IEI Integration AFL2-W10A-N28 User Manual
User Manual
AFL2-W10A-N28
MODEL:
AFL2-W10A-N28 Series
Flat Bezel Panel PC with Intel® Atom™ N2800 Dual-Core CPU,
Touchscreen, Wi-Fi, Bluetooth, USB, GbE LAN, RS-232/422/485,
2-Megapixel Camera, HD Audio and RoHS
User Manual
Rev. 1.01 - 11 March, 2014
Page I
Date Version Changes
AFL2-W10A-N28
Revision
11 March, 2014 1.01
26 February, 2013 1.00
Modified touchscreen specifications
Initial release
Page II
AFL2-W10A-N28
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
Copyright
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.
Page III
AFL2-W10A-N28
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 OVERVIEW.................................................................................................................. 2
1.1.1 Features ............................................................................................................. 3
1.2 EXTERNAL OVERVIEW................................................................................................ 3
1.2.1 Front Panel........................................................................................................ 3
1.2.1.1 LED Indicators............................................................................................ 4
1.2.1.2 Function Keys............................................................................................. 6
1.2.2 Rear Panel ......................................................................................................... 7
1.2.3 Bottom Panel...................................................................................................... 7
1.2.4 Left Side Panel................................................................................................... 8
1.3 INTERNAL OVERVIEW................................................................................................. 9
1.4 SYSTEM SPECIFICATIONS............................................................................................ 9
1.5 DIMENSIONS..............................................................................................................11
2 UNPACKING ............................................................................................................... 12
2.1 UNPACKING.............................................................................................................. 13
2.1.1 Packing List ..................................................................................................... 13
3 INSTALLATION ......................................................................................................... 17
3.1 ANTI-STATIC PRECAUTIONS ...................................................................................... 18
3.2 INSTALLATION PRECAUTIONS................................................................................... 18
3.3 INST ALLATION AND CONFIGURATION STEPS ............................................................. 19
3.4 HDD INSTALLATION................................................................................................. 19
3.5 RFID READER INSTA LLATION (OPTIONAL).............................................................. 22
3.6 AT/ATX MODE SELECTION...................................................................................... 24
3.6.1 AT Power Mode................................................................................................ 24
3.6.2 ATX Power Mode ............................................................................................. 24
3.7 CLEAR CMOS.......................................................................................................... 25
3.8 RESET THE SYSTEM.................................................................................................. 25
3.9 POWERING ON THE SYSTEM..................................................................................... 26
3.10 POWERING OFF THE SYSTEM.................................................................................. 26
Page IV
AFL2-W10A-N28
3.11 MOUNTING THE SYSTEM ........................................................................................ 26
3.1 1.1 Wall Mounting................................................................................................ 27
3.11.2 Panel Mounting.............................................................................................. 30
3.11.3 Cabinet and Rack Installation........................................................................ 31
3.1 1.4 Arm Mounting ................................................................................................ 34
3.11.5 Stand Mounting .............................................................................................. 36
3.1 1.6 V-Stand Mounting........................................................................................... 36
3.12 EXTERNAL PERIPHERAL DEVICE CONNECTION ...................................................... 39
3.12.1 Audio Connection........................................................................................... 39
3.12.2 DisplayPort Connection................................................................................. 40
3.12.3 LAN Connection............................................................................................. 41
3.12.4 Serial Device Connection .............................................................................. 42
3.12.4.1 DB-9 Serial Port Connection.................................................................. 42
3.12.4.2 RJ-45 Serial Port Connection.................................................................. 43
3.12.5 USB Device Connection................................................................................. 45
4 BIOS SETUP................................................................................................................ 47
4.1 INTRODUCTION......................................................................................................... 48
4.1.1 Starting Setup................................................................................................... 48
4.1.2 Using Setup...................................................................................................... 48
4.1.3 Getting Help..................................................................................................... 49
4.1.4 Unable to Reboot after Configuration Changes.............................................. 49
4.1.5 BIOS Menu Bar................................................................................................ 49
4.2 MAIN........................................................................................................................ 50
4.3 ADVANCED............................................................................................................... 51
4.3.1 ACPI Settings................................................................................................... 52
4.3.2 RTC Wake Settings........................................................................................... 53
4.3.3 CPU Configuration.......................................................................................... 54
4.3.4 SATA Configuration......................................................................................... 56
4.3.5 USB Configuration........................................................................................... 57
4.3.6 F81866 Super IO Configuration...................................................................... 58
4.3.6.1 Serial Port n Configuration....................................................................... 59
