IEI Integration AFL2-W19A-H61 User Manual

AFL2-W19A/AB-H61
Page I
MODEL:
Flat Bezel Panel P C with 2nd Generation In tel® Core™ i7/ i5/ i3,
HD Audio and RoHS
Rev. 1.21 - 25 Ju ly, 2013
IEI Technology Corp.
Pentium® and Celeron® processor, Touch Screen, Wi-Fi, USB,
Dual GbE LAN , RS-232/422/485, 1.3M pixel s Camera,
User Manual
User Manual
AFL2-W19A/AB-H61
Page II

Revision

Date Version Changes
25 July, 2013 1.21 Update the Note for CPU temperature alert LED in Section 1.2.1.1: LED
Indicators
14 May, 2013 1.20 Add Section 1.2.1.2: LED light
Update the mechanical keys to film keys 4 January, 2013 1.11 Update LED light bar overview 30 October, 2012 1.10 Model variations update
LED Light Bar update 18 September, 2012 1.00
Initial release
AFL2-W19A/AB-H61
Page III

Copyright

COP YRIGHT NOTICE
The information in this document is subject to change without prior notice in order to improve reliabilit y, design a nd functi on and d oes not r epresent a com mitm ent on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are reserved. No part of this manual may be reproduced by any mechanical, e lectronic, or other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered tradem ark s and produc t nam es ment ioned here in are us ed for identif icatio n purposes only and m ay be trademarks and/or registe red trademarks of their respecti ve owners.
AFL2-W19A/AB-H61
Page IV

