IEI Integration C604EP User Manual

IMBA-C604EP ATX Server Board
MODEL:
IMBA-C604EP
ATX Server Board for 32nm LGA2011 Intel® Xeon® E5 Series
CPU, Intel® C206 Chipset, DDR3, VGA, Dual Intel®
USB 3.0, HD Audio and RoHS
User Manual
Rev. 1.01 – 24 April, 2014
Page i
IMBA-C604EP ATX Server Board
Revision
Date Version Changes
24 April, 2014 1.01 Modified LAN pinouts
Updated Section
25 February, 2013 1.00 Initial release
2.4: Optional Items
Page ii
IMBA-C604EP ATX Server Board
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
Copyright
reserved. No part of this manual may be reproduced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification purposes only and may be trademarks and/or registered trademarks of their respective owners.
Page iii
IMBA-C604EP ATX Server Board
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 FEATURES................................................................................................................... 3
1.3 CONNECTORS ............................................................................................................. 4
1.4 DIMENSIONS............................................................................................................... 5
1.5 DATA FLOW................................................................................................................ 6
1.6 TECHNICAL SPECIFICATIONS ...................................................................................... 7
2 PACKING LIST........................................................................................................... 10
2.1 ANTI-STATIC PRECAUTIONS.......................................................................................11
2.2 UNPACKING PRECAUTIONS........................................................................................11
2.3 PACKING LIST........................................................................................................... 12
2.4 OPTIONAL ITEMS...................................................................................................... 13
3 CONNECTORS ........................................................................................................... 14
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 15
3.1.1 IMBA-C604EP Layout..................................................................................... 15
3.1.2 Peripheral Interface Connectors ..................................................................... 16
3.1.3 External Interface Panel Connectors............................................................... 17
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 18
3.2.1 +12V Power Connector................................................................................... 18
3.2.2 ATX Power Connector ..................................................................................... 18
3.2.3 Battery Connector............................................................................................ 20
3.2.4 Chassis Intrusion Connector............................................................................ 20
3.2.5 DDR3 DIMM Slots........................................................................................... 21
3.2.6 Digital I/O Connector...................................................................................... 22
3.2.7 Fan Connector (CPU)...................................................................................... 23
3.2.8 Fan Connectors (System)................................................................................. 24
3.2.9 Front Panel Audio Connector.......................................................................... 25
3.2.10 Front Panel Connector.................................................................................. 26
3.2.11 I2C Connector................................................................................................ 27
Page iv
IMBA-C604EP ATX Server Board
3.2.12 PCIe x8 Slots.................................................................................................. 28
3.2.13 PMBus Connector.......................................................................................... 29
3.2.14 SAS 3Gb/s Drive Connectors......................................................................... 30
3.2.15 SAS LED Connector....................................................................................... 31
3.2.16 SAS SMBus Connector................................................................................... 31
3.2.17 SATA 3Gb/s Drive Connectors....................................................................... 32
3.2.18 SATA 6Gb/s Drive Connectors....................................................................... 33
3.2.19 SMBus Connector .......................................................................................... 34
3.2.20 SPI ROM Connector...................................................................................... 35
3.2.21 TPM Connector.............................................................................................. 36
3.2.22 USB 2.0 Connectors....................................................................................... 37
3.2.23 USB 2.0 Connector (Type A).......................................................................... 38
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 39
3.3.1 Audio Connector .............................................................................................. 39
3.3.2 Ethernet and USB 2.0 Connectors................................................................... 40
3.3.3 Ethernet and USB 3.0 Connectors................................................................... 41
3.3.4 Keyboard and Mouse Connector..................................................................... 42
3.3.5 Serial Port and VGA Connector...................................................................... 43
3.3.6 USB 2.0 Connector .......................................................................................... 44
4 INSTALLATION ......................................................................................................... 45
4.1 ANTI-STATIC PRECAUTIONS...................................................................................... 46
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 46
4.2.1 Socket LGA2011 CPU Installation .................................................................. 48
4.2.2 Socket LGA2011 Cooling Kit Installation........................................................ 51
4.2.3 DIMM Installation........................................................................................... 52
4.3 JUMPER SETTINGS .................................................................................................... 54
4.3.1 AT /ATX Power Mode Selection Jumper........................................................... 55
4.3.2 Clear CMOS Jumper........................................................................................ 55
4.3.3 USB Power Selection Jumpers......................................................................... 56
4.4 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 57
4.4.1 SATA Drive Connection ................................................................................... 57
4.4.2 Dual-Port USB Cable with Slot Bracket (Optional)........................................ 59
4.5 EXTERNAL PERIPHERAL INTERFACE CONNECTION ................................................... 60
4.5.1 Audio Connector .............................................................................................. 60
Page v
4.5.2 LAN Connection............................................................................................... 61
4.5.3 Serial Device Connection ................................................................................ 62
4.5.4 USB Connection (Dual Connector)................................................................. 63
4.5.5 VGA Monitor Connection ................................................................................ 64
4.6 INSTALLING USB 3.0 DRIVER DURING WINDOWS® 7 OS INSTALLATION................. 65
5 BIOS.............................................................................................................................. 69
5.1 INTRODUCTION......................................................................................................... 70
5.1.1 Starting Setup................................................................................................... 70
5.1.2 Using Setup...................................................................................................... 70
5.1.3 Getting Help..................................................................................................... 71
5.1.4 Unable to Reboot after Configuration Changes.............................................. 71
5.1.5 BIOS Menu Bar................................................................................................ 71
5.2 MAIN........................................................................................................................ 72
5.3 ADVANCED............................................................................................................... 73
IMBA-C604EP ATX Server Board
5.3.1 ACPI Settings................................................................................................... 73
5.3.2 RTC Wake Settings........................................................................................... 75
5.3.3 T rusted Computing........................................................................................... 76
5.3.4 CPU Configuration.......................................................................................... 77
5.3.5 SATA Configuration ......................................................................................... 79
5.3.6 SAS Configuration ........................................................................................... 80
5.3.7 USB Configuration........................................................................................... 80
5.3.8 F81866 Super IO Configuration...................................................................... 82
5.3.8.1 Serial Port 1 Configuration....................................................................... 83
5.3.9 F81866 H/W Monitor....................................................................................... 84
5.3.9.1 Smart Fan Mode Configuration................................................................ 85
5.3.10 Serial Port Console Redirection.................................................................... 86
5.3.11 iEi Feature...................................................................................................... 89
5.3.12 Main Configuration Page.............................................................................. 90
5.3.12.1 NIC Configuration.................................................................................. 91
5.4 CHIPSET ................................................................................................................... 92
5.4.1 North Bridge .................................................................................................... 93
5.4.1.1 NB PCIe Configuration............................................................................. 94
5.4.1.2 Memory Configuration ............................................................................. 95
5.4.2 South Bridge..................................................................................................... 95
Page vi
IMBA-C604EP ATX Server Board
5.5 SERVER MANAGEMENT............................................................................................ 97
5.5.1 Bmc Self Test Log........................................................................................... 100
5.5.2 System Event Log........................................................................................... 101
5.5.3 BMC Network Configuration......................................................................... 103
5.6 BOOT...................................................................................................................... 104
5.7 SECURITY............................................................................................................... 106
5.8 SAVE & EXIT.......................................................................................................... 107
6 SOFTWARE DRIVERS............................................................................................ 109
6.1 AVAILABLE SOFTWARE DRIVERS .............................................................................110
6.2 SOFTWARE INSTALLATION.......................................................................................110
6.3 CHIPSET DRIVER INSTALLATION..............................................................................111
6.4 GRAPHICS DRIVER INSTALLATION...........................................................................114
6.5 LAN DRIVER INSTALLATION...................................................................................117
6.6 AUDIO DRIVER INSTALLATION ............................................................................... 121
6.7 INTEL® RAPID STORAGE TECHNOLOGY DRIVER INSTALLATION ............................ 123
6.8 USB 3.0 DRIVER INSTALLATION ............................................................................ 126
6.9 ISMM INSTALLATION............................................................................................. 129
A BIOS OPTIONS ........................................................................................................ 134
B ONE KEY RECOVERY........................................................................................... 137
B.1 ONE KEY RECOVERY INTRODUCTION .................................................................... 138
B.1.1 System Requirement....................................................................................... 139
B.1.2 Supported Operating System......................................................................... 140
B.2 SETUP PROCEDURE FOR WINDOWS........................................................................ 141
B.2.1 Hardware and BIOS Setup ............................................................................ 142
B.2.2 Create Partitions........................................................................................... 142
B.2.3 Install Operating System, Drivers and Applications..................................... 146
B.2.4 Build-up Recovery Partition.......................................................................... 147
B.2.5 Create Factory Default Image....................................................................... 149
B.3 AUTO RECOVERY SETUP PROCEDURE.................................................................... 154
B.4 SETUP PROCEDURE FOR LINUX.............................................................................. 159
B.5 RECOVERY TOOL FUNCTIONS ................................................................................ 162
B.5.1 Factory Restore............................................................................................. 164
B.5.2 Backup System............................................................................................... 165
Page vii
B.5.3 Restore Your Last Backup.............................................................................. 166
B.5.4 Manual........................................................................................................... 167
B.6 RESTORE SYSTEMS FROM A LINUX SERVER THROUGH LAN.................................. 168
B.6.1 Configure DHCP Server Settings.................................................................. 169
B.6.2 Configure TFTP Settings ............................................................................... 170
B.6.3 Configure One Key Recovery Server Settings............................................... 171
B.6.4 Start the DHCP, TFTP and HTTP................................................................. 172
B.6.5 Create Shared Directory................................................................................ 172
B.6.6 Setup a Client System for Auto Recovery...................................................... 173
B.7 OTHER INFORMATION ............................................................................................ 176
B.7.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller....................... 176
B.7.2 System Memory Requirement ........................................................................ 178
C TERMINOLOGY ..................................................................................................... 179
D DIGITAL I/O INTERFACE..................................................................................... 183
IMBA-C604EP ATX Server Board
D.1 INTRODUCTION...................................................................................................... 184
D.2 DIO CONNECTOR PINOUTS ................................................................................... 184
D.3 ASSEMBLY LANGUAGE SAMPLES........................................................................... 185
D.3.1 Enable the DIO Input Function .................................................................... 185
D.3.2 Enable the DIO Output Function.................................................................. 185
E WA TCHDOG TIMER............................................................................................... 186
F INTEL® MATRIX STORAGE MANAGER.......................................................... 189
F.1 INTRODUCTION....................................................................................................... 190
F.1.1 Precautions .................................................................................................... 190
F.2 FEA TURES AND BENEFITS ....................................................................................... 191
F.3 ACCESSING THE INTEL® MATRIX STORAGE MANAGER.......................................... 191
F.4 INST ALLING THE OPERATING SYSTEM TO THE RAID ARRAY.................................. 192
G HAZARDOUS MATERIALS DISCLOSURE....................................................... 193
G.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY..................................... 194
Page viii
IMBA-C604EP ATX Server Board
List of Figures
Figure 1-1: IMBA-C604EP ..............................................................................................................2
Figure 1-2: Connectors ..................................................................................................................4
Figure 1-3: IMBA-C604EP Dimensions (mm)...............................................................................5
Figure 1-4: Data Flow Diagram......................................................................................................6
Figure 3-1: Connectors and Jumpers.........................................................................................15
Figure 3-2: +12V Power Connector Location.............................................................................18
Figure 3-3: ATX Power Connector Pinout Location..................................................................19
Figure 3-4: Battery Connector Locations...................................................................................20
Figure 3-5: Chassis Intrusion Connector Location...................................................................21
Figure 3-6: DDR3 DIMM Slot Locations......................................................................................22
Figure 3-7: Digital I/O Connector Location ................................................................................23
Figure 3-8: CPU Fan Connector Location..................................................................................24
Figure 3-9: System Fan Connector Locations...........................................................................25
Figure 3-10: Front Panel Audio Connector Location................................................................26
Figure 3-11: Front Panel Connector Location ...........................................................................27
Figure 3-12: I2C Connector Location..........................................................................................28
Figure 3-13: PCIe x8 Slot Locations ...........................................................................................29
Figure 3-14: PMBus Connector Location...................................................................................29
Figure 3-15: SAS 3Gb/s Drive Connector Locations.................................................................30
Figure 3-16: SAS LED Connector Location ...............................................................................31
Figure 3-17: SAS SMBus Connector Location ..........................................................................32
Figure 3-18: SATA 3Gb/s Drive Connector Locations..............................................................33
Figure 3-19: SATA 6Gb/s Drive Connector Locations..............................................................34
Figure 3-20: SMBus Connector Location...................................................................................35
Figure 3-21: SPI ROM Connector Location................................................................................36
Figure 3-22: TPM Connector Location........................................................................................36
Figure 3-23: USB 2.0 Connector Pinout Locations...................................................................37
Figure 3-24: USB 2.0 Connector (Type A) Location..................................................................38
Figure 3-25: External Peripheral Interface Connector..............................................................39
Figure 3-26: Audio Connector.....................................................................................................39
