IEI Integration LVDS24-01 User Manual

F166
LVDS24-01-R10 V1.01
Jumper setting & Connection Rev: 1.01
1
Appendix
Jumper setting............................................................................................... 3
1.1 LVDS Data Format Selection .........................................................4
1.2 Input Channel Selection ................................................................. 4
1.3 Output Channel Selection ..............................................................5
1.4 Mend bit setting ................................................................................5
Connection .....................................................................................................6
2.1 LCD Panel LVDS Interface Connector (LVDS1_IN)...................8
2.2 LCD Panel LVDS Interface Connector (LVDS2_OUT)............... 9
2.3 Power Source Connector ..............................................................10
2
1
Jumper setting
ITEM
1.1 J_PID1 LVDS Data Format setting
1.2 J_PID2 Input Channel Selection
1.3 J_PID3 Output Channel Selection
1.4 J_PID4 Mend bit setting
Prepared by : Denny Yang
Checked by : Denny Yang
PM : Ian Hsu
Project Leader : Mercy Chang
Table of Jumpers
LABEL FUNCTION
3
1.1 LVDS Data Format Selection
To choice LVDS data format (you can get the information from LVDS panel spec).
J_PID1 : Clear CMOS Setup
J_PID1 DESCRIPTION
Short 1-2 (default)* Short 2-3
3 2 1
24.1
24.0
1.2 Input Channel Selection
To choice the input signal,18bits or 36bits.
J_PID2 : Input Channel Selection J_PID2 DESCRIPTION
Short 1-2 (default)* Short 2-3 18bits(single channel)
4
36bits(dual channel)
3 2 1
1.3 Output Channel Selection
To choice the output signal,24bits or 48bits.
J_PID3 : Output Channel Selection J_PID3 DESCRIPTION
Short 1-2 (default)*
48bits(dual channel)
Short 2-3 24bits(single channel)
3 2 1
1.4 Mend bit setting
18bit or 36 bit expanded 24bit or 48bit from 0 or 1
J_PID4 : Output Channel Selection J_PID4 DESCRIPTION
Short 1-2 (default)* Short 2-3
3 2 1
1bit
0bit
5
2
Connection
This chapter describes how to connect peripherals, switches and indicators to the LVDS24-01-R10 V1.01 board.
6
Table of Connectors
ITEM
2.1 LVDS1_IN LVDS Panel Connector
2.2 LVDS2_OUT LVDS Panel Connector
2.3 CN1 Power Connector
LABEL FUNCTION
7
2.1 LCD Panel LVDS Interface Connector (LVDS1_IN)
The product equipped with LVDS interface connector to provide high resolution color display.
LVDS1_IN: LVDS Connector
PIN NO. DESCRIPTION PIN NO.
1 GND1 2 GND2 3 A_Y0 4 A_Y0# 5 A_Y1 6 A_Y1# 7 A_Y2 8 A_Y2#
9 A_CK 10 A_CK# 11 A_Y3 12 A_Y3# 13 GND3 14 GND4 15 B_Y0 16 B_Y0# 17 B_Y1 18 B_Y1# 19 B_Y2 20 B_Y2# 21 B_CK 22 B_CK# 23 B_Y3 24 B_Y3# 25 GND5 26 GND6 27 VCC_LCD 28 VCC_LCD 29 VCC_LCD 30 VCC_LCD
DESCRIPTION
8
2.2 LCD Panel LVDS Interface Connector (LVDS2_OUT)
The product equipped with LVDS interface connector to provide high resolution color display.
LVDS2_OUT: LVDS Connector
PIN NO. DESCRIPTION PIN NO.
1 GND1 2 GND2
3 A_Y0 4 A_Y0#
5 A_Y1 6 A_Y1#
7 A_Y2 8 A_Y2#
9 A_CK 10 A_CK# 11 A_Y3 12 A_Y3# 13 GND3 14 GND4 15 B_Y0 16 B_Y0# 17 B_Y1 18 B_Y1# 19 B_Y2 20 B_Y2# 21 B_CK 22 B_CK# 23 B_Y3 24 B_Y3# 25 GND5 26 GND6 27 VCC_LCD 28 VCC_LCD 29 VCC_LCD 30 VCC_LCD
DESCRIPTION
9
2.3 Power Source Connector
The product supports the ATX power. It provide +5V Power.
••••CN1 :POWER Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 NC 2 GND 3 +5V
CN1 & CN2
1 2 3