4.3.6.1.1 Serial Port 1 Configuration................................................................ 59
4.3.6.1.2 Serial Port 2 Configuration................................................................ 60
4.3.6.1.3 Serial Port 3 Configuration................................................................ 60
Page V
4.3.7 H/W Monitor.................................................................................................... 62
4.3.8 Serial Port Console Redirection...................................................................... 62
4.4 IEI FEATURE............................................................................................................. 64
4.5 CHIPSET ................................................................................................................... 65
4.5.1 Host Bridge Configuration .............................................................................. 66
4.5.1.1 Internal IGD Configuration....................................................................... 66
4.5.2 South Bridge Configuration............................................................................. 67
4.6 BOOT........................................................................................................................ 69
4.7 SECURITY................................................................................................................. 71
4.8 SAVE & EXIT............................................................................................................ 72
5 SOFTWARE DRIVERS.............................................................................................. 74
5.1 AVAILABLE SOFTWARE DRIVERS .............................................................................. 75
5.2 ST ARTING THE DRIVER PROGRAM ............................................................................ 75
5.3 CHIPSET DRIVER INSTALLATION............................................................................... 76
AFL2-W10A-N28
5.4 GRAPHICS DRIVER INSTALLATION............................................................................ 79
5.5 TOUCHSCREEN DRIVER ............................................................................................ 82
5.5.1 Calibrating the Touchscreen............................................................................ 85
5.6 AUDIO DRIVER INSTALLATION ................................................................................. 88
5.7 LAN DRIVER INSTALLATION.................................................................................... 90
5.8 USB 3.0 DRIVER INSTALLATION .............................................................................. 92
5.9 WI-FI DRIVER INSTALLATION................................................................................... 95
5.10 BLUETOOTH DRIVER.............................................................................................. 98
5.11 CAMERA DRIVER INSTALLATION .......................................................................... 102
6 SYSTEM MAINTENANCE ..................................................................................... 105
6.1 SYSTEM MAINTENANCE INTRODUCTION ................................................................ 106
6.2 ANTI-STATIC PRECAUTIONS .................................................................................... 106
6.3 TURN OFF THE POWER............................................................................................ 107
6.4 OPENING THE SYSTEM............................................................................................ 107
6.4.1 Removing the Back Cover.............................................................................. 107
6.4.2 Removing the Internal Cover......................................................................... 108
6.5 REPLACING COMPONENTS...................................................................................... 109
6.5.1 Memory Module Replacement ....................................................................... 109
6.5.2 WLAN Card Replacement...............................................................................110
Page VI
AFL2-W10A-N28
6.6 REINST ALLING THE COVERS....................................................................................113
7 INTERFACE CONNECTORS..................................................................................115
7.1 PERIPHERAL INTERFACE CONNECTORS....................................................................116
7.2 INTERNAL PERIPHERAL CONNECTORS .....................................................................117
7.2.1 Audio Connector (AUDIO1)...........................................................................119
7.2.2 Battery Connector (CN2)................................................................................119
7.2.3 Bluetooth USB Connector (BLUETOOTH1)..................................................119
7.2.4 CRT Connector (VGA1)................................................................................. 120
7.2.5 Debug Connector (LPC_DEBUG1) .............................................................. 120
7.2.6 EC Debug Connector (CN1).......................................................................... 120
7.2.7 HDD Connector (JSATA1)............................................................................. 121
7.2.8 Hot Key LED Connector (HOTKEYLEDCN1).............................................. 121
7.2.9 Hot Key Connector (HOTKEYCN1).............................................................. 122
7.2.10 LED Indicator Connector (LEDCN1).......................................................... 122
7.2.11 LVDS Connector (LCD1)............................................................................. 122
7.2.12 LVDS Backlight Connector (INVERTER1).................................................. 123
7.2.13 microSD Connector (MICRO_SD1)............................................................ 123
7.2.14 Mini USB Connector (MINI_USB1)............................................................ 123
7.2.15 Power Button Connector (PW_BT1) ........................................................... 124
7.2.16 RFID USB Connector (RFID1) ................................................................... 124
7.2.17 RFID COM Connector (RFID_COM1)....................................................... 124
7.2.18 SATA LED Connector (JP5)......................................................................... 124
7.2.19 Speaker Connector (SPKR1)........................................................................ 125
7.2.20 SPI Flash Connector (SPI1) ........................................................................ 125
7.2.21 EC SPI Flash Connector (JSPI2) ................................................................ 125
7.2.22 Touch Panel Connector (TS1)...................................................................... 126
7.2.23 Touch Panel Connector (TOUCH1)............................................................. 126
7.2.24 Type K Thermocouple Connector (K_TYPE1, K_TYPE2)........................... 126
7.2.25 Webcam Connector (CAMERA1)................................................................. 127
7.2.26 Webcam Microphone Connector (WEBCAM_DMIC1) ............................... 127
7.3 EXTERNAL INTERFACE PANEL CONNECTORS.......................................................... 127
7.3.1 Ethernet Connector (JP6).............................................................................. 128
7.3.2 Power Connector (DC_IN1)....................................................................... 128