Page ix
Figure 3-27: Ethernet Connector.................................................................................................40
Figure 3-28: Ethernet Connector.................................................................................................41
Figure 3-29: RS-232 Serial Port Connector Pinouts..................................................................43
Figure 3-30: VGA Connector .......................................................................................................44
Figure 4-1: Disengage the CPU Socket Load Levers................................................................48
Figure 4-2: Remove the Protective Cover..................................................................................49
Figure 4-3: Insert the Socket LGA2011 CPU..............................................................................50
Figure 4-4: Close the Socket LGA2011 ......................................................................................50
Figure 4-5: Cooling Kit Support Bracket....................................................................................52
Figure 4-6: DIMM Installation.......................................................................................................53
Figure 4-7: AT/ATX Power Mode Selection Jumper Location..................................................55
Figure 4-8: Clear CMOS Jumper Location .................................................................................56
Figure 4-9: USB Power Selection Jumper Locations................................................................57
Figure 4-10: SATA Drive Cable Connection...............................................................................58
IMBA-C604EP ATX Server Board
Figure 4-11: SATA Power Drive Connection..............................................................................59
Figure 4-12: Dual USB Cable Connection..................................................................................60
Figure 4-13: Audio Connector.....................................................................................................61
Figure 4-14: LAN Connection......................................................................................................62
Figure 4-15: Serial Device Connection.......................................................................................63
Figure 4-16: USB Connection......................................................................................................64
Figure 4-17: VGA Connector .......................................................................................................65
Figure 4-18: Install Now ...............................................................................................................66
Figure 4-19: Load Driver..............................................................................................................66
Figure 4-20: Browse for Folder ...................................................................................................67
Figure 4-21: Select the ASMedia XHCI Controller Driver..........................................................67
Figure 4-22: Confirm the Driver File ...........................................................................................68
Figure 4-23: Select the USB Root Hub Driver............................................................................68
Figure 6-1: Chipset Driver Welcome Screen........................................................................... 111
Figure 6-2: Chipset Driver License Agreement...................................................................... 112
Figure 6-3: Chipset Driver Read Me File ................................................................................. 113
Figure 6-4: Chipset Driver Setup Operations ......................................................................... 113
Figure 6-5: Chipset Driver Installation Finish Screen............................................................ 114
Figure 6-6: Graphics Driver Welcome Screen........................................................................ 115
Figure 6-7: Ready to Install the Program ................................................................................ 115
Figure 6-8: Graphics Driver Installation Status...................................................................... 116
Page x
IMBA-C604EP ATX Server Board
Figure 6-9: Graphics Driver Installation Finish Screen ......................................................... 116
Figure 6-10: Windows Control Panel....................................................................................... 117
Figure 6-11: System Control Panel.......................................................................................... 117
Figure 6-12: Device Manager List ............................................................................................ 118
Figure 6-13: Update Driver Software Window ........................................................................ 119
Figure 6-14: Locate Driver Files............................................................................................... 119
Figure 6-15: LAN Driver Installation ........................................................................................ 120
Figure 6-16: LAN Driver Installation Complete....................................................................... 120
Figure 6-17: InstallShield Wizard Welcome Screen............................................................... 121
Figure 6-18: Audio Driver Software Configuration................................................................. 122
Figure 6-19: Restart the Computer .......................................................................................... 122
Figure 6-20: SATA RAID Driver Welcome Screen.................................................................. 123
Figure 6-21: SATA RAID Driver Warning................................................................................. 124
Figure 6-22: SATA RAID Driver License Agreement.............................................................. 124
Figure 6-23: SATA RAID Driver Read Me File......................................................................... 125
Figure 6-24: SATA RAID Driver Setup Operations................................................................. 125
Figure 6-25: SATA RAID Driver Installation Finish Screen ................................................... 126
Figure 6-26: USB 3.0 Driver Welcome Screen........................................................................ 127
Figure 6-27: USB 3.0 Driver License Agreement.................................................................... 128
Figure 6-28: USB 3.0 Driver Setup Operations....................................................................... 128
Figure 6-29: USB 3.0 Driver Installation Finish Screen ......................................................... 129
Figure 6-30: iSMM Installation Welcome Screen.................................................................... 130
Figure 6-31: iSMM License Agreement.................................................................................... 130
Figure 6-32: Customer Information.......................................................................................... 131
Figure 6-33: Setup Type............................................................................................................ 131
Figure 6-34: Ready to Install the Program.............................................................................. 132
Figure 6-35: iSMM Installation Status...................................................................................... 132
Figure 6-36: iSMM Installation Finish Screen......................................................................... 133
Figure B-1: IEI One Key Recovery Tool Menu........................................................................ 138
Figure B-2: Launching the Recovery Tool.............................................................................. 143
Figure B-3: Recovery Tool Setup Menu .................................................................................. 143
Figure B-4: Command Prompt ................................................................................................. 144
Figure B-5: Partition Creation Commands.............................................................................. 145
Figure B-6: Launching the Recovery Tool.............................................................................. 147
Figure B-7: Manual Recovery Environment for Windows..................................................... 147
Page xi
Figure B-8: Building the Recovery Partition........................................................................... 148
Figure B-9: Press Any Key to Continue.................................................................................. 148
Figure B-10: Press F3 to Boot into Recovery Mode............................................................... 149
Figure B-11: Recovery Tool Menu ........................................................................................... 149
Figure B-12: About Symantec Ghost Window........................................................................ 150
Figure B-13: Symantec Ghost Path ......................................................................................... 150
Figure B-14: Select a Local Source Drive ............................................................................... 151
Figure B-15: Select a Source Partition from Basic Drive ...................................................... 151
Figure B-16: File Name to Copy Image to ............................................................................... 152
Figure B-17: Compress Image.................................................................................................. 152
Figure B-18: Image Creation Confirmation............................................................................. 153
Figure B-19: Image Creation Complete................................................................................... 153
Figure B-20: Image Creation Complete................................................................................... 153
Figure B-21: Press Any Key to Continue................................................................................ 154
IMBA-C604EP ATX Server Board
Figure B-22: Auto Recovery Utility.......................................................................................... 155
Figure B-23: Disable Automatically Restart............................................................................ 155
Figure B-24: Launching the Recovery Tool............................................................................ 156
Figure B-25: Auto Recovery Environment for Windows ....................................................... 156
Figure B-26: Building the Auto Recovery Partition................................................................ 157
Figure B-27: Factory Default Image Confirmation ................................................................. 157
Figure B-28: Image Creation Complete................................................................................... 158
Figure B-29: Press any key to continue.................................................................................. 158
Figure B-30: IEI Feature ............................................................................................................ 159
Figure B-31: Partitions for Linux.............................................................................................. 160
Figure B-32: System Configuration for Linux......................................................................... 161
Figure B-33: Access menu.lst in Linux (Text Mode).............................................................. 161
Figure B-34: Recovery Tool Menu ........................................................................................... 162
Figure B-35: Recovery Tool Main Menu.................................................................................. 163
Figure B-36: Restore Factory Default...................................................................................... 164
Figure B-37: Recovery Complete Window.............................................................................. 164
Figure B-38: Backup System.................................................................................................... 165
Figure B-39: System Backup Complete Window ................................................................... 165
Figure B-40: Restore Backup................................................................................................... 166
Figure B-41: Restore System Backup Complete Window..................................................... 166
Figure B-42: Symantec Ghost Window ................................................................................... 167
Page xii
IMBA-C604EP ATX Server Board
Figure B-43: Disable Automatically Restart............................................................................ 174
Page xiii
IMBA-C604EP ATX Server Board
List of Tables
Table 1-1: IMBA-C604EP Specifications.......................................................................................9
Table 2-1: Packing List.................................................................................................................13
Table 2-2: Optional Items.............................................................................................................13
Table 3-1: Peripheral Interface Connectors...............................................................................17
Table 3-2: Rear Panel Connectors..............................................................................................17
Table 3-3: +12V Power Connector Pinouts................................................................................18
Table 3-4: ATX Power Connector Pinouts .................................................................................19
Table 3-5: Chassis Intrusion Connector Pinouts......................................................................21
Table 3-6: Digital I/O Connector Pinouts....................................................................................23
Table 3-7: CPU Fan Connector Pinouts......................................................................................24
Table 3-8: System Fan Connector Pinouts................................................................................25
Table 3-9: Front Panel Audio Connector Pinouts .....................................................................26
Table 3-10: Front Panel Connector Pinouts...............................................................................27
Table 3-11: I2C Connector Pinouts.............................................................................................28
Table 3-12: PMBus Connector Pinouts ......................................................................................30
Table 3-13: SAS 3Gb/s Drive Connector Pinouts......................................................................30
Table 3-14: SAS LED Connector Pinouts...................................................................................31
Table 3-15: SAS SMBus Connector Pinouts..............................................................................32
Table 3-16: SATA 3Gb/s Drive Connector Pinouts....................................................................33
Table 3-17: SATA 6Gb/s Drive Connector Pinouts....................................................................34
Table 3-18: SMBus Connector Pinouts ......................................................................................35
Table 3-19: SPI ROM Connector Pinouts ...................................................................................36
Table 3-20: TPM Connector Pinouts...........................................................................................37
Table 3-21: USB 2.0 Connector Pinouts.....................................................................................38
Table 3-22: USB 2.0 Connector (Type A) Pinouts .....................................................................38
Table 3-23: LAN2 Pinouts ............................................................................................................40
Table 3-24: Connector LEDs........................................................................................................40
Table 3-25: USB 2.0 Port Pinouts................................................................................................41
Table 3-26: LAN Pinouts ..............................................................................................................41
Table 3-27: Connector LEDs........................................................................................................41
Page xiv
IMBA-C604EP ATX Server Board
Table 3-28: USB 3.0 Port Pinouts................................................................................................42
Table 3-29: PS/2 Connector Pinouts...........................................................................................42
Table 3-30: RS-232 Serial Port Connector Pinouts...................................................................43
Table 3-31: VGA Connector Pinouts...........................................................................................43
Table 3-32: USB 2.0 Port Pinouts................................................................................................44
Table 4-1: Jumpers.......................................................................................................................54
Table 4-2: AT/ATX Power Mode Selection Jumper Settings....................................................55
Table 4-3: Clear CMOS Jumper Settings....................................................................................56
Table 4-4: USB Power Selection Jumper Settings....................................................................56
Table 5-1: BIOS Navigation Keys................................................................................................71
Page xv
IMBA-C604EP ATX Server Board
BIOS Menus
BIOS Menu 1: Main.......................................................................................................................72
BIOS Menu 2: Advanced..............................................................................................................73
BIOS Menu 3: ACPI Settings .......................................................................................................74
BIOS Menu 4: RTC Wake Settings..............................................................................................75
BIOS Menu 5: Trusted Computing..............................................................................................76
BIOS Menu 6: CPU Configuration...............................................................................................77
BIOS Menu 7: SATA Configuration.............................................................................................79
BIOS Menu 8: SAS Configuration ...............................................................................................80
BIOS Menu 9: USB Configuration...............................................................................................81
BIOS Menu 10: F81866 Super IO Configuration........................................................................82
BIOS Menu 11: Serial Port 1 Configuration Menu.....................................................................83
BIOS Menu 12: F81866 H/W Monitor...........................................................................................84
BIOS Menu 13: Smart Fan Mode Configuration ........................................................................85
BIOS Menu 14: Serial Port Console Redirection.......................................................................86
BIOS Menu 15: IEI Feature...........................................................................................................89
BIOS Menu 16: Main Configuration Page...................................................................................90
BIOS Menu 17: NIC Configuration ..............................................................................................91
BIOS Menu 18: Chipset................................................................................................................92
BIOS Menu 19: North Bridge.......................................................................................................93
BIOS Menu 20: NB PCIe Configuration ......................................................................................94
BIOS Menu 21: Memory Configuration.......................................................................................95
BIOS Menu 22: South Bridge.......................................................................................................95
BIOS Menu 23: Server Management...........................................................................................97
BIOS Menu 24: BMC Self Test Log .......................................................................................... 100
BIOS Menu 25: System Event Log........................................................................................... 101
BIOS Menu 26: BMC Network Configuration.......................................................................... 103
BIOS Menu 27: Boot.................................................................................................................. 104
BIOS Menu 28: Security............................................................................................................ 106
BIOS Menu 29: Save & Exit....................................................................................................... 107
Page xvi
IMBA-C604EP ATX Server Board
Chapter
1