Table of Contents

1 INTRODUCTION .......................................................................................................... 1
1.1 AFL2-W19A/AB-H61 FLAT BEZEL PANEL PC OVERVIEW ........................................ 2
1.1.1 Model Variations ................................................................................................ 3
1.1.2 Features ............................................................................................................. 3
1.1.3 Light Fanless Technology Design ...................................................................... 4
1.2 EXTERNAL OVERVIEW ................................................................................................ 5
1.2.1 Front Panel ........................................................................................................ 5
1.2.1.1 LED Indicators ............................................................................................ 5
1.2.1.2 LED Light ................................................................................................... 7
1.2.1.3 Function Keys ............................................................................................. 8
1.2.2 Rear Panel ......................................................................................................... 9
1.2.3 Bottom Panel ...................................................................................................... 9
1.2.4 Left Side Panel ................................................................................................. 10
1.2.5 Right Side Panel ................................................................................................ 11
1.3 INTERNAL OVERVIEW ................................................................................................ 11
1.4 SYSTEM SPECIFICATIONS .......................................................................................... 12
2 LED LIGHT BAR (OPTIONAL) ............................................................................... 14
2.1 OVERVIEW ................................................................................................................ 15
2.2 IEI LED LIGHT BAR DISPLAY SIMULATOR ............................................................... 15
2.3 IEI LED RUN ............................................................................................................ 25
2.4 LED CONTROL API .................................................................................................. 26
2.4.1 Introduction ...................................................................................................... 26
2.4.1.1 Programming Language Support .............................................................. 26
2.4.1.2 Application Content .................................................................................. 26
2.4.2 LED Control API Functions ............................................................................. 26
2.4.2.1 LIGHTBAR_DriverInit ............................................................................ 26
2.4.2.2 LIGHTBAR_DriverUninit ........................................................................ 27
2.4.2.3 LIGHTBAR_DeviceInit ........................................................................... 27
2.4.2.4 LIGHTBAR_DeviceClose ........................................................................ 27
2.4.2.5 LIGHTBAR_Brightness_Single ............................................................... 28
AFL2-W19A/AB-H61
Page V
2.4.2.6 LIGHTBAR_BLNK_Settings ................................................................... 28
2.4.2.7 LIGHTBAR_BLNK_Type ........................................................................ 29
2.4.2.8 LIGHTBAR_LED_ModeSet .................................................................... 29
2.4.3 Structures ......................................................................................................... 30
2.4.3.1 _LED_COLOR_INFO .............................................................................. 30
2.4.3.2 _LED_BLNK_SET ................................................................................... 30
2.4.3.3 _LED_BLNK_SET ................................................................................... 31
2.4.3.4 _LED_MODE_SETTINGS ...................................................................... 32
2.4.4 Programming Example .................................................................................... 32
2.4.4.1 Turn on LED - single ................................................................................ 32
2.4.4.2 Turn on LED - multiple ............................................................................. 33
2.4.4.3 LED Blink - 1 ............................................................................................ 35
2.4.4.4 LED Blink - 2 ............................................................................................ 36
3 DETAILED SPECIFICATIONS ................................................................................ 39
3.1 DIMENSIONS ............................................................................................................. 40
3.2 INTEL® CORE DESKTOP PROCESSOR .................................................................... 41
3.3 MOTHERBOARD COMPONENTS ................................................................................. 41
3.3.1 Memory Capacity ............................................................................................. 41
3.3.2 Storage Capacity .............................................................................................. 41
3.4 EXTERNAL PERIPHERAL INTERFACE CONNECTORS ................................................... 41
3.4.1 Serial Port Connectors .................................................................................... 41
3.4.2 LAN Connectivity ............................................................................................. 42
3.4.3 External USB Connectors ................................................................................ 43
3.5 AUDIO ...................................................................................................................... 44
3.5.1 Audio Codec Controller ................................................................................... 44
3.5.2 Stereo Speakers ................................................................................................ 44
4 UNPACKING ............................................................................................................... 45
4.1 UNPACKING .............................................................................................................. 46
4.1.1 Packing List ..................................................................................................... 46
5 INSTALLATION ......................................................................................................... 50
5.1 ANTI-STATIC PRECAUTIONS ...................................................................................... 51
5.2 INSTALLATION PRECAUTIONS ................................................................................... 51
5.3 INST ALLATION AND CONFIGURATION STEPS ............................................................. 52
AFL2-W19A/AB-H61
Page VI
5.4 HDD INSTALLATION ................................................................................................. 52
5.5 K-TYPE TEMPERATURE SENSOR INSTALLATION ....................................................... 55
5.6 RFID READER (OPTIONAL) ...................................................................................... 56
5.7 DVD-ROM INSTALLATION (OPTIONAL) .................................................................. 57
5.8 AT/ATX MODE SELECTION ...................................................................................... 59
5.8.1 AT Power Mode ................................................................................................ 60
5.8.2 ATX Power Mode ............................................................................................. 60
5.9 CLEAR CMOS .......................................................................................................... 60
5.10 RESET THE SYSTEM ................................................................................................ 61
5.11 POWERING ON THE SYSTEM ................................................................................... 61
5.12 POWERING OFF THE SYSTEM .................................................................................. 62
5.13 MOUNTING THE SYSTEM ........................................................................................ 62
5.13.1 Wall Mounting ................................................................................................ 63
5.13.2 Panel Mounting .............................................................................................. 66
5.13.3 Stand Mounting .............................................................................................. 67
5.13.4 Arm Mounting ................................................................................................ 67
5.14 EXTERNAL PERIPHERAL DEVICE CONNECTION ...................................................... 68
5.14.1 Audio Connection ........................................................................................... 69
5.14.2 HDMI Device Connection .............................................................................. 70
5.14.3 LAN Connection ............................................................................................. 72
5.14.4 Serial Device Connection .............................................................................. 73
5.14.5 USB Device Connection ................................................................................. 75
5.14.6 VGA Monitor Connection .............................................................................. 77
6 SYSTEM MOTHERBOARD ..................................................................................... 79
6.1 OVERVIEW ................................................................................................................ 80
6.1.1 Layout .............................................................................................................. 80
6.1.2 Peripheral Interface Connectors ..................................................................... 81
6.2 INTERNAL PERIPHERAL CONNECTORS ...................................................................... 83
6.2.1 Auto-Dimming Connector ................................................................................ 83
6.2.2 Battery Connector ............................................................................................ 84
6.2.3 BIOS Programming Connector ........................................................................ 84
6.2.4 Bluetooth Connector ........................................................................................ 85
6.2.5 CPU Fan Connector ........................................................................................ 86
6.2.6 DDR3 SO-DIMM Slots .................................................................................... 87
AFL2-W19A/AB-H61
Page VII
6.2.7 Debug Port Connector ..................................................................................... 88
6.2.8 Digital Microphone Connector ........................................................................ 89
6.2.9 EC Debug Connector ....................................................................................... 90
6.2.10 EC Programming Connector ......................................................................... 91
6.2.11 Hotkey Connector ........................................................................................... 92
6.2.12 Hotkey LED Connector .................................................................................. 92
6.2.13 JSATA Connector ........................................................................................... 93
6.2.14 K Type Thermocouple Connector .................................................................. 94
6.2.15 LVDS Connector ............................................................................................ 96
6.2.16 LVDS Backlight Inverter Connector .............................................................. 97
6.2.17 LED Connector .............................................................................................. 98
6.2.18 Light Bar Connectors ..................................................................................... 99
6.2.19 LOGO LED Connector ................................................................................ 100
6.2.20 Mini USB Connector .................................................................................... 101
6.2.21 PCIe Mini Card Slot .................................................................................... 103
6.2.22 Power Button Connector .............................................................................. 104
6.2.23 RFID Connector ........................................................................................... 104
6.2.24 SATA 3Gb/s Drive Connectors ..................................................................... 105
6.2.25 SATA Power Connector ................................................................................ 106
6.2.26 Speaker Connector ....................................................................................... 107
6.2.27 Touch panel connector (5-wire resistive type) ............................................. 108
6.2.28 Touch panel connector (projected capacitive type) ..................................... 109
6.2.29 TPM Connector ............................................................................................. 110
6.2.30 Web Camera Connector ................................................................................ 111
6.3 JUMPER SETTINGS ................................................................................................... 113
6.3.1 LVDS Voltage Selection ................................................................................... 113
6.3.2 LCD panel selection ........................................................................................ 114
7 SYSTEM MAINTENANCE ...................................................................................... 116
7.1 SYSTEM MAINTENANCE INTRODUCTION ................................................................. 117
7.2 ANTI-STATIC PRECAUTIONS ..................................................................................... 117
7.3 TURN OFF THE POWER ............................................................................................. 118
7.4 OPENIN G THE SYSTEM ............................................................................................. 118
7.4.1 Removing the Back Cover ............................................................................... 118
7.4.2 Removing the Internal Aluminum Cover ......................................................... 119
AFL2-W19A/AB-H61
Page VIII
7.5 REPLACING COMPONENTS ...................................................................................... 120
7.5.1 Memory Module Replacement ....................................................................... 120
7.5.2 WLAN Card Replacement .............................................................................. 121
7.6 REINSTALLING THE COVERS ................................................................................... 124
8 BIOS SETUP .............................................................................................................. 125
8.1 INTRODUCTION ....................................................................................................... 126
8.1.1 Starting Setup ................................................................................................. 126
8.1.2 Using Setup .................................................................................................... 126
8.1.3 Getting Help ................................................................................................... 127
8.1.4 Unable to Reboot after Configuration Changes ............................................ 127
8.1.5 BIOS Menu Bar .............................................................................................. 127
8.2 MAIN ...................................................................................................................... 128
8.3 ADVANCED ............................................................................................................. 129
8.3.1 ACPI Settings ................................................................................................. 130
8.3.2 RTC Wake Settings ......................................................................................... 131
8.3.3 T rusted Computing ......................................................................................... 132
8.3.4 CPU Configuration ........................................................................................ 133
8.3.4.1 CPU Information ..................................................................................... 134
8.3.5 SATA Configuration ....................................................................................... 136
8.3.6 Intel TXT (LT) Configuration ......................................................................... 137
8.3.7 USB Configuration ......................................................................................... 138
8.3.8 F81216 Super IO Configuration .................................................................... 140
8.3.8.1 Serial Port n Configuration ..................................................................... 140
8.3.9 H/W Monitor .................................................................................................. 144
8.3.10 Serial Port Console Redirection .................................................................. 146
8.4 IEI FEATURE ........................................................................................................... 147
8.5 CHIPSET ................................................................................................................. 148
8.5.1 Northbridge Configuration ............................................................................ 149
8.5.2 Southbridge Configuration ............................................................................ 150
8.5.3 Integrated Graphics ....................................................................................... 154
8.5.4 ME Subsystem ................................................................................................ 155
8.6 BOOT ...................................................................................................................... 157
8.7 SECURITY ............................................................................................................... 159
8.8 SAVE & EXIT .......................................................................................................... 160
AFL2-W19A/AB-H61
Page IX
9 SOFTWARE DRIVERS ............................................................................................ 162
9.1 AVAILABLE SOFTWARE DRIVERS ............................................................................ 163
9.2 STARTING THE DRIVER PROGRAM .......................................................................... 163
9.3 CHIPSET DRIVER INSTALLATION ............................................................................. 164
9.4 GRAPHICS DRIVER INSTALLATION .......................................................................... 168
9.5 TOUCH SCREEN DRIVER ......................................................................................... 173
9.5.1 Calibrating the Touch Screen ......................................................................... 176
9.6 AUDIO DRIVER INSTALLATION ............................................................................... 178
9.7 LAN DRIVER INSTALLATION .................................................................................. 180
9.8 INTEL® MANAGEMENT ENGINE COMPONENTS INSTALLATION ............................... 183
9.9 USB 3.0 DRIVER INSTALLATION ............................................................................. 186
9.10 WI-FI DRIVER INSTALLATION ............................................................................... 188
9.11 LED BAR DRIVER INSTALLATION ......................................................................... 192
9.12 AMCAP DRIVER INSTALLATION ........................................................................... 195
10 COOLING MANAGEMENT CONSOLE (ICMC) .............................................. 198
10.1 OVERVIEW ............................................................................................................ 199
10.1.1 iCMC Installation ........................................................................................ 199
10.2 ICMC OVERVIEW ................................................................................................. 202
10.2.1 Information Panel ........................................................................................ 202
10.2.2 Chart Panel .................................................................................................. 205
A SAFETY PRECAUTIONS ....................................................................................... 207
A.1 SAFETY PRECAUTIONS .......................................................................................... 208
A.1.1 General Safety Precautions ........................................................................... 208
A.1.2 CPU T empe ratur e Warning ........................................................................... 209
A.1.3 Anti-static Precautions .................................................................................. 209
A.1.4 Product Disposal ........................................................................................... 210
A.2 MAINTENANCE AND CLEANING PRECAUTIONS ...................................................... 210
A.2.1 Maintenance and Cleaning ............................................................................ 210
A.2.2 Cleaning T ools ................................................................................................ 211
B BIOS MENU OPTIONS ........................................................................................... 212
C ONE KEY RECOVERY ........................................................................................... 215
C.1 ONE KEY RECOVERY INTRODUCTION .................................................................... 216
AFL2-W19A/AB-H61
Page X
C.1.1 System Requirement ...................................................................................... 217
C.1.2 Supported Operating System ......................................................................... 218
C.2 SETUP PROCEDURE FOR WINDOWS ........................................................................ 219
C.2.1 Hardware and BIOS Setup ............................................................................ 220
C.2.2 Create Partitions ........................................................................................... 220
C.2.3 Install Operating System, Drivers and Applications ..................................... 224
C.2.4 Building the Recovery Partition .................................................................... 225
C.2.5 Create Factory Default Image ...................................................................... 227
C.3 AUTO RECOVERY SETUP PROCEDURE .................................................................... 232
C.4 SETUP PROCEDURE FOR LINUX .............................................................................. 237
C.5 RECOVERY TOOL FUNCTIONS ................................................................................ 240
C.5.1 Factory Restore ............................................................................................. 241
C.5.2 Backup System ............................................................................................... 242
C.5.3 Restore Your Last Backup .............................................................................. 243
C.5.4 Manual .......................................................................................................... 244
C.6 RESTORE SYSTEMS FROM A LINUX SERVER THROUGH LAN .................................. 245
C.6.1 Configure DHCP Server Settings .................................................................. 246
C.6.2 Configure TFTP Settings ............................................................................... 247
C.6.3 Configure One Key Recovery Server Settings ............................................... 248
C.6.4 Start the DHCP, TFTP and HTTP ................................................................. 249
C.6.5 Create Shared Directory ................................................................................ 249
C.6.6 Setup a Client System for Auto Recovery ...................................................... 250
C.7 OTHER INFORMATION ............................................................................................ 253
C.7.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller ...................... 253
C.7.2 System Memory Requirement ........................................................................ 255
D HAZARDOUS MATERIALS DISCLOSURE ....................................................... 256
D.1 HAZARDOUS MATERIAL DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ..................................... 257
AFL2-W19A/AB-H61
Page XI
List of F igures
Figure 1-1: AFL2-W19A/AB-H61 Flat Bezel Panel PC ................................................................. 2
Figure 1-2: AFL2-W19A/AB-H61 Front View Figure 1-3: LED Indicators Figure 1-4: LED Light Software (Auto) Figure 1-5: LED Light Software (Manual) Figure 1-6: Function Keys Figure 1-7: AFL2-W19A/AB-H61 Rear View Figure 1-8: AFL2-W19A/AB-H61 Bottom Panel Figure 1-9: AFL2-W19A/AB-H61 Left Side Panel Figure 1-10: AFL2-W19A/AB-H61 Right Side Panel Figure 2-1: The Setup Wizard Starts Figure 2-2: Select Installation Folder Screen Figure 2-3: Confirm Installation Screen Figure 2-4: Installation Complete Figure 2-5: iEi LED Light Bar Display Simulator Figure 2-6: Color Setting Area Figure 2-7: Color Palette Figure 2-8: Simulate the LED Light
................................................................................ 5
............................................................................................................. 5
......................................................................................... 7
..................................................................................... 7
............................................................................................................. 8
.................................................................................. 9
..........................................................................10
.......................................................................11
..................................................................11
...........................................................................................15
............................................................................16
.....................................................................................17
................................................................................................18
.......................................................................19
.....................................................................................................20
..............................................................................................................20
.............................................................................................21
Figure 2-9: Set the Left LEDs Figure 2-10: Set All the LEDs Figure 2-11: Light Duration Figure 2-12: Add new command Figure 2-13: Add Loop Start Figure 2-14: Add Loop End Figure 2-15: iEi LED RUN Softw are Figure 3-1: AFL2-W19A/AB-H61 Dimensions (mm) Figure 3-2: Serial Ports Figure 3-3: RJ-45 Ethernet Connector (Bottom Panel) Figure 3-4: RJ-45 Ethernet Connector (Left Side Panel) Figure 3-5: External USB Ports (Bottom Panel) Figure 3-6: External USB Ports (Left Side Panel)
......................................................................................................22
......................................................................................................22
..........................................................................................................23
.................................................................................................24
........................................................................................................24
..........................................................................................................25
.............................................................................................25
...................................................................40
................................................................................................................42
.............................................................42
..........................................................43
........................................................................43
......................................................................44
AFL2-W19A/AB-H61
Page XII
Figure 3-7: Audio Jack .................................................................................................................44
Figure 5-1: HDD Cover Retention Screws Figure 5-2: HDD Bracket Screw Figure 5-3: Removing the HDD Bracket Figure 5-4: Inserting the HDD Figure 5-5: Securing the HDD Figure 5-6: Insert the K-type Temperature Sensor Cable Figure 5-7: Connect the RFID USB cable Figure 5-8: Install the RFID module Figure 5-9: DVD-ROM Cover Figure 5-10: Install the DVD-ROM Figure 5-11: DVD-ROM Bracket Screws Figure 5-12: DVD-ROM Cover Figure 5-13: AT/ATX Switch Location Figure 5-14: Clear CMOS Switch Location Figure 5-15: Reset Button Location Figure 5-16: Wall-mounting Bracket Figure 5-17: Chassis Support Screws
..................................................................................53
...................................................................................................53
.....................................................................................54
......................................................................................................54
......................................................................................................55
.........................................................56
...................................................................................56
............................................................................................57
........................................................................................................58
...............................................................................................58
.....................................................................................59
......................................................................................................59
.........................................................................................60
.................................................................................61
............................................................................................61
...........................................................................................63
........................................................................................65
Figure 5-18: Secure the Panel PC Figure 5-19: Tighten the Panel Mounting Clamp Screws Figure 5-20: Mounting screw location Figure 5-21: Arm Mounting Retention S crew Holes Figure 5-22: Audio Connector Figure 5-23: HDMI Connection Figure 5-24: LAN Connection Figure 5-25: DB-9 Serial Port Connector Figure 5-26: USB Device Connection Figure 5-27: VGA Connector Figure 6-1: Connectors and Jumpers (front) Figure 6-2: Connectors and Jumpers (rear) Figure 6-3: Auto-dimming Connector Pinout Location Figure 6-4: Battery Connector Locations Figure 6-5: BIOS Programm in g Connector Location Figure 6-6: Bluetooth Connector Location Figure 6-7: CPU Fan Connector Location
...............................................................................................65
.........................................................66
........................................................................................67
..................................................................68
.....................................................................................................70
....................................................................................................71
......................................................................................................72
....................................................................................74
.........................................................................................76
.......................................................................................................78
.............................................................................80
..............................................................................81
............................................................83
...................................................................................84
................................................................85
................................................................................86
..................................................................................87
AFL2-W19A/AB-H61
Page XIII
Figure 6-8: DDR3 DIMM Slot Locations ......................................................................................88
Figure 6-9: Debug Port Connector Location Figure 6-10: Digital Microphone Connector Location Figure 6-11: Debug Port Connector Location Figure 6-12: EC Programming Connector Location Figure 6-13: Hotkey Connector Location Figure 6-14: Hotkey LED Connector Location Figure 6-15: JSATA Connector Location Figure 6-16: K Type Thermocouple Connector Location Figure 6-17: K Type Thermocouple Connector Location Figure 6-18: LVDS Connector Location Figure 6-19: LVDS Backlight Inverter C o n n ector Location Figure 6-20: LED Connector Location Figure 6-21: LED Bar Connectors Location Figure 6-22: LOGO LED Connector Location Figure 6-23: Mini USB Connector Location (MINUSB2) Figure 6-24: Mini USB Connector Location (MINUSB1) Figure 6-25: PCIe Mini Card Slot Location
..............................................................................88
...............................................................89
............................................................................90
..................................................................91
...................................................................................92
...........................................................................93
...................................................................................94
.........................................................95
.........................................................95
......................................................................................96
......................................................98
........................................................................................99
.............................................................................100
..........................................................................101
..........................................................102
..........................................................102
...............................................................................103
Figure 6-26: Power Button Connector Location Figure 6-27: RFID Connector Location Figure 6-28: SATA 3Gb/s Drive Connector Location Figure 6-29: SATA Power Connector Locatio n s Figure 6-30: Speaker Connector Location Figure 6-31: Touch Panel Connector Location Figure 6-32: Touch Panel Connector Location Figure 6-33: TPM Connector Location Figure 6-34: Web Camera Connector Location Figure 6-35: LVDS Voltage Selection Jumper Location Figure 6-36: LCD panel Selection Jumper Location Figure 7-1: Back Cover Retention Screws Figure 7-2: Internal Cover Retention Screws Figure 7-3: Internal Components Figure 7-4: DDR SO-DIMM Module Installation Figure 7-5: Removing the Antennas Figure 7-6: Releasing the WLAN Card
......................................................................104
.....................................................................................105
..............................................................106
.....................................................................107
...............................................................................108
........................................................................109
........................................................................110
......................................................................................111
.......................................................................112
.........................................................114
...............................................................115
...............................................................................119
...........................................................................119
..............................................................................................120
........................................................................121
.........................................................................................122
......................................................................................122
AFL2-W19A/AB-H61
Page XIV
Figure 7-7: Removing the WLAN card ......................................................................................123
Figure 7-8: Attaching the Antennas Figure 9-1: Drivers Figure 9-2: Chipset Driver Screen Figure 9-3: Chipset Driver Welcome Screen Figure 9-4: Chipset Driver License Agreement Figure 9-5: Chipset Driver Read Me File Figure 9-6: Chipset Driver Setup Operations Figure 9-7: Chipset Driver Installation Finish Screen Figure 9-8: Graphics Driver Read Me File Figure 9-9: Graphics Driver Setup Files Extracted Figure 9-10: Graphics Driver Welcome Screen Figure 9-11: Graphics Driver License Agreement Figure 9-12: Graphics Driver Read Me File Figure 9-13: Graphics Driver Setup Operati o n s Figure 9-14: Graphics Driver Installation Finish Screen Figure 9-15: Touch Screen Driver Welcome Screen Figure 9-16: Touch Screen Driver License Agreement
..........................................................................................123
......................................................................................................................164
.............................................................................................165
............................................................................165
.......................................................................166
..................................................................................167
..........................................................................167
.............................................................168
................................................................................169
.................................................................169
.......................................................................170
...................................................................170
..............................................................................171
......................................................................172
........................................................172
...............................................................173
...........................................................174
Figure 9-17: Touch Screen Driver Choose Install Location Figure 9-18: Touch Screen Driver Installation Screen Figure 9-19: Touch Screen Driver Update Complete Figure 9-20: PenMount Monitor Icon Figure 9-21: PenMount Monitor Popup Menu Figure 9-22: Configuration Screen Figure 9-23: Calibration Initiation Screen Figure 9-24: Calibration Screen Figure 9-25: Audio Driver Welcome Screen Figure 9-26: Audio Driver Installation Figure 9-27: Audio Driver Installation Complete Figure 9-28: LAN Driver Welcome Screen Figure 9-29: LAN Driver Ready to Install Screen Figure 9-30: LAN Driver Setup Status Screen Figure 9-31: LAN Driver Installatio n Complete Figure 9-32: Intel® ME Driver Welcome Screen Figure 9-33: Intel® ME Driver License Agreement
...................................................174
............................................................175
..............................................................175
........................................................................................176
..........................................................................176
............................................................................................177
................................................................................177
................................................................................................178
.............................................................................179
.......................................................................................179
.....................................................................180
...............................................................................181
.....................................................................181
.........................................................................182
........................................................................182
......................................................................183
..................................................................184
AFL2-W19A/AB-H61
Page XV
Figure 9-34: Intel® ME Driver Read Me File .............................................................................184
Figure 9-35: Intel® ME Driver Setup Ope ra tions Figure 9-36: Intel® ME Driver Installation Finish Screen Figure 9-37: USB 3.0 Driver Welcome Screen Figure 9-38: USB 3.0 Driver License Agreement Figure 9-39: USB 3.0 Driver Installation Figure 9-40: USB 3.0 Driver Update Complete Figure 9-41: License Agreement Figure 9-42: Setup Type Figure 9-43: Configuration Tool Figure 9-44: Ready to Install the Program Figure 9-45: Setup Status Figure 9-46: Installation Complete Figure 9-47: The InstallShield Wizard Starts Figure 9-48: Welcome Screen Figure 9-49: Ready to Install Figure 9-50: Installation Figure 9-51: Installation Complete
.....................................................................185
.......................................................185
.........................................................................186
.....................................................................187
...................................................................................187
........................................................................188
...............................................................................................189
.............................................................................................................189
................................................................................................190
...............................................................................190
..........................................................................................................191
............................................................................................192
...........................................................................193
...................................................................................................193
......................................................................................................194
.............................................................................................................194
............................................................................................195
Figure 9-52: AMCap Driver Welcome Screen Figure 9-53: AMCap Driver Choose Install Location Figure 9-54: AMCap Driver Installatio n Complete Figure 10-1: Cooling Management Console Setup Wizard Figure 10-2: Select Installation Folder Figure 10-3: Confirm Installatio n Figure 10-4: Installation Complete
Figure 10-5: Restart the System ................................................................................................201
Figure 10-6: Cooling Management Console Icon Figure 10-7: iCMC Figure 10-8: iCMC Information Panel Figure 10-9: iCMC – Chart Panel Figure 10-10: iCMC – Time Interval Adjustment Figure C-1: IEI One Key Recovery Tool Menu Figure C-2: Launching the Recovery Tool Figure C-3: Recovery Tool Setup Menu Figure C-4: Command Prompt
..........................................................................196
...............................................................196
...................................................................197
.....................................................199
......................................................................................200
..............................................................................................200
............................................................................................201
....................................................................202
.......................................................................................................................202
........................................................................................203
...............................................................................................205
......................................................................206
.........................................................................216
...............................................................................221
...................................................................................221
..................................................................................................222
AFL2-W19A/AB-H61
Page XVI
Figure C-5: Partition Creation Commands ...............................................................................223
Figure C-6: Launching the Recovery Tool Figure C-7: Manual Recovery Environment fo r Windows Figure C-8: Building the Recovery Partition Figure C-9: Press Any Key to Continue Figure C-10: Press F3 to Boot into Recovery Mode Figure C-11: Recovery Tool Menu Figure C-12: About Symantec Ghost Window Figure C-13: Symantec Ghost Path Figure C-14: Select a Local Source Drive Figure C-15: Select a Source Partition from Basic Drive Figure C-16: File Name to Copy Image to Figure C-17: Compress Image Figure C-18: Image Creation Confirmation Figure C-19: Image Creation Complete Figure C-20: Image Creation Complete Figure C-21: Press Any Key to Continue Figure C-22: Auto Recovery Utility
...............................................................................225
......................................................225
............................................................................226
...................................................................................226
................................................................227
............................................................................................227
.........................................................................228
..........................................................................................228
................................................................................229
.......................................................229
................................................................................230
...................................................................................................230
..............................................................................231
....................................................................................231
....................................................................................231
.................................................................................232
...........................................................................................233
Figure C-23: Launching the Recovery Tool Figure C-24: Auto Recovery Environment for Windows Figure C-25: Building the Auto Recovery Partition Figure C-26: Factory Default Image Confirmation Figure C-27: Image Creation Complete Figure C-28: Press any key to continue Figure C-29: Partitions for Linux Figure C-30: Manual Recovery Environment for Linux Figure C-31: Access menu.lst in Linux (Text Mode) Figure C-32: Recovery Tool Menu Figure C-33: Recovery Tool Main Menu Figure C-34: Restore Factory Default Figure C-35: Recovery Complete Window Figure C-36: Backup System Figure C-37: System Backup Complete Window Figure C-38: Restore Backup Figure C-39: Restore System Backup Complete Window
.............................................................................233
........................................................233
.................................................................234
..................................................................234
....................................................................................235
...................................................................................235
...............................................................................................237
..........................................................238
...............................................................239
............................................................................................239
...................................................................................240
.......................................................................................241
...............................................................................242
.....................................................................................................242
....................................................................243
....................................................................................................243
......................................................244
AFL2-W19A/AB-H61
Page XVII
Figure C-40: Symantec Ghost Window ....................................................................................244
AFL2-W19A/AB-H61
Page XVIII
List of Tables
Table 1-1: AFL2-W19A/AB-H61 Model Variations ........................................................................ 3
Table 1-2: LED Indicators Table 1-3: Function Key Descriptions Table 1-4: System Specifications Table 2-1: LED Simulator Software Description Table 5-1: HDMI Pinouts Table 5-2: LAN1 Pinouts Table 5-3: LAN2 Pinouts Table 5-4: RS-232 Serial Ports Pinouts (COM1, COM2) Table 5-5: RS-422/485 Serial Port Pinouts (COM3) Table 5-6: USB 2.0 connectors Pinouts (bottom panel) Table 5-7: USB 2.0 connectors Pinouts (left side panel) Table 5-8: USB 3.0 connectors Pinouts Table 5-9: VGA Pinouts Table 6-1: Peripheral Interface Connectors Table 6-2: Auto-dimming Connector Pinouts Table 6-3: Battery Connector Pinouts Table 6-4: BIOS Programming Connector Pinouts
.............................................................................................................. 6
.......................................................................................... 8
................................................................................................13
........................................................................20
..............................................................................................................71
..............................................................................................................73
..............................................................................................................73
............................................................74
...................................................................75
...........................................................76
..........................................................76
.....................................................................................77
................................................................................................................78
...............................................................................82
............................................................................83
........................................................................................84
...................................................................85
Table 6-5: Bluetooth Connector Pinouts Table 6-6: CPU Fan Connector Pinouts Table 6-7: Debug Port Connector Pinouts Table 6-8: Digital Microphone Connector Pinouts Table 6-9: Debug Port Connector Pinouts Table 6-10: EC Programming Connector Pinouts Table 6-11: Hotkey Connector Pinouts Table 6-12: Hotkey LED Connector Pinouts Table 6-13: JSATA Connector Pinouts Table 6-14: K Type Thermocouple Connector Pinouts Table 6-15: LVDS Connector Pinouts Table 6-16: LVDS Backlight Inverter Connector Pinouts Table 6-17: LED Connector Pinouts
....................................................................................86
.....................................................................................87
.................................................................................89
....................................................................90
.................................................................................91
.....................................................................91
.......................................................................................92
..............................................................................93
.......................................................................................94
.............................................................96
.........................................................................................97
.........................................................98
...........................................................................................99
AFL2-W19A/AB-H61
Page XIX
Table 6-18: LED Bar Connectors Pinouts ................................................................................100
Table 6-19: LOGO LED Connector Pinouts Table 6-20: Mini USB Connector Pinouts (MINUSB2) Table 6-21: Mini USB Connector Pinouts (MINUSB1) Table 6-22: Power Button Connector Pinouts Table 6-23: RFID Connector Pinouts Table 6-24: SATA 3Gb/s Drive Connector Pinouts Table 6-25: SATA Power Connector Pinouts Table 6-26: Speaker Connector Pinouts Table 6-27: Touch Panel Connector Pinouts Table 6-28: Touch Panel Connector Pinouts Table 6-29: TPM Connector Pinouts Table 6-30: Web Camera Connector Pinouts Table 6-31: Jumpers Table 6-32: LVDS Voltage Selection Jumper Settings Table 6-33: LCD panel Selection Jumper Settings Table 8-1: BIOS Navigation Keys Table 10-1: iCMC Information Panel Description
..............................................................................101
.............................................................102
.............................................................103
.........................................................................104
........................................................................................105
..................................................................106
...........................................................................107
..................................................................................108
...........................................................................109
...........................................................................110
.........................................................................................111
...........................................................................112
...................................................................................................................113
............................................................114
..................................................................114
..............................................................................................127
....................................................................204
AFL2-W19A/AB-H61
Page XV

