane to the workstation
(see Section 4.5.8).
Install a new backplane into the chassis.
Reinstall and reconnect all CPU cards (see Section 4.5.9) and PCI/ISA
expansion cards (see Section 4.5.10).
Reinstall the CPU card clamp.
Reinstall the dual CPU card clamp and drive bay stabilizer bracket.
Reinstall the top cover of the workstation.
Reinstall the workstation into the rack. Refer to Section 4.6 for complete
mounting instructions.Step 0:
5.5 PSU Replacement
To replace a PSU, please follow the instructions below.
Step 1:
Step 2:
Step 3:
Step 4:
Step 5:
Step 6:
Turn off and disconnect the workstation from all power sources.
Remove the workstation from the rack in which it is installed.
Open the top cover of the RPC-6010G rackmount workstation.
(See Section 4.5.1)
Remove the CPU card clamp. (See Section 4.5.2)
Disconnect all the PSU cables from their devices.
Remove the four external retention screws that secure the PSU assembly to the
rear panel of the workstation (Figure 5-1).
Page 51
RPC-6010G Rackmount LCD Workstation
Figure 5-1: PSU External Retention Screws
Step 7: Remove the two internal retention screws that secure the PSU assembly to the
right side panel of the workstation (Figure 5-2).
Page 52
Figure 5-2: PSU Internal Retention Screws
RPC-6010G Rackmount LCD Workstation
Step 8: Remove the two retention screws on the PSU mounting bracket (Figure 5-3).
Figure 5-3: PSU Mounting Bracket Retention Screws
Step 9:
Step 10:
Step 11:
Step 12:
Step 13:
Step 14:
Step 15:
Reattach the PSU mounting bracket to the new PSU with the two previously
removed retention screws.
Install the new PSU into the workstation making sure the PSU power connector
and PSU cooling fan are facing out of the workstation.
Reinsert the two previously removed internal retention screws that secure the
PSU assembly to the right side panel of the workstation.
Reinsert the four previously removed external retention screws that secure the
PSU assembly to the rear panel of the workstation.
Reinstall the CPU card clamp.
Reinstall the top cover of the workstation.
Reinstall the workstation into the rack. Refer to Section 4.6 for complete
mounting instructions.Step 0:
Page 53
5.6 Cooling Fan Replacement
To replace a cooling fan, please follow the instructions below.
CAUTION:
Carefully note the direction and orientation of the existing cooling fan prior to
replacement.
RPC-6010G Rackmount LCD Workstation
Step 1:
Step 2:
Step 3:
Step 4:
Step 5:
Step 6:
Step 7:
Step 8:
Turn off and disconnect the workstation from all power sources.
Remove the workstation from the rack in which it is installed.
Open the top cover of the RPC-6010G rackmount workstation.
(See Section 4.5.1)
Remove the CPU card clamp. (See Section 4.5.2)
Remove the dual CPU card clamp and drive bay stabilizer bracket. (See
Section 4.5.3)
Disconnect and remove all CPU cards and PCI/ISA expansion cards.
Disconnect the cooling fan from the PSU.
Remove the two external retention screws that secure the cooling fan bracket to
the left side panel of the workstation. (See Figure 5-4)
Page 54
RPC-6010G Rackmount LCD Workstation
Figure 5-4: Cooling Fan Bracket External Screws
Step 9: Remove the three retention screws that secure the cooling fan bracket to the
bottom of the workstation. (See Figure 5-5)
Figure 5-5: Cooling Fan Bracket Bottom Panel Screws
Page 55
Step 10: Remove the fan from the bracket by removing the four retention screws.
(See Figure 5-6)
RPC-6010G Rackmount LCD Workstation
Figure 5-6: Fan Retention Screws
Step 11:
Step 12:
Step 13:
Step 14:
Step 15:
Step 16:
Place the new fan into the bracket. Align the retention screw holes in the new fan
with those in the bracket and reinsert the four retention screws.
Connect the new cooling fan to the PSU.
Reinstall the three retention screws that secure the cooling fan bracket to the
bottom of the workstation.
Reinstall the two external retention screws that secure the cooling fan bracket to
the left side panel of the workstation.
Reinstall and reconnect all CPU cards and PCI/ISA expansion cards.