7.3.3 RS-232 DB-9 Serial Ports (COM1) ............................................................... 128
Page VII
7.3.4 RS-422/485 RJ-45 Serial Port (COM2)......................................................... 129
7.3.5 RS-232 RJ-45 Serial Ports (COM3) .............................................................. 129
7.3.6 USB 2.0 Connectors (USB1).......................................................................... 130
7.3.7 USB 3.0 Connectors (USB3_1)...................................................................... 130
7.3.8 DisplayPort Connector (DISPLAY_PORT1) ................................................. 130
A SAFETY PRECAUTIONS....................................................................................... 132
A.1 SAFETY PRECAUTIONS .......................................................................................... 133
A.1.1 General Safety Precautions........................................................................... 133
A.1.2 CPU Temperature Warning ........................................................................... 134
A.1.3 Anti-static Precautions.................................................................................. 134
A.1.4 Product Disposal........................................................................................... 135
A.2 MAINTENANCE AND CLEANING PRECAUTIONS...................................................... 135
A.2.1 Maintenance and Cleaning............................................................................ 135
A.2.2 Cleaning Tools............................................................................................... 136
AFL2-W10A-N28
B BIOS MENU OPTIONS........................................................................................... 137
C ONE KEY RECOVERY........................................................................................... 140
C.1 ONE KEY RECOVERY INTRODUCTION .................................................................... 141
C.1.1 System Requirement ...................................................................................... 142
C.1.2 Supported Operating System......................................................................... 143
C.2 SETUP PROCEDURE FOR WINDOWS........................................................................ 144
C.2.1 Hardware and BIOS Setup ............................................................................ 145
C.2.2 Create Partitions........................................................................................... 145
C.2.3 Install Operating System, Drivers and Applications..................................... 149
C.2.4 Building the Recovery Partition.................................................................... 150
C.2.5 Create Factory Default Image ...................................................................... 152
C.3 AUTO RECOVERY SETUP PROCEDURE.................................................................... 157
C.4 SETUP PROCEDURE FOR LINUX.............................................................................. 162
C.5 RECOVERY TOOL FUNCTIONS ................................................................................ 165
C.5.1 Factory Restore............................................................................................. 167
C.5.2 Backup System............................................................................................... 168
C.5.3 Restore Your Last Backup.............................................................................. 169
C.5.4 Manual .......................................................................................................... 170
C.6 RESTORE SYSTEMS FROM A LINUX SER VER THROUGH LAN.................................. 171
Page VIII
AFL2-W10A-N28
C.6.1 Configure DHCP Server Settings.................................................................. 172
C.6.2 Configure TFTP Settings............................................................................... 173
C.6.3 Configure One Key Recovery Server Settings............................................... 174
C.6.4 Start the DHCP, TFTP and HTTP................................................................. 175
C.6.5 Create Shared Directory................................................................................ 175
C.6.6 Setup a Client System for Auto Recovery...................................................... 176
C.7 OTHER INFORMATION ............................................................................................ 179
C.7.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller ...................... 179
C.7.2 System Memory Requirement........................................................................ 181
D WA TCHDOG TIMER .............................................................................................. 182
E HAZARDOUS MATERIALS DISCLOSURE ....................................................... 185
E.1 HAZARDOUS MATERIAL DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ..................................... 186
Page IX
AFL2-W10A-N28
List of Figures
Figure 1-1: AFL2-W10A-N28 Flat Bezel Panel PC........................................................................2
Figure 1-2: Front View....................................................................................................................3
Figure 1-3: LED Indicators.............................................................................................................4
Figure 1-4: Function Keys .............................................................................................................6
Figure 1-5: Rear View.....................................................................................................................7
Figure 1-6: Bottom Panel...............................................................................................................8
Figure 1-7: Left Side Panel ............................................................................................................8
Figure 1-8: AFL2-W10A-N28 Dimensions (mm).........................................................................11
Figure 3-1: HDD Cover Retention Screws..................................................................................20
Figure 3-2: HDD Bracket Removal..............................................................................................20
Figure 3-3: Inserting the HDD......................................................................................................21
Figure 3-4: Securing the HDD......................................................................................................21
Figure 3-5: Back Cover Retention Screws.................................................................................22
Figure 3-6: Internal Cover Retention Screws.............................................................................22
Figure 3-7: RFID Reader Module Installation.............................................................................23
Figure 3-8: RFID Reader Connection..........................................................................................23
Figure 3-9: AT/ATX Switch Location...........................................................................................24
Figure 3-10: Clear CMOS Switch Location.................................................................................25
Figure 3-11: Reset Button Location............................................................................................25