List of BIOS Menus

BIOS Menu 1: Main .....................................................................................................................128
BIOS Menu 2: Advanced BIOS Menu 3: ACPI Configuration BIOS Menu 4: RTC Wake Settings BIOS Menu 5: TPM Configuration BIOS Menu 6: CPU Configuration BIOS Menu 7: CPU Configuration BIOS Menu 8: IDE BIOS Menu 9: Intel TXT(LT) Configuration BIOS Menu 10: USB Configuration BIOS Menu 11: Super IO Configuration BIOS Menu 12: Serial Port n Configuration Menu BIOS Menu 13: Hardware Health Configuration BIOS Menu 14: Serial Port Console Redirection BIOS Menu 15: iEi Feature BIOS Menu 16: Chipset BIOS Menu 17: Northbridge Chipset Configuration BIOS Menu 18: Southbridge Chipset Configuration
Configuration ...............................................................................................136
............................................................................................................130
............................................................................................130
............................................................................................131
.............................................................................................133
.............................................................................................134
.............................................................................................135
...............................................................................137
...........................................................................................138
....................................................................................140
...................................................................140
......................................................................144
.....................................................................146
.........................................................................................................147
..............................................................................................................148
................................................................149
...............................................................151
BIOS Menu 19: Integrated Graphics BIOS Menu 20: ME Subsystem BIOS Menu 21: Boot BIOS Menu 22: Security BIOS Menu 23: Exit
BIOS Menu 24: iEi Feature .........................................................................................................236
.........................................................................................154
..................................................................................................156
...................................................................................................................157
.............................................................................................................159
.....................................................................................................................160
AFL2-W19A/AB-H61
Page 1
Chapter
1

1 Introduction

AFL2-W19A/AB-H61
Page 2

1.1 AFL2-W19A/AB-H61 Flat Bezel Panel PC Overview

Figure 1-1: AFL2-W19A/AB-H61 Flat Bezel Panel PC
The AFL2-W19A/AB-H61 is a 2nd Generation Intel® Core™ i7/ i5/ i3, Pentium® and Celeron® processor powered flat bezel panel PC with a rich variety of functions and peripherals. The AFL2-W19A/AB-H61 is designed for easy and simplified in tegration into kiosk and point-of-sales (POS) applications.
An Intel® H61 chipset ensures optimal memory, graphics, and peripheral I/O support. The system comes with 4GB DDR3 1333MHz SO-DIMMs (2GB x 2) ensuring smooth data throughputs with reduced bottlenecks and fast system access.
Three serial ports, three external USB 2.0 p orts and two external USB 3.0 ports ensure simplified connectiv ity to a variety of externa l peripheral devices. Wi-Fi capabilities and dual RJ-45 Ethernet connectors provide the system with smooth connection to an external LAN.
AFL2-W19A/AB-H61
Page 3

1.1.1 Model Variations

The model variations of the AFL2-W19A/AB-H61 Series are listed below.
Model No. Touch Screen LED Light Bar
Intel® Core™ i5 Series
AFL2-W19A-H61-i5/R-R11 Resistive Touch Yes AFL2-W19AB-H61-i5/R-R11 Resistive Touch No AFL2-W19A-H61-i5/PC-R11 Projected capacitive Yes AFL2-W19AB-H61-i5/PC-R11 Projected capacitive No Intel® Core™ i3 Series AFL2-W19A-H61-i3/R-R11 Resistive Touch Yes AFL2-W19AB-H61-i3/R-R11 Resistive Touch No AFL2-W19A-H61-i3/PC-R11 Projected capacitive Yes AFL2-W19AB-H61-i3/PC-R11 Projected capacitive No Intel® Pent ium® G6xxT Series AFL2-W19A-H61-P/R-R11 Resistive Touch Yes AFL2-W19AB-H61-P/R-R11 Resistive Touch No AFL2-W19A-H61-P/PC-R11 Projected capacitive Yes AFL2-W19AB-H61-P/PC-R11 Projected capacitive No
Table 1-1: AFL2-W19A/AB-H61 Model Variations

1.1.2 Features

The AFL2-W19A/AB-H61 features are listed below:
Programmable colorful LED light bar (for AFL2-W19AB-H61 series only)  2nd Generation Intel® Core™ i7/ i5/ i3, Pentium® and Celeron® processor  Two 204-pin DDR3 SO-DIMM slots (system max. 16GB)  Pre-installed 4GB DDR3 1333MH z SO-DIMMs (2GB x 2)  Projected capacitive touchscreen and 5-wire resistive type touch screen
supported
Wi-Fi 802.11b/g/n 2T2R high speed wireless  EM or Mifare RFID reader (on selected models)  Built-in 2M pixel webcam with AF, AE and AWB capabilities  Built-in two 2W speakers and microphone
AFL2-W19A/AB-H61
Page 4
IP64 compliant front panel  Auto dimming control  Light fanless design  K-type thermalcouple temperature sensor  Wide range 9~36 VDC input