1 Introduction

Page 1

1.1 Introduction

IMBA-C604EP ATX Server Board
Figure 1-1: IMBA-C604EP
The IMBA-C604EP is an ATX server board. It accepts a Socket LGA2011 Intel® Xeon® E5 Series processor (up to 8 cores) and supports eight 240-pin 1600/1333 MHz DDR3 DIMM modules.
The IMBA-C604EP is designed to support PCIe Gen 3.0 specifications with up to 40 lanes at 8 GT/s I/O bandwidth. In addition, the IMBA-C604EP provides server management function through the IPMI 2.0 and iKVM support.
The IMBA-C604EP is equipped with one VGA display output. Expansion and I/O include four PCIe x8 slots, two USB 3.0, eleven USB 2.0, four SAS 3Gb/s connectors, two SATA 6Gb/s connectors, four SATA 3Gb/s connectors and one COM port.
Page 2
IMBA-C604EP ATX Server Board

1.2 Features

Some of the IMBA-C604EP server board features are listed below:
ATX form factor  LGA2011 CPU socket supporting Intel® Xeon® E5 Series processor (up to 8
cores)
Intel® C604 chipset Quad-channel memory architecture (two DIMMs per channel) with
1600/1333 MHz DDR3 SDRAM support up to 64 GB of UDIMMs, 128 GB of RDIMMs or 256 GB of LRDIMMs
Dual Intel® PCIe GbE controller  Server management function through the IPMI 2.0 and iKVM support  Supports USB 3.0  Supports SAS 3Gb/s, SATA 6Gb/s and SATA 3Gb/s with RAID function  Supports PCI Express Generation 3.0 up to 40 lanes at 8 GT/s I/O bandwidth  Four PCIe x8 slots  One external RS-232 serial port  High definition audio  RoHS compliant
Page 3

1.3 Connectors

The connectors on the IMBA-C604EP are shown in the figure below.
IMBA-C604EP ATX Server Board
Figure 1-2: Connectors
Page 4
IMBA-C604EP ATX Server Board

1.4 Dimensions

The main dimensions of the IMBA-C604EP are shown in the diagram below.
Figure 1-3: IMBA-C604EP Dimensions (mm)
Page 5

1.5 Data Flow

7Figure 1-4 shows the data flow between the system chipset, the CPU and other
components installed on the server board.
IMBA-C604EP ATX Server Board
Figure 1-4: Data Flow Diagram
Page 6
IMBA-C604EP ATX Server Board

1.6 Technical Specifications

The IMBA-C604EP technical specifications are listed below.
Specification/Model IMBA-C604EP Form Factor CPU Supported
Chipset Memory
Graphics Engine
Ethernet Controllers Server Management
Audio
ATX LGA2011 Intel® Xeon® E5-16xx, E5-26xx or E5-46xx Series CPU
(up to eight cores) Intel® C604 Eight 240-pin 1600/1333 MHz DDR3 SDRAM ECC UDIMMs or
non-ECC RDIMMs/LRDIMMs support (system max. 64 GB UDIMMs/ 128 GB RDIMMs/256 GB LRDIMMs)
Quad-channel memory architecture (2 DIMMs per channel) ASPEED AST2300
PCIe VGA/2D controller, 1920x1200@60Hz 32bpp Dual Intel® 82574L PCIe GbE controller One RJ-45 port for Intelligent Platform Management Interface (IPMI)
v2.0 (LAN2) IPMI 2.0 with Virtual Media over LAN and IKVM-over-LAN support
Realtek ALC662 HD audio codec (line-out, mic-in)
BIOS Super I/O Controller Watchdog Timer Expansions I/O Interface Connectors Audio Connectors
Digital I/O Display Output Ethernet
UEFI BIOS Fintek F81866 Software programmable supports 1~2 55 sec. system reset Four PCIe x8 slots
Two external audio jacks (line-out, mic-in) One internal front panel audio connector (10-pin header)
8-bit, 4-bit input/4-bit output One VGA (driver from AST2300 ) Two RJ-45 GbE ports (LAN2 supports IPMI 2.0)
Page 7
Specification/Model IMBA-C604EP
IMBA-C604EP ATX Server Board
Fan Connectors
Front Panel
I2C Keyboard/Mouse PSMI (PMBus) Serial ATA
Serial Attached SCSI Serial Ports SMBus TPM USB Ports
One 4-pin CPU fan connector Five 4-pin system fan connectors
One 24-pin header (power LED, HDD LED, LAN LED, speaker, power button, reset button)
One 4-pin wafer connector Dual PS/2 port One 5-pin box header Two SATA 6Gb/s connectors (RAID 0, 1, 10, 5 support)
Four SATA 3Gb/s connectors (RAID 0, 1, 10, 5 support) Four SAS 3Gb/s connectors (RAID 0, 1, 10 support) One external RS-232 serial port One 4-pin wafer connector One via 20-pin header Two external USB 3.0 ports on rear IO
Four external USB 2.0 ports on rear IO Six internal USB 2.0 ports by three pin headers One internal USB 2.0 port by Type A
Environmental and Power Specifications Power Supply Power Consumption
Operating Temperature
Storage Temperature
Humidity
AT/ATX power supply Vcore_12V@5.86A, 12V@1.03A, 5V@1.72A, 3.3V@1.01A,
5VSB@0.47A (2.1 GHz Intel® Xeon® E5-2658 CPU with four 4 GB 1333 MHz DDR3 memory)
-10ºC ~ 60ºC
-20ºC ~ 70ºC
5% ~ 95% (non-condensing)
Page 8
IMBA-C604EP ATX Server Board
Specification/Model IMBA-C604EP Physical Specifications Dimensions Weight (GW/NW) Table 1-1: IMBA-C604EP Specifications
244 mm x 305 mm 1200 g / 700 g
Page 9
IMBA-C604EP ATX Server Board
Chapter
2

2 Packing List

Page 10
IMBA-C604EP ATX Server Board

2.1 Anti-static Precautions

WARNING!
Static electricity can destroy certain electronics. Make sure to follow the ESD precautions to prevent damage to the product, and injury to the user.
Make sure to adhere to the following guidelines:
Wear an anti-static wristband: Wearing an anti-static wristband can prevent
electrostatic discharge.
Self-grounding: Touch a grounded conductor every few minutes to discharge
any excess static buildup.
Use an anti-static pad: When configuring any circuit board, place it on an
anti-static mat.
Only handle the edges of the PCB: Don't touch the surface of the server
board. Hold the server board by the edges when handling.

