ICYBOX IB-CR403-C3 Instructions

Technology GmbH
ICY BOX
IB-CR403-C3
USB 3.2 (Gen 1) Type-C® CFast
www.icybox.de/en/
Key features
• High-performance multi-LUN card reader
• USB 3.2 (Gen 1) Type-C® with up to 5 Gbit/s
• CFast® 2.0 with up to 6 Gbit/s
• SD/microSD 4.0 (UHS-II) with up to 300 MB/s
• High-grade aluminium housing
• Plug & Play
Technical data
Model Article no. EAN code Brand Colour Material Interface to host computer
Card slots
Card capacity
IB-CR403-C3 60862 4250078171942 ICY BOX Black Aluminium, plastic USB 3.2 (Gen 1)* Type-C *USB 3.2 (Gen 1) is equivalent to USB 3.1 (Gen 1) and USB 3.0.
®
2.0 (SATA III)
1x CFast 1x microSD 4.0 (UHS-II) 1x SD 4.0 (UHS-II) Up to 2 TB
Packing content
IB-CR403-C3, Manual (cards not included)
Transfer rate USB 3.2 (Gen 1) Transfer rate CFast® 2.0 Transfer rate SD/microSD 4.0 Plug & Play LED
®
Power supply Operating system System requirements
Up to 5 Gbit/s Up to 6 Gbit/s Up to 300 MB/s Yes Power and access USB powered
®
®
, macOS
Windows One free USB 3.2 (Gen 1) Type-C® port or higher, alternatively one free Thunderbolt
3 port
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • info@raidsonic.de • www.icybox.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.
Technology GmbH
ICY BOX IB-CR403-C3 USB 3.2 (Gen 1) Type-C® CFast and SD card reader
www.icybox.de/en/
Small tool for real professionals
For professional photographers, CFast 2.0 is an important memory card standard that can transfer large amounts of data at up to 6 Gbps. SATA III is used for this purpose. The ICY BOX® card reader supports CFast 2.0, allowing high-resolution content to be stored quickly and easily on the laptop.
Solution for common memory cards
The high-quality aluminum housing offers even more possibilities. With the SD/microSD 4.0 (UHS-II) slot data is transferred with a speed of up to 300 MB/s to the notebook or PC. So with the IB-CR403-C3 from ICY BOX® you have a card reader that covers the most common card formats.
Card connection made easy
The ICY BOX® card reader IB-CR403-C3 supports Multi-LUN. This allows simultaneous access to all insert­ed cards. Reading, writing and moving data is amazingly easy - and thanks to USB 3.2 Type-C with up to 5 Gbit/s it’s really fast.
®
(Gen 1)
Logistical data
Packing unit: Total weight: Gross weight: (with packing): Net weight:
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • info@raidsonic.de • www.icybox.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.
60 pcs. / carton
8.53 kg
0.127 kg
0.062 kg
Dimension/carton: Dimension (with packing): Dimension of article: Country of origin:
440x330x280 mm 25x102x200 mm 74x63x15 mm China