1.1.3 Light Fanless Technology Des ign

AFL2-W19A/AB-H61 series panel PCs are designed with light fanless technology. The light fanless technology utilizes K-type thermocouple temperature sensor to detect environment temperature and control fan operation, enhancing system stability and remote environment control. The relative errors between the detect environment temperature and the actual environment temperature are no more than ±5 degrees. When the environment temperature is lower than default temperature setting, the fan will be switched off, showing the a dvantage of quiet and dust fr ee from fanless mode. W hile the environment temperature is higher, the smart fan will be turned on to speed up heat emission. The default temperature is 32 C and the setting can be adjusted in BIOS. See Section 8.3.9. The s ystems can be easily implem ented in the working environments th at require quiet and avoid dirt, like clean room, indoor HMI, and hospital.
AFL2-W19A/AB-H61
Page 5

1.2 Externa l Overview

1.2.1 Front Panel

The front side of the AFL2-W19A/AB-H61 is a flat bezel panel TFT LCD screen surrounded by a PC/ABS plastic frame. The LED light bars are for AFL2-W19AB-H61 series only.
Figure 1-2: AFL2-W19A/AB-H61 Front View
1.2.1.1 LED Indicators
There are sixteen LED indicator lig hts located along t he front of the LCD scr een (Figure 1-3).
Figure 1-3: LED Indicators
AFL2-W19A/AB-H61
Page 6
The descriptions of each LED indicator are listed below.
LED Indicator Des cription
Power
AT/ATX Mode
CPU Temperature Alert
Wi-Fi
RFID
Bluetooth
Auto-Dimming
Microphone
Shows power status. Orange: Standby mode. Blue: Power-on mode.
Shows the power mode status. Controlled by the AT/ATX power mode switch.
Blue: CPU temperature is normal. Red: CPU temperature is too high.
The Wi-Fi module is enabled or disabled. Controlled by the BIOS. See Section 8.5.2
The optional RFID reader is enabled or disabled. Controlled by the hot keys. See Table 1-3
The Bluetooth module is enabled or disabled. Controlled by the BIOS. See Section 8.5.2
The auto-dimming function is enabled or disabled. Controlled by the BIOS. See Section 8.5.2
The microphone is enabled or disabled. Controll ed b y the BIOS. See Section 8.5.2
Audio Mute
Mini USB
Function LCD On/Off Audio Volume Down Audio Volume Up Brightness Down Brightness Up
Table 1-2: LED Indicators
Red lights on when the audio is turned off. Controlled by the hot keys. See Table 1-3
The mini USB 2.0 module is enabled or disabled. Controlled by the hot keys. See Table 1-3
Shows the status of the function key below the LED indicator. Blinks when the corresponding button is pushed.
AFL2-W19A/AB-H61
Page 7
when the CPU
Darkest
Middle
1.2.1.2 LE D Light
To configure the LED I ndicators light through a quick and easy way, please follow the steps below:
NOTE:
The CPU temperature alert LED shows in red temperature reaches 80ºC.
If the CPU temperature alert LED shows in red, the user must lower the environments tem perature or close some running app lications to cool down the CPU.
Step 1: Double click the LED Light.exe icon
software.
Figure 1-4: LED Light Software (Auto)
Step 2: You can use the Auto option to adjust the LED Indicators light using preset
settings.
Step 3: Or you can use the Manual option to adjust the LED Indicators light using
following settings.
to open the LED Light
Brightest
Figure 1-5: LED Light Software (Manual)
AFL2-W19A/AB-H61
Page 8
1.2.1.3 Function Keys
The corresponding Function Ke ys are located under the bottom right han d corner of the LCD screen (Figure 1-6).
Figure 1-6: Function Keys
The Function Keys are described in Table 1-3:
Key Combination Function Key Des cription
Fn + LCD On/Off Fn + Audio Volume Down Fn + Audio Volume Up Fn + Brightness Down Fn + Brightness Up
Fn: The function key can maintain for 2sec.
Table 1-3: Function Key Descriptions
RFID Enable/Disable Audio Mute Camera Enable/Disable Mini USB / Micro SD Enable/Disable Power On/Off
Note: To power on the system, hold down the Fn + Brightness Up buttons for 3 seconds. To power down the system, hold down the FN + Brightness Up buttons for six seconds.
AFL2-W19A/AB-H61
Page 9

1.2.2 Rear Panel

The rear panel provides ac cess to retention screw holes that support various mounting. Refer to Figure 1-7.
Figure 1-7: AFL2-W19A/AB-H61 Rear View

1.2.3 Bottom Panel

The bottom panel of the AFL2-W19A/AB-H61 has the following features (Figure 1-8):
1 x AT/ATX Switch  1 x Clear CMOS switch  1 x 9V ~ 36V DC power jack  6 x Function keys  1 x HDMI port  1 x K-type connector  1 x Power button  1 x Reset button  1 x RJ-45 LAN connector  2 x RS-232 connectors (DB-9)  1 x RS-422/485 connector (DB-9)  1 x Temperature sensor
AFL2-W19A/AB-H61
Page 10
2 x USB 2.0 connectors  2 x USB 3.0 connectors  1 x VGA port
Figure 1-8: AFL2-W19A/AB-H61 Bottom Panel

1.2.4 Left Side Panel

The left side panel of the AFL2-W19A/AB-H61 has the following features (Figure 1-9):
2 x Audio jacks (Line out, MIC)  1 x RJ-45 LAN connector  1 x USB 2.0 connector
AFL2-W19A/AB-H61
Page 11
Figure 1-9: AFL2-W19A/AB-H61 Left Side Panel

1.2.5 Right Side Panel

The right side panel of the AFL2-W19A/AB-H61 provides access to the CD-ROM (optional) (Figure 1-10):
Figure 1-10: AFL2-W19A/AB-H61 Right Side Panel

1.3 Int ernal Ov er v iew

The AFL2-W19A/AB-H61 has the following components installed internally:
1 x Motherboard  2 x 2.0 GB 1333 MHz DDR3 SO-DIMMs
AFL2-W19A/AB-H61
Page 12

1.4 S ys tem Specifications

The technical specifications for the AFL2-W19A/AB-H61 systems are listed in Table 1-4.
Specification AFL2-W19A/AB-H61 LCD Size W18.9” (16:9) Max. Resolution 1440 (W) X 900 (H) Brightness (cd/m2) 250 Contrast Ratio 1000:1 LCD Color 16.7M Pixel Pitch (H x V) (mm) 0.2835(H) x 0.2835(V) Viewing Angle (H-V) 170° / 160° Backlight MTBF (hr) 30,000 Touch Screen 5-Wire resistive type touch screen (selected models only)
Projected capacitive type touch screen (selected models only)
CPU 2nd Generation Intel® Core™ i7/ i5/ i3, Pentium® and Celeron®
processor
Chipset Intel® H61 Ethernet Realtek RTL8111E PCIe GbE controller support ASF2.0 Memory Support two 204-pin DDR3 SO-DIMM slot (system max. 16GB)
preinstalled with 4GB (2GB x 2)
Expansion 1 x PCIe Mini slot for WiFi
1 x PCIe Mini slot reserved
HDD 2.5" SATA 2.0 HDD bay CD-ROM 1 x Slim Type CD-ROM bay (optional) Audio AMP 2 W + 2 W (built-in stereo speakers) Camera 2 M pixels with low lig ht func tio n Wireless 1 x Wireless LAN 802.11 b/g/n module
(internal PCIe Mini card interface) 1 x Bluetooth function (optional internal USB interface, B lue tooth V2.1+EDR)
RFID Reader EM 125 KHz or MIFARE 13.56 MHz card reader (optional) MSR card reader MSR card reader (Optional) TPM Reserved by pin-header
AFL2-W19A/AB-H61
Page 13
OSD Function LCD on / off, brightness up / down, volume up / down, Hot Key Construction Material PC + ABS plastic front frame Mounting Panel/Wall/Stand/Arm (VESA 100 mm x 100 mm) Front Panel Color Black Weight (Net/Gross) 7.9 kg / 10.0 kg Dimensions (W x H x D) (mm) 488 x 361x 65 Operation Temperature -20ºC ~ 40ºC (Ambient with air flow) Storage Temperature -20ºC ~ 60ºC Humidity 10% to 95% (non-condensing) IP level IP 64 compliant front panel Power Supply 120W power adapter
Input: 100V AC ~ 240V AC @ 50 / 60 Hz Output: 19V DC
Power Requirement 9V ~ 36V DC I/O Ports and Switches 2 x RS-232 (DB-9 connector)
1 x RS-422/485 (DB-9 connector) 2 x GbE LAN (one on bottom side, one on left side) 2 x USB 3.0 connector 3 x USB 2.0 connectors (two on bottom side, one on left side) 1 x Mini USB 2.0 connector (on front panel) 1 x Micro SD card slot (o n front pane l) 1 x Audio jack (line-out, MIC) 1 x VGA port (DB15 connector) 1 x HDMI port 1 x Power switch 1 x AT/ATX switch 1 x Reset button 1 x Clear CMOS button 1 x 9 V ~ 36V DC input jack 1 x k-type connector
Table 1-4: System Specifications
AFL2-W19A/AB-H61
Page 14
Chapter
2

2 LED Light Bar (Optional)

AFL2-W19A/AB-H61
Page 15

2.1 Overview

To notify field staffs in an efficient way to increase productivity, the AFL2-W19A-H61 integrates LED dash light s ystem on the side fr ame. With the provided A PI software and LED simulator software, us ers can customize their notification according to t heir needs through a quick and eas y user interface. The customized functions inc lude light scripts, programmable colors, light duration, flash rates and light patterns.

2.2 iEi LE D Light Bar Display Simulat or

To configure the LED light bars by iEi LED Light Bar Display Simulator, p lease f ollow the steps below:
Step 4: Make sure LED Bar driver is properly installed. See Sect ion 9.11.
Step 5: Double click the
Display Simulator.
Step 6: The Setup Wizard starts (Figure 2-1).
icon to setup the iEi LED Light Bar
Figure 2-1: The Setup Wizard Starts
AFL2-W19A/AB-H61
Page 16
Step 7: Click Next to continue.
Step 8: The Select Installation F o lder screen in Figure 2-2 appears.
Figure 2-2: Select Installation Folder Screen
Step 9: Click Next to continue.
Step 10: The Confirm Installation screen in Figure 2-3 appears.
Step 11: Click Next to proceed with the installation.
AFL2-W19A/AB-H61
Page 17
Figure 2-3: Confirm Installation Screen
Step 12: The program begins to install.
Step 13: When the installation is complete, the screen in Figure 2-4 appears.
AFL2-W19A/AB-H61
Page 18
Figure 2-4: Installation Complete
Step 14: Click Close to complete the installation.
Step 15: The iEi LED Light Bar Display Simulator icon
desktop.
Step 16: Double click it to open the iEi LED Light Bar Display Simulator, as shown in
Figure 2-5.
shows on the computer
AFL2-W19A/AB-H61
Page 19
.
Figure 2-5: iEi LED Light Bar Display Simulator
The descriptions of iEi LED Light Bar Display Simulator are listed below.
Function Des cription
New Load Save Run Add Copy Delete UP Down
Clear all current commands Load the configuration file ( *.cld ) Save all current commands Start to simulate the LED display Add a new command Copy a command Delete a command Move the command up
Move the command down Loop Start Loop End
Set loop start point.
Set Loop end point
AFL2-W19A/AB-H61
Page 20
Basic Color
User Defined Color
Function Des cription
ALL TOP LEFT RIGHT 1~34
Table 2-1: LED Simulator Software Description
Step 17: Select the color. The color setting area includes basic color and user defined
color. Click the basic color to select the desired color.
Select all the LED simulation buttons
Select the top LED simulation buttons
Select the left LED simulation buttons
Select the right LED simulation buttons
LED simulation buttons
Figure 2-6: Color Setting Area
Step 18: Or you can double click the user defined color to open the color palette and
select the desired color.
Figure 2-7: Color Palette
AFL2-W19A/AB-H61
Page 21
Step 19: After setting the color, click LED simulation button and the color of selected LED
simulation button will automatically change. See Figure 2-8.
Figure 2-8: Simulate the LED Light
Step 20: If you want to set all the left LED simulation buttons for a certain color at the
same time, click the “LEFT" button. Setting the right LED simulation buttons and top LED simulation buttons are the same way.
AFL2-W19A/AB-H61
Page 22
Figure 2-9: Set the Left LEDs
Step 21: If you want to set all the LED simulation buttons for a certain color at the same
time, click the “ALL" button.
Figure 2-10: Set All the LEDs
AFL2-W19A/AB-H61
Page 23
Step 22: Enter the light duration. Please note that the unit is second, enter a number
between 1 and 20. See Figure 2-11.
Figure 2-11: Light Duration
Step 23: Press the Add button to insert a new control command. You may continue to set
a new command in accordance with Step14 ~ Step19.
AFL2-W19A/AB-H61
Page 24
Figure 2-12: Add new command
Step 24: Press the Loop Start button to set loop start poi nt.
Figure 2-13: Add Loop Start
Step 25: Press the Loop End button to set loop end point.
AFL2-W19A/AB-H61
Page 25
Figure 2-14: Add Loop End
Step 26: Press the Run button to simulate.