Figure 3-12: Wall-mounting Bracket...........................................................................................27
Figure 3-13: Chassis Support Screws........................................................................................29
Figure 3-14: Secure the Panel PC...............................................................................................29
Figure 3-15: Cutout Dimensions.................................................................................................30
Figure 3-16: Tighten the Panel Mounting Clamp Screws.........................................................31
Figure 3-17: The Rack/Cabinet Bracket......................................................................................32
Figure 3-18: Secure the Rack/Cabinet Bracket..........................................................................33
Figure 3-19: Install into a Rack/Cabinet .....................................................................................33
Figure 3-20: Arm Mounting Retention Screw Holes..................................................................35
Figure 3-21: Arm Mounting..........................................................................................................35
Figure 3-22: Stand Mounting (Stand-A/Bxx)..............................................................................36
Figure 3-23: Drill Pilot Holes for V-Stand...................................................................................37
Page X
AFL2-W10A-N28
Figure 3-24: Secure System to V-Stand .....................................................................................38
Figure 3-25: Secure V-Stand to Mounting Area.........................................................................38
Figure 3-26: Audio Connector.....................................................................................................40
Figure 3-27: DisplayPort Connection.........................................................................................41
Figure 3-28: LAN Connection......................................................................................................42
Figure 3-29: DB-9 Serial Port Connector....................................................................................43
Figure 3-30: RJ-45 Serial Port Connector..................................................................................44
Figure 3-31: DB-9 Connector Pinout Locations ........................................................................44
Figure 3-32: USB Device Connection.........................................................................................45
Figure 5-1: Drivers........................................................................................................................76
Figure 5-2: Chipset Driver Screen...............................................................................................77
Figure 5-3: Chipset Driver Welcome Screen..............................................................................77
Figure 5-4: Chipset Driver License Agreement.........................................................................78
Figure 5-5: Chipset Driver Read Me File ....................................................................................78
Figure 5-6: Chipset Driver Setup Operations ............................................................................79
Figure 5-7: Graphics Driver Welcome Screen...........................................................................80
Figure 5-8: Graphics Driver License Agreement.......................................................................80
Figure 5-9: Graphics Driver Read Me File..................................................................................81
Figure 5-10: Graphics Driver Setup Operations........................................................................81
Figure 5-11: Graphics Driver Installation Finish Screen ..........................................................82
Figure 5-12: Touchscreen Driver Welcome Screen ..................................................................83
Figure 5-13: Touchscreen Driver License Agreement..............................................................83
Figure 5-14: Touchscreen Driver Choose Install Location ......................................................84
Figure 5-15: Touchscreen Driver Installation Screen...............................................................84
Figure 5-16: Touchscreen Driver Update Complete..................................................................85
Figure 5-17: PenMount Monitor Icon..........................................................................................85
Figure 5-18: PenMount Monitor Popup Menu............................................................................86
Figure 5-19: Configuration Screen..............................................................................................86
Figure 5-20: Calibration Initiation Screen..................................................................................87
Figure 5-21: Calibration Screen ..................................................................................................87
Figure 5-22: Audio Driver – Extracting Files..............................................................................88
Figure 5-23: Audio Driver Welcome Screen...............................................................................89
Figure 5-24: Audio Driver Installation.........................................................................................89
Figure 5-25: Audio Driver Installation Complete.......................................................................89
Figure 5-26: LAN Driver Welcome Screen .................................................................................90
Page XI
Figure 5-27: LAN Driver Ready to Install Screen.......................................................................91
Figure 5-28: LAN Driver Setup Status Screen...........................................................................91
Figure 5-29: LAN Driver Installation Complete..........................................................................92
Figure 5-30: USB 3.0 Driver Welcome Screen...........................................................................93
Figure 5-31: USB 3.0 Driver License Agreement.......................................................................93
Figure 5-32: USB 3.0 Driver Installation.....................................................................................94
Figure 5-33: USB 3.0 Driver Update Complete ..........................................................................94
Figure 5-34: License Agreement.................................................................................................95
Figure 5-35: Setup Type...............................................................................................................96
Figure 5-36: Configuration Tool..................................................................................................96
Figure 5-37: Ready to Install the Program.................................................................................97
Figure 5-38: Setup Status ............................................................................................................97
Figure 5-39: Installation Complete..............................................................................................98
Figure 5-40: Welcome Screen .....................................................................................................99
AFL2-W10A-N28