2.2 Unpacking Precautions

When the IMBA-C604EP is unpacked, please do the following:
Follow the antistatic guidelines above.  Make sure the packing box is facing upwards whe n opening.  Make sure all the packing list items are present.
Page 11

2.3 Packing List

NOTE:
If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the IMBA-C604EP was purchased from or contact an IEI sales representative directly by sending an email to 33sales@ieiworld.com.
The IMBA-C604EP is shipped with the following components:
Quantity Item and Part Number Image
1 IMBA-C604EP server board
IMBA-C604EP ATX Server Board
4 SATA cable
(P/N: 32000-062800-RS)
1 I/O shielding
(P/N: 45014-0039C0-00-RS)
1 Mini jumper pack
1 One Key Recovery CD
1 Utility CD
Page 12
IMBA-C604EP ATX Server Board
Quantity Item and Part Number Image
1 Quick Installation Guide
Table 2-1: Packing List

2.4 Optional Items

The following are optional components which may be separately purchased:
Item and Part Number Image
Dual-port USB cable with bracket (P/N: 19800-003100-300-RS)
SATA power cable (P/N: 32102-000100-200-RS)
High performance LGA2011 cooler kit (1U chassis compatible, 130W)
(P/N: CF-201 1A-RS) High performance LGA2011 cooler kit (2U chassis
compatible, 130W) (P/N: CF-201 1B-RS)
20-pin Infineon TPM module, S/W management tool, firmware v3.17
(P/N: TPM-IN01-R1 1)
Table 2-2: Optional Items
Page 13
IMBA-C604EP ATX Server Board
Chapter
3

3 Connectors

Page 14
IMBA-C604EP ATX Server Board

3.1 Peripheral Interface Connectors

This chapter details all the jumpers and connectors.

3.1.1 IMBA-C604EP Layout

The figure below shows all the connectors and jumpers.
Figure 3-1: Connectors and Jumpers
Page 15

3.1.2 Peripheral Interface Connectors

The table below lists all the connectors on the board.
Connector Type Label
+12V power source connector 8-pin Molex CPU12V1 ATX power connector 24-pin ATX ATX1 Battery holder CR2032 battery holder BAT1 Chassis intrusion connector 2-pin header JCHASSIS1
IMBA-C604EP ATX Server Board
DIMMA1, DIMMA2,
DDR3 DIMM slots DDR3 DIMM slot
Digital I/O connector 10-pin header DIO1 Fan connector (CPU) 4-pin wafer CPU_FAN1
Fan connectors (system) 4-pin wafer
Front panel audio connector 10-pin header FP_AUDIO1 Front panel connector 24-pin header SSI_F_PANEL1 I2C connector 4-pin wafer I2C_1
PCIe x8 slots PCIe x8 slot
DIMMB1, DIMMB2, DIMMC1, DIMMC2, DIMMD1, DIMMD2
SYS_FAN1, SYS_FAN2, SYS_FAN3, SYS_FAN4, SYS_FAN5
PCIEX8_SLOT1, PCIEX8_SLOT2, PCIEX8_SLOT3,
Page 16
PCIEX8_SLOT4,
PMBus connector 5-pin box header PMBUS1
SAS1, SAS2
SAS 3Gb/s drive connector 7-pin SAS connector
SAS3, SAS4
SAS LED connector 4-pin wafer SAS_LED1
IMBA-C604EP ATX Server Board
Connector Type Label
SAS SMBus connector 4-pin wafer SAS_SMBUS1
SATA 3Gb/s drive connector 7-pin SATA connector
SATA 6Gb/s drive connector 7-pin SATA connector SATA1, SATA2 SMBus connector 4-pin wafer SMBUS_1 SPI ROM connector 6-pin wafer JSPI1 TPM connector 20-pin header TPM1
USB 2.0 connectors 10-pin header
USB 2.0 connector (Type A) 4-pin Type A USB4
Table 3-1: Peripheral Interface Connectors
SATA3, SATA4, SATA5, SATA6
USB1, USB2, USB3

3.1.3 External Interface Panel Connectors

The table below lists the connectors on the external I/O panel.
Connector Type Label
Audio connector Audio jack AUDIO_CV1 Ethernet and USB 2.0 connectors RJ-45, USB 2.0 LAN2_USB_01_2 Ethernet and USB 3.0 connectors RJ-45, USB 3.0 LAN1_USB3_1 Keyboard and mouse connectors Dual PS/2 KBMS1 Serial port and VGA connector DB-9 male,
DB-15 female
USB 2.0 connectors USB 2.0 LAN2_USB_01_1
Table 3-2: Rear Panel Connectors
VGACOM1
Page 17

3.2 Internal Peripheral Connectors

The section describes all of the connectors on the IMBA-C604EP.

3.2.1 +12V Power Connector

CN Label: CPU12V1
IMBA-C604EP ATX Server Board
CN Type: CN Location: CN Pinouts:
The connector supports the +12V power supply.
Figure 3-2: +12V Power Connector Location
8-pin Molex See Figure 3-2 See Table 3-3
Pin Description Pin Description
1 GND 5 +12V 2 GND 6 +12V 3 GND 7 +12V 4 GND 8 +12V
Table 3-3: +12V Power Connector Pinouts

3.2.2 ATX Power Connector

CN Label: ATX1
24-pin A TX
Page 18
CN Type:
IMBA-C604EP ATX Server Board
See
CN Location: CN Pinouts:
Figure 3-3 Table 3-4
See
The ATX power connector connects to an ATX power supply.
Figure 3-3: ATX Power Connector Pinout Location
Pin Description Pin Description
1 +3.3V 13 +3.3V 2 +3.3V 14 -12V 3 GND 15 GND 4 +5V 16 -IO_PSON 5 GND 17 GND 6 +5V 18 GND 7 GND 19 GND 8 PWRGD_PS 20 NC 9 V_5P0_A 21 +5V 10 +12V 22 +5V 11 +12V 23 +5V 12 +3.3V 24 GND
Table 3-4: ATX Power Connector Pinouts
Page 19

3.2.3 Battery Connector

CAUTION:
Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery.
Dispose of used batteries according to instructions and local
IMBA-C604EP ATX Server Board
regulations.
CN Label: BAT1 CN Type: CN Location:
This is connected to the system battery. The battery provides power to the system clock to retain the time when power is turned off.
Battery holder
Figure 3-4
See
Figure 3-4: Battery Connector Locations

3.2.4 Chassis Intrusion Connector

CN Label: JCHASSIS1
2-pin header
Figure 3-5
See
Table 3-5
See
Page 20
CN Type: CN Location: CN Pinouts:
IMBA-C604EP ATX Server Board
The chassis intrusion connector connects to a chassis intrusion sensor or switch to detect the chassis intrusion event.
Figure 3-5: Chassis Intrusion Connector Location
Pin Description
1 CHASSIS_OPEN 2 GND
Table 3-5: Chassis Intrusion Connector Pinouts

3.2.5 DDR3 DIMM Slots

CN Label: DIMMA1, DIMMA2, DIMMB1, DIMMB2, DIMMC1, DIMMC2,
CN Type: CN Location:
The DIMM slots are for DDR3 DIMM memory modules.
NOTE:
When using only one DIMM for the system, always install it to the black slot (DIMMA1, DIMMB1, DIMMC1 or DIMMD1).
DIMMD1, DIMMD2
DDR3 DIMM slot See 7Figure 3-6
Page 21
IMBA-C604EP ATX Server Board
NOTE:
Installing the memory modules with the same memory size is highly recommended.
Figure 3-6: DDR3 DIMM Slot Locations

3.2.6 Digital I/O Connector

CN Label: DIO1 CN Type: CN Location: CN Pinouts:
The digital I/O connector provides programmable input and output for external devices. The digital I/O provides 4-bit output and 4-bit input.
10-pin header See Figure 3-7 See Table 3-6
Page 22
IMBA-C604EP ATX Server Board
Figure 3-7: Digital I/O Connector Location
Pin Description Pin Description
1 GND 2 VCC 3 Output 3 4 Output 2 5 Output 1 6 Output 0 7 Input 3 8 Input 2 9 Input 1 10 Input 0
Table 3-6: Digital I/O Connector Pinouts

3.2.7 Fan Connector (CPU)

CN Label: CPU_FAN1 CN Type: CN Location: CN Pinouts:
The fan connector attaches to a CPU cooling fan.
4-pin wafer See Figure 3-8 See Table 3-7
Page 23
Figure 3-8: CPU Fan Connector Location
IMBA-C604EP ATX Server Board
Pin Description
1 GND 2 +12V 3 FANIO1 4 PWM
Table 3-7: CPU Fan Connector Pinouts

3.2.8 Fan Connectors (System)

CN Label: SYS_FAN1, SYS_FAN2, SYS_FAN3, SYS_FAN4, SYS_FAN5 CN Type: CN Location: CN Pinouts:
Each fan connector attaches to a cooling fan.
4-pin wafer See Figure 3-9 See Table 3-8
Page 24
IMBA-C604EP ATX Server Board
Figure 3-9: System Fan Connector Locations
Pin Description
1 GND 2 +12V 3 FANIO1 4 PWM
Table 3-8: System Fan Connector Pinouts

3.2.9 Front Panel Audio Connector

CN Label: FP_AUDIO1 CN Type: CN Location: CN Pinouts:
This connector connects to speakers, a microphone and an audio input.
10-pin header
Figure 3-10
See
Table 3-9
See
Page 25
IMBA-C604EP ATX Server Board
Figure 3-10: Front Panel Audio Connector Location
Pin Description Pin Description
1 LMIC2_L 2 AUD GND 3 LMIC2_R 4 PRESENCE# 5 LLINE2-R 6 MIC2-JD 7 F_SENSE 8 NC 9 LLINE2-L 10 LINE2-JD
Table 3-9: Front Panel Audio Connector Pinouts

3.2.10 Front Panel Connector

CN Label: SSI_F_PANEL1 CN Type: CN Location: CN Pinouts:
The front panel connector connects to the indicator LEDs and buttons on the computer's front panel.
24-pin header See Figure 3-11 See Table 3-10
Page 26
IMBA-C604EP ATX Server Board
Figure 3-11: Front Panel Connector Location
Function Pin Description Function Pin Description
Power LED 1 +3.3V_DSW 2 +3.3V_DSW 3 NC 4 V_5P0_A 5 PWRLED# 6 ID_LED#_FP HDD LED 7 +3.3V 8 GR_LED_FP# 9 HDD_LED# 10 AM_LED_FP# Power Button 11 PWRBTN_SW#_C LAN1 LED 12 +3.3LAN1 13 GND 14 LAN1_LED#
Reset 15 EXTRST- 16
17 GND 18
19 ID_BT_FP# 20 CHASSIS_OPEN 21 +3.3V_DSW LAN2 LED 22 +3.3LAN2 23 NMI_BT_FP# 24 LAN2_LED#
SMB_FRU_T_3 VSB_DATA SMB_FRU_T_3 VSB_CLK
Table 3-10: Front Panel Connector Pinouts

3.2.11 I2C Connector

CN Label: I2C_1 CN Type:
4-pin wafer
Figure 3-12
CN Location: CN Pinouts:
See
Table 3-11
See
Page 27
The I2C connector is for system debug.
Figure 3-12: I2C Connector Location
IMBA-C604EP ATX Server Board
Pin Description
1 +5V_DUAL 2 I2C_DATA_GPIO 3 I2C_CLK_GPIO 4 GND
Table 3-11: I2C Connector Pinouts