2.3 iEi LE D Run

To configure the LED light bars through a quick and easy way, please follo w the steps below:
Step 1: Make sure the LED Bar driver is properly installed. See Section 9.11.
Step 2: Double click the LED-RUN.exe icon
software, as shown in Figure 2-15.
to open the LED RUN
Figure 2-15: iEi LED RUN Software
Step 3: The LED light bars start to dash in a preset mode.
AFL2-W19A/AB-H61
Page 26

2.4 LED Control API

2.4.1 Introduction

This chapter aims to explain how to use LED Light Bar Control API, and support API version is V1.0.0.7. Due LED Light Bar driver only has x86 version, this API could be used in the Windows 2000/XP(x86)/2003/7(x86) environments.
2.4.1.1 Programming Language Support
The iEi LED Light Bar Control application provides an interface to driver with:
Microsoft Visual C/C++  Microsoft Visual Basic  Other programming systems that can access functions into DLL's
2.4.1.2 Applica tion Content
The iEi LED Light Bar Control application includes the following files:
IBS_LEDCTRL.dll  IBS_LEDCTRL.lib  IBS_LEDCTRL.h

2.4.2 LED Control API Functions

2.4.2.1 LIGHTBAR_Drive rInit
Syntax: PACSM_LIGHTBAR_CTRL STD_HANDLE LIGHTBAR_DriverInit(void)
Parameters: NONE
Return value: Return a Handle from LED driver.
Remarks: Call this function to initial and start the LED Driver and retur n a Ha ndle fro m LED
driver.
AFL2-W19A/AB-H61
Page 27
2.4.2.2 LIGHTBAR_DriverUninit
Syntax: PACSM_LIGHTBAR_CTRL STD_Void LIGHTBAR_DriverUninit(HANDL E hDev)
Parameters: hDev [IN] – Handle be released.
Return value: True if success.
Remarks: Call this function to stop and uninitialized the LED Driver and to release resource of
Handle.
2.4.2.3 LIGHTBAR_De viceIn it
Syntax: PACSM_LIGHTBAR_CTRL STD_BOOLEN LIGHTBAR_DeviceInit(HANDLE hDev)
Parameters: hDev [IN] – Input Handle.
Return value: True if success.
Remarks: Call this function to initial the LED IC.
2.4.2.4 LIGHTBAR_DeviceClos e
Syntax: PACSM_LIGHTBAR_CTRL STD_BOOLEN LIGHTBAR_DeviceClose(HANDLE hDev)
Parameters: hDev [IN] – Input Handle.
Return value: True if success.
Remarks: Call this function to turn off LED IC.
AFL2-W19A/AB-H61
Page 28
2.4.2.5 LIGHTBAR_Brightness_Single
Syntax: PACSM_LIGHTBAR_CTRL STD_BOOLEN LIGHTBAR_Brightness_Single(
Parameters: hDev [IN] – Input Handle.
Brightness_Step [IN] –Point to structures buffer s to write. (see Section 2.4.3) INFO_Size [IN] – describe the data structure array size.
Return value: True if success.
Remarks: Write data to LED IC on I2C bus via drivers. This function creates data structures
include the target LED IC address and Brightness information to send to LED IC via
HANDLE hDev, PLED_COLOR_INFO Brightness_Step, int INFO_Size)
LED Driver.
2.4.2.6 LIGHTBAR_BLNK_Settings
Syntax: PACSM_LIGHTBAR_CTRL STD_BOOLEN LIGHTBAR_BLNK_Settings(
HANDLE hDev, PLED_BLNK_SET LED_Blinking_ Set)
Parameters: hDev [IN] – Input Handle.
LED_Blinking_Set [IN] –Point to structures buffers to write. (see Section 2.4.3)
Return value: True if success.
Remarks: This function is used to set LED IC Blinking modes via drivers.
AFL2-W19A/AB-H61
Page 29
2.4.2.7 LIGHTBAR_BLNK_Type
Syntax: PACSM_LIGHTBAR_CTRL STD_BOOLEN LIGHTBAR_BLNK_Type(
Parameters: hDev [IN] – Input Handle.
Brightness_Step [IN] –Point to structures buffer s to write. (see Section 2.4.3)
Return value: True if success.
Remarks: This function is used to turn on/off LED IC blinking control via drivers.
2.4.2.8 LIGHTBAR_LED_ModeSet
HANDLE hDev, PLED_BLNK_TYPE Blinking_Type)
Syntax: PACSM_LIGHTBAR_CTRL STD_BOOLEN LIGHTBAR_LED_ModeSet (
HANDLE hDev, PLED_MODE_SETTINGS LED_Mode_Settings)
Parameters: hDev [IN] – Input Handle.
LED_Mode_Settings [IN] –Point to structures buffers to write. (see Section 2.4.3)
Return value: True if success.
Remarks: This function is used to set each LED operation mode on LED IC via drivers.
AFL2-W19A/AB-H61
Page 30

2.4.3 Structures

2.4.3.1 _LED_COLOR_INFO
Syntax: typedef struct _L E D_COLOR_I N FO {
LED_INFO LED_Info; int R_LE V EL; int G_LEV EL; int B_LEV EL; }LED_COLOR_INFO, *PLED_COLOR_INFO;
Parameters:
Remarks: This s tr uc ture has included essential information to set LED IC.
R_LEVEL、G_LEVEL、B_LEVEL [int] - Store the Brightness Level information for
R, G and B LED. The brightness level was from 0 to 7. LED_Info [structure] - The LED IC address was stored in Main_Addr on the I2c bus, and LED List number are stored in R_LN、G_LN and B_LN parameters: typedef struct _LED_INFO { UCHAR Main_Addr; //Main address UCHAR R_LN; //Red list number UCHAR G_LN; //Green list number UCHAR B_LN; //B lue li s t numb e r } LED_INFO, *PL ED_INFO ;
2.4.3.2 _LED_BLNK_SET
Syntax: typedef struct _LED_BLNK_SET{
UCHAR Main_Addr; //Main address BYTE BLNK_DutCyc; //Duty Cycle BYTE BLNK_Freq; //Blink ing Frequency }LED_BLNK_SET, *PLED_BLNK_SET;
Parameters:
Main_Addr [UCHAR] - IC Address on I2C bus. BLNK_DutCyc [BYTE] - Duty Cycle of LED blinking. Duty cycle = (0 ~ 255)/256 = x% BLNK_Freq [BYTE] -Frequency of LED blinking. 0x00 = (41ms,
AFL2-W19A/AB-H61
Page 31
Remarks: This structure has used to store the blinking duty cycle and freque ncy of LED IC.
2.4.3.3 _LED_BLNK_SET
Syntax: typedef struct _LED_BLNK_TYPE{
frequency 24H z)0xFF = (1 0.73s)Frequency = [(0~255) + 1]/24= x(second)Ex300ms = (7 + 1) / 24 0.333s
Please attention one LED IC only has one duty cycle and frequency to be group used, It means all LED has the same blink mode on a LED IC.
UCHAR Main_Addr; //Main addr e ss int BLNK_TYPE; }LED_BLNK_TYPE, *PLED_BLNK_TYPE;
Parameters:
Remarks: This structure has used to turn on/off blinking circuit on the LED IC.
Main_Addr [UCHAR] – IC Address on I2C bus. BLNK_Type [i nt] - T urn on/off blinking circuit on the LED IC. Defined
by: #define LED_BLNK_ON 0 #define LED_BLNK_OFF 1
AFL2-W19A/AB-H61
Page 32
2.4.3.4 _LED_MODE_SETTINGS
Syntax: typedef stru c t _LED_MODE_ SETTING S {
UCHAR Main_Addr; //Main addr e ss int LED_00; int LED_01; int LED_02; int LED_03; int LED_04; int LED_05; int LED_06; int LED_07; int LED_08; int LED_09; int LED_10; int LED_11; int LED_12; int LED_13; int LED_14; }LED_MODE_SETTINGS, *PLED_M O DE_SETTINGS;
Parameters:
Remarks: This structure can decision operation mode for each LED.
Main_Addr [UCHAR] – IC Address on I2C bus. LED_00 ~ LED_15: Each LED operation mode, defined by
#define LED_DispMode_OFF 0 //Turn OF F LED. #define LED_DispMode_Gen 1 //General Mode #define LED_DispMode_BLNK 2 //Blinking Mode