Figure 5-41: License Agreement.................................................................................................99
Figure 5-42: Bluetooth Driver Destination Folder.................................................................. 100
Figure 5-43: Ready to Install the Program.............................................................................. 100
Figure 5-44: Installing BlueSoleil............................................................................................. 101
Figure 5-45: Bluetooth Driver Complete Installation Screen ................................................ 101
Figure 5-46: Reboot the Computer .......................................................................................... 102
Figure 5-47: AMCap Driver Welcome Screen ......................................................................... 103
Figure 5-48: AMCap Driver Choose Install Location.............................................................. 103
Figure 5-49: AMCap Driver Installation Complete.................................................................. 104
Figure 6-1: Back Cover Retention Screws.............................................................................. 108
Figure 6-2: Internal Cover Retention Screws.......................................................................... 108
Figure 6-3: Internal Components............................................................................................. 109
Figure 6-4: DDR SO-DIMM Module Installation....................................................................... 110
Figure 6-5: Releasing the WLAN Card..................................................................................... 111
Figure 6-6: Removing the WLAN card..................................................................................... 112
Figure 6-7: Attaching the Antennas......................................................................................... 113
Figure 7-1: Main Board Layout Diagram (Front Side)............................................................ 116
Figure 7-2: Main Board Layout Diagram (Solder Side).......................................................... 117
Figure C-1: IEI One Key Recovery Tool Menu........................................................................ 141
Figure C-2: Launching the Recovery Tool.............................................................................. 146
Figure C-3: Recovery Tool Setup Menu .................................................................................. 146
Page XII
AFL2-W10A-N28
Figure C-4: Command Prompt ................................................................................................. 147
Figure C-5: Partition Creation Commands.............................................................................. 148
Figure C-6: Launching the Recovery Tool.............................................................................. 150
Figure C-7: Manual Recovery Environment for Windows..................................................... 150
Figure C-8: Building the Recovery Partition........................................................................... 151
Figure C-9: Press Any Key to Continue.................................................................................. 151
Figure C-10: Press F3 to Boot into Recovery Mode............................................................... 152
Figure C-11: Recovery Tool Menu ........................................................................................... 152
Figure C-12: About Symantec Ghost Window........................................................................ 153
Figure C-13: Symantec Ghost Path ......................................................................................... 153
Figure C-14: Select a Local Source Drive ............................................................................... 154
Figure C-15: Select a Source Partition from Basic Drive ...................................................... 154
Figure C-16: File Name to Copy Image to ............................................................................... 155
Figure C-17: Compress Image.................................................................................................. 155
Figure C-18: Image Creation Confirmation............................................................................. 156
Figure C-19: Image Creation Complete................................................................................... 156
Figure C-20: Image Creation Complete................................................................................... 156
Figure C-21: Press Any Key to Continue................................................................................ 157
Figure C-22: Auto Recovery Utility.......................................................................................... 158
Figure C-23: Disable Automatically Restart............................................................................ 158
Figure C-24: Launching the Recovery Tool............................................................................ 159
Figure C-25: Auto Recovery Environment for Windows ....................................................... 159
Figure C-26: Building the Auto Recovery Partition................................................................ 160
Figure C-27: Factory Default Image Confirmation ................................................................. 160
Figure C-28: Image Creation Complete................................................................................... 161
Figure C-29: Press any key to continue.................................................................................. 161
Figure C-30: Partitions for Linux.............................................................................................. 163
Figure C-31: Manual Recovery Environment for Linux ......................................................... 164
Figure C-32: Access menu.lst in Linux (Text Mode).............................................................. 164
Figure C-33: Recovery Tool Menu ........................................................................................... 165
Figure C-34: Recovery Tool Main Menu.................................................................................. 166
Figure C-35: Restore Factory Default...................................................................................... 167
Figure C-36: Recovery Complete Window.............................................................................. 167
Figure C-37: Backup System.................................................................................................... 168
Figure C-38: System Backup Complete Window ................................................................... 168
Page XIII
Figure C-39: Restore Backup................................................................................................... 169
Figure C-40: Restore System Backup Complete Window..................................................... 169
Figure C-41: Symantec Ghost Window ................................................................................... 170
Figure C-42: Disable Automatically Restart............................................................................ 177
AFL2-W10A-N28
Page XIV
AFL2-W10A-N28
List of Tables
Table 1-1: LED Indicators ..............................................................................................................5
Table 1-2: Function Key Descriptions..........................................................................................6