3.2.12 PCIe x8 Slots

CN Label: PCIEX8_SLOT1, PCIEX8_SLOT2, PCIEX8_SLOT3, PCIEX8_SLOT4 CN Type: CN Location:
The PCIe x8 slots are for PCIe x8 expansion cards.
PCIe x8 slot
Figure 3-13
See
Page 28
IMBA-C604EP ATX Server Board
Figure 3-13: PCIe x8 Slot Locations

3.2.13 PMBus Connector

CN Label: PMBUS1 CN Type: CN Location: CN Pinouts:
The PMBus (Power Management Bus) connector provides slow-speed power management communications.
Figure 3-14: PMBus Connector Location
5-pin box header
Figure 3-14
See
Table 3-12
See
Pin Description
1 PMBUS_CLK 2 PMBUS_DAT
Page 29
Pin Description
3 PMBUS_ALERT# 4 GND 5 +3.3V
Table 3-12: PMBus Connector Pinouts

3.2.14 SAS 3Gb/s Drive Connectors

CN Label: SAS1, SAS2, SAS3, SAS4
IMBA-C604EP ATX Server Board
CN Type: CN Location: CN Pinouts:
7-pin SAS connector
Figure 3-18
See
Table 3-16
See
The SAS drive connectors can be connected to SAS drives and support up to 3Gb/s data transfer rate.
Figure 3-15: SAS 3Gb/s Drive Connector Locations
Pin Description Pin Description
Page 30
1 GND 5 RXN 2 TXP 6 RXP 3 TXN 7 GND 4 GND
Table 3-13: SAS 3Gb/s Drive Connector Pinouts
IMBA-C604EP ATX Server Board

3.2.15 SAS LED Connector

CN Label: SAS_LED1 CN Type: CN Location: CN Pinouts:
The SAS LED connector allows the SAS LED to be connected to the system.
4-pin wafer
Figure 3-16
See
Table 3-14
See
Figure 3-16: SAS LED Connector Location
Pin Description
1 GPIO_CLK1 2 SGPIO_LD1 3 SGPIO_DIN1 4 SGPIO_DO1
Table 3-14: SAS LED Connector Pinouts

3.2.16 SAS SMBus Connector

CN Label: SAS_SMBUS1 CN Type:
4-pin wafer
Page 31
See
CN Location: CN Pinouts:
The SAS SMBus (System Management Bus) connector provides low-speed system management communications for SAS.
Figure 3-17 Table 3-15
See
IMBA-C604EP ATX Server Board
Figure 3-17: SAS SMBus Connector Location
Pin Description
1 +3.3V L 2 SMB_SASCLK0 3 SMB_SASDATA0 4 GND
Table 3-15: SAS SMBus Connector Pinouts

3.2.17 SATA 3Gb/s Drive Connectors

CN Label: SATA3, SATA4, SATA5, SATA6 CN Type: CN Location: CN Pinouts:
7-pin SATA connector
Figure 3-18
See
Table 3-16
See
Page 32
The SATA drive connectors can be connected to SATA drives and support up to 3Gb/s data transfer rate.
IMBA-C604EP ATX Server Board
Figure 3-18: SATA 3Gb/s Drive Connector Locations
Pin Description Pin Description
1 GND 5 RXN 2 TXP 6 RXP 3 TXN 7 GND 4 GND
Table 3-16: SATA 3Gb/s Drive Connector Pinouts

3.2.18 SATA 6Gb/s Drive Connectors

CN Label: SATA1, SATA2 CN Type: CN Location: CN Pinouts:
The SATA drive connectors can be connected to SATA drives and support up to 6Gb/s data transfer rate.
7-pin SATA connector
Figure 3-19
See
Table 3-17
See
Page 33
Figure 3-19: SATA 6Gb/s Drive Connector Locations
IMBA-C604EP ATX Server Board
Pin Description Pin Description
1 GND 5 RXN 2 TXP 6 RXP 3 TXN 7 GND 4 GND
Table 3-17: SATA 6Gb/s Drive Connector Pinouts

3.2.19 SMBus Connector

CN Label: SMBUS_1 CN Type: CN Location: CN Pinouts:
The SMBus (System Management Bus) connector provides low-speed system management communications.
4-pin wafer
Figure 3-20
See
Table 3-18
See
Page 34
IMBA-C604EP ATX Server Board
Figure 3-20: SMBus Connector Location
Pin Description
1 +5V_DUAL 2 SMBCLK 3 SMBDATA 4 GND
Table 3-18: SMBus Connector Pinouts

3.2.20 SPI ROM Connector

CN Label: JSPI1 CN Type: CN Location: CN Pinouts:
The SPI connector is used to flash the BIOS.
6-pin wafer See Figure 3-21 See Table 3-19
Page 35
Figure 3-21: SPI ROM Connector Location
IMBA-C604EP ATX Server Board
Pin Description Pin Description
1 SPI_VCC 2 SPI_CS# 3 SPI_SO 4 SPI_CLK 5 SPI_SI 6 GND
Table 3-19: SPI ROM Connector Pinouts

3.2.21 TPM Connector

CN Label: TPM1 CN Type: CN Location: CN Pinouts:
The TPM connector connects to a TPM module.
20-pin header See Figure 3-22 See Table 3-20
Page 36
Figure 3-22: TPM Connector Location
IMBA-C604EP ATX Server Board
Pin Description Pin Description
1 LCLK 2 GND2 3 LERAME# 4 KEY 5 LRESRT# 6 +5V 7 LAD3 8 LAD2 9 +3V 10 LAD1 11 LAD0 12 GND3 13 SCL 14 SDA 15 SB3V 16 SERIRQ 17 GND1 18 GLKRUN# 19 LPCPD# 20 LDRQ#
Table 3-20: TPM Connector Pinouts

3.2.22 USB 2.0 Connectors

CN Label: USB1, USB2, USB3 CN Type: CN Location: CN Pinouts:
10-pin header See Figure 3-23 See Table 3-21
The USB connectors connect to USB 2.0/1.1 devices. Each pin header provides two USB
2.0/1.1 ports.
Figure 3-23: USB 2.0 Connector Pinout Locations
Page 37
Pin Description Pin Description
1 VCC 2 VCC 3 DATA- 4 DATA­5 DATA+ 6 DATA+ 7 GND 8 GND 9 KEY 10 NC
Table 3-21: USB 2.0 Connector Pinouts

3.2.23 USB 2.0 Connector (Type A)

CN Label: USB4
IMBA-C604EP ATX Server Board
CN Type: CN Location: CN Pinouts:
4-pin Type A
Figure 3-24
See
Table 3-22
See
The USB connector can be connected to a USB 2.0/1.1 device.
Figure 3-24: USB 2.0 Connector (Type A) Location
Pin Description
Page 38
1 VCC 2 DATA­3 DATA+ 4 GND
Table 3-22: USB 2.0 Connector (Type A) Pinouts
IMBA-C604EP ATX Server Board

3.3 External Peripheral Interface Connector Panel

The figure below shows the external peripheral interface connector (EPIC) panel. The EPIC panel consists of the following:
Figure 3-25: External Peripheral Interface Connector

3.3.1 Audio Connector

CN Label: AUDIO_CV1 CN Type: CN Location:
The audio jacks connect to external audio devices.
Line Out port (Lime): Connects to a head phone or a speaker. With
multi-channel configurations, this port can also connect to front speakers.
Microphone (Pink): Connects a microphone.
Figure 3-26: Audio Connector
Audio jack See Figure 3-25
Page 39

3.3.2 Ethernet and USB 2.0 Connectors

CN Label: LAN2_USB_01_2
IMBA-C604EP ATX Server Board
CN Type: CN Location: CN Pinouts:
RJ-45 and USB 2.0 ports See Figure 3-25 See Table 3-23 and Table 3-25
The LAN connector connects to a local network and supports IPMI 2.0.
Pin Description Pin Description
1 MDIA3- 5 MDIA2+ 2 MDIA3+ 6 MDIA1+ 3 MDIA1- 7 MDIA0­4 MDIA2- 8 MDIA0+
Table 3-23: LAN2 Pinouts
Figure 3-27: Ethernet Connector
LED Description LED Description
A on: linked
blinking: data is being sent/received
Table 3-24: Connector LEDs
The IMBA-C604EP has four USB 2.0 ports. Each USB 2.0 port can be connected to a USB 2.0/1.1 device.
B off: 10 Mb/s
green: 100 Mb/s orange: 1000 Mb/s
Page 40
IMBA-C604EP ATX Server Board
Pin Description Pin Description
1 VCC 2 DATA­3 DATA+ 4 GND
Table 3-25: USB 2.0 Port Pinouts

3.3.3 Ethernet and USB 3.0 Connectors

CN Label: LAN1_USB3_1 CN Type: CN Location: CN Pinouts:
RJ-45 and USB 3.0 ports See Figure 3-25 See Table 3-26 and Table 3-28
The LAN connector connects to a local network.
Pin Description Pin Description
1 MDIA3- 5 MDIA2+ 2 MDIA3+ 6 MDIA1+ 3 MDIA1- 7 MDIA0­4 MDIA2- 8 MDIA0+
Table 3-26: LAN Pinouts
Figure 3-28: Ethernet Connector
LED Description LED Description
A on: linked
blinking: data is being sent/received
Table 3-27: Connector LEDs
B off: 10 Mb/s
green: 100 Mb/s orange: 1000 Mb/s
Page 41
IMBA-C604EP ATX Server Board
The IMBA-C604EP has two external USB 3.0 ports. Each USB 3.0 port can be connected to a USB device.
Pin Description Pin Description
1 VBUS 2 D­3 D+ 4 GND 5 STDA_SSRX_N 6 STDA_SSRX_P 7 GND_DRAIN 8 STDA_SSTX_N 9 STDA_SSTX_P
Table 3-28: USB 3.0 Port Pinouts
NOTE:
If installing the Windows® 7 OS by using the USB 3.0 ports, loading the USB 3.0 driver during OS installation is necessary. Refer to Section
4.5.5 for detailed installation procedure.