Reinstall the dual CPU card clamp and drive bay stabilizer bracket. (See
Section 4.5.3)
Page 56
Step 17:
Reinstall the CPU card clamp. (See Section 4.5.2)
RPC-6010G Rackmount LCD Workstation
Step 18:
Step 19:
Reinstall the top cover of the workstation.
Reinstall the workstation into the rack. Refer to Section 4.6 for complete
mounting instructions.Step 0:

5.7 Disk Drive Replacement

5.7.1 3.5” Disk Drive Replacement
To replace a 3.5” disk drive, please follow the instructions below.
Step 1:
Step 2:
Step 3:
Step 4:
Turn off and disconnect the workstation from all power sources.
Remove the workstation from the rack in which it is installed.
Open the top cover of the RPC-6010G rackmount workstation.
(See Section 4.5.1)
Remove the CPU card clamp. (See Section 4.5.2)
Step 5:
Step 6:
Step 7:
Step 8:
Step 9:
Step 10:
Step 11:
Step 12:
Remove the dual CPU card clamp and drive bay stabilizer bracket. (See
Section 4.5.3)
Disconnect all cabling from every hard drive.
Remove the drive bracket (see Section 4.5.4).
Remove the retention screws that secure the 3.5” disk drive to the drive bracket
and slide the drive out of the bracket.
Install the new 3.5” disk drive. (See Section 4.5.6.3)
Reinstall the drive bracket to the workstation. (See Section 4.5.7)
Reconnect all disk drive cabling.
Close the top cover of the workstation and reinstall the workstation into the
cabinet or rack in which it was previously installed. Refer to Section 4.6 for
complete mounting instructions. Step 0:
Page 57
5.7.2 5.25” Disk Drive Replacement
To replace a 5.25” disk drive, please follow the instructions below.
NOTE:
These instructions are also applicable for replacement of a 3.5” disk drive
mounted in a 5.25” disk drive adapter bracket. Refer to Section 4.5.6.2 for
instructions on installing a 3.5” disk drive into a 5.25” drive bay slot.
RPC-6010G Rackmount LCD Workstation
Step 1:
Step 2:
Step 3:
Step 4:
Step 5:
Step 6:
Step 7:
Step 8:
Step 9:
Turn off and disconnect the workstation from all power sources.
Remove the workstation from the rack in which it is installed.
Open the top cover of the RPC-6010G rackmount workstation.
(See Section 4.5.1)
Remove the CPU card clamp. (See Section 4.5.2)
Remove the dual CPU card clamp and drive bay stabilizer bracket. (See
Section 4.5.3)
Disconnect all cabling from every hard drive.
Remove the drive bracket (see Section 4.5.4).
Remove the retention screws that secure the 5.25” disk drive to the drive
bracket and slide the drive out of the bracket.
Install the new 5.25” disk drive. (See Section 4.5.6.3)
Page 58
Step 10:
Step 11:
Step 12:
Reinstall the drive bracket to the workstation. (See Section 4.5.7)
Reconnect all disk drive cabling.
Close the top cover of the workstation and reinstall the workstation into the
cabinet or rack in which it was previously installed. Refer to Section 4.6 for
complete mounting instructions. Step 0:
RPC-6010G Rackmount LCD Workstation
Chapter
6
6 On Screen Display
(OSD) Controls
Page 59
6.1 User Mode OSD Structure
6.1.1 OSD Buttons
There are several on-screen-display (OSD) control buttons on the front panel of the
workstation. Figure 6-1 shows a typical arrangement of OSD controls.
RPC-6010G Rackmount LCD Workstation
Figure 6-1: OSD Control Buttons
NOTE:
Pressing the direction keys (LEFT or RIGHT) can bring out a simple menu that
adjusts the LCD screen brightness and contrast values.
Page 60
RPC-6010G Rackmount LCD Workstation
6.1.2 OSD Menu Structure
Table 6-1 shows the OSD menu structure.
Level 0 Level 1 Value
Main Display Features Menu
Color Menu
Language Menu
Brightness 0 to 100
Contrast 0 to 100
Horizontal Size 0 to 100
Phase 0 to 100
H. Position 0 to 100
V. Position 0 to 100
Sharpness 1 to 5
Volume Speaker
Mute
9300 - Preset NTSC value
7500 - Preset NTSC value
User RGB values from 0 to 100
English
French
German
This menu is currently disabled,
and will be implemented with
models equipped with speakers.