2.4.4 Programming Ex ample

2.4.4.1 Turn on LED - s ingle
{ //Define Data structure PLED_PWM_INFO LEDCOLOR = (PLED_PWM_INFO)ma llo c (size o f(LED_PWM_INFO));
AFL2-W19A/AB-H61
Page 33
HANDLE hSMB_Dev = LIGHTBAR_DriverInit();//I nit S MB A PI dri v er and get dev ice Handle.
LIGHTBAR_DeviceInit(hSMB_ D e v);//Init Target device
//Set LED level information. LEDCOLOR.R_LEVEL = 7; LEDCOLOR.G _LEVEL = 7; LEDCOLOR.B _LEVEL = 7;
//Set LED Address LEDCOLOR.LED_Info.Main_A ddr = 0xC0 ; LEDCOLOR.LE D_Info.R_L N = 0x00; LEDCOLOR.LE D_Info.G_L N = 0x01; LEDCOLOR.LE D_Info.B_L N = 0x02;
If(LIGHTBAR_Brightness_Single(hSMB_Dev, LEDCOLOR, 1) == False){ //Error message }
LIGHTBAR_DeviceClose(hSMB_Dev); //Close Device. LIGHTBAR_DriverUninit(hSMB_Dev); //Close Driver Handle
delete LEDCOLOR; }
2.4.4.2 Turn on LED - multiple
{ //Define Data structure PLED_PWM_INFO LEDCOLOR = (PLED_PWM_INFO)ma llo c (size o f(LED_PWM_INFO) * 4); HANDLE hSMB_Dev = LIGHTBAR_DriverInit();//I nit S MB A PI dri v er and get dev ice Handle.
LIGHTBAR_DeviceInit(hSMB_ D e v);//Init Target device
LEDCOLOR [0].LED_Info.Main_Addr = 0xD0; LEDCOLOR [0].LED_Info .R_LN = 0x02; LEDCOLOR [0].LED_Info.G_LN = 0x03; LEDCOLOR [0].LED_Info.B_LN = 0x04; LEDCOLOR [0].R_LEVEL = 7;
AFL2-W19A/AB-H61
Page 34
LEDCOLOR [0].G_LEVE L = 7; LEDCOLOR [0].B_LEVE L = 7;
LEDCOLOR [1].LED_Info.Main_Addr = 0xD0; LEDCOLOR [1].LED_Info.R_LN = 0x05; LEDCOLOR [1].LED_Info.G_LN = 0x06; LEDCOLOR [1].LED_Info.B_LN = 0x07; LEDCOLOR [1].R_LEVEL = 7; LEDCOLOR [1].G_LEVE L = 7; LEDCOLOR [1].B_LEVE L = 7;
LEDCOLOR [2].LED_Info.Main_Addr = 0xD0; LEDCOLOR [2].LED_Info.R_LN = 0x08; LEDCOLOR [2].LED_Info.G_LN = 0x 09; LEDCOLOR [2].LED_Info.B_LN = 0x0a; LEDCOLOR [2].R_LEVEL = 7; LEDCOLOR [2].G_LEVE L = 7; LEDCOLOR [2].B_LEVE L = 7;
LEDCOLOR [3].LED_Info.Main_Addr = 0xD0; LEDCOLOR [3].LED_Info.R_LN = 0x0b; LEDCOLOR [3].LED_Info.G_LN = 0x0c; LEDCOLOR [3].LED_Info.B_LN = 0x0d; LEDCOLOR [3].R_LEVEL = 7; LEDCOLOR [3].G_LEVE L = 7; LEDCOLOR [3].B_LEVE L = 7;
LEDCOLOR [4].LED_Info.Main_Addr = 0xD0; LEDCOLOR [4].LED_Info.R_LN = 0x0e; LEDCOLOR [4].LED_Info.G_LN = 0x0f; LEDCOLOR [4].LED_Info.B_LN = 0x10; LEDCOLOR [4].R_LEVEL = 7; LEDCOLOR [4].G_LEVE L = 7; LEDCOLOR [4].B_LEVE L = 7;
If(LIGHTBAR_Brightness_Single(hSMB_Dev, LEDCOLOR, 5) == False){ //Error message }
AFL2-W19A/AB-H61
Page 35
LIGHTBAR_DeviceClose(hSMB_Dev); //Close Device. LIGHTBAR_DriverUninit(hSMB_Dev); //Close Driver Handle
delete LEDCOLOR; }
2.4.4.3 LE D Blink - 1
{ PLED_MODE_SETTINGS LED_ModeSet = (PLED_MODE_SETTINGS)malloc(sizeof(LED_MODE_SETTINGS)); PLED_BLNK_SET LED_Blinking_Set = (P LED_BLNK_SET)malloc(sizeof(LED_BLNK_SET)); PLED_BLNK_TYPE LED_Blinking_Type = (PLED_BLNK_TYPE)malloc(sizeof(LED_BLNK_TYPE));
// Set Structure: Set Broadcast address LED_ModeSet.Main_Addr = 0xD0; LED_Blinking_Set.Main_Addr = 0xD0; LED_Blinking_Type.Main_Addr = 0xD0;
//Set Structure: Set blinking settings. LED_Blinking_Set.BLNK_Freq = 0x07; //300ms LED_Blinking_Set.BLNK_DutCyc = 0x80; //50:50
//Set Structure: Set each LED operation mode. LED_ModeSet.LED_00 = LED_DispMode_BLNK; //R LED_ModeSet.LED_01 = LED_DispMode_BLNK; //G LED_ModeSet.LED_02 = LED_DispMode_BLNK; //B LED_ModeSet.LED_03 = LED_DispMode_BLNK; //R LED_ModeSet.LED_04 = LED_DispMode_BLNK; //G LED_ModeSet.LED_05 = LED_DispMode_BLNK; //B LED_ModeSet.LED_06 = LED_DispMode_BLNK; //R LED_ModeSet.LED_07 = LED_DispMode_BLNK; //G LED_ModeSet.LED_08 = LED_DispMode_BLNK; //B LED_ModeSet.LED_09 = LED_DispMode_BLNK; //R LED_ModeSet.LED_10 = LED_DispMode_BLNK; //G LED_ModeSet.LED_11 = LED_DispMode_BLNK; //B LED_ModeSet.LED_12 = LED_DispMode_BLNK; //R LED_ModeSet.LED_13 = LED_DispMode_BLNK; //G
AFL2-W19A/AB-H61
Page 36
LED_ModeSet.LED_14 = LED_DispMode_BLNK; //B LED_ModeSet.LED_15 = LED_DispMode_BLNK;
//Set Structure: Enable blinking of IC LED_Blinking_Type.BLNK_TYPE = LED_BLNK_ON;
LIGHTBAR_BLNK_Settings(hSMB_Dev, LED_Blink ing _S e t); //Set LED blinking settings. LIGHTBAR_LED_ModeSet(hSMB_Dev, LED_ModeSet) //Set LED Operation Mode. LIGHTBAR_BLNK_Type(hSMB_Dev, LED_Blinking_ Typ e ); //E nab le LE D B linking. }
2.4.4.4 LE D Blink - 2
{ PLED_MODE_SETTINGS LED_ModeSet = (PLED_MODE_SETTINGS)malloc(sizeof(LED_MODE_SETTINGS)); PLED_BLNK_SET LED_Blinking_Set = (P LED_BLNK_SET)malloc(sizeof(LED_BLNK_SET)); PLED_BLNK_TYPE LED_Blinking_Type = (PLED_BLNK_TYPE)malloc(sizeof(LED_BLNK_TYPE));
// Set Structure: Set Broadcast address LED_ModeSet.Main_Addr = 0xD0; LED_Blinking_Set.Main_Addr = 0xD0; LED_Blinking_Type.Main_Addr = 0xD0;
//Set Structure: Set blinking settings. LED_Blinkin g_Set.BLNK _Freq = 0x07; //300ms LED_Blinking_Set.BLNK_DutCyc = 0x80; //50:50
//Set Structure: Set each LED operatio n mode. LED_ModeSet.LED_00 = LED_DispMode_Gen; //R LED_ModeSet.LED_01 = LED_DispMode_Gen; //G LED_ModeSet.LED_02 = LED_DispMode_Gen; //B LED_ModeSet.LED_03 = LED_DispMode_BLNK; //R LED_ModeSet.LED_04 = LED_DispMode_BLNK; //G LED_ModeSet.LED_05 = LED_DispMode_BLNK; //B
AFL2-W19A/AB-H61
Page 37
LED_ModeSet.LED_06 = LED_DispMode_Gen; //R LED_ModeSet.LED_07 = LED_DispMode_Gen; //G LED_ModeSet.LED_08 = LED_DispMode_Gen; //B LED_ModeSet.LED_09 = LED_DispMode_BLNK; //R LED_ModeSet.LED_10 = LED_DispMode_BLNK; //G LED_ModeSet.LED_11 = LED_DispMode_BLNK; //B LED_ModeSet.LED_12 = LED_DispMode_Gen; //R LED_ModeSet.LED_13 = LED_DispMode_Gen; //G LED_ModeSet.LED_14 = LED_DispMode_Gen; //B LED_ModeSet.LED_15 = LED_DispMode_BLNK;
//Set Structure: Enable blinking of IC LED_Blinking_Type.BLNK_TYPE = LED_BLNK_ON;
LIGHTBAR_BLNK_Settings (hSMB_ De v , LED_Bli nk ing_Set); //Set LED blinking settings. LIGHTBAR_LED_ModeSet(hSMB_Dev, LED_ModeSet) //Set LED Operation Mode. LIGHTBAR_BLNK_Type(hSMB_Dev, LED_Blinking_Typ e ); //Enable LED Blinking. }
NOTE:
. The LED addresses are s ho wn belo w.
AFL2-W19A/AB-H61
Page 38
LED_R_ListNumber = 02
LED_G_ListNumber = 03
LED_B_ListNumber = 04
LED_R_ListNumber = 05
LED_G_ListNumber = 06
LED_B_ListNumber = 07
LED_R_ListNumber = 08
LED_G_ListNumber = 09
LED_B_ListNumber = 0A
LED_R_ListNumber = 0B
LED_G_ListNumber = 0C
LED_B_ListNumber = 0D
LED_R_ListNumber = 0E
LED_G_ListNumber = 0F
LED_B_ListNumber = 10
LED_R_ListNumber = 02
LED_G_ListNumber = 03
LED_B_ListNumber = 04
LED_R_ListNumber = 05
LED_G_ListNumber = 06
LED_B_ListNumber = 07
LED_R_ListNumber = 02
LED_G_ListNumber = 03
LED_B_ListNumber = 04
LED_R_ListNumber = 05
LED_G_ListNumber = 06
LED_B_ListNumber = 07
LED_R_ListNumber = 08
LED_G_ListNumber = 09
LED_B_ListNumber = 0A
LED_R_ListNumber = 0B
LED_G_ListNumber = 0C
LED_B_ListNumber = 0D
LED_R_ListNumber = 0E
LED_G_ListNumber = 0F
LED_R_ListNumber = 02
LED_G_ListNumber = 03
LED_B_ListNumber = 04
LED_R_ListNumber = 05
LED_G_ListNumber = 06
LED_B_ListNumber = 07
LED_B_ListNumber = 10
LED_B_ListNumber = 10
LED_G_ListNumber = 0F
LED_R_ListNumber = 0E
LED_B_ListNumber = 0D
LED_G_ListNumber = 0C
LED_R_ListNumber = 0B
LED_B_ListNumber = 0A
LED_G_ListNumber = 09
LED_R_ListNumber = 08
LED_B_ListNumber = 07
LED_G_ListNumber = 06
LED_R_ListNumber = 05
LED_B_ListNumber = 04
LED_G_ListNumber = 03
LED_R_ListNumber = 02
LED_B_ListNumber = 10
LED_G_ListNumber = 0F
LED_R_ListNumber = 0E
LED_B_ListNumber = 0D
LED_G_ListNumber = 0C
LED_R_ListNumber = 0B
LED_B_ListNumber = 0A
LED_G_ListNumber = 09
LED_R_ListNumber = 08
LED_B_ListNumber = 07
LED_G_ListNumber = 06
LED_R_ListNumber = 05
LED_B_ListNumber = 04
LED_G_ListNumber = 03
LED_R_ListNumber = 02
CA
C8
C6
C4
ADDRESS
CC
CE
DC
DE
LED_R_ListNumber = 02
LED_G_ListNumber = 03
LED_B_ListNumber = 04
LED_R_ListNumber = 05
LED_G_ListNumber = 06
LED_B_ListNumber = 07
LED_R_ListNumber = 08
LED_G_ListNumber = 09
LED_B_ListNumber = 0A
LED_R_ListNumber = 0B
LED_G_ListNumber = 0C
LED_B_ListNumber = 0D
LED_R_ListNumber = 0E
LED_G_ListNumber = 0F
LED_B_ListNumber = 10
LED_R_ListNumber = 02
LED_G_ListNumber = 03
LED_B_ListNumber = 04
LED_R_ListNumber = 05
LED_G_ListNumber = 06
LED_B_ListNumber = 07
LED_R_ListNumber = 08
LED_G_ListNumber = 09
LED_B_ListNumber = 0A
LED_R_ListNumber = 0B
LED_G_ListNumber = 0C
LED_B_ListNumber = 0D
LED_R_ListNumber = 0E
LED_G_ListNumber = 0F
LED_B_ListNumber = 10
AFL2-W19A/AB-H61
Page 39
Chapter
3

3 Detailed Specifications

AFL2-W19A/AB-H61
Page 40

3.1 Dimensions

The AFL2-W19A/AB-H61 dimensions are shown below.
Width: 488.0 mm  Height: 361.0 mm  Depth: 65.0 mm
Figure 3-1: AFL2-W19A/AB-H61 Dimensions (mm)
AFL2-W19A/AB-H61
Page 41

3.2 In te l® Core™ Desktop Processor

An Intel® 2nd generation Core™ desktop processor is ins ta lle d in t h e s yst em. The Sandy Bridge CPU interfaces with the H61 chipset through a Direct Media Interf ace (DM I) and a Flexible Display Interface (FDI).

3.3 Motherboard Components

The following sections describe some of the features on the motherboard.

3.3.1 Me mory Capacity

Two 204-pin 1066/1333 MHz dual-channe l DDR3 SDR AM SO-DIMMs supported (system max. 16GB) in the AFL2-W19A/AB-H61 and controlled by the Intel® Core™ desktop processor installed on the internal motherboard.

3.3.2 Storage Capacity

The AFL2-W19A/AB-H61 comes equipped with a 2.5” SATA 2.0 HDD drive bay which can be easily accessed by removing two screws on the HDD cover.

3.4 Ext ernal Peripheral Interface Connectors

The following section describes the external peripheral interface connectors on the bottom panel and left side panel of the system.

3.4.1 Se rial Port Connectors

The AFL2-W19A/AB-H61 h as three serial ports. COM1 and COM2 support only RS-232 serial communications . The other ser ial port (COM 3) can be conf igured as an RS-422 or RS-485 serial port. Enabling COM devices to be powered through the COM port eliminates unnecessary and messy cabling.
AFL2-W19A/AB-H61
Page 42
Figure 3-2: Serial Ports

3.4.2 LAN Connectivity

The AFL2-W19A/AB-H61 has one RJ-45 LAN connector on the bottom panel and one RJ-45 LAN connector on the left side panel.
Figure 3-3: RJ-45 Ethernet Connector (Bottom Panel)
AFL2-W19A/AB-H61
Page 43
Figure 3-4: RJ-45 Ethernet Connector (Left Side Panel)
The PCIe LAN from the Intel® H61 chipset of the AFL2-W19A/AB-H61 is interfaced to the Realtek RTL8111E PCIe gigabit Ethernet (GbE) controllers. The RTL8111E controllers are connected directly to the RJ-45 connectors and provide external GbE connectivity.

3.4.3 External USB Connectors

There are two USB 2.0 connectors and two US B 3.0 c onnect ors on the bottom panel and one USB 2.0 connector on the left side panel of the AFL2-W19A/AB-H61. All USB connectors are full y compli ant with US B specif ication R evision 2. 0 and USB specif ication Revision 1.1 and can be in t erf ac ed to both USB 1.1 and USB 2.0 complia nt de vic es . Only USB 3.0 connectors are compatible with USB 3.0 devices.
Figure 3-5: External USB Ports (Bottom Panel)
AFL2-W19A/AB-H61
Page 44
Figure 3-6: External USB Ports (Left Side Panel)

3.5 Audio

3.5.1 Audio Codec Controller

The integrated HD Audio compliant audio controller on the Intel® H61 PCH is integrated to a Realtek ALC892 audio codec. T he Realtek ALC892 is connected to two external aud io jacks (Line out, MIC), wh ich are then connected t o com pliant audio devices. T he Realtek ALC892 is a 7.1+2 channel high definition audio codec with ten DAC channels. It supports
7.1 sound playbac k and 2 channels of indep endent st ereo so und output . The a udio jacks are shown in Figure 3-7.
Figure 3-7: Audio Jack

3.5.2 Stereo Speakers

Two internal 2 W stereo speak ers on the s ides of the AFL2-W19A/AB-H61 are interfaced to the system.
AFL2-W19A/AB-H61
Page 45
Chapter
4

4 Unpacking

AFL2-W19A/AB-H61
Page 46

4.1 Unpacking

To unpack the flat bezel panel PC, follow the steps below:
WARNING!
The front side LCD screen has a protective plastic cover stuck to the screen. Only remove the plastic cover after the flat bezel panel PC has been properly installed. This ensures the screen is protected during the installation process.
Step 1: Use box cutters, a knife or a sharp pair of scissors that seals the top side of the
external (second) box.
Step 2: Open the external (second) box.
Step 3: Use box cutters, a knife or a sharp pair of scissors that seals the top side of the
internal (first) box.
Step 4: Lift the monitor out of the boxes.
Step 5: Remove both polystyrene ends, one from each side.
Step 6: Pull the plastic cover off the flat bezel panel PC.
Step 7: Make sure all the components listed in the packing list are present. Ste p 0:

4.1.1 Pack ing Lis t

The AFL2-W19A/AB-H61 flat bezel panel PC is shipped with the following components:
Quantity Item Image
Standard
1 AFL2-W19A/AB-H61 panel PC
AFL2-W19A/AB-H61
Page 47
1 Power adapter
(P/N: 63000-FSP120AAB-RS)
1 Power cord
(P/N: 32702-000401-100-RS)
1 Power transfer cord
(P/N: 32000-089400-RS)
1 Infrared Remote Controller
(P/N: 7Z000-SLPCB005-RS)
1 IO bracket
(P/N: 41013-0290C2-00-RS)
1 Temperature Sensor Cable
(P/N: 32133-004300-100-RS)
1 Pen
(P/N: 43125-0002C0-00-RS)
4 M3 screw pack
(P/N: 44013-030041-RS)
4 M4 screw pack
(P/N: 44033-040061-RS)
1 Utility CD
1 One Key Recovery CD
Optional
AFL2-W19A/AB-H61
Page 48
Panel Mounting Kit (P/N: AFL2PK-15B)
Wall mounting kit (P/N: AFLWK-19/AFLWK-19B)
Rack Mounting Kit (P/N: AFL2RK-19A) Arm (P/N: ARM-31-RS)
Stand (P/N: STAND-A19/ STAND-B19/ STAND-C19/ STAND-210-R11)
Hybrid Card Reader (P/N: AFL2P-12AMSI-U-R10)
Magnetic Stripe Reader (P/N: AFL2P-12AMSR-U-R10)
Slim DVD Burner (P/N: 73400-AD7700S01-RS) Bluetooth Module Kit (P/N: AFL2-BT-KIT01-R11)
AFL2-W19A/AB-H61
Page 49
Trusted Platform Module (TPM) (P/N: TPM-IN01-R11) OS: Win CE 6.0 (DVD-ROM) (P/N: AFL2-17A-H61-CE060-R10) OS: Win XPE (DVD-ROM) (P/N: AFL2-17A-H61-XPE-R10) OS: Linux (DVD-ROM) (P/N: AFL2-17A-H61-LNX-R10) OS: Win 7 Embedded (DVD-ROM) (P/N: AFL2-17A-H61-WES7P-R10
AFL2-17A-H61-WES7E-R10)
If any of these items are missing or damaged, contact the distributor or sales representative imm ediately.
AFL2-W19A/AB-H61
Page 50

5 Installation

Chapter
5
AFL2-W19A/AB-H61
Page 51
may result in permanent damage to the

5.1 Anti-static Precautions

WARNING:
Failure to take ESD precautions during the maintenance of the AFL2-W19A/AB-H61 AFL2-W19A/AB-H61 and severe injury to the user.
Electrostatic discharge (ESD) can cause serious damage to electronic components, including the AFL2-W19A/AB-H61. Dry climates are es pecially susceptible to ESD. It is therefore critical that whenever the AFL2-W19A/AB-H61 is accessed internally, or any other electrical component is handled, the following anti-static precautions are strictly adhered to.
Wear an anti-static wristband: - Wearing a simple anti-static wristband can
help to prevent ESD from damaging the board.
Self-grounding: - Before handling the board touch any grounded conducting
material. During the time the board is handled, frequently touch any conducting materials that are connected to the ground.
Use an anti-static pad: - When configuring the AFL2-W19A/AB-H61, place it
on an antic-static pad. This reduces the possibility of ESD damaging the AFL2-W19A/AB-H61.
Only handle the edges of the PCB: - When handling the PCB, hold the PCB
by the edges.

5.2 Installation Precautions

When installing the flat bezel pane l PC, please follow the precautions listed below:
Power turned off: When installing the flat bezel panel PC, make sure the
power is off. Failing to turn off the power may cause severe injury to the body and/or damage to the system.
Certified Engineers: Only certified engineers should install and modify
onboard functionalities.
AFL2-W19A/AB-H61
Page 52
cover screws will crack the plastic frame.
Anti-static Discharge: If a user open the rear panel of the flat bezel panel PC,
to configure the jumpers or plug in added peripheral devices, ground themselves first and wear and anti-static wristband.

5.3 In s tallation and Configuration Steps

The following installation steps must be followed.
Step 1: Unpack the flat bezel panel PC.
Step 2: Install the HDD.
Step 3: Install the K-type temperature sensor .
Step 4: Install the RFID reader (optional).
Step 5: Install the CD-ROM (optional).
Step 6: Configure the system.
Step 7: Connect peripheral devices to the flat bezel panel PC.
Step 8: Mount the flat bezel panel PC. Ste p 0:

5.4 HDD Ins tallation

WARNING:
Over-tightening back Maximum torque for cover screws is 5 kg-cm (0.36 lb-ft/0.49 Nm).
To install the HDD into the AFL2-W19A/AB-H61, please follow the steps below:
Step 1: Remove two (2) retention screws from the HDD cover (Figure 5-1).
AFL2-W19A/AB-H61
Page 53
Figure 5-1: HDD Cover Retention Screws
Step 2: Remove the HDD cover from the device.
Step 3: Loosen the captive screw to release the HDD bracket from the chassis (Figure
5-2).
Figure 5-2: HDD Bracket Screw
AFL2-W19A/AB-H61
Page 54
Step 4: Slide the HDD bracket out of the device as shown (Figure 5-3).
Figure 5-3: Removing the HDD Bracket
Step 5: Insert an HDD into the bracket as shown (Figure 5-4).
Figure 5-4: Inserting the HDD
Step 6: Secure the HDD to the bracket using four (4) retention screws (two screws on
each side) (Figure 5-5).
AFL2-W19A/AB-H61
Page 55
Figure 5-5: Securing the HDD
Step 7: Slide the HDD module back into the device.
Step 8: Tighten the captive screw.
Step 9: Replace the HDD cover and secure it using two (2) retention screws. Ste p 0:

5.5 K-Typ e Temperature Sensor Ins tallation

The AFL2-W19A/AB-H61 has a K-type connector on the external peripheral interface panel. The K-type connector is connected to a K-type temperature sensor cable. The K-type temperature sensor cable can be found in the packing list. T o connect a K-type temperature sensor cable to the AFL2-W19A/AB-H61, please follow the instructions below.
Step 1: Locate the K-type connector. The location is shown in Chapter 1.
Step 2: Align the connector . Align the K-type temperature sensor cable with the K-type
connector on the AFL2-W19A/AB-H61 . Make sure the orientation of the connector is correct.
AFL2-W19A/AB-H61
Page 56
Figure 5-6: Insert the K-type Temperature Sensor Cable
Step 3: Insert the K-type connector. Gently insert the K-type temperature sensor cable.
The connector should engage with a gentle push.

5.6 RFID Re ad er (Optional)

The AFL2-W19A/AB-H61 series (selected models only) supports RF ID reader function. The RFID reader is loca ted at th e bottom of the scr een. An optio nal Mifar e 13.56 MH z or EM 125 KHz RFID reader can be integrated in the system. All the data on the RFID tag can be easily retrieved or updated through the reader to secure the data transmission process and increase efficiency for certain identity group.
To install the RFID reader, follow the steps below.
Step 1: Connect the RFID USB cable to the USB connector on the RFID reader module.
(Figure 5-7)
Figure 5-7: Connect the RFID USB cable
AFL2-W19A/AB-H61
Page 57
Step 4: Connect the RFID connector of the RFID USB cable to the RFID connector on
the motherboard (RFID_USB1).
Step 5: Attach the sticker of the RFID module to the bottom of the panel.
Figure 5-8: Install the RFID module
Step 6: Secure the RFID module to the motherboard using two retention screws on
either side.
Step 7: Use the RFID reader to read a RFID card.

5.7 DVD-ROM Ins tallation (Optional)

To install a DVD-ROM, please follow the steps below.
Step 1: Remove four screws from the DVD-ROM cover. (Figure 5-9).
AFL2-W19A/AB-H61
Page 58
Figure 5-9: DVD-ROM Cover
Step 2: Remove the DVD-ROM cover.
Step 3: Insert the DVD-ROM to the DVD-ROM bay. Attach the SATA cable to the
DVD-ROM and fasten the SATA cable screws (Figure 5-10).
Figure 5-10: Install the DVD-ROM
AFL2-W19A/AB-H61
Page 59
Step 4: Secure the DVD-ROM to the DVD-ROM bracket using four screws (two screws
on each side) (Figure 5-11).
Figure 5-11: DVD-ROM Bracket Screws
Step 5: Install the new DVD-ROM cover and fasten four screws on the DVD-ROM cover.
The new DVD-ROM cover can be found in the packing list and is shown in
Figure 5-12.
Figure 5-12: DVD-ROM Cover

5.8 AT/ATX Mode Se lection

AT or ATX power mode can be used on the AFL2-W19A/AB-H61. The selection is made through an AT/ATX switch loc ated on the bottom panel (Figure 5-13). To select AT m ode or ATX mode, follow the steps below.
Step 1: Locate the AT/ATX switch on the bottom panel (Figure 5-13).
AFL2-W19A/AB-H61
Page 60
Figure 5-13: AT/ATX Switch Locatio n
Step 2: Adjust the A T/A TX switch.

5.8.1 AT Power Mode

With the AT mode selec ted, the po wer is control led by a centra l power un it rather than a power switch. The AFL2-W19A/AB-H61 pane l PC turn s on autom atically when t he power is connected. The AT mode benefits a production line to control multiple panel PCs from a central management center and other applications including:
ATM  Self-service kiosk  Plant environment monitoring system  Factory automation platform  Manufacturing shop flow

5.8.2 ATX Power Mode

With the ATX mode selected, the AFL2-W19A/AB-H61 pa ne l PC go es i n a s t and b y m od e when it is turned of f . T he pane l PC c a n b e eas i ly tur n ed on v ia net wor k or a power switch in standby mode. Remote po wer control is perfect for advertising app lications since the broadcasting time for each panel PC can be set individually and controlled remotely. Other possible application includes
Security surveillance  Point-of-Sale (POS)  Advertising terminal

5.9 Clear CMOS

If the AFL2-W19A/AB-H61 fails to boot due to improper BIOS settings, the clear CMOS switch clears the CMOS da ta and resets the s ystem BIOS infor mation. To do this , adjust
AFL2-W19A/AB-H61
Page 61
the clear CMOS switch to clear CMOS m ode for a few seconds the n reinstall the clear CMOS switch back to keep CMOS mode.
Step 1: Locate the clear CMOS switch on the bottom panel (Figure 5-14).
Figure 5-14: Clear CMOS Switch Location
Step 2: Adjust the clear CMOS switch. Ste p 0:

5.10 Res et the System

The reset button en ables user to reboot the s ystem when the system is turned on. To reboot the system, follow the steps below.
Step 1: Locate the reset button on the bottom panel (Figure 5-15).
Figure 5-15: Reset Button Location
Step 2: Press the reset button. Step 0:

5.11 Powering On th e System

To power on the system, follow the steps below:
Step 1: Locate the Function and Brightness Up function keys. See Section 1.2.1.1.
AFL2-W19A/AB-H61
Page 62
Step 2: Hold down the Function and Brightness Up buttons for three seconds to power
on the system. Step 0:

5.12 Po w ering Off the Syste m

To power off the system, follow the steps below:
Step 1: Locate the Function and Brightness Up function keys. See Section 1.2.1.1.
Step 2: Hold down the Function and Brightness Up buttons for six seconds to power off
the system. Ste p 0:

5.13 Mounting the Sys tem

WARNING!
When mounting the flat bezel panel PC onto an arm, onto the wall or onto a panel, it is better to h av e m ore tha n o ne person to help with the i nstal lat ion to make sure the pane l PC does not fall down and get damaged.
The four methods of mounting the AFL2-W19A/AB-H61 are listed below.
Wall mounting  Panel mounting  Stand mounting  Arm mounting
The four mounting methods are described below.
AFL2-W19A/AB-H61
Page 63

5.13.1 Wall Mounting

To mount the flat bezel panel PC onto the wall, please follow the steps below.
Step 1: Select the location on the wall for the wall-mounting bracket.
Step 2: Carefully mark the locations of the four screw holes in the bracket on the wall.
Step 3: Drill four pilot holes at the marked locations on the wall for the bracket retention
screws.
Step 4: Align the wall-mounting bracket screw holes with the pilot holes.
Step 5: Secure the mounting-bracket to the wall by inserting the retention screws into
the four pilot holes and tightening them (Figure 5-16).
Figure 5-16: Wall-mounting Bracket
Step 8: Insert the four monitor mounting screws provided in the wall mount kit into the
four screw holes on the real panel of the flat bezel panel PC and tighten until the screw shank is secured against the rear panel (Figure 5-17).
AFL2-W19A/AB-H61
Page 64
WARNING:
Please use the M4 scre ws prov ide d in t he wall mount kit for the rear panel. If the screw is missing, the thread depth of the replacement screw should be not more than 4 mm.
Step 9: Align the mounting screws on the monitor rear panel with the mounting holes on
the bracket.
Step 10: Carefully insert the screws through the holes and gently pull the monitor
downwards until the monitor rests securely in the slotted holes (Figure 5-17). Ensure that all four of the mounting screws fit snugly into their respective slotted holes.
NOTE:
In the diagram below the bracket is already installed on the wall.
AFL2-W19A/AB-H61
Page 65
Figure 5-17: Chassis Support Screws
Step 11: Secure the panel PC by fastening the retention screw of the wall-mounting
bracket. (Figure 5-18). Ste p 0:
Figure 5-18: Secure the Panel PC
AFL2-W19A/AB-H61
Page 66