3.3.4 Keyboard and Mouse Connector

CN Label: KBMS1 CN Type: CN Location: CN Pinouts:
The PS/2 ports are for connecting a PS/2 mouse and a PS/2 keyboard.
PIN DESCRIPTION PIN DESCRIPTION
1 Keyboard Data 7 Mouse Data 2 NC 8 NC 3 GND 9 GND 4 VCC 10 VCC
Dual PS/2 See Figure 3-25 See Table 3-29
Page 42
5 Keyboard Clock 11 Mouse Clock 6 NC 12 NC
Table 3-29: PS/2 Connector Pinouts
IMBA-C604EP ATX Server Board

3.3.5 Serial Port and VGA Connector

CN Label: VGACOM1 CN Type: CN Location: CN Pinouts:
DB-9 male and DB-15 female See Figure 3-25 See Table 3-30, Figure 3-29, Table 3-31 and Figure 3-30
The serial port connects to a RS-232 serial communications device.
Pin Description Pin Description
1 DCD1 6 DSR1 2 RXD1 7 RTS1 3 TXD1 8 CTS1 4 DTR1 9 RI1 5 GND1
Table 3-30: RS-232 Serial Port Connector Pinouts
Figure 3-29: RS-232 Serial Port Connector Pinouts
The VGA connector connects to a monitor that accepts a standard VGA input.
PIN DESCRIPTION PIN DESCRIPTION
1 RED 2 GREEN 3 BLUE 4 NC 5 GND 6 GND 7 GND 8 GND 9 VCC 10 GND 11 NC 12 DDCDAT 13 HSYNC 14 VSYNC 15 DDCCLK
Table 3-31: VGA Connector Pinouts
Page 43
Figure 3-30: VGA Connector

3.3.6 USB 2.0 Connector

CN Label: LAN2_USB01_1
IMBA-C604EP ATX Server Board
CN Type: CN Location: CN Pinouts:
USB 2.0 port See Figure 3-25 See Table 3-32
The IMBA-C604EP has four external USB 2.0 ports. Each USB 2.0 port can be connected to a USB 2.0/1.1 device.
Pin
1 VCC 2 DATA­3 DATA+ 4 GND
Description
Table 3-32: USB 2.0 Port Pinouts
Page 44
IMBA-C604EP ATX Server Board
Chapter
4

4 Installation

Page 45

4.1 Anti-static Precautions

WARNING:
Failure to take ESD precautions during the installation of the IMBA-C604EP may result in permanent damage to the IMBA-C604EP and severe injury to the user.
Electrostatic discharge (ESD) can cause serious damage to electronic components, including the IMBA-C604EP. Dry climates are especially susceptib le to ESD. It is therefore critical that whenever the IMBA-C604EP or any other electrical component is handled, the following anti-static precautions are strictly adhered to.
Wear an anti-static wristband: - Wearing a simple anti-static wristband can
IMBA-C604EP ATX Server Board
help to prevent ESD from damaging the board.
Self-grounding:- Before handling the board touch any grounded conducting
material. During the time the board is handled, frequently touch any conducting materials that are connected to the ground.
Use an anti-static pad: When configuring the IMBA-C604EP, place it on an
antic-static pad. This reduces the possibility of ESD damaging the IMBA-C604EP.
Only handle the edges of the PCB:-: When handling the PCB, hold the PCB
by the edges.

4.2 Installation Considerations

NOTE:
The following installation notices and installation considerations should be read and understood before installation. All installation notices must
Page 46
be strictly adhered to. Failing to adhere to these precautions may lead to severe damage and injury to the person performing the installation.
IMBA-C604EP ATX Server Board
WARNING:
The installation instructions described in this manual should be carefully followed in order to prevent damage to the components and injury to the user.
Before and during the installation please DO the following:
Read the user manual:
o The user manual provides a complete description of the IMBA-C604EP
installation instructions and configuration options.
Wear an electrostatic discharge cuff (ESD):
o Electronic components are easily damaged by ESD. Wearing an ESD cuff
removes ESD from the body and helps prevent ESD damage.
Place the IMBA-C604EP on an antistatic p ad:
o When installing or configuring the server board, place it on an antistatic
pad. This helps to prevent potential ESD damage.
Turn all power to the IMBA-C604EP off:
o When working with the IMBA-C604EP, make sure that it is disconnected
from all power supplies and that no electricity is being fed into the system.
Before and during the installation of the IMBA-C604EP DO NOT:
Remove any of the stickers on the PCB board. These stickers are required for
warranty validation.
Use the product before verifying all the cables and power connectors are
properly connected.
Allow screws to come in contact with the PCB circuit, connector pins, or its
components.
Page 47

4.2.1 Socket LGA2011 CPU Installation

WARNING:
CPUs are expensive and sensitive components. When installing the CPU, please be careful not to damage it in anyway. Make sure the CPU is installed properly and ensure the correct cooling kit is properly installed.
DO NOT touch the pins at the bottom of the CPU. When handling the CPU, only hold it on the sides.
To install the CPU, follow the steps below.
IMBA-C604EP ATX Server Board
Step 1: Disengage the load levers. Disengage the load levers in the order as shown in
Figure 4-1. To release the load lever, press the lever down and slightly outward to clear the retention tab.
Page 48
Figure 4-1: Disengage the CPU Socket Load Levers
Step 2: Open the load plate and remove the protective cover. Press the load lever
on the left hand side to lift the load lever, and then open it all the way. The black
IMBA-C604EP ATX Server Board
protective cover can be removed by pulling up on the tab labeled "REMOVE".
Figure 4-2.
See
Figure 4-2: Remove the Protective Cover
Step 3: Inspect the CPU socket. Make sure there are no bent pins and make sure the
socket contacts are free of foreign material. If any debris is found, remove it with compressed air.
Step 4: Orientate the CPU properly. The contact array should be facing the CPU
socket.
Step 5: Align the CPU pins. Locate the triangle mark and the four orientation notches
on the CPU. Align the triangle mark to the top-right corner of the CPU socket and match the four orientation notches with the socket alignment keys
Figure 4-3).
(
Step 6: Insert the CPU. Gently insert the CPU into the socket. If the CPU pins are
properly aligned, the CPU should slide into the CPU socket smoothly.
Page 49
Figure 4-3: Insert the Socket LGA2011 CPU
IMBA-C604EP ATX Server Board
Step 7: Close the CPU socket. Close the load plate and secure the load levers in the
order as shown in original position. There will be some resistance, but will not require extreme pressure.
Figure 4-4. Engage the load lever by pushing it back to its
Page 50
Figure 4-4: Close the Socket LGA2011
IMBA-C604EP ATX Server Board
Step 8: Connect the 12 V power to the board. Connect the 12 V power from the power
supply to the board. Step 0:

4.2.2 Socket LGA2011 Cooling Kit Installation

WARNING:
DO NOT attempt to install a push-pin cooling fan.
The pre-installed support bracket prevents the board from bending and is ONLY compatible with captive screw type cooling fans.
The cooling kit can be bought from IEI. The cooling kit has a heat sink and fan.
WARNING:
Do not wipe off (accidentally or otherwise) the pre-sprayed layer of thermal paste on the bottom of the heat sink. The thermal paste between the CPU and the heat sink is important for optimum heat dissipation.
To install the cooling kit, follow the instructions below.
Step 1: A cooling kit bracket is pre-installed on the rear of the server board. See
4-5.
Figure
Page 51
Figure 4-5: Cooling Kit Support Bracket
Step 2: Place the cooling kit onto the socket LGA2011 CPU. Make sure the CPU
cable can be properly routed when the cooling kit is installed.
IMBA-C604EP ATX Server Board
Step 3: Mount the cooling kit. Gently place the cooling kit on top of the CPU. Make
sure the four threaded screws on the corners of the cooling kit properly pass through the holes of the cooling kit bracket.
Step 4: Secure the cooling kit by fastening the four retention screws of the cooling kit.
Step 5: Connect the fan cable. Connect the cooling kit fan cable to the fan connector
on the IMBA-C604EP. Carefully route the cable and avoid heat generating chips and fan blades.Step 0:

4.2.3 DIMM Installation

NOTE:
When using only one DIMM for the system, always install it to the black slot (DIMMA1, DIMMB1, DIMMC1 or DIMMD1).
Page 52
IMBA-C604EP ATX Server Board
NOTE:
Installing the memory modules with the same memory size is highly recommended.
To install a DIMM, please follow the steps below and refer to Figure 4-6.
Figure 4-6: DIMM Installation
Step 1: Open the DIMM socket handles. Open the two handles outwards as far as
they can. See
Step 2: Align the DIMM with the socket. Align the DIMM so the notch on the memory
lines up with the notch on the memory socket. See
Step 3: Insert the DIMM. Once aligned, press down until the DIMM is properly seated.
Clip the two handles into place. See
Step 4: Removing a DIMM. To remove a DIMM, push both handles outward. The
memory module is ejected by a mechanism in the socket.Step 0:
Figure 4-6.
Figure 4-6.
Figure 4-6.
Page 53

4.3 Jumper Settings

NOTE:
A jumper is a metal bridge used to close an electrical circuit. It consists of two or three metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them. To CLOSE/SHORT a jumper means connecting the pins of the jumper with the plastic clip and to OPEN a jumper means removing the plastic clip from a jumper.
IMBA-C604EP ATX Server Board
The hardware jumpers must be set before installation. Jumpers are shown in Table 4-1.
Description Label Type
AT/ATX power mode selection JATX_AT1 2-pin header Clear CMOS jumper CMOS_CLR1 2-pin header USB power selection jumpers USB_PWR1,
USB_PWR2, USB_PWR3, USB_PWR4, USB_PWR5, USB_PWR6
Table 4-1: Jumpers
3-pin header
Page 54
IMBA-C604EP ATX Server Board

4.3.1 AT/ATX Power Mode Selection Jumper

Jumper Label: JATX_AT1 Jumper Type: Jumper Settings: Jumper Location:
The AT/ATX power mode selection jumper specifies the systems power mode as AT or ATX.
Setting Description
Closed ATX power (Default) Open AT power
Table 4-2: AT/ATX Power Mode Selection Jumper Settings
2-pin header See Table 4-2 See Figure 4-7
Figure 4-7: AT/ATX Power Mode Selection Jumper Location

4.3.2 Clear CMOS Jumper

Jumper Label: CMOS_CLR1 Jumper Type: Jumper Settings: Jumper Location:
To reset the BIOS, close the jumper for 3 seconds or more, and then open jumper.
2-pin header See Table 4-3 See Figure 4-8
Page 55
Setting Description
Open Normal operation (Default) Closed Clear CMOS setup
IMBA-C604EP ATX Server Board
Table 4-3: Clear CMOS Jumper Settings
Figure 4-8: Clear CMOS Jumper Location

4.3.3 USB Power Selection Jumpers

Jumper Label: USB_PWR1, USB_PWR2, USB_PWR3, USB_PWR4,
USB_PWR5, USB_PWR6 Jumper Type: Jumper Settings: Jumper Location:
The USB power selection jumpers specify the USB power.
Setting Description
Short 1-2 +5V_Dual (Default) Short 2-3 +5V
Table 4-4: USB Power Selection Jumper Settings
3-pin header
Table 4-4
See
Figure 4-9
See
Page 56
IMBA-C604EP ATX Server Board
Figure 4-9: USB Power Selection Jumper Locations

4.4 Internal Peripheral Device Connections

This section outlines the installation of peripheral devices to the onboard connectors.