Table 1-3: System Specifications................................................................................................10
Table 3-1: DB-9 Connector Pinout..............................................................................................44
Table 6-1: BIOS Navigation Keys................................................................................................49
Table 7-1: Peripheral Interface Connectors............................................................................ 118
Table 7-2: Audio Connector (AUDIO1) Pinouts...................................................................... 119
Table 7-3: Battery Connector (CN2) Pinouts .......................................................................... 119
Table 7-4: Bluetooth USB Connector (BLUETOOTH1) Pinouts............................................ 119
Table 7-5: CRT Connector (VGA1) Pinouts............................................................................. 120
Table 7-6: Debug Connector (LPC_DEBUG1) Pinouts........................................................... 120
Table 7-7: EC Debug Connector (CN1) Pinouts...................................................................... 121
Table 7-8: HDD Connector (JSTAT1) Pinouts......................................................................... 121
Table 7-9: Hotkey LED Connector (HOTKEYLEDCN1) Pinouts............................................ 121
Table 7-10: Hotkey Connector (HOTKEYCN1) Pinouts.......................................................... 122
Table 7-11: LED Indicator Connector (LEDCN1) Pinouts...................................................... 122
Table 7-12: LVDS Connector (LCD1) Pinouts......................................................................... 123
Table 7-13: LVDS Backlight Connector (INVERTER1) Pinouts............................................. 123
Table 7-14: microSD Connector (MICRO_SD1) Pinouts........................................................ 123
Table 7-15: Mini USB Connector (MINI_USB1) Pinouts......................................................... 123
Table 7-16: Power Button Connector (PW_BT1) Pinouts...................................................... 124
Table 7-17: RFID USB Connector (RFID1) Pinouts................................................................. 124
Table 7-18: RFID COM Connector (RFID_COM1) Pinouts ..................................................... 124
Table 7-19: SATA LED Connector (JP5) Pinouts.................................................................... 124
Table 7-20: Speaker Connector (SPKR1) Pinouts.................................................................. 125
Table 7-21: SPI Flash Connector (SPI1) Pinouts.................................................................... 125
Table 7-22: EC SPI Flash Connector (JSPI2) Pinouts............................................................ 125
Table 7-23: Touch Panel Connector (TS1) Pinouts................................................................ 126
Table 7-24: Touch Panel Connector (TOUCH1) Pinouts........................................................ 126
Table 7-25: Type K Thermocouple Connector Pinouts.......................................................... 126
Table 7-26: Webcam Connector (CAMERA1) Pinouts ........................................................... 127
Page XV
Table 7-27: Webcam Microphone Connector (WEBCAM_DMIC1) Pinouts.......................... 127
Table 7-28: Rear Panel Connectors......................................................................................... 127
Table 7-29: Ethernet Connector (JP6) Pinouts....................................................................... 128
Table 7-30: Power Connector (DC_IN1) Pinouts .................................................................... 128
Table 7-31: RS-232 DB-9 Serial Ports (COM1) Pinouts.......................................................... 128
Table 7-32: RS-422/485 Serial Port (COM2) Pinouts .............................................................. 129
Table 7-33: DB-9 Connector Pinout......................................................................................... 129
Table 7-34: RS-232 RJ-45 Serial Ports (COM3) Pinouts......................................................... 129
Table 7-35: USB 2.0 Connectors (USB1) Pinouts................................................................... 130
Table 7-36: USB 3.0 Connectors (USB3_1) Pinouts............................................................... 130
Table 7-37: DisplayPort Connector (DISPLAY_PORT1) Pinouts.......................................... 131
AFL2-W10A-N28
Page XVI
AFL2-W10A-N28
List of BIOS Menus
BIOS Menu 1: Main.......................................................................................................................50
BIOS Menu 2: Advanced..............................................................................................................52
BIOS Menu 3: ACPI Configuration..............................................................................................52
BIOS Menu 4: RTC Wake Settings..............................................................................................53
BIOS Menu 5: CPU Configuration...............................................................................................55
BIOS Menu 6: SATA Configuration.............................................................................................56
BIOS Menu 7: USB Configuration...............................................................................................57
BIOS Menu 8: Super IO Configuration........................................................................................58
BIOS Menu 9: Serial Port n Configuration Menu.......................................................................59
BIOS Menu 10: Hardware Health Configuration........................................................................62
BIOS Menu 11: Serial Port Console Redirection.......................................................................63
BIOS Menu 12: iEi Feature...........................................................................................................64
BIOS Menu 13: Chipset................................................................................................................65
BIOS Menu 14: Northbridge Chipset Configuration..................................................................66
BIOS Menu 15: Internal IGD Configuration................................................................................66
BIOS Menu 16: South Bridge Configuration..............................................................................68
BIOS Menu 17: Boot.....................................................................................................................69
BIOS Menu 18: Security...............................................................................................................71
BIOS Menu 19: Exit.......................................................................................................................72
BIOS Menu 20: IEI Feature........................................................................................................ 162
Page XVII
AFL2-W10A-N28 Panel PC
Chapter
1
1 Introduction
Page 1
1.1 Overview
AFL2-W10A-N28 Panel PC
Figure 1-1: AFL2-W10A-N28 Flat Bezel Panel PC
The AFL2-W10A-N28 is an Intel® Atom™ N2800 dual-core processor powered flat bezel
panel PC with a rich variety of functions and peripherals. The AFL2-W10A-N28 is
designed for easy and simplified integration into kiosk and point-of-sales (POS)
applications.