Select
Spanish
Italian
Japanese
Russian
Traditional Chinese
Simplified Chinese
OSD Menu
OSD Time Out 0 to 60 sec
OSD Position 1 to 5
OSD Transparency 0 to 100
Auto Setting On or Off
Recall No or Yes
Aspect Ratio 4:3 or 5:4
Page 61
Level 0 Level 1 Value
RPC-6010G Rackmount LCD Workstation
Backlight Menu
Table 6-1: OSD Menus
6.2 Using the OSD
OSD menu options are described below.
6.2.1 Main Display Features
Digital Signal Menu
Analog
Light Enable On or Off
Light Contrast 0 to 100
Light Brightness 0 to 100
Light H Start 0 to 100
Light H Width 0 to 100
Light V Start 0 to 100
Light V Height 0 to 100
Select
Main display features are shown in Figure 6-2.
Figure 6-2: Main Display Features
Page 62
RPC-6010G Rackmount LCD Workstation
Brightness:
The brightness option adjusts the brightness of screen. This function
adjusts the offset value of ADC. Setting this value too high or too low will
affect the quality of image.
Contrast:
This function adjusts the gain value of ADC. Adjusting this value too high
or too low will worsen the quality of image.
Horizontal Size:
This item adjusts the screen size in the horizontal direction.
Phase:
This option adjusts the input signal and dot clock position (Analog only).
H. Position:
Adjusts the horizontal position of the display screen.
V. Position:
Adjusts the vertical position of the display screen.
Sharpness:
Adjusts the sharpness level to one of the 5 preset values. This option may
help reducing the softening edges around displayed objects.
Page 63
6.2.2 Color
RPC-6010G Rackmount LCD Workstation
Color options are shown in Figure 6-3.
Figure 6-3: Color Options
The Color menu fine-tunes the palette of color hues for the LCD.
9300:
NTSC standard Kelvin
7500:
NTSC standard Kelvin
6500:
NTSC standard Kelvin
User:
This item allows fine-tuning the balance among Red, Green, and Blue
color hues if images look garish or unrealistic.
Page 64
RPC-6010G Rackmount LCD Workstation
6.2.3 Language
The Languages are shown in Figure 6-4.
Figure 6-4: Language Menu
This menu provides options for selecting ODS screen legends in a preferred language.
Page 65
6.2.4 OSD Configurations
The OSD configurations are shown in Figure 6-5.
RPC-6010G Rackmount LCD Workstation
Figure 6-5: OSD Configurations Menu
OSD Configurations are described below.
OSD Time Out:
Determines how many seconds the OSD screen stays on screen before it
disappears when OSD is left unattended.
OSD Position:
Adjusts the OSD position on the screen. Position 1 is in the upper left of
the screen, position 2 in the upper right and position 3 in the center.
OSD Transparency
Determines the opacity of OSD background.
Auto Setting
This function automatically adjusts the LCD screen position in situations
such as connecting the LCD to a different host computer.
Page 66
Recall
Restores the default OSD settings. Note that this will restore all default
display settings.
RPC-6010G Rackmount LCD Workstation
Aspect Ratio
Adjusts the display ratio referring to the width of the screen and then to
the height of the screen.
6.2.5 Signal
The Signal menu in Figure 6-6 enables manual selection of the type of graphic source
input, i.e., analog (15-pin VGA) or digital (DVI-D).
Figure 6-6: Signal Menu
Page 67
6.2.6 Backlight
The Backlight menu in Figure 6-7 enables users to configure the LCD backlight.
RPC-6010G Rackmount LCD Workstation
Figure 6-7: Backlight Menu
Backlight Menu options are described below.
Light Enabled:
Turns backlight on or off.
Light Contrast:
Adjusts the backlight contrast.
Light Brightness:
Adjusts the backlight brightness.
Light H Start:
Adjusts the backlight projection area in the horizontal direction.
Light H Width:
Adjusts the width of the backlight projection area.
Light V Start:
Adjusts the backlight projection area in the vertical direction.
Light V Height:
Page 68
Adjusts the height of the backlight projection area.
RPC-6010G Rackmount LCD Workstation
Chapter
7

7 Software Driver

Page 69
NOTE:
The following information is provided for workstations with touch screens.