5.13.2 Panel Mounting

To mount the AFL2-W19A/AB-H61 flat bezel panel PC into a panel, please follow the steps below.
Step 1: Select the position on the panel to mount the flat bezel panel PC.
Step 2: Cut out a section from the panel that corresponds to the rear panel dimensions
of the flat bezel panel PC. Take care that the panel section that is cut out is smaller than the overall size of the frame that surrounds the flat bezel panel PC but just large enough for the rear panel of the flat bezel panel PC to fit through
Step 3: Slide the flat bezel panel PC through the hole until the frame is flush against the
panel.
Step 4: Insert the panel mounting clamps into the pre-formed holes along the edges of
the chassis, behind the frame.
Step 5: Tighten the screws that pass through the panel mounting clamps until the plastic
caps at the front of all the screws are firmly secured to the panel (Figure 5-19).
Step 0:
Figure 5-19: Tighten the Panel Mounting Clamp Screws
AFL2-W19A/AB-H61
Page 67

5.13.3 Stand Mounting

To mount the AFL2-W19A/AB-H61 us ing the stand mount ing kit, please follow t he steps below.
Step 1: Locate the screw holes on the rear of the AFL2-W19A/AB-H61. This is where
the bracket will be attached. (Figure 5-20)
Figure 5-20: Mounting screw location
Step 2: Align the bracket with the screw holes.
Step 3: To secure the bracket to the AFL2-W19A/AB-H61, insert the retention screws
into the screw holes and tighten them. Ste p 0:

5.13.4 Arm Mounting

The AFL2-W19A/AB-H61 is VESA (Video Electronics Standards Assoc iation) compliant and can be mounted on an arm with a 100mm interface pad. To mount the AFL2-W19A/AB-H61 on an arm, please follow the steps below.
Step 1: The arm is a separately purchased item. Please correctly mount the arm onto
the surface it uses as a base. To do this, refer to the installation documentation that came with the mounting arm.
AFL2-W19A/AB-H61
Page 68
NOTE:
When purchasing the arm please ensure that it is VESA compliant and that the arm has a 100mm x 100mm interface pad. If the mountin g arm is not VESA compliant it ca nnot be used to support th e AFL2-W19A/AB-H61 flat bezel panel PC.
Step 2: Once the mounting arm has been firmly attached to the surface, lift the flat bezel
panel PC onto the interface pad of the mounting arm.
Step 3: Align the retention screw holes on the mounting arm interface with those in the
flat bezel panel PC (Figure 5-21).
Figure 5-21: Arm Mounting Retention Screw Holes
Step 4: Secure the flat bezel panel PC to the interface pad by inserting four retention
screws through the bottom of the mounting arm interface pad and into the flat bezel panel PC. Ste p 0:

5.14 External Peripheral Device Connection

The following external peripheral devices can be connected to the external peripheral interface connectors.
AFL2-W19A/AB-H61
Page 69
Audio devices  HDMI devices  RJ-45 Ethernet cable connector  Serial port devices  USB devices  VGA monitor
To install these devices, connect the corresponding cable connector from the actual device to the corr esponding AFL2-W19A/AB-H61 external peripheral interface connec tor making sure the pins are properly aligned.

5.14.1 Audio Connection

The audio jacks on the ex ternal audio connector enable the AFL2-W19A/AB-H61 to be connected to a stereo sound setup. To install the audio devices, follow the steps below.
Step 1: Identify the audio plugs. The plugs on your home theater system or speakers
may not match the colors on the rear panel. If audio plugs are plugged into the wrong jacks, sound quality will be very bad.
Step 2: Plug the audio plugs into the audio jacks. Plug the audio plugs into the audio
jacks. If the plugs on your speakers are different, an adapter will need to be used to plug them into the audio jacks.
Line Out port (Lime): Connects to a headphone or a speaker.  Microphone (Pink): Connects to a microphone.
AFL2-W19A/AB-H61
Page 70
Figure 5-22: Audio Connector
Step 3: Check audio clarity. Check that the sound is coming through the right speakers
by adjusting the balance front to rear and left to right.

5.14.2 HDMI Device Connection

The HDMI connector trans mits a digital signal to compati ble HDMI display devices such as a TV or computer screen. To connect the HDMI cable to the AFL2-W19A/AB-H61, follow the steps below.
Step 1: Locate the HDMI connector. The location is shown in Chapter 1.
Step 2: Align the connector. Align the HDMI connector with the HDMI port. Make sure
the orientation of the connector is correct.
AFL2-W19A/AB-H61
Page 71
Figure 5-23: HDMI Connection
Step 3: Insert the HDMI connector. Gently insert the HDMI connector. The connector
should engage with a gentle push. If the connector does not insert easily, check again that the connector is aligned correctly, and that the connector is being inserted with the right way up.
The pinouts of the HDMI connector is shown below.
Pin Description Pin Description
1 HDMI_TMDS_C_DATA2 2 GND 3 HDMI_TMDS_C_DATA2# 4 HDMI_TMDS_C_DATA1 5 GND 6 HDMI_TMDS_C_DATA1# 7 HDMI_TMDS_C_DATA0 8 GND 9 HDMI_TMDS_C_DATA0# 10 HDMI_TMDS_C_CLK 11 GND 12 HDMI_TMDS_C_CLK# 13 NC 14 NC 15 HDMI_DDC_SCLK 16 HDMI_DDC_SDATA 17 GND 18 +5V_HDMI 19 HDMI_HPD
Table 5-1: HDMI Pinouts
AFL2-W19A/AB-H61
Page 72

5.14.3 LAN Connection

There are two external R J-45 LAN con nectors. The RJ -45 connector ena bles connecti on to an external networ k. To connect a LAN cab le with an RJ-45 connec tor, please follow the instructions below.
Step 1: Locate the RJ-45 connectors. The locations of the LAN connectors are shown
in Chapter 1.
Step 2: Align the connectors. Align the RJ-45 connector on the LAN cable with one of
the RJ-45 connectors on the AFL2-W19A/AB-H61. See Figure 5-24.
Figure 5-24: LAN Connection
Step 3: Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN
cable RJ-45 connector into the external interface.
The pinouts of the RJ-45 LAN connectors are sho wn below.
Pin Description Pin Description
1 LAN1_MDI0+ 2 LAN1_MDI0­3 LAN1_MDI1+ 4 LAN1_MDI1­5 GND 6 GND
AFL2-W19A/AB-H61
Page 73
Pin Description Pin Description
7 LAN1_MDI2+ 8 LAN1_MDI2­9 LAN1_MDI3+ 10 LAN1_MDI3­11 GND 12 GND 13 NC 14 NC L1 LAN1_LINK100 L2 LAN1_LINK1000 L3 LAN1_ACT-1 L4 POWER
Table 5-2: LAN1 Pinouts
Pin Description Pin Description
1 LAN2_MDI0+ 2 LAN2_MDI0­3 LAN2_MDI1+ 4 LAN2_MDI1­5 GND 6 GND 7 LAN12_MDI2+ 8 LAN2_MDI2­9 LAN2_MDI3+ 10 LAN2_MDI3­11 GND 12 GND 13 NC 14 NC L1 LAN12_LINK100 L2 LAN2_LINK1000 L3 LAN2_ACT-1 L4 POWER
Table 5-3: LAN2 Pinouts

5.14.4 Serial Device Connection

There are two external RS-232 DB-9 connectors and one RS-422/485 DB-9 connector for serial device connection. Follow the steps below to connect a serial device to the AFL2-W19A/AB-H61.
Step 1: Locate the DB-9 connector. The locations of the DB-9 connectors are shown
in Chapter 1.
Step 2: Insert the serial connector. Insert the DB-9 connector of a serial device into
the DB-9 connector on the bottom panel. See Figure 5-25.
AFL2-W19A/AB-H61
Page 74
Figure 5-25: DB-9 Serial Port Connector
Step 3: Secure the connector. Secure the serial device connector to the external
interface by tightening the two retention screws on either side of the connector .
The pinouts of the RS-232 serial ports are shown below.
Pin Description Pin Description
1 NDCD1 2 NSIN1 3 NSOUT1 4 NDTR1 5 GND 6 NDSR1 7 NRTS1 8 NCTS1 9 XRI1 10 NDCD2 11 NSIN2 12 NSOUT2 13 NDTR2 14 GND
Step 0:
15 NDSR2 16 NRTS2 17 NCTS2 18 XRI2
Table 5-4: RS-232 Serial Port s Pinouts (COM1, COM2)
AFL2-W19A/AB-H61
Page 75
The pinouts of the RS-422/485 serial ports are shown below.
Pin Description Pin Description
1 RXD485+ 2 RXD485# 3 TXD485+ 4 TXD485#
Table 5-5: RS-422/485 Serial Port Pinouts (COM3)

5.14.5 USB Device Connection

NOTE:
User must install the USB 3.0 driver before connecting a USB device to the system or else the system may not recognize the connected device.
There are three USB 2.0 connectors and two USB 3.0 connectors on the AFL2-W19A/AB-H61. To connect a USB device, please follow the instructions below.
Step 1: Locate the USB connectors. The locations of the USB connectors are shown
in Chapter 1.
Step 2: Align the connectors. Align the USB device connector with one of the
connectors on the bottom panel. See Figure 5-26.
AFL2-W19A/AB-H61
Page 76
Figure 5-26: USB Device Connection
Step 3: Insert the device connector. Once align ed, ge ntly insert the USB device
connector into the onboard connector. Step 0:
The pinouts of the USB 2.0 connectors are shown below.
Pin Description Pin Description
1 POWER 2 -DATA0 3 +DATA0 4 GND 5 POWER 6 -DATA1 7 +DATA1 8 GND
Table 5-6: USB 2.0 connectors Pinouts (bottom panel)
Pin Description Pin Description
1 POWER 2 -DATA2 3 +DATA2 4 USB20_GND
Table 5-7: USB 2.0 connectors Pinouts (left side panel)
AFL2-W19A/AB-H61
Page 77
The pinouts of the USB 3.0 connectors are shown below.
Step 1:
Pin Description Pin Description
1 USB3_PWR1 2 USB2P0_DM1_L 3 USB2P0_DP1_L 4 GND 5 USB3P0_RXDN1_L 6 USB3P0_RXDP1_L 7 GND 8 USB3P0_TXDN1_C_L 9 USB3P0_TXDP1_C_L 10 USB3_PWR2 11 USB2P0_DM2_L 12 USB2P0_DP2_L 13 GND 14 USB3P0_RXDN2_L 15 USB3P0_RXDP2_L 16 GND 17 USB3P0_TXDN2_C_L 18 USB3P0_TXDP2_C_L
Table 5-8: USB 3.0 connectors Pinouts

5.14.6 VGA Monitor Connection

The AFL2-W19A/AB-H61 has a single female DB-15 connector on the ext er na l pe ripher a l interface panel. The DB-15 connector is connec ted to a CR T or VGA monitor. To connect a monitor to the AFL2-W19A/AB-H61, please follow the instructions below.
Step 1: Locate the female DB-15 connector. The location of the female DB-15
connector is shown in Chapter 1.
Step 2: Align the VGA connector. Align the male DB-15 connector on the VGA screen
cable with the female DB-15 connector on the external peripheral interface.
Step 3: Insert the VGA connector. Once the connectors are properly aligned with the
insert the male connector from the VGA screen into the female connector on the AFL2-W19A/AB-H61. See Figure 5-27.
AFL2-W19A/AB-H61
Page 78
Figure 5-27: VGA Connector
Step 4: Secure the connector. Secure the DB-15 VGA connector from the VGA
monitor to the external interface by tightening the two retention screws on either side of the connector.
The pinouts of the VGA connector is shown below.
Pin Description Pin Description
1 CRT_RED 2 CRT_GREEN 3 CRT_BLUE 4 NC 5 GND 6 GND 7 GND 8 GND 9 CRT_VCC 10 CRT_PLUG# 11 NC 12 CRT_DDC_DATA 13 CRT_HSYNC 14 CRT_VSYNC 15 CRT_DDC_CLK
Table 5-9: VGA Pinouts
AFL2-W19A/AB-H61
Page 79
Chapter
6

6 System Motherboard

AFL2-W19A/AB-H61
Page 80

6.1 Overview

This chapter details all the jumpers and connectors of the system motherboard.

6.1.1 Layout

The figures below show all the connectors and jumpers of the system motherboard..
Figure 6-1: Connectors and Jumpers (front)
Loading...