An Intel® NM10 chipset ensures optimal memory, graphics, and peripheral I/O support.
The system comes with two 2.0 GB of DDR3 SO-DIMMs ensuring smooth data
throughputs with reduced bottlenecks and fast system access.
Three serial ports, two external USB 2.0 ports and two external USB 3.0 ports ensure
simplified connectivity to a variety of external peripheral devices. Wi-Fi capabilities and
one RJ-45 Ethernet connector provide the system with smooth connection to an external
LAN. An optional MSR card reader can equip the system for scanning credit cards,
identification cards, loyalty cards, gift cards, and more.
Page 2
AFL2-W10A-N28 Panel PC
1.1.1 Features
The AFL2-W10A-N28 features are listed below:
Flat-bezel LCD with LED backlight
1.86 GHz Intel® Atom™ N2800 dual-cor e processor
One 204-pin DDR3 SO-DIMM slot (system max. 4 GB) preinstalled with 2 GB
memory
Projected capacitive type and 5-wire resistive type touchscreens supported
Wi-Fi 802.11b/g/n 2T2R high speed wireless
Built-in 2-megapixel camera with AF, AE and AWB capabilities
Built-in two 1.5 W speakers and digital microphone
Optional RFID reader
IP 64 compliant front panel
1.2 External Overview
1.2.1 Front Panel
The front side of the AFL2-W10A-N28 is a flat bezel panel TFT LCD screen surrounded by
a PC/ABS plastic frame.
Figure 1-2: Front View
Page 3
1.2.1.1 LED Indicators
There are several LED indicators located along the bottom of the LCD screen (7Figure
1-3).
Figure 1-3: LED Indicators
AFL2-W10A-N28 Panel PC
The descriptions of each LED indicator are listed below.
LED Indicator Description
Power
Off: power cord not attached or power supply failure
Blinking amber: the system is connected to a power
source and is ready to be turned on.
Solid blue: the system is turned on.
Power on/off by the hot keys. See
AT/ATX Mode
AT: the system is in AT power mode
ATX: the system is in ATX power mode
Controlled by the AT/ATX power m ode switch.
CPU Temperature Alert
Blue: CPU temperature is normal.
Red: CPU temperature is too high.
Wi-Fi
On: the Wi-Fi module is enabled
Off: the Wi-Fi module is disabled.
Controlled by the BIOS. See Section
RFID
On: the optional RFID reader is enabled
Off: the optional RFID reader is disabled.
Controlled by the hot keys. See
7Table 1-3
74.5.2
8Table 1-3
Page 4
AFL2-W10A-N28 Panel PC
Bluetooth
Microphone
Audio Mute
Mini USB
Function
LCD On/Off
Audio Volume Down
Audio Volume Up
On: the Bluetooth module is enabled.
Off: the Bluetooth module is disabled.
Controlled by the BIOS. See Section
84.5.2
On: the digital microphone is enabled
Off: the digital microphone is disabled.
Controlled by the BIOS. See Section
84.5.2
On (solid red): the audio is turned off
Off: the audio is turned on
Controlled by the hot keys. See
8Table 1-3
On: the Mini USB 2.0 module is enabled
Off: the Mini USB 2.0 module is disabled.
Controlled by the hot keys. See
8Table 1-3
Shows the status of the function keys below the LED
indicators. Blinks when the corresponding button is
pushed.
Brightness Down
Brightness Up
Table 1-1: LED Indicators
WARNING:
If the CPU temperature alert LED shows in red, the user must lower the
environments temperature or close some running applications to cool
down the CPU.
Page 5
1.2.1.2 Function Keys
The function keys are located under the bottom right hand corner of the LCD screen
(
8Figure 1-4).
Figure 1-4: Function Keys
AFL2-W10A-N28 Panel PC
The function keys are described in
8Table 1-3:
Key Combination Function Key Description
Fn
Fn + LCD On/Off
Fn + Audio Volume Down
Fn + Audio Volume Up
Fn + Brightness Down
Fn + Brightness Up
Function key.
Enable/Disable RFID
Mute audio
Enable/Disable camera
Enable/Disable Mini USB or microSD
Power On/Off
Note: To power on the system, hold down the Fn +
Brightness Up buttons for six seconds. To power down the
system, hold down the Fn + Brightness Up buttons for
eight seconds.
Table 1-2: Function Key Descriptions
Page 6
AFL2-W10A-N28 Panel PC
1.2.2 Rear Panel
The rear panel provides access to retention screw holes that support VESA mounting. The
HDD bay is protected by the HDD cover. Refer to
Figure 1-5: Rear View
1.2.3 Bottom Panel
8Figure 1-5.
