ICYBOX IB-RPA100 Instructions

Quick installation guide IB-RPA100

VESA® adapter for Raspberry Pi® wall mount supported cases

Schnellinstallationsanleitung IB-RPA100

VESA®-Adapter für Raspberry Pi® Gehäuse mit

Wandhalterungsvorbereitung

Safety information

Please read carefully the following information to prevent in­juries, damage to material and device as well as data loss:

Warning levels

Signal words and safety codes indicate the warning level and provide
immediate information in terms of the probability of occurrence as well
as the type and severity of the consequences if the measures to prevent
hazards are not complied with.

DANGER

WARNING

CAUTION

IMPORTANT

disrupt operative processes.

1. Risk of electrical shock

WARNING

• Read the operating instructions prior to use

• Make sure the device has been de-energised prior to working on it

• Do not remove contact protection panels

• Avoid contact with conducting parts

• Do not bring plug contacts in contact with pointed and metal objects

• Use in intended environments only

• Operate the device using a power unit meeting the specifications of
the type plate only!

• Keep the device/power unit away from humidity, liquid, vapour
and dust

• Do not modify the device

• Do not connect the device during thunderstorms

• Approach specialist retailers if you require repairs

Warns of a directly hazardous situation
causing death or serious injury.

Warns of a potentially hazardous situation
that may cause death or serious injury.

Warns of a potentially hazardous situation
that may cause minor injury.

Warns of a potential situation that may
cause material or environmental damage and

Contact with parts conducting electricity

Risk of death by electrical shock

Safety information

2. Hazards during assembly (if intended)

CAUTION

assembly (if intended)

• Read the operating instructions prior to assembly

• Avoid coming into contact with sharp edges or pointed components

• Do not force components together

• Use suitable tools

• Use potentially enclosed accessories and tools only

3. Hazards caused by a development of heat

IMPORTANT

Overheating and failure of the device/power unit

• Prevent externally heating up components and ensure an exchange
of air

• Do not cover the fan outlet and passive cooling elements

• Avoid direct sunlight on the device/power unit

• Guarantee sufficient ambient air for the device/power unit

• Do not place objects on the device/power unit

4. Hazards caused by very small parts and packaging

WARNING

• Keep small parts and accessories away from children

• Store/dispose of plastic bags and packaging in an area that is
inaccessible to children

• Do not hand over small parts and packaging to children

5. Potential data loss

IMPORTANT

• Always comply with the information in the operating instructions/Manual

• Exclusively use the product once the specifications have been met

• Back up data prior to commissioning

• Back up data prior to connecting new hardware

• Use accessories enclosed with the product

Sharp components

Potential injuries to fingers or hands during

Insufficient device/power unit
ventilation

Risk of suffocation

Risk of death by suffocation or swallowing

Data lost during commissioning

Potentially irreversible data loss

Safety information

6. Cleaning the device

IMPORTANT

• Disconnect the device prior to cleaning

• Aggressive or intense cleaning agents and solvents are unsuitable

• Make sure there is no residual moisture after cleaning

• We recommend cleaning devices using a dry, anti-static cloth

7. Disposing of the device

IMPORTANT

Potential environmental pollution caused by components, recycling circle
interrupted

please return it to the retailer or your local waste disposal and recycling
point.

If you have any questions, please do not hesitate to contact our support
at [e-mail] or visit our website at www.raidsonic.de.

Harmful cleaning agents

Scratches, discolouration, damage caused by
moisture or short circuit in the device

Environmental pollution, unsuitable
for recycling

This icon on product and packaging indicates that this prod­uct must not be disposed of as part of domestic waste. In
compliance with the Waste Electrical and Electronic Equip­ment Directive (WEEE) this electrical device and potentially
included batteries must not be disposed of in conventional,
domestic waste or recycling waste. If you would like to
dispose of this product and potentially included batteries,