4.4.1 SATA Drive Connection

The IMBA-C604EP is shipped with four SATA drive cables. To connect the SATA drives to the connectors, please follow the steps below.
Step 1: Locate the connectors. The locations of the SATA drive connectors are shown
in Chapter 3.
Step 2: Insert the cable connector. Insert the cable connector into the on-board SATA
drive connector until it clips into place. See
Figure 4-10.
Page 57
IMBA-C604EP ATX Server Board
Figure 4-10: SATA Drive Cable Connection
Step 3: Connect the cable to the SATA disk. Connect the connector on the other end
of the cable to the connector at the back of the SATA drive. See
Step 4: Connect the SATA power cable (optional). Connect the SATA power
connector to the back of the SATA drive. See
Figure 4-11.
Figure 4-11.
Page 58
IMBA-C604EP ATX Server Board
Figure 4-11: SATA Power Drive Connection
The SATA power cable can be bought from IEI. See
Optional Items in Section 2.4.

4.4.2 Dual-Port USB Cable with Slot Bracket (Optional)

A dual-port USB 2.0 cable can be purchased separately. To connect the USB cable connector, please follow the steps below.
Step 1: Locate the connectors. The locations of the USB connectors are shown in
Chapter 3.
WARNING:
If the USB pins are not properly aligned, the USB device can burn out.
Step 2: Align the connectors. The cable has two connectors. Correctly align pin 1o n
each cable connector with pin 1 on the IMBA-C604EP USB connector.
Page 59
Step 3: Insert the cable connectors. Once the cable connectors are properly aligned
with the USB connectors on the IMBA-C604EP, connect the cable connectors to
IMBA-C604EP ATX Server Board
the on-board connectors. See
Figure 4-12.
Figure 4-12: Dual USB Cable Connection
Step 4: Attach the bracket to the chassis. Th e USB 2.0 connectors are attached to a
bracket. To secure the bracket to the chassis please refer to the installation instructions that came with the chassis.

4.5 External Peripheral Interface Connection

This section describes connecting devices to the external connectors on the IMBA-C604EP.

4.5.1 Audio Connector

The audio jacks on the external audio connector enable the IMBA-C604EP to be connected to a stereo sound setup. To install the audio devices, follow the steps below.
Page 60
IMBA-C604EP ATX Server Board
Step 1: Identify the audio plugs. The plugs on your home theater system or speakers
may not match the colors on the rear panel.
Step 2: Plug the audio plugs into the audio jacks. Plug the audio plugs into the audio
jacks. If the plugs on your speakers are different, an adapter will need to be used to plug them into the audio jacks.
Figure 4-13: Audio Connector
Step 3: Check audio clarity. Check that the sound is coming through the right speakers
by adjusting the balance front to rear and left to right.

4.5.2 LAN Connection

There are two external RJ-45 LAN connectors. The RJ-45 connectors enable connection to an external network. To connect a LAN cable with an RJ-45 connector, please follow the instructions below.
Step 1: Locate the RJ-45 connectors. The locations of the USB connectors are shown
in Chapter 3.
Step 2: Align the connectors. Align the RJ-45 connector on the LAN cable with one of
the RJ-45 connectors on the IMBA-C604EP. See
Figure 4-14.
Page 61
Figure 4-14: LAN Connection
IMBA-C604EP ATX Server Board
Step 3: Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN
cable RJ-45 connector into the on-board RJ-45 connector. Step 0:

4.5.3 Serial Device Connection

The IMBA-C604EP has one male DB-9 connector on the external peripheral interface panel for serial device connection. Follow the steps below to conn ect a serial d evice to the IMBA-C604EP.
Step 1: Locate the DB-9 connector. The location of the DB-9 connector is shown in
Chapter 3.
Step 2: Insert the serial connector. Insert the DB-9 connector of a serial device into
the DB-9 connector on the external peripheral interface. See
Figure 4-15.
Page 62
IMBA-C604EP ATX Server Board
Figure 4-15: Serial Device Connection
Step 3: Secure the connector. Secure the serial device connector to the external
interface by tightening the two retention screws on either side of the connector.

4.5.4 USB Connection (Dual Connector)

The external USB Series "A" receptacle connectors provide easier and quicker access to external USB devices. Follow the steps below to connect USB devices to the IMBA-C604EP.
Step 1: Locate the USB Series "A" receptacle connectors. The location of the USB
Series "A" receptacle connectors are shown in Chapter 3.
Step 2: Insert a USB Series "A" plug. Insert the USB Series "A" plug of a device into
the USB Series "A" receptacle on the external peripheral interface. See
Figure 4-16.
Step 0:
Page 63
IMBA-C604EP ATX Server Board
Figure 4-16: USB Connection

4.5.5 VGA Monitor Connection

The IMBA-C604EP has one female DB-15 connector on the external peripheral interface panel. The DB-15 connector is connected to a CRT or VGA monitor. To connect a monitor to the IMBA-C604EP, please follow the instructions below.
Step 1: Locate the female DB-15 connector. The location of the female DB-15
connector is shown in Chapter 3.
Step 2: Align the VGA connector. Align the male DB-15 connector on the VGA screen
cable with the female DB-15 connector on the external peripheral interface.
Step 3: Insert the VGA connector. Once the connectors are properly aligned with the
insert the male connector from the VGA screen into the female connector on the IMBA-C604EP. See
Figure 4-17.
Page 64
IMBA-C604EP ATX Server Board
Figure 4-17: VGA Connector
Step 4: Secure the connector. Secure the DB-15 VGA connector from the VGA
monitor to the external interface by tightening the two retention screws on either side of the connector.

4.6 Installing USB 3.0 Driver during Windows® 7 OS Installation

If installing the Windows® 7 OS by using the USB 3.0 ports, loading the USB 3.0 driver during the OS installation is necessary. Follow the instructions below to complete the task.
Step 1: Insert the USB flash drive containing the USB 3.0 driver into one of the USB 2.0
ports on the IMBA-C604EP.
Step 2: After clicking the Install now button during the OS inst allation (
Load Driver screen appears (
Figure 4-19). Click Browse.
Figure 4-18), the
Page 65
IMBA-C604EP ATX Server Board
Figure 4-18: Install Now
Figure 4-19: Load Driver
Step 3: Locate the USB 3.0 driver folder, select Driver, and then click OK (
Figure 4-20).
Page 66
IMBA-C604EP ATX Server Board
Figure 4-20: Browse for Folder
Step 4: Make sure the ASMedia XHCI Controller driver is selected, and then click
Next.
Figure 4-21: Select the ASMedia XHCI Controller Driver
Step 5: Click OK to continue (
Figure 4-22).
Page 67
Figure 4-22: Confirm the Driver File
Step 6: Make sure the Driver subfolder inside the USB 3.0 driver folder is selected, and
IMBA-C604EP ATX Server Board
then click OK (
Step 7: Select the USB Root Hub driver and click Next.
Figure 4-20).
Page 68
Figure 4-23: Select the USB Root Hub Driver
Step 8: Follow the on-screen instructions of the Windows setup wizard to complete the
OS installation.
IMBA-C604EP ATX Server Board
Chapter
5

5 BIOS

Page 69

5.1 Introduction

The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed.
NOTE:
Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.

5.1.1 Starting Setup

The UEFI BIOS is activated when the computer is turned on. The setup program can be activated in one of two ways.
IMBA-C604EP ATX Server Board
1. Press the Delete or F2 key as soon as the system is turned on or
2. Press the Delete or F2 key when the “Press Del or F2 to enter SETUP” message appears on the screen.
If the message disappears before the Delete or F2 key is pressed, restart the computer and try again.

5.1.2 Using Setup

Use the arrow keys to highlight items, press ENTER to select, use the PageUp and PageDown keys to change entries, press F1 for help and press E keys are shown in the following table.
Key Function
Up arrow Move to previous item Down arrow Move to next item Left arrow Move to the item on the left hand side
SC to quit. Navigation
Page 70
Right arrow Move to the item on the right hand side + Increase the numeric value or make changes
IMBA-C604EP ATX Server Board
Key Function
- Decrease the numeric value or make changes Page Up key Move to the next page Page Dn key Move to the previous page Esc key Main Menu – Quit and not save changes into CMOS
Status Page Setup Menu and Option Page Setup Menu -­Exit current page and return to Main Menu
F1 General help, only for Status Page Setup Menu and Option
Page Setup Menu F2 Load previous values F3 Load optimized defaults F4 Save changes and Exit BIOS
Table 5-1: BIOS Navigation Keys

5.1.3 Getting Help

When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears. To exit the Help Window press E the F1 key again.

5.1.4 Unable to Reboot after Configuration Changes

If the computer cannot boot after changes to the system configuration is made, CMOS defaults. Use the jumper described in Chapter 4.

5.1.5 BIOS Menu Bar

The menu bar on top of the BIOS screen has the following main items:
Main – Changes the basic system configuration.  Advanced – Changes the advanced system settings.
SC or
Chipset – Changes the chipset settings.  Boot – Changes the system boot configuration.  Security – Sets User and Supervisor Passwords.
Page 71
Save & Exit – Selects exit options and loads default settings
The following sections completely describe the configuration options found in the menu items at the top of the BIOS screen and listed above.
IMBA-C604EP ATX Server Board

5.2 Main

The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset Server Mgmt Boot Security Save & Exit
BIOS Information BIOS Vendor American Megatrends Core Version 4.6.4.1 Compliancy UEFI 2.1; PI 0.9 Project Version B232AR10.ROM Build Date and Time 12/03/2012 11:53:40
Memory Information Total Memory 4096 MB (DDR3)
System Date [Tue 02/05/2013] System Time [15:10:27]
Access Level Administrator
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Set the Date. Use Tab to switch between Data elements.
----------------------
ÆÅ
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
BIOS Menu 1: Main
The Main menu lists the following system details:
BIOS Information Memory Information
The Main menu has two user configurable fields:
Î System Date [xx/xx/xx]
Use the System Date option to set the system date. Manually enter the day, month and year.
Page 72
IMBA-C604EP ATX Server Board
Î System Time [xx:xx:xx]
Use the System Time option to set the system time. Manually enter the hours, minutes and seconds.