The bottom panel of the AFL2-W10A-N28 has the following connectors and switches
(
8Figure 1-6):
1 x 9 V ~ 36 V DC input power jack
1 x Audio line-out jack
1 x AT/ATX switch
1 x Clear CMOS switch
1 x DisplayPort connector
6 x Function keys
1 x GbE RJ-45 connector
1 x Digital microphone
1 x Power button
1 x Reset button
1 x RS-232 DB-9 connector (COM1)
1 x RS-232 RJ-45 connector (COM3)
Page 7
1 x RS-422/485 RJ-45 connector
2 x USB 2.0 connectors
2 x USB 3.0 connectors
AFL2-W10A-N28 Panel PC
Figure 1-6: Bottom Panel
1.2.4 Left Side Panel
The left side panel of the AFL2-W10A-N28 has a temperature sensor (8Figure 1-7).
Page 8
Figure 1-7: Left Side Panel
AFL2-W10A-N28 Panel PC
1.3 Internal Overview
The AFL2-W10A-N28 has the following components installed internally:
1 x Motherboard
1 x 2.0 GB 1066 MHz DDR3 SO-DIMM
1 x 802.11b/g/n wireless LAN module
1.4 System Specifications
The technical specifications for the AFL2-W10A-N28 systems are listed in 8Table 1-4.
Specification AFL2-W10A-N28
LCD Size 10.2" (16:9)
Max. Resolution 1024 (W) x 600 (H)
Brightness (cd/m2) 400
Contrast Ratio 400:1
LCD Color 262K
Pixel Pitch (H x V) (mm) 0.2175 (H) x 0.2175 (V)
Viewing Angle (H-V) 140° / 120°
Backlight LED backlight (MTBF: 30,000 hrs)
Touchscreen Projected capacitive type and 5-Wire resistive type supported
CPU 1.86 GHz Intel® Atom™ N2800 dual-core processor
Chipset Intel® NM10
Ethernet Realtek RTL8111E PCIe GbE controller support ASF2.0
Memory Preinstalled one 204-pin 1066 MHz 2 GB DDR3 SO-DIMM (max. 4 G)
HDD 2.5" SATA 3Gb/s HDD bay
Audio Realtek ALC892 HD Audio codec (Line-out)
Speaker AMP 1.5 W + 1.5 W (built-in stereo speakers)
Camera 2-megapixel camera with low light function
Microphone Digital microphone located on the bottom of the front frame
Wireless 1 x Wireless LAN 802.11 b/g/n module (PCIe Mini card)
Bluetooth Optional internal USB interface, Bluetooth V2.0+EDR
RFID Reader EM 125 KHz or MIFARE 13.56 MHz card reader (optional)
MSR Card Reader MSR card reader (optional)
Page 9
OSD Function LCD on/off, brightness up/down, volume up/down, Hot Key
Construction Material PC+ABS plastic front frame
Mounting VESA 75 mm x 75 mm (Panel, Wall, Rack, Stand or Arm)
Front Panel Color Black
Weight (N/G) 2.5 kg / 4.02 kg
Dimensions (W x H x D) 280 mm x 198 mm x 51 mm
Operating Temperature -20ºC ~ 45ºC
Storage Temperature -20ºC ~ 60ºC
Humidity 10% ~ 95% (no-condensing)
IP level IP 64 compliant front panel
Power Supply 65 W power adapter
Input: 100 V AC ~ 240 V AC @ 50 / 60 Hz
Output: 19 V DC
Power Requirement 9 V ~ 36 V DC
AFL2-W10A-N28 Panel PC
Power Consumption 19 V @ 1.5 A (Intel® Atom™ N2800 CPU with 2 GB DDR3 memory)
Safety/EMC CE, FCC
I/O Ports and Switches 1 x RS-232 (DB-9 connector)
1 x RS-232 (RJ-45 connector)
1 x RS-422/485 (RJ-45 connector)
1 x GbE LAN (RJ-45 connector)
2 x USB 2.0 connectors
2 x USB 3.0 connectors
1 x Mini USB 2.0 connector (on front panel)
1 x microSD card slot (on front panel)
1 x Audio line-out jack
1 x DisplayPort connector
1 x Power switch
1 x AT/ATX switch
1 x Reset button
1 x Clear CMOS button
1 x 9 V ~ 36 V DC input jack
Table 1-3: System Specifications
Page 10
AFL2-W10A-N28 Panel PC
1.5 Dimensions
The AFL2-W10A-N28 dimensions are shown below.
Width: 280 mm
Height: 198 mm
Depth: 51 mm
Figure 1-8: AFL2-W10A-N28 Dimensions (mm)
Page 11
AFL2-W10A-N28 Panel PC
Chapter
2
2 Unpacking
Page 12
Loading...