7.1 Touch Screen Driver
The touch screen controller enables analog resistive touch screens for four-wire, five-wire
& eight-wire models. The controller directly communicates with the PC system through the
touch screen communications interface. The controller design is superior in sensitivity,
accuracy, and friendly operation. The touch screen driver emulates the left mouse button
and the right mouse button functions.
The touch screen driver supports the following operating systems:
RPC-6010G Rackmount LCD Workstation
Microsoft Windows versions:
o Microsoft Windows 95 o Microsoft Windows 98 o Microsoft Windows ME o Microsoft Windows 2000 o Microsoft Windows NT o Microsoft Windows XP o Microsoft Windows XP Tablet PC Edition
Microsoft Windows CE versions:
o Microsoft Windows CE 2.12 o Microsoft Windows CE 3.0 o Microsoft Windows CE. NET
Linux
IMac
DOS.
Driver installation is described below.
Page 70
RPC-6010G Rackmount LCD Workstation
7.2 Driver Installation
To install the touch screen software driver, please follow the steps below.
Step 1:
Step 2:
Insert the TouchKit driver CD that came with the RPC-6010G rackmount
workstation into the CD drive.
Once the CD drive is installed, the screen in Figure 7-1 appears.
Figure 7-1: Driver CD Pop Up Screen
Step 3: Select the operating system installed on the system from the menu on the left
side of the screen.
NOTE:
The following description is for driver installation using a Windows 2000 OS. If a
different OS is installed, please refer to the driver user manual for the relevant
OS. The driver user manuals can be accessed by selecting “User Manual”
from the menu on the left side of the “Driver CD Pop Up Screen”.
Page 71
Step 4: Once the OS system is selected, the touch kit setup will prepare the install shield
wizard (Figure 7-2).
RPC-6010G Rackmount LCD Workstation
Figure 7-2: Install Shield Wizard Preparation
Step 5: After the Install Shield Wizard is ready, a welcome screen appears (Figure 7-3).
Page 72
Figure 7-3: Welcome Screen
Step 6: To continue the installation process click N
EXT.
RPC-6010G Rackmount LCD Workstation
Step 7: An Install PS/2 interface driver screen appears (Figure 7-4). It is not necessary
to install the PS/2 interface driver. To continue click N
EXT.
Figure 7-4: Install PS/2 Interface Driver
Step 8: Four point calibration options are then selected (Figure 7-5). Four point
calibrations can be done every time a user boots up, during the next time the
system boots or never. Select if and when a four-point calibration should be
done. Click N
EXT to continue.
Page 73
RPC-6010G Rackmount LCD Workstation
Figure 7-5: Install PS/2 Interface Driver
Step 9: The user is then prompted to ensure the touch monitor or the USB for the touch
controller is plugged into the system (Figure 7-6). Once the touch controller is
plugged into the system, click “OK.”
Figure 7-6: Touch Monitor/USB Touch Controller Confirmation
Page 74
RPC-6010G Rackmount LCD Workstation
Step 10: The user is then prompted to select multi-monitor system support (Figure 6-7).
Make the appropriate selection and click N
EXT to continue.
Figure 7-7: Controller Installation Directory
Page 75
Step 11: The user is then prompted to select a file directory in which the touch kit
controller is installed (Figure 7-8). The default directory is “C:\Program
Files\TouchKit.” If a different folder must be used, select browse and then select
RPC-6010G Rackmount LCD Workstation
the folder. Once the folder is selected, click N
EXT to continue.
Page 76
Figure 7-8: Controller Installation Directory
RPC-6010G Rackmount LCD Workstation
Step 12: The user is then prompted to select a file directory in which the program icons
are saved (Figure 7-9). The default folder is “TouchKit.” If a different folder must
be used, select a folder from the list shown. Once the folder is selected, click
EXT to continue.
N
Figure 7-9: Program Icon Directory
Page 77
Step 13: The program then starts installing (Figure 7-10).
RPC-6010G Rackmount LCD Workstation
Figure 7-10: Installing
Page 78
RPC-6010G Rackmount LCD Workstation
Step 14: Once the program is finished installing, the user is prompted to restart the
computer now or to restart the computer later (Figure 7-11). Select when the
computer should be restarted and click “F
installation procedure.Step 0:
INISH” to complete the driver
Figure 7-11: Installation Complete
7.3 Touch Screen Driver Configuration
To configure the touch screen driver options, refer to the TouchKit user manual located on
the driver installation CD.