5.3 Advanced

Use the Advanced menu (BIOS Menu 2) to configure the CPU and peripheral devices through the following sub-menus:
WARNING!
Setting the wrong values in the sections below may cause the system to malfunction. Make sure that the settings made are compatible with the hardware.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset Server Mgmt Boot Security Save & Exit
> ACPI Settings > RTC Wake Settings > Trusted Computing > CPU Configuration > SATA Configuration > SAS Configuration > USB Configuration > F81866 Super IO Configuration > F81866 H/M Monitor > Serial Port Console Redirection > iEi Feature
Main Configuration Page Main Configuration Page
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 2: Advanced
System ACPI Parameters
----------------------
ÆÅ
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

5.3.1 ACPI Settings

The ACPI Settings menu (BIOS Menu 3) configures the Advanced Configuration and Power Interface (ACPI) options.
Page 73
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
ACPI Settings
ACPI Sleep State [S1 (CPU Stop Clock)]
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 3: ACPI Settings
IMBA-C604EP ATX Server Board
Select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed.
----------------------
ÆÅ
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
Î ACPI Sleep State [S1 (CPU Stop Clock)]
Use the ACPI Sleep State option to specify the sleep state the system enters when it is not being used.
Î
S1 (CPU Stop Clock)
Î
S3 (Suspend to RAM)
DEFAULT
The system enters S1 (POS) sleep state. The system appears off. The CPU is stopped; RAM is refreshed; the system is running in a low power mode.
The caches are flushed and the CPU is powered off. Power to the RAM is maintained. The computer returns slower to a working state, but more power is saved.
Page 74
E
IMBA-C604EP ATX Server Board

5.3.2 RTC Wake Settings

The RTC Wake Settings menu (BIOS Menu 4) configures RTC wake event.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Wake system with Fixed Time [Disabled]
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
nable or disable System wake on alarm event. When enabled, System will wake on the date::hr::min::sec specified
----------------------
ÆÅ
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
BIOS Menu 4: RTC Wake Settings
Î Wake System with Fixed Time [Disabled]
Use the Wake System with Fixed Time option to specify the time the system should be roused from a suspended state.
Î
Disabled DEFAULT
Î
Enabled
The real time clock (RTC) cannot generate a wake event
If selected, the following appears with values that can be selected:
*Wake up every day *Wake up date *Wake up hour *Wake up minute *Wake up second After setting the alarm, the computer turns itself on
from a suspend state when the alarm goes off.
Page 75
E
I
IMBA-C604EP ATX Server Board

5.3.3 Trusted Computing

Use the Trusted Computing menu (BIOS Menu 5) to configure settings related to the Trusted Computing Group (TCG) Trusted Platform Module (TPM).
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Configuration TPM SUPPORT [Disable]
Current Status Information
NO Security Device Found
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
nables or Disables BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and
NT1A interface will not be available.
----------------------
ÆÅ
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
BIOS Menu 5: Trusted Computing
Î TPM SUPPORT [Disable]
Use the TPM SUPPORT option to configure support for the TPM.
Î
Disable DEFAULT
Î
Enable
TPM support is disabled. TPM support is enabled.
Page 76
a
T
D
IMBA-C604EP ATX Server Board

5.3.4 CPU Configuration

Use the CPU Configuration menu (BIOS Menu 6) to view detailed CPU specifications or enable the Intel Virtualization Technology.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
CPU Configuration
Intel(R) Xeon(R) CPU E5-2648L 0 @ 1.80GHz CPU Signature 206d7 Microcode Patch 70d Max CPU Speed 1800 MHz Min CPU Speed 1200 MHz Processor Cores 8 Intel HT Technology Supported Intel VT-x Technology Supported
L1 Data Cache 32 kB x 8 L1 Code Cache 32 kB x 8 L2 Cache 256 kB x 8 L3 Cache 20480 kB CPU Speed 1800 MHz 64-bit Supported
Hyper-threading [Enabled] Intel Virtualization Technology [Disabled]
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Enabled for Windows XP
nd Linux (OS optimized for Hyper-Threading
echnology) and Disabled for other OS (OS not optimized for Hyper-Threading Technology). When
isabled only one thread per enabled core is enabled.
----------------------
ÆÅ
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
BIOS Menu 6: CPU Configuration
The CPU Configuration menu (
Processor Type: Lists the brand name of the CPU being used  CPU Signature: Lists the CPU signature value.  Microcode Patch: Lists the microcode patch being used.  Max CPU Speed: Lists the maximum CPU processing speed.  Min CPU Speed: Lists the minimum CPU processing speed.  Processor Cores: Lists the number of the processor core  Intel HT Technology: Indicates if Intel HT Technology is supported by the
CPU.
BIOS Menu 6) lists the following CPU details:
Page 77
Intel VT-x Technology: Indicates if Intel VT-x Technology is supported by the
CPU.
L1 Data Cache: Lists the amount of data storage space on the L1 cache.  L1 Code Cache: Lists the amount of code storage space on the L1 cache.  L2 Cache: Lists the amount of storage space on the L2 cache.  L3 Cache: Lists the amount of storage space on the L3 cache.  CPU Speed: Lists the CPU processing speed  64-bit: Indicates if 64-bit is supported by the CPU.
Î Hyper-threading [Enabled]
Use the Hyper-threading option to enable or disable the CPU hyper threading function.
IMBA-C604EP ATX Server Board
Î
Disabled
Î
Enabled DEFAULT
Î Intel Virtualization Technology [Disabled]
Use the Intel Virtualization Technology option to enable or disable virtualization on the system. When combined with third party software, Intel® Virtualization technology allows several OSs to run on the same system at the same time.
Î
Disabled DEFAULT
Î
Enabled
Disables the use of hyper threading technology Enables the use of hyper threading technology
Disables Intel Virtualization Technology.
Enables Intel Virtualization Technology .
Page 78
IMBA-C604EP ATX Server Board

5.3.5 SATA Configuration

Use the SATA Configuration menu (BIOS Menu 7) to change and/or set the configuration of the SATA devices installed in the system.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
SATA Configuration
SATA Mode [IDE Mode]
SATA1 Not Present SATA2 Not Present SATA3 Not Present SATA4 Not Present SATA5 Not Present SATA6 Not Present
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
(1) IDE Mode. (2) AHCI Mode. (3) RAID Mode.
---------------------
ÆÅ
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
BIOS Menu 7: SATA Configuration
Î SATA Mode [IDE Mode]
Use the SATA Mode option to configure SATA device mode.
Î
Disabled
Î
IDE Mode DEFAULT
Î
AHCI Mode
Î
RAID Mode
Disables SATA devices. Configures SATA devices as normal IDE device. Configures SATA devices as AHCI device. Configures SATA devices as RAID device.
Page 79
IMBA-C604EP ATX Server Board

5.3.6 SAS Configuration

Use the SAS Configuration menu (BIOS Menu 8) to display the information of the SATA devices installed in the system.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
SAS Configuration
SAS1 Not Present SAS2 Not Present SAS3 Not Present SAS4 Not Present
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
---------------------
ÆÅ
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
BIOS Menu 8: SAS Configuration

5.3.7 USB Configuration

Use the USB Configuration menu (BIOS Menu 9) to read USB configuration information and configure the USB settings.
Page 80
d
IMBA-C604EP ATX Server Board
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
USB Configuration
USB Devices: 4 Drives, 1 Keyboard, 1 Mouse, 1 Point
Legacy USB Support [Enabled]
Mass Storage Devices:
AMI Virtual CDROM0 1.00 [Auto] AMI Virtual Floppy0 1.00 [Auto] AMI Virtual HDISK0 1.00 [Auto] AMI Virtual HDISK1 1.00 [Auto]
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Enables Legacy USB support. AUTO option
isables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications.
---------------------
ÆÅ
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
BIOS Menu 9: USB Configuration
Î Legacy USB Support [Enabled]
Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard support. Normally if this option is not enabled, any attached USB mouse or USB keyboard does not become available until a USB compatible operating system is fully booted with all USB drivers loaded. When this option is enabled, any attached USB mouse or USB keyboard can control the system even when there is no USB driver loaded onto the system.
Î
Enabled DEFAULT
Î
Disabled
Î
Auto
Legacy USB support enabled Legacy USB support disabled Legacy USB support disabled if no USB devices are
connected
Page 81
S
Î AMI Virtual CDROM0 1.00/AMI Virtual Floppy0 1.00/AMI Virtual HDISK0 1.00/AMI
Virtual HDISK1 1.00 [Auto]
This option allows selection of the mass storage device emulation type. Selecting Auto will emulate devices according to their media format. Drives with no media will be emulated according to their drive type. Configuration options are listed below.
 Auto Default  Floppy  Forced FDD  Hard Disk  CD-ROM
IMBA-C604EP ATX Server Board

5.3.8 F81866 Super IO Configuration

Use the F81866 Super IO Configuration menu (BIOS Menu 10) to set or change the configurations for the serial port 1 (COM1).
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
F81866 Super IO Configuration
F81866 Super IO Chip F81866
> Serial Port 1 Configuration
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 10: F81866 Super IO Configuration
et Parameters of Serial Port 1 (COMA)
---------------------
ÆÅ
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
Page 82
E
IMBA-C604EP ATX Server Board
5.3.8.1 Serial Port 1 Configuration
Use the Serial Port 1 Configuration menu (BIOS Menu 11) to configure the serial port 1.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Serial Port n Configuration
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=4
Change Settings [Auto]
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
nable or Disable Serial Port (COM)
---------------------
ÆÅ
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
BIOS Menu 11: Serial Port 1 Configuration Menu
Î Serial Port [Enabled]
Use the Serial Port option to enable or disable the serial port.
Î
Disabled
Î
Enabled DEFAULT
Î Change Settings [Auto]
Use the Change Settings option to change the serial port IO port address and interrupt address.
Î
Auto DEFAULT
Î
IO=3F8h; IRQ=4
Disable the serial port Enable the serial port
The serial port IO port address and interrupt address are automatically detected.
Serial Port I/O port address is 3F8h and the interrupt address is IRQ4
Î
IO=3F8h; IRQ=3, 4
Serial Port I/O port address is 3F8h and the interrupt address is IRQ3, 4
Page 83
IMBA-C604EP ATX Server Board
Î
Î
IO=2C0h; IRQ=3, 4
IO=2C8h; IRQ=3, 4
Serial Port I/O port address is 2C0h and the interrupt address is IRQ3, 4
Serial Port I/O port address is 2C8h and the interrupt address is IRQ3, 4

5.3.9 F81866 H/W Monitor

The F81866 H/W Monitor menu (BIOS Menu 12) contains the fan configuration submenus and displays operating temperature, fan speeds and system voltages.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
PC Health Status
> Smart Fan Mode Configuration
CPU temperature :+43 C System Temperature :+46 C CPU_FAN1 Speed :2145 RPM CPU_FAN6 Speed :N/A +CPU_CORE :+0.896 V +3.3V :+3.264 V PVSA_CPU :+0.888 V PVDDR_AB :+1.352 V VSB5V :+4.896 V +V3.3S :+3.264 V VSB3V :+3.312 V VBAT :+2.944 V
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Smart Fan Mode Select
---------------------
ÆÅ
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
BIOS Menu 12: F81866 H/W Monitor
Î PC Health Status
The following system parameters and values are shown. The system parameters that are monitored are:
System Temperatures:
Fan Speeds:
Page 84
o CPU Temperature o System Temperature
o CPU Fan Speed
Loading...