Page 79
RPC-6010G Rackmount LCD Workstation
THIS PAGE IS INTENTIONALLY LEFT BLANK
Page 80
RPC-6010G Rackmount LCD Workstation
Appendix
A

A Certifications

Page 81
A.1 RoHS Compliant
All RPC-6010G rackmount workstations comply with the Restriction of Hazardous
Materials (RoHS) Directive. This means that all components used to build the industrial
workstations and the workstation itself are RoHS compliant.
The RoHS Directive bans the placing on the EU market of new electrical and electronic
equipment containing more than agreed levels of lead, cadmium, mercury, hexavalent
chromium, polybrominated biphenyl (PBB) and polybrominated diphenyl ether (PBDE)
flame retardants.
RPC-6010G Rackmount LCD Workstation
Page 82
RPC-6010G Rackmount LCD Workstation
Appendix
B
B Recommended IEI
Backplanes,
Motherboards
and PSUs
Page 83
The following IEI backplanes, motherboards and power supply units are recommended for
the RPC-6010G rackmount workstation. For more information about these backplanes
RPC-6010G Rackmount LCD Workstation
please contact an IEI sales representative or visit the IEI website (www.ieiworld.com
B.1 Recommended IEI Backplanes and Motherboards
The following table lists the recommended IEI backplanes and motherboards for the
RPC-6010G rackmount workstation.
PCIe
Model No. SBC Type PCI ISA
X1 X4 X16
PCI-13SD-RS-R30 PICMG 1.0 3 + 4 3 + 3 0 0 0 AT/ATX
PCI-14S2-RS-R30 PICMG 1.0 4 8 0 0 0 AT/ATX
PCI-14S3-RS-R30 PICMG 1.0 4 9 0 0 0 AT/ATX
PX-14S3-RS-R30 PICMG 1.0 12 2 0 0 0 AT/ATX
PX-14S5-RS-R30 PICMG 1.0 7 6 0 0 0 AT/ATX
).
PSU
Connector
BP-14S-RS-R30 ISA 0 14 0 0 0 AT
PXAGP-13S3-RS-R30 PIAGP 11 0 0 0 0 AT/ATX
PE-13SD PICMG 1.3 4 0 5 0 2 ATX
PXE-13S PICMG 1.3 8 0 3 0 1 ATX
PXE-13S2 PICMG 1.3 4 0 7 0 1 ATX
PXE-13S3 PICMG 1.3 3 0 0 8 1 ATX
Table B-1: Recommended IEI Backplanes and Motherboards
Page 84
RPC-6010G Rackmount LCD Workstation
B.2 Recommended IEI Power Supply Units
The following table lists the recommended IEI power supply units for the RPC-6010G
rackmount workstation.
Type Model No. Watt
AT ACE-935AL-RS 300W
ACE-940AP-RS 390W
ATX ACE-832AP-RS 250W
ACE-841AP-RS 480W
ACE-850AP-RS 500W
Redundant ATX ACE-R4130AP-RS 300W
ACE-R4140AP-RS 400W
Table B-2: Recommended IEI Power Supply Units
Page 85
RPC-6010G Rackmount LCD Workstation
THIS PAGE IS INTENTIONALLY LEFT BLANK
Page 86
RPC-6010G Rackmount LCD Workstation

C Index

Page 87
RPC-6010G Rackmount LCD Workstation
Installation Steps ...................................23
A
ACE-832AP PSU Specifications................16
Active Area.................................................15
B
Backlight ....................................................15
Brightness..................................................15
C
Certifications ..............................................81
Contrast Ratio............................................15
D
Driver .........................................................69
Drivers
PCI/ISA Expansion Card .......................37
Precautions............................................18
Preinstalled Components ......................23
Prerequisites..........................................18
Remove the CPU Card Clamp ..............26
Remove the Drive Bracket ....................28
Remove the Drive Slot Blank Plate .......28
Remove the Dual CPU Card Clamp &
Drive Bay Stabilizer Bracket..............26
Remove the Top Cover..........................25
User Installed Components ...................23
L
LCD Specifications.....................................15
M
Touch Screen ........................................70
F
Features.......................................................2
I
Input Current..............................................16
Inrush Current............................................16
